A3LHMX-S16BNDIGITAL CAMCORDER

User Manual HMX-S15BN/HMX-S16BN High Defi nition Digital Camcorder www.samsung.com/register ii 3.5” Wide Touch Screen This camcorder adopts 3.5” wide touch LCD supporting 1.15 million pixels which enables you to record videos and photos in sharp color and image. And it also provides an enhanced LCD correction that enables you to make recordings while monitoring the image clearly in a bright sunlight. Equipped with SSD (Solid State Drive) internal memory (HMX-S15/S16 only) This camcorder is equipped with an internal SSD flash memory. The SSD memory features a quick booting and response speed which is favorable to instant imaging. Unlike a shaky or sensitive HDD (Hard Disk Drive) camcorder, it is very stable for most of the cases. The SSD memory causes extremely low noise with a high endurance, and its low power consumption helps you manage the battery more efficiently. Simple With Fingertips! User-Friendly Touch Screen If you want to focus on a certain point while recording, simply tap a desired point. Optimized to the tapped point, it enables you to make recording in a professional level with simple operations. With the enhanced touch screen-based interface, you can make recording in simple operations without knowing the complex menu structure. Sharp & Vivid 1920 x 1080 Full HD! It can reproduce the best-ever quality comparing the capacity using the latest H.264 codec. You can make recording of vivid images in the Full HD quality, and enjoy full HD videos (with no loss of quality) via the mini HDMI connection. Photos in 10 million pixels Featured by Samsung’s pixel rising technology, it reproduces a high definition still image in great color reproduction. You can enjoy a high definition video of 10 million pixels without using a separate digital camera. WiFi instant sharing wherever you are (HMX-S15/S16 only) The WiFi wireless communication technology enables you to share videos and photos on the spot wherever taken. With DLNA, you can transfer and play videos and photos in wireless connection with a home networking device such as TV or PC. key features of your full HD camcorder iii Self-Decision on Situation! Smart Auto This camcorder automatically recognizes a recording condition and optimizes itself to the scene, which enables a novice to make a quick recording. Catch the sound! Internal Zooming Microphone Equipped with the internal zooming microphone, it can capture the sound from the scene clearly. Adjusting the video zooming focus to a nearby or distant scene, you will not miss any source of sound wherever it occurs. Capture the time! Time Lapse Recording You can reconfi gure otherwise a long time of video to a shortened one using the time lapse recording at a specifi c time interval. Time lapse recording enables you to capture the passage of clouds, blooming of fl owers, natural growing progress of buds, progress of painting, and other documentary videos of personal memory. Use this function to make UGC (User-Generated Content ) videos, artistic recordings and educational programs. Video at a Glance! iVIEW, Storyboard Printing You get a quick overview of your video and save it in a single piece of picture. You can take a glance at the video without playing the whole length, which is especially useful if you want to edit the video in a short time. Direct Upload of Your Videos and Photos to the Web! The built-in editing Intelli-studio software installs directly from this camcorder to your PC, enabling convenient connection only with a USB cable. Intelli-studio also allows direct uploading of your contents to YouTube, Flickr, or Facebook. Sharing the contents with your friends is simpler than ever before. Hello ! Hello ! iv SAFETY WARNINGS What the icons and signs in this user manual mean; WARNING Means that there is a potential risk of death or serious injury. CAUTION Means that there is a potential risk of personal injury or damage to the product. CAUTION To reduce the risk of fire, explosion, electric shock, or personal injury when using your camcorder, follow these basic safety precautions. Means hints or referential pages that may be helpful when operating the camcorder. PRECHECK Settings required before using a function. These warning signs are here to prevent injury to you and others. Please follow them explicitly. After reading this section, keep it in a safe place for future reference. PRECAUTIONS Warning! • When using the AC power adapter with your camcorder, connect the adapter to an outlet with protective grounding. • Do not expose the camcorder battery to direct sunlight, heaters, radiators, fire, or any other source of excessive heat. Caution If you replace the battery with the wrong battery, you can cause an explosion.Replace only with the same battery or an equivalent type. If you plug the AC adapter into a 240V AC outlet, be sure to use a suitable plug adapter. before reading this user manual v Thank you for purchasing this Samsung Camcorder. Please read this user manual carefully before you use the camcorder and keep it handy for future reference. Should your camcorder fail to operate correctly, refer to Troubleshooting. This User Manual covers HMX-S10, HMX-S15, and HMX-S16 models. The HMX-S15 and HMX-S16 have a 32GB, and 64GB built-in storage media (SSD) respectively but also use memory cards. The HMX-S10 do not have built-in storage media (SSD) and use memory cards. Although some features of HMX-S10 models are different, they operate in the same way. Illustrations of model HMX-S10 are used in this user manual. The displays in this user manual may not be exactly the same as those you see on the LCD screen. Designs and specifications of the camcorder and other accessories are subject to change without any notice. In this user manual, the icon or symbol in the parenthesis appearing in a description of a submenu item indicates it will appear on the screen when setting the corresponding item. Ex) Submenu item of “iSCENE”
page ?? - “Sports” ( ): Recording people or ob…

Text truncated - open the document above for the full version.

19 Photo play mode PRECHECK! This On Screen Display (OSD) is shown in the Photo play mode only. Select the Play ( ) tab on the LCD screen to select the Photo play () mode.
page ?? • • Top of the LCD screen IndicatorMeaning Photo play mode / X1.1 Slide show / Playback zoom (X1.1~X8.0)  Photo image counter (current image / total number of recorded images) @ File name (fi le number) / Storage media (Memory card or internal memory (HMX-S15/S16 only)) .*/ Battery info. (remaining battery level) Erase protection 5M5M Photo resolution LCD Enhancer Bottom of the LCD screen IndicatorMeaning Volume tab (when activating slide show) Return tab Previous image/Next image tab Slide show start tab
". +"/ Date/Time Menu tab The play control tabs appear briefl y. They reappear when touching anywhere on the screen.  .*/  @
". +"/ 5M5M  .*/.*/  @@ 555MMM
".
". +"/+"/ 20 To attach the battery Align the battery with the indicator ( ▲ ) on the battery compartment, push the battery toward the arrow direction. To detach the battery Slide the Battery release switch and pull out the battery. Gently slide the Battery release switch in the direction as shown in the fi gure. • ATTACHING/DETACHING THE BATTERY Purchase extra batteries to allow continuous use of your camcorder. Use only Samsung-approved batteries. Do not use batteries from other manufacturers. Otherwise, there is a danger of overheating, fi re or explosion. Samsung is not responsible for problems occurring due to using unapproved batteries. Detach the battery from the camcorder with care preventing from falling it. • • • getting started 21 To charge the battery with the AC power adaptor The battery is not charged during the power saving mode, which may keep the mode indicator on or fl ashing. Start charging the battery after turning off the camcorder by pressing the Power ( ) button. It is recommended you to have one or more additional batteries to allow continuous use of your camcorder. It is recommended to charge the battery pack in a place with ambient temperature of 10°C ~ 30°C(50 ̊ F~86 ̊F). When charging, if both the USB cable and AC power adaptor are connected, the AC power adaptor will override the USB. • • • • 1. Press the Power () button to turn off the camcorder and then close the LCD screen.
page ?? 2. Open the jack cover and connect the AC power adaptor to the DC IN jack. 3. Connect the AC power adaptor to a wall socket. The charging (CHG) indicator lights up and charging starts. After the battery is fully charged, the charging (CHG) indicator turns green. • Please make sure that there are no foreign substances in the plug and socket when you connect the AC power supply to the camcorder. Charging the battery at low temperature may take longer or fail to fully charge (green indicator will not turn on). • • CHARGING THE BATTERY You can charge the battery using the AC power adaptor or USB cable. PRECHECK! Before starting the following procedure, make sure that the battery is attached in your camcorder. To charge the battery with the USB cable 1. Press the Power () button to turn off the camcorder.
page ?? 2. Open the jack cover. 3. Connect the USB cable to the camcorder properly and connect the other end to a USB port of a PC. The charging (CHG) indicator lights up and charging starts. After the battery is fully charged, the charging (CHG) indicator turns green. • 22 getting started The battery level display shows the amount of battery power remaining in the battery. Battery level indicator StateMessage Fully charged- 25~50% used- 50~75% used- 75~95% used - 95~98% used- Exhausted (fl ickers): The device will soon turn off. Change the battery as soon as possible. - - The device will be forced to turn off after 3 seconds. “Low Battery” CHECKING THE BATTERY STATE You can check the charging state and remaining battery capacity. The color of the LED indicates the power or charging state. Charging (CHG) indicator The color of the charging indicator shows the charging state. Charging state ChargingFully chargedError LED color (Orange)(Green)(Red/blink) To check the charging state Battery level display 45#:  <.JO>  .*/ 23 Above figures are based on a fully charged battery at a normal temperature. Low ambient temperature may affect the use time. Battery capacity decreases over time and through repeated use. Keep the camcorder turned off while not operating it. Store the battery separately when finished charging or when not using it for a long time. This will help extend the life of the battery. The battery is charged over 95% after about 2 hours, and the indicator color changes to green. It takes about 2 hours and 40 minutes for the battery to charge 100%. • • • • Available running time for the battery Battery typeIA-BP210E Charging timeUsing the AC power adaptor: approx. 160 min. Using the USB cable: approx. 390 min. Video resolutionHDSD Continuous recording timeApprox. 90min.Approx. 120min. Playback timeApprox. 110min.Approx. 130min. Charging time: Approximate time (min.) required when you fully charge a completely exhausted battery. Recording/Playback time: Approximate time (min.) available when you fully charged the battery. ‘HD’ stands for high definition image quality, and ‘SD’ stands for standard image quality. The time is only for reference. Figures shown above are measured under Samsung’s test environment, and may differ according to user and condition. The recording and playback time will be shorter when you use your camcorder in low temperatures. We recommend using the AC power adaptor when using the Time Lapse REC function. Continuous Recording (without zoom) The continuous recording time of the camcorder in the table shows the available recording time when the camcorder is in the recording mode without using any other function after recording starts. When actually recording, the battery pack may discharge 2-3 times f…

Text truncated - open the document above for the full version.

33 Compatible memory cards This camcorder can be used with SD (Secure Digital) and SDHC (Secure Digital High Capacity) cards. It is recommended to use an SDHC (Secure Digital High Capacity) card. SD cards up to 2GB are supported with this camcorder. Normal operation is not guaranteed with SD cards bigger than 2GB. MMC (Multi Media Card) and MMC Plus are not supported. Compatible memory card capacity: SD 1 ~ 2GB, SDHC 4 ~ 32GB Use compatible memory card brands. Others are not guaranteed to work. Check the compatibility when buying a memory card. - SDHC/SD cards: Panasonic, SanDisk, TOSHIBA For video recording, use a memory card that supports faster write speeds (above SDHC Class 6 card). SD/SDHC memory cards have a mechanical write-protection switch. Setting the switch prevents accidental erasure of files recorded on the card. To enable writing, move the switch up in the direction of the terminals.To set write protection, move the switch down. • • • • • • SDHC (Secure Digital High Capacity) cards SDHC (Secure Digital High Capacity) memory card - An SDHC card is a higher version (Ver.2.00) of SD card and supports capacity above 2GB. - Cannot be used with current SD enabled host devices. Common cautions for memory cards Damaged data may not be recovered. It is recommended you make a back-up of important data separately on the hard disk of your PC. Turning the power off or removing a memory card during an operation such as formatting, deleting, recording, and playback may cause data loss. After you modify the name of a file or folder stored in the memory card using your PC, your camcorder may not recognize the modified file. • • • • SELECTING A SUITABLE MEMORY CARD (NOT SUPPLIED) Usable memory card (1GB~32GB) Protection tab Terminals <SD><SDHC> Terminals Protection tab 34 Handling a memory card It is recommended that you power off before inserting or removing the memory card to avoid data loss. It is not guaranteed that you can use a memory card formatted by other devices. Be sure to format your memory card using this camcorder. You have to format newly-purchased memory cards, memory cards with data that your camcorder cannot recognize or are saved by other devices. Note that formatting erases all data on the memory card. If you cannot use a memory card that has been used with another device, format it with your camcorder. Note that formatting erases all information on the memory card. A memory card has a certain life span. If you cannot record new data, you have to purchase a new memory card. Do not bend, drop, or cause strong impact to the card. Do not place foreign substances on the memory card terminals. Use a soft dry cloth to clean the terminals if required. Do not paste anything other than label provided with the card on the label pasting section. Be careful to keep the memory card out of the reach of children, who might swallow it. Notes on use Samsung is not responsible for data loss due to misuse. We recommend using a memory card case to avoid losing data from moving and static electricity. After a period of use, the memory card may get warm. This is normal and is not a malfunction. • • • • • • • • • • • • The camcorder supports SD and SDHC memory cards for data storage preference! The data storage speed may differ, according to the manufacturer and production system. SLC (single level cell) system: faster write speed enabled. MLC (multi level cell) system: only lower write speed is supported. For best results, we recommend using a memory card that supports faster write speed. Using a lower write speed memory card for recording video may cause difficulties when storing. You may even lose your video data during the recording. In an attempt to preserve any bit of the recorded video, the camcorder forcibly stores the video on the memory card and displays a warning: “Low speed card. Please record at a lower resolution.” If you are unavoidably using a low speed memory card, resolution and quality of the recording may be lower than the set value.  page ?? The higher the resolution and quality, the more memory will be used. • • getting ready to start recording 35 Resolution Memory card / Internal memory* Internal memory* 1GB2GB4GB8GB16GB32GB64GB 1080/60i (XF)5 min10 min21 min42 min84 min167 min337 min 1080/60i(SF)7 min14 min29 min60 min121 min236 min474 min 1080/60i(F)11 min22 min45 min92 min185 min364 min731 min 1080/30p7 min14 min29 min60 min121 min236 min474 min 720/60p11 min22 min45 min92 min185 min364 min731 min 480/60p23 min47 min99 min200 min404 min790 min1587 min (Unit: Approximate minutes of recording) Resolution Memory card / Internal memory* Internal memory* 1GB2GB4GB8GB16GB32GB64GB [10M] 4224x2376 (16:9)45991719143866777899999999 [5M] 2960x1664 (16:9)612122325525154999999999999 [3M] 2224x1664 (4:3)918183538287732999999999999 [2M] 1920x1080 (16:9)1147229447859665999999999999 [VGA] 640x4803060611899999999999999999999 (Unit: Approximate number of images) The figures in the table may differ depending on the actual recording conditions and subject. The higher the quality and resolution, the more memory is used. Lower resolution and quality increases the recording time, but the image quality may suffer. The bit rate automatically adjusts to the recording image. Accordingly, the recording time may vary. Memory cards bigger than 1.8GB may not operate normally. When a video file exceeds 1.8GB, the next video file is created automatically. The maximum number of recordable photo and video files is 9999, respectively. The recording length of a Time Lapse REC may vary depending on settings. Items marked with * are available only with HMX-S15/S16 models. • • • • • • • • • RECORDABLE TIME AND CAPACITY 1GB ⴊ 1,000,000,000 bytes : actual formatted capacity may be less as the internal firmware uses a portion of the memory. Recordable time available for video Recordable number of photos 36 ATTACHING THE GRIP BELT Adjust the length of grip belt so that the camcorder is stable when you press the …

Text truncated - open the document above for the full version.

44 Using the optical zoom does not degrade the image quality and clarity. Use the digital zoom when you want to zoom more than the optical zoom range (Video recording mode only).  page ?? Focusing may become unstable when recording with a fast zoom or zooming into a subject standing too far away. In this case, use the manual focus function.  page ?? The minimum possible distance between camcorder and subject while maintaining sharp focus is about 1cm (about 0.4 inches) for wide angle and about 50cm (about 19.7 inches) for telephoto. If you want to shoot the object close to the lens at a wide angle, use the Tele Macro function.  page ?? When using the zoom function while holding the camcorder with your hand, use Anti-shake (OIS) for stable recording.  page ?? Frequent use of the zoom function consumes more power. Zooming sound by using the Zoom lever or Zoom button can be recorded. • • • • • • • ZOOMING Use the zoom function for close-up or wide-angle recording. This camcorder allows you to record using 15x optical power zoom, 18x Intelli-zoom and digital zoom. PRECHECK! Select the record (/) mode by pressing the MODE button.  page ?? Press the T (zoom) button on the LCD panel or slide the zoom lever towards T (telephoto). The distant subject is gradually magnifi ed and can be recorded. The most magnifi ed zoom ratio is 18x zoom in the normal zoom-in. • • Press the W (zoom) button on the LCD panel or slide the zoom lever towards W (wide angle). The subject moves further away. The smallest zoom ratio is the subject’s original size in the zoom-out. • • When using the zoom function, its speed can be decreased by slowly moving the Zoom (W/T) lever. A fast moving increases the zoom speed. However, the Zoom (W/T) button on the LCD panel cannot adjust the zoom speed. Zoom speed To zoom inTo zoom out basic recording W : Wide angle T : Telephoto 45 The Smart Auto mode automatically sets the Anti-shake (OIS) to On. Gross camcorder shake may not be entirely corrected even if the Anti-shake is set to On. Firmly hold the camcorder with both hands. When this function is set to On, the actual movement of the subject and the movement displayed on the screen may be slightly different. When recording in dark lighting at high magnifi cation while this function is set to On, after-images may stand out. In this case, we recommend using a tripod (not supplied) and turning the Anti-shake to Off. • • • • SETTING THE ANTI-SHAKE (OIS: OPTICAL IMAGE STABILIZER) Use the Anti-shake (OIS: Optical Image Stabilizer) function to compensate for unstable images caused by shaking movements when holding the camcorder. PRECHECK! Select the record (/) mode by pressing the MODE button.  page ?? Press the Anti-shake (OIS) () button to toggle the Anti-shake (OIS) mode between On and Off. When recording while walking or when recording in a moving car. When recording with the zoom function. When recording subjects of a small size. • • • Use the Anti-Shake function in the following cases 45#:
 <.JO>  .*/ 46 USING BACK LIGHT COMPENSATION MODE When a subject is lit from behind, this function will compensate for lighting so that the subject is not too dark. PRECHECK! Select the record (/) mode by pressing the MODE button.  page ?? Press the Back light () button to toggle the back light mode between On and Off. The subject is in front of a window. The person to be recorded is wearing white or shiny clothes and is placed against a bright background; the person’s face is too dark to distinguish his/her features. The subject is outdoors and the background is overcast. The light sources are too bright. The subject is against a snowy background. • • • • • Back lighting exists when the subject is darker than the background basic recording 45#:
 <.JO>  .*/ 47 USING THE FLASH Using the fl ash, you can capture clear and bright photos even under shadows, at night or indoors which need more light. PRECHECK! Select the Photo record () mode by pressing the MODE button.  page ?? Press the Flash () button to select the fl ash mode you want. The selected fl ash mode is displayed. DisplayMeaning Disables the fl ash. Flash works automatically when the subject or background is dark. Flash works automatically when the subject or background is dark, and it reduces red eyes of persons looking straight at fl ash. Flash always works regardless of brightness. Flash works as the shutter speed is slow. It is suitable for use around sundown or in dark places. It is recommended to use the tripod (purchase separately) to prevent camcorder shake. • Do not use the fl ash with a hand covered on it. Do not use a fl ash too close to eyes of a person. • • Use a fl ash within a distance of 1~2 meters. Frequent use of a fl ash may decrease battery time faster. You cannot use a fl ash in the following conditions. - when the continuous shooting is set - when capturing photos during video recording • • •  .*/ 5M5M  48 USING THE MANUAL DIAL With the manual dial, you can simply set the frequently used functions (Focus, Aperture, Shutter, Exposure Value) during recording. It is convenient to set functions easily without using the menu. PRECHECK! Select the record (/) mode by pressing the MODE button.  page ?? Set the manual dial to the frequently used function (Focus, Aperture, Shutter, Exposure Value).  page ?? 1. Press the MANUAL button. Press the MANUAL button to toggle focus between Auto and Manual. 2. Adjust the focus turning the MANUAL dial. You can adjust aperture, shutter, exposure value in a same way to set focus. (when one function is assigned to the manual dial.  page ??) • • • • Only one function can be assigned to the manual dial.  page ?? Even if one of functions unavailable at the same time in the menu is assigned to the manual dial, you can set the function with the manual dial, however, not in the menu. For example) When Aperture is assigned to the manual dial Aperture cannot be used if Shutter is set to Manual in the m…

Text truncated - open the document above for the full version.

Focus The camcorder usually focuses on a subject automatically (auto focus). When the camcorder is turned on, auto-focus will always be set. You can also manually focus a subject depending on the recording conditions. PRECHECK! Select the record (/) mode by pressing the MODE button.  page ?? 1. Touch the Menu () tab  “Focus”  touch the desired submenu item. 2. Touch the ( OK ) tab to complete the setting. 3. To exit the menu, touch the Return ( ) tab. Submenu items Auto: Focus is set automatically. Manual ( ): You can set focus manually when diffi cult to set focus with a function of auto focus. Drag the focus dial toward the desired direction on the LCD screen to adjust the setting values. Touch Point ( ): You can set focus by touching the specifi c point of the subject on the LCD screen. (Available only in video record mode) • • • This camcorder automatically focuses a subject from close-up to infi nity. However, the correct focus may not be obtained depending on the recording conditions. In this case, use the manual focus mode. Focusing manually during recording Focusing in a nearer subject Drag toward . Focusing on a further subject Drag toward . A picture containing several objects, some close to the camcorder, others further away. A person enveloped in fog or surrounded by snow. Very shiny or glossy surfaces like a car. People or objects moving constantly or quickly like an athlete or a crowd. • • • • Situations to set focus manually 69 OK 'PDVT .BOVBM 5PVDI
1PJOU AUTOAUTO "VUP OK 'PDVT "VUP .BOVBM 5PVDI
1PJOU AUTOAUTO Using the Touch Point function, you can focus on a small section of the picture. Focus on the particular point by touching the desired point. The Touch Point function is available only in the video record mode. “Magic Touch” in the photo record mode is available as the same function.
 page ?? Using the touch point The Auto Focus (AF) setting is useful when you operate the zoom function because you might not be able to keep accurate focus after the zoom ratio has been changed. When the Touch Point function is enabled, you can touch the AF( AF ) tab on the LCD screen to set the “Focus” to “Auto.” • • advanced recording You can activate the touch point by pressing the particular point for about 2 seconds on the LCD screen in the record STBY mode. To activate the touch point with a long touch Face Detection Your camcorder detects a subject’s face and automatically adjusts the brightness and image quality to the optimized conditions. Record faces more vividly. PRECHECK! Select the record (/) mode by pressing the MODE button.  page ?? 1. Touch the Menu () tab  “Face Detection”  touch the desired submenu item. 2. To exit the menu, touch the Return ( ) tab. Submenu items Off: Disables the function. On( ): Detects faces automatically for the optimal recording conditions. • • 70 OK 'PDVT 5PVDI
1PJOU AUTOAUTO "VUP.BOVBM 45#:  <.JO> AF  .*/ &7 4VQFS
$/JUF 'PDVT 'BDF
%FUFDUJPO  4IVUUFS AUTOAUTO OFFOFF  NORNOR AUTOAUTO OFFOFF 0GG 0O Magic Touch Simply touch the area on the LCD screen that you want to focus on when taking a photo. You can capture clearer photos as the magic touch function optimizes the focus and white balance for the point you touch. PRECHECK! Select the Photo record () mode by pressing the MODE button.  page ?? 1. Touch the Menu () tab  “Magic Touch”  touch the desired submenu item. 2. To exit the menu, touch the Return ( ) tab. You can activate the magic touch function by pressing and holding the particular point for about 2 seconds on the LCD screen in the record STBY mode. To capture the photo, press the PHOTO button after focusing or simply touch the point to focus and hold for 2 seconds with a fi nger. • • To activate the Magic Touch with a long touch Submenu items Off: Disables the function. On( ): You can simply touch the subject shown on the LCD screen that you would like to focus on. The brightness will also be adjusted for the optimized value. • • To disable the magic touch function, touch the AF ( AF ) tab on the LCD screen, then “Focus” is set to “Auto.” 71 &7 'PDVT 'BDF
%FUFDUJPO .BHJD
5PVDI  4IVUUFS AUTOAUTO OFFOFF  AUTOAUTO OFFOFF OFFOFF 0GG 0O  .JO 5M5M  advanced recording Metering The metering mode refers to the way in which a camcorder measures the quantity of light. The brightness and lighting of your photos will vary depending on the metering mode you select. PRECHECK! Select the Photo record () mode by pressing the MODE button.  page ?? 1. Touch the Menu () tab  “Metering”  touch the desired submenu item. 2. To exit the menu, touch the Return ( ) tab. Submenu items Multi (): Meters the light by calculating the amount of light from different areas in the frame. Suitable for normal capturing. Center ( ): The amount of light metered on the center of the frame infl uences the whole screen. Suitable for capturing persons as the subject occupies a large portion of the frame. Spot ( ): Measures only the center of the screen and determines aperture. Use this function when there is a severe brightness difference between background and objects. • • • xvYCC Using the xvYCC function, you can record a video with the extended colors by expanding a color space. A video of colorful fl owers or deep blue sea can be recorded in virtual colors. PRECHECK! Select the Video record () mode by pressing the MODE button.  page ?? 1. Touch the Menu () tab  “xvYCC”  touch the desired submenu item. 2. To exit the menu, touch the Return ( ) tab. Submenu items Off: Disables the function. On( ): Records images with vivid and various colors. • • You can enjoy the recorded xvYCC video in the optimal condition when playing it back on the TV supporting xvYCC. Refer to the TV’s manual for details. 72 %JHJUBM
&GGFDU 5FMF
.BDSP $POU
4IPU 4FMG
5JNFS  .FUFSJOH OFFOFF OFFOFF OFFOFF OFFOFF .VMUJ $FOUFS 4QPU %JHJUBM
&GGFDU 'BEFS 5FMF
.BDSP 8JOE
$VU  YW:$$ YW :$$ 0'' OFFOFF OFFOFF OFFOFF 0GG 0O YW :$$ YW :$$ 0'' Digital Effect Using the…
