www.hawkrown.com USER MANUAL Thank you for choosing our product. Please read this user manual thoroughly before installation and use. Retain this manual for future reference. 1.Always turn off the power before cleaning. 2.Do not disassemble or wash the bathroom fan with water. 3.To clean the fan, remove the entire bathroom fan and use a dry brush or blower. Cleaning & Maintenance Safety Instructions Please Read and follow all safety instructions before use. IMPORTANT TIPS 1.Turn off the power before installation. 2.Keep out of reach of children. 3.Do not disassemble or modify the product. 4.This product is designed for indoor use only. 5.Keep away from flammable materials. Note: Specifications are for reference only. Please refer to the product nameplate for accurate data. BEFORE INSTALLATION 1111 211 1 1 1 Machine Parts Parameters (Reference Only) Verify that all parts listed are included. Ensure the fan dimensions are compatible with your duct opening. Test the fan while plugged in to confirm proper functionality. 2 Panel 3 4 Remote control 5 Clamp 6 Manual 1 1 7 Fixed accessories Transition frame 8 Ventilation pipe 9 Wiring terminal 10 11 Glove 01/02 CONTENTS BEFORE INSTALLATION 02 INSTALLATION 03 ABOUT MICROPHONES 09 10 ABOUT OPERATION/CONTROL 28 COMMON PROBLEM 29 WARRANTY Step 1: Connect the Panel .........................................................3 Step 2: Power On and Remote Control Pairing Test ..................3 Step 3: Prepare Ceiling Opening.......................... ..................4 Step 4: Installation Adapter Frame..............................................5 Step 5: Install Ventilation Pipe............................ ..................6 Step 6: Install Machine................. ........................................... .6 Step 7: Insert the Air Outlet into the Machine..............................8 Step 8: Correctly Connect the Panel........................................... 8 Step 9: Compress the Spring Clips on Both Sides...................... 8 Auxiliary accessories Cable tie x2 1 12 Adhesive tape x2 (for machine) (for remote control/ for transition frame) X6 X6 Product Instructions·······················································10 Remote Control Operation··············································11 APP Operation·····························································17 Voice Operation····························································26 VOL+ VOL- APP RGBRGB RGB ON OFF ON OFF ON CCT+ CCT- ONOFF OFF Box SizePanel Size Fan Power Product Name V/Hz Fan Heater Light Power RGB Power 45W Heat Power 1800W 32W 14W Audio Power 10W 20.12′′x11.18′′12.6′′ x 20.08′′ 110V,60Hz Microphone 11.42" 11" 18.7′′ Note: Minimum 11-inch roof-to-ceiling clearance required for installation. Connect the front panel to the machine .The panel must be connected before performing functional tests. 1.Turn on the power to test the machine. 2.After confirming the test is successful, disconnect the panel from the machine. INSTALLATION 1. Please read these instructions carefully before installation. 2. Installation and wiring must be carried out by a qualified electrician. 3. Always turn off the power supply before installation to prevent electric shock. Note:Infra-red remote control should be pointed directly at the device to ensure proper signal reception and reaction. The panel must be removed after testing to allow the box to be installed on top. Connect the Panel Notice Step Power On and Remote Control Test 03/04 21 & Power-on Testing Note: After securing the machine in place, proceed with the remaining steps by follow- ing the instructions starting from Step 5. Step Use appropriate tools to cut an opening measuring 18.7x11.42 inches at the desired installation location in the ceiling.(You can also use the size paper prepared for you to fix the position and make the opening.) Prepare Ceiling Opening Step INSTALLATION Infra-red Remote Control VOL+ VOL- APP RGBRGB RGB ON OFF ON OFF ON CCT+ CCT- ONOFF OFF (lf you plan to install the bathroom fan on a single-side supported frame—such as in an attic or across ceiling beams-this method is suitable) 1.Ensure both side mounting brackets are correctly positioned and aligned with the support beam. 2.Use washers and screws to securely fasten the machine to the beam. Maintain level align-ment during installation to ensure proper operation and stability. Option 1 – Side Support Installation 7 7 3 Note: •Insert the transition frame into the ceiling opening above. •Above the opening, expand the transition frame towards both ends (adjustable range: 14.2 in ~ 24 in). •Once both ends of the transition frame touch the crossbeams, secure it to the beams using self-tapping screws and washers . Installation Adapter Frame Step 05/06 •Securely wrap and seal the ventilation pipe to the pre-reserved pipeline connection with adhesive tape . •Remove the air outlet grille from the main unit, and secure the grille to the other end of the ventilation pipe using a clamp . Insert the machine into the ceiling opening above and connect it to the power supply. Install Ventilation Pipe Step Install Machine Step INSTALLATIONINSTALLATION 11 5 5 11 8 8 11 8 pre - reserved pipeline air outlet air outlet (If additional reinforcement is needed, use zip ties or tape from the auxiliary installation accessories for further fixation) 3 7 7 1.The crossbeam must run parallel to the long side of the ceiling opening. •If the existing crossbeam is aligned with the short side, install additional wooden battens along the long side before securing the transition frame. 2. If the maximum extension of the transition frame cannot span between crossbeams: •Prepare wooden battens of sufficient length. •First, fix them to the crossbeams. •Then attach the transition frame to the battens. Option 2 – Top Entry Installation 07/08 Connect to Power Supply Black wire: Live wire (L) White wire: Neutral wire (N) Green wire: Ground wire (G) Improper electrical connection may result…
Text truncated - open the document above for the full version.
JIAXING HUIERPU ELECTRICAL TECHNOLOGY CO.,LTD. BUILDING A2, YONGSHENG HIGH TECH PARK, HAIYAN COUNTY, JIAXING CITY, ZHEJIANG PROVINCE, CHINA Attestation Statements Not Covered Entity Applicant & Not Covered Equipment To: Federal Communications Commission Date: Jan. 4, 26 7435 Oakland Mills Road, Columbia, MD 21046, USA Ref: Information Required by Section 2.911(d)(5)(i) & (ii) FCC ID: 2BTZV-HP24 JIAXING HUIERPU ELECTRICAL TECHNOLOGY CO.,LTD. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List, established pursuant to § 1.50002 of reference chapter, as an entity producing “covered” communication equipment. The equipment for which authorization is sought is not “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List that prohibited from receiving an equipment authorization pursuant to section § 2.903 of the FCC rules. Sincerely yours, Applicant Signature Printed Name: Tony Tan Title:Manager Address: BUILDING A2, YONGSHENG HIGH TECH PARK, HAIYAN COUNTY, JIAXING CITY, ZHEJIANG PROVINCE, CHINA Tel.: 18126454662 Email: [email protected]
1 | P a g e JIAXING HUIERPU ELECTRICAL TECHNOLOGY CO.,LTD. BUILDING A2, YONGSHENG HIGH TECH PARK, HAIYAN COUNTY, JIAXING CITY, ZHEJIANG PROVINCE, CHINA Attestation Statements To: Federal Communications Commission Date: Jan. 5, 26 7435 Oakland Mills Road, Columbia, MD 21046, USA Subject: Attestation of Compliance with FCC Covered List Software Requirements FCC ID: [2BTZV-HP24] Product Name: [Fan Heater] This letter serves as an attestation that the equipment identified above ☐ is / ☒ is not (select one) "covered" software as defined under the Federal Communications Commission (FCC) Covered List requirements, as outlined in FCC 22-84 and KDB 986446. Specifically, the undersigned certifies that the equipment for which authorization is sought: 1. Does not contain cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors, assignees, parents, subsidiaries, affiliates, or any entity that has rebranded or relabeled software produced by the aforementioned entities. 2. Does not have the capability to store, run, or deliver any software identified on the FCC Covered List, including but not limited to cybersecurity and anti-virus software. To support this attestation, the appendix evaluation documentation has been prepared and is included in the certification filing. This attestation is based on a thorough evaluation of the device's design, functionality, and software environment. The undersigned affirms that the information provided is accurate and complete to the best of their knowledge. Sincerely yours, Applicant Signature Printed Name: Tony Tan Title:Manager Address: BUILDING A2, YONGSHENG HIGH TECH PARK, HAIYAN COUNTY, JIAXING CITY, ZHEJIANG PROVINCE, CHINA Tel.: 18126454662 Email: [email protected] 2 | P a g e Evaluation regarding to the Covered List Software: Compliance Methodology Evaluation Process Results Device is Inherent compliance ☒ The Chipset(s) used is limited to run the Cybersecurity or anti-virus software. The MCU “ W701“, The RF chip “ W701“ and “ AB5705C “ don’t support the mentioned function. ☐ The Memory used is limited to run the Cybersecurity or anti-virus software. The memory size is XXX, so don’t support the mentioned function. ☐ There is storage capacity limitation for store or install the Cybersecurity or anti-virus software. The storage capacity is XXX, so don’t support the mentioned function. ☐ Operating system used is limited to run, install or deliver the Cybersecurity or anti-virus software. The Operating system “XXX“ don’t support the mentioned function. Device is not Inherent compliance ☐ Evaluation Based on Software Bill of Materials (SBoM) See attached “SBoM“ Note:The SBoM content is limited to the scope of covered list software (e.g. antivirus and cybersecurity software). ☐ Evaluation Based on Scan for Software on the device ☐ Evaluation Based on Filesystem scan ☐ Evaluation Based on Running software check
JIAXING HUIERPU ELECTRICAL TECHNOLOGY CO.,LTD. BUILDING A2, YONGSHENG HIGH TECH PARK, HAIYAN COUNTY, JIAXING CITY, ZHEJIANG PROVINCE, CHINA U.S. Agent Letter of Attestation To: Federal Communications Commission 7435 Oakland Mills Road, Columbia, MD 21046, USA Date: Jan. 4, 26 Ref: Attestation Statement – Part 2.911(d)(7) filing FCC ID: 2BTZV-HP24 JIAXING HUIERPU ELECTRICAL TECHNOLOGY CO.,LTD. (“the applicant”) certifies that, as of the date of the filing of the application, [Herland International Trading Inc] (“the agent”) is our designated U.S. agent for service of process for the above reference FCC ID. The applicant accepts to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. The applicant further acknowledges it is our responsibility to inform the FCC whenever the agent information changes. [Herland International Trading Inc] ("the agent) understand it is the agent's obligation to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address. Designated U.S. Agent Company Name: Herland International Trading Inc FRN: 0036324101 Address: 1370 Valley Vista Dr Ste 200 Diamond Bar, CA 91765 Signature: Contact Person: Jianfeng Gao Tel: 001-909-772-1888 Email: jianfenggao@hyunturlee- commerce.com Applicant Company Name: JIAXING HUIERPU ELECTRICAL TECHNOLOGY CO.,LTD. FRN: 0037821014 Address: BUILDING A2, YONGSHENG HIGH TECH PARK, HAIYAN COUNTY, JIAXING CITY, ZHEJIANG PROVINCE, CHINA Signature: Contact Person: Tony Tan Tel: 18126454662 Email: [email protected]
JIAXING HUIERPU ELECTRICAL TECHNOLOGY CO.,LTD. BUILDING A2, YONGSHENG HIGH TECH PARK, HAIYAN COUNTY, JIAXING CITY, ZHEJIANG PROVINCE, CHINA Date: Jan. 4, 26 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request for: FCC ID: 2BTZV-HP24 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request permanent confidential treatment of the exhibits accompanying this certification application as outlined below : ⎯ Block Diagram ⎯ Schematics ⎯ Operational Description The above exhibits contain trade secrets and/or proprietary information that are not publicly available and materials that the Applicant has spent considerable efforts in developing. Public disclosure of these may be harmful to the Applicant and give an unfair advantage to competitors on the market. Sincerely, Applicant Signature Printed Name: Tony Tan Title:Manager Address: BUILDING A2, YONGSHENG HIGH TECH PARK, HAIYAN COUNTY, JIAXING CITY, ZHEJIANG PROVINCE, CHINA Tel.: 18126454662 Email: [email protected]
JIAXING HUIERPU ELECTRICAL TECHNOLOGY CO.,LTD. BUILDING A2, YONGSHENG HIGH TECH PARK, HAIYAN COUNTY, JIAXING CITY, ZHEJIANG PROVINCE, CHINA Date: Jan. 4, 26 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization for FCC ID: 2BTZV-HP24 I, the undersigned, hereby authorize (Shenzhen DL Testing Technology Co., Ltd.) to act on our behalf in all matters relating to this application for equipment certification. Any act carried out by (Shenzhen DL Testing Technology Co., Ltd.) shall have the same effect as our own and I acknowledge that all responsibility for complying with the terms and conditions of certification, as specified by DERYCOM CERTIFICATION SERVICES, INC., still resides with (JIAXING HUIERPU ELECTRICAL TECHNOLOGY CO.,LTD. ). We certify that we are not subject to a denial of federal benefits that includes FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862, and that no party to the application, as defined in 47 CFR §1.2002(b), is subject to a denial of federal benefits that includes FCC benefits pursuant to that section. Sincerely, Applicant Signature Printed Name: Tony Tan Title:Manager Address: BUILDING A2, YONGSHENG HIGH TECH PARK, HAIYAN COUNTY, JIAXING CITY, ZHEJIANG PROVINCE, CHINA Tel.: 18126454662 Email: [email protected]
JIAXING HUIERPU ELECTRICAL TECHNOLOGY CO.,LTD. Product Similarity Declaration FCC ID:2BTZV-HP24 Applicant: JIAXING HUIERPU ELECTRICAL TECHNOLOGY CO.,LTD. Address: BUILDING A2, YONGSHENG HIGH TECH PARK, HAIYAN COUNTY, JIAXING CITY, ZHEJIANG PROVINCE Manufacturer: JIAXING HUIERPU ELECTRICAL TECHNOLOGY CO.,LTD. Address: BUILDING A2, YONGSHENG HIGH TECH PARK, HAIYAN COUNTY, JIAXING CITY, ZHEJIANG PROVINCE Product Name: Fan Heater Trade Mark: N/A Model Number: HP24, HP20, HP20-A, HP20-B, HP24-A, ZT19, ZT19-A, ZT19-B, ZT23, ZT23-A, ZT23-B We (JIAXING HUIERPU ELECTRICAL TECHNOLOGY CO.,LTD.) hereby state that all the models are electrical identical including the same software parameter and hardware design (i.e., circuit design, PCB Layout, RF module/circuit, antenna type(s) and antenna location, components on PCB, etc.,), same mechanical structure and design (including product enclosure, materials, etc.,), All models are the same as the samples except model name and appearance color. Applicant Signature Printed Name: Tony Tan Title:Manager Address: BUILDING A2, YONGSHENG HIGH TECH PARK, HAIYAN COUNTY, JIAXING CITY, ZHEJIANG PROVINCE, CHINA Tel.: 18126454662 Email: [email protected]
Shenzhen DL Testing Technology Co., Ltd. FCC ID: 2BTZV-HP24 EUT PHOTO(External Photos) Shenzhen DL Testing Technology Co., Ltd. FCC ID: 2BTZV-HP24 Shenzhen DL Testing Technology Co., Ltd. FCC ID: 2BTZV-HP24 Shenzhen DL Testing Technology Co., Ltd. FCC ID: 2BTZV-HP24 ※※※※※ END OF REPORT ※※※※※
Size: 25*15mm Model: HP24 FCC ID: 2BTZV-HP24 Label location
Shenzhen DL Testing Technology Co., Ltd. FCC ID: 2BTZV-HP24 EUT PHOTO(Internal Photos) Shenzhen DL Testing Technology Co., Ltd. FCC ID: 2BTZV-HP24 Shenzhen DL Testing Technology Co., Ltd. FCC ID: 2BTZV-HP24 Shenzhen DL Testing Technology Co., Ltd. FCC ID: 2BTZV-HP24 Shenzhen DL Testing Technology Co., Ltd. FCC ID: 2BTZV-HP24 BT(EDR) ANT Shenzhen DL Testing Technology Co., Ltd. FCC ID: 2BTZV-HP24 Shenzhen DL Testing Technology Co., Ltd. FCC ID: 2BTZV-HP24 Shenzhen DL Testing Technology Co., Ltd. FCC ID: 2BTZV-HP24 Shenzhen DL Testing Technology Co., Ltd. FCC ID: 2BTZV-HP24 BT(BLE)/WLAN 2.4G ANT Shenzhen DL Testing Technology Co., Ltd. FCC ID: 2BTZV-HP24 ※※※※※ END OF REPORT ※※※※※
FCC ID:2BTZV-HP24 RF Exposure Evaluation Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in KDB 447498 D01 V06 and 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. Test Result of RF Exposure Evaluation wifi 2.4G mode Channel Output power to antenna (dBm) Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result 802.11b 17.031 50.4778 0.01802 1.0 PASS 802.11g 13.650 23.1739 0.00827 1.0 PASS 802.11n HT20 14.755 29.8882 0.01067 1.0 PASS Remark: antenna gain=2.54 dBi For BLE Output power to antenna (dBm) Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result -3.08 0.4920 0.00018 1.0 PASS Remark: antenna gain=2.54dBi For EDR Output power to antenna (dBm) Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result -1.88 0.6486 0.00011 1.0 PASS Remark: antenna gain=-0.58dBi For Simultaneous transmitting, 1): The sum of the ratios of the spatially averaged results to the applicable frequency dependent MPE limits =0.01802/1 + 0.00011/1= 0.0182 < 1 Since the sum of the MPE ratios for all simultaneously transmitting antennas incorporated in the device is ≤ 1.0, the EUT is considered to satisfy MPE compliance for simultaneous transmission operations.
Inverted F Antenna Specification ITEM ANT SPEC Model Name 2.4G ANT Horizontal Vertical 2400MHz 2400MHz2500MHz2400MHz2400MHz 2500MHz Center Frequency -1.26 -0.76 -0.58 -5.25 -2.46 -1.86 MAX. Gain -0.58dB Polarization Horizontal and Vertical Azimuth Beam Pattern Omni-directional Impedance 50 Ohm Antenna Length 38.20mm Antenna Photo & Length (mm) JIAXING HUIERPU ELECTRICAL TECHNOLOGY CO.,LTD. BUILDING A2, YONGSHENG HIGH TECH PARK, HAIYAN COUNTY, JIAXING CITY, ZHEJIANG PROVINCE, CHINA Horizontal: 2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -40 Scale: 5/div Gain(dB) Frequency (MHz) Max Min Avg 2400 -1.26174 -30.0801 -7.18716 2450 -0.765802 -36.5604 -7.48023 2500 -0.585582 -22.0315 -6.59127 Vertical: 2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -30 Scale: 5/div Gain(dB) Frequency (MHz) Max Min Avg 2400 -5.2537 -22.1424 -12.4294 2450 -2.4652 -24.5837 -10.4702 2500 -1.86120 -29.5214 -9.20432
Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-251030140R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 1 of 46 FCC Part 15C Test Report FCC ID: 2BTZV-HP24 Applicant: JIAXING HUIERPU ELECTRICAL TECHNOLOGY CO.,LTD. Address: BUILDING A2, YONGSHENG HIGH TECH PARK, HAIYAN COUNTY, JIAXING CITY, ZHEJIANG PROVINCE, CHINA Manufacturer: JIAXING HUIERPU ELECTRICAL TECHNOLOGY CO.,LTD. Address: BUILDING A2, YONGSHENG HIGH TECH PARK, HAIYAN COUNTY, JIAXING CITY, ZHEJIANG PROVINCE, CHINA Product Name: Fan Heater Trade Mark: N/A Model Number: HP24, HP20, HP20-A, HP20-B, HP24-A, ZT19, ZT19-A, ZT19-B, ZT23, ZT23-A, ZT23-B Date of Receipt: Oct. 30, 2025 Test Date: Oct. 30, 2025 - Jan. 05, 2026 Date of Report: Jan. 05, 2026 Prepared By: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Comprehensive Building, Tongzhou Electronics Longgang Factory Area, No.1 Baolong Fifth Road, Baolong Community, Baolong Street, Longgang District, Shenzhen, China Applicable Standards: FCC PART 15 C 15.247 ANSI C63.10:2020 Test Result: Pass Report Number: DLE-251030140R Prepared (Test Engineer): Alisa Song Reviewer (Supervisor): Jack Bu Approved (Manager): Jade Yang This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-251030140R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 2 of 46 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 4 1.1 MEASUREMENT UNCERTAINTY 4 2 . GENERAL INFORMATION 5 2.1 GENERAL DESCRIPTION OF EUT 5 2.2 DESCRIPTION OF TEST MODES 6 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 6 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 7 2.5 TABLE OF PARAMETERS OF TEST SOFTWARE SETTING 7 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 8 3 . EMC EMISSION TEST 9 3.1 CONDUCTED EMISSION MEASUREMENT 9 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 9 3.1.2 TEST PROCEDURE 9 3.1.3 DEVIATION FROM TEST STANDARD 9 3.1.4 TEST SETUP 10 3.1.5 EUT OPERATING CONDITIONS 10 3.1.6 TEST RESULTS 11 3.2 RADIATED EMISSION MEASUREMENT 13 3.2.1 RADIATED EMISSION LIMITS 13 3.2.2 TEST PROCEDURE 14 3.2.3 DEVIATION FROM TEST STANDARD 14 3.2.4 TEST SETUP 14 3.2.5 EUT OPERATING CONDITIONS 15 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 16 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 17 3.2.8 TEST RESULTS (1GHZ~25GHZ) 19 3.3 RADIATED BAND EMISSION MEASUREMENT 21 3.3.1 TEST REQUIREMENT: 21 3.3.2 TEST PROCEDURE 21 3.3.3 DEVIATION FROM TEST STANDARD 21 3.3.4 TEST SETUP 22 3.3.5 EUT OPERATING CONDITIONS 22 3.4 CONDUCTED BAND EDGE EMISSION&CONDUCTED SPURIOUS EMISSIONS MEASUREMENT 25 3.4.1 APPLICABLE STANDARD 25 3.4.2 TEST PROCEDURE 25 3.4.3 DEVIATION FROM STANDARD 25 3.4.4 TEST SETUP 25 3.4.5 EUT OPERATION CONDITIONS 26 3.4.6 TEST RESULTS 26 4 . PEAK OUTPUT POWER 32 4.1 APPLIED PROCEDURES / LIMIT 32 Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-251030140R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 3 of 46 Table of Contents Page 4.1.1 TEST PROCEDURE 32 4.1.2 DEVIATION FROM STANDARD 32 4.1.3 TEST SETUP 32 4.1.4 EUT OPERATION CONDITIONS 32 4.1.5 TEST RESULTS 33 5 . NUMBER OF HOPPING CHANNEL 35 5.1 APPLIED PROCEDURES / LIMIT 35 5.1.1 TEST PROCEDURE 35 5.1.2 DEVIATION FROM STANDARD 35 5.1.3 TEST SETUP 35 5.1.4 EUT OPERATION CONDITIONS 35 5.1.5 TEST RESULTS 35 6 . BANDWIDTH TEST 37 6.1 APPLIED PROCEDURES / LIMIT 37 6.1.1 TEST PROCEDURE 37 6.1.2 DEVIATION FROM STANDARD 37 6.1.3 TEST SETUP 37 6.1.4 EUT OPERATION CONDITIONS 37 6.1.5 TEST RESULTS 38 7 . HOPPING CHANNEL SEPARATION MEASUREMENT 40 7.1 APPLIED PROCEDURES / LIMIT 40 7.1.1 TEST PROCEDURE 40 7.1.2 DEVIATION FROM STANDARD 40 7.1.3 TEST SETUP 40 7.1.4 EUT OPERATION CONDITIONS 40 7.1.5 TEST RESULTS 40 8 . DWELL TIME OF OCCUPANCY 42 8.1 APPLIED PROCEDURES / LIMIT 42 8.1.1 TEST PROCEDURE 42 8.1.2 DEVIATION FROM STANDARD 42 8.1.3 TEST SETUP 42 8.1.4 EUT OPERATION CONDITIONS 42 8.1.5 TEST RESULTS 43 9 . ANTENNA REQUIREMENT 46 9.1 STANDARD REQUIREMENT 46 9.2 EUT ANTENNA 46 10 . TEST SETUP PHOTO 46 11 . EUT PHOTO 46 Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-251030140R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 4 of 46 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247(c) Radiated Spurious Emission PASS 15.205 Band Edge Emission PASS 15.247(b)(1) Peak Output Power PASS 15.247(a)(iii) Number of Hopping Frequency PASS 15.247(a)(iii) Dwell Time PASS 15.247(a)(1) Bandwidth PASS 15.247(a)(1) Hopping Channel Separation PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Test lab: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Comprehensive Building, Tongzhou Electronics Longgang Factory Area, No.1 Baolong Fifth Road, Baolong Community, Baolong Street, Longgang District, Shenzhen, China FCC Test Firm Registration Number: 854456 Designation Number: CN1307 IC Registered No.: 27485 CAB ID.: CN0118 1.1 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2,providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±2.56dB 2 RF power,conducted ±0.42dB 3 Spurious emissions,conducted ±2.76dB 4 All emissions,radiated(<1G) ±3.65dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% 8 20dB Bandwidth ±0.2MHz 9 Power Spectral Density ±0.3dBm Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-251030140R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 5 of 46 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF E…
