BT-104L5 GNSS Antenna Datasheet Shenzhen Beitian Communication Co., Ltd. www.beitian.com 1 / 4 BT-104L5 GNSS Helical Antenna Datasheet Revision: 6.13 Date:2025.4 BT-104L5 GNSS Antenna Datasheet Shenzhen Beitian Communication Co., Ltd. www.beitian.com 2 / 4 PRODUCT DESCRIPTION BT-104L5 GNSS antenna is an L1+L5 active spiral antenna, designed with multi-arm spiral technology, which supports the L1 band satellite navigation signal reception of Beidou II, GPS, GLONASS and GALILEO systems, meets the current needs of multi-system compatibility and high-precision measurement, and can be widely used in high-precision navigation and positioning occasions such as portable equipment, unmanned aerial vehicles, navigation and scheduling. Accept user customization. PRODUCT APPLICATION It is suitable for the occasions that require volume and weight, such as UAV, micro RTK, Ami handset/flat panel and other portable devices. Accept user customization. TECHNICAL CHARACTERISTICS  Eight-arm coupled quadruple-fed zero phase center technology ensures right-handed circular polarization and phase center stability.  The antenna unit has high passive gain and wide beam width to ensure the receiving effect of low elevation signal.  Delicate low noise, high gain amplification and excellent out-of-band suppression;  Small size, light weight, easy to carry and install. DIMENSION Unit: mm BT-104L5 GNSS Antenna Datasheet Shenzhen Beitian Communication Co., Ltd. www.beitian.com 3 / 4 MAIN PARAMETER Item Specifications Bands GPS: L1, L1C,L5C BDS: B1I,B1C,B2a Galileo: E1, E5a QZSS: L5 IRNSS:S-L5 Polarization RHCP Axis Ratio of Antenna 3dB Horizontal Coverage 360° GAIN 3.5dBi LNA GAIN 28±2dB Noise Figure ≤2dB Output VSWR ≤2.0:1 Band flatness ±2dB Supply Voltage 3.3V Supply Current ≤30mA Operating Temperature －40°C -＋80°C Storage Temperature －45°C -＋85°C Humidity 95% Dimensions Ф18.5mm*50.0mm Connector SMA-J Weight ≤11g Waterproof grade IP67 BT-104L5 GNSS Antenna Datasheet Shenzhen Beitian Communication Co., Ltd. www.beitian.com 4 / 4 FCC Warning Statement This product has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This product generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this product does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ‐‐ Reorient or relocate the receiving antenna of the radio/TV. ‐‐ Increase the separation between the equipment and receiver(radio/TV). ‐‐ Connect the equipment into an outlet on a circuit different from that to which the receiver(radio/TV) is connected. ‐‐ Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference. (2)This device must accept any interference received, including interference that may cause undesired operation.
