2BGUG-RDKX3MRDK X3 Module

SSEUR : M.DA ROSBTS SIO BORDEAUX - LYCÉE GUSTAVE EIFFEL ✦ 1 / 39 ✦ D-Robotics RDK Suite This document is the user manual for the D-Robotics RDK Suite, providing developers with instructions and development guidance for products such as RDK X3, RDK X3 Module, and RDK Ultra. The content covers various aspects such as hardware design, system customization, application development, and algorithm toolchains. Users are welcome to update and experience, please refer to the Quick Start section for specific instructions. All RDK X3 mentioned in this document use the Ubuntu 2.0 and 3.0 version operating system. To check the system version number, you can use the following command cat /etc/version. Overview of D-Robotics RDK Suite D-Robotics Developer Kits, abbreviated as D-Robotics RDK Suite, is a robot development kit built on the D-Robotics intelligent chip, including RDK X3, RDK X3 Module. In combination with the TogetheROS.Bot robot middleware, the D-Robotics RDK Suite can help developers quickly build robot prototypes and carry out evaluation and verification work. This document will provide detailed instructions on how to use the D-Robotics RDK Suite, including setting up the development environment, running example tutorials, developing applications, and customizing system images. Regardless of which hardware you choose to use, the content described in this document will provide you with a consistent user experience. Product Introduction RDK X3 (Sunrise X3) is a full-featured development board with 5Tops edge inference power. It provides developers with flexible hardware expansion and connection options by supporting a variety of sensors and expansion components. RDK X3 Module (Sunrise X3 Module) is a compact core module that maintains the same specifications as RDK X3 and is compatible with the Raspberry Pi CM4 module in terms of size and interface. By combining with the expansion board, it can provide efficient computing and communication capabilities for various application scenarios. ESSEUR : M.DA ROSBTS SIO BORDEAUX - LYCÉE GUSTAVE EIFFEL ✦ 2 / 39 ✦ Version Release History Version: 2.1.0 New Features: Improved srpi-config system configuration tool, supporting Wi-Fi connections, enabling/disabling SSH and VNC, enabling/disabling peripheral buses on the 40-pin connector, language localization configuration, CPU overclocking, ION memory size configuration, and more. Support for /boot/config.txt system configuration file, supporting options such as dtoverlay, CPU overclocking, and IO boot state configuration. Added yolov5s v6/v7 model examples. Enhancements: SSEUR : M.DA ROSBTS SIO BORDEAUX - LYCÉE GUSTAVE EIFFEL ✦ 3 / 39 ✦ Support for outputting boot logs and entering the user command-line interface on HDMI displays to facilitate user use. Support for more HDMI display resolutions, greatly enhancing compatibility. Optimized pre-installed software lists for Desktop and server versions, removing redundant items and adding necessary software, such as VLC. Optimized layout of the Desktop menu bar, simplifying options. Bluetooth functionality is enabled by default. Added C++ interface for post-processing, improving post-processing efficiency. Automatically mount USB flash drives using udisk2, solving the problem of not being able to access NTFS file systems after automatic mounting. Support for retaining VNC password file. VNC service is not automatically started by default to reduce system resource consumption. Users can enable it through the srpi-config tool. RDK X3 v2.1 and RDK Module development board's CPU can run at a maximum frequency of 1.5GHz in normal mode and 1.8GHz after overclocking. Bug Fixes: Remove redundant kernel logs for Wi-Fi drivers. Modify apt source domain to sunrise.D-Robotics.cc. Other updates: Support for the Chromium browser, users can install and use it with sudo apt install chromium. Version: 2.0.0 This release brings many anticipated features and improvements, aiming to provide a better development experience and broader application support. Here are the main highlights of this version release: Open-source: We have fully open-sourced the source code of the operating system, including the source code of system core modules and functional modules. Developers can freely view and modify the source code, providing greater flexibility for customization and optimization. Detailed code documentation and comments will be provided to developers to help them better understand and use the source code. We welcome developers to participate in code contribution and discussions through the open- source community, together driving the improvement and optimization of the operating system. The source code is maintained on D-Robotics. Support for RDK X3 Module: We introduce a brand new core board development kit, the RDK X3 Module. The RDK X3 Module has a smaller size and is compatible with the Raspberry Pi CM4 interface. Developers can choose compatible third-party carrier boards according to their needs to expand the functionality and application scenarios of the core board. EUR : M.DA ROSBTS SIO BORDEAUX - LYCÉE GUSTAVE EIFFEL ✦ 4 / 39 ✦ Other updates: We have optimized existing functions, fixed known issues and vulnerabilities, improving the stability and performance of the operating system. Revised the documentation and help documents, providing more comprehensive and accurate technical information and guidelines. We provide lower-level APIs to facilitate developers for secondary development and integration, enabling them to customize software more flexibly. 1.1 Preparation import Tabs from '@theme/Tabs'; import TabItem from '@theme/TabItem'; Before using the RDK X3 development board, the following preparations need to be made. Development Preparation Power Supply The RDK X3 development board is powered by a USB Type C interface. It requires a power adapter that supports 5V/3A to power the board. It is recommended to use the recommended power adapter model in the Basic Accessori…

Text truncated - open the document above for the full version.

D-ROBOTICS HOLDING LIMITED Add: SUITE 603,6/F LAWS COMM PLAZA 788 CHEUNG SHA WAN RD KLN HONG KONG,CHINA Tel: 00852-2923 2379 Fax: 00852-2923 2390 Email: [email protected] Attestation Letter Date: 2024-07-14 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Dear Sir or Madam: Our product RDK X3 Module, model: RDK X3 MD 104064，RDK X3 MD 104032, RDK X3 MD 1 02032，RDK X3 MD 102016，RDK X3 MD 102000, FCC ID: 2BGUG-RDKX3M, for marketing purpose, this product only supports BT(GFSK, π/4-DQPSK, 8DPSK), BLE 1M 2.4G Wi-Fi 2412-2462 MHz(802.11b/g/n ht20),2422-2452MHz(802.11n ht40), 5G Wi-Fi 5150-5250MHz,5725-5850MHz (802.11a/n ht20/ac vht20/n ht40/ac vht40/ac vht80).The other functions, bands and modes was disabled to use by manufacturer in the software, the end user has no capability to activate it. Sincerely, Printed Name: Chunxu Hu Title: Project Manager

D-ROBOTICS HOLDING LIMITED Add: SUITE 603,6/F LAWS COMM PLAZA 788 CHEUNG SHA WAN RD KLN HONG KONG,CHINA Tel: 00852-2923 2379 Fax: 00852-2923 2390 Email: [email protected] CFR 47 §2.911(d)(5)(i)(ii) Attestation Letter Attestation Letter Date: 2024-07-14 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(5)(i)(ii) Filing FCC ID: 2BGUG-RDKX3M D-ROBOTICS HOLDING LIMITED certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. D-ROBOTICS HOLDING LIMITED certifies that as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Signature Contact Person: Chunxu Hu Title: Project Manager

U.S. AGENT LETTER OF ATTESTATION Date: 202 4-07-14 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(7) Filing FCC ID: 2BGUG-RDKX3M D-ROBOTICS HOLDING LIMITED certifies that, as of the date of the filing of the application, Iconsigh Inc. is our designated U.S. agent for service of process for the above referenced FCC ID. D-ROBOTICS HOLDING LIMITED accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Iconsigh Inc. accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Company Name: Iconsigh Inc. Address: 2310 Homestead Road, Suite C1, Los Altos, CA, 94024, USA FRN: 0033398652 Tel.: +1 (408) 320-9867 Email: [email protected] Signed by (printed name): Benjamin Kaur Signature: Applicant: D-ROBOTICS HOLDING LIMITED Address: SUITE 603,6/F LAWS COMM PLAZA 788 CHEUNG SHA WAN RD KLN HONG KONG,CHINA FRN: 0035518919 Tel: 00852-2923 2379 Email: [email protected] Signed by (printed name): Chunxu Hu Signature:

QA-FR-170-B D-ROBOTICS HOLDING LIMITED Add: SUITE 603,6/F LAWS COMM PLAZA 788 CHEUNG SHA WAN RD KLN HONG KONG,CHINA Tel: 00852-2923 2379 Fax: 00852-2923 2390 Email: [email protected] FCC Authorization Date: 2024-07-14 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To whom it may concern: We , D-ROBOTICS HOLDING LIMITED, Hereby authorizes China Certification ICT Co., Ltd (Dongguan) to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by China Certification ICT Co., Ltd (Dongguan) on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. This authorization is valid until further written notice from the applicant. Sincerely Yours, Client’s signature Printed Name: Chunxu Hu Title: Project Manager

QA-F R-171-A D-ROBOTICS HOLDING LIMITED Add: SUITE 603,6/F LAWS COMM PLAZA 788 CHEUNG SHA WAN RD KLN HONG KONG,CHINA Tel: 00852-2923 2379 Fax: 00852-2923 2390 Email: [email protected] FCC Confidential Authorization Date: 202 4-07-14 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: 2BGUG-RDKX3M In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, (D-ROBOTICS HOLDING LIMITED) hereby requests long-term confidential treatment of information accompanying this application as outlined below: Block Diagra m Sch emati cs O peration Descriptio n SOFT WARE SECURITY DESCRIPTION The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely, Signature: Printed Name: Chunxu Hu Title: Project Manager

D-ROBOTICS HOLDING LIMITED Add: SUITE 603,6/F LAWS COMM PLAZA 788 CHEUNG SHA WAN RD KLN HONG KONG,CHINA Tel: 00852-2923 2379 Fax: 00852-2923 2390 Email: [email protected] Modular Approval Letter Date: 2024-07-14 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 We, D-ROBOTICS HOLDING LIMITED, hereby request Modular Approval for Product: RDK X3 Module (Model number: RDK X3 MD 104064，RDK X3 MD 104032, RDK X3 MD 102032，RDK X3 MD 102016，RDK X3 MD 102000, FCC ID: 2BGUG-RDKX3M).The EUT meets most of the requirement for modular approval as detailed in FCC 15.212. the requirements is described below: 1. The modular has RF shielding, please refer to the EUT photo. 2. The modular transmitter has buffered modulation/data inputs, Buffered data inputs stage has been integrated in chip (Model: RTL8821CS). 3. The modular transmitter has its own power supply regulation. Please refer to the Block Diagram. 4. Comply with the antenna requirements of Section 15.203 and 15.204(c), the modular have a PCB antenna permanently attached to the module, the maximum gain： maximum Gain antenna 2.4G 5.2G 5.8G dipole antenna 2.76dBi 2.33dBi 1.56dBi 5. The EUT was tested in a stand-alone configuration, please refer to setup photos exhibit for details. 6. The module labeled with its own FCC ID. 7. Comply with any specific rules or operating requirements that ordinarily apply to a complete transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. The necessary explanation to be complied with this requirement is contained in the user manual, and please refers to the User Manual. 8. Comply with any applicable RF exposure requirements in its final configuration. S incerely, Signature: Printed Name: Chunxu Hu Title: Project Manager

D-ROBOTICS HOLDING LIMITED Add: SUITE 603,6/F LAWS COMM PLAZA 788 CHEUNG SHA WAN RD KLN HONG KONG,CHINA Tel: 00852-2923 2379 Fax: 00852-2923 2390 Email: [email protected] DECLARATION OF SIMILARITY Date: 2024-07-14 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Dear Sir or M adam: We , D-ROBOTICS HOLDING LIMITED, hereby submits FCC ID:2BGUG-RDKX3M justification for placing the FCC ID label to user's manual. According to the FCC Regulation and Guidence (KDB Publication 784748 D01 v09R01) allows for the FCC to be removed to User Manual and box if the device is Unquestionably too small for the FCC ID label to be printed. The measurement of product:Length (55mm)*Width (40mm), The label Length 20 mm*5mm, Referring to the above quote,as the product are too small for the FCC ID label to be printed, so the FCC ID label will be moved to the User manual and box. Below photo will show the detail: FCC ID label will be moved from product to the User manual and box. Printed Name: Chunxu Hu Title: Project Manager 55mm 40mm 55mm 40mm 5mm 20mm

D-ROBOTICS HOLDING LIMITED Add: SUITE 603,6/F LAWS COMM PLAZA 788 CHEUNG SHA WAN RD KLN HONG KONG,CHINA Tel: 00852-2923 2379 Fax: 00852-2923 2390 Email: [email protected] DECLARATION OF SIMILARITY Date: 2024-07-14 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Dear Sir or Madam: We, D-R OBOTICS HOLDING LIMITED, hereby declare that the product: RDK X3 Module, FCC ID: 2BGUG-RDKX3M. model: RDK X3 MD 102032，RDK X3 MD 104032，RDK X3 MD 102016，RDK X3 MD 102000 are electrically identical with the model: RDK X3 MD 104064 which was tested by China Certification ICT Co., Ltd (Dongguan). A description of the differences between these models and that are declared similar are as follows, the rest are the same. internal storage RDK X3 MD 104064 4GB DDR+64GBEMMC RDK X3 MD 104032 4GB DDR+32GBEMMC RDK X3 MD 102032 2GB DDR+32GBEMMC RDK X3 MD 102016 2GB DDR+16GBEMMC RDK X3 MD 102000 2GB DDR Please contact me should there be need for any additional clarification or information. Best Regards, Signature: Printed Name: Chunxu Hu Title: Project Manager

China Certification ICT Co., Ltd (DongGuan) No.:2403T78343E‐RF‐EXP Page 1 of 11 EUT EXTERNAL PHOTOGRAPHS RDK X3 MD 104064 China Certification ICT Co., Ltd (DongGuan) No.:2403T78343E‐RF‐EXP Page 2 of 11 China Certification ICT Co., Ltd (DongGuan) No.:2403T78343E‐RF‐EXP Page 3 of 11 China Certification ICT Co., Ltd (DongGuan) No.:2403T78343E‐RF‐EXP Page 4 of 11 Antenna China Certification ICT Co., Ltd (DongGuan) No.:2403T78343E‐RF‐EXP Page 5 of 11 RDK X3 MD 104032 China Certification ICT Co., Ltd (DongGuan) No.:2403T78343E‐RF‐EXP Page 6 of 11 RDK X3 MD 102032 China Certification ICT Co., Ltd (DongGuan) No.:2403T78343E‐RF‐EXP Page 7 of 11 RDK X3 MD 102016 China Certification ICT Co., Ltd (DongGuan) No.:2403T78343E‐RF‐EXP Page 8 of 11 RDK X3 MD 102000 China Certification ICT Co., Ltd (DongGuan) No.:2403T78343E‐RF‐EXP Page 9 of 11 RDK X3 MD 102000 China Certification ICT Co., Ltd (DongGuan) No.:2403T78343E‐RF‐EXP Page 10 of 11 RDK X3 MD 102000 China Certification ICT Co., Ltd (DongGuan) No.:2403T78343E‐RF‐EXP Page 11 of 11

Model: RDK X3 MD 104064

China Certification ICT Co., Ltd (DongGuan) No.:2403T78343E‐RF‐INP Page 1 of 3 EUT INTERNAL PHOTOGRAPHS China Certification ICT Co., Ltd (DongGuan) No.:2403T78343E‐RF‐INP Page 2 of 3 DDR EMMC China Certification ICT Co., Ltd (DongGuan) No.:2403T78343E‐RF‐INP Page 3 of 3

RF EXPOSURE EVALUATION Applicant: D-ROBOTICS HOLDING LIMITED Address: SUITE 603,6/F LAWS COMM PLAZA 788 CHEUNG SHA WAN RD KLN HONG KONG,CHINA FCC ID: 2BGUG-RDKX3M Product Name: RDK X3 Module Standard(s): 47 CFR §1.1307, 47 CFR §2.1091 447498 D04 Interim General RF Exposure Guidance v01 The above device has been tested and found compliant with the requirement of the relative standards by China Certification ICT Co., Ltd (Dongguan) Report Number: 2403T78343E-RF-00F Date Of Issue: 2024/7/10 Reviewed By: Calvin Chen Title: RF Engineer Approved By: Sun Zhong Title: Manager Test Laboratory: China Certification ICT Co., Ltd (Dongguan) No. 113, Pingkang Road, Dalang Town, Dongguan, Guangdong, China Tel: +86-769-82016888 China Certification ICT Co., Ltd (Dongguan) Report No.: 2403T78343E-RF-00F Page 2 of 5 Test Facility The Test site used by China Certification ICT Co., Ltd (Dongguan) to collect test data is located on the No. 113, Pingkang Road, Dalang Town, Dongguan, Guangdong, China. The lab has been recognized as the FCC accredited lab under the KDB 974614 D01 and is listed in the FCC Public Access Link (PAL) database, FCC Registration No. : 442868, the FCC Designation No. : CN1314. Declarations China Certification ICT Co., Ltd (Dongguan) is not responsible for the authenticity of any test data provided by the applicant. Data included from the applicant that may affect test results are marked with a triangle symbol “▲”. Customer model name, addresses, names, trademarks etc. are not considered data. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report cannot be reproduced except in full, without prior written approval of the Company. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. This report may contain data that are not covered by the accreditation scope and shall be marked with an asterisk “★”. China Certification ICT Co., Ltd (Dongguan) Report No.: 2403T78343E-RF-00F Page 3 of 5 DOCUMENT REVISION HISTORY Revision Number Report Number Description of Revision Date of Revision 1.0 2403T78343E-RF-00F Original Report 2024/7/10 China Certification ICT Co., Ltd (Dongguan) Report No.: 2403T78343E-RF-00F Page 4 of 5 1. GENERAL INFORMATION 1.1 Product Description for Equipment under Test (EUT) EUT Name: RDK X3 Module EUT Model: RDK X3 MD 104064 Multiple Model: RDK X3 MD 102032, RDK X3 MD 104032, RDK X3 MD 102016, RDK X3 MD 102000 Rated Input Voltage: DC 5V Serial Number: 2M3N-1 EUT Received Date: 2024/5/27 EUT Received Status: Good Note: The multiple models are electrically identical with the test model. Please refer to the declaration letter for more detail, which was provided by manufacturer. China Certification ICT Co., Ltd (Dongguan) Report No.: 2403T78343E-RF-00F Page 5 of 5 2. RF EXPOSURE EVALUATION 2.1 Applicable Standard According to §1.1307(b)(3)(i) (C) Or using Table 1 and the minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that frequency. For the exemption in Table 1 to apply, R must be at least λ/2π, where λ is the free-space operating wavelength in meters. If the ERP of a single RF source is not easily obtained, then the available maximum time-averaged power may be used in lieu of ERP if the physical dimensions of the radiating structure(s) do not exceed the electrical length of λ/4 or if the antenna gain is less than that of a half-wave dipole (1.64 linear value). Table 1 to § 1.1307(b)(3)(i)(C) - Single RF Sources Subject to Routine Environmental Evaluation RF Source frequency (MHz) Threshold ERP (watts) 0.3-1.34 1,920 R 2 . 1.34-30 3,450 R 2 /f 2 . 30-300 3.83 R 2 . 300-1,500 0.0128 R 2 f. 1,500-100,000 19.2R 2 . 2.2 Measurement Result Radio Frequency (MHz) λ/2Π (mm) Distance (mm) Exemption ERP (mW) Maximum Conducted Power including Tune-up Tolerance (dBm) Antenna Gain (dBi) ERP dBm mW BDR/EDR 2402-2480 19.88 200 768 8 2.76 8.61 7.26 BLE 2402-2480 19.88 200 768 6 2.76 6.61 4.58 2.4G Wi-Fi 2412-2462 19.80 200 768 23 2.76 23.61 229.61 5.2G Wi-Fi 5180-5240 9.22 200 768 14 2.33 14.18 26.18 5.8G Wi-Fi 5745-5825 8.31 200 768 14 1.56 13.41 21.93 Note: 1. The Maximum Conducted Power including Tune-up Tolerance was declared by manufacturer. 2. The BT and Wi-Fi cannot transmit simultaneously. Result: The device compliant the MPE-Based Exemption at 20cm distances. ===== END OF REPORT =====

Manufacturer:D-ROBOTICS HOLDING LIMITED 2.4 GHz + 5 GHz Dual-band Dipole Antenna General Specifications RF Specifications Frequency (MHz) Gain (dBi) 2400 2.10 2450 2.76 2500 1.3 5150 2.3 5250 2.33 5350 2.47 5425 2.25 5550 2.15 5725 1.56 5850 1.03 Frequency Range 2400 – 2500 MHz 5150 – 5850 MHz V.S.W.R ≤ 3.0 Radiation Toroidal Polarization Linear Impedance 50 Ω Connector RP-SMA female Dimensions 110 x Ø10 mm Weight g Operating Temperature -40 °C to 65 °C -40°F to 149°F SUITE 603，6/F LAWS COMM PLAZA 788 CHEUNG SHA WAN RD KLN HONG KONG,CHINA Antenna Report H -Plane E-Plane

TEST REPORT Applicant: D-ROBOTICS HOLDING LIMITED Address: SUITE 603,6/F LAWS COMM PLAZA 788 CHEUNG SHA WAN RD KLN HONG KONG,CHINA FCC ID: 2BGUG-RDKX3M Product Name: RDK X3 Module Standard(s): 47 CFR Part 15, Subpart C(15.247) ANSI C63.10-2013 KDB 558074 D01 15.247 Meas Guidance v05r02 The above device has been tested and found compliant with the requirement of the relative standards by China Certification ICT Co., Ltd (Dongguan) Report Number: 2403T78343E-RF-00B Date Of Issue: 2024/7/9 Reviewed By: Calvin Chen Title: RF Engineer Approved By: Sun Zhong Title: Manager Test Laboratory: China Certification ICT Co., Ltd (Dongguan) No. 113, Pingkang Road, Dalang Town, Dongguan, Guangdong, China Tel: +86-769-82016888 China Certification ICT Co., Ltd (Dongguan) Report No.:2403T78343E-RF-00B Page 2 of 71 Test Facility The Test site used by China Certification ICT Co., Ltd (Dongguan) to collect test data is located on the No. 113, Pingkang Road, Dalang Town, Dongguan, Guangdong, China. The lab has been recognized as the FCC accredited lab under the KDB 974614 D01 and is listed in the FCC Public Access Link (PAL) database, FCC Registration No. : 442868, the FCC Designation No. : CN1314. Declarations China Certification ICT Co., Ltd (Dongguan) is not responsible for the authenticity of any test data provided by the applicant. Data included from the applicant that may affect test results are marked with a triangle symbol “▲”. Customer model name, addresses, names, trademarks etc. are not considered data. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report cannot be reproduced except in full, without prior written approval of the Company. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. This report may contain data that are not covered by the accreditation scope and shall be marked with an asterisk “★”. China Certification ICT Co., Ltd (Dongguan) Report No.:2403T78343E-RF-00B Page 3 of 71 CONTENTS DOCUMENT REVISION HISTORY .......................................................................................... 5 1. GENERAL INFORMATION .................................................................................................... 6 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ....................................................... 6 1.2 DESCRIPTION OF TEST CONFIGURATION ........................................................................................... 7 1.2.1 EUT Operation Condition: ............................................................................................................................. 7 1.2.2 Support Equipment List and Details .............................................................................................................. 7 1.2.3 Support Cable List and Details ...................................................................................................................... 7 1.2.4 Block Diagram of Test Setup ......................................................................................................................... 8 1.3 MEASUREMENT UNCERTAINTY .......................................................................................................... 9 2. SUMMARY OF TEST RESULTS .......................................................................................... 10 3. REQUIREMENTS AND TEST PROCEDURES .................................................................. 11 3.1 AC LINE CONDUCTED EMISSIONS .................................................................................................... 11 3.1.1 Applicable Standard ..................................................................................................................................... 11 3.1.2 EUT Setup.................................................................................................................................................... 12 3.1.3 EMI Test Receiver Setup ............................................................................................................................. 12 3.1.4 Test Procedure ............................................................................................................................................. 13 3.1.5 Corrected Amplitude & Margin Calculation ................................................................................................ 13 3.2 RADIATED SPURIOUS EMISSIONS ...................................................................................................... 14 3.2.1 Applicable Standard ..................................................................................................................................... 14 3.2.2 EUT Setup.................................................................................................................................................... 14 3.2.3 EMI Test Receiver & Spectrum Analyzer Setup ......................................................................................... 15 3.2.4 Test Procedure ............................................................................................................................................. 16 3.2.5 Corrected Amplitude & Margin Calculation ................................................................................................ 16 3.3 20 DB EMISSION BANDWIDTH ........................................................................................................... 17 3.3.1 Applicable Standard ..................................................................................................................................... 17 3.3.2 EUT Setup.................................................................................................................................................... 17 3.3.3 Test Procedure ...........................................................................................…

Text truncated - open the document above for the full version.

China Certification ICT Co., Ltd (DongGuan) Report No.:2403T78343E‐RF‐00B‐TSP Page 1 of 4 TEST SETUP PHOTOGRAPHS Conducted Emissions Front View Conducted Emissions Side View China Certification ICT Co., Ltd (DongGuan) Report No.:2403T78343E‐RF‐00B‐TSP Page 2 of 4 Radiated Emission 30 MHz-1 GHz View Radiated Emission 9 kHz-30 MHz Parallel View China Certification ICT Co., Ltd (DongGuan) Report No.:2403T78343E‐RF‐00B‐TSP Page 3 of 4 Radiated Emission 9 kHz-30 MHz Perpendicular View Radiated Emission 9 kHz-30 MHz Ground-parallel View China Certification ICT Co., Ltd (DongGuan) Report No.:2403T78343E‐RF‐00B‐TSP Page 4 of 4 Radiated Emission Above 1GHz View 1-18G Radiated Emission Above 1GHz View 18-25G
