2BMBQ-CB360BUDECT Audio Baby Monitor

2 Getting Started 2.1 Charge the Baby unit •The batteries are pre-installed in the battery compartment of the baby unit. •Remove the tag at the end of the compartment cover. •Insert the DC plug of the power adapter into the DC socket at the rear bottom of the charger pod. •Connect the other end of the power adapter to the mains socket. Note : Only use the supplied power adapter. •Place the baby unit on the charger pod. The charging Indicator comes ON. •Charge the battery for 16 hours in the baby unit on the charger pod before you use it for the first time. NOTES : The standby time is up to 9 hours however, it varies depending on the sensitivity level you set, your actual use and the age of the battery. 2.1.1 Replacement of the battery cells in the Baby Unit You can replace the battery cells when the battery capacity is degraded after a long period of use. •Place the baby unit on the table with the battery lid facing upwards. •Use a small coin to turn the lock counterclockwise. •Now lift the battery compartment cover with your other hand. ·Replace the battery compartment cover. ·To lock the cover, use the small coin again to turn the lock clockwise. ·Replace the baby unit on the charger pod. · The power Indicator comes ON. 2.2 Charge the Parent Unit The parent unit comes with two battery cells. Charge the battery for 16 hours in the parent unit before you use it for the first time. · Slide off the battery compartment cover. · Insert the two supplied battery cells following the proper battery polarity into the compartment. · Replace the battery compartment cover. · Insert the small plug of the power adapter into the socket on the side of the parent unit. · Connect the other end of the power adapter to the mains socket. · The Charging Indicator comes ON. NOTES : · After the first charge (16h), the parent unit only needs 11h to be fully charged. · It takes longer to charge the battery when the parent unit is turned on. To shorten the charging time, turn the parent unit off while charging. · The standby time is up to 13 hours however, it varies depending on the sensitivity level you set, your actual use and the age of the battery. SMART ECO MODE : · Smart ECO mode automatically minimizes audio trans mission and optimizes autonomy. The closer you are to your baby, the less energy the device consumes to establish a perfect connection. The feature is self-adjusted by the system. 3 Using Your Baby Monitor 3.1 Power on/off the Parent Unit · Slide ON the power switch 12 . Power LED is now ON. · The parent unit is now powered on and will search for and link itself to the baby unit. 3.2 Power on/off the Baby Unit Slide ON the power switch 1 . Then the baby unit will automatically connect to the parent unit. 3.3 Listen to your baby Now the parent unit will sound, and the sound level indicator will inform you when the baby unit detects noise in the baby’s room. The VOX mode implemented in this device guarantees you peace of mind, as it activates the parent unit only above a certain level of sound in the baby room, to avoid being disturbed by background noises. The VOX mode is adjustable (see chapter Sound Level Indicator Setting). 3.4 Adjust Speaker Volume There are 5 volume levels on the baby unit, and 6 levels on the parent unit including VOLUME OFF. • Press or on the parent unit or on the baby unit to adjust the respective volume level. • OFF will be displayed if the volume of the parent unit is turned off. Changing the volume setting on the baby unit will affect the baby unit volume when using the Talk Back & Lullaby features. 3.5 Talk Back You can use the Talk Back feature to comfort and reassure your baby. Whilst using Talk Back you will not be able to hear your baby until you release the button. • Press and hold 20 on the Parent unit to speak to your baby. The display on the Parent unit shows Talk. • Release the key to hear your baby again. 3.5.1 Adjust Talk Back volume The baby unit has 5 volume levels from Level 1 to Level 5. Press or on the baby unit to increase or decrease the volume respectively. NOTE : If a lullaby is playing, it will stop during Talk Back, but will restart from the beginning when the Talk Back ends. 3.6 Lullaby There are 5 lullabies available to play. • Press on the baby unit to start playing a lullaby. Press again to stop playing. • Press on the baby unit to select the lullaby and start playing. • During playback, press to switch between different lullabies. NOTE : This product has an exclusive non disturbing parent mode implemented. You can play lullabies on the baby unit without hearing them on the parent unit to keep peace of mind. 3.7 Room Temperature Monitoring The baby unit constantly measures the temperature in your baby’s room and alerts you if it gets too hot (higher than 26ºC) or too cold (lower than 14ºC) with the unit showing “TEMPERATURE ”. The temperature is displayed clearly on the parent unit’s standby screen. However, it is for reference only. 4 Setting your Baby Monitor with the Parent Unit 4.1 Setting up the Language • Press to access the main menu. • Press or to select LANGUAGE. • Press and or to select your desired language. • Press to confirm the selection. 4.2 Setting up the Nightlight • Press to access the main menu. • Press or to select NIGHTLIGHT. •Press then or to select ON or OFF or DIM. • Press to confirm the selection. NOTE : 1.ON – full brightness, DIM – 80% brightness, OFF – light off. 2.The Nightlight can also be turned ON, OFF or DIM at the baby unit by pressing the button on the baby unit. 3.The Nightlight icon displays on the parent unit when the Nightlight turned on. 4.3 Setting up the Lullaby You can set the lullaby playback ON/OFF and the playback volume (level 1 to 5) at the baby unit. • Press to access the main menu. • Press or to select LULLABY. • Press then or to select ON or OFF or VOLUME. • Press to confirm the selection. NOTE : Press or to select the lullaby playback volume from levels 1 to 5 at the baby unit when VOLUME sett…

Text truncated - open the document above for the full version.

CFR 47 §2.911(d)(5)(i)AttestationLetter Applicant:HUBBLE BABY CARE LIMITED Address:Unit 802, 8/F, Nan Fung Commercial Centre, 19 Lam Lok Street, Kowloon Bay, Kowloon, Hong Kong China Tel: +852-21527638 Fax:+852-21529722 Email:[email protected] Attestation Letter Date: 09/22/2025 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(5)(i) Filing FCC ID:2BMBQ-CB360BU HUBBLE BABY CARE LIMITED certifies that the equipment for which authorization is sought, is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. SincerelyYours, Signature: PrintedName:YH Tong Title: Manager

CFR 47 §2.911 (d)(5)(ii)AttestationLetter Applicant:HUBBLE BABY CARE LIMITED Address:Unit 802, 8/F, Nan Fung Commercial Centre, 19 Lam Lok Street, Kowloon Bay, Kowloon, Hong Kong China Tel: +852-21527638 Fax:+852-21529722 Email:[email protected] Attestation Letter Date: 09/22/2025 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(5)(ii) Filing FCC ID:2BMBQ-CB360BU HUBBLE BABY CARE LIMITED certifies that as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment.And our product does not use Kaspersky software information. SincerelyYours, Signature: PrintedName:YH Tong Title: Manager

U.S. AGENT LETTER OF ATTESTATION Date: 2025-09-22 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(7) Filing FCC ID:2BMBQ-CB360BU HUBBLE BABY CARE LIMITED certifies that, as of the date of the filing of the application, Chillaxcare, LLC is our designated U.S. agent for service of process for the above referenced FCC ID. HUBBLE BABY CARE LIMITED accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Chillaxcare, LLC accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Name: Chillaxcare, LLC Address: P.O. Box 4212 Carmel, IN 46082, United States FRN: 0033441718 Tel.: +1 (248) 672-9139 Email:[email protected] Signed by (printed name): Jon Brody Signature: Applicant: HUBBLE BABY CARE LIMITED Address:Unit 802, 8/F, Nan Fung Commercial Centre, 19 Lam Lok Street, Kowloon Bay, Kowloon, Hong Kong China FRN: 0036304772 Tel: +852-21527638 Email:[email protected] Signed by (printed name): YH Tong Signature:

Applicant:HUBBLE BABY CARE LIMITED Address:Unit 802, 8/F, Nan Fung Commercial Centre, 19 Lam Lok Street, Kowloon Bay, Kowloon, Hong Kong China Tel: +852-21527638 Fax:+852-21529722 Email:[email protected] FCC Confidential Authorization Date: 2025-09-22 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID:2BMBQ-CB360BU In accordance with Sections 0.457 and 0.459 of the Commission’s Rules,HUBBLE BABY CARE LIMITED hereby requests long-term confidential treatment of information accompanying this application as outlined below: Block Diagram Schematics OperationDescription The above materialscontainproprietaryand confidentialinformationnot customarily releasedto the public.The public disclosureof these materialsprovidesunjustified benefitsto its competitorsin the market. SincerelyYours, Signature: PrintedName:YH Tong Title: Manager

Applicant:HUBBLEBABYCARELIMITED Address:Unit802,8/F,NanFungCommercialCentre,19LamLokStreet,KowloonBay, Kowloon,HongKongChina Tel:+852-21527638 Fax:+852-21529722 Email:[email protected] QA-FR-170-B7/29/2014 FCCAuthorization Date:2025-09-22 FEDERALCOMMUNICATIONSCOMMISSIONS AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 Subject:AgentAuthorization Towhomitmayconcern: We,HUBBLEBABYCARELIMITED,theundersigned,herebyauthorizes BayAreaComplianceLaboratoriesCorp.(Shenzhen)toactonitsbehalfinallmatters relatingtoapplicationforEquipmentauthorization,includingthesigningofall documentsrelatingtothesematters.AllactscarriedoutbyBayAreaCompliance LaboratoriesCorp.(Shenzhen)onourbehalfshallhavethesameeffectasourownaction. We,theundersigned,herebycertifythatwearenotsubjecttoadenialoffederalbenefits, thatincludesFCCbenefits,pursuanttoSection5301oftheAnti-DrugAbuseActof1988, 21U.S.C.862. Thisauthorizationisvaliduntilfurtherwrittennoticefromtheapplicant. SincerelyYours, Signature: PrintedName:YHTong Title:Manager

Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2501R46623E-RF-EXP Page 1 of 7 EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2501R46623E-RF-EXP Page 2 of 7 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2501R46623E-RF-EXP Page 3 of 7 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2501R46623E-RF-EXP Page 4 of 7 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2501R46623E-RF-EXP Page 5 of 7 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2501R46623E-RF-EXP Page 6 of 7 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2501R46623E-RF-EXP Page 7 of 7

36mmR 1.5mm 15.5mm Baby Unit Rating Label Rating Label (Baby Unit) 1) Material: Material: White label with matt lamination 2) Size: 36mm x 15.5mm 3) Serial Number Label Barcode Code Format: code 128 - Model Number (4 digits): B360 - Factory code (2 characters): GS - Production date year (1 digit): 4 (eg. 4=2024, 5=2025) - Production date month (1 character): H (Aug, A= Jan, B=Feb, C=Mar, D=Apr, E=May, F=Jun, G=Jul, H=Aug, I=Sep, J=Oct, K=Nov, L=Dec) - Serial no (6 digits). start from ‘000100’ Model: CB360BU FCC ID: 2BMBQ-CB360BU HVIN: CB360BU 2x AAA NiMH battery cell 1.2V 500mAh Made in China SN: B360GS4H000100 Model: CB360BU FCC ID: 2BMBQ-CB360BU HVIN: CB360BU 2x AAA NiMH battery cell 1.2V 500mAh Made in China SN: B360GS4H000100 Lable Color : White Printing Color : Pantone 443C Scale 1:1Scale 2:1

Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2501R46623E-RF-INP Page 1 of 7 EXHIBIT C - EUT INTERNAL PHOTOGRAPHS Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2501R46623E-RF-INP Page 2 of 7 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2501R46623E-RF-INP Page 3 of 7 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2501R46623E-RF-INP Page 4 of 7 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2501R46623E-RF-INP Page 5 of 7 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2501R46623E-RF-INP Page 6 of 7 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2501R46623E-RF-INP Page 7 of 7 ANT

Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2501R46623E-RF-00 TR-EM-RF020 Page 13 of 65 Version 3.0 FCC §1.1307(b) & §2.1091 - RF EXPOSURE EVALUATION Applicable Standard According to KDB 447498 D04 Interim General RF Exposure Guidance v01, clause 2.1.4 –MPE-Based Exemption: An alternative to the SAR-based exemption is provided in § 1.1307(b)(3)(i)(C), for a much wider frequency range, from 300 kHz to 100 GHz, applicable for separation distances greater or equal to λ/2π, where λ is the free-space operating wavelength in meters. The MPE-based test exemption condition is in terms of ERP, defined as the product of the maximum antenna gain and the delivered maximum time-averaged power. For this case, a RF source is an RF exempt device if its ERP (watts) is no more than a frequency-dependent value, as detailed tabular form in Appendix B. These limits have been derived based on the basic specifications on Maximum Permissible Exposure (MPE) considered for the FCC rules in § 1.1310(e)(1). Table to § 1.1307(b)(3)(i)(C) - Single RF Sources Subject to Routine Environmental Evaluation f = frequency in MHz; R = minimum separation distance from the body of a nearby person (appropriate units, e.g., m); Result Mode Frequency (MHz) Tune up conducted power # Antenna Gain # ERP Evaluation Distance (m) MPE-Based Exemption Threshold (mW) (dBm) (dBi)(dBd)(dBm)(mW) DECT 1921.536- 1928.448 20 1.76 -0.39 19.61 91.41 0.2 768 Note 1: The tune-up power and antenna gain was declared by the applicant. Note 2: 0dBd=2.15dBi. Result: Compliant

Note: The information marked # is provided by the applicant, the laboratory is not responsible for its authenticity and this information can affect the validity of the result in the test report. Customer model name, addresses, names, trademarks etc. are included. This report cannot be reproduced except in full, without prior written approval of the Company. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. This report must not be used by the customer to claim product certification, approval, or endorsement by NVLAP or any agency of the U.S. Government. This report may contain data that are not covered by the NVLAP accreditation and are marked with an asterisk “▼”. Bay Area Compliance Laboratories Corp. (Shenzhen) 5F(B-West) , 6F, 7F, the 3rd Phase of Wan Li Industrial Building D, Shihua Rd, FuTian Free Trade Zone, Shenzhen, China Tel: +86-755-33320018 Fax: +86-755-33320008 www.baclcorp.com.cn TR-EM-RF020 Page 1 of 65 Version 3.0 TEST REPORT Applicant Name: HUBBLE BABY CARE LIMITED Address: Unit 802, 8/F, Nan Fung Commercial Centre, 19 Lam Lok Street, Kowloon Bay, Kowloon, Hong Kong China Report Number: 2501R46623E-RF-00 FCC ID: 2BMBQ-CB360BU Test Standard (s) FCC PART 15D Sample Description Product Type: DECT Audio Baby Monitor Model No.: CB360BU Multiple Model(s) No.: N/A Trade Mark: Chillax Date Received: 2025/03/07 Issue Date: 2025/10/11 Test Result: Pass ▲ ▲ In the configuration tested, the EUT complied with the standards above. Prepared and Checked By: Approved By: Bruce Lin Jimmy Xiao RF Engineer EMC Manager Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2501R46623E-RF-00 TR-EM-RF020 Page 2 of 65 Version 3.0 TABLE OF CONTENTS DOCUMENT REVISION HISTORY ......................................................................................................................... 4 GENERAL INFORMATION ....................................................................................................................................... 5 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..................................................................................... 5 OBJECTIVE ................................................................................................................................................................... 5 TEST METHODOLOGY .................................................................................................................................................. 5 MEASUREMENT UNCERTAINTY .................................................................................................................................... 6 TEST FACILITY ............................................................................................................................................................. 6 SYSTEM TEST CONFIGURATION .......................................................................................................................... 7 DESCRIPTION OF TEST CONFIGURATION ...................................................................................................................... 7 EQUIPMENT MODIFICATIONS ....................................................................................................................................... 7 LOCAL SUPPORT EQUIPMENT LIST AND DETAILS ........................................................................................................ 7 EXTERNAL I/O CABLE .................................................................................................................................................. 7 BLOCK DIAGRAM OF TEST SETUP ................................................................................................................................ 8 SUMMARY OF TEST RESULTS ............................................................................................................................. 10 TEST EQUIPMENT LIST ......................................................................................................................................... 11 FCC §1.1307(B) & §2.1091 - RF EXPOSURE EVALUATION .............................................................................. 13 APPLICABLE STANDARD ............................................................................................................................................ 13 RESULT ...................................................................................................................................................................... 13 § 15.317, § 15.203 ANTENNA REQUIREMENT ..................................................................................................... 14 APPLICABLE STANDARD ............................................................................................................................................ 14 ANTENNA CONNECTOR CONSTRUCTION .................................................................................................................... 14 FCC§15.315 & §15.207 - CONDUCTED EMISSIONS ............................................................................................ 15 APPLICABLE STANDARD ............................................................................................................................................ 15 EUT SETUP ................................................................................................................................................................ 15 EMI TEST RECEIVER SETUP ....................................................................................................................................... 15 TEST PROCEDURE ...................................................................................................................................................... 16 FACTOR & OV…

Text truncated - open the document above for the full version.

ANTENNA TEST REPORT Manufacturer: Chillax Care Limited Address: Room118, Flat A, 8/F, William Industrial Building 23-25 Ng Fong Street, San Po Kong,KowloonHong Kong Product Name: EU DECT Audio Baby Monitor Product Model: CB360 BU Report Number: 2503R46625E-RF Date Of Issue: 2025/3/12 Reviewed By : Title: Approved By: Luke Yuan OTA Engineer Sun Zhong Title: Manager Test Laboratory: China Certification ICT Co., Ltd (Dongguan) No. 113, Pingkang Road, Dalang Town, Dongguan, Guangdong, China Tel: +86-769-83085888 www.ccttt.com.cn China Certification ICT Co., Ltd (Dongguan) Report No.: 2503R46625E-RF Page 2 of 13 Test Facility The Test site used by China Certification ICT Co., Ltd (Dongguan) to collect test data is located on the No. 113, Pingkang Road, Dalang Town, Dongguan, Guangdong, China. Declarations China Certification ICT Co., Ltd (Dongguan) is not responsible for the authenticity of any test data provided by the applicant. Data included from the applicant that may affect test results are marked with a triangle symbol “▲”. Customer model name, addresses, names, trademarks etc. are not considered data. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report cannot be reproduced except in full, without prior written approval of the Company. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. This report may contain data that are not covered by the accreditation scope and shall be marked with an asterisk “★”. Each test item follows the test standard(s) without deviation. China Certification ICT Co., Ltd (Dongguan) Report No.: 2503R46625E-RF Page 3 of 13 CONTENTS DOCUMENT REVISION HISTORY .......................................................................................... 4 1. GENERAL INFORMATION .................................................................................................... 5 2. TEST CONFIGURATIONS ...................................................................................................... 6 2.1 TEST ENVIRONMENT ........................................................................................................................... 6 2.2 TEST EQUIPMENT ................................................................................................................................ 6 2.3 TEST SPECIFICATION ........................................................................................................................... 6 2.4 TEST UNCERTAINTY ............................................................................................................................ 6 2.5 TEST MEASUREMENT SYSTEM ............................................................................................................ 7 2.6 TEST SETUP .......................................................................................................................................... 7 2.6.1 Antenna Gain, Efficiency and Radiation Pattern Test Setup ............................................................ 7 3. TEST RESULTS ......................................................................................................................... 8 3.1 GAIN AND EFFICIENCY ........................................................................................................................ 8 3.2 RADIATION PATTERN .......................................................................................................................... 9 4. EUT PHOTOGRAPHS ............................................................................................................ 12 5. TEST SETUP PHOTOGRAPHS ............................................................................................ 13 China Certification ICT Co., Ltd (Dongguan) Report No.: 2503R46625E-RF Page 4 of 13 DOCUMENT REVISION HISTORY Revision Number Report Number Description of Revision Date of Revision 1.0 2503R46625E-RF Original Report 2025/3/12 China Certification ICT Co., Ltd (Dongguan) Report No.: 2503R46625E-RF Page 5 of 13 1. GENERAL INFORMATION Product Name: EU DECT Audio Baby Monitor Product Model: CB360 BU Antenna Type: PCB Test Items: Gain; Efficiency; Radiation Pattern Test Frequency (MHz): 1920, 1925, 1930 Sample Number: 2ZAW-1 EUT Received Date: 2025/3/10 EUT Received Status: Good China Certification ICT Co., Ltd (Dongguan) Report No.: 2503R46625E-RF Page 6 of 13 2. TEST CONFIGURATIONS 2.1 Test Environment Temperature (°C) 29.5 Humidity (%RH) 61.5 Atmospheric Pressure (kPa) 101.3 Tester Leo Li Test Date 2025/3/12 2.2 Test Equipment Manufacturer Description Model Serial Number Calibration Date Calibrate Due Date R&S Vector Network Analyzer ZNB-8 1311601044104250 2025/2/10 2026/2/9 R&S Cross-Pol.Vivald i-ANT TC-TA18 200256 N/A N/A R&S Switch Controller OSP320 1528.3111K02\10 1442 N/A N/A R&S Switch Controller OSP320 1528.3105K03\10 1666 N/A N/A maturo Turntable controllers NCD/536/ 3082..01 N/A N/A N/A R&S Test Software AMS32 11.40.00 N/A N/A R&S Test System TS8991 N/A N/A N/A * Statement of Traceability: China Certification ICT Co., Ltd (Dongguan) attests that all calibrations have been performed, traceable to National Primary Standards and International System of Units (SI). 2.3 Test Specification IEEE Std 149-2021 2.4 Test Uncertainty Otherwise required by the applicant or Product Regulations, Decision Rule in this report did not consider the uncertainty. The extended uncertainty given in this report is obtained by combining the standard uncertainty times the coverage factor K with the 95% confidence interval. Parameter Measurement Uncertainty Passive 1.82 dB VSWR(S11) 0.57 dB China Certification ICT Co., Ltd (Dongguan) Report No.: 2503R46625E-RF Page 7 of 13 2.5 Test Measurement System Conical-cut method is used to measure EUT in OTA qualified anechoic chamber. The Conical Cut method requires the ability of the Measurement Antenna to be physically rotated …

Text truncated - open the document above for the full version.

Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2501R46623E-RF-TSP Page 1 of 3 EXHIBIT D - TEST SETUP PHOTOGRAPHS Conducted Emissions - Front View Conducted Emissions - Side View Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2501R46623E-RF-TSP Page 2 of 3 Radiated Emissions View (Below 30MHz) Radiated Emissions View (Below 1 GHz) Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2501R46623E-RF-TSP Page 3 of 3 Radiated Emissions View (1-18 GHz) Radiated Emissions View (18-20 GHz)
