2BGUG-RDKX5MRDK X5 Module

rdk_x5 copy.md2025-07-22 1 CoreModuleInterface All on-board design, nocore module. The RDK X5Module carrierboard provides a set of300pinboard-to-boardconnectors forcore module installation. During installation, the correct directionand positioning must rstbeconrmed toavoid damage to thecore module and carrierboardconnectors. The module installation method is as follows: 1. Check the pin orientation of the core module toconrm thecorrect installation direction. 2. Place the core module directlyabove the carrier boardand ensure the four positioning holes around arealigned. 3. Press down from the center of the core module. When the moduleclicks, it indicates proper installation. PowerInterface The developmentboard provides one USB TypeC interface(interface1)as the power supply interface, requiringa power adapter that supports 5V/5A to power the developmentboard.Afterconnecting the power adapter to the developmentboard,the greenpower indicator light turns on, indicating normal power supply to the developmentboard.After version3.1.0,theorangestatus indicator light ashes, indicating normal system operation. RDK X5 Module User Manual The developmentboard provides one USB TypeC interface(interface1)as the power supply interface, requiringa power adapter that supports 5V/5A to power the developmentboard.Afterconnecting the power adapter to the developmentboard,the green5VindicatorPWR indicator light turns on, indicating rdk_x5 copy.md2025-07-22 2 normal power supply to the developmentboard,and the greenACT indicator light ashes,indicating normal system operation. Do not use thecomputer's USB interface to power the developmentboard,otherwise,insucient power supply maycause the developmentboard to experienceunexpected power lossand repeated restarts. Debug SerialPort{#debug_uart} The developmentboard provides one debug serial port(interface4)toachieve serial port login and debugging functions.The parameterconguration of the computer's serial port tool is as follows: Baud rate: 115200 Databits:8 Parity: None Stopbits: 1 FlowControl: None For serial port connection, connect the developmentboard interface4 to the PCusing a Micro-USBcable. The developmentboard provides one debug serial port(rear interface22) toachieve serial port login and debugging functions.The parameterconguration of the computer's serial port tool is as follows: Baud rate: 921600 Databits:8 Parity: None Stopbits: 1 FlowControl: None For serial port connection, connect the developmentboard interface22to the PCusing a Micro-USBcable. Generally,when users use this interface for the rst time, they need to install the CH340 driver on the computer. Users can search for the keyword CH340 serial port driver to download and install it. WiredNetworkPort The developmentboard provides one Gigabit Ethernet interface(interface6), supporting1000BASE-Tand 100BASE-T standards, with static IP mode enabled by default, and the IP address is 192.168.127.10. To conrm the developmentboard's IPaddress,youcan log in to the device via the serial portand use the ifconfig command to view the eth0 network port conguration. Additionally, this interface supportsPoE (Power overEthernet) functionality,allowing simultaneous dataand power transmission through the networkcable without the need foradditional power cables, making device installation moreconvenientand exible. HDMIDisplayInterface{#hdmi_interface} The developmentboard provides one HDMI(interface10) display interface, supporting up to1080P resolution. The developmentboard outputs the Ubuntu system desktop (UbuntuServer version displays logo icon)on the monitor through the HDMIinterface. Additionally, the HDMIinterface supports real-time display ofcameraand network stream images. rdk_x5 copy.md2025-07-22 3 The developmentboard provides one HDMI(interface21) display interface, supporting up to1080P resolution. The developmentboard outputs the Ubuntu system desktop (UbuntuServer version displays logo icon)on the monitor through the HDMIinterface. Additionally, the HDMIinterface supports real-time display ofcameraand network stream images. USB DisplayInterface The developmentboardachieves multi-channelUSB interface expansion through hardwarecircuits to meet user demands forconnecting multiple USB devices.The interface descriptions areas follows: Interface Type Interface Number QuantityDescription USB 2.0 TypeC Interface 3 1 channel USB Device mode, used toconnect to the host to implement ADB, Fastboot, systemburning, and other functions USB 3.0 TypeA Interface 7 4 channels USB Host mode, expanding into4 USB ports throughHUB,used to connect USB 3.0 peripherals The developmentboardachieves multi-channelUSB interface expansion through hardwarecircuits to meet user demands forconnecting multiple USB devices.The interface descriptions areas follows: Interface Type Interface Number QuantityDescription USB 2.0 TypeC Interface3 1 channel USB Device mode, used toconnect to the host to implement ADB,Fastboot, systemburning, and other functions USB 3.0 TypeA Interface4 & Interface5 4 channels USB Host mode, expanding into4 USB ports throughHUB, used toconnect USB 3.0 peripherals USB 2.0 Switch toHOST The developmentboardcan short-circuit interface2 to switchUSB 2.0 toHOSTmode. Connectinga USB Drive The developmentboard's USB TypeA interface supports USB drive functionality,capable ofautomatically detecting and mounting connected USB drives. The default mount directory is /media/sda1. Connectinga USB toSerialAdapter Board The developmentboard's USB TypeA interface supports USB to serialadapterboard functionality,capable of automatically detecting the connection and creating device nodes /dev/ttyUSB* or /dev/ttyACM* (the asterisk representsa number starting from0). Users can refer to the UsingSerialPortschapter for usage instructions. USB Camera The developmentboard's USB TypeA interface supports USB camerafunctionality,capable ofautomatically detecting connected USB cameras and creating device node /dev/video0…

Text truncated - open the document above for the full version.

D-ROBOTICS HOLDING LIMITED Add: SUITE 603,6/F LAWS COMM PLAZA 788 CHEUNG SHA WAN RD KLN HONG KONG, CHINA Tel: 00852-2923 2379 Fax: 00852-2923 2390 Email: developer@d-robot ics.cc Attestation Letter Date: 2025-10-20 FEDERAL COMMUNICATIONS COMMISSION Authorizat ion and Evaluation Divisio n 7435 Oakland Mills Road Columbia, MD 21046 Dear Sir or Madam: Sincerely, Signature: Printed Name: Chunxu Hu Title: Project Manager Our product RDK X5 Module, FCC ID: 2BGUG-RDKX5M, model: RDKX5MD108064, RDKX5MD102000, RDKX5MD102016, RDKX5MD102032, RDKX5MD102064, RDKX5MD104000, RDKX5MD104016, RDKX5MD104032, RDKX5MD104064, RDKX5MD108000, RDKX5MD108016, RDKX5MD108032 for marketing purpose, this product only supports BT(GFSK, π/4-DQPSK, 8DPSK), BLE 1M&2M, 2.4G Wi-Fi 2412-2462MHz (802.11b/g/n ht20/ax hew20), 2422-2452MHz (802.11n ht40/ax hew40 ), 5G Wi-Fi (5150-5250MHz, 5725-5850MHz, 802.11a/n ht20/ac vht20/ax hew20, 802.11n ht40/ac vht40/ax hew40, 802.11ac vht80/ax hew80), 802.11ax mode only supports full RU and doesn't support partial RU. The other functions, b ands and modes was disabled to u se by manufacturer in the software, the end user has no capability to activate it.

D-ROBOTICS HOLDING LIMITED Add: SUITE 603,6/F LAWS COMM PLAZA 788 CHEUNG SHA WAN RD KLN HONG KONG, CHINA Tel: 00852-2923 2379 Fax: 00852-2923 2390 Email: developer@d-robot ics.cc CFR 47 §2.911(d)(5)(i)(ii) Attestation Letter Attestation Letter Date: 10/20/2025 FEDERAL COMMUNICATIONS COMMISSIONS Authorizat ion and Evaluation Divisio n 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(5)(i)(ii) Filing FCC I D: 2BGUG-RDKX5M D-ROBOTICS HOLDING LIMITED (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. D-ROB OTICS HOLDING LIMITED (“the applicant”) certifies that as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. D-ROB OTICS HOLDING LIMITED (“the applicant”) certifies that the equipment does not use Kaspersky's software information. Sincerely, Sig nature: Pr inted Name: Chunxu Hu Title: Project Manager

U.S. AGENT LETTER OF ATTESTATION Date: 2025-10-20 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(7) Filing FCC ID: 2BGUG-RDKX5M D-ROBOTICS HOLDING LIMITED certifies that, as of the date of the filing of the application, Iconsigh Inc. is our designated U.S. agent for service of process for the above referenced FCC ID. D-ROBOTICS HOLDING LIMITED accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusio n of any Co mmissio n-related proceeding involving the equipment. Iconsigh Inc. accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Company Name: Iconsigh Inc. Address: 2310 Homestead Road, Suite C1, Los Altos, CA, 94024, USA FRN: 0033398652 Tel.: +1 (408) 320-9867 Email: [email protected] Signed by (printed name): Benjamin Kaur Signature: Applicant: D-ROBOTICS HOLDING LIMITED Address: SUITE 603,6/F LAWS COMM PLAZA 788 CHEUNG SHA WAN RD KLN HONG KONG FRN: 0035518919 Tel: 00852-2923 2379 Email: [email protected] Signed by (printed name): Chunxu Hu Signature:

QA-FR-170-B D-ROBOTICS HOLDING LIMITED Ad d: SUITE 603,6/F LAWS COMM PLAZA 788 CHEUNG SHA WAN RD KLN HONG KONG, CHINA Tel: 00852-2923 2379 Fax: 00852-2923 2390 Email: developer@d-robot ics.cc FCC Authorization Date: 2025-10-20 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To whom it may concern: We, D-ROBOTICS HOLDING LIMITED, Hereby authorizes Bay Area Compliance Laboratories Corp.(Dongguan) to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by Bay Area Compliance Laboratory Corp.(Dongguan) on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely Yours, Client’s signature Printed Name: Chunxu Hu This authorization is valid until further written notice from the applicant. Title: Project Manager

QA-FR-171-A D-ROBOTICS HOLDING LIMITED Add: SUITE 603,6/F LAWS COMM PLAZA 788 CHEUNG SHA WAN RD KLN HONG KONG,CHINA Tel: 00852-2923 2379 Fax: 00852-2923 2390 Email: [email protected] FCC Confidential Authorization Date: 2025-10-20 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: 2BGUG-RDKX5M In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, D-ROBOTICS HOLDING LIMITED hereby requests long-term confidential treatment of information accompanying this application as outlined below: •Block Diagram •Schematics •Operation Description •SOFTWARE SECURITY DESCRIPTION The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely, Signature: Printed Name: Chunxu Hu Title: Project Manager

D-ROBOTICS HOLDING LIMITED Add: SUITE 603,6/F LAWS COMM PLAZA 788 CHEUNG SHA WAN RD KLN HONG KONG, CHINA Tel: 00852-2923 2379 Fax: 00852-2923 2390 Email: [email protected] DECLARA TION OF SIMILARITY Date: 2025-08-14 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Dear Sir o r Madam: We, D-ROBOTICS HOLDING LIMITED, hereby declare that the product: RDK X5 Module, FCC ID: 2BGUG-RDKX5M, model: RDKX5MD108032, RDKX5MD108016, RDKX5MD108000, RDKX5MD104064, RDKX5MD104032, RDKX5MD104016, RDKX5MD104000, RDKX5MD102064, RDKX5MD102032, RDKX5MD102016, RDKX5MD102000 is electrically identical with the model: RDKX5MD108064 which was tested by Bay Area Compliance Laboratories Corp.(Dongguan). A description of the differences between 12 models and that are declared similar are as follows： The first digit: 1 indicates the presence of wireless functionality, equipped FCS960K wireless module; Third digit: Represents RAM memory; 2G/4G/8G, and they are provided by different manufacturers; (Note: There are three models of RAM IC for RDKX5MD1040XX, that are GDB5CCQN-ML, CXDB5CCBM-MA-A and CXDB5CBAM-MA-B. They come from different manufacturers, except for differences in manufacturer and model, everything else is the same and can be replaced with each other.) Fifth and Sixth Digit: Represents memory, 0 (no memory)/16G/32G/64G. (Note: 64G eMMC can be equipped with E64GCM7T1ABE00 or KLMCG2UCTB-B041. They are all the same except for the manufacturer and model, and can be replaced with each other.) This means RDKX5MD108064 is the maximum configuration of this product. The following table lists the differences: product Model RAM EMMC Specification Model Specification Model RDKX5MD102000 2GB,LPDDR4, 4266Mbps, 200ball FBGA GDB4CBQN-ML NA NA RDKX5MD102016 16GB,eMMC, 2.7V~3.6V,FBGA-153 E16GCYNB1ABE00 RDKX5MD102032 32GB,eMMC, 2.7V~3.6V,FBGA-153 E32GCYNB1ABE00 RDKX5MD102064 64GB,eMMC, 2.7V~3.6V,FBGA-153 E64GCM7T1ABE00 KLMCG2UCTB-B041 RDKX5MD104000 4GB,LPDDR4, 4266Mbps, 200ball FBGA GDB5CCQN-ML CXDB5CCBM-MA-A CXDB5CBAM-MA-B NA NA RDKX5MD104016 16GB,eMMC, 2.7V~3.6V,FBGA-153 E16GCYNB1ABE00 RDKX5MD104032 32GB,eMMC, 2.7V~3.6V,FBGA-153 E32GCYNB1ABE00 RDKX5MD104064 64GB,eMMC, 2.7V~3.6V,FBGA-153 E64GCM7T1ABE00 KLMCG2UCTB-B041 RDKX5MD108000 8GB,LPDDR4, 4266Mbps, 200ball FBGA DL4A64G32N4V-EC NA NA RDKX5MD108016 16GB,eMMC, 2.7V~3.6V,FBGA-153 E16GCYNB1ABE00 RDKX5MD108032 32GB,eMMC, 2.7V~3.6V,FBGA-153 E32GCYNB1ABE00 RDKX5MD108064 64GB,eMMC, 2.7V~3.6V,FBGA-153 E64GCM7T1ABE00 KLMCG2UCTB-B041 Please contact me should there be need for any additional clarification or information. Best Regards, Signature: Printed Name: Chunxu Hu Title: Project Manager

D-ROBOTICS HOLDING LIMITED Add: SUITE 603,6/F LAWS COMM PLAZA 788 CHEUNG SHA WAN RD KLN HONG KONG, CHINA Tel: 00852-2923 2379 Fax: 00852-2923 2390 Email: [email protected] Modular Approval Letter Date:2025-10-20 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 We, D-ROBOTICS HOLDING LIMITED, hereby request Modular Approval for Product: RDK X5 Module (Model number: RDKX5MD108064, RDKX5MD102000, RDKX5MD102016, RDKX5MD102032, RDKX5MD102064, RDKX5MD104000, RDKX5MD104016, RDKX5MD104032, RDKX5MD104064, RDKX5MD108000, RDKX5MD108016, RDKX5MD108032, FCC ID: 2BGUG-RDKX5M). The requirement of FCC 15.212 as below: Item § 15.212 RequirementY/N Comments (i) The radio elements of the modular transmitter must have their own shielding. The physical crystal and tuning capacitors may be located external to the shielded radio elements. Yes The modular has RF shielding, please refer to the EUT photo. (ii) The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with part 15 requirements under conditions of excessive data rates or over-modulation. Yes The modular transmitter has buffered modulation/data inputs, Buffered data inputs stage has been integrated in chip (Model: FCS960K). (iii) The modular transmitter must have its own power supply regulation. Yes The modular transmitter has its own power supply regulation. Please refer to the Block Diagram. (iv) The modular transmitter must comply with the antenna and transmission system requirements of §§ 15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The “professional installation” provision of § 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. Yes Comply with the antenna requirements of Section 15.203 and 15.204(c), the modular have a chip antenna permanently attached to the module, the maximum gain is 3.12dBi. (v) The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing for compliance with part 15 requirements. Unless the transmitter module will be battery powered, it must comply with the AC line conducted requirements found in § 15.207. AC or DC power lines and data input/output lines connected to the module must not contain ferrites, unless they will be marketed with the module (see § 15.27(a)). The length of these lines shall be the length typical of actual use or, if that length is unknown, at least 10 centimeters to insure that there is no coupling between the case of the module and supporting equipment. Any accessories, peripherals, or support equipment connected to the module during testing shall be unmodified and commercially available (see § 15.31(i)). Yes The EUT was tested in a stand-alone configuration, please refer to setup photos exhibit for details. (vi) The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying its FCC identification number. Yes The module labeled with its own FCC ID. (vii) The modular transmitter must comply with any specific rules or operating requirements that ordinarily apply to a complete transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. Yes Comply with any specific rules or operating requirements that ordinarily apply to a complete transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. The necessary explanation to be complied with this requirement is contained in the user manual, and please refers to the User Manual. (viii) Radio frequency devices operating under the provisions of this part are subject to the radio frequency radiation exposure requirements specified in §§ 1.1307(b), 1.1310, 2.1091, and 2.1093 of this chapter. Yes It meets RF exposure requirements with distances greater than or equal to 20cm infinal configuration. Si ncerely, Si gnature: Printed Name: Chunxu Hu Title: Project Manager

Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2502U67463E-RF-EXP Page 1 / 13 EUT EXTERNAL PHOTOS RDKX5MD108064 RDKX5MD108032 RDKX5MD108016 RDKX5MD104032 RDKX5MD104064 RDKX 5MD104016 RDKX5MD108000 RDKX5MD102032 RDKX5MD102000 RDKX5MD102016 RDKX5MD102064 RDKX5MD104000 Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2502U67463E-RF-EXP Page 2 / 13 Model: RDKX5MD108064 no use antenna port Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2502U67463E-RF-EXP Page 3 / 13 Model: RDKX5MD102000 no use antenna port Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2502U67463E-RF-EXP Page 4 / 13 Model: RDKX5MD102016 no use antenna port Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2502U67463E-RF-EXP Page 5 / 13 Model: RDKX5MD102032 no use antenna port Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2502U67463E-RF-EXP Page 6 / 13 Model: RDKX5MD102064 no use antenna port Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2502U67463E-RF-EXP Page 7 / 13 Model: RDKX5MD104000 no use antenna port Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2502U67463E-RF-EXP Page 8 / 13 Model: RDKX5MD104016 no use antenna port Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2502U67463E-RF-EXP Page 9 / 13 Model: RDKX5MD104032 no use antenna port Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2502U67463E-RF-EXP Page 10 / 13 Model:RDKX5MD104064 no use antenna port Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2502U67463E-RF-EXP Page 11 / 13 Model: RDKX5MD108000 no use antenna port Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2502U67463E-RF-EXP Page 12 / 13 Model: RDKX5MD108016 no use antenna port Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2502U67463E-RF-EXP Page 13 / 13 Model: RDKX5MD108032 *****END ***** no use antenna port

Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2502U67463E-RF-INP Page 1 / 19 EUT INTERNAL PHOTOS Model: RDKX5MD108064 RAM(8GB):DL4A64G32N4V-EC EMMC(64GB): E64GCM7T1ABE00 Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2502U67463E-RF-INP Page 2 / 19 Bluetooth&Wifi Antenna Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2502U67463E-RF-INP Page 3 / 19 Model: RDKX5MD102000 No EMMC Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2502U67463E-RF-INP Page 4 / 19 RAM(2GB):GDB4CBQN-ML Bluetooth&Wifi Antenna Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2502U67463E-RF-INP Page 5 / 19 Model: RDKX5MD102016 RAM(2GB):GDB4CBQN-ML EMMC(16GB): E16GCYNB1ABE00 Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2502U67463E-RF-INP Page 6 / 19 Bluetooth&Wifi Antenna Model: RDKX5MD102032 EMMC(32GB): E32GCYNB1ABE00 Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2502U67463E-RF-INP Page 7 / 19 RAM(2GB): GDB4CBQN-ML Bluetooth&Wifi Antenna Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2502U67463E-RF-INP Page 8 / 19 Model: RDKX5MD102064 RAM(2GB):GDB4CBQN-ML EMMC(64GB): KLMCG2UCTB-B041 Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2502U67463E-RF-INP Page 9 / 19 Bluetooth&Wifi Antenna Model: RDKX5MD104000 No EMMC Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2502U67463E-RF-INP Page 10 / 19 RAM(4GB): CXDB5CCBM-MA-A Bluetooth&Wifi Antenna Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2502U67463E-RF-INP Page 11 / 19 Model: RDKX5MD104016 RAM(4GB): CXDB5CCBM-MA-A EMMC(16GB): E16GCYNB1ABE00 Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2502U67463E-RF-INP Page 12 / 19 Bluetooth&Wifi Antenna Model: RDKX5MD104032 EMMC(32GB): E32GCYNB1ABE00 Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2502U67463E-RF-INP Page 13 / 19 RAM(4GB): CXDB5CCBM-MA-A Bluetooth&Wifi Antenna Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2502U67463E-RF-INP Page 14 / 19 Model: RDKX5MD104064 RAM(4GB): CXDB5CCBM-MA-A EMMC(64GB): KLMCG2UCTB-B041 Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2502U67463E-RF-INP Page 15 / 19 Bluetooth&Wifi Antenna Model: RDKX5MD108000 No EMMC Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2502U67463E-RF-INP Page 16 / 19 RAM(8GB): DL4A64G32N4V-EC Bluetooth&Wifi Antenna Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2502U67463E-RF-INP Page 17 / 19 Model: RDKX5MD108016 RAM(8GB): DL4A64G32N4V-EC EMMC(16GB): E16GCYNB1ABE00 Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2502U67463E-RF-INP Page 18 / 19 Bluetooth&Wifi Antenna Model: RDKX5MD108032 EMMC(32GB): E32GCYNB1ABE00 Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2502U67463E-RF-INP Page 19 / 19 RAM(8GB): DL4A64G32N4V-EC Bluetooth&Wifi Antenna *****END *****

MAXIMUM PERMISSIBLE EXPOSURE EVALUATION REPORT Applicant: D-ROBOTICS HOLDING LIMITED Address: SUITE 603, 6/F LAWS COMM PLAZA 788 CHEUNG SHA WAN RD KLN HONG KONG, CHINA Product Name: RDK X5 Module F C C I D : 2BGUG-RDKX5M Standard(s): 47 CFR §1.1310, 47 CFR §2.1091, 47 CFR §15.247(i), 47 CFR §15.407(f) Report Number: 2502U67463E-RF-00F Report Date: 2025/10/24 The above device has been tested and found compliant with the requirement of the relative standards by Bay Area Compliance Laboratories Corp. (Dongguan). Reviewed By: Alice Tan Approved By: Pedro Yun Title: RF Engineer Title: RF Supervisor Bay Area Compliance Laboratories Corp. (Dongguan) No.12, Pulong East 1 st Road, Tangxia Town, Dongguan, Guangdong, China Tel: +86-769-86858888 Fax: +86-769-86858891 www.baclcorp.com.cn Note: The information marked ▲ is provided by the applicant, the laboratory is not responsible for its authenticity and this information can affect the validity of the result in the test report. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report cannot be reproduced except in full, without prior written approval of the Company. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. This report may contain data that are not covered by the accreditation scope and shall be marked with ★.This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the U.S. Government. Each test item follows the test standard(s) without deviation. Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: 2502U67463E-RF-00F Report Template Version: FCC §2.1091-V1.0 Page 2 of 6 CONTENTS DOCUMENT REVISION HISTORY .......................................................................................... 3 1. GENERAL INFORMATION .................................................................................................... 4 1.1 GENERAL DESCRIPTION OF EQUIPMENT UNDER TEST ..................................................................... 4 2.RF EXPOSURE EVALUATION (MPE) ................................................................................... 5 2.1. RF EXPOSURE EVALUATION .............................................................................................................. 5 2.1.1 Applicable Standard ....................................................................................................................................... 5 2.1.2 Calculation formula ....................................................................................................................................... 5 2.1.3 Calculated Data: ............................................................................................................................................. 5 EXHIBIT A - EUT PHOTOGRAPHS .......................................................................................... 6 Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: 2502U67463E-RF-00F Report Template Version: FCC §2.1091-V1.0 Page 3 of 6 DOCUMENT REVISION HISTORY Revision Number Report Number Description of Revision Date of Revision 1.0 2502U67463E-RF-00F Original Report 2025/10/24 Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: 2502U67463E-RF-00F Report Template Version: FCC §2.1091-V1.0 Page 4 of 6 1. GENERAL INFORMATION 1.1 General Description Of Equipment under Test EUT Name: RDK X5 Module EUT Model: RDKX5MD108064 Multiple Models: RDKX5MD102000, RDKX5MD102016, RDKX5MD102032, RDKX5MD102064, RDKX5MD104000, RDKX5MD104016, RDKX5MD104032, RDKX5MD104064, RDKX5MD108000, RDKX5MD108016, RDKX5MD108032 Rated Input Voltage: DC 5V EUT Received Date: 2025/6/30 EUT Received Status: Good Note: The multiple models are electrically identical with the test model. Please refer to the declaration letter for more detail, which was provided by manufacturer. Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: 2502U67463E-RF-00F Report Template Version: FCC §2.1091-V1.0 Page 5 of 6 2.RF EXPOSURE EVALUATION (MPE) 2.1. RF Exposure Evaluation 2.1.1 Applicable Standard According to subpart 15.247(i), 15.407(f)and subpart §1.1310, systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for Maximum Permissible Exposure (MPE) (§1.1310, §2.1091) (B) Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f²) 30 30–300 27.5 0.073 0.2 30 300–1500 / / f/1500 30 1500–100,000 / / 1.0 30 f = frequency in MHz; * = Plane-wave equivalent power density; According to §1.1310 and §2.1091 RF exposure is calculated. 2.1.2 Calculation formula Prediction of power density at the distance of the applicable MPE limit S = PG/4R² = power density (in appropriate units, e.g. mW/cm 2 ); P = power input to the antenna (in appropriate units, e.g., mW); G = power gain of the antenna in the direction of interest relative to an isotropic radiator, the power gain factor, is normally numeric gain; R = distance to the center of radiation of the antenna (appropriate units, e.g., cm); 2.1.3 Calculated Data: Operation Modes Frequency (MHz) Antenna Gain ▲ Conducted output power including Tune-up Tolerance ▲ Evaluation Distance (cm) Power Density (mW/cm 2 ) MPE Limit (mW/cm 2 ) (dBi) (numeric)(dBm)(mW) BT 2402-24800.43 1.103.02.0020.000.0004 1.0 BLE 2402-24800.43 1.10 3.02.0020.000.0004 1.0 2.4G Wifi 2412-24620.43 1.10 22.5177.8320.00 0.0391 1.0 5G Wifi 5150-52503.0 2.009.58.9120.000.0035 1.0 5725-58503.12 2.05 13.019.9520.000.0081 1.0 Note: The Antenna Gain and Conducted output power including Tune-up Tolerance provided by manufact…

Text truncated - open the document above for the full version.

TEST REPORT Applicant: D-ROBOTICS HOLDING LIMITED Address: SUITE 603, 6/F LAWS COMM PLAZA 788 CHEUNG SHA WAN RD KLN HONG KONG, CHINA Product Name: RDK X5 Module F C C I D : 2BGUG-RDKX5M Standard(s): 47 CFR Part 15, Subpart E(15.407) ANSI C63.10-2020+Cor. 1-2023+C63.10a-2024 + Errata to C63.10a-2024 ★ KDB 789033 D02 General U-NI…

Text truncated - open the document above for the full version.
