Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
1. ProductDefinition 2.FunctionsandFeature PW-5 tracker wheel is a wireless asset monitoring sensor developed based on standard LoRaWAN protocol. The product utilizes high-precision GNSS positioning technology and low-power Bluetooth scanning positioning, enabling rapid and accurate capture of device location information in both indoor and outdoor environments. When the monitored device is used indoors, the locator automatically starts scanning Bluetooth beacons, and when the device is moved outdoors, it automatically activates GPS+BeiDou joint positioning to quickly obtain accurate positioning data,to achieve full-scenario positioning coverage.The tracker is with small size, low power consumption, and easy installation. s UsingstandardLoRaWANprotocol Full-scenariocoverage,intelligentswitchingbetweenGPS+Bluetoothdualpositioning engines Supportsscheduledorperiodicreportingmodestomeetvariousapplicationscenario positioningneeds SupportsBluetoothwirelessconfigurationofdeviceparameters Built-inhigh-capacitylithium-thionylchloridebattery 3.Product Dimensions 1 4. 技术参数 Hardware Parameters GNSSSensor Poweron/of Thepositioningaccuracyis5m,anditsupportsdual-mode positioningofGPSandBeidou fSupportphysicalbuttonsforpoweron/offcontrol GPSAntenna 1575.42MHZ,Bandwidth±2MHZ,Impedance:50ohms, Gain2dbi,RHCP LoRaAntennaBuilt-inLoRaAntenna Wireless performance parameters workingfrequency CN470\AS923\AU915\EU868\KR920\US915Multiplefrequency bandsareselectable NetworkAccess Mode OTAAorABPoptional WorkingModeCLASSA Wireless configuration SupportBluetoothwirelessconfiguration LoRaMaximum transmission power 19dbm LoRareceive sensitivity -141dBm 2 Bluetooth transmission power 0dBm Bluetooth receiving sensitivity -96dBm Electrical characteristics batterycapacity 4000mAh operating temperature -20°C~60°C operating humidity 10%~90% DC characteristics power supplymode Built-inlithium-ionbattery supplyvoltage DC3.6V dormantstate≤40uA SendingStatus150mA physical parameter levelofprotection SizeDiameter:127mmthickness:40.80mm 3 FCC Caution. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation . This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.-Consult the dealer or an experienced radio/TV technician for help. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
QUZHOUSANMAXHARDWARETECHNOLOGYCO.,LTD CoveredEquipmentCertificationAttestationLetter 1/29/2026 NemkoNorthAmerica,Inc. 303RiverRoad Ottawa K1V1H2 Canada ATTN.:ReviewingEngineer FCCID:2BQG6-PW-5 QUZHOUSANMAXHARDWARETECHNOLOGYCO.,LTD(“theapplicant”)certifies thattheequipmentforwhichauthorizationissoughtisnot“covered”equipment prohibitedfromreceivinganequipmentauthorizationpursuanttosection2.903ofthe FCCrules. Note:Iftheequipmentforwhichtheapplicantseeksauthorizationisproducedby anyoftheentitiesidentifiedonthecurrentCoveredList,theapplicantshould includeanexplanationonwhytheequipmentisnot“covered”equipment. QUZHOUSANMAXHARDWARETECHNOLOGYCO.,LTD(“theapplicant”)certifies that,asofthedateofthefilingoftheapplication,theapplicantisnotidentifiedonthe CoveredListasanentityproducing“covered”equipment. QUZHOUSANMAXHARDWARETECHNOLOGYCO.,LTD(“theapplicant”)certifies thattheequipmentforwhichauthorizationissoughtdoesnotincludecybersecurityor anti-virussoftwareproducedorprovidedbyKasperskyLab,Inc.oranyofitssuccessors andassignees,includingequipmentwithintegratedKasperskyLab,Inc.(oranyofits successorsandassignees)cybersecurityoranti-virussoftwarepursuanttoDA-24-886 andKDB986446D01CoveredEquipmentGuidancesectionB(2a). Signed: Printedname:HUANFANGLAI Title:Generalmanager CompanyName:QUZHOUSANMAXHARDWARETECHNOLOGYCO.,LTD Date:1/29/2026
QUZHOUSANMAXHARDWARETECHNOLOGYCO.,LTD ProductSimilarityDeclaration Productname:trackerwheel Modelname:PW-5,PW-5T,PW-5H,PW-4,PW-6,PW-6H,PW-4T, PW-4H FCCID:2BQG6-PW-5 We(QUZHOUSANMAXHARDWARETECHNOLOGYCO.,LTD) herebystatethatallthemodelsareelectricalidenticalincluding thesamesoftwareparameterandhardwaredesign(circuitdesign, PCBLayout,RFmodule/circuit,antennatype(s)andantenna location,componentsonPCB,etc.,),samemechanicalstructure anddesign(includingproductenclosure,materials,etc.,),Onlythe modelnameisdifferent. Signature: Printedname:HUANFANGLAI Title:Generalmanager CompanyName:QUZHOUSANMAXHARDWARETECHNOLOGYCO.,LTD Date:January29,2026
QUZHOUSANMAXHARDWARETECHNOLOGYCO.,LTD 1/29/2026 NemkoNorthAmerica,Inc. 303RiverRoad Ottawa,Ontario,Canada K1V1H2 REQUESTFORCONFIDENTIALITY-FCC FCCID:2BQG6-PW-5 PursuanttoSections0.457(d)(1)(ii)and0.459oftheCommission’sRulesandFCCGuidance document726920,weherebyrequestconfidentialtreatmentofinformationaccompanyingthis applicationasoutlinedbelow: PERMANENTLONG-TERMCONFIDENTIALITY: Schematics BlockDiagrams TheoryofOperation Theaboveinformationcontainstradesecretsandproprietaryinformationnotcustomarilyreleasedto thepublic.Thepublicdisclosureofthisinformationmightbeharmfultotheapplicantandprovide unjustifiedbenefitstoitscompetitors.TheApplicantunderstandsthatpursuanttoRule 0.457(d)(1)(ii),disclosureofthisApplicationandallaccompanyingmaterialswillnotbemadebefore thedateoftheGrantforthisApplication. Sincerely, Signed: Printedname:HUANFANGLAI Title:Generalmanager
FCCID:2BQG6-PW-5 FCCID:2BQG6-PW-5 FCCID:2BQG6-PW-5
LabelandLabelLocation
FCCID:2BQG6-PW-5 FCCID:2BQG6-PW-5 LoraANT FCCID:2BQG6-PW-5 FCCID:2BQG6-PW-5 FCCID:2BQG6-PW-5 FCCID:2BQG6-PW-5
ReportNo.:PTC25112101701E-FC03 Page1of8 FCCTESTREPORT FCCID:2BQG6-PW-5 Product: trackerwheel ModelName: PW-5,PW-5T,PW-5H,PW-4,PW-6,PW-6H,PW-4T,PW-4H Brand : N/A ReportNo.: PTC25112101701E-FC03 Preparedfor QUZHOUSANMAXHARDWARETECHNOLOGYCO.,LTD Room36,No.2JuhaiRd.,QujiangDistrict,QuzhouCity,ZhejiangProvince,China Preparedby PreciseTesting&CertificationCo.,Ltd. Building1,No.6,TongxinRoad,DongchengStreet,Dongguan,Guangdong,China. ReportNo.:PTC25112101701E-FC03 Page2of8 TESTRESULTCERTIFICATION Applicant’sname:QUZHOUSANMAXHARDWARETECHNOLOGYCO.,LTD Address: Room36,No.2JuhaiRd.,QujiangDistrict,QuzhouCity,Zhejiang Province,China Manufacture'sname:QUZHOUSANMAXHARDWARETECHNOLOGYCO.,LTD Address: Room36,No.2JuhaiRd.,QujiangDistrict,QuzhouCity,Zhejiang Province,China Productname:trackerwheel Modelname:PW-5,PW-5T,PW-5H,PW-4,PW-6,PW-6H,PW-4T,PW-4H Testprocedure:FCCCFR47Part1.1307(b)(1) TestDate:Nov.26,2025toDec.14,2025 DateofIssue:Dec.14,2025 TestResult:PASS ThisdevicedescribedabovehasbeentestedbyPTC,andthetestresultsshowthatthe equipmentundertest(EUT)isincompliancewiththeFCCrequirements.Anditisapplicable onlytothetestedsampleidentifiedinthereport. Thisreportshallnotbereproducedexceptinfull,withoutthewrittenapprovalofPTC,this documentmaybealteredorrevisedbyPTC,personalonly,andshallbenotedinthe revisionofthedocument. TestEngineer: Jackzhou/Engineer TechnicalManager: SimonPu/Manager ReportNo.:PTC25112101701E-FC03 Page3of8 Contents Page 2TESTSUMMARY...............................................................................................................................................4 3GENERALINFORMATION..............................................................................................................................5 3.1GENERALDESCRIPTIONOFE.U.T..........................................................................................................5 4RFEXPOSURE..................................................................................................................................................6 4.1REQUIREMENTS........................................................................................................................................6 4.2THEPROCEDURES/LIMIT........................................................................................................................6 4.3MPECALCULATIONMETHOD..................................................................................................................7 4.4TESTRESULT...........................................................................................................................................7 4.5EIRPPOWER............................................................................................................................................8 4.6TESTRESULT...........................................................................................................................................8 ReportNo.:PTC25112101701E-FC03 Page4of8 2TestSummary TestItemsTestRequirementResult MaximumPermissibleExposure (ExposureofHumanstoRFFields) FCCCFR47Part1.1307(b)(1)PASS Remark: N/A:NotApplicable ReportNo.:PTC25112101701E-FC03 Page5of8 3GeneralInformation 3.1GeneralDescriptionofE.U.T. ProductName : trackerwheel ModelName : PW-5 Additionalmodel : PW-5T,PW-5H,PW-4,PW-6,PW-6H,PW-4T,PW-4H OperationFrequency : BLE:2402-2480MHz Lora:902.3-914.9MHz NumberofChannel : BLE:40channels Lora:64Channels TypeofModulation : BLE:GFSK Lora:FSK Antennainstallation : BLE:Ceramicantenna Lora:FPCAntenna AntennaGain : BLE:5.19dBi Lora:1.34dBi Powersupply : Battery: Li-ionBattery:ER18505M RatedVoltage:3.6V RatedCapacity:3500mAh12.6Wh HardwareVersion : N/A SoftwareVersion : N/A ReportNo.:PTC25112101701E-FC03 Page6of8 4RFExposure TestRequirement :FCCPart1.1307(b)(1) EvaluationMethod :KDB447498D01GeneralRFExposureGuidancev06 4.1Requirements Systemsoperatingundertheprovisionsofthissectionshallbeoperatedinamannerthatensuresthat thepublicisnotexposedtoradiofrequencyenergylevelsinexcesslimitformaximumpermissible exposure.Inaccordancewith47CFRFCCPart2SubpartJ,section2.1091thisdevicehasbeen definedasamobiledevicewherebyadistanceof0.2mnormallycanbemaintainedbetweentheuser andthedevice. 4.2Theprocedures/limit (A)LimitsforOccupational/ControlledExposure FrequencyRangeElectricFieldMagneticFieldPowerDensity(S)AveragingTime 0.3-3.06141.63(100)*6 3.0-301842/f4.89/f(900/f)*6 30-30061.40.1631.06 300-1500F/3006 1500-100,00056 (B)LimitsforGeneralPopulation/UncontrolledExposure FrequencyRangeElectricFieldMagneticFieldPowerDensity(S)AveragingTime 0.3-1.346141.63(100)*30 1.34-30824/f2.19/f(180/f)*30 30-30027.50.0730.230 300-1500F/150030 1500-100,0001.030 Note:f=frequencyinMHz;*Plane-waveequivalentpowerdensity ReportNo.:PTC25112101701E-FC03 Page7of8 4.3MPECalculationMethod E(V/m)= d GP30 PowerDensity:Pd(W/m²)= 377 2 E E=Electricfield(V/m) P=PeakRFoutputpower(W) G=EUTAntennanumericgain(numeric) d = Separationdistancebetweenradiatorandhumanbody(m) Theformulacanbechangedto Pd= 2 377 30 d GP FromthepeakEUTRFoutputpower,theminimummobileseparationdistance,d=0.2m,aswellas thegainoftheusedantenna,theRFpowerdensitycanbeobtained 4.4TestResult E(V/m) = d GP30 PowerDensity:Pd(W/m²) = 377 2 E E=Electricfield(V/m) P = PeakRFoutputpower(W) G = EUTAntennanumericgain(numeric) d=Separationdistancebetweenradiatorandhumanbody(m) Theformulacanbechangedto Pd = 2 377 30 d GP θφ FromthepeakEUTRFoutputpower,theminimummobileseparationdistance,d=0.2m,aswellas thegainoftheusedantenna,theRFpowerdensitycanbeobtained ReportNo.:PTC25112101701E-FC03 Page8of8 4.5EIRPpower Freq. (MHz) Fieldstrength(max)(dBuV/m) EIRP(max) (dBm) 902.3 89.68-5.52 908.7 89.79-5.41 914.9 89.47-5.73 Note:EIRP=E-104.8+20logD, Where EistheelectricfieldstrengthindBμV/m EIRPistheequivalentisotropicallyradiatedpowerindBm disthespecifiedmeasurementdistanceinm whereD=3,EIRP=E-95.2. 4.6TestResult Item Antenna Gain (numeric) Max.Peak OutputPower (dBm) Tuneup tolerance (dBm) MaxTuneUp Power(mW) PowerDensity…
Text truncated - open the document above for the full version.
Shenzhen Kinghelm Electronics Co., Ltd http://www.BDS666.com - 1 - SPECIFICATION TEL:0755-83040901 FAX: 18th Floor, Building T2, Lijincheng Center, Yousong Community, Longhua Street, Longhua District, Shenzhen 0755-83040901 Prepared by: Checked by : Approved by: Formed On Document Version ( V1.2 ) KH3216-A35 PART NO: CUSTOMER PART NO: CUSTOMER APPROVED BY: APPROVED DATE: Shenzhen Kinghelm Electronics Co., Ltd Shenzhen Kinghelm Electronics Co., Ltdhttp://www.BDS666.com - 2 - Table of contents Version rejigger track record..............................3 1. Introduction..................................................................4 2.D i m e n s i o n s.....................4~5 3.Evaluation Board and Matching Circuits............5 4.Electrical Characteristics..........................................6 5.Characteristic curve...................................................6 6. 方向图 Radiation Pattern...................................................7~8 7.Post Dependability Tolerance ...............9 8.Dependability Test..........................................9~10 9. Reflow Soldering Standard Condition.....................10 10.Packaging and Dimensions ....................................11 Shenzhen Kinghelm Electronics Co., Ltd http://www.BDS666.com - 3 - Version Version rejigger track record Rejigger Prepared Approve Date V1.0 initial issue 贺俊驹姚富鑫 2015.12.25 V1.1 Change the dimensional tolerance value of the product 陈星 贺俊驹 2017.05.24 V1.2 Revise contents 8.1 to 8.4 of the reliability test instructions 姚富鑫 贺俊驹 2017.11.07 Note: 1、When changing the electrical performance indicators of the product, the version number needs to be repl aced (V1.0 to V2.0, V3.0, etc.) ; 2、When changing the product testing methods (including reliability testing conditions) or the usage conditio ns, the current version number is added to the series (V1.0 is changed to V1.1, V1.2, etc.). . Shenzhen Kinghelm Electronics Co., Ltd http://www.BDS666.com - 4 - 1. INTRODUCTION kinghelm Microwave Multi-Layer Ceramic Antenna LA series are designed to be used in WLAN、WiFi、Bluetooth、PHS、 Multiple-band Mobile phone antenna, FM, etc and compact size SMD chip design. 2.Dimensions(Unit:mm) 技术详询 Shenzhen Kinghelm Electronics Co., Ltd http://www.BDS666.com - 5 - 3.Evaluation Board and Matching Circuits 4.Electrical Characteristics No. Item Specifications 4.1 Central Frequency (No matching)2875MHz After Matching2450 MHz 4.2 Band Width 100MHz typ. 4.3 Peak Gain 5.19 dBi ≤4.4 V.S.W.R 2.0 4.5 Polarization Linear 4.6 Azimuth Beam width Omni-directional 4.7 50 Impedance Ω 6.2n H 1.8n H 技术详询 Shenzhen Kinghelm Electronics Co., Ltd http://www.BDS666.com - 6 - 5.Characteristic curve coordinates 6.Radiation Pattern : Shenzhen Kinghelm Electronics Co., Ltd http://www.BDS666.com - 7 - X-Z Plane Y-Z Plane X-Y Plane Shenzhen Kinghelm Electronics Co., Ltd http://www.BDS666.com - 8 - 3D Radiation Pattern Frequency (MHz) 2400 2450 2500 Avg. Gain (dBi) -0.23 -0.36 -0.51 Peck Gain (dBi) 4.98 5.19 4.55 Efficiency (%) 70 71.2 69 Shenzhen Kinghelm Electronics Co., Ltd http://www.BDS666.com - 9 - 7.Post Dependability Tolerance Post Dependability Tolerance ( Refer to the table ) 8.Dependability Test Temperature range 25±5°C Relative Humidity range 55~75%RH Operating Temperature range -40°C~+85°C 8.1Vibration Resist The device should satisfy the electrical characteristics specified in paragraph 8.1~8.4 after applied to the vibration of 10 to 55Hz with amplitude of 1.5mm for 2 hours each in X , Y and Z directions. 8.2 Drop Shock The device should satisfy the electrical characteristics specified in paragraph 8.1~8.4 after dropping onto the hard wooden board from the height of 100cm for 3 times each facet of the 3 dimensions of the device. 8.3Solder Heat Proof The device should be satisfied after preheating at 120°C~150°C for 120 seconds and dipping in soldering Sn at 255°C+10°C for 5±0.5 seconds,or electric iron 300°C-10°C for 3±0.5 seconds, without damnify. 8.4 Tensile Strength of Terminal The device should not be broken after tensile force of 1.0kg is slowly applied to pull a lead pin of the fixed device in the lead axis direction for 10±1 seconds. No. Item Post Dependability Tolerance ±7.1 Central Frequency 5 MHz 7.2 ±Band Width 5 MHz 7.3 ±Gain 0.1 dBi ±7.4 V.S.W.R (in BW) 0.1 Shenzhen Kinghelm Electronics Co., Ltd http://www.BDS666.com - 10 - 8.5 耐弯曲试验 Bending Resist Test Weld the product to the center part of the PCB with the thickness 1.6±0.2mm as the illustration shows, and keep exerting force arrow-ward on it at speed of :1mm/S , and hold for 5±1S at the position of 1.5mm bending distance , so far , any peeling off of the product metal coating should not be detected . 8.6 Moisture Proof The device should satisfy the electrical characteristics specified in paragraph 8.1~8.4 after exposed to the temperature 60±2°Cand the relative humidity 90~95% RH for 96 hours and 1~2 hours recovery time under normal condition. 8.7 High Temperature Endurance The device should satisfy the electrical characteristics specified in paragraph 8.1~8.4 after exposed to temperature 85±5°Cfor 96±2 hours and 1~2 hours recovery time under normal temperature. 8.8 Low Temperature Endurance The device should also satisfy the electrical characteristics specified in paragraph 8.1~8.4 after exposed to the temperature -40°C±5°C for 96±2 hours and to 2 hours recovery time under normal temperature . 8.9 Temperature Cycle Test The device should also satisfy the electrical characteristics specified in paragraph 8.1~8.4 after exposed to the low temperature -40°C and high temperature +85°C for 30±2 min each by 5 cycles and 1 to 2 hours recovery time under normal temperature. 9.Reflow Soldering Standard Condition Shenzhen Kinghelm Electronics Co., Ltd http://www.BDS666.com - 11 - 10.Packaging and Dimensions 10.1 Plastic Tape Remarks for Package Reserve a length of 150~200mm for the trailer of the carrier and 250~300 mm for the leader of the carrier and further 250mm of cover tape at the le…
Text truncated - open the document above for the full version.
TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN0915-FPC19BX ProductName:Antenna Page1 SpecificationForApproval Date:2025.12.22 Version:1.0 客户名称 Customer: 客户料号 CustomerP/N: 腾祥料号 TXP/N:AN0915-FPC19BX 规格描述 Description:915MHzFPC天线1.13mm黑色线L=100mm+IPEX TengxiangCheckedBy: 腾祥审核 CustomerApprovedBy: 客户审核 DRAWN 制作 路婷 TESTEDBY 检测 CHECKEDBY 审核 胡超 CHECKEDBY 审核 Q.C.DEPT. 品管 陈祖喜 Q.C.DEPT. 品管 APPROVEDBY 核准 韦佳 APPROVEDBY 核准 NO.53ShatouShaChongRoad,ChangAnTown,Guangdongprovince,China 中国广东省东莞市长安镇沙头区沙涌路53号 TEL:86-769-81873082FAX:86-769-82663788 http://www.tenxiang.cn TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN0915-FPC19BX ProductName:Antenna Page 2 Index: 1. Specification(规格) 2. Characteristicsand ReliabilityTest (产品特性和可靠性测试标准) 3. Antenna- S ParameterTest Data(样品测试数据) 4.Testenvironmentandequipment(测试环境以及设备) 5. Antenna- RadiationPatternTest Data(辐射模式测试数据) 6. Mechanicaland PackingDrawing(图纸包装规范) RevisionHistory(变更履历) RevisionDateChangeNotificationDescription 1.02025.12.22 初版 TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN0915-FPC19BX ProductName:Antenna Page3 1.Specification SamplePhoto A.ElectricalCharacteristics Frequency频率915MHz S.W.R.驻波比参考波形 AntennaGain增益1.34dBi Polarization 极化方式Linear Impedance 阻抗50Ohm B.Material&MechanicalCharacteristics CableType线材规格1.13mm,BIack ConnectorType连接器规格I-PEX C.Environmental StorageTemperature 存储温度 -40 ̊C~+80 ̊C OperationTemperature 工作温度 -40 ̊C~+80 ̊C TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN0915-FPC19BX ProductName:Antenna Page4 2.CharacteristicsandReliabilityTest TestItems 测试 项目 TestConditionandProcedure 测试方法 Requirements 要求Result 结果 1V.S.W.R. 电压驻波比 SetDUTonNetworkAnalyzer;makeindividual calibrationtotest设置网络分析仪参数进行测试 DirectiveDUTspecification 符合待测物规范 PASS 2Insertion Loss插入损 失 SetDUTonNetworkAnalyzer;makeindividual calibrationtotest设置网络分析仪参数进行测试 DirectiveDUTspecification 符合待测物规范 PASS 3Antenna Gain 天线增益 SetDUTonAntennaChamber;makeindividual calibrationtotest设置天线暗室参数进行测试 DirectiveDUTspecification 符合待测物规范 PASS 4Solderability 可焊性 GB/T2423.28-2005 Temp:260±5°C;Duration:5seconds温度260± 5°C;持续5秒 Tinevenlyonfull 上锡均匀饱满 PASS 5PullTest 拉力 Holdingwithindividualspecification;force appliedtoaxisofterminal.单独定义产品端子拉力 1.DirectiveDUTspecification 2.FrequencyTol.≤5% 符合待测物规范;频率偏移≤5% PASS 6Dimension 尺寸 Inspectionofdimension,color,material,package, surfaceprocess.检查尺寸,颜色,材料,包装,表面处理 DirectiveDUTspecification 符合待测物规范 PASS 7RoHSWithReferencetoIEC62321:2008withflowchart 参考IEC62321测试流程 DirectiveRoHS2015/863/EU 符合RoHS2015/863/EU标准 PASS TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN0915-FPC19BX ProductName:Antenna Page5 3.Antenna-SParameterTestData 测试仪器:VSWR是使用安捷伦E5071C连接到治具来测试,状态为自由空间。 TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN0915-FPC19BX ProductName:Antenna Page6 4.Testenvironmentandequipment 暗室规格:6m*6m*6m/7m*3m*3m LTE-TDD/FDD-SCDMA测试设备:ROHDE&SCHWARZCMW500 无源效率测试设备:AgilentTechnologiesE5071B TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN0915-FPC19BX ProductName:Antenna Page7 5.Antenna-RadiationPatternTestData XZYZXY 900MHz 915MHz 930MHz 6.MechanicalDrawingSeeattachedfiles B C D / Antenna 1/1 ±0.5±0.2±1 OD1.13 Part Number Name CB-113BS Coaxial Cable 1 No. 2 1 Q'ty 1 Material Finish A SYY 2025.12.22 DES BY Note: 1.Mark is important dimension;"Cpk "Identify for process control(CpK 1.33). 2.Tolerance:Unmarked tolerance refer to the standard tolerance please. 3.Pay attention to the direction of the connector. APPROVER DATE SIGN DESCRIPTION SCALE: APP BY Tolerance X.XX X.X X TITLE: PART NO.: CUSTOMER P/N: CHK BY RF BY UNITS: mm REVISION: HFREACHRoHS2.0 CONFIDENTIAL FPC Black Black 1 CR-113-ZP-A 3 Cu I-PEX Au Plated 1 2 3 WJ 2025.12.22 HC 2025.12.22 YCX 2025.12.22 100pcs/ PE bag Revision : A Customer : ALL APPROVED BY CHECKED BY DESIGNED BY Name: Page: 1 of 1 Date: Part Number : 产品包装规范 PACKING CRITERION 8000pcs/Carton 3. SEALING 。 MEAS G W: KGS N W: KGS QTY: PCS ITEM NO: C/NO MADE IN CHINA SIDE FRONT 2.PACKING 1 . Enter PE bag。 2025.12.22 Antenna
Page1of55 FCCTESTREPORT FCCID:2BQG6-PW-5 Product: trackerwheel ModelName: PW-5,PW-5T,PW-5H,PW-4,PW-6,PW-6H,PW-4T,PW-4H Brand: N/A ReportNo.: PTC25112101701E-FC01 Preparedfor QUZHOUSANMAXHARDWARETECHNOLOGYCO.,LTD Room36,No.2JuhaiRd.,QujiangDistrict,QuzhouCity,ZhejiangProvince,China Preparedby PreciseTesting&CertificationCo.,Ltd Building1,No.6,TongxinRoad,DongchengStreet,Dongguan,Guangdong,China ReportNo.:PTC25112101701E-FC01 Page2of55 1TESTRESULTCERTIFICATION Applicant’sname: QUZHOUSANMAXHARDWARETECHNOLOGYCO.,LTD Address: Room36,No.2JuhaiRd.,QujiangDistrict,QuzhouCity,Zhejiang Province,China Manufacture'sname: QUZHOUSANMAXHARDWARETECHNOLOGYCO.,LTD Address: Room36,No.2JuhaiRd.,QujiangDistrict,QuzhouCity,Zhejiang Province,China Productname: trackerwheel Modelname: PW-5,PW-5T,PW-5H,PW-4,PW-6,PW-6H,PW-4T,PW-4H Standards:FCCCFR47Part15Section15.247 Testprocedure:ANSIC63.10-2020 TestDate: Nov.26,2025toDec.14,2025 DateofIssue: Dec.14,2025 TestResult:Pass ThisdevicedescribedabovehasbeentestedbyPTC,andthetestresultsshowthatthe equipmentundertest(EUT)isincompliancewiththeFCCrequirements.Anditisapplicableonlyto thetestedsampleidentifiedinthereport. Thisreportshallnotbereproducedexceptinfull,withoutthewrittenapprovalofPTC,thisdocument maybealteredorrevisedbyPTC,personalonly,andshallbenotedintherevisionofthedocument. TestEngineer: Jackzhou/Engineer TechnicalManager: SimonPu/Manager ReportNo.:PTC25112101701E-FC01 Page3of55 Contents Page 1TESTRESULTCERTIFICATION...............................................................................................................................2 2TESTSUMMARY..........................................................................................................................................................5 2.1TESTSITE............................................................................................................................................................6 3GENERALINFORMATION.......................................................................................................................................7 3.1GENERALDESCRIPTIONOFE.U.T.....................................................................................................................7 3.2CHANNELLIST.....................................................................................................................................................8 4EQUIPMENTDURINGTEST....................................................................................................................................9 4.1EQUIPMENTSLIST.............................................................................................................................................9 4.2MEASUREMENTUNCERTAINTY.........................................................................................................................11 4.3DESCRIPTIONOFSUPPORTUNITS...................................................................................................................12 5CONDUCTEDEMISSION..........................................................................................................................................13 5.1E.U.T.OPERATION............................................................................................................................................13 5.2EUTSETUP.......................................................................................................................................................13 5.3TESTSET-UP(BLOCKDIAGRAMOFCONFIGURATION).................................................................................14 5.4MEASUREMENTPROCEDURE............................................................................................................................14 5.5CONDUCTEDEMISSIONLIMIT...........................................................................................................................14 5.6MEASUREMENTDESCRIPTION..........................................................................................................................14 5.7CONDUCTEDEMISSIONTESTRESULT.............................................................................................................14 6RADIATEDSPURIOUSEMISSIONS......................................................................................................................15 6.1EUTOPERATION...............................................................................................................................................15 6.2TESTSETUP......................................................................................................................................................16 6.3SPECTRUMANALYZERSETUP..........................................................................................................................17 6.4TESTPROCEDURE.............................................................................................................................................18 6.5SUMMARYOFTESTRESULTS...........................................................................................................................20 7CONDUCTBANDEDGEANDSPURIOUSEMISSIONSMEASUREMENT....................................................28 7.1TESTPROCEDURE.............................................................................................................................................28 7.2TESTSETUP......................................................................................................................................................28 7.3TESTRESULT....................................................................................................................................................29 ReportNo.:PTC25112101701E-FC01 Page4of55 86DBBANDWIDTHMEASUREMENT......................................................................................................................36 TESTPROCEDURE..............................................................…
Text truncated - open the document above for the full version.
FCCID:2BQG6-PW-5 RadiatedSpuriousEmissions From30MHz-1000MHz TestfrequencyfromAbove1GHz
2553 CHINO HILLS PKWY STE C CHINO HILLS · CHINO HILLS, California, 91709 · United States
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | 1.21 mW |

Bluetooth Beacon
Equipment Class
DTS - Digital Transmission System
