4.0” Touch Screen DIGITAL CAMERA Instruction Manual Please read this manual carefully before use Please keep this manual safe for future reference Ver: LY01 Contents About the camera...................................................................1 Quick Start Guide...................................................................4 System Settings....................................................................10 Photo Mode & Setting...........................................................11 Video Mode & Setting...........................................................13 Other Modes.........................................................................15 Using the Wi-Fi function.........................................................16 For Your Safety.....................................................................19 Technical Notes....................................................................22 FCC Warning........................................................................23 ▶ Read this first Before operating the unit, please read this manual thoroughly, and retain it for future reference. ▶ Specification Still Image Size (Horizontal x Vertical): 64M 9248x6913(4:3); 64M 10560x5921(16:9); 48M 8000x6000(4:3); 48M 9120x5129(16:9); 36M 6928x5184(4:3); 21M 5248x3930(4:3); 21M 6144x3454(16:9); 16M 4640x3480(4:3); 12M 4000x3000(4:3); 8M 3264x2448(4:3); 5M 2592x1944(4:3) Still image format: JPEG Movie size (Horizontal x Vertical): 4K 3840x2160; 2K 2560x1440; FHD 1920X1080; HD 1280X720 Movie format: MOV 4.0 inch Touch Screen 16X digital zoom Multipoint autofocus Digital anti-shake Face detection Continuous shooting Self-timer Wifi Fuction Built-in flash Built-in microphone Built-in speaker Built-in 32MB flash memory, Up to 256GB Micro SD card. Design and specification are subject to change without notice. About the camera 1 Shutter Key Indicator light Power Key Filter switch Flash Lens Microphone Hanging rope hole Speaker Menu Key Push button Battery cover Type-C USBCard slot About the camera 2 4.0 inch Touch Screen Touchscreen operation: - Tap to select/highlight an item - Tap the selected item again to enter its submenu. - Swipe up, down, left, or right to browse the menu. About the camera 3 ▶ Inserting the battery and SD card 1. Unlock the cover lock 2. Open the battery cover 3. Insert the Battery 4. Insert the micro SD card Battery 1 3 4 To remove the memory card/ battery Memory card: push the memory card in once to eject the memory card. Battery: Slide the battery eject lever. 2 Format the memory card After inserting the card, briefly press the [Power] button to turn on the camera. The screen will display [Card is not formatted.] A pop-up window will automatically appear [Format? Yes/No] Click [Yes] Start using the camera. Quick Start Guide Card is not formatted. Format Yes No 4 ● Setting the Language ● Setting the [Macro] ● Setting the Date&Time Tap the [ ] icon in the bottom left corner → swipe left or right to find the [ ] icon → swipe up or down to find [format] → tap [format] → tap [Yes]. Tap the [ ] icon in the bottom left corner → swipe left or right to find the [ ] icon → swipe up or down to find [Language] → Click [Language] → swipe up or down to find the language you want → Click it. In photo mode, tap the [ ] icon in the bottom left corner → swipe left or right on the screen to find [Macro] →[ Macro On/ Macro Off ]→Click[Macro On] Tap the [ ] icon in the bottom left corner → swipe left or right to find the [ ] icon → swipe up or down to find [Date & Time] →Click [Date & Time] →[Year-Month-Day-Hour-Minute-Sec- ond]→ Click it.(Each click increments the number by 1; it cannot decrease. This cycle repeats continuously.) Year Month Day Cycle from 2026 to 2039 Cycle from 1 to 12 Cycle from 1 to 31 Cycle from 0 to 23 Cycle from 0 to 59 Cycle from 0 to 59 Hour Minute Second ● Format the memory card [ / Español / / Português / / Italiano / / Deutsch / English / Français ] Quick Start Guide 5 Tap the [ ] icon in the bottom left corner swipe left or right to find the [Flash] icon In the Photo mode,you can see [Flash? Off/On/Auto]; In the Video mode,you can see [Flash? On/Off] ● Quickly adjust the filter ● Setting the Filters ● Setting the Flash Click the [ ] icon in the bottom left corner You will see [Filter] Swipe up or down to find the filter you want Click it Enter the desired filter and take a photo. Quick Start Guide Press the filter switch to cycle through [ NormalRetroBlack and WhiteSepiaVividLomo SketchColored PencilsNegativeDreamySalonJapanese StyleDopamineCreamWarmCoolGothicSingle Red Singe YellowSinge BuleSinge Green ] Press the filter switch to cycle through: [Photo mode][Video mode] (Swipe once to switch) 6 ▶ Shooting still images/movies Shooting still images Quick Start Guide Using the Zoom T: Capture a bigger subject. W: Capture a wider view [White focus frame][Green focus frame] 1. Press the [M] button → swipe the screen → select [Photo Mode] to enter photo mode. 2. Half-press the shutter button to autofocus 3. Fully press the shutter button to take the photo. Shooting movies 1. Press the [M] button → swipe the screen → select [Video Mode] to enter video mode. 2. Half-press the shutter button to autofocus 3. Press the shutter button fully to start recording. 4. Press the shutter button again to stop recording. 7 Click the [ ] icon in the bottom right corner → Enter the interface: Click the [ ♥ ] icon → you can see 3 options[ Favorites Single/Favorite All/Reset]→Click [Favorites Single] to favorite this file, click [Favorite All] to favorite all files, click [Reset] to reset favorites. Click [>] to view the next file, click [<] to view the previous file. Clicking [ ] will show all 12 files at once. ▶ Viewing images ▶ Delete images ▶ Collect images Quick Start Guide [Video] [Photo] Click the [ ] icon→ you can see 2 options [Delete Single/ Delete All]→ Click [ Delete Single] to delete a single file, click [Delete All ] to delete all files. 8 ▶ Chargin…

Text truncated - open the document above for the full version.

Rev 1/26/2023 Shenzhen Corecam technology Development Limited Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 07-29-2026 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2BXAT-CDFH [Shenzhen Corecam technology Development Limited] certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. [Shenzhen Corecam technology Development Limited] certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24- 886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Device is inherently compliant based on hardware limitations or software controls. or A Software Bill of Materials (SBOM) is provided to the TCB for review, and The end-user or third parties cannot install additional software on this device. Sincerely, (Applicant signature) (Applicant printed name) Lemon feng Rev 1/26/2023 Shenzhen Corecam technology Development Limited Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 07-29-2026 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2BXAT-CDFH [Shenzhen Corecam technology Development Limited] ce8rtifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name) Lemon feng

Shenzhen Corecam technology Development Limited U.S. Agent Letter of Attestation To: Federal Communications Commission 7435 Oakland Mills Road, Columbia, MD 21046, USA Date: July 29, 2026 Ref: Attestation Statement – Part 2.911(d)(7) filing FCC ID: 2BXAT-CDFH Shenzhen Corecam technology Development Limited (“the applicant”) certifies that, as of the date of the filing of the application, CLF Import and Export Limited (“the agent”) is our designated U.S. agent for service of process for the above reference FCC ID. The applicant accepts to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. The applicant further acknowledges it is our responsibility to inform the FCC whenever the agent information changes. CLF Import and Export Limited ("the agent) understand it is the agent's obligation to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address. Designated U.S. Agent Company Name: CLF Import and Export Limited FRN: 0033489683 Address: 1312 17th Street #692, Denver, CO 80202, United States Signature: Contact Person: David Chen Tel: +1 949 254 2565 Email: [email protected] Applicant Company Name: Shenzhen Corecam technology Development Limited FRN: 0038684833 Address: #623, Shenhua university software innoation port, 71 District of Baoan, Liuxian 1st Rd., Xin'an St., Baoan Dist., Shenzhen, Guangdong, China Signature: Contact Person: Lemon feng Tel: +86-18211307641 Email: [email protected]

Shenzhen Corecam technology Development Limited Date: July 29, 2026 Product Model Number: CDFH, CD12 FCC ID: 2BXAT-CDFH To whom it may concern, Re: Product Certification Representative Authorization Letter We authorize QAI Laboratories Ltd. 3980 North Fraser Way, Burnaby B.C. Canada V5J 5K5 to act on our behalf on all matters concerning the above named equipment. This shall include the following: • Testing • Approval applications and procedures We declare that QAI Laboratories Ltd. is allowed to forward all information related to the approval project to the applied certification body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by QAI Laboratories Ltd. on our behalf shall have the same effect as acts of our own. By: Lemon feng Contact Listed on FCC Wesbite Title: Manager Email: [email protected] Telephone: +86-18211307641 On behalf of: Shenzhen Corecam technology Development Limited

Shenzhen Corecam technology Development Limited Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: July 29, 2026 Subject; Request for Confidentiality FCC ID: 2BXAT-CDFH To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure Software Security Requirements for UNII devices It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Lemon feng Title: Manager

Shenzhen Corecam technology Development Limited Model Difference Statement DATE: July 29, 2026 FCC ID: 2BXAT-CDFH Dear Sir/Madam, Added models CD12 asis of the original product CDFH The color of appearance and model name of series models listed are different from the main model, but the circuit and the electronic construction are the same, declared by the manufacturer. Sincerely, Name: Lemon feng Title: Manager Company name: Shenzhen Corecam technology Development Limited Address: #623, Shenhua university software innoation port, 71 District of Baoan, Liuxian 1st Rd., Xin'an St., Baoan Dist., Shenzhen, Guangdong, China

Report No: SSP26050419-1E FCC ID: 2BXAT-CDFH Annex of Test Report Annex A. EUT External Photos Model: CDFH EUT View 1 EUT View 2 Report No: SSP26050419-1E FCC ID: 2BXAT-CDFH Annex of Test Report EUT View 3 EUT View 4 Report No: SSP26050419-1E FCC ID: 2BXAT-CDFH Annex of Test Report EUT View 5 EUT View 6 Report No: SSP26050419-1E FCC ID: 2BXAT-CDFH Annex of Test Report EUT View 7 EUT View 8

Report No: SSP26050419-1E FCC ID: 2BXAT-CDFH Annex of Test Report Annex D. Label and Information FCC Label Sample Label Size:2cm*1cm FCC Label Specifications Text is Black in color and is justified. Labels are printed in indelible ink on permanent adhesive backing or silk-screened onto the EUT or shall be affixed at a conspicuous location on the EUT. Where the EUT is constructed in two or more sections connected by wires and marketed together, the above statement is required to be affixed only to the main control unit. When the EUT is so small or for such use that it is not practicable to place the statement on it, the above information shall be placed in a prominent location in the instruction manual or pamphlet supplied to the user or, alternatively, shall be placed on the container in which the device is marketed. FCC Label Location

Report No: SSP26050419-1E FCC ID: 2BXAT-CDFH Annex of Test Report Annex B. EUT Internal Photos Model: CDFH EUT Internal View 1 EUT Internal View 2 Report No: SSP26050419-1E FCC ID: 2BXAT-CDFH Annex of Test Report EUT Internal View 3 EUT Internal View 4 Report No: SSP26050419-1E FCC ID: 2BXAT-CDFH Annex of Test Report EUT Internal View 5 EUT Internal View 6 SMD Antenna

FCC ID: 2BXAT-CDFH RF Exposure Evaluation According to KDB 447498 D01 General RF Exposure Guidance v06 and part 2.1093，Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition(s), listed below, is (are) satisfied. For 100 MHz to 6 GHz and test separation distances ≤ 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison Here, The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. For 2.4GWiFi Max Conducted Power(dBm) Tune-up Power(dBm) Max Tune-up Power(dBm) Max Power(mW) Frequency(MHz) Min. distance(mm) Calc. thresholds limit 5.96 5(±1) 6 3.981 2462 5 1.227 3.0 So a SAR test is not required

Report No: SSP26050419-1E FCC Test Report Page 1 of 50 FCC TEST REPORT FCC ID: 2BXAT-CDFH Report No. : SSP26050419-1E Applicant : Shenzhen Corecam technology Development Limited Product Name : Digital Still Camera Model Name : CDFH Test Standard : FCC Part 15.247 Date of Issue : 2026-07-21 Shenzhen CCUT Quality Technology Co., Ltd. 1F, Building 35, Changxing Technology Industrial Park, Yutang Street, Guangming District, Shenzhen, Guangdong, China; (Tel.:+86-755-23406590 website: www.ccuttest.com) This test report is limited to the above client company and the product model only. It may not be duplicated without prior permitted by Shenzhen CCUT Quality Technology Co., Ltd. Report No: SSP26050419-1E FCC Test Report Page 2 of 50 Test Report Basic Information Applicant..................................: Shenzhen Corecam technology Development Limited Address of Applicant...............: #623, Shenhua university software innoation port, 71 District of Baoan, Liuxian 1st Rd., Xin'an St., Baoan Dist., Shenzhen, Guangdong, China Manufacturer..........................: Shenzhen Corecam technology Development Limited Address of Manufacturer........: #623, Shenhua university software innoation port, 71 District of Baoan, Liuxian 1st Rd., Xin'an St., Baoan Dist., Shenzhen, Guangdong, China Product Name.........................: Digital Still Camera Brand Name.............................: - Main Model..............................: CDFH Series Models..........................: CD12 Test Standard..........................: FCC Part 15 Subpart C KDB 558074 D01 15.247 Meas Guidance v05r02 ANSI C63.4-2014 ANSI C63.10-2020 + Cor. 1-2023+C63.10a-2024 + Errata to C63.10a-2024 Date of Test .............................: 2026-05-23 to 2026-07-10 Test Result...............................: PASS Tested By ................................: (Coke Huang) Reviewed By............................: (Lorzix Luo) Authorized Signatory............: (Lahm Peng) Note : This test report is limited to the above client company and the product model only. It may not be duplicated without prior permitted by Shenzhen CCUT Quality Technology Co., Ltd.. All test data presented in this test report is only applicable to presented test sample. Report No: SSP26050419-1E FCC Test Report Page 3 of 50 CONTENTS 1. General Information ....................................................................................................................................................5 1.1 Product Information .............................................................................................................................................5 1.2 Test Setup Information..........................................................................................................................................6 1.3 Compliance Standards ...........................................................................................................................................7 1.4 Test Facilities ........................................................................................................................................................7 1.5 List of Measurement Instruments ..........................................................................................................................8 1.6 Measurement Uncertainty .....................................................................................................................................9 2. Summary of Test Results ........................................................................................................................................... 10 3. Antenna Requirement ............................................................................................................................................... 11 3.1 Standard and Limit.............................................................................................................................................. 11 3.2 Test Result .......................................................................................................................................................... 11 4. Conducted Emissions ................................................................................................................................................ 12 4.1 Standard and Limit.............................................................................................................................................. 12 4.2 Test Procedure.................................................................................................................................................... 12 4.3 Test Data and Results .......................................................................................................................................... 13 5. Radiated Emissions ................................................................................................................................................... 16 5.1 Standard and Limit.............................................................................................................................................. 16 5.2 Test Procedure.................................................................................................................................................... 16 5.3 Test Data and Results .......................................................................................................................................... 18 6. Band-edge Emissions(Radiated) ............................................................................................................................... 22 6.1 Standard and Limit.............................................................................................................................................. 22 6.2 Test Procedure..............................................................................................................................................…

Text truncated - open the document above for the full version.

CA-C01 Specification Document Guangzhou Cambrian Electronic Technology Co., Ltd. Room 1119, 1st Floor, Hongda Commercial and Creative Park, No. 96, Yuanxiang Road, Yunpu Street, Huangpu District, Guangzhou City CA-C01_V02 1 SMD Antenna Specification Document CrossAir TM SMD The antenna series complies with the RoHS regulations. PN:CA-C01 2.4 GHz ISM band antenna CA-C01_V02 2 Characteristics 1.1. A small-sized SMD surface mount antenna with a size of only 3.2 X 1.6 X 0.4 mm³. 2. Low energy loss and high antenna efficiency. 3. High stability under temperature and humidity variations. Application 1.1. Antenna application for 2.4GHz ISM frequency band. 2. Bluetooth, wireless, and smart home applications. Structure 1、$QWHQQDIHHGHQG 2、$QWHQQDZHOGLQJIL[LQJHQG 3、)HHGLGHQWLILFDWLRQPDUN Size 7KUHHYLHZGUDZLQJSymbolSize(mm) L3.2±0.1 w1.6±0.1 T0.4±0.05 a0.6±0.1 Guangzhou Cambrian Electronic Technology Co., Ltd. Room 1119, 1st Floor, Hongda Commercial and Creative Park, No. 96, Yuanxiang Road, Yunpu Street, Huangpu District, Guangzhou City CA-C01_V02 3 Electrical characteristics CA-C01Specification 工作频率范围Working Frequency2450±50MHz 带宽Band Width >100MHz 阻抗Impedance50Ω 增益Gain(dBi) 2 驻波比VSWR <2 工作温度Operation Temperature-40°C~+85°C 可承受功率Power Capacity 3W The working frequency needs to be 2.45GHz, which can be achieved through impedance matching devices. Antenna pad and trace design PCB schematic reference design PCB Reference Design Guangzhou Cambrian Electronic Technology Co., Ltd. Room 1119, 1st Floor, Hongda Commercial and Creative Park, No. 96, Yuanxiang Road, Yunpu Street, Huangpu District, Guangzhou City CA-C01_V02 4 Match the device values 串联器件Series 1 Resistor 0Ω 并联器件Shunt 1 Vacant NC 串联器件Series 2 High-frequency inductor 3nh 并联器件Shunt 2 Vacant NC Guangzhou Cambrian Electronic Technology Co., Ltd. Room 1119, 1st Floor, Hongda Commercial and Creative Park, No. 96, Yuanxiang Road, Yunpu Street, Huangpu District, Guangzhou City CA-C01_V02 5 Antenna test on the test board (board thickness 1.0mm) Antenna S11 characteristics Antenna VSWR characteristics Guangzhou Cambrian Electronic Technology Co., Ltd. Room 1119, 1st Floor, Hongda Commercial and Creative Park, No. 96, Yuanxiang Road, Yunpu Street, Huangpu District, Guangzhou City CA-C01_V02 6 Efficiency and radiation map The performance parameters such as efficiency, radiation pattern, gain, etc. were obtained based on the design of the test board. The specification and characteristic test data of the CA-C01 antenna were derived from the size of the test PCB board and the test direction as shown in the figure below. The following data were obtained after the completion of the ETS 3D microwave anechoic chamber test. + Gain and efficiency Bandwidth2.4G-2.5GHz 峰值增益 Peak Gain 2dBi 带内平均增益 Average Gain across the band 1.6dBi 带内增益范围 Gain Range across the band 0.9dBi~2dBi 峰值效率Peak Efficiency 41.3% 带内平均效率 Average Efficiency across the band 40.1% Z Y X Guangzhou Cambrian Electronic Technology Co., Ltd. Room 1119, 1st Floor, Hongda Commercial and Creative Park, No. 96, Yuanxiang Road, Yunpu Street, Huangpu District, Guangzhou City CA-C01_V02 7 带内效率范围 Efficiency Range across the band 37.8%~41.3% Theta @2.45 GHz Phi @2.45 GHz Total @2.45 GHz Welding conditions The typical welding specifications for reliable and undamaged results are shown in the following figure: Guangzhou Cambrian Electronic Technology Co., Ltd. Room 1119, 1st Floor, Hongda Commercial and Creative Park, No. 96, Yuanxiang Road, Yunpu Street, Huangpu District, Guangzhou City CA-C01_V02 8 包装 Guangzhou Cambrian Electronic Technology Co., Ltd. Room 1119, 1st Floor, Hongda Commercial and Creative Park, No. 96, Yuanxiang Road, Yunpu Street, Huangpu District, Guangzhou City CA-C01_V02 9 Plastic tape specification (unit: mm) IndexAoBo ΦD TW Dimension (mm) 2.0±0.13.6±0.1 1.55±0.05 0.9±0.18.2±0.1 IndexEFPoP1P2 Dimension (mm) 1.75±0.1 3.2±0.14.0±0.14.0±0.12.0±0.1 Roll diameter IndexABC Dimension(mm)1786013.5 Standard quantity: 3000 PCS per tray. Storage environment The product should be stored under the following conditions: Temperature: -10°C to +40°C Humidity: 30% to 70% relative humidity The product should not be placed in areas exposed to corrosive gases such as sulfur. Chlorine or acids may cause the product's electrodes to oxidize, resulting in reduced weldability. The product should be placed in a toolbox and protected from moisture and dust. The product should be stored in a warehouse and protected from heat, vibration, and direct sunlight. The product should be stored in a sealed environment. Guangzhou Cambrian Electronic Technology Co., Ltd. Room 1119, 1st Floor, Hongda Commercial and Creative Park, No. 96, Yuanxiang Road, Yunpu Street, Huangpu District, Guangzhou City

Report No: SSP26050419-1E FCC ID: 2BXAT-CDFH Annex of Test Report Annex C. Test Photos Conducted Emission Test View 1 Radiated Emission Test View Below 1GHz Report No: SSP26050419-1E FCC ID: 2BXAT-CDFH Annex of Test Report Radiated Emission Test View Above 1GHz
