2BGX5-5000Magnetic Wireless Powerbank

 FCC statement 1.This device complies with Part 15 of the FCC Rules. Operation is subject to thefollowing two conditions: (1)This device may not cause harmful interference. (2)This device must accept any interference received, including interference that maycause undesired operation. 2.Changes or modications not expressly approved by the party r esponsible f orcompliance could void the user’s authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a class B digital device,pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequence energy and,if not ins talled and used in accordance with the instructions,may cause harmful interference to radio communications. However,there is no guarantee that interference will not occur in a particular installation.if this equipmemt does cause harmful interference to radio or television reception,which can be determined by turning the equipment o and on,the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit dierent from that to which thereceiver is connected. • Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.  CDB01-5,YDDY01-5

Shenzhen Putuo Technology Co., Ltd 2024-06-20 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID: 2BGX5-5000 ) [Shenzhen Putuo Technology Co., Ltd] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Changyu Qin Manager Shenzhen Putuo Technology Co., Ltd 3rd Floor, Building 9, Jiatiangang Industrial Zone, Huangtian, Hangcheng Street, Baoan District, Shenzhen. Shenzhen Putuo Technology Co., Ltd 2024-06-20 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for(FCC ID: 2BGX5-5000 ) [Shenzhen Putuo Technology Co., Ltd ] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Changyu Qin Manager Shenzhen Putuo Technology Co., Ltd 3rd Floor, Building 9, Jiatiangang Industrial Zone, Huangtian, Hangcheng Street, Baoan District, Shenzhen.

Attestation Statements (2024/6/26) TO: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA RE: Attestation Statements Part 2.911(d)(7) request for (GC：2BGX5) (Shenzhen Putuo Technology Co., Ltd), the undersigned, hereby authorize Wilson Tech Service LLC to act as our designated U.S. agent for service of process, (Shenzhen Putuo Technology Co., Ltd) accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Wilson Tech Service LLC accepts the responsibility to act as designated U.S. agent for service of process. Applicant Information： Company Name: Shenzhen Putuo Technology Co., Ltd Contact Name: Changyu Qin Address: 3rd Floor, Building 9, Jiatiangang Industrial Zone, Huangtian, Hangcheng Street, Baoan District, Shenzhen. FRN: 0035548098 Telephone No: 15014083531 Email: [email protected] Signature [Changyu Qin] U.S. Agent Information: Company Name: Wilson Tech Service LLC Address: 1312 17th Street Suite 692, Denver, CO, 80202, US FRN: 0033402033 Contact Name: Wilson Cheung Telephone No: +1-716-965-5112 Email: [email protected] Signature [Wilson Cheung]

External Photographs YDDY01-5 View of EUT-1 View of EUT-2 Page 2 of 5 View of EUT-3 View of EUT-4 Page 3 of 5 View of EUT-5 View of EUT-6 Page 4 of 5 View of EUT-7 Page 5 of 5 CDB01-5 View of EUT-8

Internal Photographs Internal View of EUT-1 Internal View of EUT-2 Page 2 of 3 Internal View of EUT-3 Internal View of EUT-4 Page 3 of 3 Internal View of EUT-5 Internal View of EUT-6

1 / 16 EUT Specification FCC ID: 2BGX5-5000 Characteristics Description Product Name Magnetic Wireless Powerbank Model number YDDY01-5, CDB01-5 Power Supply DC 5V / DC 9V / Battery 3.85V Operating Frequency Range 110-205KHz for phone charging Modulation Technique ASK for phone charging Antenna Type Coil Antenna Device category Portable (<20cm separation) Mobile (>20cm separation) Others ___ Antenna diversity Single antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Evaluation applied MPE Evaluation SAR Evaluation Applicable Standard: FCC Part 1(1.1310) ,Part 2(2.1093) and KDB 680106 D01 RF Exposure Wireless Charging Apps v03 Applicable Requirement: Three different categories of transmitters are defined by the FCC in OET Bulletin 65. These categories are fixed installation, mobile, and portable and are defined as follows: Fixed Installations: fixed location means that the device, including its antenna, is physically secured at a permanent location and is not able to be 2 / 16 easily moved to another location. Additionally, distance to humans from the antenna is maintained to at least 2 meters. Mobile Devices: a mobile device is defined as a transmitting device designed to be used in other than fixed locations and to be generally used in such a way that a separation distance of at least 20 centimeters is normally maintained between the transmitter's radiating structures and the body of the user or nearby persons. Transmitters designed to be used by consumers or workers that can be easily re-located, such as a wireless modem operating in a laptop computer, are considered mobile devices if they meet the 20 centimeter separation requirement. The FCC rules for evaluating mobile devices for RF compliance are found in 47 CFR ß2.1091. Portable Devices: a portable device is defined as a transmitting device designed to be used so that the radiating structure(s) of the device is/are within 20 centimeters of the body of the user. Portable device requirements are found in Section 2.1093 of the FCC's Rules (47 CFRß2.1093). The FCC also categorizes the use of the device as based upon the user’s awareness and ability to exercise control over his or her exposure. The two categories defined are Occupational/ Controlled Exposure and General Population/Uncontrolled Exposure. These two categories are defined as follows: Occupational/controlled exposure limits apply in situations in which persons are exposed as a consequence of their employment provided those persons are fully aware of the potential for exposure and can exercise control over their exposure. Limits for occupational/controlled exposure also apply in situations when a person is transient through a location where occupational/controlled limits apply provided he or she is made aware of the potential for exposure. The phrase fully aware in the context of applying these exposure limits means that an exposed person has received written and/or verbal information fully explaining the potential for RF exposure resulting from his or her employment. With the exception oftransient persons, this phrase also means that an exposed person has received appropriate training regarding work practices relating to controlling or mitigating his or her exposure. Such training is not required for transient persons, but they must receive written and/or verbal information and notification (for example, using signs) concerning their exposure potential and appropriate means available to mitigate their exposure. The phrase exercise control means that an exposed person is allowed to and knows how to reduce or avoid exposure by administrative or engineering controls and work practices, such as use of personal protective equipment or time averaging of exposure. General population/uncontrolled exposure limits apply in situations in which the general public may be exposed, or in which persons who are exposed as a consequence of their employment may not be fully aware of the potential for exposure or cannot exercise control over their exposure. Licensees and applicants are responsible for compliance with both the 3 / 16 occupational/controlled exposure limits and the general population/uncontrolled exposure limits as they apply to transmitters under their jurisdiction. Licensees and applicants should be aware that the occupational/controlled exposure limits apply especially in situations where workers may have access to areas in very close proximity to antennas and access to the general public may be restricted. In lieu of evaluation with the general population/uncontrolled exposure limits, amateur licensees authorized under part 97 of this chapter and members of his or her immediate household may be evaluated with respect to the occupational/controlled exposure limits in this section, provided appropriate training and information has been provided to the amateur licensee and members of his/her household. Other nearby persons who are not members of the amateur licensee's household must be evaluated with respect to the general population/uncontrolled exposure limits. Test Setup Block Test Procedure 1.Connect the EUT and equipment as above diagram of test configuration. 2.EUT was placed on a table, and the measure probe was placed at a 4 / 16 measurement distance of 20cm from the EUT to the center of the probe. 3.Power on the measuring probe, the EUT was set at the maximum field strength emission state. 4.The EUT was put in different directions (Left, Right, Front, Rear, Top and Bottom) toward to the measure probe. The distance from the top of the EUT to the probe is 20CM, and the distance from other directions is 20cm.Measure the value of field strength. 5.Record the worst data of the different directions. Measuring Device And Test Equipment Used Equipment Manufacturer Model No. Serial No. Last Cal. Cal. Interval  E&H-Field Probe(9kHz-30M Hz) Narda EHP-200A 180ZX11012 Oct. 28, 2023 1 Year Description of Support Device phone ： Manufacturer: Apple Inc. M/N: A2404 S/…

Text truncated - open the document above for the full version.

深圳市瑞通千业科技有限公司 Shenzhen Ruitong thousand industry technology Co.,LTD 客户/Ciient 英硕泰 /Yingshutai 名称/TYPE A11无线充发射线圈/A11 Wireless charging transmitter coil 产品型号 Model NO G43.5*0.6双槽有孔反背胶线长42MM 产品编号 Part nunbering systey 客户料号 Cient p/NO 工程编号 Enginrer NO 日期/Date 2023年6月14日 编制/Prepared 审核/Checked 认可/Approved 万纪美 万纪美 刘成昭 客户认可回签/Authorixed Signaturure Company Chop 本公司工程部/For Enginer Departner Only 修改内容/Rrvised Cintent 认可日期/APProved Date 深圳市瑞通千业科技有限公司 Shenzhen Ruitong thousand industry technology Co.,LTD 工程/ Enginrer 夏成毅/xiachenyi 认可/QC APProved 解超/xiechao 认可日期/APProved 2024.03.12 一、 线圈工艺/Winding Procese: NO 绕组 线规 匝数 绕线方向 备注 1 N1 2UEW-B-0.08*24*2P 10TS CCW 2 二．电气性能/FEATURES: 1.测试条件（Test conditions）：25°C,65%RH@100KHz/1V 1.1 电感量（Inductance） 1.11 L0A（单独线圈）=3.8uH±5% 1.12 L0A(线圈+磁片)=6.5uH±5% 1.2 Q值=45MIN 1.3 直流电阻（DCR）：60mΩ MAX 1.4 工作温度(Operating Temperature)：-25°C~85°C 2.测试仪器(Test instrument)：L:创达1068+1310;DCR:502BC;SIZE:Callipers N O 项目 材料 1 WIRE ￠0.08*24*2p 2UEW- 2 FERRITE 43.5*5*0.6L型双槽 有孔铁氧体硬磁反背胶 43.5*5*0.6L type double slot porous ferrite hard magnetic reverse adhesive 3 GLUE 水性白胶 深圳市瑞通千业科技有限公司 Shenzhen Ruitong thousand industry technology Co.,LTD 3.材料清单/Bill of Material 三．电路图/CIRCUIT DIAGRAM 单位： MM 四．外形图/OUTSIDE DIAGRAM 注：线圈出线位置缠绕5MM（ref）高温胶纸，磁片背面贴双面背胶。 Note: Wrap 5MM (ref) high-temperature adhesive paper around the coil outlet position, and attach double-sided adhesive on the back of the magnetic disc. 标准 A B C D E F G Water-based white glue 4 SOLDER HQ-996/JS-996 5 Tin 千岛纯锡 Thousand Island tin 6 High temperature adhesive 8MM高温胶带 8MM high temperature tape 7 8 深圳市瑞通千业科技有限公司 Shenzhen Ruitong thousand industry technology Co.,LTD STD 43.5± 0.5 39±0.5 20.5±0.2 5±0.2 42±2 3±1 1.6±0.2 单位： MM 五．包装/PACKAGE 5.3包装以现有包装盘为参照标准，以实际出货包装为准，如有特殊要求可定制。 深圳市瑞通千业科技有限公司 Shenzhen Ruitong thousand industry technology Co.,LTD The packaging shall be based on the exusting packing plate and the actual delivery package shall prevail .If there is any requirement,we can customize it. 深圳市瑞通千业科技有限公司 Shenzhen Ruitong thousand industry technology Co.,LTD 六、贮存和使用条件 Storage and Use condition 6.1 贮存条件 Storage condition 6.1.1 建议贮存条件：温度-25°C~ 85°C ，湿度70% (Max.) Recommended keeping conditions: -25°C ~85°C, 70%RH (Max.) 6.1.2 贮存期限：自生产之日起六个月内 Storage life : Within the limits of six months from being produced. 6.2 使用条件 Use condition 使用条件限制：温度=-25°C~ 85°C, 湿度≤ 90% Use condition limit: T=-25°C~85°C, RH≤ 90%.

TRF No.: 04-E001-0B TRF Originator: GTG TRF Date: 2023-12-13 Web: www.gtggroup.com E-mail: [email protected] Tel.: 86-400 755 8988 CFR 47 FCC PART 15 SUBPART C TEST REPORT For Magnetic Wireless Powerbank MODEL NUMBER: YDDY01-5, CDB01-5 REPORT NUMBER: E04A24050503F00401 ISSUE DATE: June 12, 2024 FCC ID: 2BGX5-5000 Prepared for Shenzhen Putuo Technology Co., Ltd 3rd Floor, Building 9, Jiatiangang Industrial Zone, Huangtian, Hangcheng Street, Baoan District, Shenzhen. Prepared by Guangdong Global Testing Technology Co., Ltd. Room 101-105, 203-210, Building 1, No.2, Keji 8 Road, Songshan Lake Park, Dongguan city, Guangdong, People’s Republic of China, 523808 This report is based on a single evaluation of the submitted sample(s) of the above mentioned Product, it does not imply an assessment of the production of the products. This report shall not be reproduced, except in full, without the written approval ofGuangdong Global Testing Technology Co., Ltd. REPORT NO.: E04A24050503F00401 Page 2 of 36 TRF No.: 04-E001-0B Global Testing , Great Quality. Revision History Rev. Issue Date Revisions Revised By V0 June 12, 2024 Initial Issue REPORT NO.: E04A24050503F00401 Page 3 of 36 TRF No.: 04-E001-0B Global Testing , Great Quality. Summary of Test Results Test Item Limit/Requirement Result Antenna Requirement FCC Part 15.203 Pass AC Power Line Conducted Emission FCC Part 15.207 Pass 20dB Bandwidth FCC Part 15.215 Pass Radiated Emission FCC Part 15.205/15.209 Pass Note: 1. N/A: In this whole report not applicable. *This test report is only published to and used by the applicant, and it is not for evidence purpose in China. *The measurement result for the sample received is <Pass> according to <CFR 47 FCC PART 15 SUBPART C> when <Accuracy Method> decision rule is applied. REPORT NO.: E04A24050503F00401 Page 4 of 36 TRF No.: 04-E001-0B Global Testing , Great Quality. CONTENTS 1. ATTESTATION OF TEST RESULTS ..................................................................................... 5 2. TEST METHODOLOGY ......................................................................................................... 6 3. FACILITIES AND ACCREDITATION ..................................................................................... 6 4. CALIBRATION AND UNCERTAINTY ................................................................................... 7 4.1. MEASURING INSTRUMENT CALIBRATION ........................................................... 7 4.2. MEASUREMENT UNCERTAINTY ............................................................................ 7 5. EQUIPMENT UNDER TEST .................................................................................................. 8 5.1. DESCRIPTION OF EUT ........................................................................................... 8 5.2. TEST MODE ............................................................................................................. 8 5.3. SUPPORT UNITS FOR SYSTEM TEST ................................................................... 9 5.4. SETUP DIAGRAM .................................................................................................... 9 6. MEASURING EQUIPMENT AND SOFTWARE USED......................................................... 10 7. RADIATED TEST RESULTS ............................................................................................... 11 7.1. Radiated Spurious Emission ................................................................................... 15 8. AC POWER LINE CONDUCTED EMISSION ...................................................................... 27 9. 20DB BANDWIDTH ............................................................................................................. 30 10. ANTENNA REQUIREMENT ................................................................................... 33 APPENDIX: PHOTOGRAPHS OF TEST CONFIGURATION ..................................................... 34 REPORT NO.: E04A24050503F00401 Page 5 of 36 TRF No.: 04-E001-0B Global Testing , Great Quality. 1. ATTESTATION OF TEST RESULTS Applicant Information Company Name: Shenzhen Putuo Technology Co., Ltd Address: 3rd Floor, Building 9, Jiatiangang Industrial Zone, Huangtian, Hangcheng Street, Baoan District, Shenzhen. Manufacturer Information Company Name: Shenzhen Putuo Technology Co., Ltd Address: 3rd Floor, Building 9, Jiatiangang Industrial Zone, Huangtian, Hangcheng Street, Baoan District, Shenzhen. Factory Information Company Name: Shenzhen Putuo Technology Co., Ltd Address: 3rd Floor, Building 9, Jiatiangang Industrial Zone, Huangtian, Hangcheng Street, Baoan District, Shenzhen. EUT Information Product Description: Magnetic Wireless Powerbank Model: YDDY01-5, CDB01-5 Brand: / Sample Received Date: June 5, 2024 Sample Status: Normal Sample ID: A24050503 001, A24050503 002 Date of Tested: June 5, 2024 to June 12, 2024 APPLICABLE STANDARDS STANDARD TEST RESULTS CFR 47 FCC PART 15 SUBPART C Pass Prepared By: Checked By: Jok Yang Alan He Project Engineer Laboratory Leader Approved By: Shawn Wen Laboratory Manager REPORT NO.: E04A24050503F00401 Page 6 of 36 TRF No.: 04-E001-0B Global Testing , Great Quality. 2. TEST METHODOLOGY All tests were performed in accordance with the standard CFR 47 FCC PART 15 SUBPART C 3. FACILITIES AND ACCREDITATION Accreditation Certificate A2LA (Certificate No.: 6947.01) Guangdong Global Testing Technology Co., Ltd. has been assessed and proved to be in compliance with A2LA. FCC (FCC Designation No.: CN1343) Guangdong Global Testing Technology Co., Ltd. has been recognized to perform compliance testing on equipment subject to Supplier's Declaration of Conformity (SDoC) and Certification rules ISED (Company No.: 30714) Guangdong Global Testing Technology Co., Ltd. has been registered and fully described in a report filed with ISED. The Company Number is 30714 and the test lab Conformity Assessment Body Identifier (CABID) is CN0148. Note: All tests measurement fa…
