遥控器规格 型 号 电池型号 信号接收范围 使用环境 XbotGo RC� CR���� ��m -�°C ~ ��°C （��°F ~ ���°F） 遥控器规格 快速入门指南 基本功能 使用遥控器 RC1 XbotGo Remote Controller 使用说明书 尊敬的用户，首先衷心感谢您选择 XbotGo！ 为了更好的使用本产品，请您务必在使用之前仔细阅读使用说明，并保留本手册以供日后查询。若您在使用过程中有任何问题，请及时和我们取 得联系，我们有专业人员为您答疑解惑，祝您使用愉快。 警告： 请仔细阅读所有的安全警告和使用说明，不遵守相关警告和说明很可能会导致触电、火灾或其他严重伤害。请保留所有警告和说 明事项，以备日后参考。 环境保护说明： · 认真遵守相关国家的废物处理的法律法规。电子电器用品不能按生活垃圾的方式处理。设备、附件和包装应为可回收部分。 · 禁止随意丢弃报废的机器设备。 快速入门指南 A. 打开电池仓盖，撕掉电池底部的绝缘塑料片，关闭电池仓盖。 B. 长按电源键�S开/关遥控器。 C. 开机后，点击功能选择键，进行功能选择切换。 D. 首次使用前需进行蓝牙配对。 · 长按遥控器电源键，遥控器开机后，"手机连接指示灯"为红色闪烁； · 靠近已开机的设备后，在XbotGo APP中选择XbotR-XXXXs，点击进行配对，连接 完成后，手机连接指示蓝色灯亮起。 撕掉 C A D� B E. 超出信号距离： 遥控器上出现红色菜单指示灯和圆环灯闪烁，此时遥控器链接断开，一分钟内重新进入 可接收范围遥控器蓝灯亮起自动恢复连接。 F. 休眠与关机： �S遥控器无任何操作进入休眠状态，在休眠状态下按下遥控器任意按键可进入到连接状 态。休眠超过五分钟后遥控器自动关机，按下开机键，开机后再次靠近设备后可重新连接。 注意事项 在使用过程中遥控器断开连接仅影响遥控器本身的使用，并不影响当前正在运行的程序， 如在使用过程中APP无法搜索到遥控器，可长按电源键三秒重置遥控器，重新进行配对连 接操作后即可恢复使用。 XbotGo RC1 遥控器 A. 电源键 B. 功能选择键 C. 确认键 D. 方向键（圆盘） E. 电池仓 C A E B D 拍照功能 · 按压功能选择键，切换至拍照功能； · 在拍照模式下，按压确认键拍摄照片。 转向功能 · 按压功能选择键，切换至转向功能； · 按压上、下、左、右方向键，镜头随相应操作转动方向。 注意 遥控器出现红色呼吸灯闪烁，蜂鸣器提醒，及APP出现报错、指令执行失 败等异常反馈，请对照APP端提示进行操作。 电池 注意事项 为了获得最佳的产品性能： 请勿使用不同类型的电池。 如果您不打算使用设备超过两个月，请勿将电池留在遥控器中。 电池处置： 请勿将电池作为未分类的城市垃圾处理。请参阅当地法律以正确处置电池。 关于遥控器的注意事项 打点功能（仅在摄像时可用） 通过手动标记拍摄过程的精彩时刻，自动生成的精彩集锦视频。 按下遥控器上的确认键，XbotGo APP会记录下打点时刻前后的视频 片段。按下打点键时，蓝色圆环灯闪烁，打点成功。 精彩片段可在 XbotGo App/云管理/云盘 查看。 D� 按钮和功能 在开始使用之前，请务必熟悉遥控器。 摄像功能 按压功能选择键，切换至摄像功能；在摄像功能模式下按压确认键，对拍摄状态进行控制。 · 遥控器端： A. 出现一下“滴”声响，进入摄像状状态。 B. 出现连续两下“滴滴”声响，提示此时摄像暂停或摄像未开启。 · APP端： �S蓝色提示蒙版，�S后蒙版自动消失。此时已进入摄像状态，可对应 操作指令查看拍摄状态。 Remote Controller Specifications Model: Battery Model: Signal Coverage Range: Temperature: XbotGo RC� CR���� ��m -�°C ~ ��°C （��°F ~ ���°F） Remote Controller Specifications Quick Start Guide Basic Functions Using the Remote Controller XbotGo Remote Controller User Manual We sincerely thank you for choosing XbotGo! To better use this product, please carefully read the instructions before use and keep this manual for future reference. If you have any questions, feel free to contact us. Our professionals will be happy to answer your questions and help. We wish you a pleasant experience. Warning: Please read all safety warnings and instructions carefully. Failure to comply may result in fire, electric shock, or other serious injuries. Please keep all warnings and instructions for future reference. Environmental Protection Instructions: · Comply with the waste disposal laws and regulations of relevant countries. Electronic devices should not be disposed of as household waste. Devices, accessories, and packaging should be recyclable. · Do not litter electronic wastes at will. Quick Start Guide A. Open the battery compartment cover, then remove the insulating plastic sheet from the bottom of the battery and close the battery compartment cover. B. Press and hold the power button for � seconds to turn on/off the remote controller. C. After turning on, press the function selection button to switch functions. D. Bluetooth pairing is required before the first use. · Press and hold the remote controller's power button. After the remote controller is powered on, the phone connection indicator flashes red. torn off C A D� B · Open XbotGo APP on your phone and select XbotR-XXXX in the XbotGo APP for pairing. After the connection is established, the phone connection indicator on the remote controller will turn into a solid blue. E. Exceed the signal range (�� meters): The red menu indicator light and the circular ring light on the remote control are flashing, indicating that the remote controller has been disconnected from the APP. If it returns to the reception range in less than � minute, the remote controller's blue light will turn on, and the connection will be automatically restored. XbotGo RC1 Remote Controller A. Power Button B. Function Selection Button C. Confirm Button D. Directional Buttons (Circular Disk) E. Battery Compartment E D� F. Sleep mode and Shutdown: The �S remote controller enters the dormant state without any operation. In the dormant state, press any button on the remote control to enter the connected state. After sleeping for more than five minutes, the remote control will automatically shut down, press the power button, and then close the device again after turning on to reconnect. Note: The disconnection of the remote controller during use will not affect the APP running on the phone. If the APP cannot find the remote controller during use, you can reset the remote controller by pressing the power button for � seconds, then perform the pairing again. Photo Function · Press the Function Selection button to switch to the photo mode; · In photo mode, press the confirm button to take photos. Steering Function · Press the Function Selection button to switch to the steering mode; · Press the up, down, left, and right directional buttons to rotate the gimball in the corresponding direction. Note If the remote controller's red breathing light flashes, the buzzer alerts, or if the APP displays errors, command execution failures, please follow the prompts on the APP side for operation. Battery The remote controller is equipped with a CR���� button battery. Notes For optimal product performance: · Please do not use different types of batteries. · If you do not intend to use the device for more than two months, please do not leave the battery in the remote controller. Battery Disposal: · Do not dispose of batteries as unsorted municipal waste. Please refer to local regulations for proper battery disposal. Notes on Remote Controller · The remote controller must be used within a range of �� meters from the device. · When the remote control signal is received, the App will provide pairing prompts. Mark Function (Available only during camera function mode) Manually mark the highlight moments during the game. It will for generating produce a highlight video of the game automatically online and upload to the cloud. Pressing the confirm button on the remote controller, XbotGo APP will record video s…
