2BHAE-CRUSH20Guitar Amplifier

字体: Microsoft YaHei UI A5 Introduction Thank you for choosing the Flatsons Crush20 rechargeable multi-function portable guitar amplifier. To ensure optimal use of all features and understanding of safety precautions, please read this manual thoroughly before operation. For inquiries or suggestions, contact us at: +86 40071 66908. Product Features 1. Portable Design Maintains a compact form factor while delivering extended battery life. 2. High-Efficiency Amplification Employs a powerful Class D amplifier and optimized power management, delivering 20W RMS efficiently while minimizing weight. 3. Studio-Grade Sound Processing Guitar Channel offers faithful sound reproduction with dedicated reverb; Microphone Channel features dual-band EQ (Bass/Treble) and reverb for vocal enhancement. Package Contents 1. Crush20 Guitar Amplifier ×1 2. USB-C Charging Cable (5V/2A) ×1 3. User's Manual ×1 Specifications Model Rated Power Peak Power Speaker Battery Charging Time Playback Time Channel 1 (Mic) Channel 2 (Guitar) EQ Controls Connectivity Net Weight B.T Name Gross Weight Product Dimensions Crush20 20W 30W 5.5" Full Range 7.4V/3000mAh lithium-ion battery 1.5–2 hours (USB-C 5V/2A) 4–8 hours (70% volume) SNR 85dB / Impedance 10kΩ SNR 95dB / Impedance 2kΩ Bass: ±12dB@125Hz, Treble: ±12dB@8kHz B.T Version 5.3 (15m range) Crush20 4.19 lbs (1.9 kg) 4.72 lbs (2.14 kg) 8.5" L × 6.4" W × 6.5" H (215 × 163 × 166 mm) Panel Shows Channel 1: Microphone / Active Guitar Input 1. Volume Adjust the volume of channel 1. 2. Bass Adjusts low-frequency gain of channel 1. 3. Treble Adjusts high-frequency gain of channel 1. 4. Reverb Adjust the intensity of the reverb effect. Channel 2: Passive Guitar Input 5. Guitar EFX Dedicated reverb switch for channel 2 (passive guitar). Press to activate reverb effect on Channel 2; release to disable. Note: Microphone channel reverb is always active. 6. Volume Adjust the volume of channel 2. Channel 3: B.T Wireless System 7. B.T Function Short Press: When B.T is disconnected, short press to activate pairing mode (LED flashes rapidly); when connected, short press to play/pause music. Pairing Process: Use B.T search to find device named "Crush20" and connect. After successful pairing, LED stays solid with confirmation tone. Long Press (2s): Disable B.T function. 8. Battery Indicator Four LEDs display battery level (each 25% capacity); when the red light turns off, the amplifier enters standby mode and ceases audio output. 9. Master Volume Adjust final output volume for all channels. 10. Channel 2 Input Jack Standard 1/4" (6.35mm) input interface. Connect passive guitars or dynamic microphones. 11. USB-C Charging Port Recharge using included cable with 5V/2A charger (charger not included). 12. Charging Status Light Illuminates solid red during charging, and turns off when fully charged or not being charged. 13. Channel 1 Input Jack Standard 1/4" (6.35mm) input interface. Connect dynamic microphones or active guitar. 14. Power Switch Toggle upward to power on, toggle downward to power off. Tips Active Guitar: Require battery-powered pickups with built-in preamps, delivering strong signals that need connect to Channel 1's low-impedance input to prevent distortion from overload. Passive Guitar: Use non-powered magnetic pickups generating weaker signals, requiring Channel 2's high-impedance input to avoid volume loss and noise interference. MADE IN CHINA 2 4 6 8 010 -4 -2 2 4 -88 2 4 6 8 010 2 4 6 8 010 -4 -2 2 4 -88 VOLUMEBASSTREBLE REVERB VOLUMEMASTER MICGUITAR GUITAR EFX POWER AMP GUITAR INMIC INPOWER DC IN USB 5V2A Crush20 20WATT Built-in 2 4 6 8 010 25% 50% 75% 100% BAT RoHS MADE IN CHINA FCC ID: 2BHAE-CRUSH20 1 2 3 4 5 6 7 8 9 14 13 1211 10 Crush20 User’s Manual Portable Acoustic Guitar Amplifier Getting Started Your new Flatsons Crush20 is a portable amplifier designed to faithfully reproduce the sound of acoustic instruments and a diverse assortment of vocals. With the addition of B.T wireless connectivity, you can now easily add backing tracks or other accompaniment to your performance. Here are some basic setup tips to help get you going. To operate Crush20 safely, please read the entire manual. 1. Battery Charging Fully charge the battery via USB-C (5V/2A) before use. 2. Initial Tone & Effect Setup Set bass and treble to 12 o'clock position, reverb to 9 o'clock position, turn all volumes down for neutral baseline. 3. Connect Instrument Connect your instrument or microphones to channel 1/ channel 2 input with shielded 6.35mm cables. 4. Set Tone & Effect Turn on the power switch. While playing, adjust bass, treble and reverb, then calibrate channel volume by playing intensely and reducing volume when distortion occurs. 5. Volume Optimization Slowly raise master volume to desired level. Tips Always minimize master volume before power-on to prevent speaker damage from power surge and avoid hearing injury from unexpected loud sounds Troubleshooting 1. Can't Turn on the Machine A. Check the battery level to ensure that it is sufficiently charged. B. Check that the power switch is in upward position. 2. Unable to Charge A. Use only the included 5V/2A USB-C cable. B. Ensure power source is 5V/2A DC. C. If left unused for months, recharge every 3 months to maintain battery health. 3. B.T Cannot Connect A. Check whether B.T can be turned on normally. B. If the B.T indicator light does not flash but remains lit, it is possible that another device is connected, please disconnect from the other device and then retry pairing. 4. Audio Distortion/Low Volume A. If using a passive guitar, ensure it is connected to Channel 2 input. B. If using an active guitar or microphone, connect to Channel 1 input. C. Reduce the channel volume if distortion occurs during playback. 5. No Sound from Microphone A. Confirm the microphone is a dynamic type, condenser microphones are not supported. B. Ensure the microphone is properly connected to Channel 1. C. If the microphone requires a battery, check that it is…

Text truncated - open the document above for the full version.

Local Representative Letter For Certification Service in the USA Federal Communications Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Section 2.911(d)(7), of the Commission’s Rules (47 C.F.R.) we attest as follows for the product listed below: FCC ID Model name 2BHAE-CRUSH20 Crush20, Crush30, Crush15, ED30 We hereby acknowledge as follows: i. both signees confirm that the point of contact accepts responsibility to act as a US- American Representative on behalf of the applicant ii. the point of contact provides the physical U.S. address and email as listed below iii. both parties maintain the requirements of this agreement for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. iv. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. US-American Point of Contact Applicant/Approval Holder Signature Date: 2025-12-22 Signature Date: 2025-12-22 Company Name: HOORAY INDUSTRY LLC Shenzhen Flanger Musical Instruments Co., Limited FRN: 0033926106 0035614031 Contact Name: Cindy Wu TOM CAO Address: 1408 Pinon Place Fullerton, CA 92835 United States F/513, FENGSHANGERABLDGD, 514, JIANAN1ST ROAD, WENHUI COMMUNITY, XINAN STREET, BAO'AN DISTRICT, SHENZHEN, China Phone: (626) 910-5808 13603034005 Email: [email protected] [email protected]

Shenzhen HTT Technology Co., Ltd. Report No.: HTT2025091499 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 1 of 4 Product Name: Guitar Amplifier Model No.: Crush20 EUT Constructional Details External Photo Report No.: HTT2025091499 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 2 of 4 Report No.: HTT2025091499 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 3 of 4 Report No.: HTT2025091499 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 4 of 4 ------End------

Label and Location Size: L: 3.0cm*W: 2.0cm FCC ID : 2BHAE-CRUSH20 Label and Location

Shenzhen HTT Technology Co., Ltd. Report No.: HTT2025091499 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 1 of 3 Product Name: Guitar Amplifier Model No.: Crush20 EUT Constructional Details Internal Photo Report No.: HTT2025091499 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 2 of 3 ANTENNA Report No.: HTT2025091499 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 3 of 3 ------End------

Shenzhen HTT Technology Co., Ltd. Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park, Hangcheng Road,Nanchang Community, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Page 1 of 9 RF Exposure evaluation Report Reference No. ..................... : FCC ID............................................. : HTT2025091499F03 2BHAE-CRUSH20 Compiled by ( position+printed name+signature) . : File administrators Supervised by ( position+printed name+signature) . : Project Engineer Approved by ( position+printed name+signature) . : RF Manager Date of issue .................................... : Oct. 15, 2025 Testing Laboratory Name .............. : Shenzhen HTT Technology Co.,Ltd. Address............................................ : 1F, Building B, Huafeng International Robotics Industrial Park, Hangcheng Road,Nanchang Community, Xixiang Street, Bao’an District, Shenzhen, Guangdong, China Applicant’s name ............................ : Shenzhen Flanger Musical Instruments Co., Limited Address............................................ : F/513, FENGSHANGERABLDGD, 514, JIANAN1ST ROAD, WENHUI COMMUNITY, XINAN STREET, BAO'AN DISTRICT SHENZHEN China Standard ........................................... : 47CFR §1.1310 47CFR §2.1093 KDB447498 D01 General RF Exposure Guidance v06 Shenzhen HTT Technology Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen HTT Technology Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen HTT Technology Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : Guitar Amplifier Manufacturer .................................... : Shenzhen Flanger Musical Instruments Co., Limited Trade Mark ........................................ N/A Model/Type reference ...................... : Crush20 Rating ............................................... : DC 7.4V From Battery and DC 5V From External Circuit Result ............................................... : PASS Report No.: HTT2025091499F03 Page 2 of 9 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park, Hangcheng Road,Nanchang Community, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Page 2 of 9 T E S T R E P O R T Equipment under Test : Guitar Amplifier Model /Type : Crush20 Listed Models : Crush30, Crush15, ED30 Applicant : Shenzhen Flanger Musical Instruments Co., Limited Address : F/513, FENGSHANGERABLDGD, 514, JIANAN1ST ROAD, WENHUI COMMUNITY, XINAN STREET, BAO'AN DISTRICT SHENZHEN China Manufacturer : Shenzhen Flanger Musical Instruments Co., Limited Address : F/513, FENGSHANGERABLDGD, 514, JIANAN1ST ROAD, WENHUI COMMUNITY, XINAN STREET, BAO'AN DISTRICT SHENZHEN China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: HTT2025091499F03 Page 3 of 9 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park, Hangcheng Road,Nanchang Community, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Page 3 of 9 Contents 1 T E S T S T A N D A R D S ................................................... 4 2 S U M M A R Y .............................................................. 5 2.1 General Remarks 5 2.2 Product Description 5 2.3 Special Accessories 5 2.4 Modifications 5 3 T E S T E N V I R O N M E N T 6 3.1 Address of the test laboratory 6 3.2 Test Facility 6 3.3 Statement of the measurement uncertainty 6 4 T E S T L I M I T 7 4.1 Requirement 7 4.2 Conducted Power Results 8 4.3 Manufacturing tolerance 8 4.4 Evaluation Result 9 4.5 Simultaneous Transmission for SAR Exclusion 9 5 C O N C L U S I O N 9 Report No.: HTT2025091499F03 Page 4 of 9 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park, Hangcheng Road,Nanchang Community, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Page 4 of 9 1 T E S T S T A N D A R D S The tests were performed according to following standards: ANSI C95.1–1999: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. FCC KDB 447498 D01 General RF Exposure Guidance v06: Mobile and Portable Device, RF Exposure, Equipment Authorization Procedures. FCC CFR 47 part1 1.1310: Radiofrequency radiation exposure limits. FCC CFR 47 part2 2.1093: Radiofrequency radiation exposure evaluation: portable devices Report No.: HTT2025091499F03 Page 5 of 9 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park, Hangcheng Road,Nanchang Community, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Page 5 of 9 2 S U M M A R Y 2.1 General Remarks Date of receipt of test sample : Oct. 09, 2025 Testing commenced on : Oct. 09, 2025 Testing concluded on : Oct. 15, 2025 2.2 Product Description Product Name: Guitar Amplifier Model No.: Crush20 Series model: Crush30, Crush15, ED30 Test sample(s) ID: HTT2025091499-1(Engineer sample) HTT202507075-2(Normal sample) Power Supply: DC 7.4V From Battery and DC 5V From External Circuit Adapter Information (Auxiliary test provided by the lab): Mode: GS-0500200 Input: AC100-240V, 50/60Hz, 0.3A max Output: DC 5V, 2A BLE Operation frequency: 2402MHz to 2480MHz Channel number: 40 Channel separation: 2 MHz Bit Rate of Transmitter: 1Mbps/2Mbps Antenna type: PCB Antenna Antenna gain: -0.58 dBi Bluetooth Operation frequency: 2402MHz~2480MHz Channel number: 79 Channel se…

Text truncated - open the document above for the full version.

Inverted F Antenna Specification Summary ITEM ANT SPEC Model Name 2.4G ANT Center 2400MHz 2500MHz 2400MHz 2500MHz Frequency - 1.26 - 0.76-0.58 - 5.25 - 2.46 -1.86 MAX. Gain Polarization Azimuth Beam Pattern Impedance Antenna Length Manufacture -0.58dBi Horizontal and Vert ical Omni-directional 500hm 38.20mm ZHUHAI JIELI TECHNOLOGY CO.,LTD No. 3 33, Kexing Road, Xiangzhou District, Zhuhai City Antenna Photo & Le ngth (mm) 15.2mm 5.7mm Horizontal 2450MHz Vertical 2450MHz Horizontal: 2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -40 Scale: 5/div 180 Frequency ( M Hz ) Max 2400 - 1.26174 2450 -0.765802 2500 -0.585582 Gain ( dBi ) Min Avg - 30.0801 -7.18716 - 36.5604 -7.48023 -22.0315-6.59127 Vertical: 2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -30 Scale: 5/div 180 Frequency ( M Hz ) Max 2400 -5.2537 2450 -2.4652 2500 -1.86120 Gain ( dBi ) Min - 22.1424 -24.5837 -29.5214 ANT Test Labs Attestation of Global Compliance Co., Ltd. Avg -12.4294 -10.4702 -9.20432

1 Appendix RF Test Data for BLE Company: : Shenzhen Flanger Musical Instruments Co., Limited EUT : Guitar Amplifier FCC ID: : 2BHAE-CRUSH20 Model Number : Crush20 Report No. : HTT2025091499F01 Reviewed By : Heber He 2 1. Duty Cycle 1.1 Test Result 1.1.1 Ant1 Ant1 Mode TX Type Frequency (MHz) T_on (ms) Period (ms) Duty Cycle (%) Duty Cycle Correction Factor (dB) Max. DC Variation (%) 1M SISO 2402 0.088 0.625 14.08 8.51 0.00 2440 0.088 0.625 14.08 8.51 0.03 2480 0.088 0.625 14.08 8.51 0.00 2M SISO 2402 0.056 0.625 8.96 10.48 0.00 2440 0.056 0.625 8.96 10.48 0.00 2480 0.056 0.625 8.96 10.48 0.00 3 1.2 Test Graph 1.2.1 Ant1 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV 4 1M_HCH_2480MHz_Ant1_NTNV 2M_LCH_2402MHz_Ant1_NTNV 5 2M_MCH_2440MHz_Ant1_NTNV 2M_HCH_2480MHz_Ant1_NTNV 6 2. Bandwidth 2.1 Test Result 2.1.1 OBW Mode TX Type Frequency (MHz) ANT 99% Occupied Bandwidth (MHz) Verdict Result Limit 1M SISO 2402 1 1.111 / Pass 2440 1 1.129 / Pass 2480 1 1.151 / Pass 2M SISO 2402 1 2.071 / Pass 2440 1 2.075 / Pass 2480 1 2.078 / Pass 2.1.2 6dB BW Mode TX Type Frequency (MHz) ANT 6dB Bandwidth (MHz) Verdict Result Limit 1M SISO 2402 1 0.506 >=0.5 Pass 2440 1 0.509 >=0.5 Pass 2480 1 0.523 >=0.5 Pass 2M SISO 2402 1 0.878 >=0.5 Pass 2440 1 0.872 >=0.5 Pass 2480 1 0.857 >=0.5 Pass 7 2.2 Test Graph 2.2.1 OBW 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV 8 1M_HCH_2480MHz_Ant1_NTNV 2M_LCH_2402MHz_Ant1_NTNV 9 2M_MCH_2440MHz_Ant1_NTNV 2M_HCH_2480MHz_Ant1_NTNV 10 2.2.2 6dB BW 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV 11 1M_HCH_2480MHz_Ant1_NTNV 2M_LCH_2402MHz_Ant1_NTNV 12 2M_MCH_2440MHz_Ant1_NTNV 2M_HCH_2480MHz_Ant1_NTNV 13 3. Maximum Conducted Output Power 3.1 Test Result 3.1.1 Power Mode TX Type Frequency (MHz) Maximum Peak Conducted Output Power (dBm) Verdict ANT1 Limit 1M SISO 2402 -3.82 <=30 Pass 2440 -4.16 <=30 Pass 2480 -4.15 <=30 Pass 2M SISO 2402 -3.94 <=30 Pass 2440 -4.23 <=30 Pass 2480 -4.24 <=30 Pass 14 4. Maximum Power Spectral Density 4.1 Test Result 4.1.1 PSD Mode TX Type Frequency (MHz) Maximum PSD (dBm) Verdict ANT1 Limit 1M SISO 2402 -3.96 <=8 Pass 2440 -4.24 <=8 Pass 2480 -4.29 <=8 Pass 2M SISO 2402 -4.74 <=8 Pass 2440 -4.99 <=8 Pass 2480 -4.98 <=8 Pass 15 4.2 Test Graph 4.2.1 PSD 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV 16 1M_HCH_2480MHz_Ant1_NTNV 2M_LCH_2402MHz_Ant1_NTNV 17 2M_MCH_2440MHz_Ant1_NTNV 2M_HCH_2480MHz_Ant1_NTNV 18 5. Unwanted Emissions In Non-restricted Frequency Bands 5.1 Test Result 5.1.1 Ref Mode TX Type Frequency (MHz) ANT Level of Reference (dBm) 1M SISO 2402 1 -3.97 2440 1 -4.25 2480 1 -4.28 2M SISO 2402 1 -4.74 2440 1 -4.99 2480 1 -4.98 Note1: Refer to FCC Part 15.247 (d) and ANSI C63.10-2020, the channel contains the maximum PSD level was used to establish the reference level. 5.1.2 CSE Mode TX Type Frequency (MHz) ANT Level of Reference (dBm) Limit (dBm) Verdict 1M SISO 2402 1 -3.97 -23.97 Pass 2440 1 -4.25 -24.25 Pass 2480 1 -4.28 -24.28 Pass 2M SISO 2402 1 -4.74 -24.74 Pass 2440 1 -4.99 -24.99 Pass 2480 1 -4.98 -24.98 Pass Note1: Refer to FCC Part 15.247 (d) and ANSI C63.10-2020, the channel contains the maximum PSD level was used to establish the reference level. 19 5.2 Test Graph 5.2.1 Ref 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV 20 1M_HCH_2480MHz_Ant1_NTNV 2M_LCH_2402MHz_Ant1_NTNV 21 2M_MCH_2440MHz_Ant1_NTNV 2M_HCH_2480MHz_Ant1_NTNV 22 5.2.2 CSE 1M_LCH_2402MHz_Ant1_NTNV 1M_LCH_2402MHz_Ant1_NTNV 23 1M_MCH_2440MHz_Ant1_NTNV 1M_HCH_2480MHz_Ant1_NTNV 24 1M_HCH_2480MHz_Ant1_NTNV 2M_LCH_2402MHz_Ant1_NTNV 25 2M_LCH_2402MHz_Ant1_NTNV 2M_MCH_2440MHz_Ant1_NTNV 26 2M_HCH_2480MHz_Ant1_NTNV 2M_HCH_2480MHz_Ant1_NTNV

Shenzhen HTT Technology Co., Ltd. Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park, Hangcheng Road,Nanchang Community, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ...................: FCC ID. ......................................... : HTT2025091499F01 2BHAE-CRUSH20 Compiled by ( position+printed name+signature) : File administrators Supervised by ( position+printed name+signature) : Project Engineer Approved by ( position+printed name+signature) : RF Manager Date of issue ...................................: Oct. 15, 2025 Testing Laboratory Name .............: Shenzhen HTT Technology Co.,Ltd. Address ..........................................: 1F, Building B, Huafeng International Robotics Industrial Park, Hangcheng Road,Nanchang Community, Xixiang Street, Bao’an District, Shenzhen, Guangdong, China Applicant’s name...........................: Shenzhen Flanger Musical Instruments Co., Limited Address ...........................................: F/513, FENGSHANGERABLDGD, 514, JIANAN1ST ROAD, WENHUI COMMUNITY, XINAN STREET, BAO'AN DISTRICT SHENZHEN China Test specification ......................... : Standard ..........................................: FCC Part 15.247 Shenzhen HTT Technology Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen HTT Technology Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen HTT Technology Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Equipment description ................ : Guitar Amplifier Trade Mark ......................................: N/A Manufacturer ...................................: Shenzhen Flanger Musical Instruments Co., Limited Model/Type reference .....................: Crush20 Listed Models ..................................: Crush30, Crush15, ED30 Modulation ......................................: GFSK Frequency ........................................ From 2402MHz to 2480MHz Ratings ............................................: DC 7.4V From Battery and DC 5V From External Circuit Result ..............................................: PASS Report No.: HTT2025091499F01 Page 2 of 27 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park, Hangcheng Road,Nanchang Community, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China T E S T R E P O R T Equipment under Test : Guitar Amplifier Model /Type : Crush20 Listed Models : Crush30, Crush15, ED30 Applicant : Shenzhen Flanger Musical Instruments Co., Limited Address : F/513, FENGSHANGERABLDGD, 514, JIANAN1ST ROAD, WENHUI COMMUNITY, XINAN STREET, BAO'AN DISTRICT SHENZHEN China Manufacturer : Shenzhen Flanger Musical Instruments Co., Limited Address : F/513, FENGSHANGERABLDGD, 514, JIANAN1ST ROAD, WENHUI COMMUNITY, XINAN STREET, BAO'AN DISTRICT SHENZHEN China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: HTT2025091499F01 Page 3 of 27 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park, Hangcheng Road,Nanchang Community, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Contents 1 TEST STANDARDS .......................................................................................................................................... 4 2 SUMMARY ........................................................................................................................................................ 5 2.1 General Remarks .................................................................................................................................... 5 2.2 Product Description* ................................................................................................................................ 5 2.3 Equipment Under Test ............................................................................................................................ 5 2.4 Short description of the Equipment under Test (EUT) ............................................................................ 5 2.5 EUT configuration .................................................................................................................................... 5 2.6 EUT operation mode ............................................................................................................................... 5 2.7 Block Diagram of Test Setup .................................................................................................................. 6 2.8 Related Submittal(s) / Grant (s) .............................................................................................................. 6 2.9 Modifications ........................................................................................................................................... 6 3 TEST ENVIRONMENT ...................................................................................................................................... 7 3.1 Address of the test laboratory ................................................................................................................. 7 3.2 Test Facility ............................................................................................................................................. 7 3.3 Environmental conditions ........................................................................................................................ 7 3.4 Summary o…

Text truncated - open the document above for the full version.

Shenzhen HTT Technology Co., Ltd. Report No.: HTT2025091499 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 1 of 2 Product Name: Guitar Amplifier Model No.: Crush20 Test Setup Photo Radiated Emission Report No.: HTT2025091499 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 2 of 2 Conducted Emission RF Test ------End------
