2BTXP-T4-001Tablet computer

User Operating Manual T4-001 Tablet computer About This User Guide • Some of the contents of this guide may appear differently on your device. Your actual device may differ from the illustration, depending on the software and your service provider. All information in this document is subject to change without prior notice. • Your device's applications and their functions may vary by region, or hardware specifications. CPC cannot be held liable for performance or incompatibility issues resulting from edited registry settings being edited or operating system software being modified. Any attempt to customize your operating system may cause the device or its applications to not work as they should. Important • We do not suggest you reinstalling the system. You may contact CPC support if reinstallation is necessary. • You may not disassemble the device in any circumstance. • Please keep your device away from fire, water or any extreme weather condition. • Please avoid any heavy object or hard press on front face of your device. Disclaimer of Warranties CPC shall not be liable for any damages of any kind resulting from the purchase or use the product or arising from the breach of the express warranty, including incidental, special or consequential damages, or loss of anticipated profits or benefits. CPC is not liable for performance issues or incompatibilities caused by your editing or registry settings, or your modification of operating system software. Using custom operating system software may cause your device and applications to work improperly. 1. Getting started Hold the power button for 3 seconds, devices start up directly. 2. Wi-Fi connection Tap settings-Wireless& Networks-Wi-Fi-tap to turn it to “ON”. After a moment, your Wi-Fi network nearby will be listed. If you need to rescan for available networks, tap the menu on right top corner, and tap “Refresh”. You device lists the networks it finds within range. Tap the network you have access to, enter password, and tap “Connect”. When you tablet is connected to the network, the wireless indicator appears in the status bar. Waves indicate connection strength. 3. Bluetooth Turn on Bluetooth. You must pair your device with another device before you can transfer files between them. Under “Settings”, choose “Bluetooth”. Tap Bluetooth to “ON”. The Bluetooth indicator then appears in the status bar. It will start searching available devices nearby. If you need to rescan, tap the menu on top right corner, and tap “Refresh”. 4. Camera/Video Click and select the camera; The system enters into the camera interface; Click and select the Photo button and easily take the photos; In the camera mode, move the mouse to the right, it can choose the video mode. Click the button and easily take the video. 5. Gallery You can view your digital pictures or videos in Gallery. 6. Device factory mode You may reset your tablet when necessary. This will clear all info in your tablet and get your device back to factory mode. WARNING! If you perform factory mode, all user applications, user data will be deleted. Please remember to backup any important data before performing factory mode. Troubleshooting 1. Device crash  Hold the power buttons for 10 seconds to restart. 2. Error message during operation  Delete and clear the system to factory mode with a system reset. 3. Device can’t be connected with Wi-Fi  Make sure you turn Wi-Fi to “ON” status.  Unplug Wi-Fi router, wait for 2 minutes and plug to connect again.  Make sure you input correct password by selecting “show password when your input it.  Check and make sure there is no filtering setting or device connection limit in your router setting.  Forget original Wi-Fi connection, reset Wi-Fi router, and connect again. FCC Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1)this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. FCC/IC RF Radiation Exposure and SAR Statements The Tablet computer T4-001 has been tested for body-worn Specific Absorption Rate(SAR) compliance. The FCC/IC has established detailed SAR requirements and has established that these requirements. RF Exposure Information The radio module has been evaluated under FCC Bulletin C95.1 and IEEE 1528 and found to be compliant to RF Exposure from radio frequency devices. This model meets the applicable government requirements for exposure to radio frequency waves. The highest reported SAR level for usage near the body (0mm) is 0.089 W/kg

Rev 1/26/2023 Combined Public Communications, LLC Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2026/3/24 Ref: Attestation Statements Part 2.911(d)(7) Filing FCC ID: 2BTXP-T4-001 Applicant FRN: 0037801032 [Combined Public Communications, LLC] certifies that, as of the date of the filing of the application, [Combined Public Communications, LLC] is our designated U.S. agent for service of process for the above referenced FCC ID. [Combined Public Communications, LLC] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. [Combined Public Communications, LLC] accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Company Name: Combined Public Communications, LLC FRN: 0037801032 Address: 100 Aqua Drive Cold Spring, KY 41076, United States Contact Person: Dan Labin Phone: 859-441-5554 Email: [email protected] Sincerely, [Combined Public Communications, LLC] [Combined Public Communications, LLC] [Dan Labin] [Dan Labin]

(Combined Public Communications, LLC) (2026.3.24) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID: 2BTXP-T4-001) [Combined Public Communications, LLC] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, the equipment does not utilize cyber-security or anti-virus software from Kaspersky Lab, Inc, or any of its successors and assignees, which is also on the “covered list”. Sincerely, (Applicant signature) (Applicant printed name) Dan Labin (Combined Public Communications, LLC) (2026.03.24) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for (FCC ID: 2BTXP-T4-001) [Combined Public Communications, LLC] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name) Dan Labin

Combined Public Communications, LLC 2026.3.24 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: CONFIDENTIALITY REQUEST FOR EUT NAME: Tablet computer MODEL : T4-001 FCC ID : 2BTXP-T4-001 To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the - Block Diagram - Schematics - Operational Description - FCC Software Security Requirements for UNII devices Rev 2.1 required to be submitted with this application be permanently withheld from public review. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); User Manual Test Setup Photos For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuantto KDB 726920 D01. Please contact me if there is any information you may need. Sincerely, Client’s signature: Client’s name / title : Dan Labin / CEO Contact information / address: 100 Aqua Drive Cold Spring, KY 41076, United States

Combined Public Communications, LLC 2026.03.24 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize SHENZHEN STS TEST SERVICES CO., LTD to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Client’s signature: Client’s name / title : Dan Labin / CEO Contact information / address: 100 Aqua Drive Cold Spring, KY 41076, United States

External Photos

Size:40*20mm Tablet computer FCC ID: 2BTXP-T4-001 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Label location

Internal Photos Antenna

Page: 1/11 SHENZHEN STS TEST SERVICES CO., LTD. 1/F, BUILDING 2, ZHUOKE SCIENCE PARK, 190 CHONGQING ROAD FUYONG, BAO’ AN DISTRICT, SHENZHEN,CHINA MVG COMOSAR DOSIMETRIC E-FIELD PROBE SERIAL NO.: SN 08/21 EPGO352 Calibrated at MVG Z.I. de la pointe du diable Technopôle Brest Iroise – 295 avenue Alexis de Rochon 29280 PLOUZANE - FRANCE Calibration date: 09/15/2025 Accreditations #2-6789 Scope available on www.cofrac.fr The use of the Cofrac brand and the accreditation references is prohibited from any reproduction. Summary: This document presents the method and results from an accredited COMOSAR Dosimetric E-Field Probe calibration performed at MVG, using the CALIPROBE test bench, for use with a MVG COMO SAR system only. The test results covered by accreditation are traceable to the International System of Units (SI). COMOSAR E-Field Probe Calibration Report Ref : ACR.95.19.25.BES.A Docusign Envelope ID: 711C3E09-7054-43A0-BF16-C536091746C4 COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.95.19.25.BES.A Page: 2/11 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vM This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. Name Function Date Signature Prepared by : Pedro Ruiz Measurement Responsible 9/16/2025 Checked & approved by: Jérôme L uc Technical Manager 9/16/2025 Authorized by: Laboratory Director Customer Name Distribution : Shenzhen STS Test Services Co., Ltd. Issue Name Date Modifications A Pedro Ruiz 9/16/2025 Initial release Docusign Envelope ID: 711C3E09-7054-43A0-BF16-C536091746C4 Geraldine Toutain 9/16/2025 COMOSAR E-FIELD PROBE CALIBRATION REPORT Page: 3/11 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vM This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. TABLE OF CONTENTS 1 Device Under Test ..................................................................................................... 4 2 Product Description ................................................................................................... 4 2.1 General Information _______________________________________________________ 4 3 Measurement Method ................................................................................................ 4 3.1 Sensitivity _______________________________________________________________ 4 3.2 Linearity ________________________________________________________________ 5 3.3 Isotropy _________________________________________________________________ 5 3.4 Boundary Effect __________________________________________________________ 5 3.5 Probe Modulation Response _________________________________________________ 6 4 Measurement Uncertainty .......................................................................................... 6 5 Calibration Results ..................................................................................................... 6 5.1 Calibration in air __________________________________________________________ 6 5.2 Calibration in liquid _______________________________________________________ 7 6 Verification Results ................................................................................................... 8 7 List of Equipment ...................................................................................................... 9 Docusign Envelope ID: 711C3E09-7054-43A0-BF16-C536091746C4 Ref: ACR.95.19.25.BES.A COMOSAR E-FIELD PROBE CALIBRATION REPORT Page: 4/11 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vM This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. 1 DEVICE UNDER TEST Device Under Test Device Type COMOSAR DOSIMETRIC E FIELD PROBE Manufacturer MVG Model SSE2 Serial Number SN 08/21 EPGO352 Product Condition (new / used) Used Frequency Range of Probe 0.15 GHz-7.5GHz Resistance of Three Dipoles at Connector Dipole 1: R1=0.222 M: Dipole 2: R2=0.198 M: Dipole 3: R3=0.191 M: 2 PRODUCT DESCRIPTION 2.1 GENERAL INFORMATION MVG’s COMOSAR E field Probes are built in accordance to the IEC/IEEE 62209-1528 and FCC KDB865664 D01 standards. Figure 1 – MVG COMOSAR Dosimetric E field Probe Probe Length 330 mm Length of Individual Dipoles 2 mm Maximum external diameter 8 mm Probe Tip External Diameter 2.5 mm Distance between dipoles / probe extremity 1 mm 3 MEASUREMENT METHOD The IEC/IEEE 62209-1528 and FCC KDB865664 D01 standards provide recommended practices for the probe calibrations, including the performance characteristics of interest and methods by which to assess their effect. All calibrations / measurements performed meet the fore-mentioned standards. 3.1 SENSITIVITY The sensitivity factors of the three dipoles were determined using a two step calibration method (air and tissue simulating liquid) using waveguides as outlined in the standards for frequency range 600- 7500MHz and using the calorimeter cell method (transfer method) as outlined in the standards for frequency 150-450 MHz. Docusign Envelope ID: 711C3E09-7054-43A0-BF16-C536091746C4 Ref: ACR.95.19.25.BES.A COMOSAR E-FIELD PROBE CALIBRATION REPORT Page: 5/11 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vM This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. 3.2 LINEARITY The evaluation of the linearity was done in fr…

Text truncated - open the document above for the full version.

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. SAR Test Report Report No.: STS2601349H01 Issued for Combined Public Communications, LLC 100 Aqua Drive Cold Spring, KY 41076, United States Product Name: Tablet computer Brand Name: N/A Model Name: T4-001 Series Model(s): N/A FCC ID: 2BTXP-T4-001 Test Standard: ANSI/IEEE Std. C95.1 FCC 47 CFR Part 2 (2.1093) IEEE Std. 1528-2013 Max. Report SAR (1g) Body: 0.089 W/kg(1g) Page 2 of 40 Report No.: STS2601349H01 TEST REPORT CERTIFICATION Applicant’s name ................. : Combined Public Communications, LLC Address ................................. : 100 Aqua Drive Cold Spring, KY 41076, United States Manufacturer's Name .......... : Hatch international limited Address ................................. : Unit 906A, 9/F, First Group Centre, 23 Wang Chiu Road, Kowloon Bay, Hong Kong Product description Product name ........................ : T4-001 Brand name ......................... : N/A Model name ......................... : T4-001 Series Model(s) : .................... N/A Standards ............................. : ANSI/IEEE Std. C95.1 FCC 47 CFR Part 2 (2.1093) IEEE Std. 1528-2013 The device was tested by Shenzhen STS Test Services Co., Ltd. in accordance with the measurement methods and procedures specified in KDB 865664 The test results in this report apply only to the tested sample of the stated device/equipment. Other similar device/equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Date of Test ........................................... : Date (s) of performance of tests ............. : 01 Feb. 2026 Date of Issue .......................................... : 01 Feb. 2026 Test Result.............................................. : Pass Testing Engineer : (Xin.Liu) Technical Manager : (Shifan. Long) Authorized Signatory : (Bovey Yang) Page 3 of 40 Report No.: STS2601349H01 Table of Contents 1. General Information 5 1.1 EUT Description 5 1.2 Test Environment 6 1.3 Test Factory 6 2. Test Standards and Limits 7 3. SAR Measurement System 8 3.1 Definition of Specific Absorption Rate (SAR) 8 3.2 SAR System 8 4. Tissue Simulating Liquids 11 4.1 Simulating Liquids Parameter Check 11 5. SAR System Validation 14 5.1 Validation System 14 5.2 Validation Result 14 6. SAR Evaluation Procedures 15 7. EUT Antenna Location Sketch 16 7.1 SAR test exclusion consider 17 8. EUT Test Position 18 8.1 Body-worn Position Conditions 18 9. Uncertainty 19 9.1 Measurement Uncertainty 19 10. Conducted Power Measurement 22 10.1 Test Result 22 11. EUT and Test Setup Photo 24 11.1 EUT Photo 24 11.2 Setup Photo 27 12. SAR Result Summary 30 12.1 Body SAR 30 13. Equipment List 31 Appendix A. System Validation Plots 32 Appendix B. SAR Test Plots 36 Appendix C. Probe Calibration and Dipole Calibration Report 40 Page 4 of 40 Report No.: STS2601349H01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 01 Feb. 2026 STS2601349H01 ALL Initial Issue Page 5 of 40 Report No.: STS2601349H01 1. General Information Environmental evaluation measurements of specific absorption rate (SAR) distributions in emulated human head and body tissues exposed to radio frequency (RF) radiation from wireless portable devices for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC). 1.1 EUT Description Product Name T4-001 Brand Name N/A Model Name T4-001 Series Model N/A Model Difference N/A Battery Rated Voltage: V Charge Limit Voltage: V Capacity: mAh Device Category Portable Product stage Production unit RF Exposure Environment General Population / Uncontrolled Hardware Version N/A Software Version N/A Frequency Range WLAN802.11b/g/n20: 2412 MHz ~ 2462 MHz WLAN 802.11n40: 2422 MHz ~ 2452 MHz WLAN 802.11a/n20/n40/ac20/ac40/ac80: 5150 ~ 5250 MHz WLAN 802.11a/n20/n40/ac20/ac40/ac80: 5725 ~ 5850 MHz Bluetooth: 2402 MHz to 2480 MHz Max. Reported SAR(1g): (Limit:1.6W/kg) Test distance: Body:0mm Band Mode Body Worn (W/kg) NII 5.2G WLAN 0.077 NII 5.8G WLAN 0.089 Limit 1.6W/kg FCC Equipment Class Unlicensed National Information Infrastructure TX(NII) Operating Mode: 5G WLAN: 802.11a(OFDM):BPSK,QPSK,16-QAM,64-QAM 802.11n(OFDM):BPSK,QPSK,16-QAM,64-QAM 802.11ac(OFDM):BPSK,QPSK,16-QAM,64-QAM,256-QAM Antenna Specification: WLAN: Internal antenna Hotspot Mode Not Support DTM Mode Not Support Note: 1. The EUT battery must be fully charged and checked periodically during the test to ascertain uniform power Page 6 of 40 Report No.: STS2601349H01 1.2 Test Environment Ambient conditions in the SAR laboratory: Items Required Temperature (°C) 18-25 Humidity (%RH) 30-70 1.3 Test Factory ShenZhen STS Test Services Co.,Ltd. 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub- District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration No.: 625569 IC Registration No.: 12108A A2LA Certificate No.: 4338.01 Page 7 of 40 Report No.: STS2601349H01 2. Test Standards and Limits No. Identity Document Title 1 47 CFR Part 2 Frequency Allocations and Radio Treaty Matters; General Rules and Regulations 2 IEEE Std C95.1, 2019 IEEE Standard for Safety Levels with Respect to Human Exposure to Electric,Magnetic, and Electromagnetic Fields,0 Hz to 300 GHz. It specifies the maximum exposure limit of 1.6 W/kg as averaged over any 1 gram of tissue for portable devices being used within 20 cm of the user in the uncontrolled environment. 3 IEEE Std. 1528-2013 Recommended Practice for Determining the Peak Spatial- Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques 4 FCC KDB 447498 D04 v01 RF Exposure Procedures and Equipment Authorization Policies for Mobile and Portable Devices 5 FCC KDB 865664 D01 v01r04 SAR Measurement 100 MHz to 6 GHz 6 FCC KDB 8656…

Text truncated - open the document above for the full version.

Page 21 of 40 Report No.: STS2601349H01 。 System Check uncertainty for DUT averaged over 1 gram / 10 gram. Uncertainty Component Sec. Tol Prob. Dist. Div. Ci (1g) Ci (10g) 1g Ui (+- %) 10g Ui (+-%) vi (+- %) Measurement System Probe calibration drift E.2.1.3 5.72 N 1.00 1.00 1.00 5.72 5.72 Axial Isotropy E.2.2 0.18 R 1.73 0.00 0.00 0.00 0.00 Hemispherical Isotropy E.2.2 1.04 R 1.73 0.00 0.00 0.00 0.00 Boundary effect E.2.3 0.8 R 1.73 0.00 0.00 0.00 0.00 Linearity E.2.4 1.25 R 1.73 0.00 0.00 0.00 0.00 System detection limits E.2.4 1.20 R 1.73 0.00 0.00 0.00 0.00 Modulation response E2.5 3.42 R 1.73 0.00 0.00 0.00 0.00 Readout Electronics E.2.6 0.26 N 1.00 0.00 0.00 0.00 0.00 Response Time E.2.7 0.17 R 1.73 0.00 0.00 0.00 0.00 Integration Time E.2.8 1.43 R 1.73 0.00 0.00 0.00 0.00 RF ambient conditions- Noise E.6.1 3.51 R 1.73 0.00 0.00 0.00 0.00 RF ambient conditions- reflections E.6.1 3.15 R 1.73 0.00 0.00 0.00 0.00 Probe positioner mechanical tolerance E.6.2 1.2 R 1.73 1.00 1.00 0.69 0.69 Probe positioning with respect to phantom shell E.6.3 1.4 R 1.73 1.00 1.00 0.81 0.81 Extrapolation, interpolation, and integrations algorithms for max. SAR evaluation E.5 3.9 R 1.73 0.00 0.00 0.00 0.00 System check source (dipole) Deviation of experimental dipoles E.6.4 4.8 N 1.00 1.00 1.00 4.80 4.80 Input power and SAR drift measurement 8,6.6.4 5.1 R 1.73 1.00 1.00 2.94 2.94 Dipole axis to liquid distance 8,E.6.6 2.4 R 1.73 1.00 1.00 1.39 1.39 Phantom and tissue parameters Phantom shell uncertainty— shape, thickness, and permittivity E.3.1 3.7 R 1.73 1.00 1.00 2.14 2.14 Uncertainty in SAR correction for deviations in permittivity and conductivity E.3.2 1.9 N 1.00 1.00 0.84 1.90 1.60 Liquid conductivity measurement E.3.3 2.4 R 1.73 0.78 0.71 1.08 0.98 Liquid permittivity measurement E.3.3 4.1 N 1.00 0.78 0.71 3.20 2.91 M Liquid conductivity— temperature uncertainty E.3.4 2.7 R 1.73 0.23 0.26 0.36 0.41 Liquid permittivity— temperature uncertainty E.3.4 4.8 N 1.00 0.23 0.26 1.10 1.25 M Combined Standard Uncertainty RSS 5.56 5.20 Expanded Uncertainty (95% Confidence interval) K=2 11.12 10.41 Page 22 of 40 Report No.: STS2601349H01 10. Conducted Power Measurement 10.1 Test Result 2.4G WLAN BT BLE ModeChannel NumberFrequency (MHz) Conducted Power (dBm) Output Power (mW) 124127.856.10 724377.786.00 1124627.725.92 124126.974.98 724376.044.02 1124626.844.83 124126.884.88 724376.054.03 1124626.064.04 324226.204.17 624376.374.34 924526.674.65 2.4GWIFI 802.11b 802.11g 802.11 n-HT20 802.11 n-HT40 ModeChannel NumberFrequency (MHz) Conducted Power (dBm) Output Power (mW) 024022.231.67 3924411.621.45 7824801.351.36 024021.661.47 3924411.061.28 7824800.801.20 024021.621.45 3924411.021.26 7824800.721.18 π/4-QPSK(2Mbps) 8DPSK(3Mbps) BT GFSK(1Mbps) ModeChannel NumberFrequency (MHz) Conducted Power (dBm) Output Power (mW) 02402-2.420.57 192440-2.940.51 392480-3.280.47 02402-2.460.57 192440-3.060.49 392480-3.390.46 BLE GFSK(1Mbps) GFSK(2Mbps) Page 23 of 40 Report No.: STS2601349H01 5.2G WLAN 5.8G WLAN ModeChannel NumberFrequency (MHz) Conducted Power (dBm) Output Power (mW) 36518012.2616.83 40520012.0716.11 48524012.1116.26 36518011.0612.76 40520011.0312.68 48524010.9812.53 38519010.2210.52 46523010.0210.05 36518011.0912.85 40520010.9912.56 48524010.9612.47 38519010.1810.42 46523010.0410.09 802.11ac-VHT804252108.907.76 5.2G WLAN 802.11ac-VHT20 802.11ac-VHT40 802.11a 802.11 n-HT20 802.11 n-HT40 ModeChannel NumberFrequency (MHz) Conducted Power (dBm) Output Power (mW) 149574512.5017.78 157578511.8015.14 165582511.3213.55 149574511.3713.71 157578510.6611.64 165582510.2310.54 15157559.599.10 15957958.477.03 149574511.4113.84 157578510.8112.05 165582510.3510.84 15157559.258.41 15957958.527.11 802.11ac-VHT8015557758.096.44 5.8G WLAN 802.11ac-VHT40 802.11a 802.11 n-HT20 802.11 n-HT40 802.11ac-VHT20 Page 24 of 40 Report No.: STS2601349H01 11. EUT and Test Setup Photo 11.1 EUT Photo Front side Back side Page 25 of 40 Report No.: STS2601349H01 Top side Bottom side Page 26 of 40 Report No.: STS2601349H01 Left side Right side Page 27 of 40 Report No.: STS2601349H01 11.2 Setup Photo Back Side (separation distance is 0mm) Front side(separation distance is 0mm) Page 28 of 40 Report No.: STS2601349H01 Left Side (separation distance is 0mm) Top side(separation distance is 0mm) Page 29 of 40 Report No.: STS2601349H01 Liquid depth (15 cm) 15cm Page 30 of 40 Report No.: STS2601349H01 12. SAR Result Summary 12.1 Body SAR Band Mod. Test Position Freq. Result 1g (W/Kg) Power Drift(%) Max. Turn-up Power(dBm) Meas. Output Power(dBm) Scaling Factor Scaled SAR (W/Kg) Meas.No. 5.2GHz WLAN 802.11a Front Side 5180 0.031 2.22 12.50 12.26 1.057 0.033 / Back Side 5180 0.073 -1.29 12.50 12.26 1.057 0.077 1 Left Side 5180 0.055 -2.02 12.50 12.26 1.057 0.058 / Top Side 5180 0.024 -3.13 12.50 12.26 1.057 0.025 / 5.8GHz WLAN 802.11a Front Side 5745 0.033 3.21 13.00 12.50 1.122 0.037 / Back Side 5745 0.079 -3.90 13.00 12.50 1.122 0.089 2 Back Side 5785 0.061 0.68 13.00 11.80 1.318 0.080 / Back Side 5825 0.053 -0.67 13.00 11.32 1.472 0.078 / Left Side 5745 0.061 2.43 13.00 12.50 1.122 0.068 / Top Side 5745 0.028 -1.25 13.00 12.50 1.122 0.031 / Note: 1. The test separation of all above table is 0mm. 2. Per KDB 447498 D04, the reported SAR is the measured SAR value adjusted for maximum tune-up tolerance. a. Tune-up scaling Factor = tune-up limit power (mW) / EUT RF power (mW), where tune-up limit is the maximum rated power among all production units. b. Scaled SAR(W/kg)= Measured SAR(W/kg)*Tune-up Scaling Factor 3. Per KDB 865664 D01, Repeated measurement is not required when the original highest measured SAR is <0.80 W/kg Page 31 of 40 Report No.: STS2601349H01 13. Equipment List Kind of Equipment Manufacturer Type No. Serial No. Last Calibration Calibrated Until SAR Test System SATIMO N/A V5.3.15.11 N/A N/A Waveguide MVG SWG5500 SN 13/14 WGA32 2023.07.04 2026.07.03 E-Field Probe MVG SSE2 SN 08/21 EPGO352 2025.09.15 2026.09.14 Dielectric Probe Kit MVG SCLMP SN 32…

Text truncated - open the document above for the full version.

规 格 承 认 书 Approval Sheet 客户名称 Customer 鑫华邦 日期 Data 2025/11/22 产品名称 Product WIFI ANT 客户机型 Models CP01 料号 P/N WIFI：F1415-12RB-060 客户料号 Customer P/N WIFI：A2.010.138.000 规格描述 Specifications Black FPC; WIFI: RF0.81 second-generation connector black coaxial cable, length L = 60mm; 供应商承认签印 Vender Approved By 客户承认签印 Customer Approved By Checked By: Checked By: Audit By: Audit By: Approval By: Approval By: 文件修订履历表 版本 Version 修订内容 Revise The Content 修订人 Revused 核准 Approval 修订日期 Date 备注 Note 深圳市星源创科技有限公司 Shen Zhen Xing Yuan Chuang Technology Co., Ltd 地址：深圳市宝安区沙井街道马安山社区马安山锦胜财富广场C栋610-614 Address:Room 610-614, Building C, Ma 'anshan Jinsheng Fortune Plaza, Ma 'anshan Commu…

Text truncated - open the document above for the full version.
