A3LHLP5663WDLP Projection TV

FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §§ 2.925 & §§ 15.19 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE)

Page : 1 of 20 Samsung EMC Testing and Certification Laboratory Project NO. :LBE040857 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. EMC Test Report According to FCC Part 15 Subpart B Project No. LBE040857 Equipment under Test Address 416 Maetan3-Dong,Yeongtong-Gu,Suwon-City,Gyeonggi-Do, Korea,443-742 Product Name DLP PROJECTION TV Model Name AT56L3 Manufacturer SAMSUNG Brand Name SAMSUNG Variant Model See Page 3 Date of Test April 30, 2004 Issued Date May 03, 2004 Name/Position Signature Tested by Kyung Chul,Min Test Engineer Reviewed by No Cheon, Park Manager of EMC Lab. Authorized by Kyu Baek, Chung Chief of EMC Lab. 1. This test reports does not constitute an endorsement by NIST/NVLAP or U.S Government. 2. This test report is to certify that the tested device properly complies with the requirements of FCC Rules and Regulations Part 15 Subpart B Unintentional Radiators. All tests necessary to show compliance to the requirements were and these results met the specifications requirement. This laboratory is registered by the NIST/NVLAP, U.S.A. The test reported herein have been performed in accordance with its terms of registration. NVLAP LAB CODE 200623-0 Page : 2 of 20 Samsung EMC Testing and Certification Laboratory Project NO. :LBE040857 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Table of Contents 1. General Information 1.1 Basic Information related Product 1.2 Detail Information related Product 1.3 Test Configuration 1.4 EUT Operating Conditions 1.5 Applied Standard 1.6 Test Facility 2. Summary of Test Results 3. Description of individual tests 3. 1 Conducted Emission 3. 2 Radiated Emission 4. Appendix A 4.1 Test Photography 4.2 EUT Photography Page : 3 of 20 Samsung EMC Testing and Certification Laboratory Project NO. :LBE040857 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 1. General Information 1.1 Basic Information related Product Applicant Samsung Electronics Co. Ltd; Model name AT56L3 Applicant Address Samsung Electronics Co. Ltd; 416 Maetan3- Dong, Yeongtong-Gu, Suwon-City, Gyeonggi-Do, Korea, 443-742 Contact Person Kyung Chul,Min Kind of product DLP PROJECTION TV Valiant list None Manufacturer Samsung Electronics Co.Ltd; New / Alternative / Permissive change Information This report is original report # 1.2 Detail Information related Product Specification Item(s) Description Model Name AT56L3 Product Name DLP Projection TV FCC ID A3LHLP5663W Resolution 1280 * 720 Horizontal Frequency 60 kHz Vertical Frequency 75 Hz Page : 4 of 20 Samsung EMC Testing and Certification Laboratory Project NO. :LBE040857 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 1.3 Operating Mode and Condition The system was configured for testing in typical fashion use. Cable were attached to each of the available I/O Ports. The mode of operation utilized for testing was selected to best simulate typical EUT use. - Digital Video In - PC Analog In 1.4 Equipment Modifications No equipment modifications were required. Page : 5 of 20 Samsung EMC Testing and Certification Laboratory Project NO. :LBE040857 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 1.5 Test Configuration Used EUT and Peripherals Seq Device Model NameSerial # Maker Note A DLP Projection TV AT56L3 - SAMSUNG EUT B Desktop PC M6320 625792GR301193 SAMSUNG C Printer K10158 CLG001000275 Canon D Adapter K30088 CLG001000275 Canon E PS/2 Keyboard SKR-2283S 7EAEO22707 SEJIN F PS/2 Moust OMS3PB OMS3PBGGDRT0204029666 SAMSUNG Used Cable Description Connect Cable Length [m] Shielded [Y/N] Remark 1 Power 1.7 No For EUT 2 Power 1.5 No For PC 3 Power 1.5 No For Printer 4 PS/2 1.5 No For Keyboard 5 PS/2 1.5 No For Mouse 6 Parallel (Printer) 1.5 Yes - 7 DVI 1.5 Yes - 8 PC Analog In 1.5 Yes - 9 RF In 1.5 Yes - 10 AV1 In 1.5 No - 11 AV2 In 1.5 No - 12 AV Out 1.5 No - 13 Component In1 1.5 No - 14 Component In2 1.5 No - 15 DVI Audio In 1.5 No - 16 PC Audio In 1.5 No - 17 S-Video In 2 1.5 No - 18 AV3 In 1.5 No - 19 S-Video In3 1.5 No - 20 Page : 6 of 20 Samsung EMC Testing and Certification Laboratory Project NO. :LBE040857 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Block Diagram Page : 7 of 20 Samsung EMC Testing and Certification Laboratory Project NO. :LBE040857 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 1.6 Applied Standards List Product or Generic Standards Basic Standards FCC Part15 Subpart B ANSI 63.4 : 2000 Page : 8 of 20 Samsung EMC Testing and Certification Laboratory Project NO. :LBE040857 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 1.7 Test Facility General Information The sites are constructed in conformance with the requirements of ANSI C63.4 and CISPR 22, 16-1, 16-2, 11. This EMC Testing Lab. is accredited by Korea Laboratory Accreditation Scheme(KOLAS) which signed the International Laboratory Accreditation Cooperation (ILAC) Mutual Recognition Arrangement (MRA) for the above test item(s) and test method(s). This Lab. is operated as testing laboratory in accordance with the requirements of ISO/IEC 17025:1998. Accreditation and Listing Uncertainty Test Item Expanded Uncertainty Radiated Disturbance 5.09 Disturbance voltage at the mains terminals 1.64 (According to NAMAS Pub.NIS81) Page : 9 of 20 Samsung EMC Testing and Certification Laboratory Project NO. :LBE040857 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 2. Summary of Test Results Result : PASS The equipment under test(EUT) has been found to comply with the applied standards. Test Name Applied Standard …

Text truncated - open the document above for the full version.

Page : 18 of 20 Samsung EMC Testing and Certification Laboratory Project NO. :LBE040857 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 4. Appendix A 4.1 Test Photography Picture 1. Conducted Emission (Front) Picture 2. Conducted Emission (Rear) Page : 19 of 20 Samsung EMC Testing and Certification Laboratory Project NO. :LBE040857 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Picture 3. Radiated Emission (Front) Picture 4. Radiated Emission (Rear)
