2BRS4-PG126173Wireless Gateway

MSPG126173 Intelligent control DWG NO. :MSSD-8625 A0 Specifications Customer’s Part Number: M3K-GTW MOONS’ Part Number: 4696355000170 Model: MSPG126173 P/N: A8625 CUSTOMER’S APPROVAL STAMP Please sign back after your approval. The specifications will come into force when we receive purchase order. DWG. CHK. STANDARD APPD. © 2024 MOONS'. All rights reserved. All content contained herein is subject to change without prior notice. More product documentation and MOONS' terms and conditions are available at https://www.moonsindustries.com MSPG126173 2 / 19 History Version Rev. Date Contents ECO No. DWG. CHK. APPR. A0 2025-01-08 The first version Jiabin.gu Wanghui.yan Yiping.lai MSPG126173 3 / 19 1 DESCRIPTIONS This device is used for data transmission between the server and the node controllers. Data interconnection with the server can be done using Ethernet, or cellular networks. Data interconnection with the Node Controllers use WPAN (915MHz). Bluetooth can be used for the configuration of this device or field commissioning. MSPG126173 4 / 19 1.1 FEATURES  Gateway input voltage: USB-TYPEC 9V, 12V, 20VDC.  A 20W USB PD adapter is included  Operating temperature: -40 to +60°C.  Power consumption <10W.  Transfer data between control center and nodes.  An Ethernet interface for uplink data.  A cellular RF module for data uplink.  An accord IEEE802.15.4-915 MHz standard wireless module for data downlink.  Built-in Bluetooth module for configuration.  Embedded communication encryption mechanism.  Protection class: IP66.  Meet UL, CE, SAA certification.  Certified by FCC.  The cellular module support carrier bands around the world.  The MINI-SIM card (2FF) has been installed internally. Prepaid 5-year data charges cover multiple carriers worldwide.  Warranty: 5 years standard. 2 CHARACTERISTICS 2.1 ABSOLUTE MAXIMUM RATINGS At 20 °C, 50% RH, 100Kpa conditions. PARAMETER TEST CONDITIONS MIN TYP MAX UNIT Input DC Voltage 8 / 27 Vdc 2.2 OPERATING CONDITIONS PARAMETER TEST CONDITIONS MIN TYP MAX UNIT Operating temperature Gateway -40 / +60 °C Adapter 0 / +40 °C Storage temperature Indoor dry, well-ventilated place -30 / +70 °C Relative humidity No frost 10 / 90 % Vibration / / 1 G Packaging Impact Drop / 1 / M Warranty Gateway / 5 / Years Ingress protection Gateway IP66 MSPG126173 5 / 19 2.3 EMC TYPE Standard Test level Electrostatic discharge immunity IEC61000-4-2 Level 2 RFEMS IEC61000-4-3 Level 2 Electrical fast transient burst immunity IEC61000-4-4 Level 3 Surge Immunity IEC61000-4-5 Level 2 Conducted disturbances induced by RF field immunity IEC61000-4-6 Level 2 Electromagnetic disturbance characteristics EN62368, EN62311, EN301489, EN300220, EN300440 2.4 CERTIFICATION TYPE Standard Safety certification (For AC adapter) North America: UL62368; Europe: EN62368; Australia: AS/NZS 62368 Electromagnetic interference characteristics certification North America: FCC 15.247 (915M WPAN) FCC 15C (BLUETOOTH) FCC Title 47 CFR Part 22H, Part 24E, Part 27 and Part 90 (4G CAT1) FCC 15 Class B (For AC adapter) Europe: EN 301908; EN 301489 (4G CAT1) EN 300220 (915M WPAN) EN 300440 (BLUETOOTH) Australia: AS/NZS 301908; AS/NZS 301489 (4G CAT1) AS/NZS 300220 (915M WPAN) AS/NZS 300440 (BLUETOOTH) MSPG126173 6 / 19 3 MECHANICAL DATA 3.1 DIMENSIONS 92.1 158.8 Ф 6.9 221 ± 1 170 ± 1 70 72 ± 1 Gateway MSPG126173 7 / 19 4 INTERFACE 4.1 POWER SUPPLY  Gateway Voltage input: 9V, 12V, 20V  Use IP67 waterproof connector  Power supply interface: USB-TYPE-C  A 20W USB PD XSP-20TUSAC-GaN power adapter is included in the package  The power adapter supports Quick Charge 3.0+/3.0/2.0 protocol MSPG126173 8 / 19 USB Type C socket on the housing USB Type C plug USB PD Adapter MSPG126173 9 / 19 Cable for USB PD PARAMETER TEST CONDITIONS MIN TYP MAX UNIT Adapter input Voltage AC (50/60Hz) 100 / 240 VAC Adapter output power DC 15 / 20 W Adapter output current @5V / / 3 A @9V / / 2.22 A @12V / / 1.67 A Gateway input voltage DC 8.8 12 22 VDC Gateway input current RMS 12V 100 / 1000 mA Gateway Power Dissipation 12V 0.25 2.5 10 W 4.2 LAN  RJ45 (8pin)  Meet TCP / IP protocol  100M/10M adaptive  Use IP67 waterproof connector  The console can be connected via Ethernet to receive data. MSPG126173 10 / 19 RJ45 socket on the housing RJ45 plug Ethernet RJ45 cable PARAMETER TEST CONDITIONS MIN TYP MAX UNIT Transmission rate 10 / 100 Mbps Transmission voltage 100Mbps -1.05 / +1.05 V Transmission voltage 10Mbps -2.8 / +2.8 V 4.3 Cellular Network  Support LTE 4G FDD Cat.1  Built-in 4G antenna is used by default; SMA external 4G antenna can be used upon customer request.  Bluetooth can be used to configure internal and external antenna access.  Built-in MINI-SIM card slot, MSPG126173 11 / 19  Uplink up to 5 Mbps; Downlink up to 10 Mbps  FCC (North America), CE (Europe)  Output power: Class 3 (0.2 W, 23 dBm) @ LTE  4G FDD bands: B1,2,3,4,5,7,8,9,12,13,14,18,19,20,25,26,28  The cellular module support carrier bands around the world. Support the network of major operators in Asia, Europe, America, Oceania and North Africa.  The MINI-SIM card (2FF) has been installed internally. Prepaid 5-year data charges cover multiple carriers worldwide. MINI-SIM CARD There is 3M double-sided glue on the back of the antenna 3 in 1 Antenna 4GLTE(L)+GNSS(G)+915MHz(E) Back 3M adhesive and magnet for mounting MSPG126173 12 / 19 Antenna mounting bracket 4.4 GNSS  Support of GPS, Beidou  Built-in GNSS antenna is used by default; SMA external GNSS antenna can be used upon customer request.  Bluetooth can be used to configure internal and external antenna access.  Active GNSS antenna with external SMA interface, PARAMETER TEST CONDITIONS MIN TYP MAX UNIT Sensitivity Tracking -160 / dBm Time To First Fix Cold reset 30 / / s Accuracy @CEP50 / / 2 m Navigation update rate / 1 / Hz MSPG126173 13 / 19 4.5 WPAN  An accord IEEE802.15.4-915 MHz standard wireless module for data downlink  Self-building network;  Self-healing network;  Embedded co…

Text truncated - open the document above for the full version.

ZHONGSHAN B&T TECHNOLOGY Co,. Ltd Form Number:B&T-QR-EN-002 Version: B3 Retention period: 5 years Form effective date: August 6, 2019 clause 1 page common 9 page Development Project Number: Y202003131768 Date:2020.03.30 Edition: A0 Letter of acceptance Customer Name: MOONS’ Commissioning Items: UFO Card head B&T material number: AG-041333-1963 Specifications:2.4G Built-in antenna (FPC 31.2×13）-grey 1.13 line- TerminalL=85mm Factory Signature: Writing Review Approval Huang Feihui Ouyang Yingshan Guan Ning Customer Acknowledgment Signature: Inspection Review Approval B&T contact information Company address: Shenzhen OFFICE: 408 Zhongshan Factory Address: 2nd to 4th floor, Building A, Dongfang Industrial Park, Nanlang Town, Zhongshan City Telephone: 0760-85521414 Fax: 0760-89961414 Website: http://www.tech-now.com Business contact: Xiao Guo Mobile: 18664045992 Email: [email protected] Technical contact: Ouyang Yingshan Mobile: 13113628703 Email: [email protected] Quality contact: Yuan Jinjun Mobile: 18998784314 Email: [email protected] ZHONGSHAN B&T TECHNOLOGY Co,. Ltd Form Number:B&T-QR-EN-002 Version: B3 Retention period: 5 years Form effective date: August 6, 2019 clause 2 page common 9 page Document formulation/revision/abolition of resumes Version Date Formulate/revise the content Formulate Approved A0 2020.03.30 Formulated for the first time Huang Feihui Tang Hailin/Zhou Quan ZHONGSHAN B&T TECHNOLOGY Co,. Ltd Form Number:B&T-QR-EN-002 Version: B3 Retention period: 5 years Form effective date: August 6, 2019 clause 3 page common 9 page directory 1cover ·········································································· 1 2directory ···································································· 3 3, product drawings ······················································· 4 4, performance parameter table ······································· 5 5, electrical performance test report ···························· 6-7 6, material composition and hazardous substance list ······· 8 ZHONGSHAN B&T TECHNOLOGY Co,. Ltd Form Number:B&T-QR-EN-002 Version: B3 Retention period: 5 years Form effective date: August 6, 2019 clause 4 page common 9 page 3. Product drawings ZHONGSHAN B&T TECHNOLOGY Co,. Ltd Form Number:B&T-QR-EN-002 Version: B3 Retention period: 5 years Form effective date: August 6, 2019 clause 5 page common 9 page 4. Performance parameters Electrical parameters Frequency range 2400-2500MHz Input impedance 50Ω Stop the wave Compare the seal figure Maximum gain 3.44dBi Power capacity <10w Polarization mode Line polarization Radiation direction Omnidirectional Connector model Terminal Mechanical parameters Line length 85±3mm Sustainment 1KG coaxial cable Grey 1.13 line Salt spray test 24H Environmental parameters Operating temperature -30°C~65°C ZHONGSHAN B&T TECHNOLOGY Co,. Ltd Form Number:B&T-QR-EN-002 Version: B3 Retention period: 5 years Form effective date: August 6, 2019 clause 6 page common 9 page 5. Electrical performance test report S11 Parameter 5.2 VSWBN data Freq/GHz 2.4 2.45 2.5 VSWR 1.75 1.27 1.31 5.3 Antenna anchoric test data Frequency/MH z 2400 2410 2420 2430 2440 2450 2460 2470 2480 2490 2500 gain/dBi 2.10 2.15 2.27 2.33 2.44 3.10 3.44 3.19 2.68 2.83 2.46 Efficiency/% 51.06 52.95 51.76 57.61 61.12 59.50 61.45 56.52 54.60 52.93 50.81 ZHONGSHAN B&T TECHNOLOGY Co,. Ltd Form Number:B&T-QR-EN-002 Version: B3 Retention period: 5 years Form effective date: August 6, 2019 clause 7 page common 9 page WIFI antenna pattern 2400M 3D-E1-E2-H 2450M 3D-E1-E2-H 2500M 3D-E1-E2-H ZHONGSHAN B&T TECHNOLOGY Co,. Ltd Form Number:B&T-QR-EN-002 Version: B3 Retention period: 5 years Form effective date: August 6, 2019 clause 8 page common 9 page 6. Material composition and hazardous substance table ite m tim es specificat ion Material RoHS Inspection Results (PPM) ICP detection number Detection time Cd Pb Hg Cr+6 PBB PBDE 1 1.13 Line FEP ND ND ND ND ND ND SHAEC2001149401 20.01.21 Tinned copper wire ND ND ND ND ND ND A2190201290101001 19.08.13 2 FPC Flexible circuit boards ND ND ND ND ND ND CANEC1909313701 19.05.27 Adhesive backing 3M ND ND ND ND ND ND 4226898 19.05.02 3 Termina l PBT ND ND ND ND ND ND CE/2019/C2588 19.12.23 Phosphor Bronze ND 8 ND ND ND ND CANEC1910449313 19.06.10 ZHONGSHAN B&T TECHNOLOGY Co,. Ltd Form Number:B&T-QR-EN-002 Version: B3 Retention period: 5 years Form effective date: August 6, 2019 clause 9 page common 9 page

RF Test Setup Report No: EFTA25110018-IE-02 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-107R Page 1 of 2 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Part 15C Test Setup 9kHz-30MHz 30MHz-1GHz RF Test Setup Report No: EFTA25110018-IE-02 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-107R Page 2 of 2 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. 1GHz-18GHz Picture 1 Radiated Emission Test Setup Picture 2 Conducted Emission Test Setup

1 Specification RF FunctionNumber of ANTFrequency BandRemark 902~928MHz1 Requirements of Antenna Design Requirements of Measurement Test ItemSpecificationRemark VSWR ＜2.0 Peak gain4.39dBi Efficiency>51% 3 Antenna Placement & Solution AntennaANT TypeSize (L * W * H)Cable Length (mm)Cable Type 868/915MHzPCB 59*27*1L=300RG174 Test Setup for S-parameter Measurement 4 EquipmentBrandModelS/NCorrection dateValidity period Network Analyzer KeysightE5071CMY461077442025.4.181 year Chamber Information 5 ChamberBrandModelCorrecti on date Validity period SATIMOSATIM O SG-322025.4.1 8 2 year θφ Total angle175 ̊360 ̊ How many angle scan one point 5 ̊5 ̊ Total scan point3673 S Parameter Results 6 VSWR 7 2D Radiation Pattern Results 8 3D Radiation Pattern Results 9 Results Summary (peak gain, efficiency ) FrequencyE Total. dB(dB)Efficiency(%) 902MHz4.3051.10 905MHz4.39 51.14 910MHz4.20 51.00 915MHz3.92 52.53 920MHz3.57 56.47 925MHz3.64 66.52 928MHz3.58 56.50

Bdtron, Inc. www. bdtron.com Technical Data Sheet 外置黑色圆形防水三合一天线LTE-WPAN-GNSS, RP-SMA MALE L=2M MPN: 1025A0055 Document No. - Prepared by Jerry Date 2025/09/17 Revision 1.0 Bdtron, Inc. www. bdtron.com Revised History Date Version Revised Record 17/09/2025 1.0  1st Released Bdtron, Inc. www. bdtron.com Content 1. Technical Specifications 2. Mechanical Dimensioned Drawing 3. Test report 4. Final Product Inspection Report 5. Physical picture Bdtron, Inc. www. bdtron.com Specification Rough description 外置黑色圆形防水三合一天线LTE-WPAN-GNSS, RP-SMA MALE L=2MM Item Initial Specification Final Specification Dimensions 200mm Impedance 50Ω Test environment No housing Spectrum Freq. Range 824~960&1710~2700 MHz 915 MHz VSWR ≤3.0 ≤2.5 ≤2.0 Antenna type 三合一天线 Gain(Peak gain) Radiation Polarization Vertical Rad. efficiency >32% Connector type RP-SMA Male Cable type RG174 Cable length(Total) None Isolation None Bdtron, Inc. www. bdtron.com VSWR Bdtron, Inc. www. bdtron.com Results Summary (peak gain, efficiency ) Bdtron, Inc. www. bdtron.com Bdtron, Inc. www. bdtron.com 915MHZ:3D&2D Radiation Pattern Results Bdtron, Inc. www. bdtron.com Bdtron, Inc. www. bdtron.com 4G:3D&2D Radiation Pattern Results Bdtron, Inc. www. bdtron.com Bdtron, Inc. www. bdtron.com Bdtron, Inc. www. bdtron.com 序号 No. 抽样数 Sampling Quantity 检验方法 Check Method 判定 Pass/NG 15TA200200200200OK 5TA14141414OK 5DC80808080OK 25VOK 5VOK 5VOK 35NAPASSPASSPASSPASSOK 45BAOK 5 SA BG TA SF MS BA NA 不合格品处理Nonconforming product dispose: □挑选Sorting □返工Rework □特采Concession □报废Scrap 深度千分尺 Depth Micrometer 专用治具 Special Fixture 记录保存期限Storage Life: 3Year. 检验结果Checked Result: ■合格(PASS) □不合格(NG) 核准/日期(Approved/Date) : 褚轩 2025.09.17 制作/日期(Prepared/Date): Carrie 2025.09.17 品保经理Quality Manager: 半径规 Radius Gauge PGOM外径千分尺 OD Micrometer 厚薄规 Thickness Gauge SG 螺纹规 Screw Thread Gauge IM内径千分尺 ID Micrometer卷尺 Tapeline 检验方法代码 Check Method Code V目视 Visual样本 SampleRG TG CT 备注:抽检产品超过5PCS时,则记录其中5PCS产品的数据在记录表上 Note:Please record 5pcs product inspection data when sampling quantity more than 5Pcs! 线材:无破损/毛边/色差 连接器:无变形/多料/缺料/色差 电镀不良 VSWR 备注： ■新产品New product □QA判退QA Reject □客诉产品Customer complaint □库存重检Inventory recheck 200 柱规 Pin Gauge 数量/包装方式/外箱标识 无不良 无不良 网络分析仪 Network Analyzer 数显卡尺 Digital Caliper 1025 2025/9/17 客户料号 Customer P/N 公司料号 BD P/N 1025A0055 构成:无与BOM/图纸承认书不符 8080±1.5 包装 其他 无不良 客户 Customer 1 张松茂 外观/颜色 14±1 QA检验单号 QA Report No. 客户订单号码 Customer PO 生产日期 Mfg Date 2025/9/17 生产单号 Lot No 苏州八德电子科技有限公司 成品检验报告 Final Product Inspection Report 检验日期 Checked Date N/A 公司订单号码 BD PO N/A 检验标准 Check Criteria 200±30 功能测试 检验项目 Check Item 尺寸 PF TD VC 显微镜 Microscope 电子称 Balance DC 导通测试机 Cable Tester 推/拉力计 Pull/Push Instrument PI 检 验 结 果 Checked Result 块规 Block Gauge DM 扭力计 Torque Driver 投影仪 Projection Instrument 检验数量 Checked Q'ty 检验批箱号 Cartons No. 线别负责人 Producer 检验样品实测值 Sampling Check Data 14 5 无短数/有标识 N/A PASS FR-QP24-003-A0 游标卡尺 Vernier Caliper

RF Test Data Report No.: EFTA25110018-IE-02-R4-ANNEX G Eurofins TA Technology (Shanghai) Co., Ltd. Page 1 of 5 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Radiated Spurious Emission Sweep the whole frequency band through the range from 9kHz to the 10th harmonic of the carrier, the emissions below the noise floor will not be recorded in the report. Because the Margin is relatively large, only one worst point is recorded in the report. Radiated measurements are performed by rotating the EUT in three different orthogonal test planes. EUT stand-up position (Z axis), lie-down position (X, Y axis). Receiver antenna polarization (Horizontal and Vertical). The worst-case configuration and its corresponding results are documented in the test report. LTE X axis, Vertical polarization After the pretest, External Antenna was selected as the worst Antenna for WWAN. External Antenna LTE Band 2 CH-Middle Band width Harmonic Frequency (MHz) SG (dBm) Cable Loss (dB) Gain (dBi) Antenna Polarization Result Level (dBm) Limit (dBm) Margin (dB) Azimuth (deg) 5MHz 2 3755.63 -- -- -- -- -- -- -- -- 3 5633.63 -- -- -- -- -- -- -- -- 4 7511.00 -- -- -- -- -- -- -- -- 5 9389.50 -33.54 4.30 11.10 Vertical -26.74 -13.00 13.74 96 6 11265.00 -- -- -- -- -- -- -- -- 7 13142.00 -- -- -- -- -- -- -- -- 8 15020.00 -- -- -- -- -- -- -- -- 9 16897.50 -- -- -- -- -- -- -- -- 10 18800.00 -- -- -- -- -- -- -- -- Note: 1. The other Spurious RF Radiated emissions level is no more than noise floor. 2. The worst emission was found in the antenna is Vertical position. RF Test Data Report No.: EFTA25110018-IE-02-R4-ANNEX G Eurofins TA Technology (Shanghai) Co., Ltd. Page 2 of 5 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. LTE Band 4 CH-Middle Band width Harmonic Frequency (MHz) SG (dBm) Cable Loss (dB) Gain (dBi) Antenna Polarization Result Level (dBm) Limit (dBm) Margin (dB) Azimuth (deg) 5MHz 2 3460.50 -46.69 2.70 12.70 Vertical -36.69 -13.00 23.69 154 3 5191.50 -43.09 3.20 12.50 Vertical -33.79 -13.00 20.79 36 4 6930.00 -56.91 4.20 11.80 Vertical -49.31 -13.00 36.31 175 5 8651.60 -34.98 4.40 12.50 Vertical -26.88 -13.00 13.88 99 6 10380.00 -- -- -- -- -- -- -- -- 7 12110.00 -- -- -- -- -- -- -- -- 8 13840.00 -- -- -- -- -- -- -- -- 9 15570.00 -- -- -- -- -- -- -- -- 10 17300.00 -- -- -- -- -- -- -- -- Note: 1. The other Spurious RF Radiated emissions level is no more than noise floor. 2. The worst emission was found in the antenna is Vertical position. LTE Band 5 CH-Middle Band width Harmonic Frequency (MHz) SG (dBm) Cable Loss (dB) Gain (dBi) Antenna Polarization Result Level (dBm) Limit (dBm) Margin (dB) Azimuth (deg) 5MHz 2 1668.65 -45.48 1.70 8.70 Vertical -40.63 -13.00 27.63 45 3 2503.10 -30.98 2.30 12.00 Vertical -23.43 -13.00 10.43 135 4 3337.50 -50.11 2.70 12.70 Vertical -42.26 -13.00 29.26 NA 5 4171.88 -22.60 3.00 12.50 Vertical -15.25 -13.00 2.25 NA 6 5006.25 -44.67 3.40 12.50 Vertical -37.72 -13.00 24.72 NA 7 5840.63 -31.86 3.40 12.80 Vertical -24.61 -13.00 11.61 NA 8 6675.00 -51.79 4.10 11.50 Vertical -46.54 -13.00 33.54 NA 9 7509.38 -40.58 4.20 12.20 Vertical -34.73 -13.00 21.73 NA 10 8343.75 -50.98 4.30 12.50 Vertical -44.93 -13.00 31.93 96 Note: 1. The other Spurious RF Radiated emissions level is no more than noise floor. 2. The worst emission was found in the antenna is Vertical position. RF Test Data Report No.: EFTA25110018-IE-02-R4-ANNEX G Eurofins TA Technology (Shanghai) Co., Ltd. Page 3 of 5 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. LTE Band 12 CH-Middle Band width Harmonic Frequency (MHz) SG (dBm) Cable Loss (dB) Gain (dBi) Antenna Polarization Result Level (dBm) Limit (dBm) Margin (dB) Azimuth (deg) 5MHz 2 1410.53 -55.00 1.70 8.70 Vertical -50.15 -13.00 37.15 90 3 2116.13 -36.89 2.10 11.10 Vertical -30.04 -13.00 17.04 45 4 2821.53 -67.49 2.30 13.10 Vertical -58.84 -13.00 45.84 135 5 3525.00 -35.20 2.60 12.70 Vertical -27.25 -13.00 14.25 135 6 4232.00 -- -- -- -- -- -- -- -- 7 4935.00 -- -- -- -- -- -- -- -- 8 5640.00 -- -- -- -- -- -- -- -- 9 6345.00 -- -- -- -- -- -- -- -- 10 7050.00 -- -- -- -- -- -- -- -- Note: 1. The other Spurious RF Radiated emissions level is no more than noise floor. 2. The worst emission was found in the antenna is Vertical position. LTE Band 13 CH-Middle Band width Harmonic Frequency (MHz) SG (dBm) Cable Loss (dB) Gain (dBi) Antenna Polarization Result Level (dBm) Limit (dBm) Margin (dB) Azimuth (deg) 5MHz 2 1559.41 -71.24 1.70 8.70 Vertical -64.24 -40.00 24.24 22 3 2339.40 -46.64 2.10 12.00 Vertical -38.89 -13.00 25.89 17 4 3118.00 -- -- -- -- -- -- -- -- 5 3897.50 -52.27 2.90 12.50 Vertical -44.82 -13.00 31.82 12 6 4677.00 -- -- -- -- -- -- -- -- 7 5456.50 -- -- -- -- -- -- -- -- 8 6236.00 -- -- -- -- -- -- -- -- 9 7265.60 -- -- -- -- -- -- -- -- 10 7795.00 -- -- -- -- -- -- -- -- Note: 1. The other Spurious RF Radiated emissions level is no more than noise floor. 2. The worst emission was found in the antenna is Vertical position. RF Test Data Report No.: EFTA25110018-IE-02-R4-ANNEX G Eurofins TA Technology (Shanghai) Co., Ltd. Page 4 of 5 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. LTE Band 14 CH-Middle Band width Harmonic Frequency (MHz) SG (dBm) Cable Loss (dB) Gain (dBi) Antenna Polarization Result Level (dBm) Limit (dBm) Margin (dB) Azimuth (deg) 5MHz 2 1581.72 -65.06 1.70 8.70 Vertical -60.21 -40.00 20.21 64 3 2372.59 -52.61 2.30 12.00 Vertical -45.06 -13.00 32.06 108 4 3162.00 -- -- -- -- -- -- -- -- 5 3952.50 -- -- -- -- -- -- -- -- 6 4743.00 -- -- -- -- -- -- -- -- 7 5533.50 -- -- -- -- -- -- -- -- 8 6324.00 -51.56 3.80 11.50 Vertical -46.01 -13.00 33.01 76 9 7114.50 -- -- -- -- -- -- -- -- 10 7905.00 -- -- -- -- -- -- -- -- Note: 1. Th…

Text truncated - open the document above for the full version.

Test Result Report No.: EFTA25110018-IE-02-R3-ANNEX A Eurofins TA Technology (Shanghai) Co., Ltd. Page 1 of 18 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. ANNEX A: Test Result The radiated emission was measured in the following position: EUT stand-up position (Z axis), lie-down position (X, Y axis). The worst emission was found in lie-down position (X axis) and the loop antenna is vertical, the others are vertical and horizontal. and the worst case was recorded. Test Result Report No.: EFTA25110018-IE-02-R3-ANNEX A Eurofins TA Technology (Shanghai) Co., Ltd. Page 2 of 18 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. 1. Unwanted Emission 1.1. SUB-G The following graphs display the maximum values of horizontal and vertical by software. Blue trace uses the peak detection, Green trace uses the average detection. A symbol () in the test plot below means (dBμV/m) The signal beyond the limit is carrier. Internal Antenna Channel 1: Peak + Average 0 10 20 30 40 50 60 70 80 90 100 110 120 590 650 700 750 800 850 900 950 970 Level in dB 礦 /m Frequency in MHz FCC RE QP 599.975000 MHz 32.103 dB礦/m 968.328000 MHz 31.799 dB礦/m Channel 6: Peak + Average 0 10 20 30 40 50 60 70 80 90 100 110 120 590 650 700 750 800 850 900 950 970 Level in dB 礦 /m Frequency in MHz FCC RE QP 599.975000 MHz 30.199 dB礦/m 968.062000 MHz 31.808 dB礦/m Channel 12: Peak + Average 0 10 20 30 40 50 60 70 80 90 100 110 120 590 650 700 750 800 850 900 950 970 Level in dB 礦 /m Frequency in MHz FCC RE QP 599.937000 MHz 33.285 dB礦/m 964.319000 MHz 35.709 dB礦/m Test Result Report No.: EFTA25110018-IE-02-R3-ANNEX A Eurofins TA Technology (Shanghai) Co., Ltd. Page 3 of 18 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. External Antenna Channel 1: Peak + Average 0 10 20 30 40 50 60 70 80 90 100 110 120 590 650 700 750 800 850 900 950 970 Level in dB 礦 /m Frequency in MHz FCC RE QP 599.975000 MHz 31.561 dB礦/m 963.597000 MHz 32.070 dB礦/m Channel 6: Peak + Average 0 10 20 30 40 50 60 70 80 90 100 110 120 590 650 700 750 800 850 900 950 970 Level in dB 礦 /m Frequency in MHz FCC RE QP 599.956000 MHz 30.979 dB礦/m 965.535000 MHz 32.250 dB礦/m Channel 12: Peak + Average 0 10 20 30 40 50 60 70 80 90 100 110 120 590 650 700 750 800 850 900 950 970 Level in dB 礦 /m Frequency in MHz FCC RE QP 599.994000 MHz 32.552 dB礦/m 964.319000 MHz 34.663 dB礦/m Test Result Report No.: EFTA25110018-IE-02-R3-ANNEX A Eurofins TA Technology (Shanghai) Co., Ltd. Page 4 of 18 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Result of RE Sweep the whole frequency band through the range from 9kHz to the 10th harmonic of the carrier. The Radiates Emission from 9kHz to 30MHz and 18GHz to 26.5GHz are more than 20dB below the limit are not reported. Remark: 1. Correction Factor = Antenna factor + Insertion loss (cable loss + amplifier gain) 2. Margin = Limit – Quasi-Peak/ MAX Peak/ Average 3. The following graphs display the maximum values of horizontal and vertical by software. 4. For below 1GHz QP Level @Spectrum Overview H QP Level @Spectrum Overview V QP Level @Final Results QP Limit For above 1GHz PK Level @Spectrum Overview H PK Level @Spectrum Overview V PK Level @Final Results PK Limit AVG Level @Spectrum Overview H AVG Level @Spectrum Overview V AVG Level @Final Results AVG Limit Continuous TX mode: During the test, the Radiates Emission from 30MHz to 1GHz was performed in all modes with all channels. The test data of the worst-case condition was recorded in this report. Internal Antenna Channel 1 Test Result Report No.: EFTA25110018-IE-02-R3-ANNEX A Eurofins TA Technology (Shanghai) Co., Ltd. Page 5 of 18 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Radiates Emission from 30MHz to 1GHz Test Result Report No.: EFTA25110018-IE-02-R3-ANNEX A Eurofins TA Technology (Shanghai) Co., Ltd. Page 6 of 18 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Frequency (MHz) MaxPeak (dBμV/m) Average (dBμV/m) Limit (dBμV/m) Margin (dB) Duty cycle Factor Final Margin (dB) Meas. Time (ms) Height (cm) Pol Azimuth (deg) Corr. (dB/m) 1199.13 --- 27.49 54.00 26.51 0.5 6.02 32.53 500.00 200.0 V 148.00 -15 1448.88 37.17 --- 74.00 36.83 0.5 6.02 42.85 500.00 100.0 H 106.00 -14 1806.63 56.79 --- 74.00 17.21 0.5 6.02 23.23 500.00 100.0 V 124.00 -13 1807.75 --- 53.21 54.00 0.79 0.5 6.02 6.81 500.00 100.0 V 124.00 -13 2711.13 60.07 --- 74.00 13.93 0.5 6.02 19.95 500.00 100.0 V 319.00 -9 2712.25 --- 54.81 54.00 -0.81 0.5 6.02 5.21 500.00 100.0 V 319.00 -9 3616.75 52.66 --- 74.00 21.34 0.5 6.02 27.36 500.00 200.0 V 334.00 -7 3616.75 --- 46.49 54.00 7.51 0.5 6.02 13.53 500.00 200.0 V 334.00 -7 4521.25 60.29 --- 74.00 13.71 0.5 6.02 19.73 500.00 200.0 V 354.00 -4 4521.25 --- 53.50 54.00 0.50 0.5 6.02 6.52 500.00 200.0 V 354.00 -4 6326.88 --- 51.31 54.00 2.69 0.5 6.02 8.71 500.00 200.0 H 270.00 0 6326.88 58.27 --- 74.00 15.73 0.5 6.02 21.75 500.00 200.0 H 270.00 0 Note: Factor = 20 log (1/ Duty cycle) = 6.02 Final Margin = Margin + Factor Note: The signal beyond the limit is carrier. Radiates Emission from 1GHz to 10GHz Test Result Report No.: EFTA25110018-IE-02-R3-ANNEX A Eurofins TA Technology (Shanghai) Co., Ltd. Page 7 of 18 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Channel 6 Radiates Emission from 30MHz to 1GHz Test Result Report No.: EFTA25110018-IE-02-R3-ANNEX A Eurofins TA Technology (Shanghai) Co., Ltd. Page 8 of 18 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) C…

Text truncated - open the document above for the full version.

Prepared by: Xu Ying Approved by: Xu Kai Eurofins TA Technology (Shanghai) Co., Ltd. Building 3, No.145, Jintang Rd, Pudong Shanghai, P.R.China TEL: +86-021-50791141/2/3 FAX: +86-021-50791141/2/3-8000 RF TEST REPORT Applicant MOONS' Electric (Taicang) co., Ltd. FCC ID 2BRS4-PG126173 Product Wireless Gateway Brand MOONS' Model MSPG126173 Report No. EFTA25110018-IE-02-R3 Issue Date November 25, 2025 Eurofins TA Technology (Shanghai) Co., Ltd. tested the above equipment in accordance with the requirements in FCC CFR47 Part 15C (2025). The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. RF Test Report Report No.: EFTA25110018-IE-02-R3 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-04-005R Page 2 of 52 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. TABLE OF CONTENT 1. Test Laboratory ............................................................................................................................... 4 1.1. Notes of the Test Report ......................................................................................................... 4 1.2. Test Facility ............................................................................................................................. 4 1.3. Testing Location ...................................................................................................................... 4 2. General Description of Equipment Under Test ............................................................................... 5 2.1. Applicant and Manufacturer Information ................................................................................ 5 2.2. General Information ................................................................................................................ 5 3. Applied Standards ........................................................................................................................... 6 4. Test Configuration ........................................................................................................................... 7 5. Test Case ........................................................................................................................................ 8 5.1. Maximum output power .......................................................................................................... 8 5.2. 99% Bandwidth and 6dB Bandwidth ...................................................................................... 9 5.3. Band Edge ............................................................................................................................ 10 5.4. Power Spectral Density ........................................................................................................ 11 5.5. Spurious RF Conducted Emissions ...................................................................................... 13 5.6. Unwanted Emission .........................................................…
