2BNP4-E200Smart watch

HOW TO INSTALL APP Scan the following QR code or downloads the "G Band " in application markets to install the paired APP. Demands on Device: IOS 9.0 or above; Android 5.0 or above. Scan QR code for download and installation "G Band" CONNECT WITH DEVICE Open the APP click "Device" "Add Device" "Select Device"，click the corresponding model, and follow the prompts to connect (see the operation Demands on Device: IOS 9.0 or above; Android 5.0 or above. （SKETCH MAP） Wireless connection:After successful pairing, APP will automatically save watch Wireless address. When APP is opened or operated in the background,it will automatically search and connect the watch. Data synchronization: Manually drop APP main page down to synchronize data; the watch can save offline date of 7 days. The date is more, the synchronization time will be longer. lt wiwill take no more than 2 seconds to synchronize data. After synchronization, "synchronization finish" will be popped up. -2- PRECAUTIONS Please prevent your watch from being shocked, or exposed under high temperature or blazing sun for a long time. Please don't disassemble, repair or change the device. The device should adopt current 0.5A to charge, it is forbidden to charge with over-voltage power supply. It should be used within the temperature of 0 degrees - 45 degrees. lt is forbidden to throw into fire, avoiding explosion. Please charge after drying the band with soft cloth, otherwise, it will corrode charging touch points, leading to charge fault. Please keep away from chemical substance such as gasoline, cleaning solvent, propanol, alcohol or insect repellent. Please don't use the product in high voltage and high magnetic environment. in case of sensitive dry skin or too- tight wearing, you may be uncomfortable. Please don't take a hot bath by wearing it. Please dry sweat in your wrist timely for its possibility to lead to skin itch or allergy by long-time touch with soap, sweat, allergens or contaminated ingredients.in case of frequent use, it is suggested to clean weekly. Please wipe with a damp cloth, and remove oil or dust by mild soap. Do not open more push without special requirements. COMMON PROBLEM How to do when it cannot connect with Wireless? (low speed/ failed to connect or reconnect) Please confirm whether your device is lOS9.0, Android 5.0 or above. lt takes time differently for each connection caused by the signal interference of wireless connection. lf it fails to connect for a long time，please confirm that you use it in environment without magnetic field or interference of multiple Wireless device . Turn on again after turning off the Wireless. Turn off the background applications of mobile phones or restart your mobile phones. Please don't make your mobile phones connect with other Wireless device or functions at the same time. Please check whether the APP is operated normally in the background. Otherwise, it may fail to connect. -3- Information to User This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Important Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. The uses of equipment generates and radiates radio frequency energy, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. -1- EN（英语） INSTRUCTION FOR QUICK USE ON/OFF 1.When the watch is off, charge it or press and hold for 3 seconds. The bracelet vibrates to turn on: 2.Change to shutdown interface in start-up state, and have a long press on shutdown interface for 3 seconds to power off. BAND OPERATION 1.Slide to light up screen or change display in start-up state; 2. No operation default five-second screen, users can connect to the mobile APP to modify the screen time: CÓMO INSTALAR LA APLICACIÓN Escanee el siguiente código QR o descargue "G Band" en las tiendas de aplicaciones para instalar la aplicación empare jada. Requisitos del dispositivo: IOS 9.0 o superior; Android 5.0 o superior. Escanee el código QR para descargar e instalar "G Band" CONECTAR CON EL DISPOSITIVO Abra la aplicación, haga clic en "Dispositivo", "Agregar dispositivo", "Seleccionar dispositivo", haga clic en el modelo correspondiente y siga las indicaciones para conectar (ver Requisitos del dispositivo: IOS 9.0 o superior; Android 5.0 o superior. ). （ESQUEMA） Conexión Inalámbrico: después de un emparejamiento exitoso, la aplicación guardará automáticamente la dirección Inalámbrico del reloj. Cuando la aplicación esté abierta o ejecutándose en segundo plano, buscará y se conectará automáticamente al reloj. Sincronización de datos: arrastre manualmente hacia abajo la página principal de la aplicación para sincronizar …

Text truncated - open the document above for the full version.

Shenzhen Changtai Electronics Co.,Ltd 4/F, Building 17, Huafeng Manufacturing Zone,Wanle Road, Shajing, Baoan, Shenzhen, China Attestation Statements Not Covered Entity Applicant & Not Covered Equipment To: Federal Communications Commission Date: Feb. 25, 26 7435 Oakland Mills Road, Columbia, MD 21046, USA Ref: Information Required by Section 2.911(d)(5)(i) & (ii) FCC ID: 2BNP4-E200 Shenzhen Changtai Electronics Co.,Ltd(“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List, established pursuant to § 1.50002 of reference chapter, as an entity producing “covered” communication equipment. The equipment for which authorization is sought is not “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List that prohibited from receiving an equipment authorization pursuant to section § 2.903 of the FCC rules. Sincerely yours, Applicant Signature Printed Name: Wendy Feng Title: Sales Manager Address: 4/F, Building 17, Huafeng Manufacturing Zone,Wanle Road, Shajing, Baoan, Shenzhen, China Tel.: 13510847281 Email: [email protected]

1 | P a g e Shenzhen Changtai Electronics Co.,Ltd 4/F, Building 17, Huafeng Manufacturing Zone,Wanle Road, Shajing, Baoan, Shenzhen, China Attestation Statements To: Federal Communications Commission Date: Feb. 25, 26 7435 Oakland Mills Road, Columbia, MD 21046, USA Subject: Attestation of Compliance with FCC Covered List Software Requirements FCC ID: [2BNP4-E200] Product Name: [Smart watch] This letter serves as an attestation that the equipment identified above ☐ is / ☒ is not (select one) "covered" software as defined under the Federal Communications Commission (FCC) Covered List requirements, as outlined in FCC 22-84 and KDB 986446. Specifically, the undersigned certifies that the equipment for which authorization is sought: 1. Does not contain cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors, assignees, parents, subsidiaries, affiliates, or any entity that has rebranded or relabeled software produced by the aforementioned entities. 2. Does not have the capability to store, run, or deliver any software identified on the FCC Covered List, including but not limited to cybersecurity and anti-virus software. To support this attestation, the appendix evaluation documentation has been prepared and is included in the certification filing. This attestation is based on a thorough evaluation of the device's design, functionality, and software environment. The undersigned affirms that the information provided is accurate and complete to the best of their knowledge. Sincerely yours, Applicant Signature Printed Name: Wendy Feng Title: Sales Manager Address: 4/F, Building 17, Huafeng Manufacturing Zone,Wanle Road, Shajing, Baoan, Shenzhen, China Tel.: 13510847281 Email: [email protected] 2 | P a g e Evaluation regarding to the Covered List Software: Compliance Methodology Evaluation Process Results Device is Inherent compliance ☒ The Chipset(s) used is limited to run the Cybersecurity or anti-virus software. The MCU “ JL7013A“, The RF chip “ JL7013A“ don’t support the mentioned function. ☐ The Memory used is limited to run the Cybersecurity or anti-virus software. The memory size is XXX, so don’t support the mentioned function. ☐ There is storage capacity limitation for store or install the Cybersecurity or anti-virus software. The storage capacity is XXX, so don’t support the mentioned function. ☐ Operating system used is limited to run, install or deliver the Cybersecurity or anti-virus software. The Operating system “XXX“ don’t support the mentioned function. Device is not Inherent compliance ☐ Evaluation Based on Software Bill of Materials (SBoM) See attached “SBoM“ Note:The SBoM content is limited to the scope of covered list software (e.g. antivirus and cybersecurity software). ☐ Evaluation Based on Scan for Software on the device ☐ Evaluation Based on Filesystem scan ☐ Evaluation Based on Running software check

Shenzhen Changtai Electronics Co.,Ltd 4/F, Building 17, Huafeng Manufacturing Zone,Wanle Road, Shajing, Baoan, Shenzhen, China U.S. Agent Letter of Attestation To: Federal Communications Commission 7435 Oakland Mills Road, Columbia, MD 21046, USA Date: Feb. 25, 26 Ref: Attestation Statement – Part 2.911(d)(7) filing FCC ID: 2BNP4-E200 Shenzhen Changtai Electronics Co.,Ltd (“the applicant”) certifies that, as of the date of the filing of the application, [Herland International Trading Inc] (“the agent”) is our designated U.S. agent for service of process for the above reference FCC ID. The applicant accepts to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. The applicant further acknowledges it is our responsibility to inform the FCC whenever the agent information changes. [Herland International Trading Inc] ("the agent) understand it is the agent's obligation to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address. Designated U.S. Agent Company Name: Herland International Trading Inc FRN: 0036324101 Address: 1370 Valley Vista Dr Ste 200 Diamond Bar, CA 91765 Signature: Contact Person: Jianfeng Gao Tel: 001-909-772-1888 Email: jianfenggao@hyunturlee- commerce.com Applicant Company Name: Shenzhen Changtai Electronics Co.,Ltd FRN: 0036660769 Address: 4/F, Building 17, Huafeng Manufacturing Zone,Wanle Road, Shajing, Baoan, Shenzhen, China Signature: Contact Person: Wendy Feng Tel: 13510847281 Email: [email protected]

Shenzhen Changtai Electronics Co.,Ltd 4/F, Building 17, Huafeng Manufacturing Zone,Wanle Road, Shajing, Baoan, Shenzhen, China Date: Feb. 25, 26 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request for: FCC ID: 2BNP4-E200 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request permanent confidential treatment of the exhibits accompanying this certification application as outlined below : ⎯ Block Diagram ⎯ Schematics ⎯ Operational Description The above exhibits contain trade secrets and/or proprietary information that are not publicly available and materials that the Applicant has spent considerable efforts in developing. Public disclosure of these may be harmful to the Applicant and give an unfair advantage to competitors on the market. Sincerely, Applicant Signature Printed Name: Wendy Feng Title: Sales Manager Address: 4/F, Building 17, Huafeng Manufacturing Zone,Wanle Road, Shajing, Baoan, Shenzhen, China Tel.: 13510847281 Email: [email protected]

Shenzhen Changtai Electronics Co.,Ltd 4/F, Building 17, Huafeng Manufacturing Zone,Wanle Road, Shajing, Baoan, Shenzhen, China Date: Feb. 25, 26 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization for FCC ID:2BNP4-E200 I, the undersigned, hereby authorize (Shenzhen DL Testing Technology Co., Ltd.) to act on our behalf in all matters relating to this application for equipment certification. Any act carried out by (Shenzhen DL Testing Technology Co., Ltd.) shall have the same effect as our own and I acknowledge that all responsibility for complying with the terms and conditions of certification, as specified by DERYCOM CERTIFICATION SERVICES, INC., still resides with (Shenzhen Changtai Electronics Co.,Ltd). We certify that we are not subject to a denial of federal benefits that includes FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862, and that no party to the application, as defined in 47 CFR §1.2002(b), is subject to a denial of federal benefits that includes FCC benefits pursuant to that section. Sincerely, Applicant Signature Printed Name: Wendy Feng Title: Sales Manager Address: 4/F, Building 17, Huafeng Manufacturing Zone,Wanle Road, Shajing, Baoan, Shenzhen, China Tel.: 13510847281 Email: [email protected]

Shenzhen DL Testing Technology Co., Ltd. FCC ID: 2BNP4-E200 EUT PHOTO(External Photos) Shenzhen DL Testing Technology Co., Ltd. FCC ID: 2BNP4-E200 Shenzhen DL Testing Technology Co., Ltd. FCC ID: 2BNP4-E200 Shenzhen DL Testing Technology Co., Ltd. FCC ID: 2BNP4-E200 Shenzhen DL Testing Technology Co., Ltd. FCC ID: 2BNP4-E200 Shenzhen DL Testing Technology Co., Ltd. FCC ID: 2BNP4-E200 Shenzhen DL Testing Technology Co., Ltd. FCC ID: 2BNP4-E200 Shenzhen DL Testing Technology Co., Ltd. FCC ID: 2BNP4-E200 Shenzhen DL Testing Technology Co., Ltd. FCC ID: 2BNP4-E200 Shenzhen DL Testing Technology Co., Ltd. FCC ID: 2BNP4-E200 ※※※※※ END OF REPORT ※※※※※

Size: 12*6mm Model: E200 FCC ID: 2BNP4-E200 Label location

Shenzhen DL Testing Technology Co., Ltd. FCC ID: 2BNP4-E200 EUT PHOTO(Internal Photos) ANT Shenzhen DL Testing Technology Co., Ltd. FCC ID: 2BNP4-E200 Shenzhen DL Testing Technology Co., Ltd. FCC ID: 2BNP4-E200 ※※※※※ END OF REPORT ※※※※※

FCC ID: 2BNP4-E200 RF Exposure Evaluation According to KDB 447498 D01 V06 and part 2.1093，Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition(s), listed below, is (are) satisfied. For 100 MHz to 6 GHz and test separation distances ≤ 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: [(max. power of channel, including tune-up tolerance, Mw) / (min. test separation distance, mm)] · [√f (GHz) ] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR, where f (GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest Mw and mm before calculation The result is rounded to one decimal place for comparison EIRP=E Meas +20log(d Meas )-104.7 EIRP is the equivalent isotropically radiated power, in dBm E Meas is the field strength of the emission at the measurement distance, in dBμV/m d Meas is the measurement distance, in m Here, BT Test Mode Conducted power (dBm) Max tune-up (Mw) Frequency (MHz) Min. distance(mm) Calc. thresholds limit BLE 0.076 1.018 2440 5 0.32 3.0 So a SAR test is not required

Shenzhen Changtai Fuyuan Electronics Co., LTD 3rd Floor, Building G, No. 2070, Jincheng Road, Haoxiang Community, Shajing Street, Baoan District, Shenzhen Antenna Specification 1 PRODUCT INFORMATION 1.1Manufacturer Information ManufacturerShenzhen Changtai Fuyuan Electronics Co., LTD Address 3rd Floor, Building G, No. 2070, Jincheng Road, Haoxiang Community, Shajing Street, Baoan District, Shenzhen 1.2General Description for Equipment under Test (EUT) Model Name Under Test 2.4G BT-ANT Antenna Type Wire Antenna Dimensions90mm*10mm MAX. Gain-2.70dBi Antenna Type Wire 1.3Technical Information Frequencies2400~2500MHz Test Frequencies 2400MHz, 2410MHz, 2420MHz, 2430MHz, 2440MHz, 2450MHz 2460MHz, 2470MHz, 2480MHz, 2490MHz, 2500MHz 1.4Antenna shape Tested by:Luo YouningChecked by: Li ChenjiaApproved by:Sally Yu ShenzhenChangtaiFuyuanElectronicsCo.,LTD 3rdFloor,BuildingG,No.2070,JinchengRoad,HaoxiangCommunity,ShajingStreet,BaoanDistrict,Shenzhen VSWR Frequency VSWR 2400MHz1.57 2450MHz1.76 2500MHz1.93 ShenzhenChangtaiFuyuanElectronicsCo.,LTD 3rdFloor,BuildingG,No.2070,JinchengRoad,HaoxiangCommunity,ShajingStreet,BaoanDistrict,Shenzhen 3DPattern B1.13DPatternfor2400MHz B1.23DPatternfor2450MHz ShenzhenChangtaiFuyuanElectronicsCo.,LTD 3rdFloor,BuildingG,No.2070,JinchengRoad,HaoxiangCommunity,ShajingStreet,BaoanDistrict, Shenzhen B1.33DPatternfor2500MHz ShenzhenChangtaiFuyuanElectronicsCo.,LTD 3rdFloor,BuildingG,No.2070,JinchengRoad,HaoxiangCommunity,ShajingStreet,BaoanDistrict,Shenzhen 1DRadiationPattern PHI=0 PHI=90 ShenzhenChangtaiFuyuanElectronicsCo.,LTD 3rdFloor,BuildingG,No.2070,JinchengRoad,HaoxiangCommunity,ShajingStreet,BaoanDistrict, Shenzhen THETA=90 Frequency(MHz)Gain(dBi)Efficiency(%) 2400-2.7018 2410-2.9217 2420-3.0717 2430-3.0916 2440-3.4815 2450-3.7315 2460-3.7714 2470-3.8114 2480-3.6914 2490-3.9314 2500-4.1814

Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-260120030R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 1 of 34 FCC Part 15C Test Report FCC ID: 2BNP4-E200 Applicant: Shenzhen Changtai Electronics Co.,Ltd Address: 4/F, Building 17, Huafeng Manufacturing Zone,Wanle Road, Shajing, Baoan, Shenzhen, China Manufacturer: Shenzhen Changtai Electronics Co.,Ltd Address: 4/F, Building 17, Huafeng Manufacturing Zone,Wanle Road, Shajing, Baoan, Shenzhen, China Product Name: Smart watch Trade Mark: N/A Model Number: E200 Date of Receipt: Jan. 20, 2026 Test Date: Jan. 20, 2026 – Jan. 31, 2026 Date of Report: Jan. 31, 2026 Prepared By: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Comprehensive Building, Tongzhou Electronics Longgang Factory Area, No.1 Baolong Fifth Road, Baolong Community, Baolong Street, Longgang District, Shenzhen, China Applicable Standards: FCC PART 15 C 15.247 ANSI C63.10:2020 Test Result: Pass Report Number: DLE-260120030R Prepared (Test Engineer): Alisa Song Reviewer (Supervisor): Jack Bu Approved (Manager): Jade Yang This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-260120030R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 2 of 34 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 4 1.1 MEASUREMENT UNCERTAINTY 4 2 . GENERAL INFORMATION 5 2.1 GENERAL DESCRIPTION OF EUT 5 2.2 DESCRIPTION OF TEST MODES 6 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 6 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 7 2.5 TABLE OF PARAMETERS OF TEST SOFTWARE SETTING 7 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 8 3 . EMC EMISSION TEST 9 3.1 CONDUCTED EMISSION MEASUREMENT 9 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 9 3.1.2 TEST PROCEDURE 9 3.1.3 DEVIATION FROM TEST STANDARD 9 3.1.4 TEST SETUP 10 3.1.5 EUT OPERATING CONDITIONS 10 3.1.6 TEST RESULTS 11 3.2 RADIATED EMISSION MEASUREMENT 13 3.2.1 RADIATED EMISSION LIMITS 13 3.2.2 TEST PROCEDURE 14 3.2.3 DEVIATION FROM TEST STANDARD 14 3.2.4 TEST SETUP 14 3.2.5 EUT OPERATING CONDITIONS 15 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 16 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 17 3.2.8 TEST RESULTS (1GHZ~25GHZ) 19 3.3 RADIATED BAND EMISSION MEASUREMENT 20 3.3.1 TEST REQUIREMENT: 20 3.3.2 TEST PROCEDURE 20 3.3.3 DEVIATION FROM TEST STANDARD 20 3.3.4 TEST SETUP 21 3.3.5 EUT OPERATING CONDITIONS 21 3.4 CONDUCTED BAND EDGE EMISSION&CONDUCTED SPURIOUS EMISSIONS MEASUREMENT 23 3.4.1 APPLICABLE STANDARD 23 3.4.2 TEST PROCEDURE 23 Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-260120030R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 3 of 34 Table of Contents Page 3.4.3 DEVIATION FROM STANDARD 23 3.4.4 TEST SETUP 23 3.4.5 EUT OPERATION CONDITIONS 24 3.4.6 TEST RESULTS 24 4 . PEAK OUTPUT POWER 27 4.1 APPLIED PROCEDURES / LIMIT 27 4.1.1 TEST PROCEDURE 27 4.1.2 DEVIATION FROM STANDARD 27 4.1.3 TEST SETUP 27 4.1.4 EUT OPERATION CONDITIONS 27 4.1.5 TEST RESULTS 28 5 . POWER SPECTRAL DENSITY TEST 30 5.1 APPLIED PROCEDURES / LIMIT 30 5.1.1 TEST PROCEDURE 30 5.1.2 DEVIATION FROM STANDARD 30 5.1.3 TEST SETUP 30 5.1.4 EUT OPERATION CONDITIONS 30 5.1.5 TEST RESULTS 30 6 . 6DB BANDWIDTH TEST 32 6.1 APPLIED PROCEDURES / LIMIT 32 6.1.1 TEST PROCEDURE 32 6.1.2 DEVIATION FROM STANDARD 32 6.1.3 TEST SETUP 32 6.1.4 EUT OPERATION CONDITIONS 32 6.1.5 TEST RESULTS 32 7 . ANTENNA REQUIREMENT 34 7.1 STANDARD REQUIREMENT 34 7.2 EUT ANTENNA 34 8 . TEST SETUP PHOTO 34 9 . EUT PHOTO 34 Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-260120030R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 4 of 34 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247(c) Radiated Spurious Emission PASS 15.205 Band Edge Emission PASS 15.247(b) Peak Output Power PASS 15.247(a)(2) 6dB Bandwidth PASS 15.247(e) Power Spectral Density PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Test lab: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Comprehensive Building, Tongzhou Electronics Longgang Factory Area, No.1 Baolong Fifth Road, Baolong Community, Baolong Street, Longgang District, Shenzhen, China FCC Test Firm Registration Number: 854456 Designation Number: CN1307 IC Registered No.: 27485 CAB ID.: CN0118 1.1 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±2.56dB 2 RF power,conducted ±0.42dB 3 Spurious emissions,conducted ±2.76dB 4 All emissions,radiated(<1G) ±3.65dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% 8 6dB Bandwidth ±0.2MHz 9 Power Spectral Density ±0.3dBm Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-260120030R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 5 of 34 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Product Name: Smart watch Trade Mark: N/A Model Number: E200 Test Model: E200 Model Difference: N/A Operation Frequency: 2402~2480MHz Channel numbers: 40 Channels Data Rate: 1Mbps Channel separation: 2MHz Modulation technology: GFSK Antenna Type: Internal Antenna Antenna gain: -2.7dBi Power supply: Input: DC 5V Battery: DC 3.8V Note: 1.For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. 2.The EUT’s all information provided by client. 3. Channel Lis Channel List Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequ…

Text truncated - open the document above for the full version.

Shenzhen DL Testing Technology Co., Ltd. FCC ID: 2BNP4-E200 EUT TEST PHOTO Radiated Measurement Photos Shenzhen DL Testing Technology Co., Ltd. FCC ID: 2BNP4-E200 Conducted Measurement Photos ※※※※※ END OF REPORT ※※※※※
