2BH6C-F900Projector

AOGES CO., LIMITED 1/1 US Agent for Service of Process LETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process: Company Name: AOGES CO., LIMITED Contact Name: XIAOYAN LAI Address: 1624 Market St., Ste 226, #30327 Denver CO, 80202 US Telephone No: +1 303 623 1940 Email: [email protected] FRN: 0033947847 Applicant: Company name: Shenzhen Ruichi Information Technology Co., Ltd Product Description: Projector FRN: 0035782812 Grantee code: 2BH6C FCC ID: 2BH6C-F900 Contact Name: ZHANG XINYA Address: Room 601, North Block, Jinwen Digital Valley, Hangcheng Street, Bao'an District, Shenzhen, China Telephone No: 0755-36886288 Email: [email protected] [Shenzhen Ruichi Information Technology Co., Ltd] certifies that, as of the date of this filing of the application with the TCB, [AOGES CO., LIMITED] is our designated US agent for service of process for the above referenced FCC ID. [Shenzhen Ruichi Information Technology Co., Ltd] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. [AOGES CO., LIMITED] accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. Date: 2024.08.14 Applicant’s Name: Shenzhen Ruichi Information Technology Co., Ltd US Agent’s Name: AOGES CO., LIMITED Title:CEO Title: General Manager Signature Signature XIAOYAN LAI

C5266091_X24_Ed.2 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: Shenzhen Ruichi Information Technology Co., Ltd Grantee code: 2BH6C FRN: 0035782812 FCC ID: 2BH6C-F900 Contact Name: ZHANG XINYA Address: Room 601, North Block, Jinwen Digital Valley, Hangcheng Street, Bao'an District, Shenzhen, China Telephone No: 0755-36886288 Fax No: Email: [email protected] i. [Shenzhen Ruichi Information Technology Co., Ltd] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [Shenzhen Ruichi Information Technology Co., Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. [Shenzhen Ruichi Information Technology Co., Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] identified on the Covered List as an entity producing “covered” equipment. Date: 2024.08.14 Applicant’s Name: Shenzhen Ruichi Information Technology Co., Ltd Title:CEO Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

Shenzhen Ruichi Information Technology Co., Ltd Product Similarity Declaration Product name: Projector Model name: F900, F913, F911, F901, F906, F909, F928, F995, F910, F920, F930, 269pro FCC ID: 2BH6C-F900 We (Shenzhen Ruichi Information Technology Co., Ltd) hereby state that all the models are electrical identical including the same software parameter and hardware design (i.e., circuit design, PCB Layout, RF module/circuit, antenna type(s) and antenna location, components on PCB, etc.,), same mechanical structure and design (including product enclosure, materials, etc.,), the only difference is the model name Signature: Name: ZHANG XINYA Title: CEO China, 2024.08.14

C5266091_X8_Ed.1 1/1 < Shenzhen Ruichi Information Technology Co., Ltd > Letter of Authorization Company: Shenzhen Ruichi Information Technology Co., Ltd Address: Room 601, North Block, Jinwen Digital Valley, Hangcheng Street, Bao'an District, Shenzhen, China Product Name: Projector Model Number: F900, F913, F911, F901, F906, F909, F928, F995, F910, F920, F930, 269pro FCC Identifier: 2BH6C-F900 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: ZHANG XINYA Date: 2024.08.14 Title: CEO Signature of applicant:

C5266091_X10_Ed.2 1/1 < Shenzhen Ruichi Information Technology Co., Ltd > Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2024.08.14 Subject: Request for Confidentiality FCC ID: 2BH6C-F900 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual ☐ NOTE 1 ☐ Internal Photos ☐ NOTE 1 ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In case of short-term Confidentiality, the applicant requests the exhibits selected above are withheld from public view for a period of ______ days from the date of the Grant of Equipment Authorization and prior to marketing. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. ☒ C5266091_X10_Ed.2 1/1 Sincerely, Signature: Name: ZHANG XINYA Title:CEO

Page 1 of 5 Report No.: STS2408038 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: F900 Photo 1 Photo 2 Page 2 of 5 Report No.: STS2408038 Photo 3 Photo 4 Page 3 of 5 Report No.: STS2408038 Photo 5 Photo 6 Page 4 of 5 Report No.: STS2408038 Photo 7 Photo 8 Page 5 of 5 Report No.: STS2408038 Photo 9

Label Projector Model: F900 FCC ID: 2BH6C-F900 20mm 30mm

Page 1 of 7 Report No.: STS2408038 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model:F900 Photo 1 Photo 2 BT +2.4G WIFI +5G WIFI Antenna Page 2 of 7 Report No.: STS2408038 Photo 3 Photo 4 Page 3 of 7 Report No.: STS2408038 Photo 5 Photo 6 Page 4 of 7 Report No.: STS2408038 Photo 7 Photo 8 Page 5 of 7 Report No.: STS2408038 Photo 9 Photo 10 Page 6 of 7 Report No.: STS2408038 Photo 11 Photo 12 Page 7 of 7 Report No.: STS2408038 Photo 13

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Radio Test Report Report No.: STS2408038H01 Issued for Shenzhen Ruichi Information Technology Co., Ltd Room 601, North Block, Jinwen Digital Valley, Hangcheng Street, Bao'an District, Shenzhen, China. Product Name: Projector Brand Name: N/A Model Name: F900 Series Model(s): F913, F911, F901, F906, F909, F928, F995, F910, F920, F930, 269pro FCC ID: 2BH6C-F900 Test Standards: FCC 47CFR §2.1091 Page 2 of 9 Report No.: STS2408038H01 TEST REPORT Applicant’s Name ................. : Shenzhen Ruichi Information Technology Co., Ltd Address .................................. : Room 601, North Block, Jinwen Digital Valley, Hangcheng Street, Bao'an District, Shenzhen, China. Manufacturer's Name .......... : Shenzhen Ruichi Information Technology Co., Ltd Address .................................. : Room 601, North Block, Jinwen Digital Valley, Hangcheng Street, Bao'an District, Shenzhen, China. Product Description Product Name ........................ : Projector Brand ................................... : N/A Model Number ....................... : ... : F900 Series Model(s) ...................... : F913, F911, F901, F906, F909, F928, F995, F910, F920, F930, 269pro Standards ............................. : FCC 47CFR §2.1091 447498 D04 Interim General RF Exposure Guidance v01 The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Date of Test ............................................ : Date of receipt of test item ...................... : 07 Aug. 2024 Date (s) of performance of tests.............. : 07 Aug. 2024 ~ 12 Aug. 2024 Date of Issue ........................................... : 12 Aug. 2024 Test Result ............................................... : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Chris Chen) Authorized Signatory : (Bovey Yang) Page 3 of 9 Report No.: STS2408038H01 TABLE OF CONTENTS 1. GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST FACTORY 5 2. FCC 47CFR §2.1091 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.3 TEST RESULT 9 Page 4 of 9 Report No.: STS2408038H01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 12 Aug. 2024 STS2408038H01 ALL Initial Issue Page 5 of 9 Report No.: STS2408038H01 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name Projector Brand N/A Model Number F900 Series Model(s) F913, F911, F901, F906, F909, F928, F995, F910, F920, F930, 269pro Model Difference Only the model name is different. Product Description The EUT is Projector Operation Frequency: BT: 2402~2480 MHz 2.4G WLAN: 802.11b/g/n 20: 2412~2462 MHz 802.11n(40MHz):2422~2452MHz 5G WLAN: IEEE 802.11a/n(HT20):5.180GHz-5.240GHz IEEE 802.11n(HT40): 5.190GHz-5.230GHz Modulation Type: BT BR(1Mbps): GFSK BT EDR(2Mbps): π/4-DQPSK BT EDR(3Mbps): 8DPSK 2.4G WLAN: 802.11b(DSSS):CCK,DQPSK,DBPSK 802.11g(OFDM):BPSK,QPSK,16-QAM,64-QAM 802.11n(OFDM):BPSK,QPSK,16-QAM,64-QAM 5G WLAN: 802.11a(OFDM):BPSK,QPSK,16-QAM,64-QAM 802.11n(OFDM):BPSK,QPSK,16-QAM,64-QAM Antenna gain: BT/2.4G WLAN:2.1dBi 5G WLAN:2.56dBi Antenna Designation: PIFA Rating Input: AC 100-240V~50/60Hz 1.5A Hardware version number A0240626/713M Software version number eng.ys.20240621.093637 1.2 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 Page 6 of 9 Report No.: STS2408038H01 2. FCC 47CFR §2.1091 REQUIREMENT 2.1 TEST STANDARDS Follow the maximum permissible exposure (MPE) limits specified in 447498 D04 Interim General Radio Frequency Exposure Guidelines v01. The gain of the antenna used in the product was extracted from the supplied antenna data sheet and the maximum total power input to the antenna was also measured. Calculate the distance from the product to the MPE limit by the formula. 2.2 LIMIT For single RF sources (i.e., any single fixed RF source, mobile device, or portable device, as defined in paragraph (b)(2) of this section): A single RF source is exempt if: (A) The available maximum time-averaged power is no more than 1 mW, regardless of separation distance. This exemption may not be used in conjunction with other exemption criteria other than those in paragraph (b)(3)(ii)(A) of Part 1.1307. Medical implant devices may only use this exemption and that in paragraph (b)(3)(ii)(A); (B) Or the available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold Pth (mW) described in the following formula. This method shall only be used at separation distances (cm) from 0.5 centimeters to 40 centimeters and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by: Page 7 of 9 Report No.: STS2408038H01 (C) Or using below table and the minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that frequency. For the exemption in Table 1 to apply, R must be at least λ/2π, where λ is the free-space operating wavelength in meters. If the ERP of a single RF source is not easily obtained, then the available maximum time-averaged power may be used in lieu of ERP if the physical dimensions of the radiating structure(s) do not exceed the electrical length of λ/4 or if the antenna gain is less than that of a half-wave dipole (1.64 linear value). RF Source frequency (MHz) Threshold ERP(watts) 0.3-1.34 1,920 R 2 . 1.34-30 3,450 R 2 /f 2 . 30-300 3.83 R 2 . 300-1,500 …

Text truncated - open the document above for the full version.

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Radio Test Report Report No.:STS2408038W01 Issued for Shenzhen Ruichi Information Technology Co., Ltd Room 601, North Block, Jinwen Digital Valley, Hangcheng Street, Bao'an District, Shenzhen, China. Product Name: Projector Brand Name: N/A Model Name: F900 Series Model(s): F913, F911, F901, F906, F909, F928, F995, F910, F920, F930, 269pro FCC ID: 2BH6C-F900 Test Standards: FCC Part15.247 S T L A B S Page 2 of 94 Report No.: STS2408038W01 TEST REPORT Applicant’s Name ................. : Shenzhen Ruichi Information Technology Co., Ltd Address .................................. : Room 601, North Block, Jinwen Digital Valley, Hangcheng Street, Bao'an District, Shenzhen, China. Manufacturer's Name ........... : Shenzhen Ruichi Information Technology Co., Ltd Address .................................. : Room 601, North Block, Jinwen Digital Valley, Hangcheng Street, Bao'an District, Shenzhen, China. Product Description Product Name ........................ : Projector Brand Name ........................... : N/A Model Name ........................... : F900 Series Model(s) .................... : F913, F911, F901, F906, F909, F928, F995, F910, F920, F930, 269pro Test Standards...................... : FCC Part15.247 Test Procedure ....................... : ANSI C63.10-2020 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Date of Test ............................... : Date of receipt of test item ......... : 07 Aug. 2024 Date (s) of performance of tests : 07 Aug. 2024 ~ 12 Aug. 2024 Date of Issue ............................. : 12 Aug. 2024 Test Result ................................. : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Chris Chen) Authorized Signatory : (Bovey Yang) Page 3 of 94 Report No.: STS2408038W01 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 10 2.3 FREQUENCY HOPPING SYSTEM REQUIREMENTS 10 2.4 TABLE OF PARAMETERS OF TEST SOFTWARE SETTING 12 2.5 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 12 2.6 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 13 2.7 EQUIPMENTS LIST 14 3. EMC EMISSION TEST 15 3.1 CONDUCTED EMISSION MEASUREMENT 15 3.2 RADIATED EMISSION MEASUREMENT 19 4. CONDUCTED SPURIOUS & BAND EDGE EMISSION 31 4.1 LIMIT 31 4.2 TEST PROCEDURE 31 4.3 TEST SETUP 32 4.4 EUT OPERATION CONDITIONS 32 4.5 TEST RESULTS 32 5. NUMBER OF HOPPING CHANNEL 33 5.1 LIMIT 33 5.2 TEST PROCEDURE 33 5.3 TEST SETUP 33 5.4 EUT OPERATION CONDITIONS 33 5.5 TEST RESULTS 33 6. AVERAGE TIME OF OCCUPANCY 34 6.1 LIMIT 34 6.2 TEST PROCEDURE 34 6.3 TEST SETUP 34 6.4 EUT OPERATION CONDITIONS 34 6.5 TEST RESULTS 34 7. HOPPING CHANNEL SEPARATION MEASUREMEN 35 Page 4 of 94 Report No.: STS2408038W01 Table of Contents Page 7.1 LIMIT 35 7.2 TEST PROCEDURE 35 7.3 TEST SETUP 35 7.4 EUT OPERATION CONDITIONS 35 7.5 TEST RESULTS 35 8. BANDWIDTH TEST 36 8.1 LIMIT 36 8.2 TEST PROCEDURE 36 8.3 TEST SETUP 36 8.4 EUT OPERATION CONDITIONS 36 8.5 TEST RESULTS 36 9. OUTPUT POWER TEST 37 9.1 LIMIT 37 9.2 TEST PROCEDURE 37 9.3 TEST SETUP 38 9.4 EUT OPERATION CONDITIONS 38 9.5 TEST RESULTS 38 10. ANTENNA REQUIREMENT 38 10.1 STANDARD REQUIREMENT 38 10.2 EUT ANTENNA 38 APPENDIX 1-TEST DATA 39 1. DWELL TIME 39 2. MAXIMUM PEAK CONDUCTED OUTPUT POWER 49 3. -20DB BANDWIDTH 55 4. CARRIER FREQUENCIES SEPARATION 61 5. NUMBER OF HOPPING CHANNEL 67 6. BAND EDGE 70 7. BAND EDGE(HOPPING) 77 8. CONDUCTED RF SPURIOUS EMISSION 84 APPENDIX 2-PHOTOS OF TEST SETUP 94 Page 5 of 94 Report No.: STS2408038W01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 12 Aug. 2024 STS2408038W01 ALL Initial Issue Page 6 of 94 Report No.: STS2408038W01 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 15.247 Meas Guidance v05r02. FCC Part 15.247,Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247(a)(1) Hopping Channel Separation PASS -- 15.247(a)(1)&(b)(1) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247(d) Conducted Spurious & Band Edge Emission PASS -- 15.247(a)(1)(iii) Number of Hopping Frequency PASS -- 15.247(a)(1)(iii) Dwell Time PASS -- 15.247(a)(1) Bandwidth PASS -- 15.205 Restricted bands of operation PASS -- Part 15.247(d)/part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2020. Page 7 of 94 Report No.: STS2408038W01 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ±U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.755dB 2 Unwanted Emissions, conducted ±2.874dB 3 All emissions, radiated 9K-30MHz ±3.80dB 4 All emissions, radiated 30M-1GHz ±4.18dB 5 All emissions, radiated 1G-6GHz ±4.90dB 6 All emissions, radiated>6G ±5.24dB 7 Conducted Emission (9KHz-150KHz)…

Text truncated - open the document above for the full version.

TEL：+86 0755-23073599FAX：+86 0755-23097189E-mail:[email protected] SHENZHEN 客户 : 品 名 规 格 DESCRIPTION: 料号 PART NO. ： 客 户 料 号 CUS PART NO.： 日期 D A T E ： 云顶呈样签章 工 程 ENGINEERING DEPARTMENT 品保 Q C DEPARTMENT 业 务 SALES DEPARTMENT 客户承认签章 工 程 ENGINEERING DEPARTMENT 品保 Q C DEPARTMENT 采 购 PURCHASING DEPARTMENT 联系电话：0755 23073599 ж 承认书一式三份，惠蒙贵司承认签章 ж Approval in duplicate, please signed by your company. APPROVAL YD-2.4/5GHZ Ver1.0-L120-1-A 2024.3.30 company 2.4/5GHz Ver1.0 Shenzhen star Chuangzhan Electronics Co., LTD 深圳天星创展电子有限公司 HEN SWR Antenna performance TEL：+860755-23073599FAX：+860755-23097189E-mail:[email protected] SHENZHEN PassiveTestForWIFI2.4 FreqEffiGain (MHz)(%)(dBi) 240052.790.91 241053.940.96 242052.110.9 243053.010.99 244057.671.43 245063.291.92 246062.31.88 247065.182 248068.52.1 249073.412.55 250071.92.51 Antenna efficiency and gain TEL：+860755-23073599FAX：+860755-23097189E-mail:[email protected] SHENZHEN PassiveTestForWIFI5.8 FreqEffiGain (MHz)(%)(dBi) 515055.492.56 520052.582.08 525050.521.53 530053.882.34 535059.163.2 540065.73.46 545057.362.96 550055.252.87 555051.222.4 560044.641.57 565044.981.34 570049.182.02 575060.243.43 580061.273.38 585053.192.78 TEL：+86 0755-23073599FAX：+86 0755-23097189E-mail:[email protected] SHENZHEN Antenna size diagram Unit: mm TEL：+860755-23073599FAX：+860755-23097189E-mail:[email protected] SHENZHEN 电器技术参数 电性能指标 ElectricalSpecifications 频率范围2400~2500/5150~5850MHz FrequencyRange 2400~2500/5150~5850MHz 电压驻波比≤2.0VSWR≤2.0 输入阻抗50ΩInputImpedance50Ω 增益3.5DBIGain3.5DBI 机械指标 MechanicalSpecifications 天线颜色黑色AntennaColorBlack 接口形式IPEX一代InputconnectorIPEX1 天线线长120mmCablelength120mm 工作温度-40°C~+85°CWorkingTemperature-40°C~+85°C 工作湿度20~80%WorkingHumidity20~80%

Page 1 of 2 FCC ID: 2BH6C-F900 DSS_DTS_ U-NII Setup photo Model Number: F900 DSS_DTS_ U-NII conduction DSS_DTS_ U-NII radiation L Page 2 of 2 FCC ID: 2BH6C-F900 DSS_DTS_ U-NII radiation H
