2BLLH-AT208BDFJDynamics Autosteering Kit

FJ Dynamics Technology Academy (Changzhou)Co., Ltd. Shenzhen Branch

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Feb 13, 2025
Application Purpose: Original Equipment
Equipment Note: FJDynamics Autosteering Kit
Frequency Range: 2402.00000000 - 2480.00000000
Company: FJ Dynamics Technology Academy (Changzhou)Co., Ltd. Shenzhen Branch
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

FJDynamics Autosteering Kit User Manual FJ Dynamics Technology Academy (Changzhou)Co., Ltd. Shenzhen Branch Room 401, Building 2, Nangang Second Industrial Park, Nanshan District, Shenzhen, China FJDynamics reserves the copyright for this guide and all contents herein. No part of this guide may be reproduced, extracted, reused, and/or reprinted in any form or by any means without the prior written permission of FJDynamics. This guide is subject to change without notice. Copyright Notice: •The purchased products, services, and features are stipulated by the contract. All or part of the products, services, and features described in this manual may not be within the scope of your purchase or usage. Unless otherwise specified in the contract, all the content in this manual is provided "AS IS" without warranties of any kind, express or implied. •The content of this manual is subject to change due to product upgrades and other reasons. (FJDynamics) reserves the right to modify the content of this manual without notice. •This manual only provides guidance for use of this product. Every effort has been made in the preparation of this manual to ensure accuracy of the content, but no information in this manual constitutes a warranty of any kind, express or implied. Preface: Thank you for purchasing FJDynamics' product. This manual provides detailed hardware installation guide. If you have any questions, contact the local dealer. Purpose and Intended Users: This manual introduces the physical characteristics, installation procedures, and technical specifications of the product as well as the specifications and use of the wiring harnesses and connectors. Based on the assumption that the users are familiar with the terms and concepts related to this product, this manual is intended for users who have read the preceding content and have experience in hardware installation and maintenance. Technical Support: FJDynamics' official website: www.fjdynamics.com 1 Product Introduction Disclaimer: 1.1 Main Components The sign-up/login screen is displayed in the language you selected. Sign up: For the first time use, you need to sign up. Tap Register to open the sign-up screen, enter your email address, verification code, and password, and then read and agree to the User Privacy Agreement. Log in: If you have an account already, you can log in directly by entering your username (email address) and password. Forgot password: If you forgot your password, tap Forgot Password to reset the password. Enter your email address, verification code, and new password, and then tap Login to enter the home screen of the system. Select country/region: When internet and satellite positioning are available, the system automatically selects the country or region based on your location, or you can tap in the lower left corner and select your country or region. And the corresponding time zone will follow the change. 2.4 Sign-up/Login To add, delete, modify, check, upload, synchronize, and calibrate the vehicle information, choose MENU > DEVICE SETTINGS > Vehicle Library. 2.5 Setting Vehicle Parameters Power on the control terminal, select a language, and tap Next to open the sign-up/login screen. FJDynamics APP download method: - IOS users can directly search for FJDynamics in the App store and download it. - Android users use cell phone scanning QR code to download. 2.3 Selecting a Language > SYSTEM > Heading calibration. 2. Installation and Operation Instructions 2.1 Workflow Overview This chapter describes the main operation processes and related functions of FJDynamics Autosteering Kit . Before using the system for the first time, you need to complete the installation, commissioning, and preparations to start the autosteering operation successfully. 2.2 Installation and Commissioning For hardware installation, please refer to < FJDynamics Autosteering Kit Auto Steer System Hardware Installation Manual> and <FJDynamics Autosteering Kit Hydraulic Valve Installation Instruction> for details For software using, please refer to < FJDynamics Autosteering Kit Auto Steer System Software User Manual> for details Use the following workflow to install and commission the system for the first time: Select a language Sign up and log in Enter installation information Connect to a signal source Obtain heading* Set the vehicle parameters Calibrate the angle sensor Calibrate the vehicle Calibrate the implement Complete * Drive the vehicle straight ahead for a while, and the heading is obtained automatically. If not, choose MENU 1.2 Control Terminal Ports 3 Wiring Harness FJDynamics Autosteering Kit Auto Steer System is a hydraulic autosteering system that is launched by FJDynamics for agricultural machinery and supports assisted straight line driving. The system consists of the control terminal, GNSS receiver, hydraulic valve, angle sensor, pressure sensor and wiring harnesses. The control terminal runs the software developed by FJDynamics. Size: 275×180×40 mm Basic configuration: 10.1-inch capacitive touch screen, LED backlight, 1280×800 pixels, 700 nit LCD, speaker, 2G RAM, 8G ROM; Various communication interfaces; Power supply: 10 V – 30 V Signals received: radio, satellite, and 4G Relative humidity: 0% – 95%, at 40°C (non-condensing) Operating temperature: -20°C to 70°C Storage temperature: -40°C to 85°C Size: 162 mm×64.5 mm Operating voltage: 10 V – 30 V Operating current: < 300 mA IMU accelerometer accuracy: 0.5 mg IMU gyroscope accuracy: 0.1°/s Roll/pitch: 0.2° Operating temperature: -20°C to 70°C Storage temperature: -40°C to 85°C Pressure range: 3000 psi; Output: 0-5V DC; Interface grade: G 1/4 external thread 1) 30l/min open center valve 2) 60l/min open center valve 3) 60l/min closed center valve 4) 30l/min compatible valve Power supply: 12V DC Voltage standing wave ratio: ≤2.0 Gain: >1±0.5 dBi Impedance: 50 Ω Polarization: vertical Size: ø82 mm×490 mm or ø 82 mm×301 mm Operating temperature: -20°C to 60°C 4 Project Management Contro…

Text truncated - open the document above for the full version.

Internal Photos

Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2402X97491E-RF-INP Page 1 / 19 EUT INTERNAL PHOTOS GSNSS antenna Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2402X97491E-RF-INP Page 2 / 19 Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2402X97491E-RF-INP Page 3 / 19 Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2402X97491E-RF-INP Page 4 / 19 Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2402X97491E-RF-INP Page 5 / 19 Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2402X97491E-RF-INP Page 6 / 19 Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2402X97491E-RF-INP Page 7 / 19 Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2402X97491E-RF-INP Page 8 / 19 Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2402X97491E-RF-INP Page 9 / 19 Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2402X97491E-RF-INP Page 10 / 19 Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2402X97491E-RF-INP Page 11 / 19 center console Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2402X97491E-RF-INP Page 12 / 19 WWAN Main Antenna WWAN AUX Antenna Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2402X97491E-RF-INP Page 13 / 19 BT Antenna WIFI Antenna Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2402X97491E-RF-INP Page 14 / 19 Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2402X97491E-RF-INP Page 15 / 19 Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2402X97491E-RF-INP Page 16 / 19 Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2402X97491E-RF-INP Page 17 / 19 BT&WLAN Module BT&WLAN Module Unshielded Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2402X97491E-RF-INP Page 18 / 19 PMR Module (only RX) PMR Module (only RX) Unshielded Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2402X97491E-RF-INP Page 19 / 19 WWAN Module

Test Setup Photos

Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2402X97491E-RF-00A-TSP TEST SETUP PHOTOGRAPHS Radiated Emission 9k-30MHz Parallel View Radiated Emission 9k-30MHz Perpendicular View Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2402X97491E-RF-00A-TSP Radiated Emission 9k-30MHz Ground-parallel View Radiated Emission 30M-1GHz View Bay Area Compliance Laboratories Corp. (Dongguan) EXHIBIT No.: 2402X97491E-RF-00A-TSP Radiated Emission 1-18GHz View Radiated Emission 18-25GHz View

Test Report

1 _____________________________________________________________________ Productspecificationsacknowledgment Manufacturer ：ShenzhenHelixunTechnologyCo.，LTD Description ：MainAntenna ProductType ：YTX-TX-003019A 2 1、 Cover ...................................................1 2、 Index ....................................................2 3、 ProductSpecification .......................................3 4、 ProductDrawing ..........................................3 5、 TestEquipment&Conditions ................................4 6、 TestReport ...............................................5 3 ProductSpecification Maintechnicalspecifications FrequencyRange(MHz)691-960,1710-2690MHz Impedance(Ω)50 Gain(dB)2.66 VSWR≤3.5 PhysicalProperties Size（mm）65.5*45.39 MaterialFPC CableSY113black250mm ProductDrawing 4 TestEquipment&Conditions SequenceNumberTestItemequipment SparameterVSWRAgilent5071CAgilent5071B OTATestTRP&TIS Agilent8960RSCMW500 ETSSATIMO Gain&EfficiencyGain&Efficiency ETSSATIMO Agilent5071C 5 TestReport S11Parameter-VSWR Frequency69082496017101900210025002690 VSWR3.471.182.491.383.042.311.251.69 6 RadiationPattern(3D) 7 Efficiency Freq（MHz）Gain(dB)Eff(dB)Freq（MHz）Gain(dB)Eff(dB) 700-0.62-6.138401.54-2.4 710-0.24-4.948501.18-2.84 7200.31-3.948601.75-2.96 7300.62-3.298701.99-3.19 7400.46-3.118802.28-3.28 7500.36-2.938902.37-3.27 7601.01-2.439002.21-3.20 7701.47-2.289102.08-3.08 7801.82-1.989201.73-3.09 7902.06-1.89301.25-3.19 8002.08-1.769400.86-3.43 8102.04-1.79500.75-3.49 8201.51-2.069600.36-3.55 8301.42-2.2 8 Freq（MHz）Gain(dB)Eff(dB)Freq（MHz）Gain(dB)Eff(dB) 17102.66-3.1922900.92-4.44 17302.42-3.2423101.29-4.55 17502.23-3.3623301.48-4.37 17701.88-3.5423501.24-4.26 17901.3-3.8323700.71-4.21 18100.52-3.923900.29-4.19 18300.59-4.0124100.08-4 18500.66-4.332430-0.11-4.02 18700.97-4.812450-0.07-4.06 18901.09-5.022470-0.08-3.92 19101.41-4.9224900.4-3.7 19301.18-4.9925100.43-3.74 19500.86-4.8525300.52-3.72 19700.34-4.7825500.75-3.58 19900.49-4.5225701.04-3.73 20100.06-4.4525900.81-3.79 20300.38-4.626100.58-3.98 20500.8-4.6726300.56-3.85 20700.42-4.7926500.54-3.7 2090-0.03-4.5726700.54-3.77 2110-0.03-4.4326901.06-3.8 21300.66-4.12 21501.13-3.78 21700.98-3.7

Test Report

TEST REPORT Applicant: FJ Dynamics Technology Academy (Changzhou)Co., Ltd. Shenzhen Branch Address: Room 401, Building 2, Nangang Second Industrial Park, Nanshan District, Shenzhen, China P r o d u c t N a m e : FJDynamics Autosteering Kit F C C I D : 2BLLH-AT208BD I C : 33312-AT208BD H V I N : AT208BD-2.5GY Standard(s): 47 CFR Part 15, Subpart C (15.247) RSS-247 Issue 3, August 2023 RSS-Gen, Issue 5, February 2021 Amendment 2 ANSI C63.10-2013 KDB 558074 D01 15.247 Meas Guidance v05r02 Report Number: 2402X97491E-RF-00A Report Date: 2025/1/15 The above device has been tested and found compliant with the requirement of the relative standards by Bay Area Compliance Laboratories Corp. (Dongguan). Reviewed By: Pedro Yun Approved By: Gavin Xu Title: Project Engineer Title: RF Supervisor Bay Area Compliance Laboratories Corp. (Dongguan) No.12, Pulong East 1 st Road, Tangxia Town, Dongguan, Guangdong, China Tel: +86-769-86858888 Fax: +86-769-86858891 www.baclcorp.com.cn Note: The information marked ▲ is provided by the applicant, the laboratory is not responsible for its authenticity and this information can affect the validity of the result in the test report. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report cannot be reproduced except in full, without prior written approval of the Company. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. This report may contain data that are not covered by the accreditation scope and shall be marked with ★.This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the U.S. Government. Each test item follows the test standard(s) without deviation. Bay Area Compliance Laboratories Corp. (Dongguan) Report No.:2402X97491E-RF-00A Report Template Version: FCC+IC-BLE-V1.2 Page 2 of 55 CONTENTS DOCUMENT REVISION HISTORY .......................................................................................... 4 1. GENERAL INFORMATION .................................................................................................... 5 1.1 GENERAL DESCRIPTION OF EQUIPMENT UNDER TEST ..................................................................... 5 1.2 ACCESSORY INFORMATION ................................................................................................................. 5 1.3 ANTENNA INFORMATION DETAIL ▲ ..................................................................................................... 5 1.4 EQUIPMENT MODIFICATIONS ............................................................................................................. 5 2. SUMMARY OF TEST RESULTS ............................................................................................ 6 3. DESCRIPTION OF TEST CONFIGURATION ..................................................................... 7 3.1 OPERATION FREQUENCY DETAIL ....................................................................................................... 7 3.2 EUT OPERATION CONDITION ............................................................................................................. 7 3.3 SUPPORT EQUIPMENT LIST AND DETAILS ......................................................................................... 7 3.4 SUPPORT CABLE LIST AND DETAILS .................................................................................................. 7 3.5 BLOCK DIAGRAM OF TEST SETUP ...................................................................................................... 8 3.6 TEST FACILITY ..................................................................................................................................... 9 3.7 MEASUREMENT UNCERTAINTY .......................................................................................................... 9 4. REQUIREMENTS AND TEST PROCEDURES .................................................................. 10 4.1 AC LINE CONDUCTED EMISSIONS .................................................................................................... 10 4.1.1 Applicable Standard ..................................................................................................................................... 10 4.1.2 EUT Setup.................................................................................................................................................... 12 4.1.3 EMI Test Receiver Setup ............................................................................................................................. 12 4.1.4 Test Procedure ............................................................................................................................................. 13 4.1.5 Corrected Amplitude & Margin Calculation ................................................................................................ 13 4.1.6 Test Result ................................................................................................................................................... 13 4.2 RADIATION SPURIOUS EMISSIONS .................................................................................................... 14 4.2.1 Applicable Standard ..................................................................................................................................... 14 4.2.2 EUT Setup.................................................................................................................................................... 14 4.2.3 EMI Test Receiver & Spectrum Analyzer Setup ......................................................................................... 16 4.2.4 Test Procedure ............................................................................................................................................. 16 4.2.5 Corrected Amplitude & Margin Calculation .…

Text truncated - open the document above for the full version.

Test Report

TEST REPORT Applicant: FJ Dynamics Technology Academy (Changzhou)Co., Ltd. Shenzhen Branch Address: Room 401, Building 2, Nangang Second Industrial Park, Nanshan District, Shenzhen, China P r o d u c t N a m e : FJDynamics Autosteering Kit F C C I D : 2BLLH-AT208BD I C : 33312-AT208BD H V I N : AT208BD-2.5GY Standard(s): 47 CFR Part 15, Subpart C (15.247) RSS-247 Issue 3, August 2023 RSS-Gen, Issue 5, February 2021 Amendment 2 ANSI C63.10-2013 KDB 558074 D01 15.247 Meas Guidance v05r02 Report Number: 2402X97491E-RF-00C Report Date: 2024/11/22 The above device has been tested and found compliant with the requirement of the relative standards by Bay Area Compliance Laboratories Corp. (Dongguan). Reviewed By: Pedro Yun Approved By: Gavin Xu Title: Project Engineer Title: RF Supervisor Bay Area Compliance Laboratories Corp. (Dongguan) No.12, Pulong East 1 st Road, Tangxia Town, Dongguan, Guangdong, China Tel: +86-769-86858888 Fax: +86-769-86858891 www.baclcorp.com.cn Note: The information marked ▲ is provided by the applicant, the laboratory is not responsible for its authenticity and this information can affect the validity of the result in the test report. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report cannot be reproduced except in full, without prior written approval of the Company. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. This report may contain data that are not covered by the accreditation scope and shall be marked with ★.This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the U.S. Government. Each test item follows the test standard(s) without deviation. Bay Area Compliance Laboratories Corp. (Dongguan) Report No.:2402X97491E-RF-00C Report Template Version: FCC+IC-Wi-Fi2.4-V1.0 Page 2 of 67 CONTENTS DOCUMENT REVISION HISTORY .......................................................................................... 4 1. GENERAL INFORMATION .................................................................................................... 5 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ....................................................... 5 1.2 ACCESSORY INFORMATION ................................................................................................................. 5 1.3 ANTENNA INFORMATION DETAIL▲ ................................................................................................... 6 1.4 EQUIPMENT MODIFICATIONS ............................................................................................................. 6 2. SUMMARY OF TEST RESULTS ............................................................................................ 7 3. DESCRIPTION OF TEST CONFIGURATION ..................................................................... 8 3.1 OPERATION FREQUENCY DETAIL ....................................................................................................... 8 3.2 EUT OPERATION CONDITION ............................................................................................................. 8 3.3 SUPPORT EQUIPMENT LIST AND DETAILS ......................................................................................... 8 3.4 SUPPORT CABLE LIST AND DETAILS .................................................................................................. 9 3.5 BLOCK DIAGRAM OF TEST SETUP ...................................................................................................... 9 3.6 TEST FACILITY ................................................................................................................................... 10 3.7 MEASUREMENT UNCERTAINTY ........................................................................................................ 10 4. REQUIREMENTS AND TEST PROCEDURES .................................................................. 11 4.1 AC LINE CONDUCTED EMISSIONS .................................................................................................... 11 4.1.1 Applicable Standard ..................................................................................................................................... 11 4.1.2 EUT Setup.................................................................................................................................................... 13 4.1.3 EMI Test Receiver Setup ............................................................................................................................. 13 4.1.4 Test Procedure ............................................................................................................................................. 14 4.1.5 Corrected Amplitude & Margin Calculation ................................................................................................ 14 4.1.6 Test Result ................................................................................................................................................... 14 4.2 RADIATION SPURIOUS EMISSIONS .................................................................................................... 15 4.2.1 Applicable Standard ..................................................................................................................................... 15 4.2.2 EUT Setup.................................................................................................................................................... 15 4.2.3 EMI Test Receiver & Spectrum Analyzer Setup ......................................................................................... 17 4.2.4 Test Procedure ............................................................................................................................................. 17 4.2.5 Corrected Amplitude & Margin Calculation .......…

Text truncated - open the document above for the full version.

RF Exposure Info

MAXIMUM PERMISSIBLE EXPOSURE EVALUATION REPORT Applicant: FJ Dynamics Technology Academy (Changzhou)Co., Ltd. Shenzhen Branch Address: Room 401, Building 2, Nangang Second Industrial Park, Nanshan District, Shenzhen, China P r o d u c t N a m e : FJDynamics Autosteering Kit F C C I D : 2BLLH-AT208BD Standard(s): 47 CFR §1.1310, 47 CFR §2.1091, 47 CFR §15.247(i), 47 CFR §15.407(f) Report Number: 2402X97491E-RF-00E Report Date: 2024/11/22 The above device has been tested and found compliant with the requirement of the relative standards by Bay Area Compliance Laboratories Corp. (Dongguan). Reviewed By: Pedro Yun Approved By: Gavin Xu Title: Project Engineer Title: RF Supervisor Bay Area Compliance Laboratories Corp. (Dongguan) No.12, Pulong East 1 st Road, Tangxia Town, Dongguan, Guangdong, China Tel: +86-769-86858888 Fax: +86-769-86858891 www.baclcorp.com.cn Note: The information marked ▲ is provided by the applicant, the laboratory is not responsible for its authenticity and this information can affect the validity of the result in the test report. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report cannot be reproduced except in full, without prior written approval of the Company. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. This report may contain data that are not covered by the accreditation scope and shall be marked with ★.This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the U.S. Government. Each test item follows the test standard(s) without deviation. Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: 2402X97491E-RF-00E Report Template Version: FCC §2.1091-V1.0 Page 2 of 8 CONTENTS DOCUMENT REVISION HISTORY .......................................................................................... 3 1. GENERAL INFORMATION .................................................................................................... 4 1.1 GENERAL DESCRIPTION OF EQUIPMENT UNDER TEST ..................................................................... 4 1.2 ACCESSORY INFORMATION ................................................................................................................. 4 1.3 OUTPUT POWER AND ANTENNA GAIN INFORMATION ...................................................................... 5 2. RF EXPOSURE EVALUATION (MPE) .................................................................................. 6 2.1 RF EXPOSURE EVALUATION ............................................................................................................... 6 2.1.1 Applicable Standard ....................................................................................................................................... 6 2.1.2 Calculation formula: ...................................................................................................................................... 6 2.1.3 Calculated Data .............................................................................................................................................. 7 EXHIBIT A - EUT PHOTOGRAPHS .......................................................................................... 8 Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: 2402X97491E-RF-00E Report Template Version: FCC §2.1091-V1.0 Page 3 of 8 DOCUMENT REVISION HISTORY Revision Number Report Number Description of RevisionDate of Revision 1.0 2402X97491E-RF-00E Original Report 2024/11/22 Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: 2402X97491E-RF-00E Report Template Version: FCC §2.1091-V1.0 Page 4 of 8 1. GENERAL INFORMATION 1.1 General Description of Equipment under Test EUT Name: FJDynamics Autosteering Kit Trade Name: FJDynamics EUT Model: AT208BD-2.5GY Rated Input Voltage: DC 10~30V, Typical Voltage: DC 12V EUT Received Date: 2024/9/29 EUT Received Status: Good 1.2 Accessory Information EUT Main Components Accessory Description Manufacturer Model Parameters Control Terminal FJDynamics AT208BD-2.5GY Supply Voltage: 10~30VDC GNSS Receiver FJDynamics FJD Operating Voltage: 10~30VDC Proportional Valve FJDynamics FJ31-3000PSB6NC3J5 Power Supply: 12V DC Power Wiring Harness (With Switch Key) FJDynamics / Unshielded without ferrite, 5.5Meter Main Wiring Harness FJDynamics / Unshielded without ferrite, 2.0Meter Spare Main Wiring HarnessFJDynamics Unshielded without ferrite, 2.5Meter GNSS Receiver Wiring Harness FJDynamics / Unshielded without ferrite, 4.0Meter Position Valve Wire HarnessFJDynamics / Unshielded without ferrite, 3.0Meter Proportional Val…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Kate Liu(Certification Engineer)

[email protected]Fax: NA

Test Firm

Bay Area Compliance Laboratories Corp. (Dongguan)David Zhang

[email protected]

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.40 GHz - 2.48 GHz	2.00 mW
2	15C	2.41 GHz - 2.46 GHz	179.00 mW

Confidentiality

Long Term

Grant Notes

Output power listed is conducted. The device contains an approved module (FCC ID: XMR201903EG25G) described in this filing. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. End-users must be provided with instructions and operating conditions for satisfying RF exposure compliance. The device supports 20M and 40M BW modes.
