2BSW8-W2CF3CSmart Phone

HONG KONG LELEGAO TECHNOLOGY CO.,LIMITED

Click to zoom

Application Details

Equipment Class: PCE - PCS Licensed Transmitter held to ear
Date of Grant: May 31, 2026
Application Purpose: Original Equipment
Equipment Note: Smart Phone
Frequency Range: 699.70000000 - 715.30000000
Company: HONG KONG LELEGAO TECHNOLOGY CO.,LIMITED
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Mobile Phone This device was tested for typical body-worn operations. To comply with RF exposure requirements, a minimum separation distance of 10mm must be maintained between the user’s limbs and the handset, including the antenna. Third-party belt-clips, holsters, and similar accessories used by this device should not contain any metallic components. Body- worn accessories that do not meet these requirements may not comply with RF exposure requirements and should be avoided. Use only the supplied or an approved antenna. Mobile Phone radios are also set to their highest transmission levels and placed in positions that simulate uses against the Limbs, with no separation. Ce dispositif a été testé pour les opérations typiques portées sur le corps. Pour se conformer à l'exposition RF une distance de séparation minimale de 10 mm doit être maintenue entre les les membres et le téléphone, y compris l'antenne. Clips à ceinture, bo?tiers et similaires de tiers Les accessoires utilisés par ce dispositif ne doivent pas contenir de composants métalliques. Porté par le corps les accessoires qui ne répondent pas à ces exigences peuvent ne pas être conformes à l'exposition aux RF exigences et doivent être évitées. Utilisez uniquement l'antenne fournie ou approuvée. Les radios de téléphone mobile sont également réglées à leurs niveaux de transmission les plus élevés et placées dans des positions qui simulent les utilisations contre les membres, sans séparation. Mobile Phone radios are also set to their highest transmission levels and placed in positions that simulate uses against the Limbs, with no separation. Les radios de téléphonie Mobile sont également réglées à leurs niveaux de transmission les plus élevés et placées dans des positions qui simulent des utilisations contre les membres, sans séparation. E-label viewing steps Settings - About Phone - Regulatory Information Label

Users Manual

Mobile Phone This device was tested for typical body-worn operations. To comply with RF exposure requirements, a minimum separation distance of 10mm must be maintained between the user’s body and the handset, including the antenna. Third-party belt-clips, holsters, and similar accessories used by this device should not contain any metallic components. Body-worn accessories that do not meet these requirements may not comply with RF exposure requirements and should be avoided. Use only the supplied or an approved antenna. Mobile Phone radios are also set to their highest transmission levels and placed in positions that simulate uses against the Limbs, with no separation. Ce dispositif a été testé pour les opérations typiques portées sur le corps. Pour se conformer à l'exposition RF une distance de séparation minimale de 10 mm doit être maintenue entre les les membres et le téléphone, y compris l'antenne. Clips à ceinture, bo?tiers et similaires de tiers Les accessoires utilisés par ce dispositif ne doivent pas contenir de composants métalliques. Porté par le corps les accessoires qui ne répondent pas à ces exigences peuvent ne pas être conformes à l'exposition aux RF exigences et doivent être évitées. Utilisez uniquement l'antenne fournie ou approuvée. Les radios de téléphone mobile sont également réglées à leurs niveaux de transmission les plus élevés et placées dans des positions qui simulent les utilisations contre les membres, sans séparation. Mobile Phone radios are also set to their highest transmission levels and placed in positions that simulate uses against the Limbs, with no separation. Les radios de téléphonie Mobile sont également réglées à leurs niveaux de transmission les plus élevés et placées dans des positions qui simulent des utilisations contre les membres, sans séparation. E-label viewing steps Settings - About Phone - Regulatory Information Label

Test Report

Report No.: STS2604021W01_Appendix LTE 151 Band4 QPSK BW=1.4MHz Channel=20175 RB Size=6 Position=#0 Band4 QPSK BW=1.4MHz Channel=20393 RB Size=6 Position=#0 Report No.: STS2604021W01_Appendix LTE 152 Band4 QPSK BW=10MHz Channel=20000 RB Size=50 Position=#0 Band4 QPSK BW=10MHz Channel=20175 RB Size=50 Position=#0 Report No.: STS2604021W01_Appendix LTE 153 Band4 QPSK BW=10MHz Channel=20350 RB Size=50 Position=#0 Band4 QPSK BW=15MHz Channel=20025 RB Size=75 Position=#0 Report No.: STS2604021W01_Appendix LTE 154 Band4 QPSK BW=15MHz Channel=20175 RB Size=75 Position=#0 Band4 QPSK BW=15MHz Channel=20325 RB Size=75 Position=#0 Report No.: STS2604021W01_Appendix LTE 155 Band4 QPSK BW=20MHz Channel=20050 RB Size=100 Position=#0 Band4 QPSK BW=20MHz Channel=20175 RB Size=100 Position=#0 Report No.: STS2604021W01_Appendix LTE 156 Band4 QPSK BW=20MHz Channel=20300 RB Size=100 Position=#0 Band4 QPSK BW=3MHz Channel=19965 RB Size=15 Position=#0 Report No.: STS2604021W01_Appendix LTE 157 Band4 QPSK BW=3MHz Channel=20175 RB Size=15 Position=#0 Band4 QPSK BW=3MHz Channel=20385 RB Size=15 Position=#0 Report No.: STS2604021W01_Appendix LTE 158 Band4 QPSK BW=5MHz Channel=19975 RB Size=25 Position=#0 Band4 QPSK BW=5MHz Channel=20175 RB Size=25 Position=#0 Report No.: STS2604021W01_Appendix LTE 159 Band4 QPSK BW=5MHz Channel=20375 RB Size=25 Position=#0 Band41 16QAM BW=10MHz Channel=39700 RB Size=50 Position=#0 Report No.: STS2604021W01_Appendix LTE 160 Band41 16QAM BW=10MHz Channel=40620 RB Size=50 Position=#0 Band41 16QAM BW=10MHz Channel=41540 RB Size=50 Position=#0 Report No.: STS2604021W01_Appendix LTE 161 Band41 16QAM BW=15MHz Channel=39725 RB Size=75 Position=#0 Band41 16QAM BW=15MHz Channel=40620 RB Size=75 Position=#0 Report No.: STS2604021W01_Appendix LTE 162 Band41 16QAM BW=15MHz Channel=41515 RB Size=75 Position=#0 Band41 16QAM BW=20MHz Channel=39750 RB Size=100 Position=#0 Report No.: STS2604021W01_Appendix LTE 163 Band41 16QAM BW=20MHz Channel=40620 RB Size=100 Position=#0 Band41 16QAM BW=20MHz Channel=41490 RB Size=100 Position=#0 Report No.: STS2604021W01_Appendix LTE 164 Band41 16QAM BW=5MHz Channel=39675 RB Size=25 Position=#0 Band41 16QAM BW=5MHz Channel=40620 RB Size=25 Position=#0 Report No.: STS2604021W01_Appendix LTE 165 Band41 16QAM BW=5MHz Channel=41565 RB Size=25 Position=#0 Band41 QPSK BW=10MHz Channel=39700 RB Size=50 Position=#0 Report No.: STS2604021W01_Appendix LTE 166 Band41 QPSK BW=10MHz Channel=40620 RB Size=50 Position=#0 Band41 QPSK BW=10MHz Channel=41540 RB Size=50 Position=#0 Report No.: STS2604021W01_Appendix LTE 167 Band41 QPSK BW=15MHz Channel=39725 RB Size=75 Position=#0 Band41 QPSK BW=15MHz Channel=40620 RB Size=75 Position=#0 Report No.: STS2604021W01_Appendix LTE 168 Band41 QPSK BW=15MHz Channel=41515 RB Size=75 Position=#0 Band41 QPSK BW=20MHz Channel=39750 RB Size=100 Position=#0 Report No.: STS2604021W01_Appendix LTE 169 Band41 QPSK BW=20MHz Channel=40620 RB Size=100 Position=#0 Band41 QPSK BW=20MHz Channel=41490 RB Size=100 Position=#0 Report No.: STS2604021W01_Appendix LTE 170 Band41 QPSK BW=5MHz Channel=39675 RB Size=25 Position=#0 Band41 QPSK BW=5MHz Channel=40620 RB Size=25 Position=#0 Report No.: STS2604021W01_Appendix LTE 171 Band41 QPSK BW=5MHz Channel=41565 RB Size=25 Position=#0 Band5 16QAM BW=1.4MHz Channel=20407 RB Size=6 Position=#0 Report No.: STS2604021W01_Appendix LTE 172 Band5 16QAM BW=1.4MHz Channel=20525 RB Size=6 Position=#0 Band5 16QAM BW=1.4MHz Channel=20643 RB Size=6 Position=#0 Report No.: STS2604021W01_Appendix LTE 173 Band5 16QAM BW=10MHz Channel=20450 RB Size=50 Position=#0 Band5 16QAM BW=10MHz Channel=20525 RB Size=50 Position=#0 Report No.: STS2604021W01_Appendix LTE 174 Band5 16QAM BW=10MHz Channel=20600 RB Size=50 Position=#0 Band5 16QAM BW=3MHz Channel=20415 RB Size=15 Position=#0 Report No.: STS2604021W01_Appendix LTE 175 Band5 16QAM BW=3MHz Channel=20525 RB Size=15 Position=#0 Band5 16QAM BW=3MHz Channel=20635 RB Size=15 Position=#0 Report No.: STS2604021W01_Appendix LTE 176 Band5 16QAM BW=5MHz Channel=20425 RB Size=25 Position=#0 Band5 16QAM BW=5MHz Channel=20525 RB Size=25 Position=#0 Report No.: STS2604021W01_Appendix LTE 177 Band5 16QAM BW=5MHz Channel=20625 RB Size=25 Position=#0 Band5 QPSK BW=1.4MHz Channel=20407 RB Size=6 Position=#0 Report No.: STS2604021W01_Appendix LTE 178 Band5 QPSK BW=1.4MHz Channel=20525 RB Size=6 Position=#0 Band5 QPSK BW=1.4MHz Channel=20643 RB Size=6 Position=#0 Report No.: STS2604021W01_Appendix LTE 179 Band5 QPSK BW=10MHz Channel=20450 RB Size=50 Position=#0 Band5 QPSK BW=10MHz Channel=20525 RB Size=50 Position=#0 Report No.: STS2604021W01_Appendix LTE 180 Band5 QPSK BW=10MHz Channel=20600 RB Size=50 Position=#0 Band5 QPSK BW=3MHz Channel=20415 RB Size=15 Position=#0 Report No.: STS2604021W01_Appendix LTE 181 Band5 QPSK BW=3MHz Channel=20525 RB Size=15 Position=#0 Band5 QPSK BW=3MHz Channel=20635 RB Size=15 Position=#0 Report No.: STS2604021W01_Appendix LTE 182 Band5 QPSK BW=5MHz Channel=20425 RB Size=25 Position=#0 Band5 QPSK BW=5MHz Channel=20525 RB Size=25 Position=#0 Report No.: STS2604021W01_Appendix LTE 183 Band5 QPSK BW=5MHz Channel=20625 RB Size=25 Position=#0 Band66 16QAM BW=1.4MHz Channel=131979 RB Size=6 Position=#0 Report No.: STS2604021W01_Appendix LTE 184 Band66 16QAM BW=1.4MHz Channel=132322 RB Size=6 Position=#0 Band66 16QAM BW=1.4MHz Channel=132665 RB Size=6 Position=#0 Report No.: STS2604021W01_Appendix LTE 185 Band66 16QAM BW=10MHz Channel=132022 RB Size=50 Position=#0 Band66 16QAM BW=10MHz Channel=132322 RB Size=50 Position=#0 Report No.: STS2604021W01_Appendix LTE 186 Band66 16QAM BW=10MHz Channel=132622 RB Size=50 Position=#0 Band66 16QAM BW=15MHz Channel=132047 RB Size=75 Position=#0 Report No.: STS2604021W01_Appendix LTE 187 Band66 16QAM BW=15MHz Channel=132322 RB Size=75 Position=#0 Band66 16QAM BW=15MHz Channel=132597 RB Size=75 Position=#0 Report No.: STS2604021W01_Appendix LTE 188 Band66 16QAM BW=20MHz Channel=132072 RB Size=100 Position=#0 Band66 16QAM BW=20MHz Chann…

Text truncated - open the document above for the full version.

Test Report

Report No.: STS2604021W01_Appendix LTE 711 Band4 QPSK BW=15MHz Channel=20325 RB Size=75 Position=#0 Band4 QPSK BW=20MHz Channel=20050 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 712 Band4 QPSK BW=20MHz Channel=20050 RB Size=100 Position=#0 Band4 QPSK BW=20MHz Channel=20175 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 713 Band4 QPSK BW=20MHz Channel=20175 RB Size=100 Position=#0 Band4 QPSK BW=20MHz Channel=20300 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 714 Band4 QPSK BW=20MHz Channel=20300 RB Size=100 Position=#0 Band4 QPSK BW=3MHz Channel=19965 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 715 Band4 QPSK BW=3MHz Channel=19965 RB Size=15 Position=#0 Band4 QPSK BW=3MHz Channel=20175 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 716 Band4 QPSK BW=3MHz Channel=20175 RB Size=15 Position=#0 Band4 QPSK BW=3MHz Channel=20385 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 717 Band4 QPSK BW=3MHz Channel=20385 RB Size=15 Position=#0 Band4 QPSK BW=5MHz Channel=19975 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 718 Band4 QPSK BW=5MHz Channel=19975 RB Size=25 Position=#0 Band4 QPSK BW=5MHz Channel=20175 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 719 Band4 QPSK BW=5MHz Channel=20175 RB Size=25 Position=#0 Band4 QPSK BW=5MHz Channel=20375 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 720 Band4 QPSK BW=5MHz Channel=20375 RB Size=25 Position=#0 Band41 QPSK BW=5MHz Channel=39675 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 721 Band41 QPSK BW=5MHz Channel=39675 RB Size=25 Position=#0 Band41 16QAM BW=5MHz Channel=39675 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 722 Band41 16QAM BW=5MHz Channel=39675 RB Size=25 Position=#0 Band41 QPSK BW=5MHz Channel=40620 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 723 Band41 QPSK BW=5MHz Channel=40620 RB Size=25 Position=#0 Band41 16QAM BW=5MHz Channel=40620 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 724 Band41 16QAM BW=5MHz Channel=40620 RB Size=25 Position=#0 Band41 QPSK BW=5MHz Channel=41565 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 725 Band41 QPSK BW=5MHz Channel=41565 RB Size=25 Position=#0 Band41 16QAM BW=5MHz Channel=41565 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 726 Band41 16QAM BW=5MHz Channel=41565 RB Size=25 Position=#0 Band41 QPSK BW=10MHz Channel=39700 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 727 Band41 QPSK BW=10MHz Channel=39700 RB Size=50 Position=#0 Band41 16QAM BW=10MHz Channel=39700 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 728 Band41 16QAM BW=10MHz Channel=39700 RB Size=50 Position=#0 Band41 QPSK BW=10MHz Channel=40620 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 729 Band41 QPSK BW=10MHz Channel=40620 RB Size=50 Position=#0 Band41 16QAM BW=10MHz Channel=40620 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 730 Band41 16QAM BW=10MHz Channel=40620 RB Size=50 Position=#0 Band41 QPSK BW=10MHz Channel=41540 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 731 Band41 QPSK BW=10MHz Channel=41540 RB Size=50 Position=#0 Band41 16QAM BW=10MHz Channel=41540 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 732 Band41 16QAM BW=10MHz Channel=41540 RB Size=50 Position=#0 Band41 QPSK BW=15MHz Channel=39725 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 733 Band41 QPSK BW=15MHz Channel=39725 RB Size=75 Position=#0 Band41 16QAM BW=15MHz Channel=39725 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 734 Band41 16QAM BW=15MHz Channel=39725 RB Size=75 Position=#0 Band41 QPSK BW=15MHz Channel=40620 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 735 Band41 QPSK BW=15MHz Channel=40620 RB Size=75 Position=#0 Band41 16QAM BW=15MHz Channel=40620 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 736 Band41 16QAM BW=15MHz Channel=40620 RB Size=75 Position=#0 Band41 QPSK BW=15MHz Channel=41515 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 737 Band41 QPSK BW=15MHz Channel=41515 RB Size=75 Position=#0 Band41 16QAM BW=15MHz Channel=41515 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 738 Band41 16QAM BW=15MHz Channel=41515 RB Size=75 Position=#0 Band41 QPSK BW=20MHz Channel=39750 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 739 Band41 QPSK BW=20MHz Channel=39750 RB Size=100 Position=#0 Band41 16QAM BW=20MHz Channel=39750 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 740 Band41 16QAM BW=20MHz Channel=39750 RB Size=100 Position=#0 Band41 QPSK BW=20MHz Channel=40620 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 741 Band41 QPSK BW=20MHz Channel=40620 RB Size=100 Position=#0 Band41 16QAM BW=20MHz Channel=40620 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 742 Band41 16QAM BW=20MHz Channel=40620 RB Size=100 Position=#0 Band41 QPSK BW=20MHz Channel=41490 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 743 Band41 QPSK BW=20MHz Channel=41490 RB Size=100 Position=#0 Band41 16QAM BW=20MHz Channel=41490 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 744 Band41 16QAM BW=20MHz Channel=41490 RB Size=100 Position=#0 Band5 16QAM BW=1.4MHz Channel=20407 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 745 Band5 16QAM BW=1.4MHz Channel=20407 RB Size=6 Position=#0 Band5 16QAM BW=1.4MHz Channel=20525 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 746 Band5 16QAM BW=1.4MHz Channel=20525 RB Size=6 Position=#0 Band5 16QAM BW=1.4MHz Channel=20643 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 747 Band5 16QAM BW=1.4MHz Channel=20643 RB Size=6 Position=#0 Band5 16QAM BW=10MHz Channel=20450 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 748 Band5 16QAM BW=10MHz Channel=20450 RB Size=50 Position=#0 Band5 16QAM BW=10MHz Channel=20525 RB Size=1 Position=#0 Rep…

Text truncated - open the document above for the full version.

Test Report

Report No.: STS2604021W01_Appendix LTE 771 Band66 16QAM BW=1.4MHz Channel=132665 RB Size=6 Position=#0 Band66 16QAM BW=10MHz Channel=132022 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 772 Band66 16QAM BW=10MHz Channel=132022 RB Size=50 Position=#0 Band66 16QAM BW=10MHz Channel=132322 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 773 Band66 16QAM BW=10MHz Channel=132322 RB Size=50 Position=#0 Band66 16QAM BW=10MHz Channel=132622 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 774 Band66 16QAM BW=10MHz Channel=132622 RB Size=50 Position=#0 Band66 16QAM BW=15MHz Channel=132047 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 775 Band66 16QAM BW=15MHz Channel=132047 RB Size=75 Position=#0 Band66 16QAM BW=15MHz Channel=132322 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 776 Band66 16QAM BW=15MHz Channel=132322 RB Size=75 Position=#0 Band66 16QAM BW=15MHz Channel=132597 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 777 Band66 16QAM BW=15MHz Channel=132597 RB Size=75 Position=#0 Band66 16QAM BW=20MHz Channel=132072 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 778 Band66 16QAM BW=20MHz Channel=132072 RB Size=100 Position=#0 Band66 16QAM BW=20MHz Channel=132322 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 779 Band66 16QAM BW=20MHz Channel=132322 RB Size=100 Position=#0 Band66 16QAM BW=20MHz Channel=132572 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 780 Band66 16QAM BW=20MHz Channel=132572 RB Size=100 Position=#0 Band66 16QAM BW=3MHz Channel=131987 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 781 Band66 16QAM BW=3MHz Channel=131987 RB Size=15 Position=#0 Band66 16QAM BW=3MHz Channel=132322 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 782 Band66 16QAM BW=3MHz Channel=132322 RB Size=15 Position=#0 Band66 16QAM BW=3MHz Channel=132657 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 783 Band66 16QAM BW=3MHz Channel=132657 RB Size=15 Position=#0 Band66 16QAM BW=5MHz Channel=131997 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 784 Band66 16QAM BW=5MHz Channel=131997 RB Size=25 Position=#0 Band66 16QAM BW=5MHz Channel=132322 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 785 Band66 16QAM BW=5MHz Channel=132322 RB Size=25 Position=#0 Band66 16QAM BW=5MHz Channel=132647 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 786 Band66 16QAM BW=5MHz Channel=132647 RB Size=25 Position=#0 Band66 QPSK BW=1.4MHz Channel=131979 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 787 Band66 QPSK BW=1.4MHz Channel=131979 RB Size=6 Position=#0 Band66 QPSK BW=1.4MHz Channel=132322 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 788 Band66 QPSK BW=1.4MHz Channel=132322 RB Size=6 Position=#0 Band66 QPSK BW=1.4MHz Channel=132665 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 789 Band66 QPSK BW=1.4MHz Channel=132665 RB Size=6 Position=#0 Band66 QPSK BW=10MHz Channel=132022 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 790 Band66 QPSK BW=10MHz Channel=132022 RB Size=50 Position=#0 Band66 QPSK BW=10MHz Channel=132322 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 791 Band66 QPSK BW=10MHz Channel=132322 RB Size=50 Position=#0 Band66 QPSK BW=10MHz Channel=132622 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 792 Band66 QPSK BW=10MHz Channel=132622 RB Size=50 Position=#0 Band66 QPSK BW=15MHz Channel=132047 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 793 Band66 QPSK BW=15MHz Channel=132047 RB Size=75 Position=#0 Band66 QPSK BW=15MHz Channel=132322 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 794 Band66 QPSK BW=15MHz Channel=132322 RB Size=75 Position=#0 Band66 QPSK BW=15MHz Channel=132597 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 795 Band66 QPSK BW=15MHz Channel=132597 RB Size=75 Position=#0 Band66 QPSK BW=20MHz Channel=132072 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 796 Band66 QPSK BW=20MHz Channel=132072 RB Size=100 Position=#0 Band66 QPSK BW=20MHz Channel=132322 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 797 Band66 QPSK BW=20MHz Channel=132322 RB Size=100 Position=#0 Band66 QPSK BW=20MHz Channel=132572 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 798 Band66 QPSK BW=20MHz Channel=132572 RB Size=100 Position=#0 Band66 QPSK BW=3MHz Channel=131987 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 799 Band66 QPSK BW=3MHz Channel=131987 RB Size=15 Position=#0 Band66 QPSK BW=3MHz Channel=132322 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 800 Band66 QPSK BW=3MHz Channel=132322 RB Size=15 Position=#0 Band66 QPSK BW=3MHz Channel=132657 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 801 Band66 QPSK BW=3MHz Channel=132657 RB Size=15 Position=#0 Band66 QPSK BW=5MHz Channel=131997 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 802 Band66 QPSK BW=5MHz Channel=131997 RB Size=25 Position=#0 Band66 QPSK BW=5MHz Channel=132322 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 803 Band66 QPSK BW=5MHz Channel=132322 RB Size=25 Position=#0 Band66 QPSK BW=5MHz Channel=132647 RB Size=1 Position=#0 Report No.: STS2604021W01_Appendix LTE 804 Band66 QPSK BW=5MHz Channel=132647 RB Size=25 Position=#0

Test Report

Report No.: STS2604021W01_Appendix GSM- 1 15 Peak-to-Average Ratio Band Channel Frequency (MHz) Result (dB) high Limit (dB) Verdict EGPRS1900 512 1850.2 5.717857143 13.00 PASS EGPRS1900 661 1880 5.688947368 13.00 PASS EGPRS1900 810 1909.8 6.30025 13.00 PASS EGPRS850 128 824.2 9.090952381 13.00 PASS EGPRS850 190 836.6 5.75 13.00 PASS EGPRS850 251 848.8 5.742758621 13.00 PASS EGPRS1900 Channel=512 EGPRS1900 Channel=661 Report No.: STS2604021W01_Appendix GSM- 2 EGPRS1900 Channel=810 EGPRS850 Channel=128 Report No.: STS2604021W01_Appendix GSM- 3 EGPRS850 Channel=190 EGPRS850 Channel=251 Report No.: STS2604021W01_Appendix GSM- 4 16 Occupied bandwidth Band Channel Frequency (MHz) 99% OBW (kHz) -26dB EBW (kHz) Verdict EGPRS1900 512 1850.2 240.587 309.377 PASS EGPRS1900 661 1880 242.605 310.369 PASS EGPRS1900 810 1909.8 249.518 309.738 PASS EGPRS850 128 824.2 239.426 294.128 PASS EGPRS850 190 836.6 241.618 280.868 PASS EGPRS850 251 848.8 241.670 317.322 PASS EGPRS1900 Channel=512 Report No.: STS2604021W01_Appendix GSM- 5 EGPRS1900 Channel=661 EGPRS1900 Channel=810 Report No.: STS2604021W01_Appendix GSM- 6 EGPRS850 Channel=128 EGPRS850 Channel=190 Report No.: STS2604021W01_Appendix GSM- 7 EGPRS850 Channel=251 17 Band edge Report No.: STS2604021W01_Appendix GSM- 8 Band Channel Frequency (MHz) Spur Freq (MHz) Spur Level (dBm) Limit (dBm) Verdict EGPRS1900 512 1850.2 1849.99 -35.16 -13 PASS EGPRS1900 810 1909.8 1910.00 -34.92 -13 PASS EGPRS850 128 824.2 823.99 -34.36 -13 PASS EGPRS850 251 848.8 849.00 -33.52 -13 PASS EGPRS1900 Channel=512 EGPRS1900 Channel=810 Report No.: STS2604021W01_Appendix GSM- 9 EGPRS850 Channel=128 EGPRS850 Channel=251 Report No.: STS2604021W01_Appendix GSM- 10 18 Out-of-band emissions Band Channel Frequency (MHz) Spur Freq (MHz) Spur Level (dBm) Limit (dBm) Verdict EGPRS1900 512 1850.2 16383.93 -22.49 -13 PASS EGPRS1900 661 1880 16508.25 -21.96 -13 PASS EGPRS1900 810 1909.8 16210.19 -22.84 -13 PASS EGPRS850 128 824.2 3254.30 -27.81 -13 PASS EGPRS850 190 836.6 3027.98 -28.26 -13 PASS EGPRS850 251 848.8 3031.47 -28.51 -13 PASS EGPRS1900 Channel=512 Report No.: STS2604021W01_Appendix GSM- 11 EGPRS1900 Channel=661 EGPRS1900 Channel=810 Report No.: STS2604021W01_Appendix GSM- 12 EGPRS850 Channel=128 EGPRS850 Channel=190 Report No.: STS2604021W01_Appendix GSM- 13 EGPRS850 Channel=251 09 Peak-to-Average Ratio Report No.: STS2604021W01_Appendix GSM- 14 Band Channel Frequency (MHz) Result (dB) high Limit (dB) Verdict GPRS1900 512 1850.2 2.805882353 13.00 PASS GPRS1900 661 1880 2.81311828 13.00 PASS GPRS1900 810 1909.8 3.012934783 13.00 PASS GPRS850 128 824.2 2.813026316 13.00 PASS GPRS850 190 836.6 2.821733333 13.00 PASS GPRS850 251 848.8 2.91955414 13.00 PASS GPRS1900 Channel=512 GPRS1900 Channel=661 Report No.: STS2604021W01_Appendix GSM- 15 GPRS1900 Channel=810 GPRS850 Channel=128 Report No.: STS2604021W01_Appendix GSM- 16 GPRS850 Channel=190 GPRS850 Channel=251 Report No.: STS2604021W01_Appendix GSM- 17 10 Occupied bandwidth Band Channel Frequency (MHz) 99% OBW (kHz) -26dB EBW (kHz) Verdict GPRS1900 512 1850.2 252.399 321.595 PASS GPRS1900 661 1880 247.321 315.424 PASS GPRS1900 810 1909.8 246.818 308.912 PASS GPRS850 128 824.2 245.344 318.575 PASS GPRS850 190 836.6 244.120 315.285 PASS GPRS850 251 848.8 242.242 310.969 PASS GPRS1900 Channel=512 Report No.: STS2604021W01_Appendix GSM- 18 GPRS1900 Channel=661 GPRS1900 Channel=810 Report No.: STS2604021W01_Appendix GSM- 19 GPRS850 Channel=128 GPRS850 Channel=190 Report No.: STS2604021W01_Appendix GSM- 20 GPRS850 Channel=251 11 Band edge Report No.: STS2604021W01_Appendix GSM- 21 Band Channel Frequency (MHz) Spur Freq (MHz) Spur Level (dBm) Limit (dBm) Verdict GPRS1900 512 1850.2 1849.98 -29.58 -13 PASS GPRS1900 810 1909.8 1910.02 -29.63 -13 PASS GPRS850 128 824.2 823.98 -27.58 -13 PASS GPRS850 251 848.8 849.02 -26.93 -13 PASS GPRS1900 Channel=512 GPRS1900 Channel=810 Report No.: STS2604021W01_Appendix GSM- 22 GPRS850 Channel=128 GPRS850 Channel=251 Report No.: STS2604021W01_Appendix GSM- 23 12 Out-of-band emissions Band Channel Frequency (MHz) Spur Freq (MHz) Spur Level (dBm) Limit (dBm) Verdict GPRS1900 512 1850.2 16358.47 -22.07 -13 PASS GPRS1900 661 1880 16500.26 -21.96 -13 PASS GPRS1900 810 1909.8 16572.15 -22.02 -13 PASS GPRS850 128 824.2 2484.36 -28.52 -13 PASS GPRS850 190 836.6 2676.79 -27.84 -13 PASS GPRS850 251 848.8 5804.87 -27.69 -13 PASS GPRS1900 Channel=512 Report No.: STS2604021W01_Appendix GSM- 24 GPRS1900 Channel=661 GPRS1900 Channel=810 Report No.: STS2604021W01_Appendix GSM- 25 GPRS850 Channel=128 GPRS850 Channel=190 Report No.: STS2604021W01_Appendix GSM- 26 GPRS850 Channel=251 03 Peak-to-Average Ratio Report No.: STS2604021W01_Appendix GSM- 27 Band Channel Frequency (MHz) Result (dB) high Limit (dB) Verdict GSM1900 512 1850.2 2.81 13 PASS GSM1900 661 1880 2.82 13 PASS GSM1900 810 1909.8 2.84 13 PASS GSM850 128 824.2 2.82 13 PASS GSM850 190 836.6 2.83 13 PASS GSM850 251 848.8 2.85 13 PASS GSM1900 Channel=512 GSM1900 Channel=661 Report No.: STS2604021W01_Appendix GSM- 28 GSM1900 Channel=810 GSM850 Channel=128 Report No.: STS2604021W01_Appendix GSM- 29 GSM850 Channel=190 GSM850 Channel=251 Report No.: STS2604021W01_Appendix GSM- 30 04 Occupied bandwidth Band Channel Frequency (MHz) 99% OBW (kHz) -26dB EBW (kHz) Verdict GSM1900 512 1850.2 243.995 315.571 PASS GSM1900 661 1880 244.403 315.949 PASS GSM1900 810 1909.8 237.130 313.741 PASS GSM850 128 824.2 243.364 311.515 PASS GSM850 190 836.6 243.733 318.426 PASS GSM850 251 848.8 241.811 313.999 PASS GSM1900 Channel=512 Report No.: STS2604021W01_Appendix GSM- 31 GSM1900 Channel=661 GSM1900 Channel=810 Report No.: STS2604021W01_Appendix GSM- 32 GSM850 Channel=128 GSM850 Channel=190 Report No.: STS2604021W01_Appendix GSM- 33 GSM850 Channel=251 05 Band edge Report No.: STS2604021W01_Appendix GSM- 34 Band Channel Frequency (MHz) Spur Freq (MHz) Spur Level (dBm) Limit (dBm) Verdict GSM1900 512 1850.2 1849.98 -29.82 -13 PASS GSM1900 810 1909.8 1910.02 -28.94 -13 PASS GSM850 1…

Text truncated - open the document above for the full version.

Test Report

Report No.: TR_STS2604021W01_RF_Appendix WCDMA 1 03 Peak-to-Average Ratio Band Channel Frequency (MHz) Result (dB) high Limit (dB) Verdict HSDPA Band2 Subtest1 9262 1852.4 2.87 13 PASS HSDPA Band2 Subtest1 9400 1880 3.09 13 PASS HSDPA Band2 Subtest1 9538 1907.6 3.10 13 PASS HSUPA Band2 Subtest1 9262 1852.4 3.25 13 PASS HSUPA Band2 Subtest1 9400 1880 3.45 13 PASS HSUPA Band2 Subtest1 9538 1907.6 3.47 13 PASS WCDMA Band2 9262 1852.4 2.63 13 PASS WCDMA Band2 9400 1880 2.96 13 PASS WCDMA Band2 9538 1907.6 2.86 13 PASS HSDPA Band4 Subtest1 1312 1712.4 2.81 13 PASS HSDPA Band4 Subtest1 1450 1740 3.04 13 PASS HSDPA Band4 Subtest1 1513 1752.6 2.98 13 PASS HSUPA Band4 Subtest1 1312 1712.4 3.21 13 PASS HSUPA Band4 Subtest1 1450 1740 3.40 13 PASS HSUPA Band4 Subtest1 1513 1752.6 3.34 13 PASS WCDMA Band4 1312 1712.4 2.72 13 PASS WCDMA Band4 1450 1740 2.84 13 PASS WCDMA Band4 1513 1752.6 2.79 13 PASS HSDPA Band5 Subtest1 4132 826.4 2.78 13 PASS HSDPA Band5 Subtest1 4182 836.4 2.96 13 PASS HSDPA Band5 Subtest1 4233 846.6 2.98 13 PASS HSUPA Band5 Subtest1 4132 826.4 3.20 13 PASS HSUPA Band5 Subtest1 4182 836.4 3.33 13 PASS HSUPA Band5 Subtest1 4233 846.6 3.43 13 PASS WCDMA Band5 4132 826.4 2.69 13 PASS WCDMA Band5 4182 836.4 2.86 13 PASS WCDMA Band5 4233 846.6 2.87 13 PASS HSDPA Band2 Subtest1 Channel=9262 Report No.: TR_STS2604021W01_RF_Appendix WCDMA 2 HSDPA Band2 Subtest1 Channel=9400 HSDPA Band2 Subtest1 Channel=9538 Report No.: TR_STS2604021W01_RF_Appendix WCDMA 3 HSUPA Band2 Subtest1 Channel=9262 HSUPA Band2 Subtest1 Channel=9400 Report No.: TR_STS2604021W01_RF_Appendix WCDMA 4 HSUPA Band2 Subtest1 Channel=9538 WCDMA Band2 Channel=9262 Report No.: TR_STS2604021W01_RF_Appendix WCDMA 5 WCDMA Band2 Channel=9400 WCDMA Band2 Channel=9538 Report No.: TR_STS2604021W01_RF_Appendix WCDMA 6 HSDPA Band4 Subtest1 Channel=1312 HSDPA Band4 Subtest1 Channel=1450 Report No.: TR_STS2604021W01_RF_Appendix WCDMA 7 HSDPA Band4 Subtest1 Channel=1513 HSUPA Band4 Subtest1 Channel=1312 Report No.: TR_STS2604021W01_RF_Appendix WCDMA 8 HSUPA Band4 Subtest1 Channel=1450 HSUPA Band4 Subtest1 Channel=1513 Report No.: TR_STS2604021W01_RF_Appendix WCDMA 9 WCDMA Band4 Channel=1312 WCDMA Band4 Channel=1450 Report No.: TR_STS2604021W01_RF_Appendix WCDMA 10 WCDMA Band4 Channel=1513 HSDPA Band5 Subtest1 Channel=4132 Report No.: TR_STS2604021W01_RF_Appendix WCDMA 11 HSDPA Band5 Subtest1 Channel=4182 HSDPA Band5 Subtest1 Channel=4233 Report No.: TR_STS2604021W01_RF_Appendix WCDMA 12 HSUPA Band5 Subtest1 Channel=4132 HSUPA Band5 Subtest1 Channel=4182 Report No.: TR_STS2604021W01_RF_Appendix WCDMA 13 HSUPA Band5 Subtest1 Channel=4233 WCDMA Band5 Channel=4132 Report No.: TR_STS2604021W01_RF_Appendix WCDMA 14 WCDMA Band5 Channel=4182 WCDMA Band5 Channel=4233 Report No.: TR_STS2604021W01_RF_Appendix WCDMA 15…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Xiuying Zou

[email protected]Fax: 75532909320

Technical Contact

FCC US Agent, LLCTim Payne

[email protected]

3722 Illinois Avenue, Saint Charles, IL, 60174,USA · Saint Charles, Illinois, 60174 · United States

Test Firm

SHENZHEN STS TEST SERVICES CO.,LTD.Bovey Yang

[email protected]

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
1	22H	824.2 MHz - 848.8 MHz	1.2023 W	245KGXW	2.5ppm
2	22H	824.2 MHz - 848.8 MHz	287.70 mW	242KG7W	2.5ppm
3	24E	1.85 GHz - 1.91 GHz	1.2531 W	252KGXW	2.5ppm
4	24E	1.85 GHz - 1.91 GHz	566.20 mW	250KG7W	2.5ppm
5	24E	1.85 GHz - 1.91 GHz	317.70 mW	4M18F9W	2.5ppm
6	27	1.71 GHz - 1.75 GHz	219.30 mW	4M17F9W	2.5ppm
7	22H	826.4 MHz - 846.4 MHz	155.50 mW	4M16F9W	2.5ppm
8	24E	1.85 GHz - 1.91 GHz	352.40 mW	9M00G7D	2.5ppm
9	24E	1.86 GHz - 1.90 GHz	347.50 mW	18M0G7D	2.5ppm
1	24E	1.86 GHz - 1.90 GHz	343.60 mW	18M0W7D	2.5ppm
11	27	1.72 GHz - 1.75 GHz	232.30 mW	9M00G7D	2.5ppm
12	27	1.72 GHz - 1.75 GHz	229.10 mW	18M0G7D	2.5ppm
13	27	1.72 GHz - 1.75 GHz	237.10 mW	9M01W7D	2.5ppm
14	27	1.72 GHz - 1.75 GHz	221.30 mW	18M0W7D	2.5ppm
15	22H	825.5 MHz - 847.5 MHz	163.70 mW	2M71G7D	2.5ppm
16	22H	829 MHz - 844 MHz	161.40 mW	8M99G7D	2.5ppm
17	22H	824.7 MHz - 848.3 MHz	164.40 mW	1M11W7D	2.5ppm
18	22H	829 MHz - 844 MHz	159.60 mW	8M99W7D	2.5ppm
19	27	704 MHz - 711 MHz	79.30 mW	9M02G7D	2.5ppm
2	27	699.7 MHz - 715.3 MHz	79.40 mW	1M10W7D	2.5ppm
21	27	704 MHz - 711 MHz	75.70 mW	9M00W7D	2.5ppm
22	27	709 MHz - 711 MHz	80.00 mW	9M01G7D	2.5ppm
23	27	709 MHz - 711 MHz	81.30 mW	9M00W7D	2.5ppm
24	27	2.50 GHz - 2.69 GHz	353.20 mW	4M52G7D	2.5ppm
25	27	2.51 GHz - 2.68 GHz	338.80 mW	18M0G7D	2.5ppm
26	27	2.50 GHz - 2.69 GHz	327.30 mW	9M00W7D	2.5ppm
27	27	2.51 GHz - 2.68 GHz	303.40 mW	18M0W7D	2.5ppm
28	27	1.72 GHz - 1.77 GHz	231.70 mW	13M5G7D	2.5ppm
29	27	1.72 GHz - 1.77 GHz	227.00 mW	18M0G7D	2.5ppm
3	27	1.72 GHz - 1.77 GHz	237.10 mW	9M01W7D	2.5ppm
31	27	1.72 GHz - 1.77 GHz	206.50 mW	18M1W7D	2.5ppm

Confidentiality

Long Term

Grant Notes

Output power listed is ERP for frequencies below 1 GHz and EIRP for frequencies above 1 GHz. FCC RF Exposure Information and Statement that the SAR limit of USA (FCC) for head & body Limit is 1.6 W/kg@1g and limbs is 4.0W/kg@10g. Device types have also been tested against this SAR limit. Body-worn operations are restricted to belt-clips, holsters or similar accessories that have no metallic component in the assembly and which provide at least 10mm separation between the device and the users body, for Head and Limbs is 0mm. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. The highest reported SAR for head use, body-worn accessory, Product Specific (hotspot) and simultaneous transmission, product specific(limbs 10g SAR) exposure conditions are 0.55 W/kg, 0.44W/kg and 0.63W/kg ,1.57W/kg(limbs 10g SAR) and 1.78W/kg(limbs 10g SAR simultaneous transmission) respectively. This device supports LTE of 1.4, 3, 5, 10, 15, and 20MHz bandwidth modes for FDD LTE Band 2, Band 4 and Band 66 ; LTE of 1.4, 3, 5 and 10MHz bandwidth modes for FDD LTE Band 5 and Band 12 ;LTE of 5, 10, 15 and 20MHz bandwidth modes for TDD LTE Band 41; LTE of 5 and 10MHz bandwidth modes for FDD LTE Band 17.
