P a g e 1 | 15 P a g e 2 | 15 For all troubleshooting, please visit: www.clearview4k.com.au Click on Technical Guide Thank you for choosing the 4K Ultra HD Dash Camera. You now have an extra set of eyes protecting your investment and your family in the event of an incident. Important – Please Read 1. The camera system has a voltage cut-off device to prevent the camera from draining your car battery. Today, there are some makes and models that, by not locking your car, can result in the car battery being drained – nothing to do with the camera system. 2. If you have a hybrid car, please ensure that you turn off your “start/stop” button when you park and exit your vehicle. 3. You should examine, check, and verify that your device and its SD card are correctly operating every month. SD cards go under extreme stress in Dash Cameras. Across all Camera brands globally, if your system appears faulty, try formatting the SD card first. 4. This product and its components are not waterproof. As such, please do not expose it to any water, rain, or moisture. 5. Ensure the camera lens is always kept clean, both in the front and at the back. 6. Never attempt to disassemble, repair, or make modifications to your device, as it will void your warranty and may damage the unit. 7. Please remove items from your dashboard, as they can cause reflections to be seen on the windscreen and thus captured during recording. 8. Avoid touching the lens on the camera. When cleaning, use a microfiber cloth. Preface: P a g e 3 | 15 Page 3 Contents Guide Page 4 Controls & Indicators Page 5 Connecting to the Dash Camera Page 6 Connection Troubleshooting Page 7 Home Screen Page 8 Accessing your Files Page 9 Accessing your Files Page 10 Downloading your Files / Cropping / Maps Page 11 Navigating the Settings Page 12 Navigating the Settings Page 13 Frequently Asked Questions Page 14 Disclaimer Page 15 Warranty Card Contents Guide: P a g e 4 | 15 Indicator Lights • Wi-Fi indicator (Blue): This light will be blue when Wi-Fi is on. • Power/Video/Rec (Red): This light will be red and blink/flash when operational. • GPS status (Green): This light will be green if there is a GPS signal. Functions: • Press & hold the Wi-Fi button for 4 seconds to manually turn the Wi-Fi off and on. • Press & hold the Wi-Fi button for 12 seconds to format the SD card. Factory reset/format SD card. You will hear the voice prompt. Operating System: • Powering on the system: Welcome sound / Wi-Fi on / Rear camera sound / Recording / Red light blinking. • While diving / Red light blinking / Wi-Fi on / Recording at 30FPS. • Turn the ignition off – Enter Parking mode: - Voice Prompt = Recording stopped & Wi-Fi Off. - Voice Prompt +/- 15 seconds = Parking Mode On & Recording. Controls & Indicators: P a g e 5 | 15 Step 1: Download from your app store. (Google Play for Android and Apple Store for IOS). Search “Sight Pro” and select download. Step 2: Ensure that you are within the Wi-Fi range of your dash camera. We recommend sitting in the car to connect. Start the engine to ensure the camera is getting power, (red light), and that the Wi-Fi is on (blue light). Step 3: Go to settings on your smartphone. Go to the settings named “Wi-Fi”. Find the network “SightPro – xxxx” and select. Enter your password: 12345678 Once connected under your Wi-Fi settings, the “Sight” network will be ticked & connected. (It may say “no internet connection.” This is fine.) Step 4: Go to your recently downloaded “Sight Pro” smartphone application. Once opened and loaded, click on the Dash Camera image in the middle of the page. You will be taken to a live video feed of what your camera is seeing/recording. You will also be able to view and adjust settings to your preference, view your files, and take photos. Connecting to Dash Camera: P a g e 6 | 15 Android Auto and Apple CarPlay: Across all dash cameras, these may cause interference with your mobile phone connecting to the camera's Wi-Fi. Please note that connecting to the dash camera via your mobile does not affect the camera's recording/operating system. 1.) With the engine/ignition turned off, you will hear the Dash Camera enter “Parking Mode” and the Wi-Fi switch off. On the front camera, on the side, press in (3-4 seconds) the Wi-Fi button. This will manually turn on/off the Wi-Fi on the camera. This helps prevent vehicle interference. 2.) You may also remove the camera's SD card and place it into your PC. It will operate similarly to using a USB. Recommended when you need to download large amounts of data (for speed). My phone won’t connect: Other phones connect to the Wi-Fi, but my phone doesn’t. 1.) Try turning your mobile phone off and back on again (power cycle). 2.) (iPhone) Go to your settings. Search under Apps, find “Sight Pro”. Ensure the “Local Network” is turned on. In rare cases, you can try turning the App’s Mobile Data to the “off” position. 3.) Only when trying to connect to the Dash Camera’s Wi-Fi to obtain data. Turn Airplane mode “On”. Then connect to the camera's Wi-Fi. The Dash Camera doesn’t seem to be transmitting a Wi-Fi network: With power to the camera, place a paperclip/earring into the back of the front camera, onto the slot labelled “R” (Reset). This can reset the camera and the Wi-Fi signal. Connection Troubleshooting: P a g e 7 | 15 On this page, you will see the live video recording. Digital Clock Counting: Recording time - how long it has been recording for. Resolution & Frame rate: Displays your current front camera resolution and frames per second. Cog Icon: An option to access your settings page. Enlarge the Screen: Make this screen full view and smaller again. _________________________________________________________ View Files: This takes you to view your 4x viewing files. This is where all your footage is saved. Stop Recording: Stops recording. Live Camera: Change your live viewing screen. Front or Rear or Front & Rear or Rear & Front. Resolution: Adjust the resolution of the front camer…
