2BVJT-TX103AWDigital Photo Frame

Reference No.: WTX26X06164454W001 Page 1 of 12 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn ANNEX EXHIBIT 1 - PRODUCT LABELING Proposed FCC ID Label Format Specifications: The label shall be securely affixed to a permanently attached part of the device, in a location where it is visible or easily accessible to the user, and shall not be readily detachable. The label shall be sufficiently durable to remain fully legible and intact on the device in all normal conditions of use throughout the device’s expected lifetime. Proposed Label Location on EUT FCC ID Label Location

1. RF Exposure Requirements 1.1 General Information Client Information Applicant: Shenzhen Zhengdaxin E-commerce Co., Ltd. Address of applicant: Room 125, Building A, No. 30 Sanwei Aviation Road,Sanwei Community, Hangcheng Subdistrict, Bao'an District, Shenzhen, China Manufacturer: Shenzhen Yundacheng Technology Co., Ltd. Address of manufacturer: Room 401, Building 3, Honghengtai Industrial Park, Liantang Industrial City, Shangcun Community, Gongming Subdistrict, Guangming District, Shenzhen General Description of EUT: Product Name: Digital Photo Frame Trade Name: / Model No.: TX103AW Adding Model(s): / Rated Voltage: DC 5V Rated Current: 2A Rated Power: 10.0W Battery Capacity: / Power Adapter Model: GQ12-050200-ZU Input: AC 100-240 50/60Hz 0.4A Output: DC 5V,2.0A 10.0W FCC ID: 2BVJT-TX103AW Equipment Type: Fixed device Technical Characteristics of EUT: WiFi Support Standards: 802.11b, 802.11g, 802.11n-HT20 Frequency Range: 2412-2462MHz for 802.11b/g/n(HT20) RF Output Power: 13.98dBm (Conducted) Type of Modulation: CCK, OFDM, QPSK, BPSK, 16QAM, 64QAM Quantity of Channels: 11 for 802.11b/g/n(HT20) Channel Separation: 5MHz Type of Antenna: PCB Antenna Antenna Gain: -0.47dBi 1.2 RF Exposure Exemption According to §1.1307(b)(3) and KDB 447498 D04 Interim General RF Exposure Guidance v01, system operating under the provisions of this section shall be operating in a manner that the public is not exposed to radio frequency energy level in excess limit for maximum permissible exposure. Option A: FCC Rule Part 1.1307 (b)(3)(i)(A):The available maximum time-averaged power is no more than 1mW, regardless of separation distance. Option B: FCC Rule Part 1.1307 (b)(3)(i)(B): The available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold P th (mW) described in the following formula. P th is given by: Option C: FCC Rule Part 1.1307 (b)(3)(i)(C): The minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that frequency. R must be at least λ/2π, where λ is the free-space operating wavelength in meters. Single RF Sources Subject to Routine Environmental Evaluation RF Source frequency (MHz) Threshold ERP (watts) 0.3-1.34 1,920 R 2 1.34-30 3,450 R 2 /f 2 30-300 3.83 R 2 300-1,500 0.0128 R 2 f 1,500-100,000 19.2R 2 For Multiple RF sources: FCC Rule Part 1.1307(b)(3)(ii): (A) The available maximum time-averaged power of each source is no more than 1 mW and there is a separation distance of two centimeters between any portion of a radiating structure operating and the nearest portion of any other radiating structure in the same device, except if the sum of multiple sources is less than 1 mW during the time-averaging period, in which case they may be treated as a single source (separation is not required). (B) In the case of fixed RF sources operating in the same time-averaging period, or of multiple mobile or portable RF sources within a device operating in the same time averaging period, if the sum of the fractional contributions to the applicable thresholds is less than or equal to 1 as indicated in the following equation. 1.3 Calculated Result Radio Access Technology Prediction Frequency Output Power Antenna Gain Duty Cycle Tune-Up Time-Averaged Power ERP (MHz) (dBm) (dBi) (%) (dBm) (dBm) WiFi 2412 13.98 -0.47 100 14.00 11.38 Frequency Option Min. Distance Max. Power Exposure Limit Ratio Result (MHz) (cm) (dBm) (mW) (mW) Pass/Fail 2412 C 20.00 11.38 13.74 768.00 0.02 Pass Note: 1. Time-Averaged Power=Output Power * Duty Cycle; ERP= Time-Averaged Power+ Antenna gain-2.15dB 2. Option A, B and C refers as clause 1.2. 3. For option B, Max (time-averaged power, effective radiated power (ERP)) converts to Max. Power. For option C, ERP converts to Max. Power; 4. For option B, P th (mW) converts to Exposure Limit (mW); For option C, ERP (W) converts to Exposure Limit (mW). 5. Ratio= Tune-Up ERP (mW)/ Exposure Limit (mW) Mode for Simultaneous Multi-band Transmission: Radio Access Technology Ratio 1 Ratio 2 Simultaneous Ratio Limit Result Pass/Fail -- -- -- -- -- -- Result: Pass

Summary Antenna Specification ITEM ANT SPEC Model Name 2.4G ANT Center Frequency Horizontal Vertical 2400MHz 2450MHz 2500MHz 2400MHz 2450MHz 2500MHz -1.18 -0.73 -0.47 -5.09 -2.26 -1.73 MAX. Gain -0.47dBi Polarization Horizontal and Vertical Azimuth Beam Pattern Omni-directional Impedance 50 Ohm Antenna type PCB ANT Antenna manufacturer SHENZHEN XTS TECHNOLOGY CO . , LTD . Address Room 402, 4th Floor, Building B, Queshan Science and Technology Park, Queshan Second Village, Dalang Subdistrict, Longhua District, Shenzhen City Antenna Photo & Length (mm) Horizontal: 2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -40 Scale: 5/div Frequency (MHz) Gain(dBi) Max Min Avg 2400 -1.18172 -30.0801 -7.18716 2450 -0.735800 -36.5604 -7.48023 2500 -0.475381 -22.0315 -6.59127 Vertical: 2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -30 Scale: 5/div Frequency (MHz) Gain(dBi) Max Min Avg 2400 -5.0931 -22.1424 -12.4294 2450 -2.2642 -24.5837 -10.4702 2500 -1.7311 -29.5214 -9.20432

Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 1 of 76 TEST REPORT Reference No. ....................: WTX26X06164454W001 FCC ID ............................... .: 2BVJT-TX103AW Applicant .......................... .: Shenzhen Zhengdaxin E-commerce Co., Ltd. Address .............................: Room 125, Building A, No. 30 Sanwei Aviation Road,Sanwei Community, Hangcheng Subdistrict, Bao'an District, Shenzhen, China Manufacturer .....................: Shenzhen Yundacheng Technology Co., Ltd. Address ............................ .: Room 401, Building 3, Honghengtai Industrial Park, Liantang Industrial City, Shangcun Community, Gongming Subdistrict, Guangming District, Shenzhen Product Name .................. .: Digital Photo Frame Model No... ........................ .: TX103AW Standards ......................... .: FCC Part 15.247 Date of Receipt sample ... .: 2026-06-10 Date of Test....................... .: 2026-06-10 to 2026-07-12 Date of Issue .................... .: 2026-07-18 Test Report Form No. ...... . : WTX_Part 15_247W Test Result ........................ .: Pass Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of approver. Prepared By: Waltek Testing Group (Shenzhen) Co., Ltd. Address: 1/F., Room 101, Building 1, Hongwei Industrial Park, Liuxian 2nd Road, Block 70 Bao'an District, Shenzhen, Guangdong, China Tel.: +86-755-33663308 Fax.: +86-755-33663309 Email: [email protected] Tested by: Approved by: Dashan Chen/Project Engineer Jason Su/Manager Reference No.: WTX26X06164454W001 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 2 of 76 TABLE OF CONTENTS 1. GENERAL INFORMATION .................................................................................................................................... 4 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ......................................................................... 4 1.2 TEST STANDARDS ................................................................................................................................................. 5 1.3 TEST METHODOLOGY ........................................................................................................................................... 5 1.4 TEST FACILITY ...................................................................................................................................................... 5 1.5 EUT SETUP AND TEST MODE .............................................................................................................................. 6 1.6 MEASUREMENT UNCERTAINTY ............................................................................................................................. 7 1.7 TEST EQUIPMENT LIST AND DETAILS ................................................................................................................... 8 2. SUMMARY OF TEST RESULTS ......................................................................................................................... 12 3. ANTENNA REQUIREMENT ................................................................................................................................. 13 3.1 STANDARD APPLICABLE ..................................................................................................................................... 13 3.2 EVALUATION INFORMATION ................................................................................................................................ 13 4. POWER SPECTRAL DENSITY ........................................................................................................................... 14 4.1 STANDARD APPLICABLE ..................................................................................................................................... 14 4.2 TEST SETUP BLOCK DIAGRAM ........................................................................................................................... 14 4.3 TEST PROCEDURE .............................................................................................................................................. 14 4.4 SUMMARY OF TEST RESULTS/PLOTS ................................................................................................................. 14 5. DTS BANDWIDTH ................................................................................................................................................. 15 5.1 STANDARD APPLICABLE ..................................................................................................................................... 15 5.2 TEST SETUP BLOCK DIAGRAM ........................................................................................................................... 15 5.3 TEST PROCEDURE .............................................................................................................................................. 15 5.4 SUMMARY OF TEST RESULTS/PLOTS ................................................................................................................. 15 6. RF OUTPUT POWER ............................................................................................................................................ 16 6.1 STANDARD APPLICABLE ..................................................................................................................................... 16 6.2 TEST SETUP BLOCK DIAGRAM ........................................................................................................................... 16 6.3 TEST PROCEDURE .............................................................................................................................................. 16 6.4 SUMMARY OF TES…

Text truncated - open the document above for the full version.

Reference No.: WTX26X06164454W001 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 50 of 76 Test Graphs 11B-Ant1-2412 11B-Ant1-2437 11B-Ant1-2462 Reference No.: WTX26X06164454W001 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 51 of 76 11G-Ant1-2412 11G-Ant1-2437 11G-Ant1-2462 Reference No.: WTX26X06164454W001 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 52 of 76 11N20SISO-Ant1-2412 11N20SISO-Ant1-2437 11N20SISO-Ant1-2462 Reference No.: WTX26X06164454W001 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 53 of 76 Appendix C: Maximum conducted output power Test Result Peak TestMode Antenna Frequency[MHz] Set Power Peak Powert[dBm] Conducted Limit[dBm] Verdict 11B Ant1 2412 NA 13.68 ≤30.00 PASS 11B Ant1 2437 NA 13.87 ≤30.00 PASS 11B Ant1 2462 NA 13.98 ≤30.00 PASS 11G Ant1 2412 NA 7.91 ≤30.00 PASS 11G Ant1 2437 NA 8.15 ≤30.00 PASS 11G Ant1 2462 NA 8.24 ≤30.00 PASS 11N20SISO Ant1 2412 NA 7.94 ≤30.00 PASS 11N20SISO Ant1 2437 NA 8.10 ≤30.00 PASS 11N20SISO Ant1 2462 NA 8.24 ≤30.00 PASS Reference No.: WTX26X06164454W001 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 54 of 76 Appendix D: Maximum power spectral density Test Result TestMode Antenna Frequency[MHz] Result[dBm/3-100kHz] Limit[dBm/3kHz] Verdict 11B Ant1 2412 -16.70 ≤8.00 PASS 11B Ant1 2437 -16.74 ≤8.00 PASS 11B Ant1 2462 -16.76 ≤8.00 PASS 11G Ant1 2412 -20.41 ≤8.00 PASS 11G Ant1 2437 -20.17 ≤8.00 PASS 11G Ant1 2462 -20.23 ≤8.00 PASS 11N20SISO Ant1 2412 -20.47 ≤8.00 PASS 11N20SISO Ant1 2437 -20.44 ≤8.00 PASS 11N20SISO Ant1 2462 -20.55 ≤8.00 PASS Reference No.: WTX26X06164454W001 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 55 of 76 Test Graphs 11B-Ant1-2412-PASS 11B-Ant1-2437-PASS 11B-Ant1-2462-PASS Reference No.: WTX26X06164454W001 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 56 of 76 11G-Ant1-2412-PASS 11G-Ant1-2437-PASS 11G-Ant1-2462-PASS Reference No.: WTX26X06164454W001 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 57 of 76 11N20SISO-Ant1-2412-PASS 11N20SISO-Ant1-2437-PASS 11N20SISO-Ant1-2462-PASS Reference No.: WTX26X06164454W001 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 58 of 76 Appendix E: Reference level measurement Test Result TestMode Antenna Freq(MHz) Max.Point[MHz] Result[dBm] 11B Ant1 2412 2414.01 1.87 11B Ant1 2437 2439.01 1.88 11B Ant1 2462 2460.02 1.87 11G Ant1 2412 2406.38 -6.45 11G Ant1 2437 2431.03 -6.33 11G Ant1 2462 2455.76 -6.29 11N20SISO Ant1 2412 2418.54 -6.56 11N20SISO Ant1 2437 2431.39 -6.77 11N20SISO Ant1 2462 2455.75 -6.60 Reference No.: WTX26X06164454W001 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 59 of 76 Test Graphs 11B-Ant1-2412-PASS 11B-Ant1-2437-PASS 11B-Ant1-2462-PASS Reference No.: WTX26X06164454W001 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 60 of 76 11G-Ant1-2412-PASS 11G-Ant1-2437-PASS 11G-Ant1-2462-PASS Reference No.: WTX26X06164454W001 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 61 of 76 11N20SISO-Ant1-2412-PASS 11N20SISO-Ant1-2437-PASS 11N20SISO-Ant1-2462-PASS Reference No.: WTX26X06164454W001 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 62 of 76 Appendix F: Band edge measurements Test Result TestMode Antenna ChName Frequency[MHz] RefLevel[dBm] Result[dBm] Limit[dBm] Verdict 11B Ant1 Low 2412 1.87 -43.48 ≤-18.13 PASS 11B Ant1 High 2462 1.87 -43.13 ≤-18.13 PASS 11G Ant1 Low 2412 -6.45 -45.77 ≤-26.45 PASS 11G Ant1 High 2462 -6.29 -46 ≤-26.29 PASS 11N20SISO Ant1 Low 2412 -6.56 -45.63 ≤-26.56 PASS 11N20SISO Ant1 High 2462 -6.60 -45.2 ≤-26.6 PASS Reference No.: WTX26X06164454W001 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 63 of 76 Test Graphs 11B-Ant1-2412-PASS 11B-Ant1-2462-PASS 11G-Ant1-2412-PASS

Reference No.: WTX26X06164454W001 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 64 of 76 11G-Ant1-2462-PASS 11N20SISO-Ant1-2412-PASS 11N20SISO-Ant1-2462-PASS Reference No.: WTX26X06164454W001 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 65 of 76 Appendix G: Conducted Spurious Emission Test Result TestMode Antenna Frequency[MHz] FreqRange [Mhz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict 11B Ant1 2412 30~1000 1.87 -49.09 ≤-18.13 PASS 11B Ant1 2412 1000~26500 1.87 -32.87 ≤-18.13 PASS 11B Ant1 2437 30~1000 1.88 -49.8 ≤-18.12 PASS 11B Ant1 2437 1000~26500 1.88 -32.11 ≤-18.12 PASS 11B Ant1 2462 30~1000 1.87 -48.98 ≤-18.13 PASS 11B Ant1 2462 1000~26500 1.87 -31.94 ≤-18.13 PASS 11G Ant1 2412 30~1000 -6.45 -48.9 ≤-26.45 PASS 11G Ant1 2412 1000~26500 -6.45 -34.39 ≤-26.45 PASS 11G Ant1 2437 30~1000 -6.33 -49.59 ≤-26.33 PASS 11G Ant1 2437 1000~26500 -6.33 -33.36 ≤-26.33 PASS 11G Ant1 2462 30~1000 -6.29 -48.96 ≤-26.29 PASS 11G Ant1 2462 1000~26500 -6.29 -33.83 ≤-26.29 PASS 11N20SISO Ant1 2412 30~1000 -6.56 -48.72 ≤-26.56 PASS 11N20SISO Ant1 2412 1000~26500 -6.56 -34.14 ≤-26.56 PASS 11N20SISO Ant1 2437 30~1000 -6.77 -48.79 ≤-26.77 PASS 11N20SISO Ant1 2437 1000~26500 -6.77 -33.8 ≤-26.77 PASS 11N20SISO Ant1 2462 30~1000 -6.60 -49.02 ≤-26.6 PASS 11N20SISO Ant1 2462 1000~26500 -6.60 -34.08 ≤-26.6 PASS Reference No.: WTX26X06164454W001 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 66 of 76 Test Graphs 11B-Ant1-2412-30~1000-PASS 11B-Ant1-2412-1000~26500-PASS 11B-Ant1-2437-30~1000-PASS Reference No.: WTX26X06164454W001 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 67 of 76 11B-Ant1-2437-1000~26500-PASS 11B-Ant1-2462-30~1000-PASS 11B-Ant1-2462-1000~26500-PASS Reference No.: WTX26X06164454W001 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 68 of 76 11G-Ant1-2412-30~1000-PASS 11G-Ant1-2412-1000~26500-PASS 11G-Ant1-2437-30~1000-PASS Reference No.: WTX26X06164454W001 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 69 of 76 11G-Ant1-2437-1000~26500-PASS 11G-Ant1-2462-30~1000-PASS 11G-Ant1-2462-1000~26500-PASS Reference No.: WTX26X06164454W001 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 70 of 76 11N20SISO-Ant1-2412-30~1000-PASS 11N20SISO-Ant1-2412-1000~26500-PASS 11N20SISO-Ant1-2437-30~1000-PASS Reference No.: WTX26X06164454W001 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 71 of 76 11N20SISO-Ant1-2437-1000~26500-PASS 11N20SISO-Ant1-2462-30~1000-PASS 11N20SISO-Ant1-2462-1000~26500-PASS Reference No.: WTX26X06164454W001 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 72 of 76 Appendix H: Duty Cycle Test Result TestMode Antenna Frequency[MHz] Transmission Duration [ms] Transmission Period [ms] Duty Cycle [%] Factor 11B Ant1 2412 27.00 27.00 100.00 0.00 11B Ant1 2437 27.00 27.00 100.00 0.00 11B Ant1 2462 27.00 27.00 100.00 0.00 11G Ant1 2412 27.00 27.00 100.00 0.00 11G Ant1 2437 27.00 27.00 100.00 0.00 11G Ant1 2462 27.00 27.00 100.00 0.00 11N20SISO Ant1 2412 27.00 27.00 100.00 0.00 11N20SISO Ant1 2437 27.00 27.00 100.00 0.00 11N20SISO Ant1 2462 27.00 27.00 100.00 0.00 Reference No.: WTX26X06164454W001 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 73 of 76 Test Graphs NTNV-11B-Ant1-2412 NTNV-11B-Ant1-2437 NTNV-11B-Ant1-2462 Reference No.: WTX26X06164454W001 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 74 of 76 NTNV-11G-Ant1-2412 NTNV-11G-Ant1-2437 NTNV-11G-Ant1-2462 Reference No.: WTX26X06164454W001 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 75 of 76 NTNV-11N20SISO-Ant1-2412 NTNV-11N20SISO-Ant1-2437 NTNV-11N20SISO-Ant1-2462 Reference No.: WTX26X06164454W001 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 76 of 76 APPENDIX PHOTOGRAPHS Please refer to “ANNEX” ***** END OF REPORT *****
