2BG6CTS-150AAll in one Panel PC

1 / 9 PRODUCTSPECIFICATION ProductName：AllinonePanelPC ProductModel：TS-150ACBJ Version:V0 TECHTIONSMART Organizedby CheckedbyApprovedby Connie CUSTOMERAPPROVAL ApprovedbyComment 2 / 9 Contents 1、Features..............................................................................................4 2、PhysicalSpecifications........................................................................5-7 3、Productappearance................................................................................8 4、Sixviews.................................................................................................8 5、Installation................................................................................................9 3 / 9 DocumentRevisionHistory DateVersionDescriptionEditor 2024.03.28V0NewReleaseConnie 4 / 9 1 、Features •4:3宽屏，搭载高速智能安卓系统 4:3widescreen,equippedwithhigh-speedintelligentAndroidsystem •轻薄/美观/散热性强 Thin/beautiful/heatdissipation •整机半封闭式无风扇设计 Thewholemachineissemi-closedandfanlessdesign •IP65防尘防水标准（屏面） IP65dustproofandwaterproofstandard（frontscreen) •支持纵向和横向显示模式 Supportsportraitandlandscapedisplaymodes •全天候连续不间断运行24H Continuousoperation24hoursaday •整机采用铝合金与钣金材质制成 Thewholemachineismadeofaluminumalloyandsheetmetal. •具有良好的抗震性、抗冲击性，适应苛刻环境 Ithasgoodearthquakeresistanceandimpactresistance,andcanadapttoharsh environments. •支持RTC实时时钟、定时开关机、网络唤醒、RS232串口集控. SupportsRTCreal-timeclock,scheduledpoweronandoff,networkwake-up, andRS232serialportcentralizedcontrol. •应用场景：人工智能终端、自助服务终端等 Applicationscenarios:artificialintelligenceterminals,self-serviceterminals,etc. 5 / 9 2、PHYSICALSPECIFICATIONS No.Items Specifications 1MainparametersMainparameters 2ModelTS-150ACBJ 3ProducttypeAllinonePanelPC 4FrameAluminumframe+Sheetmetalbackshell/Black 5BrandTECHTION 6DisplayparametersDisplayparameters 7 LCDSize 15” 8 ActiveArea 304.128(H)×228.096(V)mm 9 Resolution 1024*768 10 ContrastRatio 3000:1 11 PictureAatio 4:3 12 ViewingAngle 89/89/89/89(Typ.)(CR≥10) 13 ResponseTime 18ms 14BacklightTypeE-LED 15 Brightness 300cd/m2 16 Lifespan 50000H 17 Protection IP65(frontscreen) 18TouchparametersTouchparameters 19TouchTypesCapacitive(G+G)--OpticalBonding 6 / 9 20ClicksCapacitive＞50milliontimes 21Surfacehardness6H 22TouchPoint10points 23TypeofglassChemicallystrengthenedglass 24Transmittance＞85% 25AndroidsolutionAndroidsolution 26CHIPRK3399 27CPUCortex-A72*2+A53*[email protected] 28GPUMali-T860 29NPU/ 30DDRDDR3-4G 31EMMC32G 32OSDefaultAndroid9.0（Android7.1/10.0optional) 33LAN10/100/1000M 34WiFi2.4G 35B/T4.1 36SystemupgradeUSB 37PortparametersPortparameters 38 ExternalConnectors EARPHONE*1，RJ45*1，USB3.0*1(OTG)，USB3.0*1，DC12*1， COM*1，Wifiantenna*1，HDMIOUT*1 39GraphSupportedFormatGraphSupportedFormat 40Videoformatmp4、mkv、wmv、mov、flv3 7 / 9 41PictureformatBMP、JPEG、PNG、GIF 42PowerconsumptionPowerconsumption 43Standbypower（w）≤0.5W 44Powerconsumption（w）≤15W 45SupplyVoltage（v）DC12V 46Audiooutputpower8Ω*2W 47DimensionsDimensions 48PackingSize(mm)435*356*152mm 49ProductDimensions(mm)352x279.5x44.9mm 50NW(kg)3.5kg 51GW(kg)4.7kg 52Wallmountingholes(mm)100*100（M4*8mm*4pcs） 53Installationwall-mounted/table-top/hanging 54AccessoriesAccessories 55PowerCable*1 56Poweradapter*112V/4A(AC100-240V50/60Hz) 57Wifiantenna*1 58EnvironmentEnvironment 59 Operatingtemperature -10°C~60°C 60Operatinghumidity10%～90%RHNon-Condensing 61 Storagetemperature -20°C~70°C 8 / 9 62 Storagehumidity 10%~90%RHNon-Condensing 3 、产品外观图 /ProductAppearance 4、六视图/Sixviews（mm) 9 / 9 5、安装方式/Installation EmbeddedWall-mount Table-top Table-top Hanging FCC Warning This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any inte rference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interferenceto radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio/TV technician for help. Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body.

Covered Equipment Identification Letter For Certification Service in the USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Section 2.911(d)(5)(ii) of the Commission’s Rules (47 C.F.R.) we attest as follows: We, applicant Company Name: Shenzhen Techtion Smart Electronics Co., Ltd Address: Room 902, 8th Floor, Unit 1, Building No. 2, Xintianxia Chengyun Factory District, Vanke City Community, Bantian Street, Longgang District, Shenzhen, China Phone: +86-13457341663 certify that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. FCC ID: 2BG6CTS-150A If you have any questions, please feel free to contact us at the address shown below. Sincerely, Signature Date:2024-07-08 Name / Title: DEBIN ZHANG / Manager Company: Shenzhen Techtion Smart Electronics Co., Ltd Address: Room 902, 8th Floor, Unit 1, Building No. 2, Xintianxia Chengyun Factory District, Vanke City Community, Bantian Street, Longgang District, Shenzhen, China Phone: +86-13457341663 Fax: N/A E-Mail: [email protected]

Confidentiality Request Letter For Certification Service in the USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we request confidentiality for the documentation of the following products: FCC ID Model name 2BG6CTS-150A TS-150A, TS-070A, TS-070P, TS-080A, TS-080P, TS-101A, TS-101P, TS-104A, TS-104P, TS--116A, TS--116P, TS-- 120A, TS--120P, TS--121A, TS--121P, TS--133A, TS--133P, TS--150A, TS--150P, TS--156A, TS--156P, TS--170A, TS-- 170P, TS--173A, TS--173P, TS--185A, TS--185P, TS--190A, TS--190P, TS--195A, TS--195P, TS--215A, TS--215P, TS-- 238A, TS--238P, TS--270A, TS--270P, TS--320A, TS--320P, TS--430A, TS--430P, TS--550A, TS--550P For the products listed above, we request permanent confidentiality for all applicable exhibits as there are: • the Operational Description • the Block Diagram • the Schematics • the Part List • the Tune up Information The above listed exhibits contain trade secrets and proprietary information that could be of benefit to our competitors. If you have any questions, please feel free to contact us at the address shown below. Sincerely, Signature Date:2024-07-08 Name / Title: DEBIN ZHANG / Manager Company: Shenzhen Techtion Smart Electronics Co., Ltd Address: Room 902, 8th Floor, Unit 1, Building No. 2, Xintianxia Chengyun Factory District, Vanke City Community, Bantian Street, Longgang District, Shenzhen, China Phone: +86-13457341663 Fax: N/A E-Mail: [email protected]

Page 1 of 1 Rev.2.0 Shenzhen Techtion Smart Electronics Co., Ltd. WIFI Channel 12 and 13 Declaration Letter We declare the equipment identified below with regards to Channel 12 and 13 capabilities for FCC ID: 2BG6CTS-150A Declaration Product hardware does not have the capability to operate on Channel 12 and 13. Product hardware has the capability to operate on Channel 12 and 13. However, these two channels will be disabled via software and will not be accessible to user. Product hardware has the capability to operate on Channel 12 and 13. However, all the operated channels can’t be changed in the RF parameter via software. All channels have complied with all of the requirements sets out in FCC Part 15.247. Product hardware has the capability to operate on WiFi Channel 12 and 13, and meets the requirements of KDB 594280 D01 v02r01. Please note: 1.) By default, this device operates in a mode that is compliant with the U.S. requirements. 2.) This device will also use supplemental information such as geo- location data to determine that it is operating outside the U.S., if necessary, to change its power. Such supplemental data will be derived from the following: Global Navigation Satellite System (GNSS)7 sensors in the device Mobile Country Code (MCC),8 or MCC with a Mobile Network code (MNC), received from a CMRS9 carrier and received directly by a receiver on the device Country information derived from multiple adjacent access points (for example using IEEE Std 802.11d provisions) may be permitted on case-by-case basis Other suitable geo-location data based on IP addresses or other reliable source. Name / Title: DEBIN ZHANG / Manager Signature: Phone: +86-13457341663 Email: [email protected] Date: 2024-07-08

Shenzhen Techtion Smart Electronics Co., Ltd. Room 902, 8th Floor, Unit 1, Building No. 2, Xintianxia Chengyun Factory District, Vanke City Community, Bantian Street, Longgang District, Shenzhen, China Date: July. 08, 2024 FCC ID: 2BG6CTS-150A Model Number: TS-150A, TS-070A, TS-070P, TS-080A, TS-080P, TS-101A, TS-101P, TS-104A, TS-104P, TS--116A, TS--116P, TS--120A, TS--120P, TS--121A, TS--121P, TS--133A, TS--133P, TS--150A, TS--150P, TS--156A, TS--156P, TS--170A, TS--170P, TS--173A, TS--173P, TS--185A, TS--185P, TS--190A, TS--190P, TS--195A, TS--195P, TS--215A, TS--215P, TS--238A, TS--238P, TS--270A, TS--270P, TS--320A, TS--320P, TS--430A, TS--430P, TS--550A, TS--550P To: Federal Communication Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21048 To Whom It May Concern, We, Shenzhen Techtion Smart Electronics Co.,Ltd hereby declare that our product (All in one Panel PC) Model Number: TS-150A, TS-070A, TS-070P, TS-080A, TS-080P, TS-101A, TS-101P, TS-104A, TS-104P, TS--116A, TS--116P, TS--120A, TS--120P, TS--121A, TS--121P, TS--133A, TS--133P, TS--150A, TS--150P, TS--156A, TS--156P, TS--170A, TS--170P, TS--173A, TS--173P, TS--185A, TS--185P, TS--190A, TS--190P, TS--195A, TS--195P, TS--215A, TS--215P, TS--238A, TS--238P, TS--270A, TS--270P, TS--320A, TS--320P, TS--430A, TS--430P, TS--550A, TS--550P board, Schematic, Hardware version, Software version, structure and internal photos are same, named and appearance differently due to marketing purposes. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely, (Signed) Name / Title: DE BIN ZHANG / Manager Company: Shenzhen Techtion Smart Electronics Co., Ltd. Address: Room 902, 8th Floor, Unit 1, Building No. 2, Xintianxia Chengyun Factory District, Vanke City Community, Bantian Street, Longgang District, Shenzhen, China Phone: +86-13457341663 Fax: N/A E-Mail: [email protected]

FCC ID:2BG6CTS-150A Fig. 1 Fig. 2 FCC ID:2BG6CTS-150A Fig. 3 Fig. 4 Antenna FCC ID:2BG6CTS-150A Fig. 5 Fig. 6 FCC ID:2BG6CTS-150A Fig. 7 Fig. 8 FCC ID:2BG6CTS-150A Fig. 9

_____________________________________________________________________________________________________ LABEL AND LOCATION (Size: L3.48cm x 2.98cm) Label Location All in one Panel PC Model : TS-150ACBJ Input: DC 12.0V/4.0A FCC ID: 2BG6CTS-150A

FCC ID:2BG6CTS-150A Fig. 1 Fig. 2 FCC ID:2BG6CTS-150A Fig. 3 Fig. 4 FCC ID:2BG6CTS-150A Fig. 5 Fig. 6 FCC ID:2BG6CTS-150A Fig. 7 Fig. 8 FCC ID:2BG6CTS-150A Fig. 9

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‟an District, Shenzhen, China RF Exposure evaluation Report Reference No. ................. : FCC ID. ......................................... : CTA24061300104 2BG6CTS-150A Compiled by ( position+printed name+signature): File administrators Jinghua Xiao Supervised by ( position+printed name+signature): Test Engineer Lushan Kong Approved by ( position+printed name+signature) . : Manager Eric Wang Date of issue .................................... : Jun.18, 2024 Representative Laboratory Name ....................................................... : Shenzhen CTA Testing Technology Co., Ltd. Address ......................................... : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao„an District, Shenzhen, China Applicant’s name ............................ : Shenzhen Techtion Smart Electronics Co.,Ltd Address ............................................ : Room 902, 8th Floor, Unit 1, Building No. 2, Xintianxia Chengyun Factory District, Vanke City Community, Bantian Street, Longgang District, Shenzhen, China Test specification ........................ : Standard ........................................ : 47CFR §1.1310 Basis and purpose 47CFR §2.1091 Radiofrequency radiation exposure evaluation: mobile devices TRF Originator .............................. : Shenzhen Global Test Service Co.,Ltd. Master TRF ................................... : Dated 2014-12 Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .................. : All in one Panel PC Trade Mark .................................... : N/A Manufacturer ................................. : Shenzhen Techtion Smart Electronics Co.,Ltd Model/Type reference ................... : TS-150A Listed Models .............................. : Please refer to page two Hardware Version ........................ : N/A Software Version ........................... : N/A Rating ............................................ : DC 12.0V/4.0A by Adapter Result ............................................ : PASS Report No.: CTA24061300104 Page 2 of 11 T E S T R E P O R T Test Report No. : CTA24061300104 Jun. 18, 2024 ______________________________________________________________________________________________ Date of issue Equipment under Test : All in one Panel PC Model /Type : TS-150A Listed model : TS-070A, TS-070P, TS-080A, TS-080P, TS-101A, TS-101P, TS-104A, TS-104P, TS--116A, TS--116P, TS--120A, TS--120P, TS--121A, TS--121P, TS--133A, TS--133P, TS--150A, TS--150P, TS--156A, TS--156P, TS--170A, TS--170P, TS--173A, TS--173P, TS--185A, TS--185P, TS--190A, TS--190P, TS--195A, TS--195P, TS--215A, TS--215P, TS--238A, TS--238P, TS--270A, TS--270P, TS--320A, TS--320P, TS--430A, TS--430P, TS--550A, TS--550P Applicant : Shenzhen Techtion Smart Electronics Co.,Ltd Address : Room 902, 8th Floor, Unit 1, Building No. 2, Xintianxia Chengyun Factory District, Vanke City Community, Bantian Street, Longgang District, Shenzhen, China Manufacturer : Shenzhen Techtion Smart Electronics Co.,Ltd Address : Room 902, 8th Floor, Unit 1, Building No. 2, Xintianxia Chengyun Factory District, Vanke City Community, Bantian Street, Longgang District, Shenzhen, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA24061300104 Page 3 of 11 Contents 1. SUMMARY .................................................................................................................................................... 4 1.1 EUT CONFIGURATION .................................................................................................................................... 4 1.2 PRODUCT DESCRIPTION ................................................................................................................................ 4 2. TEST ENVIRONMENT .................................................................................................................................. 4 2.1 ADDRESS OF THE TEST LABORATORY .............................................................................................................. 5 2.2 TEST FACILITY ............................................................................................................................................... 5 2.3 ENVIRONMENTAL CONDITIONS ........................................................................................................................ 5 2.4 STATEMENT OF THE MEASUREMENT UNCERTAINTY .......................................................................................... 5 3. METHOD OF MEASUREMENT ................................................................................................................... 6 3.1 APPLICABLE STANDARD ................................................................................................................................. 6 3.2 REQUIREMENT .............................................................................................................................................. 6 3.3 LIMIT ............................................................................................................................................................. 6 3.4 MPE CALCULATION METHOD ......................................................................................................................... 7 3.5…

Text truncated - open the document above for the full version.

www.delincomm.com www.elincomm.com FAR109-2.4G-SZ-N 2023 v1.0 versioe 第 1 页 共 7 页 客户名称： Customer 供 应 商： Supplier 供 应 商 品 牌 ： brand of supplier 产 品 名 称 Production Name 产 品 型 号 ： ProductionNumber 产品规格承认书 Specification For Approval Shenzhen Techtion Smart Electronics Co.,Ltd DeliNCOMM DeliNCOMM 棒状天线 RG178 AR109-2.4~5.8G-SZ-N Address :Shenzhou Computer Building, Beier Road, Longgang District, Shenzhen www.delincomm.com FAR109-2.4G-SZ-N 2023 v1.0 versioe 第 2 页 共 7 页 规格书目录(Directory) 电气参数（Electrical parameters) ― ― ― ― ― ― ― ― ― 4 机械参数(Mechanical parameters) ― ― ― ― ― ― ― ― ― ― 4 工作/储存温度（Operating/ Storage Temperature） ― ― ― ― ―4 结构图纸（Structural drawings) ― ― ― ― ― ― ― ― ― ― ― 5 环境与可靠性试验(Environmental and reliability testing) ―--6.7 测试设备(Test equipment) ― ― ― ― ― ― ― ― ― ― ― ―8 测试参数(Testing Parameters） ― ― ― ― ― ― ― ― ― ― ― 9 . 10 www.delincomm.com FAR109-2.4G-SZ-N 2023 v1.0 versioe 第 3 页 共 7 页 电气参数（Electrical parameters）: Frequency 频率范围 2.4~5.8GHz Impedance 特性阻抗 50Ω S.W.R. 电压驻波比 ≤2.0 Antenna Gain 增益 2.0dBi±0.5 Polarization 极化形式 vertical polarization Return Loss 回波损耗 -9.2dB MAX 机械参数(Mechanical parameters)： Antenna Colour 天线颜色 black RF Cable Model 射频线型号 RG178 Connect Type 接口方式 SMA 工作/储存温度（Operating/ Storage Temperature）： Operating Temperature 工作温度 -40~85°C Storage Temperature 储存温度 -40~85°C www.delincomm.com FAR109-2.4G-SZ-N 2023 v1.0 versioe 第 4 页 共 7 页 结构图纸（Structural drawings)： www.delincomm.com FAR109-2.4G-SZ-N 2023 v1.0 versioe 第 5 页 共 7 页 测试设备(Test equipment): www.delincomm.com FAR109-2.4G-SZ-N 2023 v1.0 versioe 第 6 页 共 7 页 测试参数(Testing Parameters） 阻波比&回波损耗(V.S.W.R&Ruturn Loss) www.delincomm.com FAR109-2.4G-SZ-N 2023 v1.0 versioe 第 7 页 共 7 页

FCC ID:2BG6CTS-150A 1 Case No. : CTA24061300102 Ambient Condition: 23 °C, 55 %RH According Standard: ■Part15C Test Date: 2024.5.24 Test Engineer: Evan ouyang Appendix B.1: DTS Bandwidth Test Result TestMode Antenna Freq(MHz) DTS BW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict BLE Ant1 2402 0.676 2401.680 2402.356 0.5 PASS 2440 0.664 2439.680 2440.344 0.5 PASS 2480 0.684 2479.672 2480.356 0.5 PASS FCC ID:2BG6CTS-150A 2 Test Graphs BLE_Ant1_2402 BLE_Ant1_2440 BLE_Ant1_2480 FCC ID:2BG6CTS-150A 3 FCC ID:2BG6CTS-150A 4 Appendix B.2: Occupied Channel Bandwidth Test Result TestMode Antenna Freq(MHz) OCB [MHz] FL[MHz] FH[MHz] BLE Ant1 2402 1.0600 2401.5024 2402.5624 2440 1.0632 2439.4974 2440.5606 2480 1.0624 2479.4967 2480.5591 FCC ID:2BG6CTS-150A 5 Test Graphs BLE_Ant1_2402 BLE_Ant1_2440 BLE_Ant1_2480 FCC ID:2BG6CTS-150A 6 FCC ID:2BG6CTS-150A 7 Appendix B.3: Maximum conducted output power Test Result Peak TestMode Antenna Freq(MHz) Conducted Peak Powert[dBm] Conducted Limit[dBm] Verdict BLE Ant1 2402 8.66 ≤30 PASS 2440 7.61 ≤30 PASS 2480 7.01 ≤30 PASS FCC ID:2BG6CTS-150A 8 Appendix B.4: Maximum power spectral density Test Result TestMode Antenna Freq(MHz) Result[dBm/3kHz] Limit[dBm/3kHz] Verdict BLE Ant1 2402 -5.41 ≤8.00 PASS 2440 -6.37 ≤8.00 PASS 2480 -7.09 ≤8.00 PASS Note： 1. The Duty Cycle Factor and RBW Factor is compensated in the graph. FCC ID:2BG6CTS-150A 9 Test Graphs BLE_Ant1_2402 BLE_Ant1_2440 BLE_Ant1_2480 FCC ID:2BG6CTS-150A 10 FCC ID:2BG6CTS-150A 11 Appendix B.5: Band edge measurements Test Result TestMode Antenna ChName Freq(MHz) RefLevel[dBm] Result[dBm] Limit[dBm] Verdict BLE Ant1 Low 2402 8.09 -49.02 ≤-11.91 PASS High 2480 6.08 -49.31 ≤-13.92 PASS FCC ID:2BG6CTS-150A 12 Test Graphs BLE_Ant1_Low_2402 BLE_Ant1_High_2480 FCC ID:2BG6CTS-150A 13 Appendix B.6: Conducted Spurious Emission Test Result TestMode Antenna Freq(MHz) FreqRange [MHz] RefLevel [dBm] Result[dBm] Limit[dBm] Verdict BLE Ant1 2402 Reference 7.72 7.72 --- PASS 30~1000 7.72 -60.38 ≤-12.28 PASS 1000~26500 7.72 -47.62 ≤-12.28 PASS 2440 Reference 6.52 6.52 --- PASS 30~1000 6.52 -60.41 ≤-13.48 PASS 1000~26500 6.52 -47.66 ≤-13.48 PASS 2480 Reference 5.66 5.66 --- PASS 30~1000 5.66 -60.12 ≤-14.34 PASS 1000~26500 5.66 -47.25 ≤-14.34 PASS FCC ID:2BG6CTS-150A 14 Test Graphs BLE_Ant1_2402_0~Reference BLE_Ant1_2402_30~1000 BLE_Ant1_2402_1000~26500 FCC ID:2BG6CTS-150A 15 BLE_Ant1_2440_0~Reference BLE_Ant1_2440_30~1000 FCC ID:2BG6CTS-150A 16 BLE_Ant1_2440_1000~26500 BLE_Ant1_2480_0~Reference BLE_Ant1_2480_30~1000 FCC ID:2BG6CTS-150A 17 BLE_Ant1_2480_1000~26500 FCC ID:2BG6CTS-150A 18 Appendix B.7: Emissions in Restricted Bands Test Result TestMode Antenna ChName Freq(MHz) Detector Freq [MHz] Result [dBm] Limit [dBm] Result [dBuV/m] Limit [dBuV/m] Verdict BLE Ant1 Low 2402 AV 2310.000 -49.29 ≤-41.20 45.91 ≤54 PASS AV 2389.775 -48.76 ≤-41.20 46.44 ≤54 PASS AV 2390.000 -48.85 ≤-41.20 46.35 ≤54 PASS Peak 2310.000 -40.49 ≤-21.20 54.71 ≤74 PASS Peak 2366.675 -38.97 ≤-21.20 56.23 ≤74 PASS Peak 2390.000 -41.65 ≤-21.20 53.55 ≤74 PASS High 2480 AV 2483.500 -46.61 ≤-41.20 48.59 ≤54 PASS AV 2483.520 -46.61 ≤-41.20 48.59 ≤54 PASS AV 2500.000 -48.56 ≤-41.20 46.64 ≤54 PASS Peak 2483.500 -41.57 ≤-21.20 53.63 ≤74 PASS Peak 2483.760 -34.86 ≤-21.20 60.34 ≤74 PASS Peak 2500.000 -41.23 ≤-21.20 53.97 ≤74 PASS Note： 1. The Antenna Gain is compensated in the graph. 2. The Duty Cycle Factor and RBW Factor is compensated in the graph. 3. The limit in dBm for average detector is conversion from 54dBuV/m, according to 15.209(a). The limit in dBm for peak detector is 20dB above the limit of average detector in dBm. FCC ID:2BG6CTS-150A 19 Test Graphs BLE_Ant1_Low_2402_AV BLE_Ant1_Low_2402_Peak BLE_Ant1_High_2480_AV FCC ID:2BG6CTS-150A 20 BLE_Ant1_High_2480_Peak

FCC ID:2BG6CTS-150A 1 Case No. : CTA24061300103 Ambient Condition: 23 °C, 55 %RH, Test Date: 2024.5.24 Test Engineer: Evan ouyang Appendix C.1: DTS Bandwidth Test Result TestMode Antenna Frequency[MHz] DTS BW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant1 2412 8.560 2407.520 2416.080 0.5 PASS 2437 8.040 2433.000 2441.040 0.5 PASS 2462 8.040 2458.000 2466.040 0.5 PASS 11G Ant1 2412 14.400 2404.520 2418.920 0.5 PASS 2437 14.640 2429.280 2443.920 0.5 PASS 2462 15.000 2454.520 2469.520 0.5 PASS 11N20SISO Ant1 2412 15.080 2404.520 2419.600 0.5 PASS 2437 15.120 2429.480 2444.600 0.5 PASS 2462 15.000 2454.520 2469.520 0.5 PASS FCC ID:2BG6CTS-150A 2 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 FCC ID:2BG6CTS-150A 3 11G_Ant1_2412 11G_Ant1_2437 FCC ID:2BG6CTS-150A 4 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 FCC ID:2BG6CTS-150A 5 11N20SISO_Ant1_2462 FCC ID:2BG6CTS-150A 6 Appendix C.2: Occupied Channel Bandwidth Test Result TestMode Antenna Channel Frequency[MHz] OCB [MHz] FL[MHz] FH[MHz] 11B Ant1 2412 14.009 2405.0636 2419.0726 2437 13.959 2430.0312 2443.9902 2462 13.925 2455.0395 2468.9645 11G Ant1 2412 16.680 2403.7310 2420.4110 2437 16.576 2428.7374 2445.3134 2462 16.619 2453.7066 2470.3256 11N20SISO Ant1 2412 17.725 2403.2055 2420.9305 2437 17.676 2428.1827 2445.8587 2462 17.653 2453.1802 2470.8332 FCC ID:2BG6CTS-150A 7 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 FCC ID:2BG6CTS-150A 8 11G_Ant1_2412 11G_Ant1_2437 FCC ID:2BG6CTS-150A 9 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 FCC ID:2BG6CTS-150A 10 11N20SISO_Ant1_2462 FCC ID:2BG6CTS-150A 11 Appendix C.3: Maximum conducted output power Test Result -CH P Note： 1.The Duty Cycle Factor and RBW Factor is compensated in the data. Test Mode Antenna Frequency[MH z] Peak power [dBm] Limit [dBm] Verdict 11B Ant1 2412 18.90 ≤30.00 PASS 2437 19.64 ≤30.00 PASS 2462 19.64 ≤30.00 PASS 11G Ant1 2412 21.39 ≤30.00 PASS 2437 21.99 ≤30.00 PASS 2462 22.09 ≤30.00 PASS 11N20SISO Ant1 2412 20.84 ≤30.00 PASS 2437 21.40 ≤30.00 PASS 2462 21.52 ≤30.00 PASS FCC ID:2BG6CTS-150A 12 Appendix C.4: Maximum power spectral density Test Result TestMode Antenna Frequency[MHz] Result[dBm/3-100kHz] Limit[dBm/3kHz] Verdict 11B Ant1 2412 -6.67 ≤8.00 PASS 2437 -5.05 ≤8.00 PASS 2462 -6.49 ≤8.00 PASS 11G Ant1 2412 -10.91 ≤8.00 PASS 2437 -10.40 ≤8.00 PASS 2462 -9.36 ≤8.00 PASS 11N20SISO Ant1 2412 -11.27 ≤8.00 PASS 2437 -11.41 ≤8.00 PASS 2462 -11.26 ≤8.00 PASS Note： 1. The Duty Cycle Factor and RBW Factor is compensated in the graph. FCC ID:2BG6CTS-150A 13 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 FCC ID:2BG6CTS-150A 14 11G_Ant1_2412 11G_Ant1_2437 FCC ID:2BG6CTS-150A 15 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 FCC ID:2BG6CTS-150A 16 11N20SISO_Ant1_2462 FCC ID:2BG6CTS-150A 17 Appendix C.5: Band edge measurements Test Result TestMode Antenna ChName Frequency[MHz] RefLevel[dBm] Result[dBm] Limit[dBm] Verdict 11B Ant1 Low 2412 8.05 -33.7 ≤-11.95 PASS High 2462 8.77 -47.82 ≤-11.23 PASS 11G Ant1 Low 2412 4.16 -30.19 ≤-15.84 PASS High 2462 4.72 -43.92 ≤-15.28 PASS 11N20SISO Ant1 Low 2412 3.61 -31.2 ≤-16.39 PASS High 2462 4.39 -44.42 ≤-15.61 PASS FCC ID:2BG6CTS-150A 18 Test Graphs 11B_Ant1_Low_2412 11B_Ant1_High_2462 11G_Ant1_Low_2412 FCC ID:2BG6CTS-150A 19 11G_Ant1_High_2462 11N20SISO_Ant1_Low_2412 FCC ID:2BG6CTS-150A 20 11N20SISO_Ant1_High_2462 FCC ID:2BG6CTS-150A 21 Appendix C.6: Conducted Spurious Emission Test Result TestMode Antenna Frequency[MHz] FreqRange [Mhz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict 11B Ant1 2412 Reference 6.38 6.38 --- PASS 30~1000 6.38 -56.53 ≤-13.62 PASS 1000~26500 6.38 -48.04 ≤-13.62 PASS 2437 Reference 7.31 7.31 --- PASS 30~1000 7.31 -60.47 ≤-12.69 PASS 1000~26500 7.31 -47.63 ≤-12.69 PASS 2462 Reference 7.78 7.78 --- PASS 30~1000 7.78 -60.73 ≤-12.22 PASS 1000~26500 7.78 -48.02 ≤-12.22 PASS 11G Ant1 2412 Reference 3.39 3.39 --- PASS 30~1000 3.39 -60.44 ≤-16.61 PASS 1000~26500 3.39 -47.9 ≤-16.61 PASS 2437 Reference 2.40 2.40 --- PASS 30~1000 2.40 -58.83 ≤-17.6 PASS 1000~26500 2.40 -47.29 ≤-17.6 PASS 2462 Reference 2.80 2.80 --- PASS 30~1000 2.80 -60.31 ≤-17.2 PASS 1000~26500 2.80 -47.62 ≤-17.2 PASS 11N20SISO Ant1 2412 Reference 0.67 0.67 --- PASS 30~1000 0.67 -61.15 ≤-19.33 PASS 1000~26500 0.67 -47.38 ≤-19.33 PASS 2437 Reference 2.80 2.80 --- PASS 30~1000 2.80 -60.74 ≤-17.2 PASS 1000~26500 2.80 -47.82 ≤-17.2 PASS 2462 Reference 0.46 0.46 --- PASS 30~1000 0.46 -60.15 ≤-19.54 PASS 1000~26500 0.46 -47.62 ≤-19.54 PASS FCC ID:2BG6CTS-150A 22 Test Graphs 11B_Ant1_2412_0~Reference 11B_Ant1_2412_30~1000 11B_Ant1_2412_1000~26500 FCC ID:2BG6CTS-150A 23 11B_Ant1_2437_0~Reference 11B_Ant1_2437_30~1000 FCC ID:2BG6CTS-150A 24 11B_Ant1_2437_1000~26500 11B_Ant1_2462_0~Reference 11B_Ant1_2462_30~1000 FCC ID:2BG6CTS-150A 25 11B_Ant1_2462_1000~26500 11G_Ant1_2412_0~Reference FCC ID:2BG6CTS-150A 26 11G_Ant1_2412_30~1000 11G_Ant1_2412_1000~26500 11G_Ant1_2437_0~Reference FCC ID:2BG6CTS-150A 27 11G_Ant1_2437_30~1000 11G_Ant1_2437_1000~26500 FCC ID:2BG6CTS-150A 28 11G_Ant1_2462_0~Reference 11G_Ant1_2462_30~1000 11G_Ant1_2462_1000~26500 FCC ID:2BG6CTS-150A 29 11N20SISO_Ant1_2412_0~Reference 11N20SISO_Ant1_2412_30~1000 FCC ID:2BG6CTS-150A 30 11N20SISO_Ant1_2412_1000~26500 11N20SISO_Ant1_2437_0~Reference 11N20SISO_Ant1_2437_30~1000 FCC ID:2BG6CTS-150A 31 11N20SISO_Ant1_2437_1000~26500 11N20SISO_Ant1_2462_0~Reference FCC ID:2BG6CTS-150A 32 11N20SISO_Ant1_2462_30~1000 11N20SISO_Ant1_2462_1000~26500 FCC ID:2BG6CTS-150A 33 Appendix C.7: Emissions in Restricted Bands Test Result TestMode Antenna ChName Frequenc y[MHz] Detector Freq [MHz] Result [dBm] Limit [dBm] Result [dBuV/m] Limit [dBuV/m] Verdict 11B Ant1 Low 2412 AV 2310.000 -49.47 ≤-41.20 45.73 ≤54 PASS AV 2386.970 -46.61 ≤-41.20 48.59 ≤54 PASS AV 2390.000 -47.51 ≤-41.20 47.69 ≤54 PASS Peak 2310.000 -48.52 ≤-21.20 46.68 ≤74 PASS Peak 2374.360 -39.18 ≤-21.20 56.02 ≤74 PASS Peak 2390.000 -44.19 ≤-21.20 51.01 ≤74 PASS High 2462 AV 2483.500 -47.33 ≤-41.20 47.87 ≤54 PASS A…
