2BVLN-QS-1208Qingo Al Vending

All packaging materials must be disposed of in an environmentally responsible manner. Cardboard packaging can be recycled as waste paper. The protective films and foam Packaging Disposal FCC Warnning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection againstharmful interference in a residential installation. This equipment generates, uses and can radiateradio frequency energy and, if not installed and used in accordance with the instructions, maycause harmful interference to radio communications. However, there is no guarantee thatinterference will not occur in a particular installation. If this equipment does cause harmfulinterference to radio or television reception, which can be determined by turning the equipmentoff and on, the user is encouraged to try to correct the interference by one or more of thefollowing measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body.

Wuhan Qinggou Intelligent Technology Co., Ltd. No. 64, Jiukang Avenue, Caidian Economic Development Zone,Caidian District Wuhan City, Hubei Province 430120 China 2.911 (d)(5)(i) Equipment Type Attestation v1.2 Section 2.911(d)(5)(i) Certification – Equipment Type Company name: Wuhan Qinggou Intelligent Technology Co., Ltd. Address: No. 64, Jiukang Avenue, Caidian Economic Development Zone,Caidian District Wuhan City, Hubei Province 430120 China Product Name: Qingo Al Vending FCC ID: 2BVLN-QS-1208 Model(s): QS-1208CRSW(G)-US, QS-1208CREW(G)-US, QS-1209CRSW(G)-US, QS-1209CREW(G)-US,QS-1208CRS-US, QS-1208CRE-US 2.911(d)(5)(i) Equipment Type We, [Wuhan Qinggou Intelligent Technology Co., Ltd.] (“the applicant”) certify that the equipment for which authorization is sought through certification is not: • Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules. • Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name: Yang Liu Date: 2026-8-29 Title and Company name: Legal Person/ Wuhan Qinggou Intelligent Technology Co., Ltd. NOTE 1 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

2.911 (d)(5)(ii) Applicant Attestation v1.3 Wuhan Qinggou Intelligent Technology Co., Ltd. No. 64, Jiukang Avenue, Caidian Economic Development Zone,Caidian District Wuhan City, Hubei Province 430120 China Section 2.911(d)(5)(ii) Certification – Applicant (Covered List ) Company name: Wuhan Qinggou Intelligent Technology Co., Ltd. Addr ess: No. 64, Jiukang Avenue, Caidian Economic Development Zone,Caidian District Wuhan City, Hubei Province 430120 China Product Name: Qingo Al Vending FCC ID: 2BVLN-QS-1208 Model(s): QS-1208CRSW(G)-US, QS-1208CREW(G)-US, QS-1209CRSW(G)-US, QS-1209CREW(G)-US,QS-1208CRS-US, QS-1208CRE-US 2.911(d)(5)(ii) Applicant filing We, [Wuhan Qinggou Intelligent Technology Co., Ltd.] (“the applicant”) certify that, as of the date of the filing of the application, the applicant is not identified NOTE 1 on the “Covered List” NOTE 2 , established pursuant to § 1.50002 of this chapter, as an entity producing covered communications equipment. Yours sincerely, Name: Yang Liu Date: 2026-8-29 Title and Company name: Legal Person/ Wuhan Qinggou Intelligent Technology Co., Ltd. NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1)986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Wuhan Qinggou Intelligent Technology Co., Ltd. No. 64, Jiukang Avenue, Caidian Economic Development Zone,Caidian District Wuhan City, Hubei Province 430120 China Date: 2026-8-29 FCC ID: 2BVLN-QS-1208 Dear Sir/Madam, We, Wuhan Qinggou Intelligent Technology Co., Ltd. Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, only model number and colour are different for these model: Product name: Qingo Al Vending Model no.: QS-1208CRSW(G)-US, QS-1208CREW(G)-US, QS-1209CRSW(G)-US, QS- 1209CREW(G)-US,QS-1208CRS-US, QS-1208CRE-US Sincerely, Name/Title： Yang Liu/Legal Person Company: Wuhan Qinggou Intelligent Technology Co., Ltd. Address: No. 64, Jiukang Avenue, Caidian Economic Development Zone,Caidian District Wuhan City, Hubei Province 430120 China Phone: 17764008898 Fax: N/A E-Mail: [email protected]

Wuhan Qinggou Intelligent Technology Co., Ltd. No. 64, Jiukang Avenue, Caidian Economic Development Zone,Caidian District Wuhan City, Hubei Province 430120 China Letter of Authorization Company: Wuhan Qinggou Intelligent Technology Co., Ltd. Address: No. 64, Jiukang Avenue, Caidian Economic Development Zone,Caidian District Wuhan City, Hubei Province 430120 China FCC ID: 2BVLN-QS-1208 Model Number(s): QS-1208CRSW(G)-US, QS-1208CREW(G)-US, QS-1209CRSW(G)- US, QS-1209CREW(G)-US,QS-1208CRS-US, QS-1208CRE-US Product Description: Qingo Al Vending We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Sincerely, Name/Title： Yang Liu/Legal Person Company: Wuhan Qinggou Intelligent Technology Co., Ltd. Address: No. 64, Jiukang Avenue, Caidian Economic Development Zone,Caidian District Wuhan City, Hubei Province 430120 China Phone: 17764008898 Fax: N/A E-Mail: [email protected]

Wuhan Qinggou Intelligent Technology Co., Ltd. No. 64, Jiukang Avenue, Caidian Economic Development Zone,Caidian District Wuhan City, Hubei Province 430120 China Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2026-8-29 Subject; Request for Confidentiality FCC ID: 2BVLN-QS-1208 Product name: Qingo Al Vending Model no.: QS-1208CRSW(G)-US, QS-1208CREW(G)-US, QS-1209CRSW(G)-US, QS- 1209CREW(G)-US,QS-1208CRS-US, QS-1208CRE-US To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Wuhan Qinggou Intelligent Technology Co., Ltd. No. 64, Jiukang Avenue, Caidian Economic Development Zone,Caidian District Wuhan City, Hubei Province 430120 China Sincerely, Name/Title： Yang Liu/Legal Person Company: Wuhan Qinggou Intelligent Technology Co., Ltd. Address: No. 64, Jiukang Avenue, Caidian Economic Development Zone,Caidian District Wuhan City, Hubei Province 430120 China Phone: 17764008898 Fax: N/A E-Mail: [email protected]

FCC ID:2BVLN-QS-1208 External Photos of the EUT FCC ID:2BVLN-QS-1208

Label and Location Size: L: 8.0cm*W: 6.0cm Label and Location FCC ID : 2BVLN-QS-1208

FCC ID:2BVLN-QS-1208 Internal Photos of the EUT FCC ID:2BVLN-QS-1208 WIFI ANT LTE ANT FCC ID:2BVLN-QS-1208 FCC ID:2BVLN-QS-1208 FCC ID:2BVLN-QS-1208 FCC ID:2BVLN-QS-1208 FCC ID:2BVLN-QS-1208 FCC ID:2BVLN-QS-1208

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn RF Exposure MPE Report Reference No. .................... : FCC ID. ........................................... : CTA26071002307 2BVLN-QS-1208 Compiled by ( position+printed name+signature) . : File administrators Zoey Cao Supervised by ( position+printed name+signature) . : Project Engineer Ace Chai Approved by ( position+printed name+signature) . : RF Manager Eric Wang Date of issue .................................... : Jul. 25, 2026 Testing Laboratory Name.............. : Shenzhen CTA Testing Technology Co., Ltd. Address ........................................... : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Applicant’s name ........................... : Wuhan Qinggou Intelligent Technology Co., Ltd. Address ........................................... : No. 64, Jiukang Avenue, Caidian Economic Development Zone, Caidian District Wuhan City, Hubei Province, 430120 China Standard........................................... : 47CFR §1.1310 47CFR §2.1091 KDB447498 D01 General RF Exposure Guidance v06 Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purpses as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : Qingo Al Vending Trade Mark ....................................... : N/A Manufacturer .................................... : Wuhan Qinggou Intelligent Technology Co., Ltd. Model/Type reference ...................... : QS-1208CRSW(G)-US Listed Models ................................... : QS-1208CREW(G)-US, QS-1209CRSW(G)-US, QS-1209CREW(G)-US, QS-1208CRS-US, QS-1208CRE-US Rating ............................................... : AC 120V, 60Hz Result ............................................... : PASS Report No.: CTA26071002307 Page 2 of 10 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : Qingo Al Vending Model /Type : QS-1208CRSW(G)-US Listed Models : QS-1208CREW(G)-US, QS-1209CRSW(G)-US, QS-1209CREW(G)-US, QS-1208CRS-US, QS-1208CRE-US Model difference : The PCB board, circuit, structure and internal of these models are the same, only model number and colour are different for these model. So the tests were performed on model QS-1208CRSW(G)-US and the test results for the main test model can cover the listed models. Applicant : Wuhan Qinggou Intelligent Technology Co., Ltd. Address : No. 64, Jiukang Avenue, Caidian Economic Development Zone, Caidian District Wuhan City, Hubei Province, 430120 China Manufacturer : Wuhan Qinggou Intelligent Technology Co., Ltd. Address : No. 64, Jiukang Avenue, Caidian Economic Development Zone, Caidian District Wuhan City, Hubei Province, 430120 China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA26071002307 Page 3 of 10 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 TEST STANDARDS ............................................................................................................ 4 2 SUMMARY .......................................................................................................................... 5 2.1 General Remarks ..................................................................................................... 5 2.2 Product Description ................................................................................................. 5 2.3 Special Accessories ................................................................................................. 6 2.4 Modifications ............................................................................................................ 6 3 TEST ENVIRONMENT ....................................................................................................... 7 3.1 Address of the test laboratory .................................................................................. 7 3.2 Test Facility .............................................................................................................. 7 3.3 Statement of the measurement uncertainty ............................................................. 7 4 Test limit .............................................................................................................................. 8 4.1 Requirement ............................................................................................................ 8 4.2 MPE Calculation Method ......................................................................................... 8 4.3 Conducted Power Results ....................................................................................... 9 4.4 Manufacturing tolerance .......................................................................................... 9 4.5 Standalone MPE Result .........…

Text truncated - open the document above for the full version.

Antenna specification Product material number: Y0RPV0CA0BA Version: 1.0 Date: June 13th, 2024 Status: temporary version Product name: WIFI sucker antenna main features: Frequency range: 2400-2500 MHz Size: φ 29.6 * 221mm Efficiency: up to 16.4% (MP) Meet RoHS standards 天线服务 Y0RPV0CA0BA 规格书 Antenna_Datasheet4 / 20 catalogue 目录4 1规格参数5 1.1.电气性能5 1.2.机械, 环境特性6 2图纸7 3详细性能参数8 3.1.S 参数测试8 3.1.1.电压驻波比8 3.1.2.回波损耗9 3.2.辐射性能测试10 3.2.1.效率10 3.2.2.平均增益11 3.2.3.峰值增益12 3.2.4.3D & 2D 辐射场型图13 3.2.4.1.测试状态: 在300 × 300 mm 的金属板上13 3.2.4.2.测试状态: 自由空间状态14 4包装15 联系我们17 法律声明18 文档历史20 天线服务 Y0RPV0CA0BA 规格书 Antenna_Datasheet5 / 20 Test status: on a 300 × 300 mm metal plate & free space status. 1.1.behaviour of electricity Electrical specification frequency range 2400–2500 MHz impedance 50 Ω Polarization mode Linear Radiation field pattern Omni-directional voltage standing wave ratio MP≤ 1.7 FS≤ 1.7 Peak gain MP≤ -2.5 dBi FS≤ -2.4 dBi FS: free state MP: On a 300 × 300 mm metal plate. 1 specification parameters 天线服务 Y0RPV0CA0BA 规格书 Antenna_Datasheet6 / 20 1.2.Mechanical and environmental characteristics machinery Antenna size Φ 29.6× 221 mm Shell material & colorCarbon steel & black Cable Type & Color & LengthRG174 & black & 3000mm Connector typeRP SMA male head weightAbout 46.8 g Installation typeMagnetic attraction environment Working temperature -20 °C to +65 °C storage temperature -20 °C to +65 °C Meet environmental protection standards RoHS 天线服务 Y0RPV0CA0BA 规格书 Antenna_Datasheet7 / 20 2 drawings 天线服务 Y0RPV0CA0BA 规格书 Antenna_Datasheet8 / 20 3.1.S parameter test 3.1.1.voltage standing wave ratio voltage standing wave ratio Frequency (MHz) 24002450two thousan d and five hundred 5150550058505925632567257125 voltage standi ng wave ratio MPone point six 1.21.7------- FS1.51.21.7------- 3 Detailed performance parameters VSW R MPF S si x fi v e f o u r t h r e e 2 o n e Frequency(MHz) V S W R 2 3 0 0 2 3 5 0 2 4 0 0 2 4 5 0 t w o t h o u s 2 5 5 0 2 6 0 0 天线服务 Y0RPV0CA0BA 规格书 Antenna_Datasheet9 / 20 3.1.2.return loss Return loss (dB) Frequency (MHz) 24002450two thousan d and five hundred 5150550058505925632567257125 return loss (dB) MP-13.1-19.3-11.9------- FS-13.4-21.3-11.7------- Return Loss MPFS 0 -5 -10 -15 -20 -25 -30 -35 Frequency(MHz) R e t u r n L o s s ( d B ) 2 3 0 0 2 3 5 0 2 4 0 0 2 4 5 0 t w o t h o u s 2 5 5 0 2 6 0 0 天线服务 Y0RPV0CA0BA 规格书 Antenna_Datasheet10 / 20 3.2.Radiation performance test 3.2.1.efficiency Efficiency (%) Frequency (MHz) 24002450two thousan d and five hundred 5150550058505925632567257125 Efficiency (%) MP14.714.113.5------- FS15.315.613.2------- Efficienc y MPFS 100 90 80 70 60 50 40 thirt y twe nty 10 0 Frequency(MHz) E f f i c i e n c y ( % ) 2 3 0 0 2 3 5 0 2 4 0 0 2 4 5 0 t w o t h o u s 2 5 5 0 2 6 0 0 天线服务 Y0RPV0CA0BA 规格书 Antenna_Datasheet11 / 20 3.2.2.Average gain Average gain (dB) Frequency (MHz) 24002450two thousan d and five hundred 5150550058505925632567257125 Average gain (dB) MP-8.3-8.5-8.7------- FS-8.1-8.1-8.8------- Average Gain MPFS 0 -2 -4 -6 -8 -10 -12 -14 Frequency(MHz) A v e r a g e G a i n ( d B ) 2 3 0 0 2 3 5 0 2 4 0 0 2 4 5 0 t w o t h o u s 2 5 5 0 2 6 0 0 天线服务 Y0RPV0CA0BA 规格书 Antenna_Datasheet12 / 20 3.2.3.Peak gain Peak gain (dBi) Frequency (MHz) 24002450two thousan d and five hundred 5150550058505925632567257125 Peak gain (dBi) MP-2.7-3.0-2.6------- FS-2.8-3.2-4.8------- Peak Gain MPFS f o u r 2 0 -2 -4 -6 -8 Frequency(MHz) P e a k G a i n ( d B i ) 2 3 0 0 2 3 5 0 2 4 0 0 2 4 5 0 t w o t h o u s 2 5 5 0 2 6 0 0 天线服务 Y0RPV0CA0BA 规格书 Antenna_Datasheet13 / 20 3.2.4.3 d-2 d radiation pattern 3.2.4.1.Test status: on a 300 × 300 mm metal plate. Testing laboratory: GL-G-1 strap 2450 MHz Z × Y X Z × Y X 天线服务 Y0RPV0CA0BA 规格书 Antenna_Datasheet14 / 20 3.2.4.2.Test state: free space state Testing laboratory: GL-G-1 2450 MHz 天线服务 Y0RPV0CA0BA 规格书 Antenna_Datasheet15 / 20 StepPackaging picture / 2D pictureDescription oneOne product in a small bag 2 A big bag with 50 small bags and a big bag with 50 products. 4 packaging 天线服务 Y0RPV0CA0BA 规格书 Antenna_Datasheet16 / 20 three A box contains 4 large bags. Estimated quantity of 200 products in a box Products that are not enough will be packed in suitable cartons. The carton size: 370 x 370 x 295 mm. four Label position Carton label① Quality label② five Carton sealing I-shaped box sealing sixThe above initial packaging methods are for reference only, and the final actual packaging method is subject to the actual shipping packaging. 天线服务 Y0RPV0CA0BA 规格书 Antenna_Datasheet17 / 20 contact us Shanghai Yiyuan Communication Technology Co., Ltd. (hereinafter referred to as "Yiyuan Communication") always takes providing customers with the most timely and comprehensive service as its purpose. If you need any help, please feel free to contact our Shanghai headquarters as follows: Shanghai Yiyuan Communication Technology Co., Ltd. Building 5, Technology Oasis Phase III (Zone B), No.1016 Tianlin Road, Minhang District, Shanghai Postal Code: 200233 Tel: +86 21 5108 6236 E- mail:[email protected] Or contact our local office. For details, please visit:http://www.quectel.com/cn/support/sales.htm. If you need technical support or feedback the problems in our technical documents, please log on to the website at any time: http://www.quectel.com/cn/support/technical.htmO r s e n d a n e m a i l t o :[email protected]. 天线服务 Y0RPV0CA0BA 规格书 Antenna_Datasheet18 / 20 Legal statement Mobile Communication provides the contents of this document to support the customer's product design. The customer must design the product according to the specifications and parameters provided in the document. At the same time, you understand and agree that the reference design provided by Mobile Communication is only an example. You agree to use your independent analysis, evaluation and judgment when designing your target products. Please read this statement carefully before using any hardware, software or services instructed in this document. You hereby acknowledg…

Text truncated - open the document above for the full version.

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. .................... : FCC ID. .......................................... : CTA26071002301 2BVLN-QS-1208 Compiled by ( position+printed name+signature) . : File administrators Zoey Cao Supervised by ( position+printed name+signature) . : Project Engineer Ace Chai Approved by ( position+printed name+signature) . : RF Manager Eric Wang Date of issue .................................... : Jul. 25, 2026 Testing Laboratory Name ............. : Shenzhen CTA Testing Technology Co., Ltd. Address ............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Applicant’s name ........................... : Wuhan Qinggou Intelligent Technology Co., Ltd. Address ............................................ : No. 64, Jiukang Avenue, Caidian Economic Development Zone, Caidian District Wuhan City, Hubei Province, 430120 China Test specification.......................... : Standard .......................................... : FCC Part 15.247 TRF Originator ................................. : Shenzhen CTA Testing Technology Co., Ltd. Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .................... : Qingo Al Vending Trade Mark ....................................... : N/A Manufacturer .................................... : Wuhan Qinggou Intelligent Technology Co., Ltd. Model/Type reference ...................... : QS-1208CRSW(G)-US Listed Models ................................... : QS-1208CREW(G)-US, QS-1209CRSW(G)-US, QS-1209CREW(G)-US, QS-1208CRS-US, QS-1208CRE-US Modulation Type .............................. : CCK/DSSS/OFDM Operation Frequency ....................... : From 2412 - 2462MHz Rating ............................................... : AC 120V, 60Hz Result ............................................... : PASS Report No.: CTA26071002301 Page 2 of 40 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : Qingo Al Vending Model /Type : QS-1208CRSW(G)-US Listed Models : QS-1208CREW(G)-US, QS-1209CRSW(G)-US, QS-1209CREW(G)- US,QS-1208CRS-US, QS-1208CRE-US Model difference : The PCB board, circuit, structure and internal of these models are the same, only model number and colour are different for these model. So the tests were performed on model QS-1208CRSW(G)-US and the test results for the main test model can cover the listed models. Applicant : Wuhan Qinggou Intelligent Technology Co., Ltd. Address : No. 64, Jiukang Avenue, Caidian Economic Development Zone, Caidian District Wuhan City, Hubei Province, 430120 China Manufacturer : Wuhan Qinggou Intelligent Technology Co., Ltd. Address : No. 64, Jiukang Avenue, Caidian Economic Development Zone, Caidian District Wuhan City, Hubei Province, 430120 China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA26071002301 Page 3 of 40 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 TEST STANDARDS ...................................................................................................................................... 4 2 SUMMARY .................................................................................................................................................... 5 2.1 General Remarks .............................................................................................................................. 5 2.2 Product Description ........................................................................................................................... 5 2.3 Equipment Under Test ....................................................................................................................... 5 2.4 Short description of the Equipment under Test (EUT) ...................................................................... 5 2.5 EUT configuration .............................................................................................................................. 5 2.6 EUT operation mode ......................................................................................................................... 6 2.7 Block Diagram of Test Setup ............................................................................................................. 6 2.8 Related Submittal(s) / Grant (s) ......................................................................................................... 6 2.9 Modifications ...................................................................................................................................... 6 3 TEST ENVIRONMENT ...............…

Text truncated - open the document above for the full version.

1 FCC Appendix RF Test Data for 2.4GWIFI FCC ID : 2BVLN-QS-1208 Company : Wuhan Qinggou Intelligent Technology Co., Ltd. EUT : Qingo Al Vending Model Number : QS-1208CRSW(G)-US Report No. : CTA26071002301 Reviewed By : Eric Wang 2 Appendix A: DTS Bandwidth Test Result TestMode Antenna Frequency[MHz] DTS BW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant1 2412 10.200 2406.960 2417.160 0.5 PASS 2437 10.240 2431.920 2442.160 0.5 PASS 2462 10.200 2456.920 2467.120 0.5 PASS 11G Ant1 2412 15.680 2404.040 2419.720 0.5 PASS 2437 15.640 2429.120 2444.760 0.5 PASS 2462 15.880 2454.120 2470.000 0.5 PASS 11N20SISO Ant1 2412 16.920 2403.440 2420.360 0.5 PASS 2437 16.480 2428.520 2445.000 0.5 PASS 2462 16.360 2453.520 2469.880 0.5 PASS 11N40SISO Ant1 2422 34.560 2405.040 2439.600 0.5 PASS 2437 35.040 2419.720 2454.760 0.5 PASS 2452 35.760 2434.160 2469.920 0.5 PASS 3 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 4 11G_Ant1_2412 11G_Ant1_2437 5 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 6 11N20SISO_Ant1_2462 11N40SISO_Ant1_2422 7 11N40SISO_Ant1_2437 11N40SISO_Ant1_2452 8 Appendix B: Occupied Channel Bandwidth Test Result TestMode Antenna Channel Frequency[MHz] OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant1 2412 13.416 2405.2995 2418.7155 --- --- 2437 13.424 2430.3038 2443.7278 --- --- 2462 13.427 2455.3088 2468.7358 --- --- 11G Ant1 2412 16.868 2403.5899 2420.4579 --- --- 2437 16.847 2428.5933 2445.4403 --- --- 2462 16.855 2453.6412 2470.4962 --- --- 11N20SISO Ant1 2412 17.911 2403.0495 2420.9605 --- --- 2437 17.834 2428.1008 2445.9348 --- --- 2462 17.883 2453.0882 2470.9712 --- --- 11N40SISO Ant1 2422 36.131 2404.0824 2440.2134 --- --- 2437 36.035 2419.1476 2455.1826 --- --- 2452 36.057 2434.1309 2470.1879 --- --- 9 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 10 11G_Ant1_2412 11G_Ant1_2437 …
