2BQG6-B100Bluetooth Beacon

User Manual Document Version: V1.0 Manufacturer: QUZHOU SANMAX HARDWARE TECHNOLOGY CO., LTD. FCC ID: 2BQG6-B100 1. Product Overview The Model B100 is a 2.4GHz ISM band Bluetooth Low Energy (BLE) broadcasting beacon. It is widely applied in indoor positioning, asset tracking, personnel management, and proximity sensing scenarios. This device is powered by two ER18505 3.6V lithium thionyl chloride primary batteries connected in parallel. The non-rechargeable battery solution provides ultra-long service life, low self-discharge rate, and stable power supply in wide temperature environments. 2. Basic Technical Specifications Item Specification Model Number B100 Wireless Protocol Bluetooth Low Energy (BLE) Operating Frequency Band 2402 MHz ~ 2480 MHz (2.4 GHz ISM Band) Power Supply Two ER18505 Li-SOCl₂ batteries, parallel connection, 3.6V nominal voltage Item Specification Battery Type Non-rechargeable primary lithium battery, NO recharge allowed Operating Temperature Range -40°C ~ +85°C Storage Temperature Range -55°C ~ +85°C Installation Method Wall-mounted, fixed by side mounting holes Certification Compliance FCC Part 15.247 3. Safety Instructions 3.1 Battery Safety Warnings 1. The ER18505 batteries inside the device are non-rechargeable primary lithium batteries. DO NOT attempt to recharge, heat, crush, puncture, disassemble or solder the batteries. Recharging will cause fire, explosion, battery leakage and permanent damage. 2. Do not short-circuit the positive and negative electrodes of the battery. 3. Do not mix use new batteries and old batteries, do not mix batteries of different types. When replacing batteries, replace the two parallel batteries at the same time. 4. Keep the device and batteries away from open flame, high temperature environment and direct sunlight exposure. 5. Battery disposal: Please dispose of waste batteries in accordance with local environmental protection regulations. Do not discard batteries into domestic garbage, do not incinerate batteries. 6. Prevent children from touching and swallowing the batteries. 3.2 General Operation Safety 1. Install the device in a well-ventilated dry environment. Avoid long-term soaking in water, heavy dust and corrosive gas environment. 2. Do not make unauthorized disassembly, modification and transformation of the internal circuit of the device. 3. Do not knock, drop or violently vibrate the device. 4. FCC Compliance Statements (Mandatory FCC Warning Clauses) This device complies with Part 15 Subpart C of the FCC Rules. 4.1 FCC Operation Conditions Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. 4.2 FCC Caution Statement CAUTION: Any changes or modifications to this device not expressly approved by the party responsible for FCC compliance will void the user's authority to operate this equipment. 4.3 FCC Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy. If not installed and used in accordance with the instructions, it may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception (which can be determined by turning the equipment off and on), the user is encouraged to try to correct the interference by one or more of the following measures:  Reorient or relocate the receiving antenna.  Increase the separation distance between the equipment and the receiver.  Connect the equipment to a circuit different from that to which the receiver is connected. 4.4 FCC RF Exposure Statement This portable BLE beacon device complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. The internal antenna of the device is integrated inside the housing, and normal operation of the device will not exceed the FCC RF exposure requirement. 4.5 FCC ID Label Information The permanent FCC ID label of this product is marked on the rear outer surface of the device, inside the central recessed area of the housing. The label content is permanently engraved by laser marking process: FCC ID: 2BQG6-B100 The laser-engraved label is durable, wear-resistant, non-falling, clearly visible without disassembly, and fully meets the FCC permanent marking requirements. 5. Installation & Use Instructions 1. Mounting Installation: Use the reserved mounting holes on both sides of the housing to fix the device on the wall or target surface with screws. 2. After installation, ensure the rear FCC ID label is completely exposed, without being blocked by wall, bracket or other obstacles. 3. The device will automatically broadcast BLE signal after power on. Users can configure broadcast parameters (UUID, major/minor, broadcast interval, transmit power) through the matching BLE configuration mobile APP. 4. No manual operation is required after normal power-on installation, the device works continuously with battery power supply. 6. Maintenance & Troubleshooting 1. Daily maintenance: Wipe the device shell with dry soft cloth. Do not use corrosive chemical cleaners. 2. No signal broadcast: Check whether the battery is exhausted, replace two new ER18505 batteries at the same time. 3. Weak wireless signal: Check battery remaining power, check whether the installation position is blocked by metal obstacles. 4. Battery abnormal leakage: Immediately stop using the device, properly dispose of the waste battery, clean the battery compartment before installing new batteries. 7. Warranty Note The manufacturer warrants that the produ…

Text truncated - open the document above for the full version.

QUZHOUSANMAXHARDWARETECHNOLOGYCO.,LTD CoveredEquipmentCertificationAttestationLetter 4/23/2026 NemkoNorthAmerica,Inc. 303RiverRoad Ottawa K1V1H2 Canada ATTN.:ReviewingEngineer FCCID:2BQG6-B100 QUZHOUSANMAXHARDWARETECHNOLOGYCO.,LTD(“theapplicant”)certifies thattheequipmentforwhichauthorizationissoughtisnot“covered”equipment prohibitedfromreceivinganequipmentauthorizationpursuanttosection2.903ofthe FCCrules. Note:Iftheequipmentforwhichtheapplicantseeksauthorizationisproducedby anyoftheentitiesidentifiedonthecurrentCoveredList,theapplicantshould includeanexplanationonwhytheequipmentisnot“covered”equipment. QUZHOUSANMAXHARDWARETECHNOLOGYCO.,LTD(“theapplicant”)certifies that,asofthedateofthefilingoftheapplication,theapplicantisnotidentifiedonthe CoveredListasanentityproducing“covered”equipment. QUZHOUSANMAXHARDWARETECHNOLOGYCO.,LTD(“theapplicant”)certifies thattheequipmentforwhichauthorizationissoughtdoesnotincludecybersecurityor anti-virussoftwareproducedorprovidedbyKasperskyLab,Inc.oranyofitssuccessors andassignees,includingequipmentwithintegratedKasperskyLab,Inc.(oranyofits successorsandassignees)cybersecurityoranti-virussoftwarepursuanttoDA-24-886 andKDB986446D01CoveredEquipmentGuidancesectionB(2a). Signed: Printedname:HUANFANGLAI Title:Generalmanager CompanyName:QUZHOUSANMAXHARDWARETECHNOLOGYCO.,LTD Date:4/23/2026

QUZHOUSANMAXHARDWARETECHNOLOGYCO.,LTD ProductSimilarityDeclaration Productname:BluetoothBeacon Modelname:B100,B200,B300,T10,T20 FCCID:2BQG6-B100 We(QUZHOUSANMAXHARDWARETECHNOLOGYCO.,LTD) herebystatethatallthemodelsareelectricalidenticalincluding thesamesoftwareparameterandhardwaredesign(circuitdesign, PCBLayout,RFmodule/circuit,antennatype(s)andantenna location,componentsonPCB,etc.,),samemechanicalstructure anddesign(includingproductenclosure,materials,etc.,),Onlythe modelnameisdifferent. Signature: Printedname:HUANFANGLAI Title:Generalmanager CompanyName:QUZHOUSANMAXHARDWARETECHNOLOGYCO.,LTD Date:April23,2026

QUZHOUSANMAXHARDWARETECHNOLOGYCO.,LTD 4/23/2026 NemkoNorthAmerica,Inc. 303RiverRoad Ottawa,Ontario,Canada K1V1H2 REQUESTFORCONFIDENTIALITY-FCC FCCID:2BQG6-B100 PursuanttoSections0.457(d)(1)(ii)and0.459oftheCommission’sRulesandFCCGuidance document726920,weherebyrequestconfidentialtreatmentofinformationaccompanyingthis applicationasoutlinedbelow: PERMANENTLONG-TERMCONFIDENTIALITY: Schematics BlockDiagrams TheoryofOperation Theaboveinformationcontainstradesecretsandproprietaryinformationnotcustomarilyreleasedto thepublic.Thepublicdisclosureofthisinformationmightbeharmfultotheapplicantandprovide unjustifiedbenefitstoitscompetitors.TheApplicantunderstandsthatpursuanttoRule 0.457(d)(1)(ii),disclosureofthisApplicationandallaccompanyingmaterialswillnotbemadebefore thedateoftheGrantforthisApplication. Sincerely, Signed: Printedname:HUANFANGLAI Title:Generalmanager

FCCID:2BQG6-B100 FCCID:2BQG6-B100 FCCID:2BQG6-B100 FCCID:2BQG6-B100

LabelandLabelLocation FCCID:2BQG6-B100

FCCID:2BQG6-B100 FCCID:2BQG6-B100 FCCID:2BQG6-B100 FCCID:2BQG6-B100 FCCID:2BQG6-B100 FCCID:2BQG6-B100 FCCID:2BQG6-B100 FCCID:2BQG6-B100

Page1of2 RFEXPOSUREEVALUATION FCCID:2BQG6-B100 ProductName: BluetoothBeacon ModelName: B100,B200,B300,T10,T20 BluetoothVersion:BLE Operatingfrequency:2402-2480MHz NumbersofChannel:40channelsforDTS AntennaType:FPCantenna AntennaGain:2.52dBi TypeofModulation:GFSK Powersupply: Input:DC5V Battery: Li-ionBattery:ER18505 RatedVoltage:3.6V HardwareVersion:N/A SoftwareVersion:N/A Page2of2 StandardRequirement Accordingto§15.247(i)and§1.1307b(1),systemsoperatingundertheprovisionsofthis sectionshallbeoperatedinamannerthatensuresthatthepublicisnotexposedtoradio frequencyenergylevelsinexcessoftheCommission’sguidelines.SeeKDB447498D01 GeneralRFExposureGuidancev06,section4.3.1. The1-gand10-gSARtestexclusionthresholdsfor100MHzto6GHzattestseparation distances≤50mmaredeterminedby: [(max.powerofchannel,includingtune-uptolerance,mW)/(min.testseparationdistance, mm)]*[√f(GHz)]≤3.0for1-gSARand≤7.5for10-gSARextremitySAR,where f(GHz)istheRFchanneltransmitfrequencyinGHz PoweranddistanceareroundedtothenearestmWandmmbeforecalculation Theresultisroundedtoonedecimalplaceforcomparison. Thetestexclusionsareapplicableonlywhentheminimumtestseparationdistanceis≤ 50mmandfortransmissionfrequenciesbetween100MHzand6GHz.Whentheminimumtest separationdistanceis<5mm,adistanceof5mmisappliedtodetermineSARtestexclusion. RoutineSARevaluationreferstothatspecificallyrequiredby§2.1093,usingmeasurements orcomputersimulation.WhenroutineSARevaluationisnotrequired,portabletransmitters withoutputpowergreaterthantheapplicablelowthresholdrequireSARevaluationtoquality forTCBapproval. Channel (MHz) Maximum output power (dBm) Tuneup tolerance (dBm) MaxTune UpPower (mW) Distance (mm) Calculation results Limit Operating Mode 2480 2.332.33±1 2.15278250.6780413BLE_1M AccordingtoKDB447498,ThedeviceonlysupportBTfunction,andnosimultaneousSAR measurementisrequired. Signature SimonPu Manager Date:2026-04-01

TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN2400-FPC295BX ProductName:Antenna Page1 SpecificationForApproval Date:2024.10.31 Version:1.0 客户名称 Customer： 客户料号 CustomerP/N： 腾祥料号 TXP/N：AN2400-FPC295BX 规格描述 Description:2.4GFPC天线1.13mm黑色线L=70mm+IPEX TengxiangCheckedBy: 腾祥审核 CustomerApprovedBy: 客户审核 DRAWN 制作 路婷 TESTEDBY 检测 CHECKEDBY 审核 胡超 CHECKEDBY 审核 Q.C.DEPT. 品管 江美如 Q.C.DEPT. 品管 APPROVEDBY 核准 韦佳 APPROVEDBY 核准 NO.53ShatouShaChongRoad,ChangAnTown,Guangdongprovince,China 中国广东省东莞市长安镇沙头区沙涌路53号 TEL:86-769-81873082FAX:86-769-82663788 http://www.tenxiang.cn TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN2400-FPC295BX ProductName:Antenna Page2 Index: 1.Specification(规格) 2.CharacteristicsandReliabilityTest(产品特性和可靠性测试标准) 3.Antenna-SParameterTestData(样品测试数据) 4.Antenna-RadiationPatternTestData(辐射模式测试数据) 5.MechanicalandPackingDrawing(图纸包装规范) RevisionHistory（变更履历） RevisionDateChangeNotificationDescription 1.02024.10.31 初版 TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN2400-FPC295BX ProductName:Antenna Page3 1.Specification SamplePhoto A.ElectricalCharacteristics Frequency频率2400-2500MHz S.W.R.驻波比<=2.0 AntennaGain增益2.37dBi Polarization 极化方式Linear Impedance 阻抗50Ohm B.Material&MechanicalCharacteristics CableType线材规格OD1.13mm,Black ConnectorType连接器规格I-PEX C.Environmental StorageTemperature 存储温度 -40 ̊C~+80 ̊C OperationTemperature 工作温度 -40 ̊C~+80 ̊C TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN2400-FPC295BX ProductName:Antenna Page4 2.CharacteristicsandReliabilityTest TestItems 测试 项目 TestConditionandProcedure 测试方法 Requirements 要求Result 结果 1V.S.W.R. 电压驻波比 SetDUTonNetworkAnalyzer;makeindividual calibrationtotest设置网络分析仪参数进行测试 DirectiveDUTspecification 符合待测物规范 PASS 2Insertion Loss插入损 失 SetDUTonNetworkAnalyzer;makeindividual calibrationtotest设置网络分析仪参数进行测试 DirectiveDUTspecification 符合待测物规范 PASS 3Antenna Gain 天线增益 SetDUTonAntennaChamber;makeindividual calibrationtotest设置天线暗室参数进行测试 DirectiveDUTspecification 符合待测物规范 PASS 4Solderability 可焊性 GB/T2423.28-2005 Temp:260±5°C;Duration:5seconds温度260± 5°C;持续5秒 Tinevenlyonfull 上锡均匀饱满 PASS 5PullTest 拉力 Holdingwithindividualspecification;force appliedtoaxisofterminal.单独定义产品端子拉力 1.DirectiveDUTspecification 2.FrequencyTol.≤5% 符合待测物规范;频率偏移≤5% PASS 6Dimension 尺寸 Inspectionofdimension,color,material,package, surfaceprocess.检查尺寸,颜色,材料,包装,表面处理 DirectiveDUTspecification 符合待测物规范 PASS 7 SaltSpray盐 雾 GB/T2423.17-2008 Temp:35°C;RH:≥95%;NaClsolution:≥ 5%;Time:24H 温度35°C；湿度≥95%;盐水浓度≥5%；测试24H 1.NoVisualDamage 2.FrequencyTol.≤5% 无明显外观不良;频率偏移≤5% PASS 8RoHSWithReferencetoIEC62321:2008withflowchart 参考IEC62321测试流程 DirectiveRoHS2015/863/EU 符合RoHS2015/863/EU标准 PASS TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN2400-FPC295BX ProductName:Antenna Page5 3.Antenna-SParameterTestData 4.Antenna-RadiationPatternTestData TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN2400-FPC295BX ProductName:Antenna Page6 XZYZXY 2400MHz 2450MHz 2500MHz 5.MechanicalDrawingSeeattachedfiles B C D AN2400-FPC295BX / Antenna 1/1 ±0.5±0.2±1 OD1.13mm Part Number Name CB-113BS Coaxial Cable 1 No. 2 1 1 Q'ty 1 Material Finish B SYY 2024.10.31 DES BY Note: 1.Mark is important dimension;"Cpk "Identify for process control(CpK 1.33). 2.Tolerance:Unmarked tolerance refer to the standard tolerance please. 3.Pay attention to the direction of the connector. APPROVER DATE SIGN DESCRIPTION SCALE: APP BY Tolerance X.XX X.X X° TITLE: PART NO.: CUSTOMER P/N: CHK BY RF BY UNITS: mm REVISION: HFREACHRoHS2.0 CONFIDENTIAL AN2400-FPC400100-B FPC Black CR-113-ZP-A 3 Cu I-PEX Au Plated Black 1 2 20231125 明确防护胶水的颜色和规格 SYY 3 WJ 2024.10.31 HC 2024.10.31 YCX 2024.10.31 100pcs/ PE bag Revision : A Customer : ALL APPROVED BY CHECKED BY DESIGNED BY Name: Page: 1 of 1 Date: Part Number : 产品包装规范 PACKING CRITERION 8000pcs/Carton 3. SEALING 。 MEAS G W: KGS N W: KGS QTY: PCS ITEM NO: C/NO MADE IN CHINA SIDE FRONT 2.PACKING 1 . Enter PE bag。 2024.10.31 AN2400-FPC295BX Antenna

Page1of71 FCCTESTREPORT FCCID:2BQG6-B100 Product: BluetoothBeacon ModelName: B100,B200,B300,T10,T20 Brand: N/A ReportNo.: PTC26022506001E-FC01 Preparedfor QUZHOUSANMAXHARDWARETECHNOLOGYCO.,LTD Room36,No.2JuhaiRd.,QujiangDistrict,QuzhouCity,ZhejiangProvince,China Preparedby PreciseTesting&CertificationCo.,Ltd Building1,No.6,TongxinRoad,DongchengStreet,Dongguan,Guangdong,China ReportNo.:PTC26022506001E-FC01 Page2of71 1TESTRESULTCERTIFICATION Applicant’sname: QUZHOUSANMAXHARDWARETECHNOLOGYCO.,LTD Address: Room36,No.2JuhaiRd.,QujiangDistrict,QuzhouCity,Zhejiang Province,China Manufacture'sname: QUZHOUSANMAXHARDWARETECHNOLOGYCO.,LTD Address: Room36,No.2JuhaiRd.,QujiangDistrict,QuzhouCity,Zhejiang Province,China Productname: BluetoothBeacon Modelname: B100,B200,B300,T10,T20 Standards:FCCCFR47Part15Section15.247 Testprocedure:ANSIC63.10-2020 TestDate: Mar.07,2026toApr.01,2026 DateofIssue: Apr.01,2026 TestResult:Pass ThisdevicedescribedabovehasbeentestedbyPTC,andthetestresultsshowthatthe equipmentundertest(EUT)isincompliancewiththeFCCrequirements.Anditisapplicableonlyto thetestedsampleidentifiedinthereport. Thisreportshallnotbereproducedexceptinfull,withoutthewrittenapprovalofPTC,thisdocument maybealteredorrevisedbyPTC,personalonly,andshallbenotedintherevisionofthedocument. TestEngineer: Jackzhou/Engineer TechnicalManager: SimonPu/Manager ReportNo.:PTC26022506001E-FC01 Page3of71 Contents Page 1TESTRESULTCERTIFICATION...............................................................................................................................2 2TESTSUMMARY..........................................................................................................................................................5 2.1TESTSITE............................................................................................................................................................6 3GENERALINFORMATION.......................................................................................................................................7 3.1GENERALDESCRIPTIONOFE.U.T.....................................................................................................................7 3.2CHANNELLIST.....................................................................................................................................................8 4EQUIPMENTDURINGTEST....................................................................................................................................9 4.1EQUIPMENTSLIST.............................................................................................................................................9 4.2MEASUREMENTUNCERTAINTY.........................................................................................................................11 4.3DESCRIPTIONOFSUPPORTUNITS...................................................................................................................12 5CONDUCTEDEMISSION..........................................................................................................................................13 5.1E.U.T.OPERATION............................................................................................................................................13 5.2EUTSETUP.......................................................................................................................................................13 5.3TESTSET-UP(BLOCKDIAGRAMOFCONFIGURATION).................................................................................14 5.4MEASUREMENTPROCEDURE............................................................................................................................14 5.5CONDUCTEDEMISSIONLIMIT...........................................................................................................................14 5.6MEASUREMENTDESCRIPTION..........................................................................................................................14 5.7CONDUCTEDEMISSIONTESTRESULT.............................................................................................................14 6RADIATEDSPURIOUSEMISSIONS......................................................................................................................17 6.1EUTOPERATION...............................................................................................................................................17 6.2TESTSETUP......................................................................................................................................................18 6.3SPECTRUMANALYZERSETUP..........................................................................................................................19 6.4TESTPROCEDURE.............................................................................................................................................20 6.5SUMMARYOFTESTRESULTS...........................................................................................................................22 7CONDUCTBANDEDGEANDSPURIOUSEMISSIONSMEASUREMENT....................................................30 7.1TESTPROCEDURE.............................................................................................................................................30 7.2TESTSETUP......................................................................................................................................................31 7.3TESTRESULT....................................................................................................................................................32 ReportNo.:PTC26022506001E-FC01 Page4of71 86DBBANDWIDTHMEASUREMENT......................................................................................................................45 TESTPROCEDURE....................................................................................................…

Text truncated - open the document above for the full version.

ReportNo.:PTC26022506001E-FC01 Page49of71 9MaximumPeakOutputPower TestRequirement:FCCCFR47Part15Section15.247 TestMethod:ANSIC63.10-2020 TestLimit: Regulation15.247(b)(3),Forsystemsusingdigitalmodulationinthe 902-928MHz,2400-2483.5MHz,and5725-5850MHzbands:1Watt.As analternativetoapeakpowermeasurement,compliancewiththeone Wattlimitcanbebasedonameasurementofthemaximumconducted outputpower. 9.1TestProcedure 1.TheRFoutputofEUTwasconnectedtothespectrumanalyzerbyRFcableandattenuator.The pathlosswascompensatedtotheresultsforeachmeasurement. 2.SettothemaximumpowersettingandenabletheEUTtransmitcontinuously. 3.Measuretheconductedoutputpowerandrecordtheresultsinthetestreport. 4.Thesignalanalyzerresolutionbandwidthwassetto2MHzandvideobandwidthof10MHz,Apeak detectorwasused,sweeptimewassettoautoandtracemodewasMaxHold.Thespanwassetto 10MHz.Amarkerwasplacedatthepeakofthesignalandtheresultsrecordedinthetablesbelow. 9.2TestSetup 9.3TestResult TestModeAntennaFrequency[MHz] ConductedPeak Power[dBm] Conducted Limit[dBm] Verdict BLE_1MAnt124020.55≤30PASS BLE_1MAnt124400.99≤30PASS BLE_1MAnt124802.33≤30PASS BLE_2MAnt124020.09≤30PASS BLE_2MAnt124400.97≤30PASS BLE_2MAnt124802.05≤30PASS ReportNo.:PTC26022506001E-FC01 Page50of71 TestGraphs: BLE_1M-Ant1-2402-PASS BLE_1M-Ant1-2440-PASS BLE_1M-Ant1-2480-PASS ReportNo.:PTC26022506001E-FC01 Page51of71 BLE_2M-Ant1-2402-PASS BLE_2M-Ant1-2440-PASS ReportNo.:PTC26022506001E-FC01 Page52of71 BLE_2M-Ant1-2480-PASS ReportNo.:PTC26022506001E-FC01 Page53of71 10PowerSpectraldensity TestRequirement:FCCCFR47Part15Section15.247 TestMethod:ANSIC63.10-2020 TestLimit:Regulation15.247(f)Thepowerspectraldensityconductedfromthe intentionalradiatortotheantennaduetothedigitalmodulation operationofthehybridsystem,withthefrequencyhoppingoperation turnedoff,shallnotbegreaterthan8dBminany3kHzbandduring anytimeintervalofcontinuoustransmission. 10.1TestProcedure 1.RemovetheantennafromtheEUTandthenconnectalowRFcablefromtheantennaporttothe spectrum. 2.Setthespectrumanalyzer:RBW=3kHz.VBW=10kHz,Span=1.5timestheDTSchannelbandwidth(6 dBbandwidth).Sweep=auto;DetectorFunction=Peak.Trace=Maxhold. 3.Allowthetracetostabilize.Usethemarker-deltafunctiontodeterminetheseparationbetweenthepeaksof theadjacentchannels.ThelimitisspecifiedinoneofthesubparagraphsofthisSectionSubmitthisplot. 10.2TestSetup 10.3TestResult TestModeAntennaFrequency[MHz]Result[dBm/3kHz]Limit[dBm/3kHz]Verdict BLE_1MAnt12402-15.42≤8.00PASS BLE_1MAnt12440-13.16≤8.00PASS BLE_1MAnt12480-13.48≤8.00PASS BLE_2MAnt12402-18.48≤8.00PASS BLE_2MAnt12440-16.34≤8.00PASS BLE_2MAnt12480-15.23≤8.00PASS ReportNo.:PTC26022506001E-FC01 Page54of71 TestGraphs: BLE_1M-Ant1-2402-PASS BLE_1M-Ant1-2440-PASS BLE_1M-Ant1-2480-PASS ReportNo.:PTC26022506001E-FC01 Page55of71 BLE_2M-Ant1-2402-PASS BLE_2M-Ant1-2440-PASS ReportNo.:PTC26022506001E-FC01 Page56of71 BLE_2M-Ant1-2480-PASS ReportNo.:PTC26022506001E-FC01 Page57of71 11AntennaApplication 11.1AntennaRequirement Forintentionaldevice,accordingtoFCC47CFRSection15.203,anintentional radiatorshallbedesignedtoensurethatnoantennaotherthanthatfurnishedbythe responsiblepartyshallbeusedwiththedevice.AndaccordingtoFCC47CFRSection 15.247(b),iftransmittingantennasofdirectionalgaingreaterthan6dBiareused,the powershallbereducedbytheamountindBthatthedirectionalgainoftheantenna exceeds6dBi. 11.2Result TheEUT’Santenna,permanentattachedantenna,isinternalFPCantenna.The antenna’sgainis2.52dBiandmeetstherequirement. ReportNo.:PTC26022506001E-FC01 Page58of71 12TestSetup ConductedEmissions RadiatedSpuriousEmissions TestFrequencyFrom30MHzto1GHz ReportNo.:PTC26022506001E-FC01 Page59of71 TestfrequencyfromAbove1GHz ReportNo.:PTC26022506001E-FC01 Page60of71 13EUTPhotos ReportNo.:PTC26022506001E-FC01 Page61of71 ReportNo.:PTC26022506001E-FC01 Page62of71 ReportNo.:PTC26022506001E-FC01 Page63of71 ReportNo.:PTC26022506001E-FC01 Page64of71 ReportNo.:PTC26022506001E-FC01 Page65of71 ReportNo.:PTC26022506001E-FC01 Page66of71 ReportNo.:PTC26022506001E-FC01 Page67of71 ReportNo.:PTC26022506001E-FC01 Page68of71 ReportNo.:PTC26022506001E-FC01 Page69of71 ReportNo.:PTC26022506001E-FC01 Page70of71 ReportNo.:PTC26022506001E-FC01 Page71of71 ******THEENDREPORT******

FCCID:2BQG6-B100 ConductedEmissions RadiatedSpuriousEmissions From30MHz-1000MHz FCCID:2BQG6-B100 TestfrequencyfromAbove1GHz
