2BTZV-HP08Smart Fan

www.hawkrown.com USER MANUAL Thank you for choosing our product. Please read this user manual thoroughly before installation and use. Retain this manual for future reference. 1.Always turn off the power before cleaning. 2.Do not disassemble or wash the bathroom fan with water. 3.To clean the fan, remove the entire bathroom fan and use a dry brush or blower. Cleaning & Maintenance Safety Instructions Please Read and follow all safety instructions before use. IMPORTANT TIPS 1.Turn off the power before installation. 2.Keep out of reach of children. 3.Do not disassemble or modify the product. 4.This product is designed for indoor use only. 5.Keep away from flammable materials. Note: Specifications are for reference only. Please refer to the product nameplate for accurate data. Box SizeSeries No. V/Hz Heating Power HKJC-JRQQHSBGSX/HKST-JRQBSBGSX RGB Power Fan Power Speaker Power 1800W Total Power 1920W 40W 5W3W 21′′ x 10′′x 4.5′′ 110V,60Hz BEFORE INSTALLATION 121 4 3 required,1spare 3 required,1spare 4 4 11 1 Machine Parts Parameters (Reference Only) Verify that all parts listed are included. Please read these instructions carefully before installation. Test the machine while plugged in to confirm proper functionality. 2 Support FootsRemote control 3 Expansion tube 4 Self-tapping screw 5 Screw 6 Wall Hanger 7 Manual 8 01/02 CONTENTS BEFORE INSTALLATION 02 03 05 INSTALLATION ABOUT OPERATION/CONTROL 21 COMMON PROBLEM 22 WARRANTY TimeTime+Time- V+ V- Product Instructions ·······················································05 Main Interface Operation ················································05 Remote Control Operation··············································08 APP Operation·····························································11 Connect your machine to the mobile APP ····················11 Connect your speaker to the mobile APP·····················14 Voice Operation····························································20 Portable Use ································································ 03 Fixed Use····································································03 If you want to fix the machine in the same position, you can use wall hanger for fixing. If you do not want the machine to be fixed in the same position, you can use screwsto fix the support footson the machine. The support foots are equipped with rollers for dragging. 1.Place the wall hanger against the wall at the desired location. 2.Use a pencil to mark through all three mounting holes of the wall hanger. 3.Remove the wall hanger to expose the marked points. 4.Drill holes at the marked positions using a power drill. Before installation, connect the power supply and test whether the machineworks properly. If no issues are found, proceed with the installation. INSTALLATION NOTE: Power On and Test Locate Mounting Holes Installation options: Option 1 – Portable Use 03/04 & Power-on Testing Note: With this installation method, no fix support foots are required. Step Insert the expansion plastic tubeinto the pre-drilled holes Use the Expansion Plastic Tube Step Pass three self-tapping screwsthrough the reserved holes of the wall hanger respectively, align each screw with the expansion plastic tube, and use a power tool to drive the screws into the expansion tubes. Secure the Wall Hanger Step After fixing the hanger, align the two reserved hanging openings on the rear of the machine with the two raised buckles of the hanger and clamp them tightly.Then the installation is complete. Secure the Machine Step Option 2 – Fixed Use INSTALLATION Machine Downward OFFFAN RGBBLUETOOTH HIGHLOW TIMERSWING Note: The "High"and"Low" buttons , control the heating modes only. Normal Shutdown Procedure: After turning off the High/Low mode, the fan will continue to operate while " " blinks to display a 30s countdown. Once the countdown ends, the fan will automatically stop, the air deflector will close, and then the panel will descend to reset. Tip-over Protection During Operation: •High/Low Mode Operation: If the machine tips over while running in High/Low mode, the status light bar will turn purple, and " " will blink for a 30s countdown. The fan will continue running for 30s before automatically shutting down. •Pure Fan Mode Operation: If the machine tips over while running in pure Fan mode, the fan will stop immediately without a countdown. Mode Switching Logic: When switching from high/low mode to fan mode, " " will blink for a 30s countdown. The Fan function will activate once the countdown is complete. Product Instructions: Main Interface Operation: 05/06 About Operation/ControlAbout Operation/Control Off: Short press to turn off all functions. Long press to connect to WiFi for mobile network configuration. High Warmth Mode: Short press" High "to activate the High warmth function. The liftable panel will rise to the top position, the louver blades will automatically open (90 ° by default), the fan will start, the high warmth function will activate, and the status light bar will turn red. Short press again to turn off the high warmth function. The status indicator light will turn blue and " " will flash. OFFFAN BLUETOOTHTIMER LOW SWINGRGB HIGH OFF FAN Fan : 1. Start the FanShort press" " Liftable panel rises to top position louver blades auto-open (default 90°)Fan starts,Status light bar turns blue. 2. Wind Speed ControlShort press" " When the " " light stays on → Strong wind mode is activated. Press " " again: the button flashes→ Weak wind mode is activated. 3. Next short press“ ”to turn off the fan functionCloses blades Panel automatically descends. 4. Long press “ ”:Disables status light bar. FAN FAN FAN FAN FAN FAN OFFFAN RGBBLUETOOTH HIGHLOW TIMERSWING Show current Interface Status light bar Main Interface Lyrics Liftable panel Ambient temperature. Time Ambient light Speaker Louver blade (The APP shows the air duct temperature) HIGH Low Warmth Mode: Short press" Low " to activate the Low warmth function. Th…

Text truncated - open the document above for the full version.

JIAXING HUIERPU ELECTRICAL TECHNOLOGY CO.,LTD. BUILDING A2, YONGSHENG HIGH TECH PARK, HAIYAN COUNTY, JIAXING CITY, ZHEJIANG PROVINCE, CHINA U.S. Agent Letter of Attestation To: Federal Communications Commission 7435 Oakland Mills Road, Columbia, MD 21046, USA Date: Jan. 14, 26 Ref: Attestation Statement – Part 2.911(d)(7) filing FCC ID: 2BTZV-HP08 JIAXING HUIERPU ELECTRICAL TECHNOLOGY CO.,LTD. (“the applicant”) certifies that, as of the date of the filing of the application, [Herland International Trading Inc] (“the agent”) is our designated U.S. agent for service of process for the above reference FCC ID. The applicant accepts to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. The applicant further acknowledges it is our responsibility to inform the FCC whenever the agent information changes. [Herland International Trading Inc] ("the agent) understand it is the agent's obligation to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address. Designated U.S. Agent Company Name: Herland International Trading Inc FRN: 0036324101 Address: 1370 Valley Vista Dr Ste 200 Diamond Bar, CA 91765 Signature: Contact Person: Jianfeng Gao Tel: 001-909-772-1888 Email: jianfenggao@hyunturlee- commerce.com Applicant Company Name: JIAXING HUIERPU ELECTRICAL TECHNOLOGY CO.,LTD. FRN: 0037821014 Address: BUILDING A2, YONGSHENG HIGH TECH PARK, HAIYAN COUNTY, JIAXING CITY, ZHEJIANG PROVINCE, CHINA Signature: Contact Person: Tony Tan Tel: 18126454662 Email: [email protected]

JIAXING HUIERPU ELECTRICAL TECHNOLOGY CO.,LTD. BUILDING A2, YONGSHENG HIGH TECH PARK, HAIYAN COUNTY, JIAXING CITY, ZHEJIANG PROVINCE, CHINA Attestation Statements Not Covered Entity Applicant & Not Covered Equipment To: Federal Communications Commission Date: Jan. 14, 26 7435 Oakland Mills Road, Columbia, MD 21046, USA Ref: Information Required by Section 2.911(d)(5)(i) & (ii) FCC ID: 2BTZV-HP08 JIAXING HUIERPU ELECTRICAL TECHNOLOGY CO.,LTD. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List, established pursuant to § 1.50002 of reference chapter, as an entity producing “covered” communication equipment. The equipment for which authorization is sought is not “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List that prohibited from receiving an equipment authorization pursuant to section § 2.903 of the FCC rules. Sincerely yours, Applicant Signature Printed Name: Tony Tan Title:Manager Address: BUILDING A2, YONGSHENG HIGH TECH PARK, HAIYAN COUNTY, JIAXING CITY, ZHEJIANG PROVINCE, CHINA Tel.: 18126454662 Email: [email protected]

1 | P a g e JIAXING HUIERPU ELECTRICAL TECHNOLOGY CO.,LTD. BUILDING A2, YONGSHENG HIGH TECH PARK, HAIYAN COUNTY, JIAXING CITY, ZHEJIANG PROVINCE, CHINA Attestation Statements To: Federal Communications Commission Date: Jan. 14, 26 7435 Oakland Mills Road, Columbia, MD 21046, USA Subject: Attestation of Compliance with FCC Covered List Software Requirements FCC ID: [2BTZV-HP08] Product Name: [Smart Fan] This letter serves as an attestation that the equipment identified above ☐ is / ☒ is not (select one) "covered" software as defined under the Federal Communications Commission (FCC) Covered List requirements, as outlined in FCC 22-84 and KDB 986446. Specifically, the undersigned certifies that the equipment for which authorization is sought: 1. Does not contain cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors, assignees, parents, subsidiaries, affiliates, or any entity that has rebranded or relabeled software produced by the aforementioned entities. 2. Does not have the capability to store, run, or deliver any software identified on the FCC Covered List, including but not limited to cybersecurity and anti-virus software. To support this attestation, the appendix evaluation documentation has been prepared and is included in the certification filing. This attestation is based on a thorough evaluation of the device's design, functionality, and software environment. The undersigned affirms that the information provided is accurate and complete to the best of their knowledge. Sincerely yours, Applicant Signature Printed Name: Tony Tan Title:Manager Address: BUILDING A2, YONGSHENG HIGH TECH PARK, HAIYAN COUNTY, JIAXING CITY, ZHEJIANG PROVINCE, CHINA Tel.: 18126454662 Email: [email protected] 2 | P a g e Evaluation regarding to the Covered List Software: Compliance Methodology Evaluation Process Results Device is Inherent compliance ☒ The Chipset(s) used is limited to run the Cybersecurity or anti-virus software. The MCU “ W701“, The RF chip “ W701“ and “ AB5602D “ don’t support the mentioned function. ☐ The Memory used is limited to run the Cybersecurity or anti-virus software. The memory size is XXX, so don’t support the mentioned function. ☐ There is storage capacity limitation for store or install the Cybersecurity or anti-virus software. The storage capacity is XXX, so don’t support the mentioned function. ☐ Operating system used is limited to run, install or deliver the Cybersecurity or anti-virus software. The Operating system “XXX“ don’t support the mentioned function. Device is not Inherent compliance ☐ Evaluation Based on Software Bill of Materials (SBoM) See attached “SBoM“ Note:The SBoM content is limited to the scope of covered list software (e.g. antivirus and cybersecurity software). ☐ Evaluation Based on Scan for Software on the device ☐ Evaluation Based on Filesystem scan ☐ Evaluation Based on Running software check

JIAXING HUIERPU ELECTRICAL TECHNOLOGY CO.,LTD. BUILDING A2, YONGSHENG HIGH TECH PARK, HAIYAN COUNTY, JIAXING CITY, ZHEJIANG PROVINCE, CHINA Date: Jan. 14, 26 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request for: FCC ID: 2BTZV-HP08 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request permanent confidential treatment of the exhibits accompanying this certification application as outlined below : ⎯ Block Diagram ⎯ Schematics ⎯ Operational Description The above exhibits contain trade secrets and/or proprietary information that are not publicly available and materials that the Applicant has spent considerable efforts in developing. Public disclosure of these may be harmful to the Applicant and give an unfair advantage to competitors on the market. Sincerely, Applicant Signature Printed Name: Tony Tan Title:Manager Address: BUILDING A2, YONGSHENG HIGH TECH PARK, HAIYAN COUNTY, JIAXING CITY, ZHEJIANG PROVINCE, CHINA Tel.: 18126454662 Email: [email protected]

JIAXING HUIERPU ELECTRICAL TECHNOLOGY CO.,LTD. BUILDING A2, YONGSHENG HIGH TECH PARK, HAIYAN COUNTY, JIAXING CITY, ZHEJIANG PROVINCE, CHINA Date: Jan. 14, 26 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization for FCC ID: 2BTZV-HP08 I, the undersigned, hereby authorize (Shenzhen DL Testing Technology Co., Ltd.) to act on our behalf in all matters relating to this application for equipment certification. Any act carried out by (Shenzhen DL Testing Technology Co., Ltd.) shall have the same effect as our own and I acknowledge that all responsibility for complying with the terms and conditions of certification, as specified by DERYCOM CERTIFICATION SERVICES, INC., still resides with (JIAXING HUIERPU ELECTRICAL TECHNOLOGY CO.,LTD. ). We certify that we are not subject to a denial of federal benefits that includes FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862, and that no party to the application, as defined in 47 CFR §1.2002(b), is subject to a denial of federal benefits that includes FCC benefits pursuant to that section. Sincerely, Applicant Signature Printed Name: Tony Tan Title:Manager Address: BUILDING A2, YONGSHENG HIGH TECH PARK, HAIYAN COUNTY, JIAXING CITY, ZHEJIANG PROVINCE, CHINA Tel.: 18126454662 Email: [email protected]

JIAXING HUIERPU ELECTRICAL TECHNOLOGY CO.,LTD. Product Similarity Declaration FCC ID:2BTZV-HP08 Applicant: JIAXING HUIERPU ELECTRICAL TECHNOLOGY CO.,LTD. Address: BUILDING A2, YONGSHENG HIGH TECH PARK, HAIYAN COUNTY, JIAXING CITY, ZHEJIANG PROVINCE, CHINA Manufacturer: JIAXING HUIERPU ELECTRICAL TECHNOLOGY CO.,LTD. Address: BUILDING A2, YONGSHENG HIGH TECH PARK, HAIYAN COUNTY, JIAXING CITY, ZHEJIANG PROVINCE, CHINA Product Name: Smart Fan Trade Mark: N/A Model Number: HP08, ZT41, ZT42, ZT43, ZT44, ZT45, HP42, HP43, HP44, HP45 We (JIAXING HUIERPU ELECTRICAL TECHNOLOGY CO.,LTD.) hereby state that all the models are electrical identical including the same software parameter and hardware design (i.e., circuit design, PCB Layout, RF module/circuit, antenna type(s) and antenna location, components on PCB, etc.,), same mechanical structure and design (including product enclosure, materials, etc.,), All models are the same as the samples except model name and appearance color. Applicant Signature Printed Name: Tony Tan Title:Manager Address: BUILDING A2, YONGSHENG HIGH TECH PARK, HAIYAN COUNTY, JIAXING CITY, ZHEJIANG PROVINCE, CHINA Tel.: 18126454662 Email: [email protected]

Shenzhen DL Testing Technology Co., Ltd. FCC ID: 2BTZV-HP08 EUT PHOTO(External Photos) Shenzhen DL Testing Technology Co., Ltd. FCC ID: 2BTZV-HP08 Shenzhen DL Testing Technology Co., Ltd. FCC ID: 2BTZV-HP08 Shenzhen DL Testing Technology Co., Ltd. FCC ID: 2BTZV-HP08 ※※※※※ END OF REPORT ※※※※※

Size: 25*15mm Model: HP08 FCC ID: 2BTZV-HP08 Label location

Shenzhen DL Testing Technology Co., Ltd. FCC ID: 2BTZV-HP08 EUT PHOTO(Internal Photos) Shenzhen DL Testing Technology Co., Ltd. FCC ID: 2BTZV-HP08 Shenzhen DL Testing Technology Co., Ltd. FCC ID: 2BTZV-HP08 BT(BLE)/WLAN 2.4G ANT Shenzhen DL Testing Technology Co., Ltd. FCC ID: 2BTZV-HP08 Shenzhen DL Testing Technology Co., Ltd. FCC ID: 2BTZV-HP08 Shenzhen DL Testing Technology Co., Ltd. FCC ID: 2BTZV-HP08 Shenzhen DL Testing Technology Co., Ltd. FCC ID: 2BTZV-HP08 Shenzhen DL Testing Technology Co., Ltd. FCC ID: 2BTZV-HP08 BT(EDR) ANT Shenzhen DL Testing Technology Co., Ltd. FCC ID: 2BTZV-HP08 ※※※※※ END OF REPORT ※※※※※

FCC ID:2BTZV-HP08 RF Exposure Evaluation Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in KDB 447498 D01 V06 and 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. Test Result of RF Exposure Evaluation wifi 2.4G mode Channel Output power to antenna (dBm) Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result 802.11b 17.148 51.8561 0.01852 1.0 PASS 802.11g 13.781 23.8836 0.00853 1.0 PASS 802.11n HT20 14.878 30.7468 0.01098 1.0 PASS Remark: antenna gain=2.54 dBi For BLE Output power to antenna (dBm) Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result -3.00 0.5012 0.00018 1.0 PASS Remark: antenna gain=2.54dBi For EDR Output power to antenna (dBm) Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result -1.71 0.6745 0.00013 1.0 PASS Remark: antenna gain=0 dBi For Simultaneous transmitting, 1): The sum of the ratios of the spatially averaged results to the applicable frequency dependent MPE limits =0.01852/1 + 0.00013/1= 0.01865 < 1 Since the sum of the MPE ratios for all simultaneously transmitting antennas incorporated in the device is ≤ 1.0, the EUT is considered to satisfy MPE compliance for simultaneous transmission operations.
