TPL3135 BLE Module Datasheet Version：V1.1 Copyright：©2025 TPL3135 BLE Module Datasheet 1、Introduction 2、Module Parameters 3、Module Size 4、Pin Definition 5、Reference Design 5.1、VBAT Power Supply Reference Design 5.2、VCC Power Supply Reference Design 6、Hardware Design Considerations 6.1、Module placement requirements on the bottom plate 6.2、Power supply requirements 6.3、UART Communication 7、Reflow Profile 8、Revision History ItemParameters Module NameTPL3131 PackageSMT（Stamp Hole） Size11.2x15.06(mm） Voltage RangeVBAT( 2.7V~5.5V）或 VCC ( 1.9V~3.5V） Wireless StandardBluetooth 5.4 Frequency Range2402~2480MHz Sensitivity-92dBm Default Communication interfaceUART FLASH Size256KB RAM Size32KB Operating current3.5mA Sleep current3uA Shutdown current200nA GPIO Number2 Work Temperature-20°C~+85°C Storage Temperature-60°C~+150°C 1、Introduction TPL3131 is a BLE 5.4 low power Bluetooth module, which can be widely used in short distance wireless Bluetooth communication. It has the characteristics of small size, low power consumption, strong anti-interference ability and long transmission distance. The other main features of the module are as follows: compliant with Bluetooth 5 .4 standard, which can support various Profile configurations. Support low power Bluetooth data transparent transmission Support AT command control Support online OTA upgrade module firmware Ultra small package 2、Module Parameters 3、Module Size Top View Side view NumberNamePinFunctionNotes 1NCNCNCNot connected 2TXUART_TX Serial port transmission 3RXUART_RX Serial port receiving 4GNDGround Power 'Ground' 5VCCVCC Power supply( 1.9V~3.5V） Two AA batteries/button cell batteries are recommended. When powered by VBAT, it outputs 3.3V voltage externally. 6VBATVBAT Power supply ( 2.7V~5.5V） 5V/3.3V power supply, 4.2V lithium battery, three dry cells recommended for use 4、Pin Definition Explanation: When powered by VBAT, the VCC pin outputs 3.3V externally and can only be used as a signal source, with a maximum output current of 10mA. 5、Reference Design The TPL3131 module can be powered through either the VBAT pin or the VCC pin. The VBAT pin supports 2.7-5.5V, and it is recommended to use the VBAT pin for 5V and 3.3V systems. The VCC pin supports 1.9V-3.5V, and it is recommended to use the VCC pin when powering with two dry batteries or button batteries. 5.1、VBAT Power Supply Reference Design For 5V or 3.3V system power supply, the VBAT power supply pin is used. When the VBAT power supply is greater than 3.3V, the TPL3131 chip serial port level is 3.3V. When the VBAT power supply is less than 3.3V, the TPL3131 chip serial port level equals the VBAT voltage. When connected to an MCU with 3.3V level IO, UART can be connected in series with a 100Ω resistor. When connecting to an MCU with 5V level IO, it is recommended to use a level conversion circuit. The schematic provides a 3.3V to 5V conversion circuit using MOSFETs. Among them, the MCU serial ports Custom_Tx and Custom_Rx used for Bluetooth communication are at 5V level. When the VBAT pin is powered, the internal LDO of the chip will be activated, and VCC outputs a 3.3V voltage externally. 说明： In the diagram, VCC_3V3 is the voltage output externally converted by the internal LDO of the chip. The customer only needs to provide 5V voltage from VBAT. The circuit with two 2N7002 MOSFETs is a serial port level conversion circuit designed, and it can be replaced with other conversion circuits. The TPL3131 serial port IO level is 3.3V. It is recommended to use a conversion circuit when connecting to a 5V level. If a modular power-off method is used to control shutdown power consumption, it is recommended to disconnect the GND circuit to prevent leakage current due to voltage differences at the IO interfaces. 5.2、VCC Power Supply Reference Design Two dry batteries or button batteries are recommended to power via the VCC pin, and the MCU serial ports Custom_Tx and Custom_Rx used for Bluetooth communication need to be equal to or lower than the VCC voltage. 说明： The VCC (1.9V~3.5V) pin is powered, and the VBAT is left floating and not connected. The TX and RX of the chip need to be cross-connected with the main control MCU, and the series-connected resistors R1 and R3 in between can be added according to requirements. If using a module power-off method to control shutdown power consumption, it is recommended to disconnect the GND circuit to prevent leakage current caused by voltage differences at the IO interface. 6、Hardware Design Considerations 6.1、Module placement requirements on the bottom plate (1) In order to meet the performance of the antenna on board, it is forbidden to place metal parts around the antenna, away from high frequency devices.Avoid using metal in the product housing and keep metal screw inside away from the RF part of the module. (2) Pay attention to the layout of the module on the soleplate, and minimize the impact of the soleplate on the performance of the module PCB antenna. The following are suggested: Option 1: Place the module at the edge of the motherboard and the antenna area extends beyond the edge of the motherboard. Option 2: Place the module at the edge of the motherboard, which empties an area at the antenna position. Option 3: If the above scheme is limited and cannot be implemented, make sure that the area of the module PCB antenna and the area of 5 mm extension need to be cleared (copper, wiring and placement of components are strictly prohibited). 6.2、Power supply requirements (1) It is recommended to use DC regulator power supply to supply power to the module. The power ripple factor is as small as possible and the module needs to be grounded reliably. Please note that the correct connection between the positive and negative poles of the power supply, such as reverse connection may cause permanent damage to the module. (2) Check the power supply to ensure that between the recommended supply voltage, if the maximum value is exceeded, the module will be permane…
