A3LAT61L6RDLP TV Monitor

FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §§ 2.925 & §§ 15.19 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE)

Page : 1 of 17 Samsung EMC Testing and Certification Laboratory Project NO. :LBE050659 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. EMC Test Report According to FCC Part 15 Subpart B Project No. LBE050659 Equipment under Test Address 416 Maetan3-Dong,Yeongtong-Gu,Suwon-Si,Gyeonggi-Do, Korea,443-742 Product Name DLP TV Monitor Model Name AT61L6 Manufacturer SAMSUNG Brand Name SAMSUNG Variant Model See Page 3 FCC ID A3LAT61L6R Date of Test March 28 ~ 31, 2005 Issued Date April 6, 2005 Name/Position Signature Tested by Tae Young, Jang Test Engineer Reviewed by No Cheon, Park Manager of EMC Lab. Authorized by Seung Kyu, Cha Chief of EMC Lab. 1. This test reports does not constitute an endorsement by NIST/NVLAP or U.S Government. 2. This test report is to certify that the tested device properly complies with the requirements of FCC Rules and Regulations Part 15 Subpart B Unintentional Radiators. All tests necessary to show compliance to the requirements were and these results met the specifications requirement. This laboratory is registered by the NIST/NVLAP, U.S.A. The test reported herein have been performed in accordance with its terms of registration. Page : 2 of 17 Samsung EMC Testing and Certification Laboratory Project NO. :LBE050659 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Table of Contents 1. General Information 1.1 Basic Information related Product 1.2 Detail Information related Product 1.3 EUT Operating Conditions 1.4 Equipment Modifications 1.5 Test Configuration 1.6 Applied Standards 1.7 Test Facility 2. Summary of Test Results 3. Description of individual tests 3.1 Conducted Emission 3.2 Radiated Emission 4. Appendix A 4.1 Test Photography 4.2 EUT Photography Page : 3 of 17 Samsung EMC Testing and Certification Laboratory Project NO. :LBE050659 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 1. General Information 1.1 Basic Information related Product Applicant Samsung Electronics Co., Ltd Model name AT61L6 Applicant Address 416 Maetan3- Dong, Yeongtong-Gu, Suwon-Si, Gyeonggi-Do, Korea, 443-742 Contact Person Chang Young, Choi Kind of product DLP TV Monitor Valiant list None Manufacturer Samsung Electronics Co., Ltd 1.2 Detail Information related Product Specification Item(s) Description Power Supply AC 110 ~ 120V, 60Hz Maximum Resolution 1024 X 768 Horizontal Frequency 60.023KHz Vertical Frequency 75.029Hz Page : 4 of 17 Samsung EMC Testing and Certification Laboratory Project NO. :LBE050659 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 1.3 Operating Mode and Condition The system was configured for testing in typical fashion use. Cables were attached to each of the available I/O Ports. Where applicable, peripherals were attached to the I/O cables. The mode of operation utilized for testing was selected to best simulate typical EUT use. - PC Analog In - DVI In 1.4 Equipment Modifications No equipment modifications were required. Page : 5 of 17 Samsung EMC Testing and Certification Laboratory Project NO. :LBE050659 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 1.5 Test Configuration Used EUT and Peripherals Seq Device Model Name Serial # Maker FCC ID A DLP TV Monitor AT61L6 - SAMSUNG A3LAT61L6R B Personal Computer M6050 812092FRCO2822SAMSUNG DoC C Printer ML-1740 BABX820386E SAMSUNG A3LML-1740P D USB Keyboard SDM4510UH 4M037682 SAMSUNGDoC E PS/2 Mouse P801 03024123 SAMSUNGDoC Port Description Connect Cable Length [m] Shielded [Y/N] Remark 1 Power 1.5 No to the Mains 2 Power(For PC) 1.5 No to the Mains 3 Power(For Printer) 1.5 No to the Mains 4 Ant 1 in 1.5 Yes Termination 5 Ant 2 in 1.5 Yes Termination 6 RF out 1.5 Yes Termination 7 Composite 1 in 1.5 No Termination 8 Composite 2 in 1.5 No Termination 9 Composite 3 in 1.5 No Termination 10 S-video 1 in 1.5 No Termination 11 S-video 2 in 1.5 No Termination 12 S-video 3 in 1.5 No Termination 13 Component 1 in 1.5 No Termination 14 Component 2 in 1.5 No Termination 15 PC audio in 1.5 No Termination 16 DVI audio in 1.5 No Termination 17 PC Analog in 1.5 Ye s To the PC 18 PC DVI in 1.5 Ye s To the PC 19 Composite out 1.5 No Termination 20 HDMI 1.5 Ye s Termination 21 PS/2 Cable 1.2 No To the PC 22 USB Cable 1.2 No To the PC Page : 6 of 17 Samsung EMC Testing and Certification Laboratory Project NO. :LBE050659 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Block Diagram Page : 7 of 17 Samsung EMC Testing and Certification Laboratory Project NO. :LBE050659 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 1.6 Applied Standards List Applied Standards Test Procedure FCC Part15 Subpart B ANSI C63.4 : 2003 1.7 Test Facility General Information The sites are constructed in conformance with the requirements of ANSI C63.4 and CISPR 16-1, 16-2. This EMC Testing Lab. is accredited by Korea Laboratory Accreditation Scheme(KOLAS) which signed the International Laboratory Accreditation Cooperation (ILAC) Mutual Recognition Arrangement (MRA) for the above test item(s) and test method(s). This Lab. is operated as testing laboratory in accordance with the requirements of ISO/IEC 17025:1998. Accreditation and Listing Uncertainty Test Item Expanded Uncertainty Conducted Emission 1.64 Radiated Emission 5.09 (According to NAMAS Pub.NIS81) Page : 8 of 17 Samsung EMC Testing and Certification Laboratory Project NO. :LBE050659 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 2. Summary of Test Results Result : PASS The equipment under test(EUT) has been found to comply with the applied standards. Test Name Applied Standard Result Electromagneti…

Text truncated - open the document above for the full version.

Page : 15 of 17 Samsung EMC Testing and Certification Laboratory Project NO. :LBE050659 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 4. Appendix A 4.1 Test Photography Picture 1. Conducted Emission Picture 2. Radiated Emission (front view) Page : 16 of 17 Samsung EMC Testing and Certification Laboratory Project NO. :LBE050659 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Picture 3. Radiated Emission (rear view)
