2BU7Q-AG45GPS tracker

Gastor Pty Ltd

Click to zoom

Application Details

Equipment Class: PCB - PCS Licensed Transmitter
Date of Grant: Apr 10, 2026
Application Purpose: Original Equipment
Equipment Note: GPS tracker
Frequency Range: 699.00000000 - 716.00000000
Company: Gastor Pty Ltd
Country: Australia

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Page1|14 UserManual Pleaseregisteryourdevicetoactivateit. Seepage4. Page2|14 Page2ContentsGuide/ImportantInformation Page3Controls&Indicators/Installation Page4-5Setup Page6HomePage/Impact/Perimeter Page7Perimeter/Temperature Page8Speed/Locate Page9MakeaclaimUserGuide Page10Alarms Page11Products Page12NavigatingtheSettings Page13FrequentlyAskedQuestions Page14Warranty ImportantInformation Understandingyoursmartalarm: Themostcommonquestionis,why,whenanalarmistriggered,canittakea shortwhilefortheApptonotifyme? Onaverage,thiscantakeanywherefrom30secondsto2minutes,basedon severalvariables.Satellitesignal,dataupload,networklatency,server processing,andyourmobile'sbackgroundactivity. However,whenthealert/notificationcomesthrough,itwill displaythecorrecttimethealarmoccurred. Page3|14 Functions: Pleaseseethesideoftheboxforfitmentinstructions.  Oncepoweredon,thedeviceautomaticallyturnson. Bluelight:GPSstatusindicator.  Redlight:GSM/LTE.  USB-Ctothepowercord. SIMCard–Mini  FacetheSIMcard(chipdown)asillustratedabove. (Clipsin–clicksound) Installation: Locateyourvehicle’sOBDport–usuallywithinarm’sreachofthedriver.  Inserttheprovidedharness’sUSB-Cintothesmartalarm'sUSB-CPort.  Plugtheharness’sOBDplugintoyourcar'sOBDport. Placethedouble-sidedtapeoverthelogo(notoverthelightsensor).  Findaflatareaandplacethedevice,logo,andlightsensorfacedown.  Thedevicewillpoweronstraightaway. o Redlighton,thenflashingwithblueforapproximately30-40seconds. o Solidredlight,withflashingblue30-40seconds. oAfterapproximately70seconds-nolights. Onceyou’veinstalledandactivatedyourdevice,itmaytakeupto30 minutesforittobecomefullyoperationalintheApp. Page4|14 Ifyoudonotregisteryourdevice,anyclaimmadewillbeassessed basedontheoriginalinvoicedate. Step1: Downloadtheappfromyourappstore. (GooglePlayforAndroidandAppleStoreforIOS). Search“AutoGuard”andselectdownload. Step2: GointotheAuto-Guardapp. Clickon“Register”. Completetheform.(Pleaseensurethisinformationisaccurate.) YouwillfindyouruniqueProductNo.locatedontheboxandthedevice. Press“Submit”. Youwillreceiveyourwelcomeletterviaemail,withyourapplogindetails. (Username&Password)Pleasecheckyourspamandjunkfolders. Iftheimagesandwordsareblocked,viewthemonyourmobiledevice. Page5|14 Step3: Gobackintotheapp. Enteryourlogindetailsandpress“Submit”. SelectyourAsset. IfyouhavepurchasedmorethanoneAuto-Guardproductandwishtoadditto anexistingaccount,select“AddAsset”. Page6|14 Hereyoucanmanageyoursmartalarmaccordingtoyourpreferences. Youcanalsoadjustthesettingsandpurchaseadditionalvalue-added products. Optiontorenameyourasset. TheImpactalarmcanbeturnedon andoffwiththetoggleswitch.You canpress“Setup”andadjustthe sensitivity.Thisfeaturewillsenda pushnotificationtoyourmobile phoneintheeventanimpact/accident hastakenplace. Hereyoucancreateaninvisible barrieraroundalocationofyour choosing.Receiveanalarmifyour vehicleentersorleavesthese locations. Page7|14 Enteranaddress Increase/Decreasesize Namethislocation Alarmtoenter/exit CreateanewPerimeter Setupatemperature alarm.Receiveanalarm oncethepreset temperatureisreached. Basedonthetemperature aroundthedevice. Thedevicecanbeupto 10degreeswarmer,asit alittlePC. Page8|14 Hereyoucanpreseta high-speedalarm.Inthe eventthevehiclegoes overthisspeed,youwill receivethealarm. Needtofindyourvehicle? Simplypress“Locate”- usingthebuilt-inGPS, yourvehicle’scurrent locationwillbedisplayed. PresstheBellIcontoget anewlocationupdate. Ifyouhavegoodsignal, thismaytakeanywhere from30secondsto 2minutes. Refresh Refreshesthemappage. Page9|14 MakeaClaim(Subjecttoyourregion/country) Ifyouhavehadanat-faultcollisionandmade aclaimwithyourcarinsurer. Click“select”anddownloadtheformto receivearefundforyourexcess. Theemailaddressislocatedontheform. UserManual Adigitalversionofthismanual. Easytoreadandcanbeupdatedintheapp whennewfeaturesareadded. Page10|14 Alarms Hereyoucanviewallthealarmsthatyouhave received.Allhistoricalalarmsaresavedhere andcanbedeleted. Areddotindicatesthatyouhaveunreadalarms. Clickonthealarm. Page11|14 Products(PostPurchase) Besuretoviewthistabfromtimetotimeas therewillbeexclusivespecialsonall vehicle-relatedproductsafteryoutakedelivery. Loyaltydiscountswillbeapplied. Page12|14 Map–Themappingplatformused. LowBattery-Onlyapplicableforthebattery-poweredunits. Tamper-Notificationsentifthedeviceisremoved. Password–Changeyourloginpassword. About–Detailsabouttheproduct. CurrentVersion–Yourcurrentappversion. Page13|14 WhyamInotreceivingthealarms? Headtoyourphone’ssettings,findtheApp,andensure“Push Notifications”areturnedon. Ensurethatyouhaveturnedthealarm/s“on”withintheapp.  IfyourdeviceisinanareathatisoutofGPSsignal,itmaydelaythe alarmfrombeingsent.Anexample,inthebasementofabuilding. Yourmobilephonemustbewithinamobilecoverageareatoreceivethe alarmnotificationsfromthedevice. Onrareoccasions,whenyoursmartalarmhasbeenfittedwithinyour vehicle,itmaybecausinginterference.Totestthis,unplugthedevice andplugitintoapowerbankoutsidethevehicle.Testbyusingthe “Locate”function. Thetemperaturedoesn’tseemaccurate: Thetemperatureofyourdevicewillbehigherthanyourcar’scabin temperature.Muchlikeanycomputer,itwillgenerateitsownheat. Mysmartalarmdoesn’tseemtobeworking: First,locatewherethedevicehasbeeninstalled,usuallywithinarm’sreachof thedriver.UnplugtheUSB-Cpowercordandplugitbackin.Youshouldseea “red”lightcomeon. Iactivated/registeredmydeviceintheapp,butIdidnotreceive theactivationletter: Theletterwillbesenttothesameemailaddressyouenteredonthe registrationform.Pleasecheckyourspamandjunkfolders.Ifyoustillhave notreceivedtheletter,pleaseheadtowww.auto-guard.com.au/contactwith yourname,surname,planlength,productnumber,andvehicle’s registration/platenumber.Someemailprogramsmayblockthecontent;try viewingitonanotherdevice. P a g e14 | 14 Important: You must registeryour smart alarm and activatethe excessbenefitwithin 7 days of purchase.If registrationis not completedwithin this period,your coveragewill be deemedto commencefrom the retailer’sdate of sale, not the date of activation.…

Text truncated - open the document above for the full version.

Test Report

1 FCC Appendix RF Test Data for LTE Band 26 Company: : Gastor Pty Ltd EUT : GPS tracker Model Number : AG45 FCC ID : 2BU7Q-AG45 Report No. : CTA26031300111 Reviewed By : Eric Wang 2 Appendix B: Peak-to-Average Ratio(CCDF) Test Result Band Bandwidth Modulation Channel RB Configuration Result(dB) Limit(dB) Verdict Band26(814- 824) 1.4MHz QPSK 26697 1RB#0 4.82 13 PASS Band26(814- 824) 1.4MHz 16QAM 26697 1RB#0 5.84 13 PASS Band26(814- 824) 1.4MHz QPSK 26697 6RB#0 5.48 13 PASS Band26(814- 824) 1.4MHz 16QAM 26697 6RB#0 6.39 13 PASS Band26(814- 824) 1.4MHz QPSK 26740 1RB#0 4.81 13 PASS Band26(814- 824) 1.4MHz 16QAM 26740 1RB#0 5.80 13 PASS Band26(814- 824) 1.4MHz QPSK 26740 6RB#0 5.51 13 PASS Band26(814- 824) 1.4MHz 16QAM 26740 6RB#0 6.38 13 PASS Band26(814- 824) 1.4MHz QPSK 26783 1RB#0 5.51 13 PASS Band26(814- 824) 1.4MHz 16QAM 26783 1RB#0 6.11 13 PASS Band26(814- 824) 1.4MHz QPSK 26783 6RB#0 5.65 13 PASS Band26(814- 824) 1.4MHz 16QAM 26783 6RB#0 6.54 13 PASS Band26(814- 824) 3MHz QPSK 26705 1RB#0 4.98 13 PASS Band26(814- 824) 3MHz 16QAM 26705 1RB#0 5.92 13 PASS Band26(814- 824) 3MHz QPSK 26705 15RB#0 5.45 13 PASS Band26(814- 824) 3MHz 16QAM 26705 15RB#0 6.24 13 PASS Band26(814- 824) 3MHz QPSK 26740 1RB#0 4.89 13 PASS Band26(814- 824) 3MHz 16QAM 26740 1RB#0 5.65 13 PASS 3 Band26(814- 824) 3MHz QPSK 26740 15RB#0 5.40 13 PASS Band26(814- 824) 3MHz 16QAM 26740 15RB#0 6.24 13 PASS Band26(814- 824) 3MHz QPSK 26775 1RB#0 5.32 13 PASS Band26(814- 824) 3MHz 16QAM 26775 1RB#0 6.38 13 PASS Band26(814- 824) 3MHz QPSK 26775 15RB#0 5.54 13 PASS Band26(814- 824) 3MHz 16QAM 26775 15RB#0 6.41 13 PASS Band26(814- 824) 5MHz QPSK 26715 1RB#0 4.84 13 PASS Band26(814- 824) 5MHz 16QAM 26715 1RB#0 5.61 13 PASS Band26(814- 824) 5MHz QPSK 26715 25RB#0 5.59 13 PASS Band26(814- 824) 5MHz 16QAM 26715 25RB#0 6.32 13 PASS Band26(814- 824) 5MHz QPSK 26740 1RB#0 4.89 13 PASS Band26(814- 824) 5MHz 16QAM 26740 1RB#0 5.64 13 PASS Band26(814- 824) 5MHz QPSK 26740 25RB#0 5.69 13 PASS Band26(814- 824) 5MHz 16QAM 26740 25RB#0 6.37 13 PASS Band26(814- 824) 5MHz QPSK 26765 1RB#0 5.11 13 PASS Band26(814- 824) 5MHz 16QAM 26765 1RB#0 5.82 13 PASS Band26(814- 824) 5MHz QPSK 26765 25RB#0 5.71 13 PASS Band26(814- 824) 5MHz 16QAM 26765 25RB#0 6.45 13 PASS Band26(814- 824) 10MHz QPSK 26740 1RB#0 5.12 13 PASS Band26(814- 824) 10MHz 16QAM 26740 1RB#0 5.70 13 PASS Band26(814- 824) 10MHz QPSK 26740 50RB#0 5.60 13 PASS 4 5 Test Graphs Band26(814-824)-1.4MHz-QPSK-26697-1RB#0- PASS Band26(814-824)-1.4MHz-16QAM-26697- 1RB#0-PASS Band26(814-824)-1.4MHz-QPSK-26697-6RB#0- PASS Band26(814-824)-1.4MHz-16QAM-26697- 6RB#0-PASS Band26(814-824)-1.4MHz-QPSK-26740-1RB#0- PASS Band26(814-824)-1.4MHz-16QAM-26740- 1RB#0-PASS 6 Band26(814-824)-1.4MHz-QPSK-26740-6RB#0- PASS Band26(814-824)-1.4MHz-16QAM-26740- 6RB#0-PASS Band26(814-824)-1.4MHz-QPSK-26783-1RB#0- PASS Band26(814-824)-1.4MHz-16QAM-26783- 1RB#0-PASS Band26(814-824)-1.4MHz-QPSK-26783-6RB#0- PASS Band26(814-824)-1.4MHz-16QAM-26783- 6RB#0-PASS Band26(814-824)-3MHz-QPSK-26705-1RB#0- PASS Band26(814-824)-3MHz-16QAM-26705-1RB#0- PASS 7 Band26(814-824)-3MHz-QPSK-26705-15RB#0- PASS Band26(814-824)-3MHz-16QAM-26705- 15RB#0-PASS Band26(814-824)-3MHz-QPSK-26740-1RB#0- PASS Band26(814-824)-3MHz-16QAM-26740-1RB#0- PASS Band26(814-824)-3MHz-QPSK-26740-15RB#0- PASS Band26(814-824)-3MHz-16QAM-26740- 15RB#0-PASS Band26(814-824)-3MHz-QPSK-26775-1RB#0- PASS Band26(814-824)-3MHz-16QAM-26775-1RB#0- PASS 8 Band26(814-824)-3MHz-QPSK-26775-15RB#0- PASS Band26(814-824)-3MHz-16QAM-26775- 15RB#0-PASS Band26(814-824)-5MHz-QPSK-26715-1RB#0- PASS Band26(814-824)-5MHz-16QAM-26715-1RB#0- PASS Band26(814-824)-5MHz-QPSK-26715-25RB#0- PASS Band26(814-824)-5MHz-16QAM-26715- 25RB#0-PASS Band26(814-824)-5MHz-QPSK-26740-1RB#0- PASS Band26(814-824)-5MHz-16QAM-26740-1RB#0- PASS 9 Band26(814-824)-5MHz-QPSK-26740-25RB#0- PASS Band26(814-824)-5MHz-16QAM-26740- 25RB#0-PASS Band26(814-824)-5MHz-QPSK-26765-1RB#0- PASS Band26(814-824)-5MHz-16QAM-26765-1RB#0- PASS Band26(814-824)-5MHz-QPSK-26765-25RB#0- PASS Band26(814-824)-5MHz-16QAM-26765- 25RB#0-PASS Band26(814-824)-10MHz-QPSK-26740-1RB#0- PASS Band26(814-824)-10MHz-16QAM-26740- 1RB#0-PASS 10 Band26(814-824)-10MHz-QPSK-26740-50RB#0- PASS 11 Appendix C: 26dB Bandwidth and Occupied Bandwidth Test Result Band Bandwi dth Modulat ion Channel RB Configuratio n Occupied Bandwidth (MHz) 26dB Bandwidth (MHz) Verdict Band26(814-824) 1.4MHz QPSK 26697 6RB#0 1.0923 1.431 PASS Band26(814-824) 1.4MHz QPSK 26740 6RB#0 1.0909 1.411 PASS Band26(814-824) 1.4MHz QPSK 26783 6RB#0 1.0884 1.427 PASS Band26(814-824) 1.4MHz 16QAM 26697 6RB#0 1.1044 1.475 PASS Band26(814-824) 1.4MHz 16QAM 26740 6RB#0 1.1017 1.481 PASS Band26(814-824) 1.4MHz 16QAM 26783 6RB#0 1.1035 1.468 PASS Band26(814-824) 3MHz QPSK 26705 15RB#0 2.6844 3.150 PASS Band26(814-824) 3MHz QPSK 26740 15RB#0 2.6921 3.157 PASS Band26(814-824) 3MHz QPSK 26775 15RB#0 2.6924 3.125 PASS Band26(814-824) 3MHz 16QAM 26705 15RB#0 2.6870 3.188 PASS Band26(814-824) 3MHz 16QAM 26740 15RB#0 2.6818 3.149 PASS Band26(814-824) 3MHz 16QAM 26775 15RB#0 2.6834 3.115 PASS Band26(814-824) 5MHz QPSK 26715 25RB#0 4.4786 5.093 PASS Band26(814-824) 5MHz QPSK 26740 25RB#0 4.4875 5.150 PASS Band26(814-824) 5MHz QPSK 26765 25RB#0 4.4829 5.099 PASS Band26(814-824) 5MHz 16QAM 26715 25RB#0 4.4816 5.109 PASS Band26(814-824) 5MHz 16QAM 26740 25RB#0 4.4887 5.123 PASS Band26(814-824) 5MHz 16QAM 26765 25RB#0 4.4814 5.081 PASS Band26(814-824) 10MHz QPSK 26740 50RB#0 8.9163 9.660 PASS Band26(814-824) 10MHz 16QAM 26740 27RB#0 5.2027 7.307 PASS 12 Test Graphs Band26(814-824)-1.4MHz-QPSK-26697-6RB#0- PASS Band26(814-824)-1.4MHz-16QAM-26697- 6RB#0-PASS Band26(814-824)-1.4MHz-QPSK-26740-6RB#0- PASS Band26(814-824)-1.4MHz-16QAM-26740- 6RB#0-PASS Band26(814-824)-1.4MHz-QPSK-26783-6RB#0- PASS Band26(814-824)-1.4MHz-16QAM-26783- 6RB#0-PASS 13 Band26(814-824)-3MHz-QPSK-26705-15RB#0- PASS Band26(814-824)-3MHz-16QAM-26705- 15RB#0-PASS Band26(814-824)-3MHz-QPSK-26740-15RB#0- PASS Band26(814-824)-3MHz-16QAM-2674…

Text truncated - open the document above for the full version.

Test Report

1 FCC Appendix RF Test Data for LTE Band 7 Company: : Gastor Pty Ltd EUT : GPS tracker Model Number : AG45 FCC ID : 2BU7Q-AG45 Report No. : CTA26031300105 Reviewed By : Eric Wang 2 Appendix B: Peak-to-Average Ratio(CCDF) Test Result Band Bandwidth Modulation Channel RB Configuration Result(dB) Limit(dB) Verdict Band7 5MHz QPSK 20775 1RB#0 4.62 13 PASS Band7 5MHz 16QAM 20775 1RB#0 5.51 13 PASS Band7 5MHz QPSK 20775 25RB#0 5.32 13 PASS Band7 5MHz 16QAM 20775 25RB#0 6.04 13 PASS Band7 5MHz QPSK 21100 1RB#0 4.60 13 PASS Band7 5MHz 16QAM 21100 1RB#0 5.28 13 PASS Band7 5MHz QPSK 21100 25RB#0 5.22 13 PASS Band7 5MHz 16QAM 21100 25RB#0 6.46 13 PASS Band7 5MHz QPSK 21425 1RB#0 5.14 13 PASS Band7 5MHz 16QAM 21425 1RB#0 5.39 13 PASS Band7 5MHz QPSK 21425 25RB#0 5.40 13 PASS Band7 5MHz 16QAM 21425 25RB#0 6.07 13 PASS Band7 10MHz QPSK 20800 1RB#0 4.72 13 PASS Band7 10MHz 16QAM 20800 1RB#0 5.45 13 PASS Band7 10MHz QPSK 21100 1RB#0 4.78 13 PASS Band7 10MHz 16QAM 21100 1RB#0 5.53 13 PASS Band7 10MHz QPSK 21400 1RB#0 4.66 13 PASS Band7 10MHz 16QAM 21400 1RB#0 5.05 13 PASS Band7 10MHz QPSK 20800 50RB#0 5.29 13 PASS Band7 10MHz QPSK 21100 50RB#0 5.48 13 PASS Band7 10MHz QPSK 21400 50RB#0 5.45 13 PASS Band7 15MHz QPSK 20825 1RB#0 4.65 13 PASS Band7 15MHz 16QAM 20825 1RB#0 5.66 13 PASS Band7 15MHz QPSK 21100 1RB#0 4.60 13 PASS Band7 15MHz 16QAM 21100 1RB#0 5.25 13 PASS Band7 15MHz QPSK 21375 1RB#0 4.48 13 PASS Band7 15MHz 16QAM 21375 1RB#0 5.37 13 PASS Band7 15MHz QPSK 20825 75RB#0 5.55 13 PASS Band7 15MHz QPSK 21100 75RB#0 5.80 13 PASS Band7 15MHz QPSK 21375 75RB#0 5.83 13 PASS Band7 20MHz QPSK 20850 1RB#0 4.50 13 PASS Band7 20MHz QPSK 21100 1RB#0 4.94 13 PASS Band7 20MHz QPSK 21350 1RB#0 4.62 13 PASS Band7 20MHz QPSK 20850 100RB#0 5.18 13 PASS Band7 20MHz QPSK 21100 100RB#0 5.54 13 PASS Band7 20MHz QPSK 21350 100RB#0 5.57 13 PASS 4 Test Graphs Band7-5MHz-QPSK-20775-1RB#0-PASS Band7-5MHz-16QAM-20775-1RB#0-PASS Band7-5MHz-QPSK-20775-25RB#0-PASS Band7-5MHz-16QAM-20775-25RB#0-PASS Band7-5MHz-QPSK-21100-1RB#0-PASS Band7-5MHz-16QAM-21100-1RB#0-PASS Band7-5MHz-QPSK-21100-25RB#0-PASS Band7-5MHz-16QAM-21100-25RB#0-PASS 5 Band7-5MHz-QPSK-21425-1RB#0-PASS Band7-5MHz-16QAM-21425-1RB#0-PASS Band7-5MHz-QPSK-21425-25RB#0-PASS Band7-5MHz-16QAM-21425-25RB#0-PASS Band7-10MHz-QPSK-20800-1RB#0-PASS Band7-10MHz-16QAM-20800-1RB#0-PASS Band7-10MHz-QPSK-21100-1RB#0-PASS Band7-10MHz-16QAM-21100-1RB#0-PASS 6 Band7-10MHz-QPSK-21400-1RB#0-PASS Band7-10MHz-16QAM-21400-1RB#0-PASS Band7-10MHz-QPSK-20800-50RB#0-PASS Band7-10MHz-QPSK-21100-50RB#0-PASS Band7-10MHz-QPSK-21400-50RB#0-PASS Band7-15MHz-QPSK-20825-1RB#0-PASS Band7-15MHz-16QAM-20825-1RB#0-PASS Band7-15MHz-QPSK-21100-1RB#0-PASS 7 Band7-15MHz-16QAM-21100-1RB#0-PASS Band7-15MHz-QPSK-21375-1RB#0-PASS Band7-15MHz-16QAM-21375-1RB#0-PASS Band7-15MHz-QPSK-20825-75RB#0-PASS Band7-15MHz-QPSK-21100-75RB#0-PASS Band7-15MHz-QPSK-21375-75RB#0-PASS Band7-20MHz-QPSK-20850-1RB#0-PASS Band7-20MHz-QPSK-21100-1RB#0-PASS 8 Band7-20MHz-QPSK-21350-1RB#0-PASS Band7-20MHz-QPSK-20850-100RB#0-PASS Band7-20MHz-QPSK-21100-100RB#0-PASS Band7-20MHz-QPSK-21350-100RB#0-PASS 9 Appendix C: 26dB Bandwidth and Occupied Bandwidth Test Result Band Bandwidth Modulation Channel RB Configuration Occupied Bandwidth (MHz) 26dB Bandwidth (MHz) Verdict Band7 5MHz QPSK 20775 25RB#0 4.4862 5.022 PASS Band7 5MHz QPSK 21100 25RB#0 4.4785 5.103 PASS Band7 5MHz QPSK 21425 25RB#0 4.4899 5.139 PASS Band7 5MHz 16QAM 20775 25RB#0 4.4856 5.143 PASS Band7 5MHz 16QAM 21100 25RB#0 4.4859 5.108 PASS Band7 5MHz 16QAM 21425 25RB#0 4.4877 5.123 PASS Band7 10MHz QPSK 20800 50RB#0 8.9560 9.893 PASS Band7 10MHz QPSK 21100 50RB#0 8.9823 9.934 PASS Band7 10MHz QPSK 21400 50RB#0 8.9789 9.892 PASS Band7 10MHz 16QAM 20800 27RB#0 4.9738 5.843 PASS Band7 10MHz 16QAM 21100 27RB#0 4.9933 5.848 PASS Band7 10MHz 16QAM 21400 27RB#0 5.0053 5.847 PASS Band7 15MHz QPSK 20825 75RB#0 13.444 14.82 PASS Band7 15MHz QPSK 21100 75RB#0 13.448 14.83 PASS Band7 15MHz QPSK 21375 75RB#0 13.414 14.75 PASS Band7 15MHz 16QAM 20825 27RB#0 5.0757 6.059 PASS Band7 15MHz 16QAM 21100 27RB#0 5.1433 6.075 PASS Band7 15MHz 16QAM 21375 27RB#0 5.1065 6.178 PASS Band7 20MHz QPSK 20850 100RB#0 17.907 19.40 PASS Band7 20MHz QPSK 21100 100RB#0 17.938 19.56 PASS Band7 20MHz QPSK 21350 100RB#0 17.956 19.44 PASS Band7 20MHz 16QAM 20850 27RB#0 5.2317 6.409 PASS Band7 20MHz 16QAM 21100 27RB#0 5.3054 6.503 PASS Band7 20MHz 16QAM 21350 27RB#0 5.2406 6.373 PASS 10 Test Graphs Band7-5MHz-QPSK-20775-25RB#0-PASS Band7-5MHz-16QAM-20775-25RB#0-PASS Band7-5MHz-QPSK-21100-25RB#0-PASS Band7-5MHz-16QAM-21100-25RB#0-PASS Band7-5MHz-QPSK-21425-25RB#0-PASS Band7-5MHz-16QAM-21425-25RB#0-PASS Band7-10MHz-QPSK-20800-50RB#0-PASS Band7-10MHz-QPSK-21100-50RB#0-PASS 11 Band7-10MHz-QPSK-21400-50RB#0-PASS Band7-10MHz-16QAM-20800-27RB#0-PASS Band7-10MHz-16QAM-21100-27RB#0-PASS Band7-10MHz-16QAM-21400-27RB#0-PASS Band7-15MHz-QPSK-20825-75RB#0-PASS Band7-15MHz-QPSK-21100-75RB#0-PASS Band7-15MHz-QPSK-21375-75RB#0-PASS Band7-15MHz-16QAM-20825-27RB#0-PASS 12 Band7-15MHz-16QAM-21100-27RB#0-PASS Band7-15MHz-16QAM-21375-27RB#0-PASS Band7-20MHz-QPSK-20850-100RB#0-PASS Band7-20MHz-QPSK-21100-100RB#0-PASS Band7-20MHz-QPSK-21350-100RB#0-PASS Band7-20MHz-16QAM-20850-27RB#0-PASS Band7-20MHz-16QAM-21100-27RB#0-PASS Band7-20MHz-16QAM-21350-27RB#0-PASS 13 Appendix D: Band Edge Test Result Band Bandwidth Modulation Channel RB Configuration Result(dBm) Verdict Band7 5MHz QPSK 20775 1RB#0 -26.31 PASS Band7 5MHz 16QAM 20775 1RB#0 -25.31 PASS Band7 5MHz QPSK 20775 1RB#24 -47.19 PASS Band7 5MHz 16QAM 20775 1RB#24 -47.20 PASS Band7 5MHz QPSK 20775 25RB#0 -30.33 PASS Band7 5MHz 16QAM 20775 25RB#0 -30.27 PASS Band7 5MHz QPSK 21425 1RB#0 -46.76 PASS Band7 5MHz 16QAM 21425 1RB#0 -46.78 PASS Band7 5MHz QPSK 21425 1RB#24 -29.38 PASS Band7 5MHz 16QAM 21425 1RB#24 -31.15 PASS Band7 5MHz QPSK 21425 25RB#0 -46.48 PASS Band7 5MHz 16QAM 21425 25RB#0 -46.36 PASS Band7 10MHz QPSK 20800 1RB#0 -31.33 PASS Band7 10MHz 16QAM 20800 1RB#0 -32.42 PASS Band7 10…

Text truncated - open the document above for the full version.

Test Report

66 Band5-10MHz-QPSK-20525-1RB#49-30~1000- PASS Band5-10MHz-QPSK-20525-1RB#49- 1000~3000-PASS Band5-10MHz-QPSK-20525-1RB#49- 3000~10000-PASS Band5-10MHz-16QAM-20525-1RB#49- 0.009~0.15-PASS Band5-10MHz-16QAM-20525-1RB#49-0.15~30- PASS Band5-10MHz-16QAM-20525-1RB#49-30~1000- PASS Band5-10MHz-16QAM-20525-1RB#49- 1000~3000-PASS Band5-10MHz-16QAM-20525-1RB#49- 3000~10000-PASS 67 Band5-10MHz-QPSK-20600-1RB#0-0.009~0.15- PASS Band5-10MHz-QPSK-20600-1RB#0-0.15~30- PASS Band5-10MHz-QPSK-20600-1RB#0-30~1000- PASS Band5-10MHz-QPSK-20600-1RB#0-1000~3000- PASS Band5-10MHz-QPSK-20600-1RB#0- 3000~10000-PASS Band5-10MHz-16QAM-20600-1RB#0- 0.009~0.15-PASS Band5-10MHz-16QAM-20600-1RB#0-0.15~30- PASS Band5-10MHz-16QAM-20600-1RB#0-30~1000- PASS 68 Band5-10MHz-16QAM-20600-1RB#0- 1000~3000-PASS Band5-10MHz-16QAM-20600-1RB#0- 3000~10000-PASS Band5-10MHz-QPSK-20600-1RB#49- 0.009~0.15-PASS Band5-10MHz-QPSK-20600-1RB#49-0.15~30- PASS Band5-10MHz-QPSK-20600-1RB#49-30~1000- PASS Band5-10MHz-QPSK-20600-1RB#49- 1000~3000-PASS Band5-10MHz-QPSK-20600-1RB#49- 3000~10000-PASS Band5-10MHz-16QAM-20600-1RB#49- 0.009~0.15-PASS 69 Band5-10MHz-16QAM-20600-1RB#49-0.15~30- PASS Band5-10MHz-16QAM-20600-1RB#49-30~1000- PASS Band5-10MHz-16QAM-20600-1RB#49- 1000~3000-PASS Band5-10MHz-16QAM-20600-1RB#49- 3000~10000-PASS Band5-10MHz-QPSK-20450-50RB#0- 0.009~0.15-PASS Band5-10MHz-QPSK-20450-50RB#0-0.15~30- PASS Band5-10MHz-QPSK-20450-50RB#0-30~1000- PASS Band5-10MHz-QPSK-20450-50RB#0- 1000~3000-PASS 70 Band5-10MHz-QPSK-20450-50RB#0- 3000~10000-PASS Band5-10MHz-QPSK-20525-50RB#0- 0.009~0.15-PASS Band5-10MHz-QPSK-20525-50RB#0-0.15~30- PASS Band5-10MHz-QPSK-20525-50RB#0-30~1000- PASS Band5-10MHz-QPSK-20525-50RB#0- 1000~3000-PASS Band5-10MHz-QPSK-20525-50RB#0- 3000~10000-PASS Band5-10MHz-QPSK-20600-50RB#0- 0.009~0.15-PASS Band5-10MHz-QPSK-20600-50RB#0-0.15~30- PASS 71 Band5-10MHz-QPSK-20600-50RB#0-30~1000- PASS Band5-10MHz-QPSK-20600-50RB#0- 1000~3000-PASS Band5-10MHz-QPSK-20600-50RB#0- 3000~10000-PASS 72 Appendix F: Frequency Stability Test Result Temperature Band Bandwidt h Modulatio n Channe l RB Configure Voltag e [Vdc] Tempe rature (°C) Deviation (Hz) Deviation (ppm) Limit (ppm) Verdict Band5 1.4MHz QPSK 20407 6RB#0 NV -30 -4.31 -0.005226 ±2.5 PASS Band5 1.4MHz QPSK 20407 6RB#0 NV -20 -5.65 -0.006851 ±2.5 PASS Band5 1.4MHz QPSK 20407 6RB#0 NV -10 -5.14 -0.006233 ±2.5 PASS Band5 1.4MHz QPSK 20407 6RB#0 NV 0 -4.45 -0.005396 ±2.5 PASS Band5 1.4MHz QPSK 20407 6RB#0 NV 10 -4.33 -0.005250 ±2.5 PASS Band5 1.4MHz QPSK 20407 6RB#0 NV 20 -2.86 -0.003468 ±2.5 PASS Band5 1.4MHz QPSK 20407 6RB#0 NV 30 -4.58 -0.005554 ±2.5 PASS Band5 1.4MHz QPSK 20407 6RB#0 NV 40 -3.63 -0.004402 ±2.5 PASS Band5 1.4MHz QPSK 20407 6RB#0 NV 50 -4.35 -0.005275 ±2.5 PASS Band5 1.4MHz 16QAM 20407 6RB#0 NV -30 -7.47 -0.009058 ±2.5 PASS Band5 1.4MHz 16QAM 20407 6RB#0 NV -20 -7.14 -0.008658 ±2.5 PASS Band5 1.4MHz 16QAM 20407 6RB#0 NV -10 -4.53 -0.005493 ±2.5 PASS Band5 1.4MHz 16QAM 20407 6RB#0 NV 0 -7.57 -0.009179 ±2.5 PASS Band5 1.4MHz 16QAM 20407 6RB#0 NV 10 -5.48 -0.006645 ±2.5 PASS Band5 1.4MHz 16QAM 20407 6RB#0 NV 20 -7.94 -0.009628 ±2.5 PASS Band5 1.4MHz 16QAM 20407 6RB#0 NV 30 -6.69 -0.008112 ±2.5 PASS Band5 1.4MHz 16QAM 20407 6RB#0 NV 40 -4.29 -0.005202 ±2.5 PASS Band5 1.4MHz 16QAM 20407 6RB#0 NV 50 -7.12 -0.008633 ±2.5 PASS Band5 1.4MHz QPSK 20525 6RB#0 NV -30 -5.12 -0.006121 ±2.5 PASS Band5 1.4MHz QPSK 20525 6RB#0 NV -20 3.91 0.004674 ±2.5 PASS Band5 1.4MHz QPSK 20525 6RB#0 NV -10 -3.25 -0.003885 ±2.5 PASS Band5 1.4MHz QPSK 20525 6RB#0 NV 0 -3.91 -0.004674 ±2.5 PASS Band5 1.4MHz QPSK 20525 6RB#0 NV 10 -2.32 -0.002773 ±2.5 PASS Band5 1.4MHz QPSK 20525 6RB#0 NV 20 -3.56 -0.004256 ±2.5 PASS Band5 1.4MHz QPSK 20525 6RB#0 NV 30 -4.55 -0.005439 ±2.5 PASS Band5 1.4MHz QPSK 20525 6RB#0 NV 40 -4.23 -0.005057 ±2.5 PASS Band5 1.4MHz QPSK 20525 6RB#0 NV 50 -3.59 -0.004292 ±2.5 PASS Band5 1.4MHz 16QAM 20525 6RB#0 NV -30 -8.04 -0.009611 ±2.5 PASS Band5 1.4MHz 16QAM 20525 6RB#0 NV -20 -5.66 -0.006766 ±2.5 PASS Band5 1.4MHz 16QAM 20525 6RB#0 NV -10 -6.90 -0.008249 ±2.5 PASS Band5 1.4MHz 16QAM 20525 6RB#0 NV 0 -7.41 -0.008858 ±2.5 PASS Band5 1.4MHz 16QAM 20525 6RB#0 NV 10 -5.97 -0.007137 ±2.5 PASS Band5 1.4MHz 16QAM 20525 6RB#0 NV 20 -5.48 -0.006551 ±2.5 PASS Band5 1.4MHz 16QAM 20525 6RB#0 NV 30 -6.48 -0.007747 ±2.5 PASS Band5 1.4MHz 16QAM 20525 6RB#0 NV 40 -7.00 -0.008368 ±2.5 PASS 73 Band5 1.4MHz 16QAM 20525 6RB#0 NV 50 -6.57 -0.007854 ±2.5 PASS Band5 1.4MHz QPSK 20643 6RB#0 NV -30 -22.14 -0.026099 ±2.5 PASS Band5 1.4MHz QPSK 20643 6RB#0 NV -20 2.92 0.003442 ±2.5 PASS Band5 1.4MHz QPSK 20643 6RB#0 NV -10 -3.15 -0.003713 ±2.5 PASS Band5 1.4MHz QPSK 20643 6RB#0 NV 0 -3.95 -0.004656 ±2.5 PASS Band5 1.4MHz QPSK 20643 6RB#0 NV 10 -3.89 -0.004586 ±2.5 PASS Band5 1.4MHz QPSK 20643 6RB#0 NV 20 2.40 0.002829 ±2.5 PASS Band5 1.4MHz QPSK 20643 6RB#0 NV 30 -2.79 -0.003289 ±2.5 PASS Band5 1.4MHz QPSK 20643 6RB#0 NV 40 -4.62 -0.005446 ±2.5 PASS Band5 1.4MHz QPSK 20643 6RB#0 NV 50 -3.71 -0.004373 ±2.5 PASS Band5 1.4MHz 16QAM 20643 6RB#0 NV -30 -6.01 -0.007085 ±2.5 PASS Band5 1.4MHz 16QAM 20643 6RB#0 NV -20 -8.08 -0.009525 ±2.5 PASS Band5 1.4MHz 16QAM 20643 6RB#0 NV -10 -3.81 -0.004491 ±2.5 PASS Band5 1.4MHz 16QAM 20643 6RB#0 NV 0 -3.06 -0.003607 ±2.5 PASS Band5 1.4MHz 16QAM 20643 6RB#0 NV 10 -6.67 -0.007863 ±2.5 PASS Band5 1.4MHz 16QAM 20643 6RB#0 NV 20 -8.31 -0.009796 ±2.5 PASS Band5 1.4MHz 16QAM 20643 6RB#0 NV 30 -6.17 -0.007273 ±2.5 PASS Band5 1.4MHz 16QAM 20643 6RB#0 NV 40 -4.21 -0.004963 ±2.5 PASS Band5 1.4MHz 16QAM 20643 6RB#0 NV 50 -5.81 -0.006849 ±2.5 PASS Band5 3MHz QPSK 20415 15RB#0 NV -30 -3.08 -0.003731 ±2.5 PASS Band5 3MHz QPSK 20415 15RB#0 NV -20 -2.10 -0.002544 ±2.5 PASS Band5 3MHz QPSK 20415 15RB#0 NV -10 -3.56 -0.004313 ±2.5 PASS Band5 3MHz QPSK 20415 15RB#0 NV 0 -2.63 -0.003186 ±2.5 PASS Band5 3MHz QPSK 20415 15RB#0 NV 10 -4.05 -0.004906 ±2.5 PASS Band5 3MHz QPSK 20415 15RB#0 NV 20 -3.72 -0.004506 ±2.5 PASS Band5 3MHz QPSK 20415 15RB#0 NV 30 -3.85 -0.004664 ±2.5 PASS Band5 3MH…

Text truncated - open the document above for the full version.

Test Report

56 Band5-5MHz-QPSK-20525-1RB#24-30~1000- PASS Band5-5MHz-QPSK-20525-1RB#24-1000~3000- PASS Band5-5MHz-QPSK-20525-1RB#24- 3000~10000-PASS Band5-5MHz-16QAM-20525-1RB#24- 0.009~0.15-PASS Band5-5MHz-16QAM-20525-1RB#24-0.15~30- PASS Band5-5MHz-16QAM-20525-1RB#24-30~1000- PASS Band5-5MHz-16QAM-20525-1RB#24- 1000~3000-PASS Band5-5MHz-16QAM-20525-1RB#24- 3000~10000-PASS 57 Band5-5MHz-QPSK-20525-25RB#0-0.009~0.15- PASS Band5-5MHz-QPSK-20525-25RB#0-0.15~30- PASS Band5-5MHz-QPSK-20525-25RB#0-30~1000- PASS Band5-5MHz-QPSK-20525-25RB#0-1000~3000- PASS Band5-5MHz-QPSK-20525-25RB#0- 3000~10000-PASS Band5-5MHz-16QAM-20525-25RB#0- 0.009~0.15-PASS Band5-5MHz-16QAM-20525-25RB#0-0.15~30- PASS Band5-5MHz-16QAM-20525-25RB#0-30~1000- PASS 58 Band5-5MHz-16QAM-20525-25RB#0- 1000~3000-PASS Band5-5MHz-16QAM-20525-25RB#0- 3000~10000-PASS Band5-5MHz-QPSK-20625-1RB#0-0.009~0.15- PASS Band5-5MHz-QPSK-20625-1RB#0-0.15~30- PASS Band5-5MHz-QPSK-20625-1RB#0-30~1000- PASS Band5-5MHz-QPSK-20625-1RB#0-1000~3000- PASS Band5-5MHz-QPSK-20625-1RB#0-3000~10000- PASS Band5-5MHz-16QAM-20625-1RB#0-0.009~0.15- PASS 59 Band5-5MHz-16QAM-20625-1RB#0-0.15~30- PASS Band5-5MHz-16QAM-20625-1RB#0-30~1000- PASS Band5-5MHz-16QAM-20625-1RB#0-1000~3000- PASS Band5-5MHz-16QAM-20625-1RB#0- 3000~10000-PASS Band5-5MHz-QPSK-20625-1RB#24-0.009~0.15- PASS Band5-5MHz-QPSK-20625-1RB#24-0.15~30- PASS Band5-5MHz-QPSK-20625-1RB#24-30~1000- PASS Band5-5MHz-QPSK-20625-1RB#24-1000~3000- PASS 60 Band5-5MHz-QPSK-20625-1RB#24- 3000~10000-PASS Band5-5MHz-16QAM-20625-1RB#24- 0.009~0.15-PASS Band5-5MHz-16QAM-20625-1RB#24-0.15~30- PASS Band5-5MHz-16QAM-20625-1RB#24-30~1000- PASS Band5-5MHz-16QAM-20625-1RB#24- 1000~3000-PASS Band5-5MHz-16QAM-20625-1RB#24- 3000~10000-PASS Band5-5MHz-QPSK-20625-25RB#0-0.009~0.15- PASS Band5-5MHz-QPSK-20625-25RB#0-0.15~30- PASS 61 Band5-5MHz-QPSK-20625-25RB#0-30~1000- PASS Band5-5MHz-QPSK-20625-25RB#0-1000~3000- PASS Band5-5MHz-QPSK-20625-25RB#0- 3000~10000-PASS Band5-5MHz-16QAM-20625-25RB#0- 0.009~0.15-PASS Band5-5MHz-16QAM-20625-25RB#0-0.15~30- PASS Band5-5MHz-16QAM-20625-25RB#0-30~1000- PASS Band5-5MHz-16QAM-20625-25RB#0- 1000~3000-PASS Band5-5MHz-16QAM-20625-25RB#0- 3000~10000-PASS 62 Band5-10MHz-QPSK-20450-1RB#0-0.009~0.15- PASS Band5-10MHz-QPSK-20450-1RB#0-0.15~30- PASS Band5-10MHz-QPSK-20450-1RB#0-30~1000- PASS Band5-10MHz-QPSK-20450-1RB#0-1000~3000- PASS Band5-10MHz-QPSK-20450-1RB#0- 3000~10000-PASS Band5-10MHz-16QAM-20450-1RB#0- 0.009~0.15-PASS Band5-10MHz-16QAM-20450-1RB#0-0.15~30- PASS Band5-10MHz-16QAM-20450-1RB#0-30~1000- PASS 63 Band5-10MHz-16QAM-20450-1RB#0- 1000~3000-PASS Band5-10MHz-16QAM-20450-1RB#0- 3000~10000-PASS Band5-10MHz-QPSK-20450-1RB#49- 0.009~0.15-PASS Band5-10MHz-QPSK-20450-1RB#49-0.15~30- PASS Band5-10MHz-QPSK-20450-1RB#49-30~1000- PASS Band5-10MHz-QPSK-20450-1RB#49- 1000~3000-PASS Band5-10MHz-QPSK-20450-1RB#49- 3000~10000-PASS Band5-10MHz-16QAM-20450-1RB#49- 0.009~0.15-PASS 64 Band5-10MHz-16QAM-20450-1RB#49-0.15~30- PASS Band5-10MHz-16QAM-20450-1RB#49-30~1000- PASS Band5-10MHz-16QAM-20450-1RB#49- 1000~3000-PASS Band5-10MHz-16QAM-20450-1RB#49- 3000~10000-PASS Band5-10MHz-QPSK-20525-1RB#0-0.009~0.15- PASS Band5-10MHz-QPSK-20525-1RB#0-0.15~30- PASS Band5-10MHz-QPSK-20525-1RB#0-30~1000- PASS Band5-10MHz-QPSK-20525-1RB#0-1000~3000- PASS 65 Band5-10MHz-QPSK-20525-1RB#0- 3000~10000-PASS Band5-10MHz-16QAM-20525-1RB#0- 0.009~0.15-PASS Band5-10MHz-16QAM-20525-1RB#0-0.15~30- PASS Band5-10MHz-16QAM-20525-1RB#0-30~1000- PASS Band5-10MHz-16QAM-20525-1RB#0- 1000~3000-PASS Band5-10MHz-16QAM-20525-1RB#0- 3000~10000-PASS Band5-10MHz-QPSK-20525-1RB#49- 0.009~0.15-PASS Band5-10MHz-QPSK-20525-1RB#49-0.15~30- PASS

Test Report

46 Band5-3MHz-QPSK-20525-15RB#0-30~1000- PASS Band5-3MHz-QPSK-20525-15RB#0-1000~3000- PASS Band5-3MHz-QPSK-20525-15RB#0- 3000~10000-PASS Band5-3MHz-16QAM-20525-15RB#0- 0.009~0.15-PASS Band5-3MHz-16QAM-20525-15RB#0-0.15~30- PASS Band5-3MHz-16QAM-20525-15RB#0-30~1000- PASS Band5-3MHz-16QAM-20525-15RB#0- 1000~3000-PASS Band5-3MHz-16QAM-20525-15RB#0- 3000~10000-PASS 47 Band5-3MHz-QPSK-20635-1RB#0-0.009~0.15- PASS Band5-3MHz-QPSK-20635-1RB#0-0.15~30- PASS Band5-3MHz-QPSK-20635-1RB#0-30~1000- PASS Band5-3MHz-QPSK-20635-1RB#0-1000~3000- PASS Band5-3MHz-QPSK-20635-1RB#0-3000~10000- PASS Band5-3MHz-16QAM-20635-1RB#0-0.009~0.15- PASS Band5-3MHz-16QAM-20635-1RB#0-0.15~30- PASS Band5-3MHz-16QAM-20635-1RB#0-30~1000- PASS 48 Band5-3MHz-16QAM-20635-1RB#0-1000~3000- PASS Band5-3MHz-16QAM-20635-1RB#0- 3000~10000-PASS Band5-3MHz-QPSK-20635-1RB#14-0.009~0.15- PASS Band5-3MHz-QPSK-20635-1RB#14-0.15~30- PASS Band5-3MHz-QPSK-20635-1RB#14-30~1000- PASS Band5-3MHz-QPSK-20635-1RB#14-1000~3000- PASS Band5-3MHz-QPSK-20635-1RB#14- 3000~10000-PASS Band5-3MHz-16QAM-20635-1RB#14- 0.009~0.15-PASS 49 Band5-3MHz-16QAM-20635-1RB#14-0.15~30- PASS Band5-3MHz-16QAM-20635-1RB#14-30~1000- PASS Band5-3MHz-16QAM-20635-1RB#14- 1000~3000-PASS Band5-3MHz-16QAM-20635-1RB#14- 3000~10000-PASS Band5-3MHz-QPSK-20635-15RB#0-0.009~0.15- PASS Band5-3MHz-QPSK-20635-15RB#0-0.15~30- PASS Band5-3MHz-QPSK-20635-15RB#0-30~1000- PASS Band5-3MHz-QPSK-20635-15RB#0-1000~3000- PASS 50 Band5-3MHz-QPSK-20635-15RB#0- 3000~10000-PASS Band5-3MHz-16QAM-20635-15RB#0- 0.009~0.15-PASS Band5-3MHz-16QAM-20635-15RB#0-0.15~30- PASS Band5-3MHz-16QAM-20635-15RB#0-30~1000- PASS Band5-3MHz-16QAM-20635-15RB#0- 1000~3000-PASS Band5-3MHz-16QAM-20635-15RB#0- 3000~10000-PASS Band5-5MHz-QPSK-20425-1RB#0-0.009~0.15- PASS Band5-5MHz-QPSK-20425-1RB#0-0.15~30- PASS 51 Band5-5MHz-QPSK-20425-1RB#0-30~1000- PASS Band5-5MHz-QPSK-20425-1RB#0-1000~3000- PASS Band5-5MHz-QPSK-20425-1RB#0-3000~10000- PASS Band5-5MHz-16QAM-20425-1RB#0-0.009~0.15- PASS Band5-5MHz-16QAM-20425-1RB#0-0.15~30- PASS Band5-5MHz-16QAM-20425-1RB#0-30~1000- PASS Band5-5MHz-16QAM-20425-1RB#0-1000~3000- PASS Band5-5MHz-16QAM-20425-1RB#0- 3000~10000-PASS 52 Band5-5MHz-QPSK-20425-1RB#24-0.009~0.15- PASS Band5-5MHz-QPSK-20425-1RB#24-0.15~30- PASS Band5-5MHz-QPSK-20425-1RB#24-30~1000- PASS Band5-5MHz-QPSK-20425-1RB#24-1000~3000- PASS Band5-5MHz-QPSK-2…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Judy Lu

[email protected]Fax: 13249055303

Technical Contact

GLOCERTS TECHNOLOGY INCHuiying Fan

[email protected]

19784 SUNKISSED RIDGE DR · United States

Test Firm

SHENZHEN CTA TESTING TECHNOLOGY CO., LTD.Eric Wang

[email protected]

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
1	22H	824.2 MHz - 848.8 MHz	845.30 mW	245KGXW	2.5ppm
2	24E	1.85 GHz - 1.91 GHz	248.30 mW	246KGXW	2.5ppm
3	24E	1.85 GHz - 1.91 GHz	154.50 mW	1M10G7D	2.5ppm
4	24E	1.85 GHz - 1.91 GHz	136.80 mW	18M1G7D	2.5ppm
5	24E	1.85 GHz - 1.91 GHz	119.10 mW	9M86W7D	2.5ppm
6	27	1.71 GHz - 1.75 GHz	165.60 mW	8M96G7D	2.5ppm
7	27	1.71 GHz - 1.75 GHz	137.70 mW	18M0G7D	2.5ppm
8	27	1.71 GHz - 1.75 GHz	123.00 mW	8M62W7D	2.5ppm
9	22H	824 MHz - 849 MHz	130.00 mW	4M48G7D	2.5ppm
1	22H	824 MHz - 849 MHz	125.00 mW	8M93G7D	2.5ppm
11	22H	824 MHz - 849 MHz	93.50 mW	5M28W7D	2.5ppm
12	27	2.50 GHz - 2.57 GHz	211.80 mW	13M4G7D	2.5ppm
13	27	2.50 GHz - 2.57 GHz	205.60 mW	18M0G7D	2.5ppm
14	27	2.50 GHz - 2.57 GHz	162.90 mW	5M31W7D	2.5ppm
15	27	699 MHz - 716 MHz	96.40 mW	2M69G7D	2.5ppm
16	27	699 MHz - 716 MHz	94.40 mW	8M94G7D	2.5ppm
17	27	699 MHz - 716 MHz	75.50 mW	5M21W7D	2.5ppm
18	27	777 MHz - 787 MHz	86.50 mW	4M49G7D	2.5ppm
19	27	777 MHz - 787 MHz	68.90 mW	8M94G7D	2.5ppm
2	27	777 MHz - 787 MHz	56.40 mW	5M26W7D	2.5ppm
21	27	704 MHz - 716 MHz	118.90 mW	8M93G7D	2.5ppm
22	27	704 MHz - 716 MHz	89.50 mW	5M18W7D	2.5ppm
23	24E	1.85 GHz - 1.92 GHz	179.10 mW	8M95G7D	2.5ppm
24	24E	1.85 GHz - 1.92 GHz	163.70 mW	18M1G7D	2.5ppm
25	24E	1.85 GHz - 1.92 GHz	139.30 mW	8M59W7D	2.5ppm
26	9	814 MHz - 824 MHz	161.10 mW	2M69G7D	2.5ppm
27	9	814 MHz - 824 MHz	137.40 mW	8M92G7D	2.5ppm
28	9	814 MHz - 824 MHz	128.20 mW	5M20W7D	2.5ppm
29	22H	824 MHz - 849 MHz	163.70 mW	1M10G7D	2.5ppm
3	22H	824 MHz - 849 MHz	160.70 mW	13M5G7D	2.5ppm
31	22H	824 MHz - 849 MHz	134.30 mW	6M13W7D	2.5ppm
32	27	2.57 GHz - 2.62 GHz	167.50 mW	13M5G7D	2.5ppm
33	27	2.57 GHz - 2.62 GHz	135.50 mW	18M0G7D	2.5ppm
34	27	2.57 GHz - 2.62 GHz	120.20 mW	6M32W7D	2.5ppm
35	27	2.50 GHz - 2.69 GHz	147.20 mW	4M51G7D	2.5ppm
36	27	2.50 GHz - 2.69 GHz	137.10 mW	18M0G7D	2.5ppm
37	27	2.50 GHz - 2.69 GHz	109.60 mW	6M35W7D	2.5ppm
38	27	1.71 GHz - 1.78 GHz	293.80 mW	4M49G7D	2.5ppm
39	27	1.71 GHz - 1.78 GHz	263.00 mW	18M1G7D	2.5ppm
4	27	1.71 GHz - 1.78 GHz	225.90 mW	8M07W7D	2.5ppm

Confidentiality

Long Term

Grant Notes

Output power listed is ERP for operation below 1GHz and EIRP for operation above 1GHz. This device supports LTE bandwidths of 1.4, 3, 5, 10, 15, 20 MHz at LTE Band 2/4/25/66 and of 1.4, 3, 5, 10 MHz at LTE Band 5/12 and of 5, 10, 15, 20 MHz at LTE Band 7/38/41 and of 5, 10 MHz at LTE Band 13/17 and of 1.4, 3, 5, 10, 15 MHz at LTE Band 26. RF exposure compliance is addressed for 1.1310 and 2.1091 MPE limits. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons. End Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This device contains functions that are not operational in U.S. Territories. This filing is only applicable for US operations.
