2BUHQ-TXM2830wireless module

TEST REPORT Report No. : KES-RF250845 Page1/54 KES Co., Ltd. #3002, #3503, #3701, 40, Simin-daero365beon-gil, Dongan-gu, Anyang-si,Gyeonggi-do, 14057, Republic ofKorea Tel : +82-31-425-6200, Fax : +82-31-341-3838 KES-QP16-F01(00-23-01-01)KES Co., Ltd. You can check the authenticity of this test report on our website (www.kes.co.kr). FCC TEST REPORT 1. Client ○ Name : TECHXEN INC ○ Address : 9th floor, N Tower Garden 26, Hwangsaeul-ro 200 beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, South Korea 2. Sample Description ○ Product item : wireless module ○ Model name : TX-M2830 ○ Manufacturer etc. : TECHXEN INC 3. Date of test :2026.01.05 ~ 2026.01.09 4. Location of Test :Permanent Testing LabOn Site Testing ○ Address : 473-21, Gayeo-ro, Yeoju-si, Gyeonggi-do, 12658, Rep. of Korea 5. FCC Rule part(s) :Part 15 Subpart C 15.247 6. Test result :PASS The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced and copied without permission without the written consent of KES Co., Ltd. This laboratory is not accredited for the test results marked *. This test report is not related to KOLAS accreditation. Affirmation Tested byTechnical Manager Name : Myeong-Ho, Lee(Signature) Name :Yeong-Jun Cho(Signature) 2026. 01. 22. KES Co., Ltd. Report No. : KES-RF250845 Page2/54 KES-QP16-F01(00-23-01-01)KES Co., Ltd. You can check the authenticity of this test report on our website (www.kes.co.kr). REPORT REVISION HISTORY DateTest Report No.Revision History 2026.01.22KES-RF250845Initial This report shall not be reproduced except in full, without the written approval of KES Co., Ltd. This document may be altered or revised by KES Co., Ltd. personnel only, and shall be noted in the revision section of the document. Any alteration of this document not carried out by KES Co., Ltd. will constitute fraud and shall nullify the document. Report No. : KES-RF250845 Page3/54 KES-QP16-F01(00-23-01-01)KES Co., Ltd. You can check the authenticity of this test report on our website (www.kes.co.kr). TABLE OF CONTENTS 1.General information ................................................................................................................................... 4 1.1.EUT description .......................................................................................................................... 4 1.2.Test configuration........................................................................................................................ 4 1.3.Information about derivative model ............................................................................................ 5 1.4.Accessory information ................................................................................................................ 5 1.5.Device modifications................................................................................................................... 5 1.6.Sample calculation ..................................................................................................................... 5 1.7.Measurement Uncertainty .......................................................................................................... 5 1.8.Frequency/channel operations ................................................................................................... 6 2.Summary of tests ....................................................................................................................................... 7 3.Test results ................................................................................................................................................. 8 3.1.6㏈bandwidth .......................................................................................................................... 8 3.2.Output power ............................................................................................................................ 12 3.3.Power spectral density ............................................................................................................. 14 3.4.Radiated restricted band and emissions .................................................................................. 18 3.5.Conducted spurious emissions & band edge ........................................................................... 43 3.6.AC conducted emissions .......................................................................................................... 50 3.7.Antenna Requirement............................................................................................................... 53 Appendix A. Measurement equipment.......................................................................................................... 54 Report No. : KES-RF250845 Page4/54 KES-QP16-F01(00-23-01-01)KES Co., Ltd. You can check the authenticity of this test report on our website (www.kes.co.kr). 1.General information Applicant:TECHXEN INC Applicant address:9th floor, N Tower Garden 26, Hwangsaeul-ro 200 beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, South Korea Test site:KES Co., Ltd. Test site address:#3002, #3503, #3701, 40, Simin-daero365beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do, 14057, Rep. of Korea 473-21, Gayeo-ro, Yeoju-si, Gyeonggi-do, 12658, Rep. of Korea Test FacilityFCC Accreditation Designation No.: KR0100, Registration No.: 444148 FCC rule part(s):15.247 FCC ID:2BUHQ-TXM2830 Test device serial No.:ProductionPre-productionEngineering 1.1.EUT description Equipment under testwireless module Frequency range & Number of channels 2 402㎒~ 2 480㎒(LE 1,2 Mbps) : 40 ch 2 405㎒~ 2 480㎒(Zigbee) : 16 ch ModelTX-M2830 Modulation techniqueGFSK,DSSS Antenna specificationWIRE Antenna // Peak gain: 4.52㏈i Power sourceDC 3.3 V H/W versionMC2543 F/W versionTX-M2830-V00000370 1.2.Test configuration TheTECHXEN INC // wireless module // TX-M2830 // FCC ID: 2BUHQ-TXM2830was tested according to the specification of EUT, the EUT must compl…

Text truncated - open the document above for the full version.

1. Product Overview 1-1. Overview The TX—M2830 model is designed for wireless data transmission and reception under the Zigbee,BLE communication standard, an RF transceiver and External Antenna via U.FL connector. 1-2. Features TX-M2830 Product Manual Zigbee, BLEWireless 2.8V ~ 3.6VVoltage UART Communication 2. Components 2-1. The TX-M2830 wireless module is supplied in tape-and-reel packaging. 3. Product Specifications Product Manual TX-M2830ModelName 14.0 x12.0 x 1.9 mmDimensions DC 3.3VPower Supply -30°C to+80°C OperatingTemperature UARTInterface Zigbee,BLEWirelessStandard 2.402 ~ 2.485GHzFrequency Range: 16 Channels, BLE : 40Channels Numberof Channels : On-BoardPCB PatternAntennaAntenna type: 4. User Manual 4-1. Pin Description DescriptionTypePin NamePin No. 3.3V Power SupplyPowerVDD12 GroundGroundGND1,11, 13, 30 UART TransmitI/OTXD22 UART ReceiveI/ORXD21 4-2. Operation description (1) Power the module by applying 3.3V to the VDD pin of the wireless module. (2) The module is controlled by a host microcontroller (MCU) via a UART interface. (3) Configure the module by sending commands via the TXD/RXD pins, discover and register with the network and transmit and receive data. Product Manual Note : How to display the FCC ID Certification mark For very small devices, the mark may appear in the user manual TECHXEN INC TX-M2830 2546 KC FCC ID 2BUHQ-TXM2830 - 7 - FCC Compliance Statement This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to correct the interference by one of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. FCC Caution Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. End Product Labeling The module is labeled with its own FCC ID. If the FCC ID are not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. In that case, the final end product must be labeled in a visible area with the following: “Contains FCC ID: 2BUHQ-TXM2830 Information on test modes and additional testing requirements -OEM integrator is still responsible for testing their end-product for any additional compliance requirements required with this module installed (for example, digital device emissions, PC peripheral requirements, additional transmitter in the host, etc.). Additional testing, Part 15 Subpart B disclaimer -The final host product also requires Part 15 subpart B compliance testing with the modular transmitter installed to be properly authorized for operation as a Part 15 digital device.

Rev 1/26/2023 TECHXEN INC Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 01-16-2026 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2BUHQ-TXM2830 TECHXEN INC (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. TECHXEN INC (“the applicant”) certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Device is inherently compliant based on hardware limitations or software controls. or A Software Bill of Materials (SBOM) is provided to the TCB for review, and The end-user or third parties cannot install additional software on this device. Sincerely, Engineering Manager / seung yeon You TECHXEN INC Rev 1/26/2023 TECHXEN INC Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 01-16-2026 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2BUHQ-TXM2830 TECHXEN INC (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, Engineering Manager / seung yeon You TECHXEN INC

TECHXEN INC 9th floor, N Tower Garden 26, Hwangsaeul-ro 200 beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, South Korea Tel: +82-10-4201-4338 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: January 16, 2026 Ref: Attestation Statements Part 2.911(d)(7) Filing FCC ID: 2BUHQ-TXM2830 Applicant FRN : 0037894680 TECHXEN INC certifies that, as of the date of the filing of the application, FCC US AGENT, LLC. is our designated U.S. agent for service of process for the above referenced FCC ID. TECHXEN INC accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. FCC US AGENT, LLC. accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Company Name: FCC US Agent, LLC FRN: 0033402884 Address: 3722 Illinois Avenue, Saint Charles, IL, 60174, USA Contact Person: Tim Payne Phone: 708-571-3148 Email: [email protected] Sincerely, TECHXEN INC FCC US AGENT, LLC. Engineering Manager / seung yeon You Tim Payne [U.S. Agent signature] Rev 1/26/2023

Applicant / Grantee TECHXEN INC / 2BUHQ FCC ID 2BUHQ-TXM2830 Section 15.212 Modular Transmitters Request for Modular Approval Request for Limited Modular Approval Requirements EUT Conditions Comply (Y/N) Single Modular Approval Requirements 1 The radio elements of the modular transmitter must have their own shielding. The physical crystal and tuning capacitors may be located external to the shielded radio elements. The radio elements of the modular transmitter are enclosed within a dedicated metal shield to prevent coupling. Y 2 The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over- modulation. All modulation and data inputs are buffered through the onboard circuitry to ensure compliance under all conditions. Y 3 The modular transmitter must have its own power supply regulation.. The module incorporates its own internal voltage regulation to maintain compliance regardless of the host's power supply. Y 4 The modular transmitter must comply with the antenna and transmission system requirements of Sections 15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The “professional installation” provision of Section 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. The module is equipped with a U.FL antenna connector, which is considered a 'unique' antenna coupler in accordance with Section 15.203 Y 5 The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing for compliance with Part 15 requirements. Unless the transmitter module will be battery powered, it must comply with the AC line conducted requirements found in Section 15.207. AC or DC power lines and data input/output lines connected to the module must not contain ferrites, unless they will be marketed with the module (see Section 15.27(a)). The length of these lines shall be the length typical of actual use or, if that length is unknown, at least 10 centimeters The module was tested in a stand- alone configuration on a test fixture to demonstrate independent compliance. Y to insure that there is no coupling between the case of the module and supporting equipment. Any accessories, peripherals, or support equipment connected to the module during testing shall be unmodified and commercially available (see Section 15.31(i)). 6 The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying its FCC identification number. (A) If using a permanently affixed label, the modular transmitter must be labeled with its own FCC identification number, and, if the FCC identification number is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: XYZMODEL1” or “Contains FCC ID: XYZMODEL1.” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. (B) If the modular transmitter uses an electronic display of the FCC identification number, the information must be readily accessible and visible on the modular transmitter or on the device in which it is installed. If the module is installed inside another device, then the outside of the device into which the module is installed must display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains FCC certified transmitter module(s).” Any similar wording that expresses the same meaning may be used. The user manual must include instructions on how to access the electronic display. A copy of these instructions must be included Due to the module's small physical size, the FCC ID is displayed electronically in compliance with FCC regulations. Instructions for identifying this electronic identification are provided in the user manual. Y in the application for equipment authorization. 7 The modular transmitter must comply with any specific rules or operating requirements that ordinarily apply to a complete transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. Comprehensive instructions explaining the specific operational requirements are provided in the product's user manual. Y 8 The modular transmitter must comply with any applicable RF exposure requirements in its final configuration. The module complies with all applicable RF exposure requirements for its intended final configuration and usage. Y seung yeon You / Engineering Manager TECHXEN INC January 16, 2026.

TECHXEN INC 9th floor, N Tower Garden 26, Hwangsaeul-ro 200 beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, South Korea +82-10-4201-4338 Date: January 16, 2026 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2BUHQ-TXM2830 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: PERMANENT Exhibit Type File Name Part List Part List.pdf Schematics Diagram(s) Schematics.pdf Operation description Operational Description.pdf Block diagram Block diagram.pdf And the above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Engineering Manager / seung yeon You TECHXEN INC

TECHXEN INC 9th floor, N Tower Garden 26, Hwangsaeul-ro 200 beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, South Korea Tel: +82-10-4201-4338 Date: January 16, 2026 Model : TX-M2830 To whom it may concern: I, the undersigned, hereby authorize Young-Jin, Lee of KES Co., Ltd. and hereafter referred to as KES Co., Ltd., to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Young-Jin, Lee of KES Co., Ltd. on our behalf shall have the same effect as acts of our own. In authorizing KES Co., Ltd. as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; TECHXEN INC 9th floor, N Tower Garden 26, Hwangsaeul-ro 200 beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, South Korea Tel: +82-10-4201-4338 j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, seung yeon You / Engineering Manager TECHXEN INC

Page 1 of 1 TX-260123-06Document No TX-M2830Model SY YouApproved ByJoshPrepared By Antenna Installation and Compliance StatementSubject 1. Introduction This statement is to certify that the TX-M2830 wireless module is designed and manufactured in full compliance with the antenna requirements specified in FCC Part 15.203. The regulation stipulates that no antenna other than that furnished by the responsible party shall be used with the device to prevent unauthorized modifications. 2. Technical Specification of Antenna Connection The TX-M2830 utilizes a standard U.FL connector for the RF interface. According to the measured data in the antenna specification, the peak gain of the antenna is -5.14 dBiat 2402 MHz. Antenna Type: External / Module Antenna Connection Method: U.FL Connector Peak Gain: 4.38 dBi(2400.000 MHz) 3. Implementation of Permanent Attachment To ensure that the device meets the "permanently attached" criteria of FCC Part 15.203, Techxenimplements the following technical measures during the mass production process: Permanent Bonding: An industrial-grade permanent adhesive is applied to the U.FL connector interface after initial assembly. Tamper Resistance: Once the adhesive is cured, the antenna cannot be disconnected or replaced by the end-user without causing permanent physical damage to the module’s RF circuit or the antenna assembly. Manufacturing Control: This process is performed strictly at the factory level; therefore, the device is not sold to end-users without the antenna being permanently fixed. 4. Conclusion We, the undersigned, hereby declare that the TX-M2830 complies with all requirements of FCC Part 15.203 through the use ofa permanently bonded connection. The end-user will not have access to any means of replacing the antenna with an unauthorized type. (Signature) Name: Seung yeonYou Title: Manager Company : Techxen Address : 9th floor, N Tower Garden 26, Hwangsaeul-ro 200 beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, 13595, Korea

FCC ID : 2BUHQ-TXM2830 Page 1 of 1 External photos

FCC ID : 2BUHQ-TXM2830 Page 1 of 1 Label Location Label & Label The device is so small that it is not practicable to place the statement specified under 15.19 statement request, the information required by this paragraph shall be placed in a prominent location in the User’s Manual.

FCC ID : 2BUHQ-TXM2830 Page 1 of 1 Internal photos

FCC ID: 2BUHQ-TXM2830 Page 1 of 1 RF exposure According to 447498 D01 General RF Exposure Guidance v06 The 1-g and 10-g SAR test exclusion thresholds for 100 ㎒ to 6 ㎓ at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(㎓)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, Where; f(㎓) is the RF channel transmit frequency in ㎓ Power and distance are rounded to the nearest ㎽ and mm before calculation The result is rounded to one decimal place for comparison Results Mode Frequency (㎓) Distance (mm) Max Average tune-up power (㏈m) Calculation value Exclusion Threshold (㏈m) (㎽) LE 1 Mbps 2.402 ~ 2.480 5 5.00 3.162 0.996 ≤3.0 LE 2 Mbps 2.402 ~ 2.480 5 5.00 3.162 0.996 Zigbe 2.405 ~ 2.480 5 -3.00 0.501 0.158

JYCELETRONICO.,LTD 1 Customer： ProductName：WIRECABLE85mmAntenna Productcode ： Antenna-TX- Customercode： Sampledate：2024-6-13 Confirm： ApprovalQualityEngineerSignature DavidHenrylisa CustomerConfirm： ApprovalQualityEngineerSignature Confirmresult ：□ PASS □ NG □ Others JYCELETRONICO.,LTD 2 SPECIFICATIONITEM ItemDescription 1.............................................SPEC 2.............................................SPECITEM 3.............................................Engineerdrawing 4.............................................Performance JYCELETRONICO.,LTD 3 RFAntennaCableAssembly Specification 1.ElectricalProperties 1.1FrequencyRange........................2.4GHz-2.5GHz 1.2Impedance.................................50ΩNominal 1.3VSWR..........................................1.92:1MAX 1.4ReturnLoss.................................-14dBMax 1.5Gain(peak).................................4.52dBi 1.6Cableloss....................................0.02dBiMax 1.7Polarization.................................LinearVertical 1.8Conn..........................................IPEX1.13 2.PhysicalProperties: 2.1AntennaMaterial.................................Cu 2.2OperatingTemp..............................-20°C-+65°C 2.3StorageTemp.................................-30°C-+75°C JYCELETRONICO.,LTD 4 AntennaTestequipment SPEC:2.4GHzBluetoothAntenna Product 测试环境 Testenvironment S参数 （S-parameter) 1.电压驻波比(VSWR) 2.回波损耗（RrtunLoss) 网络分析仪：Agilent8753ES 2.有源测试 (Active) 1.发射功率（TRP) 2.接收灵敏度（TIS） 3.屏灭/屏亮 1.暗室：5*3*3m（3D）Chamber 2.综测仪：Agilent8960,CMW500 3.无源测试 （Passive) 1.天线增益(Gain) 2.天线效率（Efficiency) 1.暗室：5*3*3m（3D）Chamber 2.网络分析仪：Agilent8753ES 20mm JY10619 6 4 mm±2 TCA48 TW-MSJ-85-238 BLACK 85mm RG1.37 GR cable ipex to open,L=85MM 4 JYCELETRONICO.,LTD 6 1.0驻波比V.S.W.R JYCELETRONICO.,LTD 7 2.0回波损耗Logmag JYCELETRONICO.,LTD 8 3.0史密斯图Smith JYCELETRONICO.,LTD 9 2.4GhzPerformancedata: JYCELETRONICO.,LTD 10 Frequency:2.40GHzPeakGain:4.38dBiEfficiency:67.63% ~END~ JYCELETRONICO.,LTD 11 Frequency:2.45GHzPeakGain:4.46dBiEfficiency:64.72% JYCELETRONICO.,LTD 12 Frequency:2.50GHzPeakGain:4.41dBiEfficiency:66.84% JYCELETRONICO.,LTD 13 CompanyProfile JYCELECTRONICCO.,LTD.isaprofessionalproductionand processingcompanyspecializinginvarioustypesofRF connector,antennas,coaxialprocessing,IPEXconnectors,GPS antennas,GSMantennas,2.4Gantennas,researchanddevelopment, andotherproducts.Ithasacompleteandscientificquality managementsystem.Theintegrity,strength,andproductqualityof JYCELECTRONICCO.,LTD.havebeenrecognizedbytheindustry. ~~Theend~~

FCC ID : 2BUHQ-TXM2830 Page 1 of 1 Radiated test AC conducted test Blank
