2BUHI-APB01Amplify power box subassembly

1 OWNER’S MANUAL Amplify 2 IMPORTANT SAFETY GUIDES READ AND FOLLOW ALL INSTRUCTIONS IT IS UNLAWFUL TO INSTALL THIS UNIT WITHOUT FIRST OBTAINING A PERMIT FROM THE LOCAL ELECTRICAL INSPECTION AUTHORITY. A Reference to the warning marking provided with the heater, indicating the importance of attaching the marking. There are the relevant explainations for all kinds of warning notice; also there is the limit for the location of warning notice as below; 1) The hyperthermia warning marking should be located on the outside of the door at eye level. 2) The fire warning marking should be located on the interior wall above the heater at eye level. B) All wiring to the sauna heater and accessories shall be routed away from any direct radiation form the sauna heater. C) Any receptacle shall not be installed inside the heated room. D) The sauna heater shall not be subjected to water spray and that shower heads shall not be installed above the sauna heaters. E) No plumbing fixtures (taps, etc) are to be installed in the sauna room. F) The door of the heated room do not include any locking or latching system, malfunction of which could cause entrapment inside the heated room. G) The dry-bath bathing room shall be provided with intended ventilation. H) Hyperthermia occurs when the internal temperature of the body reaches a level several degrees above the normal body temperature of 98.6 °F H. the symptoms of hyperthermia include an increase in the internal temperature of the body, dizziness,lethargy,drowsiness, and fainting. The effects of hyperthermia include: a)Failure to perceive heat; b)Failure to recognize the need to exit the room; c)Unawareness of impending hazard; d)Fetal damage in pregnant women; e)Physical inability to exit the room; and f)Unconsciousness. WARING- The use of alcohol, drugs, or medication is capable of greatly increasing the risk of fatal hyperthermia. SAVE THESE INSTRUCTIONS 3 TABLE OF CONTENTS PRE-INSTALLATION Control Panel ....................................................................... 13 Warm-Up Time/Usage .......................................................... Specifications........................................................................4 Pre-Installation Info ............................................................... 4 ASSEMBLY INSTRUCTIONS............................................... 5 OPERATING INSTRUCTIONS 14 Sauna Protocol ...................................................................... 15 Amplify OWNER’S MANUAL ASSEMBLY INSTRUCTIONS............................................... . . . 1 6 WARNING........................................................................1 6 4 Amplify SERIES SPECIFICATIONS AMPLIFY 2 Dimensions Power 1,35 cm x 1,22 cm x 1,97cm AMPLIFY 3 Dimensions Power 1,64cm x 1,22 cm 1,97 cm Power Dimensions A true dedicated outlet is an outlet that runs from the wall outlet on your home to the breaker box with nothing else on that line. Plugging your sauna into your wall outlet with any other electrical device is not a true dedicated outlet and will hinder the saunas ability to warm up properly. 120V,18.92A,2270W 240V,13.67A,3280W AMPLIFY 4 1,70cm x 1,71 cm x 1,97cm 240V,16.25A,3900W PRE-INSTALLATION 1.If your sauna requires a dedicated outlet , please have a certified electrician install a dedicated outlet for sauna. 2.Remember your sauna should be assembled by two or more people. 3.Do not place plumbing or plumbing fixtures in the sauna. 4.Keep all liquids away from the heating panels and electronics. 5.Install sauna on a level surface. 6.Install sauna in an area that is dry and protected from the weather. 7.Keep flammable objects and corrosive chemical substancesaway from the sauna. 8.Installation of the sauna in an area below standard room temperature can increase warm- up time. 2x Full Spectrum (FS) Heater 1x Floor 1x Bench J 2x FS Heater Covers LK 2x FS Heater Top Panel M 4x FS Heater brackets N 1x Right Wall G 1x Back Wall F 1x Left Wall I 1x Front Wall with glass panel H 1x1x6x ABC 1x Roof DE 12 1x Allen wrench 8 12x 9 12x 10 12x 7 12x 11 2x 2x 12 6x 3 4x 4 4x 5 8x 6 12x ȩ!33%-",9ȩ).3425#4)/.3 Amplify 5 9OUȩWILLȩWANTȩTWOȩORȩMOREȩPEOPLEȩTOȩASSEMBLEȩYOURȩSAUNA Unpack each wall segment from the shipping material. Stage each wall segment in the room you will be assembling the unit. STEP 1 Be sure you have two people assisting with this step. This is the side with the sauna information label Place the back wall on the back of the floor panel . on the bottom edge. STEP 2 PRE- STEPS A 2 12 F E E E E F Attach the feet pegs with supplied Allen wrench and bolts to the underside of floor . NOTE: Make sure the floor panel is on a surface that is perfectly level and relatively smooth. Failure to do so can cause the door to not close all the way in the later steps. 2E A NOTE: Before you begin installing the walls, be sure you have at least: • 6 in between the back of the sauna and the outlet wall. • 12 in gap from the top of the sauna to the ceiling. • Place the sauna next to the wall power outlet to ensure you have access to the wall power socket outlet to cut the power to the unit if required. In this step, make sure one person is holding the wall while the other helps balance it and press it in place. 6 STEP 3 As you insert each wall segment, you will insert the U-clips in the pre-drilled holes in the corner. This will keep the walls sealed together. The front wall will be inserted next. Be careful of the glass door and panel as you insert the wall. Place right wall on the right side of floor panel . This wall panel should sit flush once properly seated. Make sure no gaps are visible in the corner of the two walls as you insert it. It should be inserted flush. STEP 4 H GE 3 3 H E G 7 STEP 5 Once all the U-clips have been inserted in the corners, the next step will be to place the roof on top. Make sure the side with the main power cord receptacle faces the back. After securing the U-clip , the left wall will be the last to …

Text truncated - open the document above for the full version.

Page 1 of 4 External Photos Page 2 of 4 Page 3 of 4 Page 4 of 4

Label (52*16.5MM): Location Model: Amplify APB FCC ID: 2BUHI-APB01

Page 1 of 4 Internal Photos Page 2 of 4 Antenna Page 3 of 4 Page 4 of 4

Sunlighten, Inc. MPE ASSESSMENT REPORT Report Type: FCC MPE assessment report Model: Amplify APB REPORT NUMBER: 2510B1662SHA-003 ISSUE DATE: March 20, 2026 DOCUMENT CONTROL NUMBER: TTRFFCCMPE-01_V1 © 2018 Intertek Intertek Testing Services (Shanghai FTZ) Co., Ltd Building No.86, 1198 Qinzhou Road (North) Caohejing Development Zone Shanghai 200233, China Telephone: 86 21 6127 8200 www.intertek.com TEST REPORT This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. TTRFFCCMPE-01_V1© 2018 Intertek Page 2 of 9 Report no.: 2510B1662SHA-003 Applicant: Sunlighten, Inc. 10975 EI Monte Street, Leawood, KS 66211, United States Manufacturer: Sunlighten, Inc. 10975 EI Monte Street, Leawood, KS 66211, United States Product Name: Amplify power box subassembly Type/Model: Amplify APB FCC ID: 2BUHI-APB01 SUMMARY: The equipment complies with the requirements according to the following standard(s) or Specification: KDB447498 D01 General RF Exposure Guidance v06 FCC Part2.1091, FCC Part2.1093 FCC Part1.1307(b) PREPARED BY: REVIEWED BY: Project Engineer Scout Gong Reviewer Eric Li Report No.: 2510B1662SHA-003 TEST REPORT TTRFFCCMPE-01_V1© 2018 Intertek Page 3 of 9 Revision History Report No. Version Description Issued Date 2510B1662SHA-003 Rev. 01 Initial issue of report March 20, 2026 Report No.: 2510B1662SHA-003 TEST REPORT TTRFFCCMPE-01_V1© 2018 Intertek Page 4 of 9 1 GENERAL INFORMATION 1.1 Description of Equipment Under Test (EUT) Product name: Amplify power box subassembly Type/Model: Amplify APB Description of EUT: The EUT is power box which supports Wi-Fi/BLE function. Rating: 120-240V AC Category of EUT: Class B EUT type: Table top Floor standing Software Version: - Hardware Version: - Serial numbers: A260126-47-001 Sample received date: January 26, 2026 Date of test: January 26, 2026, to February 26, 2026 Report No.: 2510B1662SHA-003 TEST REPORT TTRFFCCMPE-01_V1© 2018 Intertek Page 5 of 9 1.2 Technical Specification Frequency Range: 2402-2480MHz Support Standards: Bluetooth LE Type of Modulation: GFSK Channel Number: 40 Data Rate: 1Mbps, 2Mbps Antenna Information: 3.78 dBi, External antenna Frequency Band: 2400MHz ~ 2483.5MHz Support Standards: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n(HT20), IEEE 802.11n(HT40) Type of Modulation: IEEE 802.11b: DSSS (CCK, DQPSK, DBPSK) IEEE 802.11g: OFDM (64-QAM, 16-QAM, QPSK, BPSK) IEEE 802.11n(HT20): OFDM (64-QAM, 16-QAM, QPSK, BPSK) IEEE 802.11n(HT40): OFDM (64-QAM, 16-QAM, QPSK, BPSK) Operating Frequency: 2412MHz to 2462MHz for IEEE 802.11b/g/n(HT20) 2422MHz to 2452MHz for IEEE 802.11n(HT40) Channel Number: 11 Channels for 802.11b, 802.11g ,802.11n(HT20) 7 Channels for 802.11n(HT40) Channel Separation: 5 MHz Antenna: External antenna: 3.78 dBi Gain Report No.: 2510B1662SHA-003 TEST REPORT TTRFFCCMPE-01_V1© 2018 Intertek Page 6 of 9 1.3 Description of Test Facility Name: Intertek Testing Services (Shanghai FTZ) Co., Ltd Address: Building 86, No. 1198 Qinzhou Road (North), Shanghai 200233, P.R. China Telephone: 86 21 61278200 Telefax: 86 21 54262353 The test facility is recognized, certified, or accredited by these organizations: CNAS Accreditation Lab Registration No. CNAS L21189 FCC Accredited Lab Designation Number: CN0175 IC Registration Lab CAB identifier.: CN0014 VCCI Registration Lab Registration No.: R-14243, G-10845, C-14723, T-12252 A2LA Accreditation Lab Certificate Number: 3309.02 Report No.: 2510B1662SHA-003 TEST REPORT TTRFFCCMPE-01_V1© 2018 Intertek Page 7 of 9 2 MPE Assessment Test Result: Pass 2.1 MPE Assessment Limit Mobile device exposure for standalone operations: Frequency range E-field strength (V/m) H-field strength (A/m) B-field (uT) Equivalent plane wave power density S eq (W/m 2 ) 0-1 Hz - 3,2 × 10 4 4 × 10 4 - 1-8 Hz 10 000 3,2 × 10 4 /f 2 4 × 10 4 /f 2 - 8-25 Hz 10 000 4 000/f 5 000/f - 0,025-0,8 kHz 250/f 4/f 5/f - 0,8-3 kHz 250/f 5 6,25 - 3-150 kHz 87 5 6,25 - 0,15-1 MHz 87 0,73/f 0,92/f - 1-10 MHz 87/f 1/2 0,73/f 0,92/f - 10-400 MHz 28 0,073 0,092 2 400-2 000 MHz 1,375 f 1/2 0,0037 f 1/2 0,0046 f 1/2 f/200 2-300 GHz 61 0,16 0,20 10 Mobile device exposure for simultaneous transmission operations: the sum of the MPE ratios for all simultaneously transmitting antennas incorporated in a host device is ≤ 1.0 Report No.: 2510B1662SHA-003 TEST REPORT TTRFFCCMPE-01_V1© 2018 Intertek Page 8 of 9 2.2 Assessment Results Power density (S) is calculated according to the formula: S = PG / (4πR²) Where S = power density in mW/cm² P = Radiated transmit power in mW G = numeric gain of transmit antenna R = distance (cm) As we can see from the test report 2510B1662SHA-001, 2510B1662SHA-002: The calculations in the table below use the highest gain of antenna for client EUT. These calculations represent worst case in terms of the exposure levels. Note: 1 mW/cm2 from 1.310 Table 1. BLE, WIFI cannot simultaneous transmitting, so the maximum rate of MPE is: 0.0486 mW/cm 2 ≤ 1.0 mW/cm 2 Mode Work Frequency Power Antenna Gain R S Limits (MHz) dBm mW dBi (Numeric) (cm) (mW/cm2) (mW/cm2) BLE 2402 – 2480 8.99 7.925 3.78 2.388 20 0.0038 1.0000 Wi-Fi 2412 – 2462 20.10 102.329 3.78 2.388 20 0.0486 1.0000 Report No.: 2510B1662SH…

Text truncated - open the document above for the full version.

深圳市优信无线科技有限公司 终端天线Mobile Antenna YX-P2425WZ3-050 型号 YX-P2425WZ3-050 Model YX-P2425WZ3-050 主要技术参数 Main Technical Specifications 频率范围 驻波比 输入阻抗 增益 极化形式 最大功率 输入接口 高度 重量 天线颜色 工作温度 2400-2500MHz ≤2.0 50Ω 3dBi 垂直极化 50W SMA-弯公头 (50±2)mm 10g 黑色 -40~70°C Frequency Range VSWR Input Impedance Gain Polarization type Max. Power Input Connector Length Weight Antenna Color Working Temperature 2400-2500MHz ≤2.0 50Ω 3dBi 垂直极化 50W SMA-WJ (50±2)mm 10g 黑色 -40~70°C Antenna manufacturer: Shenzhen Youxin Wireless Technology Co., Ltd. Address: 3rd Floor, Zhongwan Maker Center, No.25 Hongmian 4th Road,Bao'an Community, Yuanshan Subdistrict, Longgang District, Shenzhen, Guangdong, P.R.China N a m e 深圳市优信无线科技有限公司 深圳市优信无线科技有限公司

Sunlighten, Inc. RF TEST REPORT Report Type: FCC Part 15.247 RF report MODEL: Amplify APB REPORT NUMBER: 2510B1662SHA-001 ISSUE DATE: March 20, 2026 DOCUMENT CONTROL NUMBER: TTRF15.247-02_V1 © 2018 Intertek Intertek Testing Services (Shanghai FTZ) Co., Ltd Building No.86, 1198 Qinzhou Road (North) Caohejing Development Zone Shanghai 200233, China Telephone: 86 21 6127 8200 www.intertek.com TEST REPORT This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. TTRF15.247-02_V1 © 2018 Intertek Page 2 of 46 Report no.: 2510B1662SHA-001 Applicant: Sunlighten, Inc. 10975 EI Monte Street, Leawood, KS 66211, United States Manufacturer: Sunlighten, Inc. 10975 EI Monte Street, Leawood, KS 66211, United States Product Name: Amplify power box subassembly Type/Model: Amplify APB FCC ID: 2BUHI-APB01 SUMMARY: The equipment complies with the requirements according to the following standard(s) or Specification: 47CFR Part 15 (2024): Radio Frequency Devices (Subpart C) C63.10-2020 +Cor. 1-2023 +C63.10a-2024 +Errata to C63.10a-2024: American National Standard of Procedures for Compliance Testing of Unlicensed Wireless Device – Corrigendum 1 PREPARED BY: REVIEWED BY: Project Engineer Scout Gong Reviewer Eric Li Report No.: 2510B1662SHA-001 TEST REPORT TTRF15.247-02_V1 © 2018 Intertek Page 3 of 46 Content REVISION HISTORY................................................................................................................................................ 5 MEASUREMENT RESULT SUMMARY ..................................................................................................................... 6 1 GENERAL INFORMATION ............................................................................................................................. 7 1.1 DESCRIPTION OF EQUIPMENT UNDER TEST (EUT) ................................................................................................ 7 1.2 TECHNICAL SPECIFICATION ................................................................................................................................ 7 1.3 DESCRIPTION OF TEST FACILITY .......................................................................................................................... 8 2 TEST SPECIFICATIONS ................................................................................................................................... 9 2.1 STANDARDS OR SPECIFICATION .......................................................................................................................... 9 2.2 MODE OF OPERATION DURING THE TEST ............................................................................................................ 9 2.3 TEST SOFTWARE LIST ..................................................................................................................................... 10 2.4 TEST PERIPHERALS LIST .................................................................................................................................. 10 2.5 TEST ENVIRONMENT CONDITION: .................................................................................................................... 10 2.6 INSTRUMENT LIST ......................................................................................................................................... 11 2.7 MEASUREMENT UNCERTAINTY ........................................................................................................................ 12 3 MINIMUM 6DB BANDWIDTH ..................................................................................................................... 13 3.1 LIMIT ......................................................................................................................................................... 13 3.2 MEASUREMENT PROCEDURE .......................................................................................................................... 13 3.3 TEST CONFIGURATION ................................................................................................................................... 13 3.4 TEST RESULTS OF MINIMUM 6DB BANDWIDTH ................................................................................................... 13 4 MAXIMUM CONDUCTED OUTPUT POWER AND E.I.R.P. ............................................................................. 14 4.1 LIMIT ......................................................................................................................................................... 14 4.2 MEASUREMENT PROCEDURE .......................................................................................................................... 14 4.3 TEST CONFIGURATION ................................................................................................................................... 14 4.4 TEST RESULTS OF MAXIMUM CONDUCTED OUTPUT POWER ................................................................................. 14 5 POWER SPECTRUM DENSITY ..................................................................................................................... 15 5.1 LIMIT ............…

Text truncated - open the document above for the full version.

Report No.: 2510B1662SHA-002 TEST REPORT TTRF15.247-03_V1 © 2018 Intertek Page 56 of 61 11N40SISO-Ant1-2422-PASS 11N40SISO-Ant1-2437-PASS 11N40SISO-Ant1-2452-PASS Report No.: 2510B1662SHA-002 TEST REPORT TTRF15.247-03_V1 © 2018 Intertek Page 57 of 61 Duty Cycle Test Result Test Mode Antenna Frequency [MHz] Transmission Duration [ms] Transmission Period [ms] Duty Cycle [%] Factor 11B Ant1 2412 17.00 17.00 100.00 0.00 11B Ant1 2437 19.00 19.00 100.00 0.00 11B Ant1 2462 19.00 19.00 100.00 0.00 11G Ant1 2412 5.49 5.52 99.46 0.02 11G Ant1 2437 5.49 5.52 99.46 0.02 11G Ant1 2462 5.48 5.52 99.28 0.03 11N20SISO Ant1 2412 5.07 5.11 99.22 0.03 11N20SISO Ant1 2437 5.09 5.12 99.41 0.03 11N20SISO Ant1 2462 5.08 5.12 99.22 0.03 11N40SISO Ant1 2422 2.47 2.51 98.41 0.07 11N40SISO Ant1 2437 2.47 2.51 98.41 0.07 11N40SISO Ant1 2452 2.47 2.50 98.80 0.05 Report No.: 2510B1662SHA-002 TEST REPORT TTRF15.247-03_V1 © 2018 Intertek Page 58 of 61 Test Graphs NTNV-11B-Ant1-2412 NTNV-11B-Ant1-2437 NTNV-11B-Ant1-2462 Report No.: 2510B1662SHA-002 TEST REPORT TTRF15.247-03_V1 © 2018 Intertek Page 59 of 61 NTNV-11G-Ant1-2412 NTNV-11G-Ant1-2437 NTNV-11G-Ant1-2462 Report No.: 2510B1662SHA-002 TEST REPORT TTRF15.247-03_V1 © 2018 Intertek Page 60 of 61 NTNV-11N20SISO-Ant1-2412 NTNV-11N20SISO-Ant1-2437 NTNV-11N20SISO-Ant1-2462 Report No.: 2510B1662SHA-002 TEST REPORT TTRF15.247-03_V1 © 2018 Intertek Page 61 of 61 NTNV-11N40SISO-Ant1-2422 NTNV-11N40SISO-Ant1-2437 NTNV-11N40SISO-Ant1-2452 **************************************** END ***************************************

Sunlighten, Inc. RF TEST REPORT Report Type: FCC Part 15.247 RF report MODEL: Amplify APB REPORT NUMBER: 2510B1662SHA-002 ISSUE DATE: March 20, 2026 DOCUMENT CONTROL NUMBER: TTRF15.247-03_V1 © 2018 Intertek Intertek Testing Services (Shanghai FTZ) Co., Ltd Building No.86, 1198 Qinzhou Road (North) Caohejing Development Zone Shanghai 200233, China Telephone: 86 21 6127 8200 www.intertek.com TEST REPORT This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. TTRF15.247-03_V1 © 2018 Intertek Page 2 of 61 Report no.: 2510B1662SHA-002 Applicant: Sunlighten, Inc. 10975 EI Monte Street, Leawood, KS 66211, United States Manufacturer: Sunlighten, Inc. 10975 EI Monte Street, Leawood, KS 66211, United States Product Name: Amplify power box subassembly Type/Model: Amplify APB FCC ID: 2BUHI-APB01 SUMMARY: The equipment complies with the requirements according to the following standard(s) or Specification: 47CFR Part 15 (2024): Radio Frequency Devices (Subpart C) C63.10-2020 +Cor. 1-2023 +C63.10a-2024 +Errata to C63.10a-2024: American National Standard of Procedures for Compliance Testing of Unlicensed Wireless Device – Corrigendum 1 PREPARED BY: REVIEWED BY: Project Engineer Scout Gong Reviewer Eric Li Report No.: 2510B1662SHA-002 TEST REPORT TTRF15.247-03_V1 © 2018 Intertek Page 3 of 61 Content REVISION HISTORY................................................................................................................................................ 5 MEASUREMENT RESULT SUMMARY ..................................................................................................................... 6 1 GENERAL INFORMATION ............................................................................................................................. 7 1.1 DESCRIPTION OF EQUIPMENT UNDER TEST (EUT) ................................................................................................ 7 1.2 TECHNICAL SPECIFICATION ................................................................................................................................ 8 1.3 ANTENNA INFORMATION .................................................................................................................................. 8 1.4 DESCRIPTION OF TEST FACILITY ......................................................................................................................... 9 2 TEST SPECIFICATIONS ................................................................................................................................. 10 2.1 STANDARDS OR SPECIFICATION ........................................................................................................................ 10 2.2 MODE OF OPERATION DURING THE TEST .......................................................................................................... 10 2.3 TEST SOFTWARE LIST ..................................................................................................................................... 11 2.4 TEST PERIPHERALS LIST .................................................................................................................................. 11 2.5 TEST ENVIRONMENT CONDITION: .................................................................................................................... 11 2.6 INSTRUMENT LIST ......................................................................................................................................... 12 2.7 MEASUREMENT UNCERTAINTY ........................................................................................................................ 13 3 MINIMUM 6DB BANDWIDTH ..................................................................................................................... 14 3.1 LIMIT ......................................................................................................................................................... 14 3.2 MEASUREMENT PROCEDURE .......................................................................................................................... 14 3.3 TEST CONFIGURATION ................................................................................................................................... 14 3.4 TEST RESULTS OF MINIMUM 6DB BANDWIDTH ................................................................................................... 14 4 MAXIMUM CONDUCTED OUTPUT POWER AND E.I.R.P. ............................................................................. 15 4.1 LIMIT ......................................................................................................................................................... 15 4.2 MEASUREMENT PROCEDURE .......................................................................................................................... 15 4.3 TEST CONFIGURATION ................................................................................................................................... 16 4.4 TEST RESULTS OF MAXIMUM CONDUCTED OUTPUT POWER ................................................................................. 16 5 POWER SPECTRU…

Text truncated - open the document above for the full version.

Page 1 of 5 Setup Photos Page 2 of 5 1. Conducted Emission Page 3 of 5 2. Radiated Emission Below 1GHz Page 4 of 5 Above 1GHz Page 5 of 5 3. RF
