2BH9E-VIPRLED FLOOR LAMP

INSTRUCTION MANUAL WWW.EZEVENT.NET FOR YOUR OWN SAFETY, PLEASE READ THIS INSTRUCTION MANUAL CAREFULLY BEFORE YOU INITIALLY START-UP THANK YOU FOR PURCHASING AN EZEVENT PRODUCT, WE HOPE YOU ENJOY USING IT. #LIGHT UP YOUR DREAMS ENG INSERT THE LAMP BODY INTO THE BASE. PULL OUT THE SPRING PLUNGER AND INSERT THE LAMP BODY INTO THE BASE UNTIL THE CLIP SPRINGS BACK TO ITS ORIGINAL POSITION. 1 2 INSERT THE BLUE PLUG OF THE WIRE INTO THE BLUE SOCKET OF THE BASE, TURN RIGHT IS ‘‘ON’’ AND TURN LEFT IS ‘‘OFF’’. INSERT THE BLACK PLUG OF THE CABLE INTO THE SOCKET (100-240V). BLUE SOCKET: INPUT 100 - 240V. USB SOCKET: OUTPUT 5V - 2.1A. WHITE SOCKET: OUTPUT 100 - 240V. 3 4 CHARGING STATUS (DISCHARGE) RED LIGHT ON: INDICATES 0-29% BATTERY POWER. BLUE LIGHT ON: INDICATES 30-89% BATTERY POWER. GREEN LIGHT ON: INDICATES 90-100% BATTERY POWER. CHARGING STATUS (CHARGING) FLASHING RED LIGHT: INDICATES 0-29% BATTERY POWER. FLASHING BLUE LIGHT: INDICATES 30-89% BATTERY POWER. FLASHING GREEN LIGHT: INDICATES 90-99.9% BATTERY POWER. GREEN LIGHT ON: INDICATES 100% BATTERY POWER. *TO KEEP THE BATTERY IN GOOD WORKING ORDER OVER TIME, PLEASE CHARGE/DISCHARGE IT AT LEAST ONCE EVERY SIX MONTHS. BATTERY INDICATOR COLOUR LED INDICATOR GREEN, BLUE, RED 5 CLICK TO INCREASE THE BRIGHTNESS BY STEPS: 20% - 40% - 60% - 80% - 100%. LONG PRESS, DIMMER GOES FROM 20% TO 100%. 6-8 SECONDS TO COMPLETE STEPLESS DIMMING. DIMMING + CLICK TO DECREASE THE BRIGHTNESS BY STEPS: 100% - 80% - 60% - 40% - 20%. LONG PRESS, DIMMER GOES FROM 100% TO 20%. 6-8 SECONDS TO COMPLETE STEPLESS DIMMING. DIMMING - CLICK TO SWITCH VIP-R ON OR OFF. ON/OFF CYCLICALLY CLICK TO CHANGE THE COLOR TEMPERATURE: 2600K - 3000K - 3500K - 5000K - 6500K. IF THERE’S NO OPERATION ON THE TOUCHING PANEL DURING 10-12 SECONDS, THE TOUCHING PANEL IS LOCKED. TO UNLOCK IT, LONG PRESS THIS BUTTON FOR 6 SECONDS. CCT CYCLICALLY CLICK THE BUTTON TO ACTIVATE 30 MINUTES TIMER, 60 MINUTES TIMER AND NO TIMER. TO CONNECT VIP-R TO TUYA: PRESS AND HOLD THIS BUTTON (WHEN THE RED AND BLUE INDICATORS ARE FLASHING) TO SWITCH TO TUYA AND CONNECT TO THE NETWORK. PAIR Instructions WWW.EZEVENT.NET BLUE SOCKET WHITE SOCKET USB SOCKET DOWNLOAD THE TUYA APPLICATION ONTO YOUR MOBILE PHONE. PRESS + THEN ADD A DEVICE. CHOOSE YOUR WIFI NETWORK. THE LAMP APPEARS. SETTINGS: ON/OFF. COLOUR TEMPERATURE. DIMMER. CLICK ON THE PEN AT THE TOP RIGHT OF THE SCREEN: RENAME TO VIP-R. CREATE GROUPS TO OBTAIN VIP-RS WITH DIFFERENT SETTINGS DEPENDING ON THE ZONES WHERE THEY ARE PLACED, SO THAT YOU CAN SWITCH ON/OFF, CHANGE THE COLOUR OR INTENSITY OF SEVERAL VIP-RS AT THE SAME TIME. 6 Technical SpecificationsDimensions WWW.EZEVENT.NET CCT 2600 TO 6500K CRI >90 INTENSITY UP TO 1800 LUMENS USB CHARGER 5V 2.1A CONTROL SENSITIVE PANEL TUYA APPLICATION GRADE IP IP20 LENSES ASYMETRIC 15° X 55° HEIGHT UNFOLDED - 240 CM FOLDED - 130 CM TEMPERATURE 0-40° WEIGHT 10KG LED POWER 45 WATTS VOLTAGE AC 100-240V 50/60HZ BATTERY 14,6 V - 23400 MAH - 341 WH AUTONOMY * UP TO 10 HOURS CHARGING TIME * 8 HOURS CHARGING INDICATOR COLOR LED POWER 55W MAX ASSEMBLY EASY FIX INSTALLATION <10 SECONDS FINISH BLACK OR WHITE * FOR INDICATION ONLY. WARNING • Read the instruction in this manual carefully and thoroughly, as they give important information regarding safety during use and maintenance. Keep this manual with the unit, in order to consult it in the future. If the unit is sold or given to another operator, make certain that it always has its manual, to enable the new owner to read about its operation and relative instructions. • To prevent fire or shock hazard, do not expose this product under a high temperature. • This product must be earthed. • Take care not to damage the power cord. • After having removed the packaging check that the unit is NOT damaged in any way. • If in doubt, DON’T use it and contact an authorized dealer. • NEVER use the unit under the following conditions: - In places subject to vibrations or bumps. - In places with a temperature of over 40 °C or less than 0 °C. - In places with high humidity or rain. • DO NOT open the unit, there are no user serviceable parts inside. • NEVER try to repair the unit yourself. Repairs by unqualified people could cause damage or faulty operation. Contact your nearest dealer. • Wait for at least one second to turn on the power after turning off this unit. • Packaging material (plastic bags, polystyrene foam, nails, etc.) MUST NOT be left within children’s reach, as it can be dangerous. • STOP using the unit immediately In the event of serious operation problems and either contact your local dealer for a check or contact us directly. • DO NOT dismantle or modify the unit. • If in doubt, DON’T use it and contact an authorized dealer. • This unit must only be operated by adults. DO NOT allow children to tamper or play with it. Warranty: 24 months / Battery 6 months. DESIGNED IN FRANCE, ASSEMBLED IN CHINA. WWW.EZEVENT.NET INSTRUCTION MANUAL WWW.EZEVENT.NET FOR YOUR OWN SAFETY, PLEASE READ THIS INSTRUCTION MANUAL CAREFULLY BEFORE YOU INITIALLY START-UP THANK YOU FOR PURCHASING AN EZEVENT PRODUCT, WE HOPE YOU ENJOY USING IT. #LIGHT UP YOUR DREAMS ENG INSERT THE LAMP BODY INTO THE BASE. PULL OUT THE SPRING PLUNGER AND INSERT THE LAMP BODY INTO THE BASE UNTIL THE CLIP SPRINGS BACK TO ITS ORIGINAL POSITION. 1 2 INSERT THE BLUE PLUG OF THE WIRE INTO THE BLUE SOCKET OF THE BASE, TURN RIGHT IS ‘‘ON’’ AND TURN LEFT IS ‘‘OFF’’. INSERT THE BLACK PLUG OF THE CABLE INTO THE SOCKET (100-240V). BLUE SOCKET: INPUT 100 - 240V. USB SOCKET: OUTPUT 5V - 2.1A. WHITE SOCKET: OUTPUT 100 - 240V. 3 BLUE SOCKET WHITE SOCKET USB SOCKET 4 CHARGING STATUS (DISCHARGE) RED LIGHT ON: INDICATES 0-29% BATTERY POWER. BLUE LIGHT ON: INDICATES 30-89% BATTERY POWER. GREEN LIGHT ON: INDICATES 90-100% BATTERY POWER. CHARGING STATUS (CHARGING) FLASHING RED LIGHT: INDICATES 0-29% BATTERY POWER. FLASHING BLUE LIGHT: INDICATES 30-89% BATTERY POWER. FLASHING GREEN LIGHT: INDICATES 90-99.9% BATTERY POWER. GREEN LIGHT ON: INDICATES 100% …

Text truncated - open the document above for the full version.

MYHP LIMITED U.S. Agent Designation for Service of Process - Certification Attestation Letter Federal Communications Commission Authorization and Evaluation Division 7 435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: 2BH9E-VIPR FRN of applicant: 0035797786 Per section 2.911(d)(7) of the FCC rules, MYHP LIMITED certifies that the equipment for which authorization is sought is designated to the following U.S. agent* for service of process: Company Name: uux GROUP INC FCC Registration Number (FRN): 0033701590 Physical U.S. Company Address: 36 South 18th Avenue, Suite A Brighton, CO USA 80601 Contact Person: Jack Fu Agent Email Address: [email protected] The above contact person accepts the obligation for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Signed: Signed Printed name Herve Pequignet Tille CEO Company Name MYHP LIMITED Date 8/14/2024 Agent Signed: Signed Printed name Jack Fu Tille Manager Company Name UUX GROUP INC Date 8/14/2024 *the applicant must designate a contact located in the United States for purposes of acting as the applicant's agent for service of process, regardless of whether the applicant is a domestic or foreign entity An applicant located in the United States may designate itself as the agent for service of process

MYHP LIMITED Covered Equipment Certification Attestation Letter 8/14/2024 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: 2BH9E-VIPR MYHP LIMITED certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. MYHP LIMITED certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Signed: Printed name: Herve Pequignet Title: CEO Company Name: MYHP LIMITED Date: 8/14/2024

DATE : 2024-08-14 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint Jason Wu of Global United Technology Services Co., Ltd.and No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with MYHP LIMITED and Victory Factory Building Unit 30, 2FL, 16 Wong Chuk Hang Road, Wong Chuk Hang, Hong Kong, China Signature: Name: Herve Pequignet Title: CEO Company: MYHP LIMITED

MYHP LIMITED DATE : 2024-08-14 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2BH9E-VIPR Product Name: LED FLOOR LAMP Request for Confidentiality To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Signature: Name: Herve Pequignet Title: CEO Company: MYHP LIMITED

Differences Declaration To w h o m c o n c e r n , We company MYHP LIMITED hereby declares: The product models VIP-R, VIP-R C are identical in the same PCB layout, interior structure and electrical circuits, The only difference is that the VIP-R base has a battery pack, and the VIP-R C base does not have a battery pack. Authorized signature: Date: 2024-08-14

Page 1 of 4 Test Model No.: VIP‐R Page 2 of 4 Page 3 of 4 Page 4 of 4

50*65MM AC: 100-240V 0.18-0.45A Power: 45W Battery:14.6V 23.4AH 341.6WH USB: 5V2.1A FCC ID: 2BH9E-VIPR

Page 1 of 10 Test Model No.: VIP‐R Page 2 of 10 Page 3 of 10 Page 4 of 10 Page 5 of 10 Page 6 of 10

Page 7 of 10 Page 8 of 10 Page 9 of 10 Page 10 of 10

FCC ID: 2BH9E-VIPR RF Exposure Evaluation Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. Test Result of RF Exposure Evaluation Band Frequency Max output power (dBm) Output power (mW) Antenna gain (dBi) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Verdict BLE 2440MHz 4.67 2.93 2.42 0.0010 1.0 PASS WIFI 2.4G 2412MHz 17.68 58.61 2.42 0.0204 1.0 Remark: The max power density is less than MPE exempt limit, so it is compliance.

Global United Technology Services Co., Ltd. Report No.: GTS2024070218F02 Authorized Signature: Robinson Luo Laboratory Manager This results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Page 1 of 33 TEST REPORT Applicant: MYHP LIMITED Address of Applicant: Victory Factory Building Unit 30, 2FL, 16 Wong Chuk Hang Road, Wong Chuk Hang, Hong Kong, China Manufacturer: MYHP LIMITED Address of Manufacturer: Victory Factory Building Unit 30, 2FL, 16 Wong Chuk Hang Road, Wong Chuk Hang, Hong Kong, China Equipment Under Test (EUT) Product Name: LED FLOOR LAMP Model No.: VIP-R, VIP-R C FCC ID: 2BH9E-VIPR Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247 Date of sample receipt: July 23, 2024 Date of Test: July 24, 2024-August 14, 2024 Date of report issued: August 14, 2024 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: GTS2024070218F02 Global United Technology Services Co., Ltd. No. 123-128, Tower A,Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 33 2 Version Version No. Date Description 00 August 14, 2024 Original Prepared By: Date: August 14, 2024 Project Engineer Check By: Date: August 14, 2024 Reviewer Report No.: GTS2024070218F02 Global United Technology Services Co., Ltd. No. 123-128, Tower A,Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 33 3 Contents Page 1 COVER PAGE ........................................................................................................................................... 1 2 VERSION .................................................................................................................................................. 2 3 CONTENTS .............................................................................................................................................. 3 4 TEST SUMMARY ..................................................................................................................................... 4 5 GENERAL INFORMATION ...................................................................................................................... 5 5.1 GENERAL DESCRIPTION OF EUT ......................................................................................................... 5 5.2 TEST MODE ........................................................................................................................................ 7 5.3 DESCRIPTION OF SUPPORT UNITS ....................................................................................................... 7 5.4 DEVIATION FROM STANDARDS ............................................................................................................. 7 5.5 ABNORMALITIES FROM STANDARD CONDITIONS ................................................................................... 7 5.6 TEST FACILITY .................................................................................................................................... 7 5.7 TEST LOCATION ................................................................................................................................. 7 5.8 ADDITIONAL INSTRUCTIONS ................................................................................................................. 7 6 TEST INSTRUMENTS LIST ..................................................................................................................... 8 7 TEST RESULTS AND MEASUREMENT DATA .................................................................................... 10 7.1 ANTENNA REQUIREMENT ................................................................................................................... 10 7.2 CONDUCTED EMISSIONS ................................................................................................................... 11 7.3 CONDUCTED OUTPUT POWER ........................................................................................................... 14 7.4 CHANNEL BANDWIDTH ...................................................................................................................... 15 7.5 POWER SPECTRAL DENSITY ............................................................................................................. 16 7.6 SPURIOUS EMISSION IN NON-RESTRICTED & RESTRICTED BANDS ....................................................... 17 7.6.1 Conducted Emission Method ..................................................................................................... 17 7.6.2 Radiated Emission Method ........................................................................................................ 18 8 TEST SETUP PHOTO ............................................................................................................................ 33 9 EUT CONSTRUCTIONAL DETAILS ..................................................................................................... 33 Report No.: GTS2024070218F02 Global United Technology Services Co., Ltd. No. 123-128, Tower A,Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 4 of 33 4 Test Summary Test Item Section Result Antenna requirement FCC part 15.203/15.247 (c) Pass AC Power Line Conducted Emission FCC part 15.207 Pass Conducted Peak Output Power FCC part 15.247 (b)(3) Pass Channel Bandwidth & 99% OCB FCC part 15.247 (a)(2) Pass Po…

Text truncated - open the document above for the full version.

Report No.: GTS2024070218F02 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 1 of 22 AppendixA: DTS Bandwidth Test Result Test Mode Antenna Frequency[MHz] Rate DTS BW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant1 2412 1Mbps 11.080 2405.400 2416.480 0.5 PASS 11B Ant1 2437 1Mbps 11.040 2430.440 2441.480 0.5 PASS 11B Ant1 2462 1Mbps 10.560 2455.400 2465.960 0.5 PASS 11G Ant1 2412 6Mbps 15.080 2404.400 2419.480 0.5 PASS 11G Ant1 2437 6Mbps 15.160 2429.360 2444.520 0.5 PASS 11G Ant1 2462 6Mbps 15.080 2454.400 2469.480 0.5 PASS 11N20SISO Ant1 2412 MCS0 15.080 2404.400 2419.480 0.5 PASS 11N20SISO Ant1 2437 MCS0 15.080 2429.400 2444.480 0.5 PASS 11N20SISO Ant1 2462 MCS0 15.040 2454.400 2469.440 0.5 PASS 11N40SISO Ant1 2422 MCS0 34.960 2404.480 2439.440 0.5 PASS 11N40SISO Ant1 2437 MCS0 35.040 2419.400 2454.440 0.5 PASS 11N40SISO Ant1 2452 MCS0 35.040 2434.400 2469.440 0.5 PASS Report No.: GTS2024070218F02 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 22 Test Graphs 11B-Ant1-2412-PASS 11B-Ant1-2437-PASS 11B-Ant1-2462-PASS 11G-Ant1-2412-PASS 11G-Ant1-2437-PASS 11G-Ant1-2462-PASS Report No.: GTS2024070218F02 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 22 11N20SISO-Ant1-2412-PASS 11N20SISO-Ant1-2437-PASS 11N20SISO-Ant1-2462-PASS 11N40SISO-Ant1-2422-PASS 11N40SISO-Ant1-2437-PASS 11N40SISO-Ant1-2452-PASS Report No.: GTS2024070218F02 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 4 of 22 AppendixB: Occupied Channel Bandwidth Test Result Test Mode Antenna Channel Frequency[MHz] Rate OCB [MHz] FL[MHz] FH[MHz] 11B Ant1 2412 1Mbps 14.939 2403.8542 2418.7932 11B Ant1 2437 1Mbps 14.899 2428.8494 2443.7484 11B Ant1 2462 1Mbps 14.883 2453.8478 2468.7308 11G Ant1 2412 6Mbps 16.973 2403.4066 2420.3796 11G Ant1 2437 6Mbps 16.913 2428.4245 2445.3375 11G Ant1 2462 6Mbps 16.971 2453.4204 2470.3914 11N20SISO Ant1 2412 MCS0 17.652 2403.1379 2420.7899 11N20SISO Ant1 2437 MCS0 17.917 2428.0576 2445.9746 11N20SISO Ant1 2462 MCS0 17.986 2453.0090 2470.9950 11N40SISO Ant1 2422 MCS0 35.684 2404.0244 2439.7084 11N40SISO Ant1 2437 MCS0 35.653 2419.0562 2454.7092 11N40SISO Ant1 2452 MCS0 35.657 2434.0301 2469.6871 Report No.: GTS2024070218F02 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 5 of 22 Test Graphs 11B-Ant1-2412 11B-Ant1-2437 11B-Ant1-2462 11G-Ant1-2412 11G-Ant1-2437 11G-Ant1-2462 Report No.: GTS2024070218F02 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 6 of 22 11N20SISO-Ant1-2412 11N20SISO-Ant1-2437 11N20SISO-Ant1-2462 11N40SISO-Ant1-2422 11N40SISO-Ant1-2437 11N40SISO-Ant1-2452 Report No.: GTS2024070218F02 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 7 of 22 AppendixC: Maximum conducted output power Test Result Peak Test Mode Antenna Frequency[MHz] Rate Peak Powert[dBm] Conducted Limit[dBm] Verdict 11B Ant1 2412 1Mbps 17.68 ≤30.00 PASS 11B Ant1 2437 1Mbps 17.36 ≤30.00 PASS 11B Ant1 2462 1Mbps 17.28 ≤30.00 PASS 11G Ant1 2412 6Mbps 17.25 ≤30.00 PASS 11G Ant1 2437 6Mbps 17.21 ≤30.00 PASS 11G Ant1 2462 6Mbps 17.37 ≤30.00 PASS 11N20SISO Ant1 2412 MCS0 17.12 ≤30.00 PASS 11N20SISO Ant1 2437 MCS0 17.19 ≤30.00 PASS 11N20SISO Ant1 2462 MCS0 17.22 ≤30.00 PASS 11N40SISO Ant1 2422 MCS0 17.05 ≤30.00 PASS 11N40SISO Ant1 2437 MCS0 17.10 ≤30.00 PASS 11N40SISO Ant1 2452 MCS0 17.31 ≤30.00 PASS Report No.: GTS2024070218F02 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 8 of 22 AppendixD: Maximum power spectral density Test Result Test Mode Antenna Frequency[MHz] Rate Result[dBm/3-100kHz] Limit[dBm/3kHz] Verdict 11B Ant1 2412 1Mbps -8.95 ≤8.00 PASS 11B Ant1 2437 1Mbps -8.84 ≤8.00 PASS 11B Ant1 2462 1Mbps -8.36 ≤8.00 PASS 11G Ant1 2412 6Mbps -14.35 ≤8.00 PASS 11G Ant1 2437 6Mbps -14.87 ≤8.00 PASS 11G Ant1 2462 6Mbps -14.73 ≤8.00 PASS 11N20SISO Ant1 2412 MCS0 -14.84 ≤8.00 PASS 11N20SISO Ant1 2437 MCS0 -14.26 ≤8.00 PASS 11N20SISO Ant1 2462 MCS0 -15.3 ≤8.00 PASS 11N40SISO Ant1 2422 MCS0 -17.02 ≤8.00 PASS 11N40SISO Ant1 2437 MCS0 -17.3 ≤8.00 PASS 11N40SISO Ant1 2452 MCS0 -16.99 ≤8.00 PASS Report No.: GTS2024070218F02 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 9 of 22 Test Graphs 11B-Ant1-2412-PASS 11B-Ant1-2437-PASS 11B-Ant1-2462-PASS 11G-Ant1-2412-PASS 11G-Ant1-2437-PASS 11G-Ant1-2462-PASS…

Text truncated - open the document above for the full version.

Report No.: GTS2024070218F02 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 15 of 22 11B-Ant1-2462-0~Reference-PASS 11B-Ant1-2462-30~1000-PASS 11B-Ant1-2462-1000~26500-PASS 11G-Ant1-2412-0~Reference-PASS 11G-Ant1-2412-30~1000-PASS 11G-Ant1-2412-1000~26500-PASS Report No.: GTS2024070218F02 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 16 of 22 11G-Ant1-2437-0~Reference-PASS 11G-Ant1-2437-30~1000-PASS 11G-Ant1-2437-1000~26500-PASS 11G-Ant1-2462-0~Reference-PASS 11G-Ant1-2462-30~1000-PASS 11G-Ant1-2462-1000~26500-PASS Report No.: GTS2024070218F02 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 17 of 22 11N20SISO-Ant1-2412-0~Reference-PASS 11N20SISO-Ant1-2412-30~1000-PASS 11N20SISO-Ant1-2412-1000~26500-PASS 11N20SISO-Ant1-2437-0~Reference-PASS 11N20SISO-Ant1-2437-30~1000-PASS 11N20SISO-Ant1-2437-1000~26500-PASS Report No.: GTS2024070218F02 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 18 of 22 11N20SISO-Ant1-2462-0~Reference-PASS 11N20SISO-Ant1-2462-30~1000-PASS 11N20SISO-Ant1-2462-1000~26500-PASS 11N40SISO-Ant1-2422-0~Reference-PASS 11N40SISO-Ant1-2422-30~1000-PASS 11N40SISO-Ant1-2422-1000~26500-PASS Report No.: GTS2024070218F02 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 19 of 22 11N40SISO-Ant1-2437-0~Reference-PASS 11N40SISO-Ant1-2437-30~1000-PASS 11N40SISO-Ant1-2437-1000~26500-PASS 11N40SISO-Ant1-2452-0~Reference-PASS 11N40SISO-Ant1-2452-30~1000-PASS 11N40SISO-Ant1-2452-1000~26500-PASS Report No.: GTS2024070218F02 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 20 of 22 AppendixG: Duty Cycle Test Result Test Mode Antenna Frequency[MHz] Rate Transmission Duration [ms] Transmission Period [ms] Duty Cycle [%] Factor 11B Ant1 2412 1Mbps 0.99 1.00 99.00 0.04 11B Ant1 2437 1Mbps 0.99 1.00 99.00 0.04 11B Ant1 2462 1Mbps 0.99 1.00 99.00 0.04 11G Ant1 2412 6Mbps 0.69 0.70 98.57 0.06 11G Ant1 2437 6Mbps 0.69 0.70 98.57 0.06 11G Ant1 2462 6Mbps 0.69 0.70 98.57 0.06 11N20SISO Ant1 2412 MCS0 0.65 0.66 98.48 0.07 11N20SISO Ant1 2437 MCS0 0.65 0.67 97.01 0.13 11N20SISO Ant1 2462 MCS0 0.65 0.66 98.48 0.07 11N40SISO Ant1 2422 MCS0 0.34 0.35 97.14 0.13 11N40SISO Ant1 2437 MCS0 0.34 0.35 97.14 0.13 11N40SISO Ant1 2452 MCS0 0.34 0.35 97.14 0.13 Report No.: GTS2024070218F02 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 21 of 22 Test Graphs NTNV-11B-Ant1-2412 NTNV-11B-Ant1-2437 NTNV-11B-Ant1-2462 NTNV-11G-Ant1-2412 NTNV-11G-Ant1-2437 NTNV-11G-Ant1-2462 Report No.: GTS2024070218F02 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 22 of 22 NTNV-11N20SISO-Ant1-2412 NTNV-11N20SISO-Ant1-2437 NTNV-11N20SISO-Ant1-2462 NTNV-11N40SISO-Ant1-2422 NTNV-11N40SISO-Ant1-2437 NTNV-11N40SISO-Ant1-2452 ------End------

Global United Technology Services Co., Ltd. Report No.: GTS2024070218F01 Authorized Signature: Robinson Luo Laboratory Manager This results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Page 1 of 27 TEST REPORT Applicant: MYHP LIMITED Address of Applicant: Victory Factory Building Unit 30, 2…
