2BQNA-MINIXRCutting Plotter

MINI-XR User manual Package Content Cutting Mat*1 Power Adapter*1 MINI-XR*1 Cable*1 Holder*1Blade*1 Appearance and function 1. Power Button 2. holder clamp 3. carriage 4. sensor 5. Unloading Button 6. Front cover 7. lock cover 8. pinch wheel 9. USB port 10. Supply port 1 67 9 10 8 2345 Product Operation Guide Before using the machine, please read the included safety precautions. Before unloading materials, please ensure the machine is in a stopped state; do not forcefully eject the paper. 1. How to Power on 2. How to Load Materials 3. How to Unload Materials Connect the power cord to the machine, ensure the other end is plugged into a compatible socket, install the knife holder into the tool slot and ensure it is secured. Connect the machine to a desktop computer using the included USB cable or via Bluetooth, then click the power button once to start the machine. Fix the material on the cutting mat, insert the cutting mat with the loaded material into the area under the paper pressing roller along the guide slot from the front of the machine, and wait for about two seconds for automatic paper feeding. Or click the Paper In/Out Button to feed paper (in the non-paper feeding state). Click the Paper In/Out Button to eject the paper (in the paper fed state); use tools such as tweezers to take out the cut materials from the cutting mat. The blade needle is very sharp; be careful to avoid injury Do not use acetone-based solutions to clean the product, as they may damage the machine. 4. How to Replace the Blade Needle 5. How to Clean the Machine To use this product properly, please download the software Crzou Play. Download address: https://www.crzou.com/down Open the tool holder clip and remove the cutting tool; gently push the top plunger and carefully remove the blade needle; take out the new blade needle, remove the protective cover, and insert the tail end of the blade needle into the cutting tool; put the cutting tool into the tool holder clip and lock it. MINIXR requires regular cleaning. Excessive use may cause debris accumulation around the paper pressing roller and steel spike roller. Please clean the machine with cleaning tools such as a soft cloth and alcohol (70% or higher). 1. Product Specifications 2. Operation lnstructions Specifications and Instructions Tool Holder Maximum Feeding Size Maximum Cutting size Maximum Cutting Thickness Maximum Cutting speed Contour Cutting Maximum Blade Pressure Machine Dimensions Machine weight Connection Method Machine input Operating Temperature 1 160mm 135mm 1mm 105mm/s Infrared Contour 700g 250mm*120mm*115mm 1. 7KG Bluetooth/USB 24VDC 2A 36W +5°C - +35°C Power On Power Off Restart Paper In Paper Out Reset Repeat Last Cutting 1 2 3 4 5 6 7 Click the power button once Press and hold the power button for3s to power off Press and hold the power button for8s to restart In non-paper- fed stateclick the Paper In/Out button in paper-fed state,clickthe Paper in/Out button In paper-fed state,double-clickthe power button ln paper-fed state,click thepower button once Safety Precautions Risk of injury, fire, and electric shock. Strictly follow safety protocols. Contains moving parts. Children under 14 must be supervised. For dry indoor use only. Avoid moisture/liquids. Sharp blades may cause injury. Handle with care. Disconnect power before replacing damaged blades/tools. Keep sharp blades/small parts away from children (choking hazard). DO NOT disassemble or modify the machine. Use original adapter with grounded outlet to prevent shock. Secure power cord to avoid tripping/snagging (especially near children). 1. 2. 3. 4. 5. 6. 7. 8. 9. Power off before unplugging. NEVER pull the cord. Use on stable, non-slip surface. Clear debris under rubber feet. Keep away from drapes/blinds to avoid entanglement. Maintain 30cm clearance for mat movement. DO NOT touch mat/material during cutting – even when paused. Fully disconnect power during maintenance/cleaning. Clean with damp cloth only. NO flammable/corrosive solvents. Store in dry, ventilated area away from sunlight/heat. Avoid humid/chemically corrosive environments. 10. 11. 12. 13. 14. 15. 16. 17. 18. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
