A3LML2545Mono Laser Printer

ML-254x Series Mono Laser Printer User’s Guide imagine the possibilities Thank you for purchasing a Samsung product. Copyright_ 2 copyright © 2011 Samsung Electronics Co., Ltd. All rights reserved. This user’s guide is provided for information purposes only. All information included herein is subject to change without notice. Samsung Electronics is not responsible for any direct or indirect damages, arising from or related to use of this user’s guide. •Samsung and Samsung logo are trademarks of Samsung Electronics Co., Ltd. •PCL and PCL 6 are trademarks of Hewlett-Packard Company. •Microsoft, Internet Explorer, Windows, Windows Vista, Windows 7 and Windows 2008 Server R2 are either registered trademarks or trademarks of Microsoft Corporation. •TrueType, LaserWriter and Macintosh are trademarks of Apple Computer, Inc. •All other brand or product names are trademarks of their respective companies or organizations. Refer to the 'LICENSE.txt' file in the provided CD-ROM for the open source license information. REV. 0.98 Safety information_ 3 safety information These warnings and precautions are included to prevent injury to you and others, and to prevent any potential damage to your machine. Be sure to read and understand all of these instructions before using the machine. Use common sense for operating any electrical appliance and whenever using your machine. Also, follow all warnings and instructions marked on the machine and in the accompanying literature. After reading this section, keep it in a safe place for future reference. Important safety symbols This section explains the meanings of all icons and signs in the user's guide. These safety symbols are in order, according to the degree of danger. Explanation of all icons and signs used in the user’s guide: WarningHazards or unsafe practices that may result in severe personal injury or death. CautionHazards or unsafe practices that may result in minor personal injury or property damage. Do not attempt. Do not disassemble. Do not touch. Unplug the power cord from the wall socket. Make sure the machine is grounded to prevent electric shock. Call the service center for help. Follow directions explicitly. Operating environment Warning Do not use if the power cord is damaged or if the electrical outlet is not grounded. This could result in electric shock or fire. •If the machine gets overheated, it releases smoke, makes strange noises, or generates an odd odor, immediately turn off the power switch and unplug the machine. •The user should be able to access the power outlet in case of emergencies that might require the user to pull the plug out. This could result in electric shock or fire. Do not place anything on top of the machine (water, small metal or heavy objects, candles, lit cigarettes, etc.). This could result in electric shock or fire. Do not bend, or place heavy objects on the power cord. Stepping on or allowing the power cord to be crushed by a heavy object could result in electric shock or fire. Safety information_ 4 Caution During an electrical storm or for a period of non-operation, remove the power plug from the electrical outlet. This could result in electric shock or fire. If the plug does not easily enter the electrical outlet, do not attempt to force it in. Call an electrician to change the electrical outlet, or this could result in electric shock. Be careful, the paper output area is hot. Burns could occur. Do not allow pets to chew on the AC power, telephone or PC interface cords. This could result in electric shock or fire and/or injury to your pet. If the machine has been dropped, or if the cabinet appears damaged, unplug the machine from all interface connections and request assistance from qualified service personnel. Otherwise, this could result in electric shock or fire. If the machine does not operate properly after these instructions have been followed, unplug the machine from all interface connections and request assistance from qualified service personnel. Otherwise, this could result in electric shock or fire. Operating method Caution Do not forcefully pull the paper out during printing. It can cause damage to the machine. When printing large quantities, the bottom part of the paper output area may get hot. Do not allow children to touch. Burns can occur. Be careful not to put your hand between the machine and paper tray. You may get injured. When removing jammed paper, do not use tweezers or sharp metal objects. It can damage the machine. Do not block or push objects into the ventilation opening. This could result in elevated component temperatures which can cause damage or fire. Do not allow too many papers to stack up in the paper output tray. It can damage the machine. Be care when replacing paper or removing jammed paper. New paper has sharp edges and can cause painful cuts. This machine's power reception device is the power cord. To switch off the power supply, remove the power cord from the electrical outlet. Installation / Moving Do not remove the plug by pulling on the cord; do not handle the plug with wet hands. This could result in electric shock or fire. Safety information_ 5 Warning Do not place the machine in an area with dust, humidity, or water leaks. This could result in electric shock or fire. Caution Before moving the machine, turn the power off and disconnect all cords. Then lift the machine: • If the machin e weighs under 20 kg (44.09 lbs), lift with 1 person. • If the machin e weighs 20 kg (44.09 lbs) - 40kg (88.18 lbs), lift with 2 people. • If the machine weighs more than 40 kg (88.18 lbs), lift with 4 or more people. The machine could fall, causing injury or machine damage. Use only No.26 AWG a a. AWG: American Wire Gauge or larger, telephone line cord, if necessary. Otherwise, it can cause damage to the machine. Do not place the machine on an unstable surface. The machine could fall, causing injury or machine damage. Do not put a cover over the machine or place …

Text truncated - open the document above for the full version.

From: 라상경 Sent: Thursday, June 02, 2011 8:46 PM To: PCTEST TCB/CB Cc: 'PCTEST - Channy Park'; 'PCTEST - Greg Czumak'; 'PCTEST - Gregory Snyder'; 'PCTEST - Mark Czumak'; 'PCTEST - Randy Ortanez'; 'PCTEST - Steve Liu'; PCTEST - Mia Park Subject: Re: RE: Follow-Up Question Regarding FCC ID: A3LML2545 Page 1 of 4 6/3/2011 Hello Concerning your request, we revised the report as attached Thanks Sang Kyung, Ra ------- Original Message ------- Sender : PCTEST TCB/CB<[email protected]> [email protected] Date : 2011-05-24 09:43 (GMT-07:00) Title : RE: Follow-Up Question Regarding FCC ID: A3LML2545 Dear Mr. Ra, Thank you for your response. Please note that RT questions 2 and 3 have not been addressed in the test report. Please address and/or send the revised test report. The item indicated above must be submitted before processing can continue on the 라 상 경 (Ra, Sang Kyung)/General Manager Head of QA Lab America Samsung Electronics America, above referenced application. Sincerely, Mark Czumak Senior Certification Engineer From: SangKyung Ra Sent: Monday, May 23, 2011 8:12 PM To: PCTEST TCB/CB Cc: PCTEST - Channy Park; PCTEST - Greg Czumak; PCTEST - Gregory Snyder; PCTEST - Mark Czumak; PCTEST - Mia Park; PCTEST - Randy Ortanez; PCTEST - Steve Liu Subject: Re: Questions Regarding FCC ID: A3LML2545 Hello Mark Thanks for your patience Please refer to the attached revised report and documents you wanted to verify If you have any questions or comments, please don't hesistate to contact me Sincerely yours Sang Kyung (Peter), Ra PCTEST TCB/CB Tel. 1.410.290.6652 Fax. 1.410.290.6654 [email protected] www.pctesttcb.com Please consider the environment before printing this e- mail. This communication and its attachments contain information from PCTEST TCB/CB and are intended for the exclusive use of the recipient (s) named above. It may contain information that is confidential and/or legally privileged. Any unauthorized use that may compromise that confidentiality via distribution or disclosure is prohibited. Please notify the sender immediately if you receive this communication in error, and delete it from your computer system. Usage of PCTEST email addresses for non- business related activities is strictly prohibited. No warranty is made that the e-mail or attachment(s) are free from computer virus or other defect. Thank you. 라 상 경 (Ra, Sang Kyung)/General Manager Page 2 of 4 6/3/2011 ------- Original Message ------- Sender : PCTEST TCB/CB<[email protected]> [email protected] Date : 2011-05-18 15:24 (GMT-07:00) Title : Questions Regarding FCC ID: A3LML2545 To: Mr. Peter Ra / Samsung Electronics Co., Ltd. From: Mr. Mark Czumak / PCTEST TCB RE: FCC ID: A3LML2545 Applicant: Samsung Electronics Co., Ltd. Correspondence Reference Number: A3L0631 Confirmation Number: 1Y1105160631 Date of Original Email: May 18, 2011 Subject: Request for additional information In regards to your recent TCB application referenced above, we kindly request that you provide the following additional information. 1.The Block Diagram that was submitted does not include oscillators/clocks in the EUT. Please revise to include with the center frequencies. Page 3 of 4 6/3/2011 2.The Agilent amplifier listed in section 4.2.1 of the test report is past the calibration due date at the date of testing. Please address. 3.FYI - The section page numbers are not provided in the test report Table of Contents. Please revise to include the page numbers. The item indicated above must be submitted before processing can continue on the above referenced application. Sincerely, Mark Czumak Certification Engineer PCTEST TCB/CB Tel. 1.410.290.6652 Fax. 1.410.290.6654 [email protected] www.pctesttcb.com Right-click here to download pictures. To help protect your privacyOutlook prevented Please consider the environment before printing this e- mail. This communication and its attachments contain information from PCTEST TCB/CB and are intended for the exclusive use of the recipient (s) named above. It may contain information that is confidential and/or legally privileged. Any unauthorized use that may compromise that confidentiality via distribution or disclosure is prohibited. Please notify the sender immediately if you receive this communication in error, and delete it from your computer system. Usage of PCTEST email addresses for non- business related activities is strictly prohibited. No warranty is made that the e-mail or attachment(s) are free from computer virus or other defect. Thank you. Page 4 of 4 6/3/2011

PCTEST Engineering Laboratory Inc. 6660 Dobbin Road Suite A-E Columbia, Maryland 21045-4844 Tel.: 410-290-6652 / Fax: 410-290-6654 © 2011 PCTEST Engineering Laboratory Inc. June 16, 2011 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: SAMSUNG Electronics Co., Ltd. FCC ID: A3LML2545 Notice of Superseding Exhibit To Whom It May Concern: On behalf of SAMSUNG Electronics Co., Ltd., we have superseded the following exhibits for the Mono Laser Printer. 1. Test Report The exhibits have been superseded to revise the Input Rating. Should you have any questions or comments concerning the above, please contact the undersigned.

ML-2540 Printer_Front ML-2540 Printer_Rear ML-2540 SIDE_RIGHT ML-2540 SIDE_LEFT ML-2540 TOP VIEW ML-2540 Bottom VIEW ML-2540 Model Name ML-2540 PowerCordWithPrinter ML-2540 Power Cord

Project No. : LBE20112456 Mono Laser Printer : ML-2545 -23/26- This report must not be reproduced, except in full, without written permission from CS & Environment center. Appendix – EUT photography Front View Rear View & Label location Project No. : LBE20112456 Mono Laser Printer : ML-2545 -26/26- This report must not be reproduced, except in full, without written permission from CS & Environment center. SMPS Label Rating

ML-2540 Printer_Front ML-2540 Printer_Rear ML-2540 Printer_Right ML-2540 Printer_Left ML-2540 Printer_TOP VIEW ML-2540 Printer_Bottom VIEW ML-2540 Main PBA_Rear SUNGHO , SANDPIPER-H V2 ML-2540 SMPS & HVPS PBA_Front SUNGHO , SANDPIPER-H V2 ML-2540 SMPS & HVPS PBA_Rear SCTH , SANDPIPER-H V2 ML-2540 SMPS & HVPS PBA_Front SCTH , SANDPIPER-H V2 ML-2540 SMPS & HVPS PBA_Rear ML-2540 OPE PBA_Front ML-2540 OPE PBA_Rear

Project No. : LBE20112456 Mono Laser Printer : ML-2545 -6/26- This report must not be reproduced, except in full, without written permission from CS & Environment center. 3.5 EUT Description The following features describe EUT represented by this report: Item Specification and Description Processor TEMUJIN (300 MHz) Standard System memory Embedded SDRAM core of ESMT with 8 MB size Resolution True 1 200 x 1 200 dpi Copy Quality mode N/A Paper Handling Cassette Type, 250 Sheets Power Rating [220~240] VAC, 3 A, 50/60 Hz Power Consumption Power save mode : Less than 6.5 Watts Printing mode: MAX. 400 Watts Printer Language GDI PC Interfaces USB 2.0 OS compatibility Windows 2000, XP, Vista, Windows7, 2003 Server, 2008 Sever, Various Linux OS, and Mac OS X 10.3~10.6 Modes of Operation USB Printing Intended Class for Emissions Class B 3.6 Clock Frequencies Kind of Clocks Frequency [MHz] Kind of Clocks Frequency [MHz] Main Source Clock 12 Video Clock 22.344 7 CPU Internal Clock 300 USB Device Clock 12

-1/26- E E E M M M C C C T T T E E E S S S T T T R R R E E E P P P O O O R R R T T T Project No. LBE20112456 Issue No. 1 Applicant Name of organization Samsung Electronics Co., Ltd. Address 416 Maetan 3-Dong, Yeongtong-Gu, Suwon-Si, Gyeonggi-Do 443-742 Korea Date of application April 19, 2011 EUT Type of device Class B personal computers and peripherals Equipment authorization Declaration of Conformity Certification Verification FCC ID A3LML2545 Kind of product Mono Laser Printer Model No. ML-2545 Variant Model No. ML-2540 Manufacturer 1) Samsung Electronics Co., Ltd. 259, Gongdan-Dong, Gumi-City, Gyeongsangbuk-Do, Korea 730-030 2) Samsung Electronics (Shandong) Digital Printing Co., Ltd. 264209, Samsung Road, Weihai Hi-Tech. IDZ, Shandong Province, P.R.China 3) Weihai Shin Heung Digital Electronics Co., Ltd. 98, Samsung Road, Weihai Hi-Tech. IDZ, Shandong Province, P.R.China 4) Intops : Intops (Weihai) Electronics Co., Ltd. Keji Road-268-1, Weihai Hi-Tech,Industries Development Zone , Shandong Province , CHINA Applied Standards FCC Part 15, Subpart B / ANSI C63.4-2009 Test Period April 20, 2011 ~ April 21, 2011 Issue date May 19, 2011 Test result : Complied The equipment under test has found to be compliant with the applied standards. (Refer to the attached test result for more detail.) Tested by : Sung Jin Sim Reviewed by : No Cheon Park The test results in this report only apply to the tested sample. This report must not be reproduced, except in full, without written permission from CS & Environment center. 416 Maetan 3-Dong, Yeongtong-Gu, Suwon-Si, Gyeonggi-Do, 443-742 Korea Tel: 82 31 277 7752, Fax: 82 31 277 7753 Project No. : LBE20112456 Mono Laser Printer : ML-2545 -2/26- This report must not be reproduced, except in full, without written permission from CS & Environment center. Table of contents 1. Summary of test results 1.1 Emission - 3page 2. General Information 2.1 Test facility - 4 page 3. Test configuration 3.1 Test Peripherals - 4 page 3.2 EUT operating mode - 5 page 3.3 Details of Sampling - 5 page 3.4 Used cable description - 5 page 3.5 EUT Description - 6 page 3.6 Clock Frequencies - 6 page 3.7 Test configuration and condition - 7 page 3.8 Measurement uncertainty - 7 page 4. Result of individual tests 4.1 Conducted disturbance - 8 page 4.2 Radiated disturbance - 14 page Appendix – EUT photography - 23 page Project No. : LBE20112456 Mono Laser Printer : ML-2545 -3/26- This report must not be reproduced, except in full, without written permission from CS & Environment center. 1. Summary of test results 1.1 Emission The EUT has been tested according to the following specifications: Applied Test type Applied standard Result Remarks Conducted Disturbance (Mains Port) FCC Part 15 Subpart B / ANSI C63.4-2009 Complied Meets Class B Limit Radiated Disturbance Complied Meets Class B Limit Project No. : LBE20112456 Mono Laser Printer : ML-2545 -4/26- This report must not be reproduced, except in full, without written permission from CS & Environment center. 2. General Information 2.1 Test facility The CS & Environment center is located on Samsung Electronics Co., Ltd. at 416 Maetan 3-Dong, Yeongtong-Gu, Suwon-Si, Gyeonggi-Do, South Korea. All testing are performed in Semi-anechoic chambers conforming to the site attenuation Characteristics defined by ANSI C63.4, CISPR 22, 16-1 and 16-2. and Shielded rooms. The CS & Environment center is operated as testing laboratory in accordance with the requirements of ISO/IEC 17025:2005. 3. Test Setup configuration 3.1 Test Peripherals The cables used for these peripherals are either permanently attached by the peripheral manufacturer or coupled with an assigned cable as defined below. The following is a listing of the EUT and peripherals utilized during the performance of EMC test: Description Model No. Serial No. Manufacturer Fcc ID / DoC Mono Laser Printer ML-2545 - SAMSUNG EUT Laptop PC NT-RV511 ZZDN93CZB00036R SAMSUNG DoC Adapter A10-090P1A CNBA4400215ADON43AB01380 Chicony DoC USB mouse SC-1000 328447928 Primax electronics Ltd., DoC Head set Microsoft - Plantronics - Project No. : LBE20112456 Mono Laser Printer : ML-2545 -5/26- This report must not be reproduced, except in full, without written permission from CS & Environment center. 3.2 EUT operating mode To achieve compliance with the applied standards and/or specifications, the following mode(s) were considered and tested. Operating Mode 1 Standby Operating Mode 2 USB Printing(Duplex) 3.3 Details of Sampling Customer selected, single unit. 3.4 Used cable description The EUT is configured, installed, arranged and operated in a manner consistent with typical applications. Interface cables/loads/devices are connected to at least one of each type of interface port of the EUT, and where practical, each cable shall be terminated in a device typical of actual usage. The type(s) of interconnecting cables to be used and the interface port (of the EUT) to which these were connected; Connected cable Length [m] Shielded [Y/N] Note Power 1.8 No For EUT Power 1.8 No For laptop PC USB 1.8 Yes From laptop PC to EUT USB 1.5 Yes From laptop PC to Mouse Audio 1.8 No From Notebook PC to Headphones Project No. : LBE20112456 Mono Laser Printer : ML-2545 -6/26- This report must not be reproduced, except in full, without written permission from CS & Environment center. 3.5 EUT Description The following features describe EUT represented by this report: Item Specification and Description Processor TEMUJIN (300 MHz) Standard System memory Embedded SDRAM core of ESMT with 8 MB size Resolution True 1 200 x 1 200 dpi Copy Quality mode N/A Paper Handling Cassette Type, 250 Sheets Power Rating [110 ~ 127] VAC, 5 A, 50/60 Hz Power Consumption Power save mode : Less than 6.5 Watts Printing mode: MAX. 400 Watts Printer Language GDI PC Interfaces USB 2.0 OS compatibility Windows 2000, XP, Vista, Windows7, 2003 Server, 2008 Sever, Various Linux OS, and Mac OS X 10.3~10.6 Modes of Operation USB Printing Intended Class fo…

Text truncated - open the document above for the full version.

Project No. : LBE20112456 Mono Laser Printer : ML-2545 -9/26- This report must not be reproduced, except in full, without written permission from CS & Environment center. 4.1.3 Photograph of Test Setup Front Rear Project No. : LBE20112456 Mono Laser Printer : ML-2545 -17/26- This report must not be reproduced, except in full, without written permission from CS & Environment center. 4.2.3 Photograph of Test Setup Front (below 1 GHz) Rear (below 1 GHz) Project No. : LBE20112456 Mono Laser Printer : ML-2545 -18/26- This report must not be reproduced, except in full, without written permission from CS & Environment center. Front (above 1 GHz) Rear (above 1 GHz)
