2BVDR-M1SM5Laser Engraving Machine

Note: The images are for reference only, the actual product shall prevail. Product Manual L1 Pro 24W A Letter to Customers Dear Customer， To ensure smooth assembly and use, we have prepared this assembly and operation guide manual. Please read the following content carefully and follow the instructions to ensure safety and convenience during use. If you encounter any issues, you can scan the WIKI QR code or visit the company website to access relevant tutorial videos. If the machine malfunctions, please refer to the names of the corresponding components and inform us of the problem and machine condition via the after-sales email provided on this page. After-sales email:[email protected] Official website：https://laservii.com/ Wiki:https://wiki.laservii.com/en/home Inquiry email: [email protected] Facebook Official websiteWiki Facebook: https://www.facebook.com/profile.php?id=61584424918207 Table of Contents 1.Safety Instructions 2.Component Introduction 3.Accessories List 4.Unboxing Guide 5.Machine Assembly 6.Machine Calibration 7.Machine Testing 8.APP Introduction 9.Regular Maintenance 10.Product Parameters Safety Instructions 1.Always wear specialized protective glasses matched to the laser type (e.g., 1064nm for fiber lasers). Do not operate the machine without protection. 2.Strictly prohibit engraving PVC, foam, or chlorine-containing materials, as they produce highly toxic gases. Test unknown materials with an 1×1cm sample first. 3.Place the device on a stable surface with a load-bearing capacity ≥3 times the device weight. Leave ≥20cm of ventilation space around it, away from children’s reach. 4.Turn on desktop ventilation or an external fan during engraving. For wood or leather processing, use an activated carbon filter box to reduce odors and dust. 5.Before powering on, check that the power cord is undamaged, USB connections are secure, and the device is properly grounded. Avoid touching power ports with wet hands. 6.Do not leave the station during operation. Press the emergency stop button for temporary pauses. Avoid touching the laser head’s path or high-temperature workpieces. 7.Keep a small dry powder fire extinguisher in the work area. When engraving flammable materials (e.g., cardboard), reduce power and shorten processing time. 8.Regularly clean lenses with anhydrous ethanol, wiping in one direction to avoid scratches. Always disconnect power before cleaning. 9.Do not operate after drinking, fatigue, or taking drowsiness-inducing medication. Do not remove safety covers for convenience. 10.In case of fire, cut power immediately and use the extinguisher. For laser eye burns, rinse with water and seek medical attention promptly. Component Introduction 1 3 5 6 7 8 2 12345678 Y-axis left slider Y-axis motor Optical shaft Y-axis limitRear frameX-axis slider Laser module Y-axis right slider 4 Component Introduction 1 3 4 5 6 7 2 1234567 Y-axis limit trigger Front frame Belt tensionin g piece Y-axis profile X-axis limit X-axis profile X-axis motor Component Introduction 1 3 4 5 2 12345 DC socketSilicone light guide column Power button Type-C interface TF card slot Y-axis right part X1 Y-axis left part X1 X-axis module X1 Front Frame X1 Rear Frame X1 Optical Axis Module X1 Screw M5*12 X4 Self-tapping screw M3*10 X2 Accessories List TF Card X1 Laser module 24W X1 12V 3A/5A Adapter X1 data line X1 Wrench Set X1 Accessory List Housing X1 Screw M3*8 X8 1. Front and Rear Frame Assembly Required materials: Y-axis left part X1, Y-axis right part X1, front frame X1, rear frame X1, Screw M5*12 X4. Insert the front and rear frames into the slots of the Y-axis left and right parts. Pass the M5 * 12 screws through the frames and tighten them onto the profiles. Note: The Y-axis left part includes the motor. 2. X-axis Component Assembly Required materials: X-axis component X1. Align the X-axis front plate with the front frame and press the X-axis component onto the Y-axis left and right parts from top to bottom. Note: Confirm the direction of the X- axis slider before pressing down. Machine Assembly 3. Optical Shaft Component Installation Required materials: Optical shaft component X1. Pass the optical shaft component through the hole under the X-axis slider and insert it into the coupling on the Y-axis left part. Tighten the two set screws on the coupling. Loosen the set screws on the coupling at the other end, push it to the right against the synchronous pulley, and tighten the four set screws on the coupling. Machine Assembly Enlarge image1 Enlarge image2 Enlarge image3Enlarge image4 4. Laser Module Installation 5. Harness Mylar Sheet Assembly Required materials: Laser module 7W/12W X1. Required materials: Self-tapping screw M3 * 10 X2. Insert the laser module into the X-axis slider from top to bottom, then tighten the hand-tightened screw from the side. Use two M3 self-tapping screws to pass through the Mylar sheet on the harness and tighten it onto the Y-axis left part. Machine Assembly Note: If the laser module is low, only tighten the bottom hand-tightened screw. 6. Wiring X motor wire Machine Assembly Y motor wire X limit line Y limit line Connect the wires from the motherboard harness to the corresponding positions on the machine as shown. Laser head wire 7. Housing Installation 8. Housing Wiring Required materials: Housing X1 Base Plate X1 Screws M3*8 X8 Place the housing over the machine from the top, then secure it to the housing by passing the M3*8 screws through the base plate from underneath. As shown in the figure, use the cables to connect the DC ports and Type-C ports of the main board and the housing respectively. Connect the emergency stop switch cable to the wiring port of the main board. Machine Assembly Required materials: Type-C Cable X1 DC Cable X1 Type-C Cable DC Cable emergency stop switch cable 1. Eccentric Nut Adjustment Machine Calibration Check if the POM wheels on the Y-axis left/right parts and X-axis slider match the profiles and move smoothly without jam…
