2BGPI-COM601Lightshow Speaker

Sicherheit / Safety Bestimmungsgemäße Verwendung » Das Gerät darf ausschließlich wie beschrieben bestimmungsgemäß verwendet werden. » Die in dieser Anleitung beschriebenen Vorgehensweisen sind unbedingt einzuhalten. Umgang mit Batterien / Akkus › Das Gerät darf nicht geöffnet, ins Feuer geworfen, in Flüssig keiten getaucht oder kurz geschlossen werden. › Laden Sie das Gerät nur mit dem mitgelieferten Ladekabel. Bei Verwendung eines falschen Ladegerätes kann es zum Brand, zur Explosion und zu Verätzungen kommen. › Bei Beschädigung und unsachgemäßem Gebrauch des Akkus können Dämpfe austreten. Führen Sie Frischluft zu und suchen Sie bei Beschwerden einen Arzt auf. Die Dämpfe können die Atemwege reizen. › Bei einem beschädigten Akku kann Akkuflüssigkeit austreten. Sollte einer der Akkus ausgelaufen sein, vermeiden Sie den Kontakt von Haut, Augen und Schleimhäuten mit der Akku flüssigkeit. Bei Kontakt mit Akkuflüssigkeit spülen Sie die betroffenen Stellen sofort mit reichlich klarem Wasser ab und suchen Sie umgehend einen Arzt auf. Grundlegende Sicherheitshinweise › Kontrollieren Sie das Gerät vor der Verwendung auf äußere sichtbare Schäden. Nehmen Sie ein beschädigtes oder heruntergefallenes Gerät nicht in Betrieb. › Personen, die aufgrund ihrer körperlichen, geistigen oder motorischen Fähigkeiten nicht in der Lage sind das Gerät sicher zu bedienen, dürfen das Gerät nur unter Aufsicht oder An­ weisung durch eine verantwortliche Person benutzen. › Gestatten Sie Kindern die Benutzung des Gerätes nur unter Aufsicht. › Lassen Sie Reparaturen am Gerät nur von autorisierten Fach­ betrieben durchführen. Durch unsachgemäße Reparaturen können erhebliche Gefahren für den Benutzer entstehen. › Schützen Sie das Gerät vor Feuchtigkeit und dem Eindringen von Flüssigkeiten. Intended use » Only use the device as intended. » Comply with the procedures described in these operating instructions. Handling (storage) batteries › The device must not be opened, thrown into fire, dipped in fluids or be shortcircuited. › Charge the device only with the delivered recharger cable. Using a wrong charger can lead to fire, explosion and acid burns. › In the case of damage and improper use of the storage battery, vapours can escape. Supply fresh air and consult a doctor in case of complaints. The vapours can irritate the airways. › In the case of a damaged storage battery, battery fluid can leak. If one of the storage batteries has leaked, please avoid contact of the skin, the eyes and the mucous membranes with the battery fluid. In the case of contact with the battery fluid, immediately rinse the corresponding spots with plenty of clear water and consult a doctor promptly. Basic safety information › Check the device for any visible external damage before use. Do not put into operation a damaged or fallen device. › Persons, who are not in a position to safely operate the product due to their physical, mental or motor skills, may only use the device under supervision or instruction by a responsible person. Lightshow Speaker (COM 601) Bitte lesen Sie diese Anleitung vor Inbetriebnahme aufmerksam durch und bewahren Sie sie für weitere Zwecke oder Benutzer auf. Please read this manual carefully before initial operation and keep it for future reference or other users. Lieferumfang / Package Includes 1 × Lautsprecher 1 × Ladekabel 1 × Bedienungsanleitung 1 × Speaker 1 × Charging Cable 1 × User Manual Technische Details / Technical details Bluetooth Version: 5.1 Reichweite / Range: 15 m Output: 5 W Frequenzbereich / Frequency response: 100 Hz – 20 KHz Akku / Battery: 500 mAh / 3,7 V Empfänger / Sensitivity: 84 ± 2 dB S/R: ≥ 65 dB Verzerrung / Distortion: 1 % Ladezeit / Charge time: 1,5 – 2,5 h Betriebszeit / Uptime: ~ 2 – 4 h Größe / Size: 80 × 80 × 41 mm Entsorgung / Disposal Elektro­ und Elektronik­Altgeräte dürfen nicht mit dem Hausmüll entsorgt werden, sondern müssen an einer öffentlich ausgewiesenen Sammelstelle oder bei der Verkaufsstelle abgegeben werden. Für weitere Informationen, wenden Sie sich bitte an Ihre Verkaufsstelle oder die öffentlichen Behörden. Wenn Sie die Verpackung entsorgen, achten Sie auf die entsprechenden Bestimmungen in Ihrem Land. Electrical and electronic equipment must not be disposed of with household waste, but must be returned to a public separate collection or at the point of sale. For more information, please contact your sales outlet or the public authorities. When you dispose of the packaging, pay attention to the relevant regulations in yo+ur country. Konformitätserklärung / Declaration of conformity Hiermit erklärt ZOGI / Herzog Products GmbH, dass dieses Produkt den gesetzlichen EU Bestimmungen, Normen und Richtlinien zum Zeitpunkt des Erwerbs entspricht. Die Konformitätserklärung finden Sie unter folgendem Link: https://s3­eu­west­1.amazonaws.com/shop­files.zogi.biz/ product­attachments/Lightshow­Speaker­V2.pdf Hereby ZOGI / Herzog Products GmbH declares that this product complies with the legal EU regulations, standards and guidelines at the time of purchase. The Declaration of Conformity can be found under the following URL: https://s3-eu-west-1.amazonaws.com/shop-files.zogi.biz/ product-attachments/Lightshow-Speaker-V2.pdf › Children are only allowed to use the device under supervision. › The device may only be repaired by authorised specialised companies. Improper repairs can lead to significant dangers for the user, and to the expiry of the warranty claim. Protect the device from moisture and the penetration of fluids. 1 2345 1 LED Kontroll­Licht 2 Kurzes Drücken: Track zurück Langes Drücken: leiser 3 Kurzes Drücken: Pause – Anruf – Pause – Spielen Langes Drücken: An­ / Ausschalten 4 Kurzes Drücken: Nächster Track Langes Drücken: lauter 5 Type­C DC 5V Ladebuchse Status LED Kontroll-Licht / Status LED status light Wenn die Kontroll­LED schnell blau blinkt, ist der Lautsprecher im Bluetooth­Modus. Beim Aufladen leuchtet es rot und erlischt, wenn der Vorgang abgeschlossen ist. When the …

Text truncated - open the document above for the full version.

Shenzhen ZOGI Technology Limited 2.911 (d)(5)(i) Equipment Type Attestation v1.2 Section 2.911(d)(5)(i) Certification – EquipmentType Company name: Shenzhen ZOGI Technology Limited Address: A303, Donglian Building, Chuangye 2nd Road, Bao an District, Shenzhen, China Product Name: Lightshow Speaker FCC ID: 2BGPI-COM601 Model(s): COM 601 2.911(d)(5)(i) EquipmentType We, [Shenzhen ZOGI Technology Limited] (“the applicant”) certify that the equipment for which authorization is sought through certification is not: • Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules. • Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name: Cathy Liu Date: 2024-06-11 Title and Company name: Process team Leader/ Shenzhen ZOGI Technology Limited NOTE 1 “Covered List ”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Shenzhen ZOGI Technology Limited 2.911 (d)(5)(ii) Applicant Attestation v1.3 Section 2.911(d)(5)(ii) Certification – Applicant (Covered List ) Company name: Shenzhen ZOGI Technology Limited Address: A303, Donglian Building, Chuangye 2nd Road, Bao an District, Shenzhen, China Product Name: Lightshow Speaker FCC ID: 2BGPI-COM601 Model(s): COM 601 2.911(d)(5)(ii) Applicant filing We, [Shenzhen ZOGI Technology Limited] (“the applicant”) certify that, as of the date of the filing of the application, the applicant is not identified NOTE 1 on the “Covered List” NOTE 2 ,established pursuant to §1.50002 of this chapter,as an entity producing coveredcommunications equipment. Yours sincerely, Name: Cathy Liu Date: 2024-06-11 Title and Company name: Process team Leader/ Shenzhen ZOGI Technology Limited NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List ”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Shenzhen ZOGI Technology Limited Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2024-06-11 Subject; Request for Long Term Confidentiality FCC ID: 2BGPI-COM601 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Cathy Liu Title: Process team Leader

Shenzhen ZOGI Technology Limited A303, Donglian Building, Chuangye 2nd Road, Bao an District, Shenzhen, China Agent Authorization Compa ny: Shenzhen ZOGI Technology Limited Address: A303, Donglian Building, Chuangye 2nd Road, Bao an District, Shenzhen, China Product Name: Lightshow Speaker Model Number(s): COM 601 Product Description: Lightshow Speaker We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2024-06-11 Name: Cathy Liu Title: Process team Leader Company: Shenzhen ZOGI Technology Limited

Page 1 of 4 Appendix C: Photographs of EUT Product: Lightshow Speaker Model: COM 601 External Photos Page 2 of 4 Page 3 of 4 Page 4 of 4

Label Artwork and Location Model: COM 601 Label: Size: L*W=34*45mm Location

Page 1 of 5 Appendix C: Photographs of EUT Product: Lightshow Speaker Model: COM 601 Internal Photos Page 2 of 5 Antenna Page 3 of 5 Page 4 of 5 Page 5 of 5

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID. ............................ : 2BGPI-COM601 Test Report No. ............... : TCT240522E036 Date of issue ................... : Jun. 07, 2024 Testing laboratory .......... : SHENZHEN TONGCE TESTING LAB Testing location/ address: 2101 & 2201, Zhenchang Factory Renshan Industrial Zone, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, 518103, People's Republic of China Applicant's name ............ : Shenzhen ZOGI Technology Limited Address ........................... : A303, Donglian Building, Chuangye 2nd Road, Bao an District, Shenzhen, China Manufacturer's name ... : Shenzhen ZOGI Technology Limited Address ........................... : A303, Donglian Building, Chuangye 2nd Road, Bao an District, Shenzhen, China Standard(s) ..................... : KDB 447498 D01 General RF Exposure Guidance v06 Product Name ................. : Lightshow Speaker Trade Mark ...................... : N/A Model/Type reference..... : COM 601 Rating(s).......................... : Rechargeable Li-ion Battery DC 3.7V Date of receipt of test item ......................................... : May 22, 2024 Date (s) of performance of test ................................... : May 22, 2024 ~ Jun. 07, 2024 Tested by (+signature) ... : Yannie ZHONG Check by (+signature) .... : Beryl ZHAO Approved by (+signature): Tomsin General disclaimer: This report shall not be reproduced except in full, without the written approval of SHENZHEN TONGCE TESTING LAB. This document may be altered or revised by SHENZHEN TONGCE TESTING LAB personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT240522E036 Page 2 of 6 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Table of Contents 1. General Product Information .................................................................. 3 1.1. EUT description ..................................................................................................... 3 1.2. Model(s) list ............................................................................................................ 3 2. General Information ................................................................................. 4 2.1. Test environment and mode ................................................................................. 4 2.2. Description of Support Units ................................................................................ 4 3. Facilities and Accreditations .................................................................. 5 3.1. Facilities ................................................................................................................. 5 3.2. Location ................................................................................................................. 5 4. Test Results and Measurement Data ..................................................... 6 Report No.: TCT240522E036 Page 3 of 6 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. General Product Information 1.1. EUT description Product Name ....................... : Lightshow Speaker Model/Type reference........... : COM 601 Sample Number....................: TCT240522E017-0101 Operation Frequency ........... : 2402MHz~2480MHz Modulation Type ................... : For BT: GFSK, π/4-DQPSK, 8DPSK For BLE: GFSK Antenna Type ........................ : PCB Antenna Antenna Gain ........................ : -0.68dBi Rating(s)................................ : Rechargeable Li-ion Battery DC 3.7V Note: The antenna gain listed in this report is provided by applicant, and the test laboratory is not responsible for this parameter. 1.2. Model(s) list None. Report No.: TCT240522E036 Page 4 of 6 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 2. General Information 2.1. Test environment and mode Item Normal condition Temperature +25ºC Voltage DC 3.7V Humidity 56% Atmospheric Pressure: 1008 mbar Test Mode: Engineering mode: Keep the EUT in continuous transmitting by select channel 2.2. Description of Support Units The EUT has been tested as an independent unit together with other necessary accessories or support units. The following support units or accessories were used to form a representative test configuration during the tests. Equipment Model No. Serial No. FCC ID Trade Name / / / / / Note: 1. All the equipment/cables were placed in the worst-case configuration to maximize the emission during the test. 2. Grounding was established in accordance with the manufacturer’s requirements and conditions for the intended use. 3. For conducted measurements (Output Power, 20dB Occupied Bandwidth, Carrier Frequencies Separation, Hopping Channel Number, Dwell Time, Spurious Emissions), the antenna of EUT is connected to the test equipment via temporary antenna connector, the antenna connector is soldered on the antenna port of EUT, and the temporary antenna connector is listed in the Test Instruments. Report No.: TCT240522E036 Page 5 of 6 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 3. Facilities and Accreditations 3.1. Facilities The test facility is recognized, certified, or accredited by the following organizations: ● FCC - Registration No.: 645098 SHENZHEN TONGCE TESTING LAB Designation Number: CN1205 The testing lab has been registered and fully described in a report with the (FCC) Federal Communications Commission. The acceptance letter from the FCC is maintained in our files. ● IC - Registration No.: 10668A-1 SHENZHEN TONGCE TESTING LAB CAB identifier: CN0031 The testing lab has been registered by Certification and Engineering Bureau of Industry Canada for radio equipment testing. 3.2. Location SHENZHEN TONGCE TESTING LAB Address: 2101 & 2201, Zhenchang Factory, Renshan Indus…

Text truncated - open the document above for the full version.

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID. ............................ : 2BGPI-COM601 Test Report No. ............... : TCT240522E018 Date of issue ................... : Jun. 07, 2024 Testing laboratory .......... : SHENZHEN TONGCE TESTING LAB Testing location/ address: 2101 & 2201, Zhenchang Factory Renshan Industrial Zone, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, 518103, People's Republic of China Applicant's name ............ : Shenzhen ZOGI Technology Limited Address ........................... : A303, Donglian Building, Chuangye 2nd Road, Bao an District, Shenzhen, China Manufacturer's name ... : Shenzhen ZOGI Technology Limited Address ........................... : A303, Donglian Building, Chuangye 2nd Road, Bao an District, Shenzhen, China Standard(s) ..................... : FCC CFR Title 47 Part 15 Subpart C Section 15.247 FCC KDB 558074 D01 15.247 Meas Guidance v05r02 ANSI C63.10:2013 Product Name ................. : Lightshow Speaker Trade Mark ...................... : N/A Model/Type reference..... : COM 601 Rating(s).......................... : Rechargeable Li-ion Battery DC 3.7V Date of receipt of test item ......................................... : May 22, 2024 Date (s) of performance of test ................................... : May 22, 2024 ~ Jun. 07, 2024 Tested by (+signature) ... : Yannie ZHONG Check by (+signature) .... : Beryl ZHAO Approved by (+signature): Tomsin General disclaimer: This report shall not be reproduced except in full, without the written approval of SHENZHEN TONGCE TESTING LAB. This document may be altered or revised by SHENZHEN TONGCE TESTING LAB personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT240522E018 Page 2 of 56 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Table of Contents 1. General Product Information .................................................................. 3 1.1. EUT description ..................................................................................................... 3 1.2. Model(s) list ............................................................................................................ 3 1.3. Operation Frequency ............................................................................................ 3 2. Test Result Summary .............................................................................. 4 3. General Information ................................................................................. 5 3.1. Test environment and mode ................................................................................. 5 3.2. Description of Support Units ................................................................................ 5 4. Facilities and Accreditations .................................................................. 6 4.1. Facilities ................................................................................................................. 6 4.2. Location ................................................................................................................. 6 4.3. Measurement Uncertainty ..................................................................................... 6 5. Test Results and Measurement Data ..................................................... 7 5.1. Antenna requirement ............................................................................................ 7 5.2. Conducted Emission ............................................................................................. 8 5.3. Conducted Output Power ................................................................................... 12 5.4. Emission Bandwidth ........................................................................................... 13 5.5. Power Spectral Density ....................................................................................... 14 5.6. Conducted Band Edge and Spurious Emission Measurement ....................... 15 5.7. Radiated Spurious Emission Measurement ...................................................... 17 Appendix A: Test Result of Conducted Test Appendix B: Photographs of Test Setup Appendix C: Photographs of EUT Report No.: TCT240522E018 Page 3 of 56 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. General Product Information 1.1. EUT description Product Name ....................... : Lightshow Speaker Model/Type reference........... : COM 601 Sample Number....................: TCT240522E017-0101 Bluetooth Version ................ : V5.1 (This report is for BLE) Operation Frequency ........... : 2402MHz~2480MHz Channel Separation ............. : 2MHz Data Rate............................... : LE 1M PHY, LE 2M PHY Number of Channel .............. : 40 Modulation Type ................... : GFSK Antenna Type ........................ : PCB Antenna Antenna Gain ........................ : -0.68dBi Rating(s)................................ : Rechargeable Li-ion Battery DC 3.7V Note: The antenna gain listed in this report is provided by applicant, and the test laboratory is not responsible for this parameter. 1.2. Model(s) list None. 1.3. Operation Frequency Channel Frequency Channel Frequency Channel Frequency Channel Frequency 0 2402MHz 10 2422MHz 20 2442MHz 30 2462MHz 1 2404MHz 11 2424MHz 21 2444MHz 31 2464MHz ... ... ... ... ... ... ... ... 8 2418MHz 18 2438MHz 28 2458MHz 38 2478MHz 9 2420MHz 19 2440MHz 29 2460MHz 39 2480MHz Remark: Channel 0, 19 & 39 have been tested. Report No.: TCT240522E018 Page 4 of 56 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 2. Test Result Summary Requirement CFR 47 Section Result Antenna requirement §15.203/§15.247 (c) PASS AC Power Line Conducted Emission §15.207 PASS Conducted Peak Output Power §15.247 (b)(3) PAS…

Text truncated - open the document above for the full version.

1.6mm1.6mm

Page 1 of 2 Appendix B: Photographs of Test Setup Product: Lightshow Speaker Model: COM 601 Radiated Emission Page 2 of 2 Conducted Emission
