2BMUF-TL-4KTGTG MAXX

                        '( )* + , - . '( )* + , - .  SS  SS HardwarePowerChipsetVideoDecodingRAMFlash eMMC 32GB Video Output HDMI 2.1 , HDCP2.2 DC Input RangePower ConsumptionAspect Ratio Auto, Full screen Video ResolutionVideo FileFormat Support *.mkv, *.wmv, *.mpg, *.mpeg, *.dat, *.avi,*.mov, *.iso, *.mp4, *.rm, *.jpg, *.bmp, *.gif etc... Easily access live TV, DVR, on-demand, streaming apps, and more on TG S TREAM . Ask Google Assistant to control it all using your voice. device device device AV1 [email protected] up to 4Kx2K@60fps STBPower Adapter BatteryQuick Guide Remote ControlHDMI Cable Google, Google Play, Android TV, Google Cast and other marks aretrademarks of Google LLC.The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries. Amlogic S905X5M-B 5.0V 2.0A 12W This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:-- Reorient or relocate the receiving antenna.-- Increase the separation between the equipment and receiver.-- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Powered by Android TV TM FCC STATEMENT FCC STATEMENT QUICK START GUIDE SAFETY INFORMATION SPECIFICATION QUICK GUIDE DEVICE INFORMATION SETUP DIAGRAM SETUP Led Indicators Power DC IN HDMI output Ethernet Optical USB max.5.0V 500mA HDMIHDMI HDMIHDMI Power Input TV Ethernet Connection Note: Please turn off all equipment before connecting. The device can connect to the network via Ethernet or Wi-Fi. QUICK START GUIDE VideoOperating TemperatureModel TL-4KTG Ⲛ査 -- Consult the dealer or an experienced radio/TV technician for help.This device and its antenna(s) must not be co-located or operation in conjunction with any other antenna or transmitter.Radiation Exposure StatementThis device complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment must be installed and operated in accordance with provided instructions and the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons.CAUTIONRisks of explosion if the battery is replaced by an incorrect type:• Replacement of a battery with an incorrect type that can compromise safety (for example, in the case of some lithium battery types)• Disposal of a battery into fire or a hot oven, or mechanically crushing or cuttingof a battery, that can result in an explosion• Leaving a battery in an extremely high temperature surrounding environmentthat can result in an explosion or the leakage of flammable liquid or gas• A battery subjected to extremely low air pressure that may result in an explosion or the leakage of flammable liquid or gas.

深圳市英佳创电子科技有限公司 http://www.szsyjc.com 第 1 页共 23 页 总部地址：深圳市光明区马田街道油麻岗路11号宏域光明谷C栋 HeadquartersAddress:BuildingC,HongyuGuangmingValley,No.11,YoumaGangRoad,MatanStreet,GuangmingDistrict, ShenzhenCity 东莞分厂：东莞市桥头镇石水口银河三路2号英佳创产业园 DongguanBranch:YingjiachuangIndustrialPark,No.2Yinhe3rdRoad,Shishuikou,QiaotouTown,DongguanCity 杭州办事处：杭州滨江区浦沿街道至仁街5号滨润科创园1栋509 509,Building1,BinrunScienceandTechnologyPark,No.5ZhrenStreet,PuyanStreet,BinjiangDistrict,Hangzhou 绵阳办事处：四川省绵阳市高新区绵兴东路35号万向高新国际4F-34号 MianyangOffice:No.4F-34WanxiangHigh-techInternational,No.35MianxingEastRoad,GaoxinDistrict,MianyangCity,Sichuan Province 电话：0755-27810060传真：0755-27810057网址：http://www.szsyjc.com CUSTOMERNAME 客户名称 深圳市华曦达科技股份有限公司 ShenzhenHuaxidaTechnologyCo.,LTD CUSTOMERP/N 客户料号 PARTNAME 品名 WIFI-12.4G/5G黑色内置天线（L=80mm） WIFI-12.4G/5Gbuilt-inantenna(L=80mm) P/N 料号 YJC-6N080-B112 APPROVALREV. 版次 A0 DELIVERYDATE 送样日期 2024年11月07日 November07,2024 PREPAREDBY 承办 殷飞杰YinFeijie CHECKEDBY 审核 方文锋FangWenfeng APPROVEDBY 核准 肖汉Chauhan CustomerApproved 客户承认 PreparedBy 承办 CheckedBy 审核 ApprovedBy 核准 深圳市英佳创电子科技有限公司 http://www.szsyjc.com 第 2 页共 23 页 目录（Catalogue） 1、封面(Cover)······································································1 2、目录(Catalogue)······························································2 3、履历表(Resume)·································································3 4、产品平面图(Productplan)······················································4 5、端子平面图(Terminalplan)·············································5 6、包装方式图（Packingpatterndrawing）········································6 7、环境性能测试(Environmentalperformancetesting)······························7 8、天线实物图与位置图Antennaphysicaldiagramandlocationdiagram·············8 9、天线性能测试图Antennaperformancetestdiagram··································8 10、隔离度测试图(Isolationtestchart)·········································9 11、参考坐标系(ReferenceCoordinateSystem)··································10 12、2D.3D（WIFI-2）测试数据(2D.3D(WIFI-2)testdata)·············11-13 13、拉力测试报告单（Tensiontestreport）····································14-15 14、端子测试报告单（Terminaltestreport）···························16 15、线材规格参数(Wirespecificationdescription)·····································17 16、ROHS物料控制报告(ROHSMaterialcontrolreport)······························18 17、MSDS·········································································19-23 深圳市英佳创电子科技有限公司 http://www.szsyjc.com 第 3 页共 23 页 履历表(Resumer)： 版本 Version 变更内容及更改原因 Changesandreasons 发行 publish 发行 publish A/0初版发行（Issued） 2024年11月07日 (November07,2024） 深圳市英佳创电子科技有限公司 http://www.szsyjc.com 第 4 页共 23 页 产品平面图(Productplan)： 深圳市英佳创电子科技有限公司 http://www.szsyjc.com 第 5 页共 23 页 端子平面图： 深圳市英佳创电子科技有限公司 http://www.szsyjc.com 第 6 页共 23 页 包装方式图（Packingpatterndrawing）： 深圳市英佳创电子科技有限公司 http://www.szsyjc.com 第 7 页共 23 页 环境性能测试 (Environmentalperformancetesting) : 项目(Project)测试条件(Testcondition)规格 (Specification) 储存环境 Storage Conditions Intheabsenceofspecifiedtesttemperature, humidity,airpressureisasfollows: 在没有指定的情况下测试温度、湿度、气压如下： 1.Temperatureis-45°C~+85°C 1.温度为-45°C~+85°C 2.Relativehumidityof20~80% 2.相对湿度为20~80% 3.Airpressureis86kpato106kpa 3.气压为86kpa-106kpa Electricaland mechanicalproperties isnormal 电气机械性能正常 高低温试验 highandlow temperaturetest Between85°Cand-45°Cfor5loops,then1-2 hundernormalconditions,checktheappearance quality. 在85°C与-45°C之间进行5次循环，然后在正常条件 下1-2H，检查外观质量。 Sizeshouldmeetthe requirementsand shouldsatisfythe contentwiththe electricaland mechanicalproperties 尺寸应满足规定并应满 足于机械、电气性能 耐恒定 湿热试验 Constantdampand hotresistance test 80+/-3%relativehumidity,temperaturetest: 40°C.Lasts2hafter,trytotakeoutthe determinationofelectricalproperties,within 5minaftertry1-2hunderarticlenormalthing, checktheappearancequality 相对湿度80±3%，试验温度：40°C.持续2H作用后， 试品取出后5min之内测定电气性能，试品在正常条 件下1-2H，检查外观质量 Sizeshouldmeetthe requirementsand shouldsatisfythe contentwiththe electricaland mechanicalproperties 尺寸应满足规定并应满 足于机械、电气性能 振动试验 vibrationtest 10-55hz,vibrationfrequencyrangeof displacementamplitude:0.35MM,acceleration amplitude:50.0M/S,sweepcycles:30times 振频范围10-55HZ，位移幅值：0.35MM， 加速度幅值：50.0M/S，扫频循环次数：30次 Electricaland mechanicalproperties isnormal 电气机械性能正常 跌落试验 falldowntest 1mhighaltitudeinaccordancewiththe perpendicularaxisfreedrop3times 1M高空按照互相垂直的轴方向自由跌落3次 Electricaland mechanicalproperties isnormal 电气机械性能正常 深圳市英佳创电子科技有限公司 http://www.szsyjc.com 第 8 页共 23 页 天线实物图与位置图：Antennaphysicaldiagramandlocationdiagram 天线性能测试图:Antennaperformancetestdiagram Freq/GHz2.42.452.55.155.55.85 VSWR1.71.51.51.11.31.4 天 线 贴 附 位 置 深圳市英佳创电子科技有限公司 http://www.szsyjc.com 第 9 页共 23 页 隔离度测试图 WIFI-1&WIFI-2Isolationtestdiagram Freq/GHz2.42.452.55.155.55.85 S21/dB-25-31-36-31-39-36 深圳市英佳创电子科技有限公司 http://www.szsyjc.com 第 10 页共 23 页 参考坐标系ReferenceCoordinateSystem XYXZYZ 0°RightUpUp 90°FrontRightFront 180°LeftDownDown 270°BackLeftBack Y+ X+ Z+ 深圳市英佳创电子科技有限公司 http://www.szsyjc.com 第 11 页共 23 页 2D、3D测试数据(WIFI-1)：2Dand3Dtestdata(WIFI-1): Efficiency&Gainof WIFI-1 Frequency/MhzEfficiency/%MaxGain/dBi 240067.142.5 241067.612.89 242069.822.94 243070.962.72 244073.623.19 245073.113.47 246074.643.56 247076.033.23 248075.513.23 249071.613.19 250068.873.08 5150 57.282.6 5200 59.292.54 5250 57.282.77 5300 59.292.79 5350 58.343.19 5400 57.543.24 5450 65.312.92 5500 63.683.38 5550 63.243.54 5600 64.423.91 5650 68.394.32 5700 63.534.05 5750 63.244 5800 60.673.47 5850 63.13.2 深圳市英佳创电子科技有限公司 http://www.szsyjc.com 第 12 页共 23 页 Phi=0freq=2400MHzPhi=90freq=2400MHzTheta=90freq=2400MHz ZXYface@2400MHzXYZface@2400MHzYZXface@2400MHz ZXYface@2450MHzXYZface@2450MHzYZXface@2450MHz ZXYface@2500MHzXYZface@2500MHzYZXface@2500MHz 深圳市英佳创电子科技有限公司 http://www.szsyjc.com 第 13 页共 23 页 ZXYface@5150MHzXYZface@5150MHzYZXface@5150MHz ZXYface@5350MHzXYZface@5350MHzYZXface@5350MHz ZXYface@5550MHzXYZface@5550MHzYZXface@5550MHz ZXYface@5850MHzXYZface@5850MHzYZXface@5850MHz 深圳市英佳创电子科技有限公司 http://www.szsyjc.com 第 14 页共 23 页 测试报告单Tensiontestreport 报告编号：NY20241107 客户代码 Customercode 1028 客户料号 Customer material number 客户描述 Customer descripti on 2.4G/5G内置天线 （L=80mm） 2.4G/5Gbuilt-in an…

Text truncated - open the document above for the full version.

Setup Photographs AC Power Line Conducted Emission Radiated Band edge and Spurious Emission Page 2 of 2

1 / 32 Appendix D Duty Cycle Condition Mode Frequency (MHz) Antenna On Time (ms) Period (ms) Duty Cycle (%) Correction Factor (dB) 1/T (kHz) Final settingFor VBW (kHz) NVNT BLE 1M 2402 Ant1 0.4 3.75 10.67 9.72 2.51 1 NVNT BLE 1M 2440 Ant1 0.4 3.75 10.67 9.72 2.51 1 NVNT BLE 1M 2480 Ant1 0.4 3.75 10.67 9.72 2.5 1 NVNT BLE 2M 2402 Ant1 0.2 3.75 5.33 12.73 4.9 1 NVNT BLE 2M 2440 Ant1 0.2 3.75 5.33 12.73 4.9 1 NVNT BLE 2M 2480 Ant1 0.2 3.75 5.33 12.73 4.94 1 2 / 32 Test Graphs Duty Cycle NVNT BLE 1M 2402MHz Ant1 Duty Cycle NVNT BLE 1M 2440MHz Ant1 3 / 32 Duty Cycle NVNT BLE 1M 2480MHz Ant1 Duty Cycle NVNT BLE 2M 2402MHz Ant1 4 / 32 Duty Cycle NVNT BLE 2M 2440MHz Ant1 Duty Cycle NVNT BLE 2M 2480MHz Ant1 5 / 32 Maximum Conducted Output Power Condition Mode Frequency (MHz) Antenna Conducted Power (dBm) Duty Factor (dB) Total Power (dBm) Limit (dBm) Verdict NVNT BLE 1M 2402 Ant1 -3.32 0 -3.32 30 Pass NVNT BLE 1M 2440 Ant1 -2.8 0 -2.8 30 Pass NVNT BLE 1M 2480 Ant1 -2.65 0 -2.65 30 Pass NVNT BLE 2M 2402 Ant1 -2.84 0 -2.84 30 Pass NVNT BLE 2M 2440 Ant1 -2.66 0 -2.66 30 Pass NVNT BLE 2M 2480 Ant1 -2.63 0 -2.63 30 Pass 6 / 32 Test Graphs Power NVNT BLE 1M 2402MHz Ant1 Power NVNT BLE 1M 2440MHz Ant1 7 / 32 Power NVNT BLE 1M 2480MHz Ant1 Power NVNT BLE 2M 2402MHz Ant1 8 / 32 Power NVNT BLE 2M 2440MHz Ant1 Power NVNT BLE 2M 2480MHz Ant1 9 / 32 -6dB Bandwidth Condition Mode Frequency (MHz) Antenna -6 dB Bandwidth (MHz) Limit -6 dB Bandwidth (MHz) Verdict NVNT BLE 1M 2402 Ant1 0.66 0.5 Pass NVNT BLE 1M 2440 Ant1 0.66 0.5 Pass NVNT BLE 1M 2480 Ant1 0.66 0.5 Pass NVNT BLE 2M 2402 Ant1 1.13 0.5 Pass NVNT BLE 2M 2440 Ant1 1.13 0.5 Pass NVNT BLE 2M 2480 Ant1 1.13 0.5 Pass 10 / 32 Test Graphs -6dB Bandwidth NVNT BLE 1M 2402MHz Ant1 -6dB Bandwidth NVNT BLE 1M 2440MHz Ant1 11 / 32 -6dB Bandwidth NVNT BLE 1M 2480MHz Ant1 -6dB Bandwidth NVNT BLE 2M 2402MHz Ant1 12 / 32 -6dB Bandwidth NVNT BLE 2M 2440MHz Ant1 -6dB Bandwidth NVNT BLE 2M 2480MHz Ant1 13 / 32 Occupied Channel Bandwidth Condition Mode Frequency (MHz) Antenna 99% OBW (MHz) NVNT BLE 1M 2402 Ant1 1.005 NVNT BLE 1M 2440 Ant1 1.011 NVNT BLE 1M 2480 Ant1 1.021 NVNT BLE 2M 2402 Ant1 2.035 NVNT BLE 2M 2440 Ant1 2.035 NVNT BLE 2M 2480 Ant1 2.041 14 / 32 Test Graphs OBW NVNT BLE 1M 2402MHz Ant1 OBW NVNT BLE 1M 2440MHz Ant1 15 / 32 OBW NVNT BLE 1M 2480MHz Ant1 OBW NVNT BLE 2M 2402MHz Ant1 16 / 32 OBW NVNT BLE 2M 2440MHz Ant1 OBW NVNT BLE 2M 2480MHz Ant1 17 / 32 Maximum Power Spectral Density Level Condition Mode Frequency (MHz) Antenna Conducted PSD (dBm/3kHz) Duty Factor (dB) Total PSD (dBm/3kHz) Limit (dBm/3kHz) Verdict NVNT BLE 1M 2402 Ant1 -18.95 0 -18.95 8 Pass NVNT BLE 1M 2440 Ant1 -17.85 0 -17.85 8 Pass NVNT BLE 1M 2480 Ant1 -17.75 0 -17.75 8 Pass NVNT BLE 2M 2402 Ant1 -21.35 0 -21.35 8 Pass NVNT BLE 2M 2440 Ant1 -21.26 0 -21.26 8 Pass NVNT BLE 2M 2480 Ant1 -21.28 0 -21.28 8 Pass 18 / 32 Test Graphs PSD NVNT BLE 1M 2402MHz Ant1 PSD NVNT BLE 1M 2440MHz Ant1 19 / 32 PSD NVNT BLE 1M 2480MHz Ant1 PSD NVNT BLE 2M 2402MHz Ant1 20 / 32 PSD NVNT BLE 2M 2440MHz Ant1 PSD NVNT BLE 2M 2480MHz Ant1 21 / 32 Band Edge Condition Mode Frequency (MHz) Antenna Max Value (dBc) Limit (dBc) Verdict NVNT BLE 1M 2402 Ant1 -46.45 -20 Pass NVNT BLE 1M 2480 Ant1 -47.48 -20 Pass NVNT BLE 2M 2402 Ant1 -39.53 -20 Pass NVNT BLE 2M 2480 Ant1 -45.94 -20 Pass 22 / 32 Test Graphs Band Edge NVNT BLE 1M 2402MHz Ant1 Ref Band Edge NVNT BLE 1M 2402MHz Ant1 Emission 23 / 32 Band Edge NVNT BLE 1M 2480MHz Ant1 Ref Band Edge NVNT BLE 1M 2480MHz Ant1 Emission 24 / 32 Band Edge NVNT BLE 2M 2402MHz Ant1 Ref Band Edge NVNT BLE 2M 2402MHz Ant1 Emission 25 / 32 Band Edge NVNT BLE 2M 2480MHz Ant1 Ref Band Edge NVNT BLE 2M 2480MHz Ant1 Emission 26 / 32 Conducted RF Spurious Emission Condition Mode Frequency (MHz) Antenna Max Value (dBc) Limit (dBc) Verdict NVNT BLE 1M 2402 Ant1 -45.07 -20 Pass NVNT BLE 1M 2440 Ant1 -46.54 -20 Pass NVNT BLE 1M 2480 Ant1 -45.6 -20 Pass NVNT BLE 2M 2402 Ant1 -43.09 -20 Pass NVNT BLE 2M 2440 Ant1 -44.97 -20 Pass NVNT BLE 2M 2480 Ant1 -45.58 -20 Pass 27 / 32 Test Graphs Tx. Spurious NVNT BLE 1M 2402MHz Ant1 Ref Tx. Spurious NVNT BLE 1M 2402MHz Ant1 Emission 28 / 32 Tx. Spurious NVNT BLE 1M 2440MHz Ant1 Ref Tx. Spurious NVNT BLE 1M 2440MHz Ant1 Emission 29 / 32 Tx. Spurious NVNT BLE 1M 2480MHz Ant1 Ref Tx. Spurious NVNT BLE 1M 2480MHz Ant1 Emission 30 / 32 Tx. Spurious NVNT BLE 2M 2402MHz Ant1 Ref Tx. Spurious NVNT BLE 2M 2402MHz Ant1 Emission 31 / 32 Tx. Spurious NVNT BLE 2M 2440MHz Ant1 Ref Tx. Spurious NVNT BLE 2M 2440MHz Ant1 Emission 32 / 32 Tx. Spurious NVNT BLE 2M 2480MHz Ant1 Ref Tx. Spurious NVNT BLE 2M 2480MHz Ant1 Emission

121 / 142 Tx. Spurious NVNT n20 2437MHz Ant1 Ref Tx. Spurious NVNT n20 2437MHz Ant1 Emission 122 / 142 Tx. Spurious NVNT n20 2437MHz Ant2 Ref Tx. Spurious NVNT n20 2437MHz Ant2 Emission 123 / 142 Tx. Spurious NVNT n20 2462MHz Ant1 Ref Tx. Spurious NVNT n20 2462MHz Ant1 Emission 124 / 142 Tx. Spurious NVNT n20 2462MHz Ant2 Ref Tx. Spurious NVNT n20 2462MHz Ant2 Emission 125 / 142 Tx. Spurious NVNT n40 2422MHz Ant1 Ref Tx. Spurious NVNT n40 2422MHz Ant1 Emission 126 / 142 Tx. Spurious NVNT n40 2422MHz Ant2 Ref Tx. Spurious NVNT n40 2422MHz Ant2 Emission 127 / 142 Tx. Spurious NVNT n40 2437MHz Ant1 Ref Tx. Spurious NVNT n40 2437MHz Ant1 Emission 128 / 142 Tx. Spurious NVNT n40 2437MHz Ant2 Ref Tx. Spurious NVNT n40 2437MHz Ant2 Emission 129 / 142 Tx. Spurious NVNT n40 2452MHz Ant1 Ref Tx. Spurious NVNT n40 2452MHz Ant1 Emission 130 / 142 Tx. Spurious NVNT n40 2452MHz Ant2 Ref Tx. Spurious NVNT n40 2452MHz Ant2 Emission 131 / 142 Tx. Spurious NVNT ax20 2412MHz Ant1 Ref Tx. Spurious NVNT ax20 2412MHz Ant1 Emission 132 / 142 Tx. Spurious NVNT ax20 2412MHz Ant2 Ref Tx. Spurious NVNT ax20 2412MHz Ant2 Emission 133 / 142 Tx. Spurious NVNT ax20 2437MHz Ant1 Ref Tx. Spurious NVNT ax20 2437MHz Ant1 Emission 134 / 142 Tx. Spurious NVNT ax20 2437MHz Ant2 Ref Tx. Spurious NVNT ax20 2437MHz Ant2 Emission 135 / 142 Tx. Spurious NVNT ax20 2462MHz Ant1 Ref Tx. Spurious NVNT ax20 2462MHz Ant1 Emission 136 / 142 Tx. Spurious NVNT ax20 2462MHz Ant2 Ref Tx. Spurious NVNT ax20 2462MHz Ant2 Emission 137 / 142 Tx. Spurious NVNT ax40 2422MHz Ant1 Ref Tx. Spurious NVNT ax40 2422MHz Ant1 Emission 138 / 142 Tx. Spurious NVNT ax40 2422MHz Ant2 Ref Tx. Spurious NVNT ax40 2422MHz Ant2 Emission 139 / 142 Tx. Spurious NVNT ax40 2437MHz Ant1 Ref Tx. Spurious NVNT ax40 2437MHz Ant1 Emission 140 / 142 Tx. Spurious NVNT ax40 2437MHz Ant2 Ref Tx. Spurious NVNT ax40 2437MHz Ant2 Emission 141 / 142 Tx. Spurious NVNT ax40 2452MHz Ant1 Ref Tx. Spurious NVNT ax40 2452MHz Ant1 Emission 142 / 142 Tx. Spurious NVNT ax40 2452MHz Ant2 Ref Tx. Spurious NVNT ax40 2452MHz Ant2 Emission

91 / 142 Band Edge NVNT n20 2412MHz Ant2 Ref Band Edge NVNT n20 2412MHz Ant2 Emission 92 / 142 Band Edge NVNT n20 2462MHz Ant1 Ref Band Edge NVNT n20 2462MHz Ant1 Emission 93 / 142 Band Edge NVNT n20 2462MHz Ant2 Ref Band Edge NVNT n20 2462MHz Ant2 Emission 94 / 142 Band Edge NVNT n40 2422MHz Ant1 Ref Band Edge NVNT n40 2422MHz Ant1 Emission 95 / 142 Band Edge NVNT n40 2422MHz Ant2 Ref Band Edge NVNT n40 2422MHz Ant2 Emission 96 / 142 Band Edge NVNT n40 2452MHz Ant1 Ref Band Edge NVNT n40 2452MHz Ant1 Emission 97 / 142 Band Edge NVNT n40 2452MHz Ant2 Ref Band Edge NVNT n40 2452MHz Ant2 Emission 98 / 142 Band Edge NVNT ax20 2412MHz Ant1 Ref Band Edge NVNT ax20 2412MHz Ant1 Emission 99 / 142 Band Edge NVNT ax20 2412MHz Ant2 Ref Band Edge NVNT ax20 2412MHz Ant2 Emission 100 / 142 Band Edge NVNT ax20 2462MHz Ant1 Ref Band Edge NVNT ax20 2462MHz Ant1 Emission 101 / 142 Band Edge NVNT ax20 2462MHz Ant2 Ref Band Edge NVNT ax20 2462MHz Ant2 Emission 102 / 142 Band Edge NVNT ax40 2422MHz Ant1 Ref Band Edge NVNT ax40 2422MHz Ant1 Emission 103 / 142 Band Edge NVNT ax40 2422MHz Ant2 Ref Band Edge NVNT ax40 2422MHz Ant2 Emission 104 / 142 Band Edge NVNT ax40 2452MHz Ant1 Ref Band Edge NVNT ax40 2452MHz Ant1 Emission 105 / 142 Band Edge NVNT ax40 2452MHz Ant2 Ref Band Edge NVNT ax40 2452MHz Ant2 Emission 106 / 142 Conducted RF Spurious Emission Condition Mode Frequency (MHz) Antenna Max Value (dBc) Limit (dBc) Verdict NVNT b 2412 Ant1 -54.59 -30 Pass NVNT b 2412 Ant2 -54.86 -30 Pass NVNT b 2437 Ant1 -53.63 -30 Pass NVNT b 2437 Ant2 -56.58 -30 Pass NVNT b 2462 Ant1 -54.36 -30 Pass NVNT b 2462 Ant2 -54.84 -30 Pass NVNT g 2412 Ant1 -52.92 -30 Pass NVNT g 2412 Ant2 -52.12 -30 Pass NVNT g 2437 Ant1 -52.28 -30 Pass NVNT g 2437 Ant2 -52.61 -30 Pass NVNT g 2462 Ant1 -51.76 -30 Pass NVNT g 2462 Ant2 -55.02 -30 Pass NVNT n20 2412 Ant1 -54.8 -30 Pass NVNT n20 2412 Ant2 -50.2 -30 Pass NVNT n20 2437 Ant1 -54.41 -30 Pass NVNT n20 2437 Ant2 -52.38 -30 Pass NVNT n20 2462 Ant1 -54.36 -30 Pass NVNT n20 2462 Ant2 -52.66 -30 Pass NVNT n40 2422 Ant1 -49.85 -30 Pass NVNT n40 2422 Ant2 -47.97 -30 Pass NVNT n40 2437 Ant1 -47.66 -30 Pass NVNT n40 2437 Ant2 -49.97 -30 Pass NVNT n40 2452 Ant1 -46.63 -30 Pass NVNT n40 2452 Ant2 -49.16 -30 Pass NVNT ax20 2412 Ant1 -50.62 -30 Pass NVNT ax20 2412 Ant2 -50.51 -30 Pass NVNT ax20 2437 Ant1 -48.9 -30 Pass NVNT ax20 2437 Ant2 -41.97 -30 Pass NVNT ax20 2462 Ant1 -51.48 -30 Pass NVNT ax20 2462 Ant2 -50.39 -30 Pass NVNT ax40 2422 Ant1 -48.77 -30 Pass NVNT ax40 2422 Ant2 -48.01 -30 Pass NVNT ax40 2437 Ant1 -46.98 -30 Pass NVNT ax40 2437 Ant2 -48.29 -30 Pass NVNT ax40 2452 Ant1 -47.44 -30 Pass NVNT ax40 2452 Ant2 -49.09 -30 Pass 107 / 142 Test Graphs Tx. Spurious NVNT b 2412MHz Ant1 Ref Tx. Spurious NVNT b 2412MHz Ant1 Emission 108 / 142 Tx. Spurious NVNT b 2412MHz Ant2 Ref Tx. Spurious NVNT b 2412MHz Ant2 Emission 109 / 142 Tx. Spurious NVNT b 2437MHz Ant1 Ref Tx. Spurious NVNT b 2437MHz Ant1 Emission 110 / 142 Tx. Spurious NVNT b 2437MHz Ant2 Ref Tx. Spurious NVNT b 2437MHz Ant2 Emission 111 / 142 Tx. Spurious NVNT b 2462MHz Ant1 Ref Tx. Spurious NVNT b 2462MHz Ant1 Emission 112 / 142 Tx. Spurious NVNT b 2462MHz Ant2 Ref Tx. Spurious NVNT b 2462MHz Ant2 Emission 113 / 142 Tx. Spurious NVNT g 2412MHz Ant1 Ref Tx. Spurious NVNT g 2412MHz Ant1 Emission 114 / 142 Tx. Spurious NVNT g 2412MHz Ant2 Ref Tx. Spurious NVNT g 2412MHz Ant2 Emission 115 / 142 Tx. Spurious NVNT g 2437MHz Ant1 Ref Tx. Spurious NVNT g 2437MHz Ant1 Emission 116 / 142 Tx. Spurious NVNT g 2437MHz Ant2 Ref Tx. Spurious NVNT g 2437MHz Ant2 Emission 117 / 142 Tx. Spurious NVNT g 2462MHz Ant1 Ref Tx. Spurious NVNT g 2462MHz Ant1 Emission 118 / 142 Tx. Spurious NVNT g 2462MHz Ant2 Ref Tx. Spurious NVNT g 2462MHz Ant2 Emission 119 / 142 Tx. Spurious NVNT n20 2412MHz Ant1 Ref Tx. Spurious NVNT n20 2412MHz Ant1 Emission 120 / 142 Tx. Spurious NVNT n20 2412MHz Ant2 Ref Tx. Spurious NVNT n20 2412MHz Ant2 Emission

深圳市英佳创电子科技有限公司 http://www.szsyjc.com 第 1 页共 23 页 总部地址：深圳市光明区马田街道油麻岗路11号宏域光明谷C栋 HeadquartersAddress:BuildingC,HongyuGuangmingValley,No.11,YoumaGangRoad,MatanStreet,GuangmingDistrict, ShenzhenCity 东莞分厂：东莞市桥头镇石水口银河三路2号英佳创产业园 DongguanBranch:YingjiachuangIndustrialPark,No.2Yinhe3rdRoad,Shishuikou,QiaotouTown,DongguanCity 杭州办事处：杭州滨江区浦沿街道至仁街5号滨润科创园1栋509 509,Building1,BinrunScienceandTechnologyPark,No.5ZhrenStreet,PuyanStreet,BinjiangDistrict,Hangzhou 绵阳办事处：四川省绵阳市高新区绵兴东路35号万向高新国际4F-34号 MianyangOffice:No.4F-34WanxiangHigh-techInternational,No.35MianxingEastRoad,GaoxinDistrict,MianyangCity,Sichuan Province 电话：0755-27810060传真：0755-27810057网址：http://www.szsyjc.com CUSTOMERNAME 客户名称 深圳市华曦达科技股份有限公司 ShenzhenHuaxidaTechnologyCo.,LTD CUSTOMERP/N 客户料号 PARTNAME 品名 WIFI-22.4G/5G黑色内置天线（L=40mm） WIFI-22.4G/5Gbuilt-inantenna(L=40mm) P/N 料号 YJC-6N040-B76 APPROVALREV. 版次 A0 DELIVERYDATE 送样日期 2024年11月07日 November07,2024 PREPAREDBY 承办 殷飞杰YinFeijie CHECKEDBY 审核 方文锋FangWenfeng APPROVEDBY 核准 肖汉Chauhan CustomerApproved 客户承认 PreparedBy 承办 CheckedBy 审核 ApprovedBy 核准 深圳市英佳创电子科技有限公司 http://www.szsyjc.com 第 2 页共 23 页 目录（Catalogue） 1、封面(Cover)······································································1 2、目录(Catalogue)······························································2 3、履历表(Resume)·································································3 4、产品平面图(Productplan)······················································4 5、端子平面图(Terminalplan)·············································5 6、包装方式图（Packingpatterndrawing）········································6 7、环境性能测试(Environmentalperformancetesting)······························7 8、天线实物图与位置图Antennaphysicaldiagramandlocationdiagram·············8 9、天线性能测试图Antennaperformancetestdiagram··································8 10、隔离度测试图(Isolationtestchart)·········································9 11、参考坐标系(ReferenceCoordinateSystem)··································10 12、2D.3D（WIFI-2）测试数据(2D.3D(WIFI-2)testdata)·············11-13 13、拉力测试报告单（Tensiontestreport）····································14-15 14、端子测试报告单（Terminaltestreport）···························16 15、线材规格参数(Wirespecificationdescription)·····································17 16、ROHS物料控制报告(ROHSMaterialcontrolreport)······························18 17、MSDS·········································································19-23 深圳市英佳创电子科技有限公司 http://www.szsyjc.com 第 3 页共 23 页 履历表(Resumer)： 版本 Version 变更内容及更改原因 Changesandreasons 发行 publish 发行 publish A/0初版发行（Issued） 2024年11月07日 (November07,2024） 深圳市英佳创电子科技有限公司 http://www.szsyjc.com 第 4 页共 23 页 产品平面图(Productplan)： 深圳市英佳创电子科技有限公司 http://www.szsyjc.com 第 5 页共 23 页 端子平面图： 深圳市英佳创电子科技有限公司 http://www.szsyjc.com 第 6 页共 23 页 包装方式图（Packingpatterndrawing）： 深圳市英佳创电子科技有限公司 http://www.szsyjc.com 第 7 页共 23 页 环境性能测试 (Environmentalperformancetesting) : 项目(Project)测试条件(Testcondition)规格 (Specification) 储存环境 Storage Conditions Intheabsenceofspecifiedtesttemperature, humidity,airpressureisasfollows: 在没有指定的情况下测试温度、湿度、气压如下： 1.Temperatureis-45°C~+85°C 1.温度为-45°C~+85°C 2.Relativehumidityof20~80% 2.相对湿度为20~80% 3.Airpressureis86kpato106kpa 3.气压为86kpa-106kpa Electricaland mechanicalproperties isnormal 电气机械性能正常 高低温试验 highandlow temperaturetest Between85°Cand-45°Cfor5loops,then1-2 hundernormalconditions,checktheappearance quality. 在85°C与-45°C之间进行5次循环，然后在正常条件 下1-2H，检查外观质量。 Sizeshouldmeetthe requirementsand shouldsatisfythe contentwiththe electricaland mechanicalproperties 尺寸应满足规定并应满 足于机械、电气性能 耐恒定 湿热试验 Constantdampand hotresistance test 80+/-3%relativehumidity,temperaturetest: 40°C.Lasts2hafter,trytotakeoutthe determinationofelectricalproperties,within 5minaftertry1-2hunderarticlenormalthing, checktheappearancequality 相对湿度80±3%，试验温度：40°C.持续2H作用后， 试品取出后5min之内测定电气性能，试品在正常条 件下1-2H，检查外观质量 Sizeshouldmeetthe requirementsand shouldsatisfythe contentwiththe electricaland mechanicalproperties 尺寸应满足规定并应满 足于机械、电气性能 振动试验 vibrationtest 10-55hz,vibrationfrequencyrangeof displacementamplitude:0.35MM,acceleration amplitude:50.0M/S,sweepcycles:30times 振频范围10-55HZ，位移幅值：0.35MM， 加速度幅值：50.0M/S，扫频循环次数：30次 Electricaland mechanicalproperties isnormal 电气机械性能正常 跌落试验 falldowntest 1mhighaltitudeinaccordancewiththe perpendicularaxisfreedrop3times 1M高空按照互相垂直的轴方向自由跌落3次 Electricaland mechanicalproperties isnormal 电气机械性能正常 深圳市英佳创电子科技有限公司 http://www.szsyjc.com 第 8 页共 23 页 天线实物图与位置图：Antennaphysicaldiagramandlocationdiagram 天线性能测试图:Antennaperformancetestdiagram Freq/GHz2.42.452.55.155.55.85 VSWR1.61.21.31.91.21.5 天 线 贴 附 位 置 深圳市英佳创电子科技有限公司 http://www.szsyjc.com 第 9 页共 23 页 隔离度测试图 WIFI-1&WIFI-2Isolationtestdiagram Freq/GHz2.42.452.55.155.55.85 S21/dB-25-31-36-31-39-36 深圳市英佳创电子科技有限公司 http://www.szsyjc.com 第 10 页共 23 页 参考坐标系ReferenceCoordinateSystem XYXZYZ 0°RightUpUp 90°FrontRightFront 180°LeftDownDown 270°BackLeftBack Y+ X+ Z+ 深圳市英佳创电子科技有限公司 http://www.szsyjc.com 第 11 页共 23 页 2D、3D测试数据(WIFI-2)：2Dand3Dtestdata(WIFI-2): Efficiency&Gainof WIFI-2 Frequency/MhzEfficiency/%MaxGain/dBi 240057.281.11 241063.531.52 242063.531.48 243066.991.89 244068.712.07 245069.822.2 246069.182.26 247069.662.25 248068.712.3 249065.462.27 250064.712.37 5150 58.753.74 5200 61.663.67 5250 61.243.7 5300 61.943.34 5350 62.813.04 5400 60.812.51 5450 68.081.33 5500 65.010.95 5550 66.990.74 5600 66.830.82 5650 69.021.19 5700 66.530.95 5750 67.31.43 5800 63.240.8 5850 65.770.87 深圳市英佳创电子科技有限公司 http://www.szsyjc.com 第 12 页共 23 页 Phi=0freq=2400MHzPhi=90freq=2400MHzTheta=90freq=2400MHz ZXYface@2400MHzXYZface@2400MHzYZXface@2400MHz ZXYface@2450MHzXYZface@2450MHzYZXface@2450MHz ZXYface@2500MHzXYZface@2500MHzYZXface@2500MHz 深圳市英佳创电子科技有限公司 http://www.szsyjc.com 第 13 页共 23 页 ZXYface@5150MHzXYZface@5150MHzYZXface@5150MHz ZXYface@5350MHzXYZface@5350MHzYZXface@5350MHz ZXYface@5550MHzXYZface@5550MHzYZXface@5550MHz ZXYface@5850MHzXYZface@5850MHzYZXface@5850MHz 深圳市英佳创电子科技有限公司 http://www.szsyjc.com 第 14 页共 23 页 测试报告单Tensiontestreport 报告编号：NY20241107 客户代码 Customercode 1028 客户料号 Customer material number 客户描述 Customer descripti on 2.4G/5G内置天线 （L=40mm） 2.4G/5Gbuilt-in a…

Text truncated - open the document above for the full version.

TRF No.: 04-E001-0B TRF Originator: GTG TRF Date: 2023-12-13 Web: www.gtggroup.com E-mail: [email protected] Tel.: 86-400 755 8988 CFR 47 FCC PART 15 SUBPART C, ISED RSS-247 ISSUE 3 (DTS) TEST REPORT For TG MAXX MODEL NUMBER: TL-4KTG REPORT NUMBER: E04A25100217F00104 ISSUE DATE: November 14, 2025 FCC ID: 2BMUF-TL-4KTG Prepared for Translite Global LLC PO BOX 1015, Spring, Texas 77383, United States Prepared by Guangdong Global Testing Technology Co., Ltd. Room 101-105, 203-210, Building 1, No.2, Keji 8 Road, Songshan Lake Park, Dongguan city, Guangdong, People’s Republic of China, 523808 This report is based on a single evaluation of the submitted sample(s) of the above mentioned product, it does not imply an assessment of the production of the products. This report shall not be reproduced, except in full, without the written approval of Guangdong Global Testing Technology Co., Ltd. REPORT NO.: E04A25100217F00104 Page 2 of 43 TRF No.: 04-E001-0B Global Testing , Great Quality. Revision History Rev. Issue Date Revisions Revised By V0 November 14, 2025 Initial Issue REPORT NO.: E04A25100217F00104 Page 3 of 43 TRF No.: 04-E001-0B Global Testing , Great Quality. Summary of Test Results Test Item Clause Limit/Requirement Result Antenna Requirement FCC: ANSI C63.10-2020; ISED: ANSI C63.10- 2020+Cor.1-2023+C63.10a- 2024 FCC Part 15.203/15.247 (c) RSS-GEN Clause 6.8 Pass AC Power Line Conducted Emission FCC: ANSI C63.10-2020; ISED: ANSI C63.10- 2020+Cor.1-2023+C63.10a- 2024 FCC Part 15.207 RSS-GEN Clause 8.8 Pass Conducted Output Power FCC: ANSI C63.10-2020; ISED: ANSI C63.10- 2020+Cor.1-2023+C63.10a- 2024 FCC Part 15.247 (b)(3) RSS-247 Clause 5.4 (d) Pass 6dB Bandwidth and 99% Occupied Bandwidth FCC: ANSI C63.10-2020; ISED: ANSI C63.10- 2020+Cor.1-2023+C63.10a- 2024 FCC Part 15.247 (a)(2) RSS-247 Clause 5.2 (a) ISED RSS-Gen Clause 6.7 Pass Power Spectral Density FCC: ANSI C63.10-2020; ISED: ANSI C63.10- 2020+Cor.1-2023+C63.10a- 2024 FCC Part 15.247 (e) RSS-247 Clause 5.2 (b) Pass Conducted Band edge and spurious emission FCC: ANSI C63.10-2020; ISED: ANSI C63.10- 2020+Cor.1-2023+C63.10a- 2024 FCC Part 15.247(d) RSS-247 Clause 5.5 Pass Radiated Band edge and Spurious Emission FCC: ANSI C63.10-2020; ISED: ANSI C63.10- 2020+Cor.1-2023+C63.10a- 2024 FCC Part 15.247 (d) FCC Part 15.205/15.209 RSS-247 Clause 5.5 RSS-GEN Clause 8.9 Pass Duty Cycle FCC: ANSI C63.10-2020; ISED: ANSI C63.10- 2020+Cor.1-2023+C63.10a- 2024 None; for reporting purposes only. Pass *This test report is only published to and used by the applicant, and it is not for evidence purpose in China. *The measurement result for the sample received is <Pass> according to <CFR 47 FCC PART 15 SUBPART C, ISED RSS-247 ISSUE 3 (DTS)> when <Accuracy Method> decision rule is applied. REPORT NO.: E04A25100217F00104 Page 4 of 43 TRF No.: 04-E001-0B Global Testing , Great Quality. CONTENTS 1. ATTESTATION OF TEST RESULTS ..................................................................................... 5 2. TEST METHODOLOGY ......................................................................................................... 6 3. FACILITIES AND ACCREDITATION ..................................................................................... 6 4. CALIBRATION AN…
