A3L05SAM1Digital Still Camera

Digital Camera / Camcorder Owner’s Instruction BookBefore operating the unit, please read thisInstruction Book thoroughly, and retain it forfuture reference. AF Auto Focus CCD Charge Coupled Device LCD Liquid Crystal Display SC-MS10/MS11/MS15 ENGLISH Use only approved battery packs.Otherwise there is a danger of overheating, fire or explosion.Samsung is not responsible for problems occurring due to using unapproved batteries. US PATENT 4415844 00934C SC-MS10 USA~007 9/30/05 10:54 AM Page C ENGLISH Notices and Safety Instructions Safety Instructions This symbol is intended to alert the user to the presence ofuninsulated “dangerous voltage” within the product’s enclosurethat may be of sufficient magnitude to constitute a risk of electricshock to persons.This symbol is intended to alert the user to the presence ofimportant operating and maintenance (servicing) instructions inthe literature accompanying the appliance. WARNING - To Reduce The Risk Of Fire Or Electric Shock, Do Not Expose This Apparatus To Rain Or Moisture. 1. Read these instructions.2. Keep these instructions.3. Heed all warnings.4. Follow all instructions.5. Do not use this apparatus near water.6. Clean only with dry cloth.7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9. Do not defeat the safety purpose of the polarized or grounding type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plugdoes not fit into your outlet. Consult an electrician for replacement of the obsolete outlet. 10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the pointwhere they exit from the apparatus. 11. Only use attachments/accessories specified by the manufacturer. 12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold withthe apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. 13. Unplug this apparatus during lightning storms or when unused for long periods of time. 14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been moisture, does not operate normally, or has been dropped. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OFELECTRIC SHOCK, DO NOT REMOVECOVER (OR BACK). NO USER-SERVICEABLE PARTSINSIDE, REFER SERVICING TOQUALIFIED SERVICE PERSONNEL. CAUTION Shock Hazard Marking and Associated Graphical Symbols Explanation of Safety Related Symbols SAM_00934C_SEA_SAFETY 9/30/05 11:01 AM Page 100 ENGLISH Notices and Safety Instructions15. The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall beplaced on the apparatus. 16. VENTILATION: Slots and openings in the cabinet are provided for ventilation to ensure reliable operation of the CAMCORDER and to protect it from overheating. These openings must not be blocked or covered. Never place your CAMCORDER on a bed, sofa, rug, or other similar surface: on or near a radiator or heat register. This CAMCORDER should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is providedor the manufacturer’s instructions have been adhered to. 17. POWER SOURCES: The CAMCORDER should be operated only from the type of power source indicated on the label.If you are not sure of the type of power supply at your home, consult your appliance dealer or local power company. A CAMCORDER is intended to be operated from battery power, or other sources, refer to the operating instructions. 18. GROUNDING OR POLARIZATION: This CAMCORDER may be equipped with either a polarized 2-wire AC line plug (a plug having one blade wider than the other)or a 3-wire grounding type plug, a plug having a third (grounding)pin. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug still fails to fit, contact your electrician to replace your outlet. Do not defeat the safety purposeof the polarized plug. 19. POWER-CORD PROTECTION: Power-supply cords should be routed so that they are not likely tobe walked on or pinched by items placed upon or against them, paying particular attention to cords or plugs, convenient receptacles, and the point where they exit from the unit. 20. OUTDOOR ANTENNA GROUNDING: If an outside antenna or cable system is connected to the CAMCORDER, be sure the antenna or cable system is groundedto provide some protection against voltage surges and built-up static charges, Section 810 of the National Electrical Code, ANSI/NFPA No. 70-1984, provides information with respect to proper grounding of the mast and supporting structure, groundingof the lead-in wire and supporting structure, grounding of the mastand supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding to conductors, locationof antenna-discharge unit, connection to grounding electrodes and requirements for the grounding electrode.See figure below. SAM_00934C_SEA_SAFETY 9/30/05 11:01 AM Page 101 ENGLISH Notices and Safety Instructions21. LIGHTNING: For added protection of this CAMCORDER during a lightning storm or when it is left unattended and unused for long periods oftime, unplug it from the wall outlet and disconnect the antenna orcable system. This will prevent damage to the CAMCORDER due to lightning and power-line surges. 22. POWER LINES: An outside antenna system should not be located in the vicinity ofoverhead power lines or other electric light or power circ…

Text truncated - open the document above for the full version.

M3-MML (BM92386) SDT SDTI MCLK LRCK SCL K ITU-656 LINE IN MAIN MICOM EORFN GLDJUDP C L K / D A T A SCLK CS DO DI H-SYNCV-SYNC 27M CLK GPE FUNCTION RESET D D O N 3V R E G CLK/CS/DATA 3.1V 3.1V 1.8V 3.1V 12.0V15.0V 3.1V 12M X-TAL 24.5M X-T A 54 M RESET BAT CUR CHG CHG 10bit SIO ( 32Mb NOR FLASH S29PL032J60BF 16bit FD[0:15],FA[1:15],FPINT,FRDY,FRDX,FWEX,FCS6X CS 27M CLK OFDM & CH RS_ Decoder RF H.264 Codec Scaler DDR SDRAM TS DEMUX ITU-R601 Output MPEG2 TS CLK/DATA ANT CS X-TAL 3.1V 2.5V 3.1V 1.2V 필요전원 LCD 12V BL,CCD 15V CCD -7.5 SYSTEM 3.1V DSP 1.8V DMB(RF) 1.2V STROBO AUDIOMOTOR 5V DDR,DMB 2.5V CLK/DATA CS

Page : 22 of 22 Project NO. :LBE052092 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory.

Page : 1 of 22 Project NO. :LBE052092 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. EMC Test Report According to FCC Part 15 Subpart B Project No. LBE052092 Equipment under Test Applicant Samsung Electronics Co., Ltd Address 416 Maetan3-Dong,Yeongtong-Gu,Suwon-Si,Gyeonggi-Do, Korea,443-742 Kind of Product Digital Still Camera Model Name SC-MS15BL Manufacturer Samsung Electronics Co., Ltd Brand Name SAMSUNG Variant Model See Page 3 FCC ID A3L05SAM1 Date of Test August 24 ~ 25, 2005 Issued Date September 5, 2005 Name/Position Signature Tested by Tae Young, Jang Test Engineer Reviewed by No Cheon, Park Manager of EMC Lab. Authorized by Seung Kyu, Cha Chief of EMC Lab. 1. This test reports does not constitute an endorsement by NIST/NVLAP or U.S Government. 2. This test report is to certify that the tested device properly complies with the requirements of FCC Rules and Regulations Part 15 Subpart B Unintentional Radiators. All tests necessary to show compliance to the requirements were and these results met the specifications requirement. This laboratory is registered by the NIST/NVLAP, U.S.A. The test reported herein have been performed in accordance with its terms of registration. Page : 2 of 22 Project NO. :LBE052092 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Table of Contents 1. General Information 1.1 Basic Information related Product 1.2 Detail Information related Product 1.3 Test Configuration 1.4 EUT Operating Conditions 1.5 Applied Standard 1.6 Test Facility 2. Summary of Test Results 3. Description of individual tests 3. 1 Conducted Emission 3. 2 Radiated Emission 4. Appendix A 4.1 Test Photography 4.2 EUT Photography Page : 3 of 22 Project NO. :LBE052092 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 1. General Information 1.1 Basic Information related Product Applicant Samsung Electronics Co., Ltd Model name SC-MS15BL Applicant Address 416 Maetan3- Dong, Yeongtong-Gu, Suwon-Si, Gyeonggi-Do, Korea, 443-742 Contact Person Jae Soon, Kang Kind of product Digital Still Camera Valiant list SC-MS10BL, SC-MS10S, SC-MS10B, SC-MS10R SC-MS11BL, SC-MS11S, SC-MS11B, SC-MS11R SC-MS15S, SC-MS15B, SC-MS15R Manufacturer Samsung Electronics Co., Ltd Page : 4 of 22 Project NO. :LBE052092 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 1.2 Detail Information related Product Specification Movie Format MPEG4 Profile SP Signal Format NTSC/PAL(Factory option) Dimension(WxHxD) 90 * 55 * 18.5 Weight(Net) 120g Power Consumption LCD On / LCD Off 2.2W Size 2.5" Trans Pixel 115K Resolution 640*240 Bright Adjust O Color Adjust O Tint Adjust X Rotation Angle X LCD Monitor Mirror X Internal Memory 64M/128M/256/512M Memory Slot Mini SD Storage HDD None Type Li-ion (Detachable) Capacity 820mAH*3.7V Battery Extra Battery X Light X Flash Strobe(GN 4) Speaker O (Mono) Mic MONO Remote X View Finder X Shoe X Tripod O Page : 5 of 22 Project NO. :LBE052092 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 1.3 Operating Mode and Condition The system was configured for testing in typical fashion use. Cables were attached to each of the available I/O Ports. Where applicable, peripherals were attached to the I/O cables. The mode of operation utilized for testing was selected to best simulate typical EUT use. - External & Internal Memory : USB - PC Camera : USB AV operating modes were covered by another report. 1.4 Equipment Modifications No equipment modifications were required. 1.5 Test Configuration Used EUT and Peripherals Seq Device Model Name Serial # Maker FCC ID A Digital Still Camera SC-MS15BL - SAMSUNG A3L05SAM1 B Adapter SAM-PJ 6CAY700109 SAMSUNG DOC C Note PC SP40 SKU29REXB00004TSAMSUNG DOC D Adapter(Note PC) API3AD05 BA44-00190A SAMSUNG DOC E Printer ML-1740 BABX820386E SAMSUNGA3LML-1710P F Ear-Phone - - - - Used Cable Description Connect Cable Length [m] Shielded [Y/N] Remark 1 Power 1.8 No 2 Power 1.8 No 3 Power 1.8 No 4 USB 1.7 No 5 Ear-Phone 1.7 No 6 Parallel (Printer) 1.8 Yes Page : 6 of 22 Project NO. :LBE052092 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Block Diagram 1.6 Applied Standards List Product or Generic Standards Basic Standards FCC Part15 Subpart B ANSI C63.4 : 2003 Page : 7 of 22 Project NO. :LBE052092 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 1.7 Test Facility General Information The sites are constructed in conformance with the requirements of ANSI C63.4 and CISPR 16-1, 16-2. This EMC Testing Lab. is accredited by Korea Laboratory Accreditation Scheme(KOLAS) which signed the International Laboratory Accreditation Cooperation (ILAC) Mutual Recognition Arrangement (MRA) for the above test item(s) and test method(s). This Lab. is operated as testing laboratory in accordance with the requirements of ISO/IEC 17025:1998. Accreditation and Listing Uncertainty Test Item Expanded Uncertainty Conducted Emission +/-3.30 Radiated Emission +/-5.09 (According to NAMAS Pub.NIS81) Page : 8 of 22 Project NO. :LBE052092 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 2. Summary of Test Results Result : PASS The equipment under test(EUT) has been found to comply with the applied standards. Test Name Applied Standard Result Electromagnetic Emission Test 3.1 Conducted Emission FCC Part15 Subpart B Complied 3.2 Radiated Emission FCC Part15 Subpart B Complied Page : 9 of 22 Project NO. :LBE052092 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 3. Description of Individual Tests 3.1 Conducted Emission Test Information Test Engineer Tae …

Text truncated - open the document above for the full version.

Page : 15 of 22 Project NO. :LBE052092 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 4. Appendix A 4.1 Test Photography Picture 1. Conducted Emission (Front) Picture 2. Conducted Emission (Side) Page : 16 of 22 Project NO. :LBE052092 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Picture 3. Radiated Emission (Front) Picture 4. Radiated Emission (Rear)
