2BWS9TDMNEOBluetooth Headphones

User Manual M a n u e l d ' u t i l i s a t i o n Bedienungsanleitung Manual de usuario Manuale utente G e b r u i k e r s h a n d l e i d i n g Manual do utilizador Mode/ Bluetooth • Hold 3s - BT pairing • Click to change modes See page 3 MFB/ Play Hold 2s - power on Twist to Switch – Instantly switches from headphones to Speakers when twisted. Twist to Pause – Music pauses when twisted and resumes when untwisted. Twist to PowerTwist to Power – Twist to power down untwist to power up. Manual Speaker – Speaker only, twist inactive. Twist Modes Vybe A udio L LC / D BA T DM. Bluetooth Headphones TDMNeo LEGAL · UNITED STATES FCC Caution § 15.19 Labeling requirements This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. § 15.21 Changes or modification warning Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. TDM. NEO·LEGAL · FCC·05 LEGAL · UNITED STATES FCC Caution — continued § 15.105 Information to the user Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. • • • • TDM. NEO·LEGAL · FCC·06 LEGAL · UNITED STATES RF Exposure RF exposure — portable device The device has been evaluated to meet general RF exposure requirements. The device can be used in portable exposure conditions without restriction. TDM. NEO·LEGAL · FCC·07 LEGAL · EUROPEAN UNION Declaration of Conformity TDM. Official Ltd. hereby declares that this product, TDM. Neo, is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. In accordance with Article 10(2) and Article 10(10), this product is allowed to be used in all EU member states. TDM. NEO·LEGAL · EU·10 LEGAL · CANADA IC Warning IC Warning This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence- exempt RSS(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) l’appareil ne doit pas produire de brouillage; (2) l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. TDM. NEO·LEGAL · IC·08 LEGAL · CANADA RF Exposure RF exposure — portable device The device has been evaluated to meet general RF exposure requirements. The device can be used in portable exposure conditions without restriction. L’appareil a été évalué pour répondre aux exigences générales en matière d’exposition aux RF. L’appareil peut être utilisé en condition d’exposition portable sans restriction. TDM. NEO·LEGAL · IC·09 2093 PHILADELPHIA PIKE #5466 CLAYMONT, DE 19703

Rev 1/26/2023 VYBE AUDIO LLC Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2026-07-11 FCC ID: 2BWS9TDMNEO Ref. #1: Attestation Statements Part 2.911(d)(5)(i) Filing VYBE AUDIO LLC certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. VYBE AUDIO LLC certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Device is inherently compliant based on hardware limitations or software controls. or A Software Bill of Materials (SBOM) is provided to the TCB for review, and The end-user or third parties cannot install additional software on this device. Ref. #2: Attestation Statements Part 2.911(d)(5)(ii) Filing VYBE AUDIO LLC certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Applicant: VYBE AUDIO LLC Address: 2093 PHILADELPHIA PIKE #5466 CLAYMONT, DE 19703 Contact Person: David Brailsford Tel.: 302300 7037 Email: [email protected] Sincerely, Signature:

Attestation Statements Date: 2026-07-11 TO: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA RE: Attestation Statements Part 2.911(d)(7) request for(FCC ID: 2BWS9TDMNEO) VYBE AUDIO LLC, the undersigned, hereby authorize VYBE AUDIO LLC to act as our designated agent for service of process, VYBE AUDIO LLC accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. VYBE AUDIO LLC accepts the responsibility to act as designated agent for service of process. Applicant Information： Company name: VYBE AUDIO LLC Contact Name: David Brailsford Address: 2093 PHILADELPHIA PIKE #5466 CLAYMONT, DE 19703 Telephone No: 302300 7037 Email: [email protected] FRN: 0038590204 Signature: David Brailsford Agent Information: Company Name: VYBE AUDIO LLC Address:2093 PHILADELPHIA PIKE #5466 CLAYMONT, DE 19703 FRN: 0038590204 Contact Name: David Brailsford Telephone No: 302300 7037 Email: [email protected] Signature: David Brailsford

VYBE AUDIO LLC Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: August 10, 2026 Subject; Request for Confidentiality FCC ID: 2BWS9TDMNEO To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure SOFTWARE SECURITY REQUIREMENTS FOR U-NII DEVICES In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: David Brailsford Title: Director

Effective Date: April 2, 2020 QSF 7.6.4-8 – Agent Authorization Letter Template Page 1 of 1 Revision Date: Revision: 0 VYBE AUDIO LLC Date：2026-07-11 Product Model Number: TDMNeo FCC ID：2BWS9TDMNEO To whom it may concern, Re: Product Certification Representative Authorization Letter We authorize QAI Laboratories Ltd. 3980 North Fraser Way, Burnaby B.C. Canada V5J 5K5 to act on our behalf on all matters concerning the above named equipment. This shall include the following: • Testing • Approval applications and procedures We declare that QAI Laboratories Ltd. is allowed to forward all information related to the approval project to the applied certification body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by QAI Laboratories Ltd. on our behalf shall have the same effect as acts of our own. Signature: By: David Brailsford Contact Listed on FCC Wesbite Title: Director Email: [email protected] On behalf of: VYBE AUDIO LLC

Page 1 of 8 Report No.: LGT26F165 Appendix - External Photographs of EUT Constructional Details Photo 1 Photo 2 Page 2 of 8 Report No.: LGT26F165 Appendix - External Photographs of EUT Constructional Details Photo 3 Photo 4 Page 3 of 8 Report No.: LGT26F165 Appendix - External Photographs of EUT Constructional Details Photo 5 Photo 6 Page 4 of 8 Report No.: LGT26F165 Appendix - External Photographs of EUT Constructional Details Photo 7 Photo 8 Page 5 of 8 Report No.: LGT26F165 Appendix - External Photographs of EUT Constructional Details Photo 9 Photo 10 Page 6 of 8 Report No.: LGT26F165 Appendix - External Photographs of EUT Constructional Details Photo 11 Photo 12 Page 7 of 8 Report No.: LGT26F165 Appendix - External Photographs of EUT Constructional Details Photo 13 Photo 14 Page 8 of 8 Report No.: LGT26F165 Appendix - External Photographs of EUT Constructional Details Photo 15 Photo 16

x x - x x x x x x I C : 3 5 8 2 1 - T D M N E O F C C I D : 2 B W S 9 T D M N E O C o m p a n y A d d r e s s : 2 0 9 3 P H I L A D E L P H I A P I K E # 5 4 6 6 C L A Y M O N T , D E 1 9 7 0 3 , U S A M o d e l N u m b e r T D M N e o C o m p a n y N a m e : V Y B E A u d i o L L C M a d e I n C h i n a S N : X X X X X X X X X X X X

Page 1 of 5 Report No.: LGT26F165 Appendix - Internal Photographs of EUT Constructional Details Photo 1 Photo 2 Page 2 of 5 Report No.: LGT26F165 Appendix - Internal Photographs of EUT Constructional Details Photo 3 Photo 4 Page 3 of 5 Report No.: LGT26F165 Appendix - Internal Photographs of EUT Constructional Details Photo 5 Photo 6 BT ANT Page 4 of 5 Report No.: LGT26F165 Appendix - Internal Photographs of EUT Constructional Details Photo 7 Photo 8 Page 5 of 5 Report No.: LGT26F165 Appendix - Internal Photographs of EUT Constructional Details Photo 9 Photo 10

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Page 1 of 8 EMF TEST REPORT Product Name: Bluetooth Headphones Model Number: TDMNeo FCC ID: 2BWS9TDMNEO Issued For : VYBE AUDIO LLC 2093 PHILADELPHIA PIKE #5466 CLAYMONT, DE 19703 Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT26F165HA04 Sample Received Date: Jun. 23, 2026 Date of Test: Jun. 23, 2026 ~ Jul. 08, 2026 Date of Issue: Jul. 08, 2026 Report No.: LGT26F165HA04 Page 2 of 8 TEST REPORT CERTIFICATION Applicant: VYBE AUDIO LLC Address: 2093 PHILADELPHIA PIKE #5466 CLAYMONT, DE 19703 Manufacturer: VYBE AUDIO LLC Address: 2093 PHILADELPHIA PIKE #5466 CLAYMONT, DE 19703 Product Name: Bluetooth Headphones Trademark: TDM Model Number: TDMNeo Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC 47 CFR §2.1093 KDB 447498 D01 General RF Exposure Guidance v06 PASS Prepared by: Approved by: Chris Chen Engineer Technical Director Report No.: LGT26F165HA04 Page 3 of 8 TABLE OF CONTENTS 1 . GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST LABORATORY 5 2 . FCC 47CFR §2.1093 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.3 TEST RESULT 8 Report No.: LGT26F165HA04 Page 4 of 8 Revision History Rev. Issue Date Revisions 00 Jul. 08, 2026 Initial Issue Report No.: LGT26F165HA04 Page 5 of 8 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name: Bluetooth Headphones Test Model Number: TDMNeo Series Number: N/A Model Difference: N/A Frequency Bands: Bluetooth 2402-2480MHz Rating: Input: DC 5V 2A Battery: Capacity: 1000mAh Rated Voltage: 3.7V Hardware Version: 9.1 Software Version: V0.0.33 1.2 TEST LABORATORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Accreditation Certificate: FCC Registration No.: 746540 CAB ID: CN0136 Report No.: LGT26F165HA04 Page 6 of 8 2. FCC 47CFR §2.1093 REQUIREMENT 2.1 TEST STANDARDS The limit for Maximum Permissible Exposure (MPE) specified in KDB 447498 D01 General RF Exposure Guidance v06 is followed. The gain of the antennas used in the product is extracted from the Antenna data sheets provided and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis Transmission formula is far field assumption, the calculated result of that is an over-prediction for near field power density. It is taken as worst case to specify the safety range. 2.2 LIMIT Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. Report No.: LGT26F165HA04 Page 7 of 8 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] • [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz. Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. Report No.: LGT26F165HA04 Page 8 of 8 2.3 TEST RESULT Turn up Result Mode Turn up Power BT-GFSK -1.5±1dBm BT-π/4-DQPSK -1±1dBm BT-8DPSK -0.5±1dBm BLE 1M-GFSK -2.5±1dBm BLE 2M-GFSK -2±1dBm The MPE result of worst mode: RF Function Frequency (MHz) Max Turn up Power (dBm) Max Turn up Power (mW) Estimated SAR Limit Ratio Result BT 2441 0.50 1.12 0.351 3 0.117 Pass BLE 2440 -1.00 0.79 0.248 3 0.083 Pass Note: 1. The Maximum Power Density is less than the limit, complies with the exemption requirements. ※※※※※END OF THE REPORT※※※※※

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Page 1 of 59 RF TEST REPORT Product Name: Bluetooth Headphones Model Number: TDMNeo FCC ID: 2BWS9TDMNEO Issued For : VYBE AUDIO LLC 2093 PHILADELPHIA PIKE #5466 CLAYMONT, DE 19703 Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT26F165RF04 Sample Received Date: Jun. 23, 2026 Date of Test: Jun. 23, 2026 ~ Jul. 08, 2026 Date of Issue: Jul. 08, 2026 Report No.: LGT26F165RF04 Page 2 of 59 TEST REPORT CERTIFICATION Applicant: VYBE AUDIO LLC Address: 2093 PHILADELPHIA PIKE #5466 CLAYMONT, DE 19703 Manufacturer: VYBE AUDIO LLC Address: 2093 PHILADELPHIA PIKE #5466 CLAYMONT, DE 19703 Product Name: Bluetooth Headphones Trademark: TDM Model Number: TDMNeo Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC Part 15.247, Subpart C ANSI C63.10-2020 + Cor.1-2023 PASS Prepared by: Approved by: Chris Chen Vita Li Engineer Technical Director Report No.: LGT26F165RF04 Page 3 of 59 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST LABORATORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 9 2.3 TEST SOFTWARE AND POWER LEVEL 9 2.4 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 10 2.5 EQUIPMENTS LIST 11 3. EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.2 TEST PROCEDURE 14 3.3 TEST SETUP 14 3.4 EUT OPERATING CONDITIONS 14 3.5 TEST RESULTS 15 4. RADIATED EMISSION MEASUREMENT 17 4.1 RADIATED EMISSION LIMITS 17 4.2 TEST PROCEDURE 19 4.3 TEST SETUP 19 4.4 EUT OPERATING CONDITIONS 20 4.5 FIELD STRENGTH CALCULATION 20 4.6 TEST RESULTS (BAND EDGE REQUIREMENTS) 29 5. CONDUCTED SPURIOUS & BAND EDGE EMISSION 33 5.1 LIMIT 33 5.2 TEST PROCEDURE 33 5.3 TEST SETUP 33 5.4 EUT OPERATION CONDITIONS 33 5.5 TEST RESULTS 33 6. POWER SPECTRAL DENSITY TEST 34 6.1 LIMIT 34 6.2 TEST PROCEDURE 34 6.3 TEST SETUP 34 6.4 EUT OPERATION CONDITIONS 34 Report No.: LGT26F165RF04 Page 4 of 59 6.5 TEST RESULTS 34 7. BANDWIDTH TEST 35 7.1 LIMIT 35 7.2 TEST PROCEDURE 35 7.3 TEST SETUP 35 7.4 EUT OPERATION CONDITIONS 35 7.5 TEST RESULTS 35 8. PEAK OUTPUT POWER TEST 36 8.1 LIMIT 36 8.2 TEST PROCEDURE 36 8.3 TEST SETUP 36 8.4 EUT OPERATION CONDITIONS 36 8.5 TEST RESULTS 36 9. ANTENNA REQUIREMENT 37 9.1 STANDARD REQUIREMENT 37 9.2 EUT ANTENNA 37 APPENDIX I - TEST RESULTS 38 1. DUTY CYCLE 38 2. BANDWIDTH 41 3. MAXIMUM CONDUCTED OUTPUT POWER 46 4. MAXIMUM POWER SPECTRAL DENSITY 49 5. UNWANTED EMISSIONS IN NON-RESTRICTED FREQUENCY BANDS 52 APPENDIX II - MEASUREMENT PHOTOS 59 Report No.: LGT26F165RF04 Page 5 of 59 Revision History Rev. Issue Date Revisions 00 Jul. 08, 2026 Initial Issue Report No.: LGT26F165RF04 Page 6 of 59 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 Part 15.247 Meas Guidance v05r02. FCC Part 15.247, Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247 (a)(2) 6dB Bandwidth PASS -- 15.247 (b)(3) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247 (d) Conducted Spurious & Band Edge Emission PASS -- 15.247 (e) Power Spectral Density PASS -- 15.205 Restricted Band Edge Emission PASS -- Part 15.247(d)/ Part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2020 + Cor.1-2023. Report No.: LGT26F165RF04 Page 7 of 59 1.1 TEST LABORATORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Accreditation Certificate: FCC Registration No.: 746540 CAB ID: CN0136 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 Occupied Channel Bandwidth ±0.46% 2 RF Output Power, Conducted ±0.71dB 3 Power Spectral Density, Conducted ±1.57dB 4 Unwanted Emission, Conducted ±0.63dB 5 Conducted emission ±2.80dB 6 All Emissions, Radiated (0.009-30MHz) ±2.16dB 7 All Emissions, Radiated (30MHz-1GHz) ±4.61dB 8 All Emissions, Radiated (1GHz-18GHz) ±5.49dB 9 All Emissions, Radiated (18GHz-40GHz) ±4.31dB 10 Temperature ±0.5°C 11 Humidity ±2% 12 Duty Cycle ±2.3% Note: The measurement uncertainty is not included in the test result. Report No.: LGT26F165RF04 Page 8 of 59 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name: Bluetooth Headphones Test Model Number: TDMNeo Series Number: N/A Model Difference: N/A Product Description: Operation Frequency: 2402~2480 MHz Modulation Type: GFSK Radio Technology: BLE Bluetooth Configuration: BLE (1M PHY, 2M PHY) Number Of Channel: 40 Antenna Designation: FPC Antenna Antenna Gain (dBi) 3.39 Channel List: Please refer to the Note 3. Rating: Input: DC 5V 2A Battery: Capacity: 1000mAh Rated Voltage: 3.7V Hardware Version: 9.1 Software Version: V0.0.33 Connecting I/O Port(s): Please refer to the Note 1. Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User Manual. 2. The antenna information refers to the manufacturer provide report, applicable only to the tested sample identified in the report.…

Text truncated - open the document above for the full version.

客户名称 customer Name 客户项目名customer project Name BT-981 合立讯项目名 Helixun project Name BT-981 客户编码 customer P/N 合立讯料号 Helixun P/N HLX-BT-981-V2 频段 Band 2400-2500MHZ 版本号 version AO 设计人信息/Designer Information 射频工程师 RF Engineer 电子工程师 EE Engineer 结构工程师 ME Engineer 合立讯审批/Helixun Approval 客户批准/customer Approval 制作 prepared BY 审核 checked BY 批准 Approval BY 审核 checked BY 批准 Approval BY 签章 signature 日期 Date 2026-06-17 修订履历/change Log 版本 version 修订内容 change Description 责任人 person in charge 核准 Approval BY 日期 Date 深 圳 合立讯科技有限公司 规 格 SPECIFICATION FOR APPROVAL 地址： 深圳市宝安区西乡街道铁仔路 56 号金环宇大厦 1004 室 书 1 Shenzhen HeLixun Technology Co., Ltd. Address: Room 1004, Jinhuanyu Building, 56 Tiezi Road, xixiang street, Bao 'an District, Shenzhen Antenna Type: FPC Antenna 深圳合立讯科技有限公司 产品图纸或实物图片 Drawing or Product Image 地址： 深圳市宝安区西乡街道铁仔路 56 号金环宇大厦 1004 室 3 Shenzhen HeLixun Technology Co., Ltd. Address: Room 1004, Jinhuanyu Building, 56 Tiezi Road, xixiang street, Bao 'an District, Shenzhen Unit 产品图纸或实物图片 Drawing or Product Image 地址： 深圳市宝安区西乡街道铁仔路 56 号金环宇大厦 1004 室 3 深圳合立讯科技有限公司 Shenzhen HeLixun Technology Co., Ltd. Address: Room 1004, Jinhuanyu Building, 56 Tiezi Road, xixiang street, Bao 'an District, Shenzhen Unit 客户名称 customer Name 东莞市晨新电子科技有限公司 项目名称 project Name BT-981 合立讯料号 Hel ixun P/N HLX-BT-981-V2 频段 Band 2400-2500MHZ 测试日期 Test Date 2026-06-17 测试人 Inspector 吴捷 天线测试设备简介 Antenna Test Equ ipment Introduct ion 测试天线输入特性使用 Agi lent E5071c and Agi lent 5071c 矢量网络分析仪 ； 辐射特性利用 Test of antenna input character ist ics us ing Agi lent E5071c and Agi lent 5071c vector network ana lyzer ; The rad iat ion pattern of the antenna are tested us ing the ETS star lab 3D near f ie ld Anecho ic Chamber, and the instrument is used to ag i lent8960 E5515 and Ag i lent E4438C. The test coord inates of the darkroom are as fo llows : ETS 三维近场暗室进行测试，并分别使用 CMW500 和Agilent 5071C 进行了分析。暗房的测试坐标如 射频性能测量报告 RF Performance Test Report 深圳合立讯科技有限公司 地址： 深圳市宝安区西乡街道铁仔路 56 号金环宇大厦 1004 室 下: 5 Shenzhen HeLixun Technology Co., Ltd. Address: Room 1004, Jinhuanyu Building, 56 Tiezi Road, xixiang street, Bao 'an District, Shenzhen Sequence Number Test Item equipment S parameter VSWR Agilent 5071C & Agilent 5062A OTA Test TRP&TIS Agilent 8960 E5515C& Agilent 4438C&CMW500 ETS&SATIMO Gain & EfficiencyGain & Efficiency ETS&SATIMO Agilent 5071C 深圳合立讯科技有限公司 地址： 深圳市宝安区西乡街道铁仔路 56 号金环宇大厦 1004 室 Testsystem 6 Shenzhen HeLixun Technology Co., Ltd. Address: Room 1004, Jinhuanyu Building, 56 Tiezi Road, xixiang street, Bao 'an District, Shenzhen 3.1 S11 Parameter-Log Mag Frequen cy (MHz) 2400245024802500 Log Mag -14.57-18.03-14.11-11.59 Frequen cy (MHz) 2400245024802500 VSWR 1.481.311.501.73 深圳合立讯科技有限公司 3.Test Result 3.1 S11 Parameter-VSWR 3. Test Result 地址： 深圳市宝安区西乡街道铁仔路 56 号金环宇大厦 1004 室 BT 7 Shenzhen HeLixun Technology Co., Ltd. Address: Room 1004, Jinhuanyu Building, 56 Tiezi Road, xixiang street, Bao 'an District, Shenzhen Frequen cy (MHz) 2400245024802500 Smi th(Ω) 53.7438.9433.6931.32 3.Test Result 3.1 S11 Parameter-Smi th 深圳合立讯科技有限公司 地址： 深圳市宝安区西乡街道铁仔路 56 号金环宇大厦 1004 室 8 Shenzhen HeLixun Technology Co., Ltd. Address: Room 1004, Jinhuanyu Building, 56 Tiezi Road, xixiang street, Bao 'an District, Shenzhen Frequency (MHz)Efficiency (%)Max GAIN (dBi) 2400 47.76 3.39 2410 46.80 3.27 2420 46.03 3.20 2430 45.17 2.95 2440 44.57 2.87 2450 44.88 2.84 2460 44.41 3.03 2470 43.81 3.07 2480 42.67 2.92 4 . 2 Test Result 1 Gain & Efficiency——ANT 4 . 2 Test Result 1 2D Pattern——BTANT 地址： 深圳市宝安区西乡街道铁仔路 56 号金环宇大厦 1004 室 9 Address: Room 1004, Jinhuanyu Building, 56 Tiezi Road, xixiang street, Bao 'an District, Shenzhen 4 . 2 Test Result 1 2D Pattern——BTANT 地址： 深圳市宝安区西乡街道铁仔路 56 号金环宇大厦 1004 室 10 Address: Room 1004, Jinhuanyu Building, 56 Tiezi Road, xixiang street, Bao 'an District, Shenzhen

Page 1 of 2 Report No.: LGT26F165 Appendix - Test Setup photos Set-up for Radiated Spurious Emission, Below 1GHz Set-up for Radiated Spurious Emission, Above 1GHz Page 2 of 2 Report No.: LGT26F165 Set-up for Conducted Emission
