FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: · Reorient or relocate the receiving antenna. · Increase the separation between the equipment and receiver. · Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. · Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifi cations to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

FCC ID:2BVJT-HY300PRO www.cotecna-toby.com TB-RF-073-3.1 Appendix III EUT External Photographs Photo 1 Appearance of EUT Photo 2 Appearance of EUT FCC ID:2BVJT-HY300PRO www.cotecna-toby.com TB-RF-073-3.1 Photo 3 Appearance of EUT Photo 4 Appearance of EUT FCC ID:2BVJT-HY300PRO www.cotecna-toby.com TB-RF-073-3.1 Photo 5 Appearance of EUT Photo 6 Appearance of EUT

FCC ID:2BVJT-HY300PRO www.cotecna-toby.com TB-RF-073-3.1 Appendix I Label Appendix II Label Location FCC ID:2BVJT-HY300PRO Model: HY300 Pro

FCC ID:2BVJT-HY300PRO www.cotecna-toby.com TB-RF-073-3.1 Appendix IV EUT Internal Photographs Photo 7 Internal of EUT Photo 8 Appearance of PCB FCC ID:2BVJT-HY300PRO www.cotecna-toby.com TB-RF-073-3.1 Photo 9 Appearance of PCB Photo 10 Appearance of PCB FCC ID:2BVJT-HY300PRO www.cotecna-toby.com TB-RF-073-3.1 Photo 11 Appearance of PCB Photo 12 Appearance of PCB BLE&WIFI Ant

Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202603-0411-4 Page: 1 of 8 TB-RF-073-3.1 1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China Tel: +86 75526509301 Email: [email protected] www.cotecna-toby.com Maximum Permissible Exposure Evaluation FCC ID: 2BVJT-HY300PRO Report No. : TBR-C-202603-0411-4 Applicant : Shenzhen Zhengdaxin E-commerce Co., Ltd. Equipment Under Test (EUT) EUT Name : Projector Model No. : HY300 Pro Series Model No. : HY300,YK300,Ultra300,Z10,P8 Brand Name : ZRZTM Sample ID : HC-C-202603-0411-01-01 Receipt Date : 2026-03-26 Test Date : 2026-03-26 to 2026-04-14 Issue Date : 2026-04-14 Standards : FCC Part 2.1091 Test Method : KDB 447498 D01 General RF Exposure Guidance v06 Conclusions : PASS In the configuration tested, the EUT complied with the standards specified above. Test By : Kael Li Reviewed By : Henry huang Approved By : Ivan Su This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in the report. Report No.: TBR-C-202603-0411-4 Page: 2 of 8 www.cotecna-toby.com TB-RF-073-3.1 CONTENTS CONTENTS ............................................................................................................................................. 2 1. GENERAL INFORMATION ABOUT EUT.............................................................................. 4 1.1 Client Information ................................................................................................................. 4 1.2 General Description of EUT (Equipment Under Test) ................................................... 4 2. MEASUREMENT UNCERTAINTY .......................................................................................... 5 3. TEST FACILITY.......................................................................................................................... 6 4. METHOD OF MEASUREMENT FOR FCC............................................................................ 7 5. TEST RESULT............................................................................................................................ 8 Report No.: TBR-C-202603-0411-4 Page: 3 of 8 www.cotecna-toby.com TB-RF-073-3.1 Revision History Report No. Version Description Issued Date TBR-C-202603-0411-4 Rev.01 Initial issue of report 2026-04-14 Report No.: TBR-C-202603-0411-4 Page: 4 of 8 www.cotecna-toby.com TB-RF-073-3.1 1. General Information about EUT 1.1 Client Information Applicant : Shenzhen Zhengdaxin E-commerce Co., Ltd. Address : Room 125, Building A, No. 30 Sanwei Aviation Road, Sanwei Community, Hangcheng Subdistrict, Bao'an District, Shenzhen, China Manufacturer : Shenzhen Zhengdaxin E-commerce Co., Ltd. Address : Room 125, Building A, No. 30 Sanwei Aviation Road, Sanwei Community, Hangcheng Subdistrict, Bao'an District, Shenzhen, China 1.2 General Description of EUT (Equipment Under Test) EUT Name : Projector Models No. : HY300 Pro, HY300,YK300,Ultra300,Z10,P8 Model Different : All these models are exactly the same in terms of the same printed circuit board, layout and electrical circuits. The difference lies in the different appearance colors. Product Description : Operation Frequency: Bluetooth LE: 2402MHz~2480MHz 2.4G Wi-Fi: 2412MHz~2462MHz Modulation Type: Bluetooth LE: GFSK 802.11b: DSSS (DQPSK, DBPSK, CCK) 802.11g: OFDM (BPSK, QPSK,16QAM, 64QAM) 802.11n: OFDM (QPSK, BPSK, 16QAM, 64QAM) Antenna Gain: 2.95dBi Chip Antenna Power Rating : Input: AC100-240V~, 50/60Hz 1A Software Version : N/A Hardware Version : N/A Remark: The above antenna information is declared by manufacturer and for more detailed features description, please refer to the manufacturer's specifications, the laboratory shall not be held responsible. Report No.: TBR-C-202603-0411-4 Page: 5 of 8 www.cotecna-toby.com TB-RF-073-3.1 2. Measurement Uncertainty The reported uncertainty of measurement y±U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %. Test Item Parameters Expanded Uncertainty (ULab) Conducted Emission Level Accuracy: 9kHz~150kHz 150kHz to 30MHz ±3.50 dB ±3.10 dB Radiated Emission Level Accuracy: 9kHz to 30 MHz ±4.60 dB Radiated Emission Level Accuracy: 30MHz to 1000 MHz ±4.50 dB Radiated Emission Level Accuracy: Above 1000MHz ±4.20 dB Temperature / ±0.6°C Humidity / ±4% Supply voltages / ±2% Time / ±4% Report No.: TBR-C-202603-0411-4 Page: 6 of 8 www.cotecna-toby.com TB-RF-073-3.1 3. Test Facility The testing report were performed by the Shenzhen Toby Technology Co., Ltd., in their facilities located at 1/F., Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. At the time of testing, the following bodies accredited the Laboratory: CNAS (L5813) The Laboratory has been accredited by CNAS to ISO/IEC 17025: 2017 General Requirements for the Competence of Testing and Calibration Laboratories for the competence in the field of testing. And the Registration No.: CNAS L5813. A2LA Certificate No.: 4750.01 The laboratory has been accredited by American Association for Laboratory Accreditation(A2LA) to ISO/IEC 17025：2017 General Requirements for the Competence of Testing and Calibration Laboratories for the technical competence in the field of Electrical Testing. And the A2LA Certificate No.: 4750.01.FCC Accredited Test Site Number: 854351. Designation Number: CN1223. IC Registration No.: (11950A) The Laboratory has been registered by Certification and Engineering Bureau of Industry Canada for radio equipment testing. The site registration: Site# 11950A. CAB identifier: CN0056. Report No.: TBR-C-202603-0411-4 Page: 7 of 8 www.cotecna-toby.com TB-RF-073-3.1 4. Method of Measurement f…

Text truncated - open the document above for the full version.

1/1 ONEWAVETECHNOLOGYCO.,LTD. 1 P/N: WAN127030JD251SN03 7030 Chip antenna For WLAN Dual-Band Applications Dimension (mm) L 7.00 ± 0.20 W 3.00 ± 0.20 T 1.15 ± 0.20 1F, No. 151, Ligong Street, Beitou District, Taipei City, Taiwan ONEWAVE TECHNOLOGY CO., LTD. 2/11 Part Number Information WAN 12 7030 J D25 1S N 03 A G B C D H E F A Product Series Antenna B Dimension L x W 7.0X3.0mm (+-0.2mm) C Material High K material D Working Frequency 2.4~2.5GHz E Feeding mode Monopole & Single Feeding F Antenna type Type = 03 G、H Internal Code 1. Electrical Specification Specification Part Number WAN127030JD251SN03 Central Frequency 2450/ 2500MHz Bandwidth 100 / 800 (Min.) MHz Return Loss -10 (Max) dB Peak Gain 2.95 / 5.40 dBi Impedance 50 Ohm Operating Temperature -40～+110 °C Maximum Power 4 W Resistance to Soldering Heats 10 ( @ 260°C) sec. Polarization Linear Azimuth Beamwidth Omni-directional Termination Cu / Sn (Leadless) Remark : Bandwidth & Peak Gain was measured under evaluation board of next page ONEWAVE TECHNOLOGY CO., LTD. 3/11 2. Recommended PCB Pattern Evaluation Board Dimension Unit : mm Suggested Matching Circuit 重要資訊 : 匹配元件建議使用精準度高的電感±0.1~0.3nH、電容±0.1pF ONEWAVE TECHNOLOGY CO., LTD. 4/11 Matching circuit 50 ohm transmission Line  Layout Dimensions in Clearance area( Size=27.0*7.0mm) FootPrint (Unit : mm) ONEWAVE TECHNOLOGY CO., LTD. 6/11 Radiation Pattern X Y Z Efficiency Peak Gain Directivity 2400MHz 70.69 % 2.83 dBi 4.33 dBi 2450MHz 72.86 % 2.95 dBi 4.32 dBi 2500MHz 71.46 % 2.89 dBi 4.34 dBi ONEWAVE TECHNOLOGY CO., LTD. 7/11 Chamber Coordinate System ONEWAVE TECHNOLOGY CO., LTD. 8/11 4. Reliability and Test Condictions ITEM REQUIREMENTS TEST CONDITION Solderability 1. Wetting shall exceed 90% coverage 2. No visible mechanical damage TEMP (°C) 230°C 4±1 sec. 150°C 60sec Pre-heating temperature:150°C/60sec. Solder temperature:230±5°C Duration:4±1sec. Solder:Sn-Ag3.0-Cu0.5 Flux for lead free: rosin Solder heat Resistance 1. No visible mechanical damage 2. Central Freq. change :within ± 6% TEMP (°C) 260°C 10±0.5 sec. 150°C 60sec Pre-heating temperature:150°C/60sec. Solder temperature:260±5°C Duration:10±0.5sec. Solder:Sn-Ag3.0-Cu0.5 Flux for lead free: rosin Component Adhesion (Push test) 1. No visible mechanical damage The device should be reflow soldered(230±5°C for 10sec.) to a tinned copper substrate A dynometer force gauge should be applied the side of the component. The device must with-ST-F 0.5 Kg without failure of the termination attached to component. Component Adhesion (Pull test) 1. No visible mechanical damage Insert 10cm wire into the remaining open eye bend ,the ends of even wire lengths upward and wind together. Terminal shall not be remarkably damaged. Thermal shock 1. No visible mechanical damage 2. Central Freq. change :within ±6% +110°C=>30±3min -40°C=>30±3min Test cycle:10 cycles The chip shall be stabilized at normal condition for 2~3 hours before measuring. Resistance to High Temperature 1. No visible mechanical damage 2. Central Freq. change :within ±6% 3. No disconnection or short circuit. Temperature: +110±5°C Duration: 1000±12hrs The chip shall be stabilized at normal condition for 2~3 hours before measuring. Resistance to Low Temperature 1. No visible mechanical damage 2. Central Freq. change :within ±6% 3. No disconnection or short circuit. Temperature:-40±5°C Duration: 1000±12hrs The chip shall be stabilized at normal condition for 2~3 hours before measuring. Humidity 1. No visible mechanical damage 2. Central Freq. change :within ±6% 3. No disconnection or short circuit. Temperature: 40±2°C Humidity: 90% to 95% RH Duration: 1000±12hrs The chip shall be stabilized at normal condition for 2~3 hours before measuring. Phase Temperature(°C) Time(min) 1 +110±5°C 30±3 2 Room Temperature Within 3sec 3 -40±2°C 30±3 4 Room Temperature Within 3sec ONEWAVE TECHNOLOGY CO., LTD. 9/11 PRE-HEATING 250~260 230 SOLDERING NATURAL COOLING 10s max. 180 150 60~120 s 30~60s 5. Soldering and Mounting Mildly activated rosin fluxes are preferred. The minimum amount of solder can lead to damage from the stresses caused by the difference in coefficients of expansion between solder, chip and substrate. The terminations are suitable for all wave and re-flow soldering systems. If hand soldering cannot be avoided, the preferred technique is the utilization of hot air soldering tools. Reflow Soldering TIME(sec.) Recommended temperature profiles for re-flow soldering in Figure 1. Products attachment with a soldering iron is discouraged due to the inherent process control limitations. In the event that a soldering iron must be employed the following precautions are recommended. ‧Preheat circuit and products to 150°C ‧Never contact the ceramic with the iron tip ‧Use a 20 watt soldering iron with tip diameter of 1.0mm ‧280°C tip temperature (max) ‧1.0mm tip diameter (max) ‧Limit soldering time to 3 sec. 300 Iron Soldering PRE-HEATING SOLDERING NATURAL COOLING within 3s 350 150 Over 60s Gradual cooling TIME(sec.) TEMPERATURE(° C) TEMPERATURE(° C) ONEWAVE TECHNOLOGY CO., LTD. 10/11 6. Packaging Information  Tape Specification: Reel Specification: (7’’, Φ180 mm) Tape Width(mm) A(mm) B(mm) C(mm) D(mm) Chip/Reel(pcs) 16 16±1.0 60±2 13.5±0.5 178±2 3000 ONEWAVE TECHNOLOGY CO., LTD. 11/11 7. Storage and Transportation Information Storage Conditions To maintain the solderability of terminal electrodes: 1. Temperature and humidity conditions: -10~ 40°C and 30~70% RH. 2. Recommended products should be used within 6 months from the time of delivery. 3. The packaging material should be kept where no chlorine or sulfur exists in the air. Transportation Conditions 1. Products should be handled with care to avoid damage or contamination from perspiration and skin oils. 2. The use of tweezers or vacuum pick up is strongly recommended for individual components. 3. Bulk handling should ensure that abrasion and mechanical shock are minimized.

Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0411-3 Page: 1 of 39 FCC ID: 2BVJT-HY300PRO TB-RF-073-3.1 RF Test Data for Bluetooth LE (Conducted Measurements) General Description of EUT Product Name: Projector Test Model: HY300 Pro Sample ID: HC-C-202603-0411-01-01 Environmental Conditions Temperature: 25.6°C Relative Humidity: 48.2% Test Voltage: AC 120V Test Engineer: Kael Li Note: For a more detailed features description, please refer to the report TBR-C-202603-0411-3 The report only show the worst case data. Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0411-3 Page: 2 of 39 FCC ID: 2BVJT-HY300PRO TB-RF-073-3.1 Contents 1. Duty Cycle ..................................................................................................................................................................................... 3 2. Maximum Conducted Output Power ............................................................................................................................................ 7 3. -6dB Bandwidth ........................................................................................................................................................................... 11 4. Occupied Channel Bandwidth .................................................................................................................................................... 15 5. Maximum Power Spectral Density Level ................................................................................................................................... 19 6. Band Edge ................................................................................................................................................................................... 23 7. Conducted RF Spurious Emission ............................................................................................................................................. 28 8. Restrict Band ............................................................................................................................................................................... 35 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0411-3 Page: 3 of 39 FCC ID: 2BVJT-HY300PRO TB-RF-073-3.1 1. Duty Cycle Condition Mode Frequency (MHz) Antenna Duty Cycle (%) Correction Factor (dB) 1/T (kHz) NVNT BLE 1Mbps 2402 Ant1 61.44 2.12 2.6 NVNT BLE 1Mbps 2440 Ant1 61.28 2.13 2.61 NVNT BLE 1Mbps 2480 Ant1 61.28 2.13 2.61 NVNT BLE 2Mbps 2402 Ant1 32.32 4.91 4.95 NVNT BLE 2Mbps 2440 Ant1 32.32 4.91 4.95 NVNT BLE 2Mbps 2480 Ant1 32.16 4.93 4.98 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0411-3 Page: 4 of 39 FCC ID: 2BVJT-HY300PRO TB-RF-073-3.1 Test Graphs Duty Cycle NVNT BLE 1Mbps 2402MHz Ant1 Duty Cycle NVNT BLE 1Mbps 2440MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0411-3 Page: 5 of 39 FCC ID: 2BVJT-HY300PRO TB-RF-073-3.1 Duty Cycle NVNT BLE 1Mbps 2480MHz Ant1 Duty Cycle NVNT BLE 2Mbps 2402MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0411-3 Page: 6 of 39 FCC ID: 2BVJT-HY300PRO TB-RF-073-3.1 Duty Cycle NVNT BLE 2Mbps 2440MHz Ant1 Duty Cycle NVNT BLE 2Mbps 2480MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0411-3 Page: 7 of 39 FCC ID: 2BVJT-HY300PRO TB-RF-073-3.1 2. Maximum Conducted Output Power Condition Mode Frequency (MHz) Antenna Total Power (dBm) Limit (dBm) Verdict NVNT BLE 1Mbps 2402 Ant1 3.844 30 Pass NVNT BLE 1Mbps 2440 Ant1 3.215 30 Pass NVNT BLE 1Mbps 2480 Ant1 2.752 30 Pass NVNT BLE 2Mbps 2402 Ant1 4.148 30 Pass NVNT BLE 2Mbps 2440 Ant1 3.704 30 Pass NVNT BLE 2Mbps 2480 Ant1 3.15 30 Pass Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0411-3 Page: 8 of 39 FCC ID: 2BVJT-HY300PRO TB-RF-073-3.1 Test Graphs Power NVNT BLE 1Mbps 2402MHz Ant1 Power NVNT BLE 1Mbps 2440MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0411-3 Page: 9 of 39 FCC ID: 2BVJT-HY300PRO TB-RF-073-3.1 Power NVNT BLE 1Mbps 2480MHz Ant1 Power NVNT BLE 2Mbps 2402MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0411-3 Page: 10 of 39 FCC ID: 2BVJT-HY300PRO TB-RF-073-3.1 Power NVNT BLE 2Mbps 2440MHz Ant1 Power NVNT BLE 2Mbps 2480MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0411-3 Page: 11 of 39 FCC ID: 2BVJT-HY300PRO TB-RF-073-3.1 3. -6dB Bandwidth Condition Mode Frequency (MHz) Antenna -6 dB Band…

Text truncated - open the document above for the full version.

Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0411-31 Page: 1 of 63 FCC ID: 2BVJT-HY300PRO TB-RF-073-3.1 RF Test Data for 2.4G WiFi (Conducted Measurements) General Description of EUT Product Name: Projector Test Model: HY300 Pro Sample ID: HC-C-202603-0411-01-01 Environmental Conditions Temperature: 25.2°C Relative Humidity: 48.6% Test Voltage: AC 120V Test Engineer: Kael Li Note: For a more detailed features description, please refer to the report TBR-C-202603-0411-31 The report only show the worst case data. Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0411-31 Page: 2 of 63 FCC ID: 2BVJT-HY300PRO TB-RF-073-3.1 Contents 1. Duty Cycle ..................................................................................................................................................................................... 3 2. Maximum Conducted Output Power .......................................................................................................................................... 10 3. -6dB Bandwidth ........................................................................................................................................................................... 11 4. Occupied Channel Bandwidth .................................................................................................................................................... 18 5. Maximum Power Spectral Density Level ................................................................................................................................... 25 6. Band Edge ................................................................................................................................................................................... 32 7. Conducted RF Spurious Emission ............................................................................................................................................. 41 8. Restrict Band ............................................................................................................................................................................... 54 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0411-31 Page: 3 of 63 FCC ID: 2BVJT-HY300PRO TB-RF-073-3.1 1. Duty Cycle Condition Mode Frequency (MHz) Antenna Duty Cycle (%) Correction Factor (dB) 1/T (kHz) NVNT b 2412 Ant1 51.05 2.92 0.08 NVNT b 2437 Ant1 51.07 2.92 0.08 NVNT b 2462 Ant1 51.05 2.92 0.08 NVNT g 2412 Ant1 58.78 2.31 0.18 NVNT g 2437 Ant1 58.78 2.31 0.18 NVNT g 2462 Ant1 58.67 2.32 0.18 NVNT n(HT20) 2412 Ant1 57.6 2.4 0.19 NVNT n(HT20) 2437 Ant1 57.54 2.4 0.19 NVNT n(HT20) 2462 Ant1 57.49 2.4 0.19 NVNT n(HT40) 2422 Ant1 56.59 2.47 0.33 NVNT n(HT40) 2437 Ant1 56.61 2.47 0.33 NVNT n(HT40) 2452 Ant1 56.59 2.47 0.33 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0411-31 Page: 4 of 63 FCC ID: 2BVJT-HY300PRO TB-RF-073-3.1 Test Graphs Duty Cycle NVNT b 2412MHz Ant1 Duty Cycle NVNT b 2437MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0411-31 Page: 5 of 63 FCC ID: 2BVJT-HY300PRO TB-RF-073-3.1 Duty Cycle NVNT b 2462MHz Ant1 Duty Cycle NVNT g 2412MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0411-31 Page: 6 of 63 FCC ID: 2BVJT-HY300PRO TB-RF-073-3.1 Duty Cycle NVNT g 2437MHz Ant1 Duty Cycle NVNT g 2462MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0411-31 Page: 7 of 63 FCC ID: 2BVJT-HY300PRO TB-RF-073-3.1 Duty Cycle NVNT n(HT20) 2412MHz Ant1 Duty Cycle NVNT n(HT20) 2437MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0411-31 Page: 8 of 63 FCC ID: 2BVJT-HY300PRO TB-RF-073-3.1 Duty Cycle NVNT n(HT20) 2462MHz Ant1 Duty Cycle NVNT n(HT40) 2422MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0411-31 Page: 9 of 63 FCC ID: 2BVJT-HY300PRO TB-RF-073-3.1 Duty Cycle NVNT n(HT40) 2437MHz Ant1 Duty Cycle NVNT n(HT40) 2452MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0411-31 Page: 10 of 63 FCC ID: 2BVJT-HY300PRO TB-RF-073-3.1 2. Maximum Conducted Output Power Condition Mode Frequency (MHz) Antenna Conducted Power (dBm) Duty Factor (dB) Total Power (dBm) Limit (dBm) Verdict NVNT b 2412 Ant1 13.21 2.92 16.13 30 Pass NVNT b 2437 Ant1 13.27 2.92 16.19 30 Pass NVNT b 2462 Ant1 13.28 2.92 16.2 30 Pass NVNT g 2412 Ant1 10.68 2.31 12.99 30 Pass NVNT g 2437 Ant1 10.78 2.31 13.09 30 Pass NVNT g 2462 Ant1 10.57 2.32 12.89 30 Pass NVNT n(HT20) 2412 Ant1 10.62 2.4 13.02 30 Pass NVNT n(HT20) 2437 Ant1 10.7 2.4 13.1 30 Pass NVNT n(HT20) 2462 Ant1 10.5 2.4…

Text truncated - open the document above for the full version.

Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202603-0411-3 Page: 1 of 32 TB-RF-073-3.1 1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China Tel: +86 75526509301 Email: [email protected] www.cotecna-toby.com Radio Test Report FCC ID: 2BVJT-HY300PRO Report No. : TBR-C-202603-0411-3 Applicant : Shenzhen Zhengdaxin E-commerce Co., Ltd. Equipment Under Test (EUT) EUT Name : Projector Model No. : HY300 Pro Series Model No. : HY300,YK300,Ultra300,Z10,P8 Brand Name : ZRZTM Sample ID : HC-C-202603-0411-01-01&HC-C-202603-0411-02-01 Receipt Date : 2026-03-26 Test Date : 2026-03-26 to 2026-04-14 Issue Date : 2026-04-14 Standards : FCC Part 15 Subpart C 15.247 Test Method : ANSI C63.10: 2020 KDB 558074 D01 15.247 Meas Guidance v05r02 Conclusions : PASS In the configuration tested, the EUT complied with the standards specified above. Test By : Kael Li Reviewed By : Henry huang Approved By : Ivan Su This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in the report. Report No.: TBR-C-202603-0411-3 Page: 2 of 32 www.cotecna-toby.com TB-RF-073-3.1 Contents CONTENTS ............................................................................................................................................ 2 1. GENERAL INFORMATION ABOUT EUT ............................................................................. 5 1.1 Client Information ................................................................................................................ 5 1.2 General Description of EUT (Equipment Under Test) ................................................... 5 1.3 Block Diagram Showing the Configuration of System Tested ...................................... 6 1.4 Description of Support Units .............................................................................................. 7 1.5 Description of Test Mode ................................................................................................... 7 1.6 Description of Test Software Setting ................................................................................ 8 1.7 Measurement Uncertainty .................................................................................................. 9 1.8 Test Facility......................................................................................................................... 10 2. TEST SUMMARY..................................................................................................................... 11 3. TEST SOFTWARE .................................................................................................................. 11 4. TEST EQUIPMENT AND TEST SITE .................................................................................. 12 5. CONDUCTED EMISSION ...................................................................................................... 13 5.1 Test Standard and Limit ................................................................................................... 13 5.2 Test Setup.................................................................................…
