2BH9E-VIPRPLED FLOOR LAMP

INSTRUCTION MANUAL WWW.EZEVENT.NET FOR YOUR OWN SAFETY, PLEASE READ THIS INSTRUCTION MANUAL CAREFULLY BEFORE YOU INITIALLY START-UP THANK YOU FOR PURCHASING AN EZEVENT PRODUCT, WE HOPE YOU ENJOY USING IT. #LIGHT UP YOUR DREAMS ENG INSERT THE LAMP BODY INTO THE BASE. PULL OUT THE SPRING PLUNGER AND INSERT THE LAMP BODY INTO THE BASE UNTIL THE CLIP SPRINGS BACK TO ITS ORIGINAL POSITION. 1 2 INSERT THE BLUE PLUG OF THE WIRE INTO THE BLUE SOCKET OF THE BASE, TURN RIGHT IS ‘‘ON’’ AND TURN LEFT IS ‘‘OFF’’. INSERT THE BLACK PLUG OF THE CABLE INTO THE SOCKET (100-240V). BLUE SOCKET: INPUT 100 - 240V. USB SOCKET: OUTPUT 5V - 2.1A. WHITE SOCKET: OUTPUT 100 - 240V. 3 4 CHARGING STATUS (DISCHARGE) RED LIGHT ON: INDICATES 0-29% BATTERY POWER. BLUE LIGHT ON: INDICATES 30-89% BATTERY POWER. GREEN LIGHT ON: INDICATES 90-100% BATTERY POWER. CHARGING STATUS (CHARGING) FLASHING RED LIGHT: INDICATES 0-29% BATTERY POWER. FLASHING BLUE LIGHT: INDICATES 30-89% BATTERY POWER. FLASHING GREEN LIGHT: INDICATES 90-99.9% BATTERY POWER. GREEN LIGHT ON: INDICATES 100% BATTERY POWER. *TO KEEP THE BATTERY IN GOOD WORKING ORDER OVER TIME, PLEASE CHARGE/DISCHARGE IT AT LEAST ONCE EVERY SIX MONTHS. BATTERY INDICATOR COLOUR LED INDICATOR GREEN, BLUE, RED 5 CLICK TO INCREASE THE BRIGHTNESS BY STEPS: 20% - 40% - 60% - 80% - 100%. LONG PRESS, DIMMER GOES FROM 20% TO 100%. 6-8 SECONDS TO COMPLETE STEPLESS DIMMING. DIMMING + CLICK TO DECREASE THE BRIGHTNESS BY STEPS: 100% - 80% - 60% - 40% - 20%. LONG PRESS, DIMMER GOES FROM 100% TO 20%. 6-8 SECONDS TO COMPLETE STEPLESS DIMMING. DIMMING - CLICK TO SWITCH VIP-R ON OR OFF. ON/OFF CYCLICALLY CLICK TO CHANGE THE COLOR TEMPERATURE: 2600K - 3000K - 3500K - 5000K - 6500K. IF THERE’S NO OPERATION ON THE TOUCHING PANEL DURING 10-12 SECONDS, THE TOUCHING PANEL IS LOCKED. TO UNLOCK IT, LONG PRESS THIS BUTTON FOR 6 SECONDS. CCT CYCLICALLY CLICK THE BUTTON TO ACTIVATE 30 MINUTES TIMER, 60 MINUTES TIMER AND NO TIMER. TO CONNECT VIP-R TO TUYA: PRESS AND HOLD THIS BUTTON (WHEN THE RED AND BLUE INDICATORS ARE FLASHING) TO SWITCH TO TUYA AND CONNECT TO THE NETWORK. PAIR Instructions WWW.EZEVENT.NET BLUE SOCKET WHITE SOCKET USB SOCKET DOWNLOAD THE TUYA APPLICATION ONTO YOUR MOBILE PHONE. PRESS + THEN ADD A DEVICE. CHOOSE YOUR WIFI NETWORK. THE LAMP APPEARS. SETTINGS: ON/OFF. COLOUR TEMPERATURE. DIMMER. CLICK ON THE PEN AT THE TOP RIGHT OF THE SCREEN: RENAME TO VIP-R. CREATE GROUPS TO OBTAIN VIP-RS WITH DIFFERENT SETTINGS DEPENDING ON THE ZONES WHERE THEY ARE PLACED, SO THAT YOU CAN SWITCH ON/OFF, CHANGE THE COLOUR OR INTENSITY OF SEVERAL VIP-RS AT THE SAME TIME. 6 Technical SpecificationsDimensions WWW.EZEVENT.NET CCT 2600 TO 6500K CRI >90 INTENSITY UP TO 1800 LUMENS USB CHARGER 5V 2.1A CONTROL SENSITIVE PANEL TUYA APPLICATION GRADE IP IP20 LENSES ASYMETRIC 15° X 55° HEIGHT UNFOLDED - 240 CM FOLDED - 130 CM TEMPERATURE 0-40° WEIGHT 10KG LED POWER 45 WATTS VOLTAGE AC 100-240V 50/60HZ BATTERY 14,6 V - 23400 MAH - 341 WH AUTONOMY * UP TO 10 HOURS CHARGING TIME * 8 HOURS CHARGING INDICATOR COLOR LED POWER 55W MAX ASSEMBLY EASY FIX INSTALLATION <10 SECONDS FINISH BLACK OR WHITE * FOR INDICATION ONLY. WARNING • Read the instruction in this manual carefully and thoroughly, as they give important information regarding safety during use and maintenance. Keep this manual with the unit, in order to consult it in the future. If the unit is sold or given to another operator, make certain that it always has its manual, to enable the new owner to read about its operation and relative instructions. • To prevent fire or shock hazard, do not expose this product under a high temperature. • This product must be earthed. • Take care not to damage the power cord. • After having removed the packaging check that the unit is NOT damaged in any way. • If in doubt, DON’T use it and contact an authorized dealer. • NEVER use the unit under the following conditions: - In places subject to vibrations or bumps. - In places with a temperature of over 40 °C or less than 0 °C. - In places with high humidity or rain. • DO NOT open the unit, there are no user serviceable parts inside. • NEVER try to repair the unit yourself. Repairs by unqualified people could cause damage or faulty operation. Contact your nearest dealer. • Wait for at least one second to turn on the power after turning off this unit. • Packaging material (plastic bags, polystyrene foam, nails, etc.) MUST NOT be left within children’s reach, as it can be dangerous. • STOP using the unit immediately In the event of serious operation problems and either contact your local dealer for a check or contact us directly. • DO NOT dismantle or modify the unit. • If in doubt, DON’T use it and contact an authorized dealer. • This unit must only be operated by adults. DO NOT allow children to tamper or play with it. Warranty: 24 months / Battery 6 months. DESIGNED IN FRANCE, ASSEMBLED IN CHINA. WWW.EZEVENT.NET INSTRUCTION MANUAL WWW.EZEVENT.NET FOR YOUR OWN SAFETY, PLEASE READ THIS INSTRUCTION MANUAL CAREFULLY BEFORE YOU INITIALLY START-UP THANK YOU FOR PURCHASING AN EZEVENT PRODUCT, WE HOPE YOU ENJOY USING IT. #LIGHT UP YOUR DREAMS ENG INSERT THE LAMP BODY INTO THE BASE. PULL OUT THE SPRING PLUNGER AND INSERT THE LAMP BODY INTO THE BASE UNTIL THE CLIP SPRINGS BACK TO ITS ORIGINAL POSITION. 1 2 INSERT THE BLUE PLUG OF THE WIRE INTO THE BLUE SOCKET OF THE BASE, TURN RIGHT IS ‘‘ON’’ AND TURN LEFT IS ‘‘OFF’’. INSERT THE BLACK PLUG OF THE CABLE INTO THE SOCKET (100-240V). BLUE SOCKET: INPUT 100 - 240V. USB SOCKET: OUTPUT 5V - 2.1A. WHITE SOCKET: OUTPUT 100 - 240V. 3 BLUE SOCKET WHITE SOCKET USB SOCKET 4 CHARGING STATUS (DISCHARGE) RED LIGHT ON: INDICATES 0-29% BATTERY POWER. BLUE LIGHT ON: INDICATES 30-89% BATTERY POWER. GREEN LIGHT ON: INDICATES 90-100% BATTERY POWER. CHARGING STATUS (CHARGING) FLASHING RED LIGHT: INDICATES 0-29% BATTERY POWER. FLASHING BLUE LIGHT: INDICATES 30-89% BATTERY POWER. FLASHING GREEN LIGHT: INDICATES 90-99.9% BATTERY POWER. GREEN LIGHT ON: INDICATES 100% …

Text truncated - open the document above for the full version.

MYHP LIMITED U.S. Agent Designation for Service of Process - Certification Attestation Letter Federal Communications Commission Authorization and Evaluation Division 7 435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: 2BH9E-VIPRP FRN of applicant: 0035797786 Per section 2.911(d)(7) of the FCC rules, MYHP LIMITED certifies that the equipment for which authorization is sought is designated to the following U.S. agent* for service of process: Company Name: uux GROUP INC FCC Registration Number (FRN): 0033701590 Physical U.S. Company Address: 36 South 18th Avenue, Suite A Brighton, CO USA 80601 Contact Person: Jack Fu Agent Email Address: [email protected] The above contact person accepts the obligation for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Signed: Signed Printed name Herve Pequignet Tille CEO Company Name MYHP LIMITED Date 8/20/2024 Agent Signed: Signed Pr inted name Jack Fu Title:Manager Company Name UUX GROUP INC Date 8/20/2024 *the applicant must designate a contact located in the United States for purposes of acting as the applicant's agent for service of process, regardless of whether the applicant is a domestic or foreign entity An applicant located in the United States may designate itself as the agent for service of process

MYHP LIMITED Covered Equipment Certification Attestation Letter 8/20/2024 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: 2BH9E-VIPRP MYHP LIMITED certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. MYHP LIMITED certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Signed: Printed name: Herve Pequignet Title: CEO Company Name: MYHP LIMITED Date: 8/20/2024

DATE : 2024-08-20 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint Jason Wu of Global United Technology Services Co., Ltd.and No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with MYHP LIMITED and Victory Factory Building Unit 30, 2FL, 16 Wong Chuk Hang Road, Wong Chuk Hang, Hong Kong, China Signature: Name: Herve Pequignet Title: CEO Company: MYHP LIMITED

MYHP LIMITED DATE : 2024-08-20 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2BH9E-VIPRP Product Name: LED FLOOR LAMP Request for Confidentiality To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Signature: Name: Herve Pequignet Title: CEO Company: MYHP LIMITED

Differences Declaration To w h o m c o n c e r n , We company MYHP LIMITED hereby declares: The product models VIP-R+, VIP-R+ C are identical in the same PCB layout, interior structure and electrical circuits, The only difference is that the VIP-R+ base has a battery pack, and the VIP-R+ C base does not have a battery pack. Authorized signature: Date: 2024-08-20

Page 1 of 4 Test Model No.: VIP‐R+ Page 2 of 4 Page 3 of 4 Page 4 of 4

50*65MM AC: 100-240V 0.24-0.58A Power: 58W Battery:14.6V 23.4AH 341.6WH USB: 5V2.1A FCC ID: 2BH9E-VIPRP

Page 1 of 12 Test Model No.: VIP‐R+ Page 2 of 12 Page 3 of 12 Page 4 of 12 Page 5 of 12 Page 6 of 12

Page 7 of 12 Page 8 of 12 Page 9 of 12 Page 10 of 12 Page 11 of 12

Page 12 of 12

FCC ID: 2BH9E-VIPRP RF Exposure Evaluation Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. Test Result of RF Exposure Evaluation Band Frequency Max output power (dBm) Output power (mW) Antenna gain (dBi) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Verdict BLE 2402MHz 15.84 38.37 3.15 0.0158 1.0 PASS Remark: The max power density is less than MPE exempt limit, so it is compliance.

Global United Technology Services Co., Ltd. Report No.: GTS2024070219F01 Authorized Signature: Robinson Luo Laboratory Manager This results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Page 1 of 27 TEST REPORT Applicant: MYHP LIMITED Address of Applicant: Victory Factory Building Unit 30, 2FL, 16 Wong Chuk Hang Road, Wong Chuk Hang, Hong Kong, China Manufacturer: MYHP LIMITED Address of Manufacturer: Victory Factory Building Unit 30, 2FL, 16 Wong Chuk Hang Road, Wong Chuk Hang, Hong Kong, China Equipment Under Test (EUT) Product Name: LED FLOOR LAMP Model No.: VIP-R+, VIP-R+ C FCC ID: 2BH9E-VIPRP Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247 Date of sample receipt: July 23, 2024 Date of Test: July 24, 2024-August 20, 2024 Date of report issued: August 20, 2024 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: GTS2024070219F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 27 2 Version Version No. Date Description 00 August 20, 2024 Original Prepared By: Date: August 20, 2024 Project Engineer Check By: Date: August 20, 2024 Reviewer Report No.: GTS2024070219F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 27 3 Contents Page 1 COVER PAGE ........................................................................................................................................... 1 2 VERSION .................................................................................................................................................. 2 3 CONTENTS .............................................................................................................................................. 3 4 TEST SUMMARY ..................................................................................................................................... 4 5 GENERAL INFORMATION ...................................................................................................................... 5 5.1 GENERAL DESCRIPTION OF EUT ......................................................................................................... 5 5.2 TEST MODE ........................................................................................................................................ 7 5.3 DESCRIPTION OF SUPPORT UNITS ....................................................................................................... 7 5.4 DEVIATION FROM STANDARDS ............................................................................................................. 7 5.5 ABNORMALITIES FROM STANDARD CONDITIONS ................................................................................... 7 5.6 TEST FACILITY .................................................................................................................................... 7 5.7 TEST LOCATION ................................................................................................................................. 7 5.8 ADDITIONAL INSTRUCTIONS ................................................................................................................. 7 6 TEST INSTRUMENTS LIST ..................................................................................................................... 8 7 TEST RESULTS AND MEASUREMENT DATA .................................................................................... 10 7.1 ANTENNA REQUIREMENT ................................................................................................................... 10 7.2 CONDUCTED EMISSIONS ................................................................................................................... 11 7.3 CONDUCTED OUTPUT POWER ........................................................................................................... 14 7.4 CHANNEL BANDWIDTH ...................................................................................................................... 15 7.5 POWER SPECTRAL DENSITY ............................................................................................................. 16 7.6 SPURIOUS EMISSION IN NON-RESTRICTED & RESTRICTED BANDS ....................................................... 17 7.6.1 Conducted Emission Method ..................................................................................................... 17 7.6.2 Radiated Emission Method ........................................................................................................ 18 8 TEST SETUP PHOTO ............................................................................................................................ 27 9 EUT CONSTRUCTIONAL DETAILS ..................................................................................................... 27 Report No.: GTS2024070219F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 4 of 27 4 Test Summary Test Item Section in CFR 47 Result Antenna requirement 15.203/15.247 (c) Pass AC Power Line Conducted Emission 15.207 Pass Conducted Output Power 15.247 (b)(3) Pass Channel Bandwidth 15.247 (a)(2) Pass Power Spectral Density 15.247 (e) …

Text truncated - open the document above for the full version.

Report No.: GTS2024070219F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 1 of 8 AppendixA: DTS Bandwidth Test Result Test Mode Antenna Frequency[MHz] DTS BW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict BLE_1M Ant1 2402 0.508 2401.636 2402.144 0.5 PASS BLE_1M Ant1 2440 0.508 2439.652 2440.160 0.5 PASS BLE_1M Ant1 2480 0.504 2479.648 2480.152 0.5 PASS Test Graphs BLE_1M-Ant1-2402-PASS BLE_1M-Ant1-2440-PASS / BLE_1M-Ant1-2480-PASS / Report No.: GTS2024070219F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 8 AppendixB: Occupied Channel Bandwidth Test Result Test Mode Antenna Frequency[MHz] OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict BLE_1M Ant1 2402 0.90619 2401.4333 2402.3395 --- --- BLE_1M Ant1 2440 0.88641 2439.4375 2440.3239 --- --- BLE_1M Ant1 2480 0.89860 2479.4328 2480.3314 --- --- Test Graphs BLE_1M-Ant1-2402 BLE_1M-Ant1-2440 / BLE_1M-Ant1-2480 / Report No.: GTS2024070219F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 8 AppendixC: Maximum conducted output power Test Result Test Mode Antenna Frequency[MHz] Conducted Peak Power[dBm] Conducted Limit[dBm] Verdict BLE_1M Ant1 2402 15.84 ≤30 PASS BLE_1M Ant1 2440 15.24 ≤30 PASS BLE_1M Ant1 2480 15.38 ≤30 PASS Test Graphs BLE_1M-Ant1-2402-PASS BLE_1M-Ant1-2440-PASS / BLE_1M-Ant1-2480-PASS / Report No.: GTS2024070219F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 4 of 8 AppendixD: Maximum power spectral density Test Result Test Mode Antenna Frequency[MHz] Result[dBm/3kHz] Limit[dBm/3kHz] Verdict BLE_1M Ant1 2402 4.97 ≤8.00 PASS BLE_1M Ant1 2440 4.39 ≤8.00 PASS BLE_1M Ant1 2480 4.68 ≤8.00 PASS Test Graphs BLE_1M-Ant1-2402-PASS BLE_1M-Ant1-2440-PASS / BLE_1M-Ant1-2480-PASS / Report No.: GTS2024070219F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 5 of 8 AppendixE:Band edge measurements Test Result Test Mode Antenna Channel Frequency[MHz] RefLevel[dBm] Result[dBm] Limit[dBm] Verdict BLE_1M Ant1 Low 2402 15.59 -27.81 ≤-4.41 PASS BLE_1M Ant1 High 2480 14.31 -43.33 ≤-5.69 PASS Test Graphs BLE_1M-Ant1-2402-PASS BLE_1M-Ant1-2480-PASS Report No.: GTS2024070219F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 6 of 8 AppendixF:Conducted Spurious Emission Test Result Test Mode Antenna Frequency[MHz] FreqRange [MHz] RefLevel [dBm] Result[dBm] Limit[dBm] Verdict BLE_1M Ant1 2402 0~Reference 15.69 15.69 --- PASS BLE_1M Ant1 2402 30~1000 15.69 -61.6 ≤-4.31 PASS BLE_1M Ant1 2402 1000~26500 15.69 -41.24 ≤-4.31 PASS BLE_1M Ant1 2440 0~Reference 15.05 15.05 --- PASS BLE_1M Ant1 2440 30~1000 15.05 -61.64 ≤-4.95 PASS BLE_1M Ant1 2440 1000~26500 15.05 -50.02 ≤-4.95 PASS BLE_1M Ant1 2480 0~Reference 14.39 14.39 --- PASS BLE_1M Ant1 2480 30~1000 14.39 -61.35 ≤-5.61 PASS BLE_1M Ant1 2480 1000~26500 14.39 -50.32 ≤-5.61 PASS Test Graphs BLE_1M-Ant1-2402-0~Reference-PASS BLE_1M-Ant1-2402-30~1000-PASS BLE_1M-Ant1-2402-1000~26500-PASS BLE_1M-Ant1-2440-0~Reference-PASS Report No.: GTS2024070219F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 7 of 8 BLE_1M-Ant1-2440-30~1000-PASS BLE_1M-Ant1-2440-1000~26500-PASS BLE_1M-Ant1-2480-0~Reference-PASS BLE_1M-Ant1-2480-30~1000-PASS / BLE_1M-Ant1-2480-1000~26500-PASS / Report No.: GTS2024070219F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 8 of 8 AppendixG: Duty Cycle Test Result Test Mode Antenna Frequency[MHz] ON Time [ms] Period [ms] Duty Cycle [%] Duty Cycle Factor[dB] BLE_1M Ant1 2402 0.38 0.64 59.38 2.26 BLE_1M Ant1 2440 0.38 0.64 59.38 2.26 BLE_1M Ant1 2480 0.38 0.64 59.38 2.26 Test Graphs NTNV-BLE_1M-Ant1-2402 NTNV-BLE_1M-Ant1-2440 / NTNV-BLE_1M-Ant1-2480 / ------End------

SPECIFICATION Shenzhen DreamLNK Technology Co.,Ltd. 深圳市骏晔科技有限公司 Shenzhen DreamLNK Technology Co., Ltd. 2400-2500MHz(FPC)天线 产 品 规 格 书 客 户 频 段 2400MHz~2500MHz 线材名称 版 本 A1 客户料号 骏晔料号 F6-2.4G 骏晔编号 R F设计 James wang 射频经理 Knight Ai 结构设计 结构经理 技术总监 日 期 2016-03-12 客户确认： 装配是否符合贵司要求：□OK □NG 深圳市骏晔科技有限公司 保密要求 本公司已拥有专有技术所提供的资料应严加保密，在未经本公司事先书面同意的时不允许透露给任何人或其他公司 公司地址：深圳市宝安区新湖路华美居A区C座602 电话：0755-29369047 传真：0755-27844601 Page 2 目录 封 面 ....................................................................................................... 1 目 录 .......................................................................................... 2 一、产品图片 ...................................................................................... 3 二、产品参数 ....................................................................................... 3 三、S11 数据 ................................................................................. ...... 4 四、产品结构图 ................................................................................... 6 五、环境可靠性实验报告 .................................................................. 7 六、联系方式 ........................................................ ..... ........................ 7 深圳市骏晔科技有限公司 保密要求 本公司已拥有专有技术所提供的资料应严加保密，在未经本公司事先书面同意的时不允许透露给任何人或其他公司 公司地址：深圳市宝安区新湖路华美居A区C座602 电话：0755-29369047 传真：0755-27844601 Page 3 一、 产品图片 二、产品参数 产品测试参数 产品名称(Name) FPC内置天线 产品型号(Model Type) F06-2.4G 电 性 能 指 标 (Electrical Specifications) 频率范围 (Frenquency Range) 2400-2500 MHz 极化方式 （Polarization） 垂直 输入阻抗(Impedance) 50 Ω 辐射方向 全向 驻波比（VSWR） ≦1.3 最 大 功 率(Admitted Power ) 1W 增益(Gain) 3dBi±0.5 带宽 (Bandwidth) 135/46MHz 连接方式( Connector Type) 焊线 机 械 指 标 (Mechanical Specifications) 尺寸 (Dimensions) 34.3*9.5mm 材料( Antenna cover) FR-4 连接器型号 (Connector) 焊线 引线长度(Cable Length) 130±3mm 工作温度 (Working Temperature) -20°C-+70°C 存放温度 (Limit Temperature) -40°C-+85°C 深圳市骏晔科技有限公司 保密要求 本公司已拥有专有技术所提供的资料应严加保密，在未经本公司事先书面同意的时不允许透露给任何人或其他公司 公司地址：深圳市宝安区新湖路华美居A区C座602 电话：0755-29369047 传真：0755-27844601 Page 4 三、S11（ VSWR 、Return loss 、Smith）数据 3.1 ：网络分析仪测试报告 3.2 ：暗室 2D、3DRaditation Pattern 深圳市骏晔科技有限公司 保密要求 本公司已拥有专有技术所提供的资料应严加保密，在未经本公司事先书面同意的时不允许透露给任何人或其他公司 公司地址：深圳市宝安区新湖路华美居A区C座602 电话：0755-29369047 传真：0755-27844601 Page 5 深圳市骏晔科技有限公司 保密要求 本公司已拥有专有技术所提供的资料应严加保密，在未经本公司事先书面同意的时不允许透露给任何人或其他公司 公司地址：深圳市宝安区新湖路华美居A区C座602 电话：0755-29369047 传真：0755-27844601 Page 6 四、结构图纸 深圳市骏晔科技有限公司 保密要求 本公司已拥有专有技术所提供的资料应严加保密，在未经本公司事先书面同意的时不允许透露给任何人或其他公司 公司地址：深圳市宝安区新湖路华美居A区C座602 电话：0755-29369047 传真：0755-27844601 Page 7 说明：天线设计过程中需要结合产品外形结构，射频模块信号输入输出接口的位置，以及产品内部的干扰 源的位置来决定弹簧天线的摆放位置，角度，离铺地的间距，离 PCB 基板的高度等。预留π型网络以便匹配 天线，调试天线时请务必提供整套产品外壳及内部 PCBA 功能板，将外部的干扰源及寄生电容计算到匹配当 中去，使天线达到最佳的性能指标及工作效率。左图为侧视图，右图为俯视图。匹配网络的 PCB 走线参考 0.5mm 线宽，网络两边铺地参考 0.35mm 间距以保持良好的阻抗特性。如疑问请 Email 至 [email protected] 将 PCB 文件发至该邮箱或与 FAE 联络。 五、环境性能测试 项目 测试条件 规格 储存环境 在没有指定的情况下测试温度、湿度、气压如下： 1. 温度为-30°C～+80°C 2.相对湿度为45%-85% 3.气压为86kpa-106kpa 电气机械性能正常 高低温试验 在70°C与40°C之间进行5次循环，然后在正常条件下 1-2H，检查外观质量。 尺寸应满足规定并应 满足满足 于机械、电气性能 耐恒定湿热 试验 相对湿度95±3%，试验温度：40°C.持续2H作用后， 试品取出后5min之内测定电气性能，试品在正常条 件下1-2H，检查外观质量 尺寸应满足规定并应 满足满足 于机械、电气性能 振动试验 振频范围10-55HZ，位移幅值：0.35MM，加速度幅值： 50.0M/S，扫频循环次数：30次 电气机械性能正常 跌落试验 1M高空按照互相垂直的轴方向自由跌落3次 电气机械性能正常 六、联系方式 深圳骏晔科技有限公司 Shenzhen DreamLnk Technology Co., Ltd ★ 数据采集、智能家居、物联网应用、无线遥控技术、远距离有源 RFID、天线研发★ 【商务合作】[email protected] 【电话】0755-29369047 【技术支持】[email protected] 【网址】www.dreamlnk.com 【公司地址】广东省 深圳市 宝安区 新湖路华美居A区C座602 【工厂地址】广东省 东莞市塘厦镇138工业区裕华街7号华智创新谷B栋5楼

Page 1 of 2 Test Model No.: VIP‐R+ Radiated Emission Page 2 of 2 Conducted Emissions
