2BU76-H08smartphone
Shenzhen Zhimei Technology Co., Ltd.
Click to zoom
Application Details
- Equipment Class
- PCE - PCS Licensed Transmitter held to ear
- Date of Grant
- Apr 30, 2026
- Application Purpose
- Original Equipment
- Equipment Note
- smartphone
- Frequency Range
- 824.00000000 - 849.00000000
- Country
- China
Documents & Files
Document Text
Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Users Manual
smartphone H08 TD-LTE Terminal User Manual (Note: The type approval code is displayed in the form of a label) I. Basic Product Overview Model: H08; Product Name: TD-LTE Terminal (hereinafter referred to as the "Terminal"). This terminal is waterproof and dustproof, integrated with a public network communication module. It supports 4G calls, data communication, and high-precision GPS positioning. II. Product Application Scenarios Suitable for various industries including outdoor travel, express transportation, and property management. III. Main Product Functions 1. Precise Positioning: Equipped with a built-in high-precision GPS module, supporting the GPS positioning system. 2. SMS Sending and Receiving: Supports SMS transmission with stable and reliable communication, ensuring communication needs in remote areas or regions with unstable signals. 3. 4G Call Support: Loaded with a 4G network, providing high-speed data transmission to meet the demand for large-volume data transmission and adapt to the future development trend of communication. IV. Product Card Configuration Information Public Network Card The public network SIM card supports 4G standard Nano SIM cards (compatible with China Unicom, China Mobile, and China Telecom standards respectively). Card Slot Operation 1. Use your hand to snap open the card slot and take it out. 2. Place the SIM card in the designated position, then insert the card slot back into the device and press the waterproof plug tightly. V. Notes 1. Before the waterproof test, press the waterproof plug at the SIM socket tightly as shown in the figure. 2. The speaker sound may be affected after being soaked in water; shake out the liquid and wait for a period of time to resume normal operation. 3. The waterproof effect may be impaired if the device is subjected to a destructive drop. VI. Safety and Effective Use Guidelines Using third-party ROOT flashing or unauthorized operating system updates may pose certain risks to the operating system. This product is not sold with a power adapter. If consumers use a power adapter for power supply, they should purchase a matching power adapter that has obtained CCC certification and meets standard requirements. For the safe and effective use of the terminal, please carefully read the following information before use. The following suggestions will help you comply with the warranty terms and significantly extend the service life of the terminal. Keep the terminal and all its related accessories out of the reach of children. Do not allow the terminal and related accessories to come into contact with liquids or be placed in humid environments. Do not attempt to disassemble the terminal, and do not repair the terminal or its accessories without authorization. Do not use any charger not specified by the manufacturer to avoid potential hazards. On Aircraft Wireless devices may interfere with the aircraft's electronic navigators. Please comply with the relevant regulations of the airline and do not use this device in areas where wireless devices are prohibited. Personal Medical Devices The terminal may affect the operation of pacemakers, hearing aids, cochlear implants, or other implanted devices. Please avoid placing the terminal in a chest pocket. When answering calls, hold the terminal to the ear on the opposite side of the pacemaker. Always maintain a minimum distance of 15cm between the terminal and the pacemaker. If you suspect interference, immediately turn off the terminal, move it to a farther position, and contact your cardiologist for details. For other medical devices or implanted devices such as hearing aids, consult their manufacturers for specific information. While Driving Always stay fully focused while driving. If you receive a call while driving, pull out of the lane and stop the vehicle. Child Safety Instructions Keep the terminal and all its related accessories out of the reach of children. Do not allow children to use the terminal or its related accessories; children may cause injury to themselves or others, and may accidentally damage the terminal or related accessories. Some small parts in the terminal or its accessories may be disassembled, and swallowing them can be dangerous. Would you like me to export this English manual as a Word document (consistent with the original format) or optimize the image display effect in the document? Specific Absorption Rate (SAR) information SAR tests are conducted using standard operating positions accepted by the FCC with the smartphone transmitting at its highest certified power level in all tested frequency bands, although the SAR is determined at the highest certified power level, the actual SAR level of the smartphone while operating can be well below the maximum value. Before a new model smartphone is a available for sale to the public, it must be tested and certified to the FCC that it does not exceed the exposure limit established by the FCC, tests for each smartphone are performed in positions and locations as required by the FCC. For body worn operation, this model smartphone has been tested and meets the FCC RF exposureguidelines when used with an accessory designated for this product or when used with an accessory that contains no metal and that positions the handset a minimum of 0 cm from the body. Non-compliance with the above restrictions may result in violation of RF exposure guidelines. Head: 0.474 W/kg Body: 0.607 W/kg This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to pa…
Text truncated - open the document above for the full version.
RF Exposure Info
! "#$% &'()*+,'-./01222131441567819::;<-:.0 0'='>'?@' 2A)B*' CD EFGH IJKLM NO HF PP NJO Q R SRJILK IT UK SO GN VLPP JR GN S ROT WGOFJLO OF WRGOO N SSRJX P JV YZ[\ EF GNVJRM OGJN KJNO GN I F R GN GH OJ Q LH I JNP] VJR OF SLRSJH VJR WFGKF GO GH HLQMGOO I NI GH NJO OJ Q R P H I GN WFJP JR S RO WGOFJLO WRGOO N SSRJX P JV YZ[\ ^_`ab cde fg dhai_^j e klmno pq db^r e kmk dsclll tuvwux yz{| }~~| {z z l uja klq u_ai r_`i xu^ i_b aix uvwux knn jj ba ai b^w_u^i xjjmxjj ^^i ai ^w_u^i xjjmxjj mxgjj bvwi knn p iw_ ^`b n xj tuvwux jba_wb n m k tar jba_wb n m k tar wjuxu_ lnn ¡¢ £¤¥ ¦ § ̈©ª «¬®§¬ ̄ ¦° § ̈©ª «¬®§¬ ̄ ±² ³ ́μ² ±² ³ ́μ² ¶·· ̧¹º» ¼¹½¾ ¾»· ¾¹»º ¶¹·¿ À»· º¹¾½ »¹»» º¶» ½¹»¿ ¿¹ ̧ ̧ ½·· ¼·¹½ ¿¹½½ ¼¾»· ̧½ ¼¿ ¼»·· ¶·¹» ¼¿¹º ¼¿¾· ¶¾¹ ̧ ¼º¹¾ ¼À»· ¶¿¹¾ ¼½¹¶ ¼º·· ¶º¹¾ ̧·¹¼ ¼½·· ¶½¹À ̧·¹» ¼½»· ¾·¹» ̧·¹½ ̧··· ¾¼¹¼ ̧¼¹¼ ̧¼·· ¾¶¹¿ ̧¼¹½ ̧¶·· ¾º¹À ̧¶¹¶ ̧¾»· » ̧¹¾ ̧¾ ̧¿·· »»¹¶ ̧¾¹¿ ¶··· ¿¶¹º ̧»¹À ¶¶·· à à ¶»·· ¿À¹¼ ̧» ¶À·· ¿À¹¾ ̧¾¹ ̧ ¶½·· à à ¾ ̧·· à à ¾¿·· à à ¾½·· à à 3 o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`a bcdec` f efgh ijklmknop qrs tkuvwxyk zkj{xwwxyxwp | j }~ nmowxyxwp | { jklmxjk {kvmjk jklmxjk {kvmjk 3 9 ! "#$"% &'()*+,'-./01222131441567819::;<-:.0 0'='>'?@' 2A)B*' CD EFGH IJKLM NO HF PP NJO Q R SRJILK IT UK SO GN VLPP JR GN S ROT WGOFJLO OF WRGOO N SSRJX P JV YZ[\ EF GNVJRM OGJN KJNO GN I F R GN GH OJ Q LH I JNP] VJR OF SLRSJH VJR WFGKF GO GH HLQMGOO I NI GH NJO OJ Q R P H I GN WFJP JR S RO WGOFJLO WRGOO N SSRJX P JV YZ[\ ^ _ `_ab `cb debf ghi cej`eh klmno gpa qr psntlku a vwxyz _{ pok| a vxv p}gwww c~~ k c~ rrw ~un vz h~lnt |lmt ~k tlo nt ~~ vyy uu on nt okl~kt uuxuu kkt nt kl~kt uuxuu xruu ot vyy _f etl kmo y u c~~ buonlo y x v cn| buonlo y x v cn| fu~~l wy^y ¡¢£¤ ¥¦§ ̈ © ª«¬ ® ̄°© ̄®± ̈² © ª«¬ ® ̄°© ̄®± ³ ́μ¡¶ ³ ́μ¡¶ ·¹¹ 3 z » 43.33 (4.33) 21.59 (2.16) 9 ! "#$"# %&'()*+&,-./011102033045670899:;,9-/ /&<&=&>?& 1@(A)& BC DEFG HIJKL MN GE OO MIN P Q RQIHKJ HS TJ RN FM UKOO IQ FM R QNS VFNEIKN NE VQFNN M RRQIW O IU XYZ[ DE FMUIQL NFIM JIMN FM H E Q FM FG NI P KG H IMO\ UIQ NE RKQRIG UIQ VEFJE FN FG GKPLFNN H MH FG MIN NI P Q O G H FM VEIO IQ R QN VFNEIKN VQFNN M RRQIW O IU XYZ[ ] ^_ ` abcdefghi jcffklm jnggi opqrstuv twxyqrvqzu `{up|{xvpyty } `z~t ~tuvq|qx{vqzu z pyytuv {qy{vqzu {vt tv {qy{vqzu {vt j nkhif j j kdkig k lgbcdlg kdkig k lgbcdlg j gi ghn gldh kdkig k lgbcdlg kdkig k lgbcdlg gil hkmgl ng jnkl ¡ gil hkmgl ¢dghi £¤aj ¥¡ gil hkmgl ¦ kd§lkidh di ng jnkl ̈ ¤ ¤ gil hkmgl ¦ kd§lkidh di © ¤ª ¡ £ kdegl dicim j £ g«glghg l§g j ¡ a cidfgigl ¬gdingm £ jd¢hk ghglkil ng jnkl j ¤ ¡ fed«dgl ª ̈ ̈ ̈ nklkigldg eldl i igi k lgbcdlg nklkigldg eldl i igi k lgbcdlg gl gigl ® ̈j ¤ £ ¡ gl gigl ng jnkl ª ̈¤ ªdlgidhk cegl ¬lmikl ¤ ¡£ nklkigldg eldl i igi k lgbcdlg nklkigld g eldl i igi k lgbcdlg gfeglkiclg ©cfddim jghl gi ¡ © ¡¡ ¤ ¡ ¤ ¤ ¤ …
Text truncated - open the document above for the full version.
Test Setup Photos
Shenzhen DL Testing Technology Co., Ltd. EUT TEST PHOTO Radiated Measurement Photos Shenzhen DL Testing Technology Co., Ltd. ※※※※※ END OF REPORT ※※※※※
Test Setup Photos
SAR Setup photos for FCC ID: 2BU76–H08 Right Touch Right Tilt Left Touch Left Tilt Body Front side(separation distance is 5mm) Body Back side(separation distance is 5mm) Body Left side(separation distance is 5mm) Body Right side(separation distance is 5mm) Body Bottom side(separation distance is 5mm) Body Top side(separation distance is 5mm)
Test Report
Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-260114055R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 1 of 39 FCC Test Report FCC ID: 2BU76-H08 Applicant: Shenzhen Zhimei Technology Co., Ltd. Address: Room 301, Floor 3, Zhenhua Times Plaza, No. 21, Heping Road, Qinghua Community, Longhua Subdistrict, Shenzhen City Manufacturer: Shenzhen Zhimei Technology Co., Ltd. Address: Room 301, Floor 3, Zhenhua Times Plaza, No. 21, Heping Road, Qinghua Community, Longhua Subdistrict, Shenzhen City Product Name: smartphone Trade Mark: N/A Model Number: H08, H01, H02, H03, H04, H05, H06, H07, H08, H08A, H08B, H09, H10, H11, H12, H13, H14, H15, H16, H17, H18, H19, H20, ZMD-H01, ZMD-H02, ZMD-H03, ZMD-H04, ZMD-H05, ZMD-H06, ZMD-H07, ZMD-H08, ZMD-H09, ZMD-H10, ZMD-H11, ZMD-H12, ZMD-H13, ZMD-H14, ZMD-H15, ZMD-H16, ZMD-H17, ZMD-H18, ZMD-H19, ZMD-H20, K01, K02, K03, K04, K05, K06, K07, K08, K09, K10, K11, K12, K13, K14, K15, K16, K17, K18, K19, K20, ZMD-K01, ZMD-K02, ZMD-K03, ZMD-K04, ZMD-K05, ZMD-K06, ZMD-K07, ZMD-K08, ZMD-K09, ZMD-K10, ZMD-K11, ZMD-K12, ZMD-K13, ZMD-K14, ZMD-K15, ZMD-K16, ZMD-K17, ZMD-K18, ZMD-K19, ZMD-K20, W01, W02, W03, W04, W05, W06, W07, W08, W09, W10, W11, W12, W13, W14, W15, W16, W17, W18, W19, W20, ZMD-W01, ZMD-W02, ZMD-W03, ZMD-W04, ZMD-W05, ZMD-W06, ZMD-W07, ZMD-W08, ZMD-W09, ZMD-W10, ZMD-W11, ZMD-W12, ZMD-W13, ZMD-W14, ZMD-W15, ZMD-W16, ZMD-W17, ZMD-W18, ZMD-W19, ZMD-W20, C100, C200, C300, C400, C500, C600, C700, C800, C900 Date of Receipt: Jan. 14, 2026 Test Date: Jan. 14, 2026 - Mar. 03, 2026 Date of Report: Mar. 03, 2026 Prepared By: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Comprehensive Building, Tongzhou Electronics Longgang Factory Area, No.1 Baolong Fifth Road, Baolong Community, Baolong Street, Longgang District, Shenzhen, China Applicable Standards: FCC CFR Title 47 Part22 Subpart H FCC CFR Title 47 Part24 Subpart E FCC CFR Title 47 Part27 ANSI/ TIA/ EIA-603-E-2016 FCC KDB 971168 D01 Power Meas. License Digital Systems v03v01 ANSI C63.26:2015 Test Result: Pass Report Number: DLE-260114055R Prepared (Test Engineer): Alisa Song Reviewer (Supervisor): Jack Bu Approved (Manager): Jade Yang This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-260114055R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 2 of 39 TABLE OF CONTENTS Test Report Declaration Page 1. TEST SUMMARY .......................................................................................................................................... 3 2. GENERAL PRODUCT INFORMATION ........................................................................................................ 4 2.1. Description of Device (EUT) .................................................................................................................. 4 2.2. Product Function ................................................................................................................................... 5 2.3. Independent Operation Modes .............................................................................................................. 5 3. TEST SITES ................................................................................................................................................... 6 3.1. Test Facilities ......................................................................................................................................... 6 3.2. Measurement Uncertainty ..................................................................................................................... 6 3.3. List of Test and Measurement Instruments ........................................................................................... 7 4. TEST SET-UP ................................................................................................................................................ 8 4.1. Principle of Configuration Selection ...................................................................................................... 8 4.2. Block Diagram of Test Set-up ............................................................................................................... 8 4.3. Test Environment: ................................................................................................................................. 8 5. EMISSION TEST RESULTS ......................................................................................................................... 9 5.1. Conducted RF Output Power ................................................................................................................ 9 5.2. -26dB and 99% Occupied Bandwidth ................................................................................................. 16 5.3. Peak to Average Radio ....................................................................................................................... 17 5.4. Frequency Stability .............................................................................................................................. 18 5.5. Conducted Spurious Emissions .......................................................................................................... 22 5.6. Conducted Out of Band Emissions ..................................................................................................... 23 5.7. Transmitter Radiated Power (EIRP/ERP) .............................................................................................. 24 5.8. Radiated Out of Band Emissions........................................................................................................... 30 6. PHOTOGRAPHS OF TEST SET-UP ................................................................…
Text truncated - open the document above for the full version.
Test Report
版本:R-A生效日期：202 5-9-26 第 1 页 共 14 页 深圳市华讯视通科技有限公司 ShenzhenHuaxunshitongTechnologyCo.,Ltd. Antenna Specification Document 客户名称: 智美德 Project Name A76-A13 Antenna frequency band EGSM900/DCS1800 WCDMA:B1/B2/B5/B8 4G:B1/B2/B3/B5/B7/B8/ B20/B38/B39/B40/B41 GPS/WIFI 规格描述 □支架+弹片□单弹片□支架+FPC+顶针 ▇FPC□FM天线□GPS天线 □其它 □同轴线 □WIFI天线: ☑FPC+线材： □PCB+线长： 客户确认 供应商确认 射频确认结构确认审核 联系人王鹏超手机 13480925226 电话 0755-23705212 传真 0755-23705213 邮箱[email protected] 地址 :深圳市宝安区航城街道黄田大门路1号鸿丰华互联网创意园3楼3005 版本:R-A生效日期：2025-9-26 第 2 页共 14 页 1. 测试项目与设备 测试项目设备 1.S参 数（S-parameter） 1.回波损耗（ReturnLoss） 2.电压驻波比（VSWR） 网络分析仪:AgilentE5071B HP8753D 2.有源测试 （Active） 1.发射功率（TRP） 2.接收灵敏度（TIS） 1.暗室：ETS7x4x3m(3D)Chamber ETS5x3x3m(3D)Chamber 2.综合测试仪:Agilent8960E5515B×2 StarPointSP6011 3.无源测试 （Passive） 1.天线增益（Gain）2.天线效 率（Efficiency） 1.暗室：ETS7x4x3m(3D)Chamber ETS5x3x3m(3D)Chamber 2.网络分析仪：AgilentE5071B HP8753D 2.匹配电路-GSM天线： 我司未对匹配电路做任何修改 版本:R-A生效日期：2025-9-26 第 3 页共 14 页 3. 天线性能： 版本:R-A生效日期：2025-9-26 第 4 页共 14 页 版本:R-A生效日期：2025-9-26 第 5 页共 14 页 4 . 环境处理： 5.GPS 实测 : 版本:R-A生效日期：202 5-9-26 第 6 页 共 14 页 Gain and Efficiency 4G 版本:R-A生效日期：2025-9-26 第 7 页共 14 页 版本:R-A生效日期：2025-9-26 第 8 页共 14 页 版本:R-A生效日期：2025-9-26 第 9 页共 14 页 版本:R-A生效日期：2025-9-26 第 10 页共 14 页 WiFi-2.4G 版本:R-A生效日期：2025-9-26 第 11 页共 14 页 WIFI-5G 版本:R-A生效日期：2025-9-26 第 12 页共 14 页 版本:R-A生效日期：2025-9-26 第 13 页共 14 页 版本:R-A生效日期：2025-9-26 第 14 页共 14 页 6. 天线结构图：
Test Report
Report Band7 QAM16 BW=20MHz Channel=20850 RB Size=1 Position=#Max Band7 QAM16 BW=20MHz Channel=20850 RB Size=50 Position=#0 Report Band7 QAM16 BW=20MHz Channel=20850 RB Size=50 Position=#Max Band7 QAM16 BW=20MHz Channel=20850 RB Size=100 Position=#0 Report Band7 QPSK BW=20MHz Channel=21350 RB Size=1 Position=#0 Band7 QPSK BW=20MHz Channel=21350 RB Size=1 Position=#Max Report Band7 QPSK BW=20MHz Channel=21350 RB Size=50 Position=#0 Band7 QPSK BW=20MHz Channel=21350 RB Size=50 Position=#Max Report Band7 QPSK BW=20MHz Channel=21350 RB Size=100 Position=#0 Band7 QAM16 BW=20MHz Channel=21350 RB Size=1 Position=#0 Report Band7 QAM16 BW=20MHz Channel=21350 RB Size=1 Position=#Max Band7 QAM16 BW=20MHz Channel=21350 RB Size=50 Position=#0 Report Band7 QAM16 BW=20MHz Channel=21350 RB Size=50 Position=#Max Band7 QAM16 BW=20MHz Channel=21350 RB Size=100 Position=#0 Report 06 Out-of-band emissions Band Bandwidth (MHz) UL Channel RB Size RB Position Modulation Spur Freq (MHz) Spur Level (dBm) Limit (dBm) Verdict Band2 1.4 18607 6 #0 QPSK 19894.55 -36.32 -13 PASS Band2 1.4 18607 6 #0 QAM16 19465.15 -36.53 -13 PASS Band2 1.4 18900 6 #0 QPSK 1830.30 -32.53 -13 PASS Band2 1.4 18900 6 #0 QAM16 1831.25 -35.39 -13 PASS Band2 1.4 19193 6 #0 QPSK 17474.90 -36.71 -13 PASS Band2 1.4 19193 6 #0 QAM16 19658.00 -35.62 -13 PASS Band2 3 18615 15 #0 QPSK 19879.35 -37.20 -13 PASS Band2 3 18615 15 #0 QAM16 17491.53 -37.15 -13 PASS Band2 3 18900 15 #0 QPSK 19745.88 -37.06 -13 PASS Band2 3 18900 15 #0 QAM16 18858.10 -36.75 -13 PASS Band2 3 19185 15 #0 QPSK 19012.48 -36.44 -13 PASS Band2 3 19185 15 #0 QAM16 18904.18 -36.74 -13 PASS Band2 5 18625 25 #0 QPSK 18781.63 -36.74 -13 PASS Band2 5 18625 25 #0 QAM16 19582.00 -36.51 -13 PASS Band2 5 18900 25 #0 QPSK 19544.00 -36.78 -13 PASS Band2 5 18900 25 #0 QAM16 19813.80 -37.14 -13 PASS Band2 5 19175 25 #0 QPSK 19649.93 -36.74 -13 PASS Band2 5 19175 25 #0 QAM16 18900.38 -37.09 -13 PASS Band2 10 18650 50 #0 QPSK 18737.45 -36.97 -13 PASS Band2 10 18650 50 #0 QAM16 18817.73 -36.63 -13 PASS Band2 10 18900 50 #0 QPSK 18744.10 -37.13 -13 PASS Band2 10 18900 50 #0 QAM16 19833.75 -36.58 -13 PASS Band2 10 19150 50 #0 QPSK 19496.03 -36.81 -13 PASS Band2 10 19150 50 #0 QAM16 18421.10 -36.97 -13 PASS Band2 15 18675 75 #0 QPSK 18848.60 -36.98 -13 PASS Band2 15 18675 75 #0 QAM16 19503.15 -36.93 -13 PASS Band2 15 18900 75 #0 QPSK 19396.75 -36.91 -13 PASS Band2 15 18900 75 #0 QAM16 19700.75 -36.24 -13 PASS Band2 15 19125 75 #0 QPSK 2518.58 -23.33 -13 PASS Band2 15 19125 75 #0 QAM16 19887.90 -36.24 -13 PASS Band2 20 18700 100 #0 QPSK 18755.03 -36.16 -13 PASS Band2 20 18700 100 #0 QAM16 19691.73 -37.03 -13 PASS Band2 20 18900 100 #0 QPSK 18831.03 -36.56 -13 PASS Band2 20 19100 100 #0 QPSK 0.10 -28.68 -13 PASS Band2 20 19100 100 #0 QAM16 0.56 -29.28 -13 PASS Band5 1.4 20407 6 #0 QPSK 0.59 -31.58 -13 PASS Band5 1.4 20407 6 #0 QAM16 0.59 -31.07 -13 PASS Band5 1.4 20525 6 #0 QPSK 2518.53 -29.84 -13 PASS Band5 1.4 20525 6 #0 QAM16 0.58 -31.45 -13 PASS Band5 1.4 20643 6 #0 QPSK 0.59 -31.81 -13 PASS Band5 1.4 20643 6 #0 QAM16 0.59 -32.30 -13 PASS Report Band5 3 20415 15 #0 QPSK 2519.65 -31.73 -13 PASS Band5 3 20415 15 #0 QAM16 0.10 -31.82 -13 PASS Band5 3 20525 15 #0 QPSK 0.58 -31.05 -13 PASS Band5 3 20525 15 #0 QAM16 0.59 -32.01 -13 PASS Band5 3 20635 15 #0 QPSK 0.10 -32.19 -13 PASS Band5 3 20635 15 #0 QAM16 0.10 -32.06 -13 PASS Band5 5 20425 25 #0 QPSK 0.10 -32.45 -13 PASS Band5 5 20425 25 #0 QAM16 0.10 -32.36 -13 PASS Band5 5 20525 25 #0 QPSK 0.10 -31.75 -13 PASS Band5 5 20525 25 #0 QAM16 0.10 -31.85 -13 PASS Band5 5 20625 25 #0 QPSK 0.10 -31.90 -13 PASS Band5 5 20625 25 #0 QAM16 0.10 -32.46 -13 PASS Band5 10 20450 50 #0 QPSK 0.10 -31.46 -13 PASS Band5 10 20450 50 #0 QAM16 2613.93 -25.12 -13 PASS Band5 10 20525 50 #0 QPSK 0.10 -31.80 -13 PASS Band5 10 20525 50 #0 QAM16 0.10 -31.97 -13 PASS Band5 10 20600 50 #0 QPSK 0.10 -31.71 -13 PASS Band5 10 20600 50 #0 QAM16 0.10 -31.53 -13 PASS Band7 5 20775 25 #0 QPSK 6144.63 -40.25 -25 PASS Band7 5 20775 25 #0 QAM16 7304.95 -38.85 -25 PASS Band7 5 21425 25 #0 QPSK 5133.93 -37.64 -25 PASS Band7 5 21425 25 #0 QAM16 5137.75 -36.25 -25 PASS Band7 10 20800 50 #0 QPSK 7635.93 -40.21 -25 PASS Band7 10 20800 50 #0 QAM16 7278.40 -39.84 -25 PASS Band7 10 21400 50 #0 QPSK 5130.55 -38.99 -25 PASS Band7 10 21400 50 #0 QAM16 6157.90 -39.82 -25 PASS Band7 15 20825 75 #0 QPSK 7465.15 -39.97 -25 PASS Band7 15 20825 75 #0 QAM16 7812.33 -39.14 -25 PASS Band7 15 21375 75 #0 QPSK 5301.33 -39.32 -25 PASS Band7 15 21375 75 #0 QAM16 5935.60 -39.96 -25 PASS Band7 20 20850 100 #0 QPSK 7258.15 -40.22 -25 PASS Band7 20 20850 100 #0 QAM16 6456.03 -39.88 -25 PASS Band7 20 21350 100 #0 QPSK 5844.48 -40.16 -25 PASS Band7 20 21350 100 #0 QAM16 5920.53 -39.95 -25 PASS Report Band2 QAM16 BW=1.4MHz Channel=18607 RB Size=6 Position=#0 Band2 QAM16 BW=1.4MHz Channel=18900 RB Size=6 Position=#0 Report Band2 QAM16 BW=1.4MHz Channel=19193 RB Size=6 Position=#0 Band2 QAM16 BW=10MHz Channel=18650 RB Size=50 Position=#0 Report Band2 QAM16 BW=10MHz Channel=18900 RB Size=50 Position=#0 Band2 QAM16 BW=10MHz Channel=19150 RB Size=50 Position=#0 Report Band2 QAM16 BW=15MHz Channel=18675 RB Size=75 Position=#0 Band2 QAM16 BW=15MHz Channel=18900 RB Size=75 Position=#0 Report Band2 QAM16 BW=15MHz Channel=19125 RB Size=75 Position=#0 Band2 QAM16 BW=20MHz Channel=18700 RB Size=100 Position=#0 Report Band2 QAM16 BW=20MHz Channel=19100 RB Size=100 Position=#0 Band2 QAM16 BW=3MHz Channel=18615 RB Size=15 Position=#0 Report Band2 QAM16 BW=3MHz Channel=18900 RB Size=15 Position=#0 Band2 QAM16 BW=3MHz Channel=19185 RB Size=15 Position=#0 Report Band2 QAM16 BW=5MHz Channel=18625 RB Size=25 Position=#0 Band2 QAM16 BW=5MHz Channel=18900 RB Size=25 Position=#0 Report Band2 QAM16 BW=5MHz Channel=19175 RB Size=25 Position=#0 Band2 QPSK BW=1.4MHz Channel=18607 RB Size=6 Position=#0 Report Band2 QPSK BW=1.4MHz Channel=18900 RB Size=6 Position=#0 Band2 QPSK BW=1.4MHz Channel=19193 RB Size=6 Position=#0 Report Band2 QPSK BW=10MHz …
Text truncated - open the document above for the full version.
Test Report
Report Band2 QPSK BW=20MHz Channel=18700 RB Size=50 Position=#0 Band2 QPSK BW=20MHz Channel=18700 RB Size=50 Position=#Max Report Band2 QPSK BW=20MHz Channel=18700 RB Size=100 Position=#0 Band2 QAM16 BW=20MHz Channel=18700 RB Size=1 Position=#0 Report Band2 QAM16 BW=20MHz Channel=18700 RB Size=1 Position=#Max Band2 QAM16 BW=20MHz Channel=18700 RB Size=50 Position=#0 Report Band2 QAM16 BW=20MHz Channel=18700 RB Size=50 Position=#Max Band2 QPSK BW=20MHz Channel=19100 RB Size=1 Position=#0 Report Band2 QPSK BW=20MHz Channel=19100 RB Size=1 Position=#Max Band2 QPSK BW=20MHz Channel=19100 RB Size=50 Position=#0 Report Band2 QPSK BW=20MHz Channel=19100 RB Size=50 Position=#Max Band2 QPSK BW=20MHz Channel=19100 RB Size=100 Position=#0 Report Band2 QAM16 BW=20MHz Channel=19100 RB Size=1 Position=#0 Band2 QAM16 BW=20MHz Channel=19100 RB Size=1 Position=#Max Report Band2 QAM16 BW=20MHz Channel=19100 RB Size=50 Position=#0 Band2 QAM16 BW=20MHz Channel=19100 RB Size=50 Position=#Max Report Band5 QPSK BW=1.4MHz Channel=20407 RB Size=1 Position=#0 Band5 QPSK BW=1.4MHz Channel=20407 RB Size=1 Position=#Max Report Band5 QPSK BW=1.4MHz Channel=20407 RB Size=3 Position=#0 Band5 QPSK BW=1.4MHz Channel=20407 RB Size=3 Position=#Max Report Band5 QPSK BW=1.4MHz Channel=20407 RB Size=6 Position=#0 Band5 QAM16 BW=1.4MHz Channel=20407 RB Size=1 Position=#0 Report Band5 QAM16 BW=1.4MHz Channel=20407 RB Size=1 Position=#Max Band5 QAM16 BW=1.4MHz Channel=20407 RB Size=3 Position=#0 Report Band5 QAM16 BW=1.4MHz Channel=20407 RB Size=3 Position=#Max Band5 QAM16 BW=1.4MHz Channel=20407 RB Size=6 Position=#0 Report Band5 QPSK BW=1.4MHz Channel=20643 RB Size=1 Position=#0 Band5 QPSK BW=1.4MHz Channel=20643 RB Size=1 Position=#Max Report Band5 QPSK BW=1.4MHz Channel=20643 RB Size=3 Position=#0 Band5 QPSK BW=1.4MHz Channel=20643 RB Size=3 Position=#Max Report Band5 QPSK BW=1.4MHz Channel=20643 RB Size=6 Position=#0 Band5 QAM16 BW=1.4MHz Channel=20643 RB Size=1 Position=#0 Report Band5 QAM16 BW=1.4MHz Channel=20643 RB Size=1 Position=#Max Band5 QAM16 BW=1.4MHz Channel=20643 RB Size=3 Position=#0 Report Band5 QAM16 BW=1.4MHz Channel=20643 RB Size=3 Position=#Max Band5 QAM16 BW=1.4MHz Channel=20643 RB Size=6 Position=#0 Report Band5 QPSK BW=3MHz Channel=20415 RB Size=1 Position=#0 Band5 QPSK BW=3MHz Channel=20415 RB Size=1 Position=#Max Report Band5 QPSK BW=3MHz Channel=20415 RB Size=8 Position=#0 Band5 QPSK BW=3MHz Channel=20415 RB Size=8 Position=#Max Report Band5 QPSK BW=3MHz Channel=20415 RB Size=15 Position=#0 Band5 QAM16 BW=3MHz Channel=20415 RB Size=1 Position=#0 Report Band5 QAM16 BW=3MHz Channel=20415 RB Size=1 Position=#Max Band5 QAM16 BW=3MHz Channel=20415 RB Size=8 Position=#0 Report Band5 QAM16 BW=3MHz Channel=20415 RB Size=8 Position=#Max Band5 QAM16 BW=3MHz Channel=20415 RB Size=15 Position=#0 Report Band5 QPSK BW=3MHz Channel=20635 RB Size=1 Position=#0 Band5 QPSK BW=3MHz Channel=20635 RB Size=1 Position=#Max Report Band5 QPSK BW=3MHz Channel=20635 RB Size=8 Position=#0 Band5 QPSK BW=3MHz Channel=20635 RB Size=8 Position=#Max Report Band5 QPSK BW=3MHz Channel=20635 RB Size=15 Position=#0 Band5 QAM16 BW=3MHz Channel=20635 RB Size=1 Position=#0 Report Band5 QAM16 BW=3MHz Channel=20635 RB Size=1 Position=#Max Band5 QAM16 BW=3MHz Channel=20635 RB Size=8 Position=#0 Report Band5 QAM16 BW=3MHz Channel=20635 RB Size=8 Position=#Max Band5 QAM16 BW=3MHz Channel=20635 RB Size=15 Position=#0 Report Band5 QPSK BW=5MHz Channel=20425 RB Size=1 Position=#0 Band5 QPSK BW=5MHz Channel=20425 RB Size=1 Position=#Max Report Band5 QPSK BW=5MHz Channel=20425 RB Size=12 Position=#0 Band5 QPSK BW=5MHz Channel=20425 RB Size=12 Position=#Max Report Band5 QPSK BW=5MHz Channel=20425 RB Size=25 Position=#0 Band5 QAM16 BW=5MHz Channel=20425 RB Size=1 Position=#0 Report Band5 QAM16 BW=5MHz Channel=20425 RB Size=1 Position=#Max Band5 QAM16 BW=5MHz Channel=20425 RB Size=12 Position=#0 Report Band5 QAM16 BW=5MHz Channel=20425 RB Size=12 Position=#Max Band5 QAM16 BW=5MHz Channel=20425 RB Size=25 Position=#0 Report Band5 QPSK BW=5MHz Channel=20625 RB Size=1 Position=#0 Band5 QPSK BW=5MHz Channel=20625 RB Size=…
Text truncated - open the document above for the full version.
Contact Information
Applicant
Jack bu
[email protected]Fax: 18906679427
Technical Contact
Herland International Trading Inc1370 Valley Vista Dr Ste 200 Diamond Bar, CA 91765 Valley Vista Dr Ste 200 Diamond Bar, CA 91765
Diamond Bar, California · United States
Test Firm
Shenzhen DL Testing Technology Co., Ltd.Jade Yang
Technical Specifications
| # | Rule Parts | Frequency Range | Power Output | Emission | Tolerance |
|---|---|---|---|---|---|
| 1 | 24E | 1.85 GHz - 1.91 GHz | 129.00 mW | 18M0G7D | 0.0963ppm |
| 2 | 24E | 1.85 GHz - 1.91 GHz | 128.00 mW | 4M52W7D | 0.0525ppm |
| 3 | 24E | 1.85 GHz - 1.91 GHz | 129.00 mW | 4M52W7D | 0.0525ppm |
| 4 | 22H | 824 MHz - 849 MHz | 128.00 mW | 8M99G7D | 0.1043ppm |
| 5 | 22H | 824 MHz - 849 MHz | 128.00 mW | 4M51G7D | 0.1068ppm |
| 6 | 22H | 824 MHz - 849 MHz | 118.00 mW | 4M51W7D | 0.1068ppm |
| 7 | 27 | 2.50 GHz - 2.57 GHz | 123.00 mW | 17M9G7D | 0.0386ppm |
| 8 | 27 | 2.50 GHz - 2.57 GHz | 128.00 mW | 18M0G7D | 0.0484ppm |
