2BVD4-BAA5522ADigital Signage

DIGITAL SIGNAGE USER MANUAL Please read this manual carefully before operating your set and retain it for future reference. www.geephon.com 1 CAUTION RISKOFELECTRICSHOCK DONOTOPEN CAUTION:TO AVOIDTHE RISK OF ELECTRIC SHOCK. DO NOT REMOVE COVER (OR BACK). NO USER - SERVICEABLE PARTS INSIDE. REFER SERVICINGTO QUALIFIED SERVICE PERSONNEL. This symbol is intended to alert the user to avoid the risk of electric shock, do not disassemble this equipment by anyone except a qualified service personnel. This symbol is intended to alert the user to the presence of important operation and maintenance instructions in the literature accompanying the equipment. WARNING 2 § 15.19 Label requirements. (Suit for Verification (VOC) and Certification (ID)) This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. § 15.21 Information to user.(Suit for Verification (VOC) and Certification (ID) and Declaration of Conformity(DOC)) Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. § 15.105 Information to the user. (Suit for Class A and Class B digital device(unintentional radiator or intentional radiator)) Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. *RF warning for Mobile device:(Suit for FCC Part 15.247 of ID) This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. FCC Caution. Precautions for Safe Installation - Before installation, it is essential to read the "Preparatory Matters before Installation" thoroughly and adhere to all operational instructions within this guide. -Employ lifting equipment appropriate for the product's weight for hoisting. Prior to hoisting, ascertain the dimensions, weight, hoisting height, etc. of the equipment. Overloading is strictly prohibited. -Before hoisting, it is essential to inspect the work site, lifting and hoisting machinery, slings, safety devices, control mechanisms, brakes, hooks and so on. -Obvious and visible safety warning signs must be set up in the hoisting operation area. -Before the hoisting operation, the weight and center of gravity of the object to be hoisted must be clearly known, and the center of gravity should be accurately located when hoisting. - Trial hoisting and trial lowering must be carried out before the formal hoisting to ensure that the hoisting and landing processes are smooth and stable. -There should be sufficient lighting equipment for night operations. -Hoisting operations are prohibited in bad weather conditions such as heavy fog, strong winds, and heavy rain. -Tools and debris on the equipment should be removed before hoisting to avoid hurting people if they fall. -When hoisting, the installation personnel should stand in a position where they can avoid. When the equipment has been hoisted and moved to the docking position of the fixed base, the installation personnel can then approach to support the equipment for alignment. 3 Precautions for Use The specification of the AC power cord must be matched with the corresponding wire diameter according to the maximum current value used by the equipment to prevent the wire from heating up due to substandard wire specifications. When the equipment is exposed to intense sunlight, its surface will become very hot. Please do not touch it at this time. Under intense sunlight, the remote control may not work, which is a normal phenomenon. In case of such a situation, it is necessary to shield the remote control and place it close to the receiving head of the equipment, or wait until the sunlight is no longer intense before operating it. When disconnecting the AC power supply, please ensure that the equipment is not exposed to intense sunlight for a long time. When storing the equipment, cover it with a cloth or box. This can prevent problems such as screen blackening, creasing and yellowing, and help extend the service life of electronic components. 4 1. Read Instructions All the safety and operating instructions should be read before the appliance is operated. 2. Retain Instructions The safety and operating instructions should be retained for future reference. 3. Heed Warnings All warnings on the appliance and in the operating instructions should be adhered to. 4. Follow Instructions All operating instructions should be followed. 5. Battery Batteries shall not be exposed to excessive heat such as sunshine, fire or so on. 6. Earthing Connection The apparatus shall be connected to a MAlNS socket outlet with a protective earthing connection. 7. Water and Moisture The appliance should not be used near water. 8. Ventilation The appl…

Text truncated - open the document above for the full version.

Rev 1/26/2023 GEEPHON INTELLIGENCE TECHNOLOGY CO., LTD. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 4-10-2026 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID:2BVD4-BAA5522A [GEEPHON INTELLIGENCE TECHNOLOGY CO., LTD.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. [GEEPHON INTELLIGENCE TECHNOLOGY CO., LTD.] (“the applicant”) certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Device is inherently compliant based on hardware limitations or software controls. or A Software Bill of Materials (SBOM) is provided to the TCB for review, and The end-user or third parties cannot install additional software on this device. Sincerely, (Applicant signature) (Applicant printed name) Rosen Zhou Rev 1/26/2023 GEEPHON INTELLIGENCE TECHNOLOGY CO., LTD. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 4-10-2026 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID:2BVD4-BAA5522A [GEEPHON INTELLIGENCE TECHNOLOGY CO., LTD.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name) Rosen Zhou

GEEPHON INTELLIGENCE TECHNOLOGY CO., LTD. Date: 2026-4-10 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD FCC ID:2BVD4-BAA5522A To Whom It May Concern: This letter is to ascertain thatGEEPHON INTELLIGENCE TECHNOLOGY CO., LTD./Room 401,Building A,Qiaode Science and TechnologyPark,No. 7, Guangming District EUT: Digital Signage MODEL No.: BAA5522A-BB-45P, B*A5522A-**-***(*can be 0-9 or A- Z) Has been the units used for conducting FCC compliance testing, the SDoC part Have be tested by EMTEK (SHENZHEN) CO., LTD. If you have any question or concerns, pls. contact us. Sincerely, Client’s signature ： Client’s name / title ：Rosen Zhou Contact information / address: GEEPHON INTELLIGENCE TECHNOLOGY CO., LTD. /Room 401,Building A,Qiaode Science and TechnologyPark,No. 7, Guangming District

GEEPHON INTELLIGENCE TECHNOLOGY CO., LTD. U.S. Agent Designation for Service of Process - Certification Attestation Letter 4/ 10/2026 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Ref: Attestation Statements Part 2.911(d)(7) Filing FCC ID:2BVD4-BAA5522A Applicant FRN: 0038207239 [GEEPHON INTELLIGENCE TECHNOLOGY CO., LTD.] (“the applicant”) certifies that, a s of the date of the filing of the application, [Global Product Services and Consultation LLC] is our designated U.S. agent for service of process for the above referenced FCC ID. [GEEPHON INTELLIGENCE TECHNOLOGY CO., LTD.] accepts to maintain an agent fo r no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. [Global Product Services and Consultation LLC] accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Company Name: Global Product Services and Consultation LLC FCC Registration Number (FRN): 0033406703 Physical U.S. Company Address: 328 W Palm Ave. Monrovia, CA91016 Contact Person: Michael Chan Cell Phone : 626-366-4358 Agent Email Address: [email protected] Sincerely, Company: GEEPHON INTELLIGENCE TECHNOLOGY CO., LTD. Company Representative: Rosen Zhou Title: Engineer Signature: Designated Agent: [Global Product Services and Consultation LLC] Designated Agent Representative: [Michael Chan] Title: [Technical Director] Signature: Date : 04/14/2026 SC:6048040

Rev 11/20/07 GEEPHON INTELLIGENCE TECHNOLOGY CO., LTD. Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID:2BVD4-BAA5522A Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram, Schematics, Operational Description, Block Diagram, Schematics, Operational Description, The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Client’s name / title ：Rosen Zhou Contact information / address: GEEPHON INTELLIGENCE TECHNOLOGY CO., LTD. /2F., No. 19, Ln, 146, Xinhu 2nd Rd., Neihu Dist. Date: 2026-4-10

GEEPHON INTELLIGENCE TECHNOLOGY CO., LTD. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Date: 2026-4-10 SUBJECT: FCC Application for FCC ID:2BVD4-BAA5522A To Whom It May Concern: We, the undersigned, hereby authorize Lisa Wang at EMTEK (SHENZHEN) CO., LTD.on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by EMTEK (SHENZHEN) CO., LTD.on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, Client’s name / title ：Rosen Zhou Contact information / address: GEEPHON INTELLIGENCE TECHNOLOGY CO., LTD. /Room 401,Building A,Qiaode Science and TechnologyPark,No. 7, Guangming District

GEEPHON INTELLIGENCE TECHNOLOGY CO., LTD. Declaration on model difference We the undersigned hereby confirm that any of our production units bearing the following model numbers are identical in circuitry and electrical, mechanical and physical construction; * can be 0-9 or A-Z to indicate the different code of the client or the different sales market. FCC ID: 2BVD4-BAA5522A Production name Trade name Model no. Digital Signage GEEPHON BAA5522A-BB-45P, B*A5522A-**-***(*can be 0-9 or A- Z) Confirmed by GEEPHON INTELLIGENCE TECHNOLOGY CO., LTD. Client’s name / title ： Rosen Zhou/Engineer Contact information / address: GEEPHON INTELLIGENCE TECHNOLOGY CO., LTD. /Room 401,Building A,Qiaode Science and TechnologyPark,No. 7, Guangming District Date: 2026-4-10

Label location

Antenna location

FCC ID : 2BVD4-BAA5522A RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) Radiation as specified in §1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density(mW/cm 2 ) Average Time (A) Limits for Occupational/Control Exposures 300-1500 -- -- F/300 6 1500- 100000 -- -- 5 6 (B) Limits for General Population/Uncontrol Exposures 300-1500 -- -- F/1500 6 1500- 100000 -- -- 1 30 11.1 Friis transmission formula: Pd= (Pout*G)\ (4*pi*R 2 ) Where Pd= Power density in mW/cm 2 Pout=output power to antenna in mW G= Numeric gain of the antenna relative to isotropic antenna Pi=3.1416 R= distance between observation point and center of the radiator in cm Pd the limit of MPE, 1mW/cm 2 ,If we know the maximum gain of the nd total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. RF Exposure Information: The radiated output power of this device meets the limits of FCC/IC radio frequency exposure limits.This device should be operated with a minimum separation distance of 20cm (8 inches) between the equipment and a person's body. 11.2 Measurement Result Wifi 2.4G Antenna gain: 8 dBi Measured power (dBm) Tune-up power (dBm) Max tune-up power (dBm) Antenna Gain Numeric Evaluation result (mW/cm2 ) Power density Limits (mW/cm2 ) 8.93 8.0 to 9.0 9.0 6.31 0.00997 1

SPECIFICATIONFOR APPROVAL NO. （ Number （ Page （ Contents ） ofPage ） Code ） 1 Spec Cover 11 2 Spec Item 12 3 Drawing 13 4 Test Reports 14 5 S Parameter 15 6 Gain Test 16 7 8 9 10 --- 11--- 12 --- Dongguan Chuangjie Electronics Co., Ltd. ADD：3rd Floor, Building A, Junteng Technology Park, No. 61 Danning Pujiang Road, Humen Town, Dongguan City, Guangdong Province, China DESCRIPTIONSIGNDATEAPPROVER D C B YD 2015-03-05 SCALE: 1/1 UNITS: mm REVISION: A APPROVED BY Tolerance D C A E 7 6 5 4 32 1 D C B A E 7 5 6 4 3 1 2 2.4G 5G 5.8G Antenna PART NO.: GF-8614-60-IPEX 1 DWG NAME: NB058-113B-90IX.DWG 4 32 1 C B A B CHECKED BY DESIDNED BY 8 8 ±3°X° X.X ±0.20 X.XX ±0.10 FPC 86*14mm SHOWA-O.D. 1.13mm Black Mini Connector Part Number Name NB004-A01 FPC R-CB-113B Coaxial Cable Connector CI-113 1 No. 2 3 1 1 Q'ty 1 Material leon 2015-03-05 jeff 2015-03-05 Dongguan Chuangjie Electronics Co., Ltd. GF-8614GF-8614-60-IPEX 1 Test Reports Impedance50 0hm Nominal Return Loss-15 dB Max RadiationOmni-directional Cable Loss4.9 dB / m Max PolarizationLinear, Vertical Admitted Power1 W Connectoripex PhysicalProperties Antenna MaterialFPC Cable TypeO.D.1.13mm // 125 mm Operating Temp. -10 ~ +60 ̊C Storage Temp.-10 ~ +70 ̊C Sample Photo A. Electrical Characteristics Frequency 2400~2500MHz S.W.R.<= 2.0 4900~5900MHz Gai n (Peak)8dBi S Parameter Test AgilentE5071C G ainTest Antenna Radi ation Pattern VS Gain 0

Report No. ENS2603180142W00401R Page 1 of 75 Ver.1.0 $印章$ TEST REPORT Product Name : Digital Signage Model Number : BAA5522A-BB-45P, B*A5522A-**-***(*can be 0-9 or A- Z) FCC ID : 2BVD4-BAA5522A Prepared for : GEEPHON INTELLIGENCE TECHNOLOGY CO., LTD. Address : Room 401, Building A, Qiaode Science and Technology Park, No. 7, Guangming High tech Park West District, Tianliao Community, Yutang Street, Guangming District, Shenzhen Prepared by : EMTEK (SHENZHEN) CO., LTD. Address : Building 69, Majialong Industry Zone,Nanshan District, Shenzhen, Guangdong, China Tel: (0755) 26954280 Fax: (0755) 26954282 Report Number : ENS2603180142W00401R Date(s) of Tests : March 19, 2026 to April 7, 2026 Date of issue : April 7, 2026 $二维码$ Report No. ENS2603180142W00401R Page 2 of 75 Ver.1.0 TABLE OF CONTENTS 1 TEST RESULT CERTIFICATION ........................................................................................................ 3 2 EUT TECHNICAL DESCRIPTION ...................................................................................................... 5 3 SUMMARY OF TEST RESULT ........................................................................................................... 6 4 TEST METHODOLOGY ...................................................................................................................... 7 4.1 GENERAL DESCRIPTION OF APPLIED STANDARDS .............................................................. 7 4.2 MEASUREMENT EQUIPMENT USED ........................................................................................ 7 4.3 DESCRIPTION OF TEST MODES ............................................................................................... 8 5 FACILITIES AND ACCREDITATIONS ................................................................................................ 9 5.1 FACILITIES .................................................................................................................................. 9 5.2 EQUIPMENT ................................................................................................................................ 9 5.3 LABORATORY ACCREDITATIONS AND LISTINGS ................................................................... 9 6 TEST SYSTEM UNCERTAINTY ....................................................................................................... 10 7 SETUP OF EQUIPMENT UNDER TEST ........................................................................................... 11 7.1 RADIO FREQUENCY TEST SETUP 1 ........................................................................................ 11 7.2 RADIO FREQUENCY TEST SETUP 2 ........................................................................................ 11 7.3 CONDUCTED EMISSION TEST SETUP ................................................................................... 14 7.4 BLOCK DIAGRAM CONFIGURATION OF TEST SYSTEM ....................................................... 15 7.5 SUPPORT EQUIPMENT ............................................................................................................ 15 8 TEST REQUIREMENTS.................................................................................................................... 16 8.1 DTS 6DB BANDWIDTH .............................................................................................................. 16 8.2 DTS 99%BANDWIDTH .............................................................................................................. 22 8.3 MAXIMUM PEAK CONDUCTED OUTPUT POWER ................................................................. 28 8.4 MAXIMUM POWER SPECTRAL DENSITY ............................................................................... 34 8.5 UNWANTED EMISSIONS IN NON-RESTRICTED FREQUENCY BANDS ............................... 40 8.6 RADIATED SPURIOUS EMISSION ........................................................................................... 58 8.7 CONDUCTED EMISSION TEST ................................................................................................ 70 8.8 ANTENNA APPLICATION .......................................................................................................... 73 9 APPENDIX PHOTOGRAPHS OF EUT ............................................................................................. 74 10 APPENDIX PHOTOGRAPHS OF TEST SETUP .............................................................................. 75 Report No. ENS2603180142W00401R Page 3 of 75 Ver.1.0 1 TEST RESULT CERTIFICATION Applicant : GEEPHON INTELLIGENCE TECHNOLOGY CO., LTD. Address : Room 401, Building A, Qiaode Science and Technology Park, No. 7, Guangming High tech Park West District, Tianliao Community, Yutang Street, Guangming District, Shenzhen Manufacturer : GEEPHON INTELLIGENCE TECHNOLOGY CO., LTD. Address : Room 401, Building A, Qiaode Science and Technology Park, No. 7, Guangming High tech Park West District, Tianliao Community, Yutang Street, Guangming District, Shenzhen EUT : Digital Signage Model Name : BAA5522A-BB-45P, B*A5522A-**-***(*can be 0-9 or A- Z) Trademark : GEEPHON Measurement Procedure Used: APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 2, Subpart J FCC 47 CFR Part 15, Subpart C PASS IC RSS-GEN, Issue 5(04-2018)+A1(03-2019)+A2(02-2021) IC RSS-247 Issue 3(08-2017) PASS The above equipment was tested by EMTEK(SHENZHEN) CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10 (2020) and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 2, Part 15.247, IC RSS-247 Issue 3 and IC RSS-GEN, Issue 5. The test results of this report relate only to the tested sample identified in this report. Date of Test : March 19, 2026 to April 7, 2026 Prepared by : Cai Zefeng /Editor Reviewer : Xia Lilu /Supervisor Approve & Authoriz…

Text truncated - open the document above for the full version.

Report No. ENS2603180142W00401R Page 48 of 75 Ver.1.0 11B-Ant1-2462-0~Reference-PASS 11B-Ant1-2462-30~1000-PASS 11B-Ant1-2462-1000~26500-PASS Report No. ENS2603180142W00401R Page 49 of 75 Ver.1.0 11G-Ant1-2412-0~Reference-PASS 11G-Ant1-2412-30~1000-PASS 11G-Ant1-2412-1000~26500-PASS Report No. ENS2603180142W00401R Page 50 of 75 Ver.1.0 11G-Ant1-2437-0~Reference-PASS 11G-Ant1-2437-30~1000-PASS 11G-Ant1-2437-1000~26500-PASS Report No. ENS2603180142W00401R Page 51 of 75 Ver.1.0 11G-Ant1-2462-0~Reference-PASS 11G-Ant1-2462-30~1000-PASS 11G-Ant1-2462-1000~26500-PASS Report No. ENS2603180142W00401R Page 52 of 75 Ver.1.0 11N20SISO-Ant1-2412-0~Reference-PASS 11N20SISO-Ant1-2412-30~1000-PASS 11N20SISO-Ant1-2412-1000~26500-PASS Report No. ENS2603180142W00401R Page 53 of 75 Ver.1.0 11N20SISO-Ant1-2437-0~Reference-PASS 11N20SISO-Ant1-2437-30~1000-PASS 11N20SISO-Ant1-2437-1000~26500-PASS Report No. ENS2603180142W00401R Page 54 of 75 Ver.1.0 11N20SISO-Ant1-2462-0~Reference-PASS 11N20SISO-Ant1-2462-30~1000-PASS 11N20SISO-Ant1-2462-1000~26500-PASS Report No. ENS2603180142W00401R Page 55 of 75 Ver.1.0 11N40SISO-Ant1-2422-0~Reference-PASS 11N40SISO-Ant1-2422-30~1000-PASS 11N40SISO-Ant1-2422-1000~26500-PASS Report No. ENS2603180142W00401R Page 56 of 75 Ver.1.0 11N40SISO-Ant1-2437-0~Reference-PASS 11N40SISO-Ant1-2437-30~1000-PASS 11N40SISO-Ant1-2437-1000~26500-PASS Report No. ENS2603180142W00401R Page 57 of 75 Ver.1.0 11N40SISO-Ant1-2452-0~Reference-PASS 11N40SISO-Ant1-2452-30~1000-PASS 11N40SISO-Ant1-2452-1000~26500-PASS Report No. ENS2603180142W00401R Page 58 of 75 Ver.1.0 8.6 RADIATED SPURIOUS EMISSION 8.6.1 Applicable Standard According to FCC Part 15.247(d),15.205, 15.209 and KDB 558074 D01 15.247 Meas Guidancev05r02 According to IC RSS-Gen and RSS-247 8.6.2 Conformance Limit According to FCC Part 15.247(d): radiated emissions which fall in the restricted bands, as defined in §15.205(a), must also comply with the radiated emission limits specified in §15.209(a) (see §15.205(c)). According to FCC Part15.205, Restricted bands MHz MHz MHz GHz 0.090-0.110 16.42-16.423 399.9-410 4.5-5.15 10.495-0.505 16.69475-16.69525 608-614 5.35-5.46 2.1735-2.1905 16.80425-16.80475 960-1240 7.25-7.75 4.125-4.128 25.5-25.67 1300-1427 8.025-8.5 4.17725-4.17775 37.5-38.25 1435-1626.5 9.0-9.2 4.20725-4.20775 73-74.6 1645.5-1646.5 9.3-9.5 6.215-6.218 74.8-75.2 1660-1710 10.6-12.7 6.26775-6.26825 123-138 2200-2300 14.47-14.5 8.291-8.294 149.9-150.05 2310-2390 15.35-16.2 8.362-8.366 156.52475-156.52525 2483.5-2500 17.7-21.4 8.37625-8.38675 156.7-156.9 2690-2900 22.01-23.12 8.41425-8.41475 162.0125-167.17 3260-3267 23.6-24.0 12.29-12.293 167.72-173.2 3332-3339 31.2-31.8 12.51975-12.52025 240-285 3345.8-3358 36.43-36.5 12.57675-12.57725 322-335.4 3600-4400 (2) 13.36-13.41 According toFCC Part15.205the level of any transmitter spurious emission in Restricted bands shall not exceed the level of the emission specified in the following table Restricted Frequency(MHz) Field Strength (μV/m) Field Strength (dBμV/m) Measurement Distance 0.009-0.490 2400/F(KHz) 20 log (uV/m) 300 0.490-1.705 24000/F(KHz) 20 log (uV/m) 30 1.705-30 30 29.5 30 30-88 100 40 3 88-216 150 43.5 3 216-960 200 46 3 Above 960 500 54 3 8.6.3 Test Configuration Test according to clause 6.2 radio frequency test setup 8.6.4 Test Procedure This test is required for any spurious emission that falls in a Restricted Band, as defined in Section 15.205. It must be performed with the highest gain of each type of antenna proposed for use with the EUT. Use the following spectrum analyzer settings: For Above 1GHz: The EUT was placed on a turn table which is 1.5m above ground plane. Maximum procedure was performed on the highest emissions to ensure EUT compliance. Span = wide enough to fully capture the emission being measured RBW = 1 MHz VBW  RBW Sweep = auto Detector function = peak Trace = max hold Report No. ENS2603180142W00401R Page 59 of 75 Ver.1.0 For Below 1GHz: The EUT was placed on a turn table which is 0.8m above ground plane. Maximum procedure was performed on the highest emissions to ensure EUT compliance. Span = wide enough to fully capture the emission being measured RBW = 100 kHz for VBW  RBW Sweep = auto Detector function = peak Trace = max hold For Below 30MHz: The EUT was placed on a turn table which is 0.8m above ground plane. Maximum procedure was performed on the highest emissions to ensure EUT compliance. Span = wide enough to fully capture the emission being measured RBW = 9kHz VBW  RBW Sweep = auto Detector function = peak Trace = max hold For Below 150KHz: The EUT was placed on a turn table which is 0.8m above ground plane. Maximum procedure was performed on the highest emissions to ensure EUT compliance. Span = wide enough to fully capture the emission being measured RBW = 200Hz VBW  RBW Sweep = auto Detector function = peak Trace = max hold Follow the guidelines in ANSI C63.10 with respect to maximizing the emission by rotating the EUT, measuring the emission while the EUT is situated in three orthogonal planes (if appropriate), adjusting the measurement antenna height and polarization, etc. A pre-amp and a high pass filter are required for this test, in order to provide the measuring system with sufficient sensitivity. Allow the trace to stabilize. The peak reading of the emission, after being corrected by the antenna factor, cable loss, pre-amp gain, etc., is the peak field strength, which must comply with the limit. Submit this data. Now set the VBW to 10 Hz, while maintaining all of the other instrument settings. This peak level, once corrected, must comply with the limit. If the dwell time per channel of the hopping signal is less than 100 ms, then the reading obtained with the 10 Hz VBW may be further adjusted by a “duty cycle correction factor”, derived from 20log(dwell time/100 ms), in an effort to demonstrate compliance with the limit. Submit this data. Repeat above procedures until all frequency measured was complete. 8.6.5 Test Results Tem…

Text truncated - open the document above for the full version.

Report No. Page 1 of 2 Ver.1.0 TEST SETUP PHOTOGRAPHS 1.1. Photos of Conducted Emission Measurement Report No. Page 2 of 2 Ver.1.0 1.2. Photos of Radiation Emission Measurement
