2BRY3-GA5000Magnetic Power Bank

5000 mAh Magnetic Power Bank USER MANUAL CAUTION: Risk of Fire and Burns. Do Not Open, Crush, Heat Above(45) or Incinerate. Follow Manufacturer’s Instructions. Model NO.: GA5000 Please read this User Manual carefully before using the product and keep it property Product parameter Name: Magnetic Power Bank Model No.: GA5000 Battery Type: Lithium Polymer Material: ABS + PC Battery capacity: 5000mAh (3.85V 19.25Wh) Rated capacity: 3000mAh (5VDC, 2A) Energy conversion: ≥ 60% USB-C port input: 5VDC, 3A USB-C port output: 5VDC, 3A USB-C wire output: 5VDC, 3A Watch wireless charging output: 5W Total output: 5VDC, 3A (15W Max.) Product size: 134x57x17 mm 5.28x2.24x0.67 inch Net weight: 122g/4.30oz Product description: Checking quantity of electricity: Charging the power bank: Charging Your Device Wirelessly and Recharging Your Portable Charger Simultaneously This product is a portable charging device that can provide wired charging and wireless charging for iwatch, mobile phones, tablets, e-books, game machines and other famous products. The product has the characteristics of wired charging and wireless charging in one, magnetic suction positioning, power digital display, supports 15W standard fast charging, two output, etc. Product built-in FOD, overcharge, over discharge, temperature protection and other safety protection circuit. Connect the Type-C charging cable to the corresponding output port of the power bank, and the power bank will automatically turn on the output. Due to compatibility, some smartphones need to press the button to turn on the power output function, which is a normal phenomenon and need not be ignored. Press the key once to supply power to the external equipment. Please read all instructions and warnings before using this product. Improper use will damage the product or personal safety. 1. This product has an over-current protection function. If the product is used improperly, it will turn o or reduce the output power, reduce the charging speed and ensure safety. Please check whether the equipment is used improperly or not. 2. Do not let children use alone under 12 year, especially the accessories. 3. Please use a dry soft cloth to clean the surface. Do not use chemicals, soap or detergent. 4. Please don't dismantle the machine by yourself. The user's abnormal use or improper placement of this product may reduce the service life or damage the product. Therefore, the responsibility does not belong to the warranty responsibility or the manufacturer's responsibility. Please understand. 5. There is a conversion rate in the power bank, so the battery capacity of the power bank is not equal to the rechargeable capacity. 6. Please charge your power bank regularly (at least 5 months is recommended) to maintain its long service life. 7. Improper use of the product may easily result in the product itself or endanger the safety of personal and property. 8. If consumers violate the product manual and improperly apply or use, the personal and property damage caused by consumers and the company will not bear any legal responsibility. 9. Non-professionals are strictly prohibited to decompose this product. 10. Avoid using electrical appliances or loads that exceed the output current of the product (the circuit will be protected, no output). 11. Avoid strong physical eects, including knocking, throwing, trampling, squeezing, etc. Misuse, dropping, or excessive force may cause product damage. 12. Store the product in a cool, dry place. Do not store the product in a hot or humid environment. Do not dispose of the product in heat or re. 13. Use of a power supply or charger not recommended or sold by the product manufacturer may result in a risk of re or injury to persons. 14. Operating temperature should be between 0°C to 45°C/32°F to 113°F 15. Storage Temperature range: -10 to 60°C 16. When disposing of secondary cells or batteries, keep cells or batteries of dierent electrochemical systems separate from each other. Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interfer ence in which case the user will be required to correct the interference at his own expense. measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. Note: The Grantee is not responsible for any changes or modications not expressly approved by the party responsible for compliance. such modications could void the user's authority to operate the equipment. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. INSTRUCTIONS PERTAINING TO RISK OF FIRE OR INJURY TO PERSONS IMPORTANT SAFETY INSTRUCTIONS WARNING-When using this product, basic precautions should always be followed. including the following: a) Read all the instructions before using the product. b) To reduce the risk of injury, close supervision is necessary when the product is used near children. c) Do not put ngers or hands into the product. d) Do not expose…

Text truncated - open the document above for the full version.

Huizhou Huiyang Shunxuan Technology Co., Ltd. No. 397, Qiubao Road, Xintang Village, Qiuchang Street, Huiyang District, Huizhou GuangDong , China Date: 10-28-2025 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2BRY3-GA5000 FRN: 0037458460 US Agent – Attestation Statement / Part 2.911(d)(7) Huizhou Huiyang Shunxuan Technology Co., Ltd. certifies, that as of 10-28-2025, we have designated FCC US Agent, LLC to accept service of process on our behalf for FCC ID: 2BRY3-GA5000 Huizhou Huiyang Shunxuan Technology Co., Ltd., accepts to maintain an agent of service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. FCC US Agent, LLC, accepts as of the date of the filing of this application, the obligation of being the designated agent for the purpose of accepting service of process on behalf of Huizhou Huiyang Shunxuan Technology Co., Ltd. for FCC ID: 2BRY3-GA5000 Designated Agent Information: Company Name: FCC US Agent, LLC FRN: 0033402884 Address: 3722 Illinois Avenue, Saint Charles, IL, 60174, USA Contact Person: Tim Payne Phone: 708-571-3148 Email: [email protected] Sincerely, Huizhou Huiyang Shunxuan Technology Co., Ltd. Designated Agent: FCC US Agent, LLC Company Representative: Xiaoqiang Yang Designated Agent Representative: Tim Payne Signature: Signature:

Huizhou Huiyang Shunxuan Technology Co., Ltd. Date: 10‐16‐2025 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for FCC ID:2BRY3‐GA5000 [Huizhou Huiyang Shunxuan Technology Co., Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, the equipment does not utilize cyber‐security or anti‐virus software from Kaspersky Lab, Inc, or any of its successors and assignees, which is also on the “covered list”. Sincerely, Xiaoqiang Yang (Applicant printed name) Huizhou Huiyang Shunxuan Technology Co., Ltd. Date: 10‐16‐2025 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for FCC ID:2BRY3‐GA5000 [Huizhou Huiyang Shunxuan Technology Co., Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Xiaoqiang Yang (Applicant printed name)

Huizhou Huiyang Shunxuan Technology Co., Ltd. FCC ID: 2BRY3-GA5000 POWER OF ATTORNEY Date: oct. 16, 2025 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern: We, the undersigned, hereby authorize Waltek Testing Group Co., Ltd. (Deval Qin) on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Waltek Testing Group Co., Ltd. (Deval Qin) on our behalf shall have the same effect as acts of our own. This authorization expires on oct. 15, 2026. Sincerely, Huizhou Huiyang Shunxuan Technology Co., Ltd. Signature Xiaoqiang Yang/ General Manager Typed name and Title

Huizhou Huiyang Shunxuan Technology Co., Ltd. Date: Oct. 16, 2025 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2BRY3-GA5000 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Long-term confidentiality: Schematics Block Diagram Operational Description Schematics.pdf Block Diagram.pdf Operational Description.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Huizhou Huiyang Shunxuan Technology Co., Ltd. Signature Xiaoqiang Yang/ General Manager Typed name and Title

Huizhou Huiyang Shunxuan Technology Co., Ltd. FCC ID: 2BRY3-GA5000 Date: 10/27/2025 Subject: authorization for adding family models To whom it May concern, Statement We confirm the product Magnetic Power Bank with models GA5000, GA06, GA08, GA10, GA30 are same in the Schematic, PCB layout, Operation description, BOM and Antenna. Only the model name is different. Yours sincerely, [signature] Xiaoqiang Yang General Manager Huizhou Huiyang Shunxuan Technology Co., Ltd.

Appendix-GA5000-Photos Page 4 of 12 2. Photographs –Constructional Details 2.1. EUT – External View Model GA5000 FCC ID: 2BRY3-GA5000 Appendix-GA5000-Photos Page 5 of 12 Appendix-GA5000-Photos Page 6 of 12 Appendix-GA5000-Photos Page 7 of 12

Name: Magnetic Power Bank Model No.: GA5000 Battery Type: Lithium PolymerUSB-C wire output: 5VDC, 3A USB-C port input: 5VDC, 3AUSB-C port output: 5VDC, 3A Total output: 5VDC, 3A(15W Max) Watch wireless charging output: 5W Battery capacity: 5000mAh(3.85V 19.25Wh)Rated capacity: 3000mAh (5VDC,2A) Energy conversion: ≥ 60%Manufacturer: Huizhou Huiyang Shunxuan Technology Co., Ltd . Address: No.397, Qiubao Road, Xintang Village, Qiuchang Street, Huiyang District, Huizhou City,ChinaFCC ID 2BRY3-GA5000 CAUTION: Risk of Fire and Burns.Do Not Open, Crush, Heat Above(45 ) or Incinerate. Follow Manufacturer’s Instructions. Made in China

Appendix-GA5000-Photos Page 8 of 12 2.2. EUT – Internal View Model GA5000 FCC ID: 2BRY3-GA5000 Appendix-GA5000-Photos Page 9 of 12 Appendix-GA5000-Photos Page 10 of 12 Appendix-GA5000-Photos Page 11 of 12 Appendix-GA5000-Photos Page 12 of 12 ======End====== ANT

Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Page 1 of 13 TEST REPORT Reference No. .................... : WTD25D08227060W002 FCC ID ................................ : 2BRY3-GA5000 Applicant ............................ : Huizhou Huiyang Shunxuan Technology Co., Ltd. Address .............................. : No. 397, Qiubao Road, Xintang Village, Qiuchang Street, Huiyang District, Huizhou Guan gDong China Manufacturer .................... : Huizhou Huiyang Shunxuan Technology Co., Ltd. Address .............................. : No. 397, Qiubao Road, Xintang Village, Qiuchang Street, Huiyang District, Huizhou Guan gDong China Product ............................... : Magnetic Power Bank Model(s). ............................ : GA5000, GA06, GA08, GA10, GA30 Standards........................... : FCC 47CFR Part 1.1307 Date of Receipt Sample .... : 2025-08-27 Date of Test ....................... : 2025-09-02 to 2025-11-14 Date of Issue ...................... : 2025-11-18 Test Result ......................... : Pass Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the si gnatures of compiler and approver. Prepared By: Waltek Testing Group Co., Ltd. Address: No. 77, Houjie Section, Guantai Road, Houjie Town, Dongguan City, Guangdong, China Tel: +86-769-2267 6998 Fax: +86-769-2267 6828 Compiled by: Approved by: Frank Yin / Project Engineer Deval Qin / Designated Reviewer Reference No.: WTD25D08227060W002 Page 2 of 13 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn 2 Contents Page 1 COVER PAGE ........................................................................................................................................... 1 2 CONTENTS ............................................................................................................................................... 2 3 REVISION HISTORY ................................................................................................................................. 3 4 GENERAL INFORMATION ....................................................................................................................... 4 4.1 GENERAL DESCRIPTION OF E.U.T ................................................................................................... 4 4.2 DETAILS OF ACCESSORIES ............................................................................................................... 4 4.3 TEST FACILITY ................................................................................................................................ 5 4.4 SUBCONTRACTED ........................................................................................................................... 5 4.5 ABNORMALITIES FROM STANDARD CONDITIONS ................................................................................ 5 4.6 TEST MODE .................................................................................................................................... 6 5 TEST SUMMARY ...................................................................................................................................... 7 6 EQUIPMENT USED DURING TEST ......................................................................................................... 8 6.1 EQUIPMENTS LIST ........................................................................................................................... 8 6.2 DESCRIPTION OF AUXILIARY EQUIPMENT .......................................................................................... 8 6.3 TEST EQUIPMENT CALIBRATION ....................................................................................................... 8 7 RF EXPOSURE ......................................................................................................................................... 9 7.1 EUT OPERATION ............................................................................................................................ 9 7.2 TEST SETUP ................................................................................................................................... 9 7.3 FIELD STRENGTH MEASUREMENTS ................................................................................................ 10 7.4 MATHEMATICAL MODEL .................................................................................................................. 10 7.5 FCC RULES.................................................................................................................................. 11 7.6 TEST RESULT ............................................................................................................................... 12 8 PHOTOGRAPHS OF TEST SETUP ....................................................................................................... 13 Reference No.: WTD25D08227060W002 Page 3 of 13 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn 3 Revision History Test Report No. Date of Receipt Sample Date of Test Date of Issue Purpose CommentApproved WTD25D08227060W002 2025-08-27 2025-09-02 to 2025-11-14 2025-11-18 Original - Valid Reference No.: WTD25D08227060W002 Page 4 of 13 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn 4 General Information 4.1 General Description of E.U.T Product: Magnetic Power Bank Model(s): GA5000, GA06, GA08, GA10, GA30 Model Description: Only the model name is different. Model GA5000 was tested in this report. Test Sample No.: 1-1/1 Type of Modulation: ASK Frequency Range: 321-335kHz Antenna installation: Inductive loop coil Antenna Hardware Version: ZL-038mini-V1.1 Software Version: ZL-038mini-V1.1 4.2 Details of accessories Ratings: Battery capacity: 5000mAh (3.85V 19.25Wh) Rated capacity: 3000mAh (5VDC, 2A) USB-C input: 5VDC, 3A USB-C output: 5VDC, 3A US…

Text truncated - open the document above for the full version.

惠州启泰电子科技有限公司 HuizhouQitaiElectronicTechnologyCo.,LTD SPECIFICATIONSSHEET CUSTOMER: 客户 DESCRIPTION: 品名描述 CUSTOMERP/N: 客户品名 PARTNUMBER: 制造商料号 DATEOFAPPLICATION: 提出日期 金天下 2025-9-18 CLASSIFICATIONOFSPEC.PRESENTATION.(Ticktherelevantbox"√") oNewapplication新规格 √Newpartisaddedtoacceptedspecification新产品规格追加记录 oRevisionofacceptedspecification既存规格图面变更 ACCEPTANCESTAMP() APPROVALBY 承认 CHECKBY 审查 PREPAREBY 制作 ADDRESS:3rdFloor,No.181,Mingyue2ndRoad,ShiwanTown,BoluoCounty,Huizhoucity TELPHONE:0752-6668681 E-MAIL:[email protected] 惠州启泰电子科技有限公司 HuizhouQitaiElectronicTechnologyCo.,LTD HistoryForRevisedSpecification CUSTOMERP/N: 客户品名 PARTNUMBER: 制造商料号 Item 项次 DESCRIPTION(ContentOrReasonForChanged) 变更内容 Rev. 版本 CustRev. 客户版本 Date 日期 Revisor 修订者 1 InitialRelease(初版发行) A0 2025-9-18 冯欣 APPROVEDBY 承认 CHECKEDBY 审查 PREPAREDBY 制作 DATE 日期 PAGE 页码 晁子奇 冯欣 2025-9-18 1of3 惠州启泰电子科技有限公司 HuizhouQitaiElectronicTechnologyCo.,LTD Specification 规格内容 CUSTOMERP/N: 客户品名 PARTNUMBER: 制造商料号 1.DIMENSIONS():(Unit:mm) 单位（Unit）：毫米（mm） ABCDEFGH 24.5±0.523.5±0.514.5±0.57.5±0.22±1 2.7ma 70±2 x 2.2±0.1 1.背胶为白色背胶，φ18.0。 2.磁铁规格：φ7.5*2.2，磁场3400GS。 3. 带两根77mm左右φ0.8热缩套管。 4.手表为苹果手表软磁W142。 APPROVEDBY 承认 CHECKEDBY 审查 PREPAREDBY 制作 DATE 日期 PAGE 页码 2025-9-18 2of3 惠州启泰电子科技有限公司 HuizhouQitaiElectronicTechnologyCo.,LTD Specification 规格内容 CUSTOMERP/N: 客户品名 PARTNUMBER: 制造商料号 2.WINDINGDETAILS(绕线详细说明) Coil1 圈数 Turns 线径 WireDia 绕线方式疏/密 Wdg.Type Spred/Close 绕线方向 Wdg.Direction 相交是/否 Intersect Yes/Not 13TS 0.08*24P热风绞线(HotAir strandedWire) 密绕（Close） 逆绕 是（Yes） 3.电气特性（ELECTRICALCHARACTERISTICS）: 温度TEMPERATURE:25±10,RELATIVEHUMIDITY:6510% 序号 NO. 项目 ITEM 端子 TERMINAL 标准 SPECIFICATION 测试条件 TESTFREQUENCY 测试仪器 TESTEQUIPMENTS Coil1 1.INDS-F 7.8uh±0.3uh 100kHz/VUC2906A 2. QS-F 20Min 100kHz/VUC2906A 3.DCRS-F 160Max 100kHz/VUC2906A APPROVEDBY 承认 CHECKEDBY 审查 PREPAREDBY 制作 DATE 日期 PAGE 页码 2025-9-18 3of3

Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Page 1 of 24 TEST REPORT Reference No. .................... : WTD25D08227060W001 FCC ID ................................ : 2BRY3-GA5000 Applicant ............................ : Huizhou Huiyang Shunxuan Technology Co., Ltd. Address .............................. : No. 397, Qiubao Road, Xintang Village, Qiuchang Street, Huiyang District, Huizhou GuangDong China Manufacturer .................... : Huizhou Huiyang Shunxuan Technology Co., Ltd. Address .............................. : No. 397, Qiubao Road, Xintang Village, Qiuchang Street, Huiyang District, Huizhou GuangDong China Product ............................... : Magnetic Power Bank Model(s). ............................ : GA5000, GA06, GA08, GA10, GA30 Standards........................... : FCC CFR47 Part 15C Date of Receipt Sample .... : 2025-08-27 Date of Test ....................... : 2025-09-02 to 2025-11-14 Date of Issue ...................... : 2025-11-18 Test Result ......................... : Pass Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Prepared By: Waltek Testing Group Co., Ltd. Address: No. 77, Houjie Section, Guantai Road, Houjie Town, Dongguan City, Guangdong, China Tel: +86-769-2267 6998 Fax: +86-769-2267 6828 Compiled by: Approved by: Frank Yin / Pro ject Engineer Deval Qin / Designated Reviewer Reference No.: WTD25D08227060W001 Page 2 of 24 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn 2 Contents Page 1 COVER PAGE ........................................................................................................................................... 1 2 CONTENTS ............................................................................................................................................... 2 3 REVISION HISTORY ................................................................................................................................. 3 4 GENERAL INFORMATION ....................................................................................................................... 4 4.1 GENERAL DESCRIPTION OF E.U.T ................................................................................................... 4 4.2 DETAILS OF ACCESSORIES ............................................................................................................... 4 4.3 TEST MODE .................................................................................................................................... 5 4.4 TEST FACILITY ................................................................................................................................ 5 5 TEST SUMMARY ...................................................................................................................................... 6 6 EQUIPMENT USED DURING TEST ......................................................................................................... 7 6.1 EQUIPMENTS LIST ........................................................................................................................... 7 6.2 DESCRIPTION OF SUPPORT UNITS ................................................................................................... 8 6.3 MEASUREMENT UNCERTAINTY ......................................................................................................... 8 6.4 TEST EQUIPMENT CALIBRATION ....................................................................................................... 8 7 CONDUCTED EMISSION ......................................................................................................................... 9 7.1 EUT OPERATION ............................................................................................................................ 9 7.2 EUT SETUP .................................................................................................................................... 9 7.3 MEASUREMENT DESCRIPTION .......................................................................................................... 9 7.4 CONDUCTED EMISSION TEST RESULT ............................................................................................ 10 8 RADIATED SPURIOUS EMISSIONS ..................................................................................................... 12 8.1 EUT OPERATION .......................................................................................................................... 12 8.2 TEST SETUP ................................................................................................................................. 13 8.3 SPECTRUM ANALYZER SETUP ........................................................................................................ 14 8.4 TEST PROCEDURE ........................................................................................................................ 14 8.5 CORRECTED AMPLITUDE & MARGIN CALCULATION ......................................................................... 14 8.6 SUMMARY OF TEST RESULTS ........................................................................................................ 15 9 BANDWIDTH MEASUREMENT ............................................................................................................. 23 9.1 TEST PROCEDURE ........................................................................................................................ 23 9.2 TEST RESULT ............................................................................................................................... 23 10 ANTENNA REQUIREMENT ................................................................................................................... 24 11 RF EXPOSURE …

Text truncated - open the document above for the full version.

Appendix-GA5000-Photos Page 1 of 12 1. Test Setup photos Model GA5000 FCC ID: 2BRY3-GA5000 1.1 Photograph – Conducted Emission For Conducted Emission Test Site 1# 1.2 Photograph – Radiated Emissions For 9kHz-30MHz Test Site 2# Appendix-GA5000-Photos Page 2 of 12 For 30MHz-1000MHz Test Site 2# 1.3 Photograph – RF Exposure Appendix-GA5000-Photos Page 3 of 12
