A3LSCHA512Single Mode CDMA Cellular Phone

P O RTABLE CELLULAR TELEPHONE SCH-A512 User’s Manual Printed in Korea Code No. : GH68-xxxxxA English. 2002/03. Rev.1.0 ELECTRONICS World Wide Web http://www.samsungmobile.com 3 QUICK SAFETY GUIDE ..............................................................7 UNPACKING ............................................................................... 9 YOUR PHONE Phone Layout .............................................................................. 10 Display ....................................................................................... 13 Backlight .................................................................................... 15 Service Light ............................................................................... 15 GETTING STARTED Using the Battery ........................................................................ 16 Switching the Phone On/Off ........................................................ 21 Your Phone’s Mode ....................................................................... 22 CALL FUNCTIONS Making a Call ............................................................................... 24 Redialing the Last Number ............................................................ 25 Making a Call from the Phonebook ............................................... 26 Speed Dialing ............................................................................... 29 Pause Dialing ............................................................................... 31 Voice Dialing ................................................................................ 33 Adjusting the Volume ..................................................................... 33 Answering a Call ........................................................................... 34 In-Call Options .............................................................................. 35 Quick-switching to Manner Mode ................................................... 36 Viewing Missed Calls ..................................................................... 37 Call Forwarding ............................................................................ 37 Call Waiting .................................................................................. 38 Three-Way Calling ........................................................................ 39 Table of Contents 54 USING THE MENUS Accessing the Menu Facility ........................................................... 40 Accessing a Menu Functions by Scrolling ....................................... 41 Accessing a Menu Functions by Using its Shortcut .......................... 43 List of Menu Functions ................................................................. 44 MY PHONE Set Start Menu(MENU OK-1) ................................................ 48 Set Menu Screen (MENU OK-2) ............................................. 49 My Name (MENU OK-3) ........................................................ 50 Sliding Text (MENU OK-4)...................................................... 50 Animation (MENU OK-5)........................................................ 51 Delete Menu (MENU OK-6).................................................... 51 Reset Menu (MENU OK-7)...................................................... 52 External Clock (MENU OK-8).................................................. 52 Dial Number (MENU OK-9).................................................... 52 Language (MENU OK-0)........................................................ 52 MUSIC BOX Select Bell(MENU 1-1) ........................................................... 53 Select Melody (MENU 1-2) ..................................................... 53 Music Bell (MENU 1-3) ........................................................... 54 Select My Bell (MENU 1-4)...................................................... 54 Select My Bell (MENU 1-5)...................................................... 54 GAMES ......................................................................... 55 PHONEBOOK Find Number(MENU 3-1)...................................................... 56 Call Sent (MENU 3-2)............................................................ 61 Call Received (MENU 3-3)...................................................... 61 Add Entry (MENU 3-4)........................................................... 62 Caller Alert (MENU 3-5)......................................................... 62 Group Editing (MENU 3-6)..................................................... 64 Delete All (MENU 3-7)........................................................... 66 My Phone Number (MENU 3-#)............................................. 66 PLANNER Morning Call(MENU 4-1)...................................................... 67 Alarm (MENU 4-2)................................................................ 68 Scheduler (MENU 4-3)........................................................... 70 Memo (MENU 4-4)................................................................ 72 Calculator (MENU 4-5)........................................................... 73 World Time (MENU 4-6)........................................................ 74 D-Day Plus (MENU 4-7)......................................................... 75 Unit Conversion (MENU 4-8).................................................. 76 Time Manager (MENU 4-9).................................................... 77 GONEXT/MSG GoNext(MENU 5-1)............................................................... 79 Msg Manager (MENU 5-2)...................................................... 80 Set Modem (MENU 5-3)......................................................... 89 SOUNDS Bell/Vibration(MENU 6-1)..................................................... 91 Ring Volume (MENU 6-2)....................................................... 92 Connect Tone (MENU 6-3)...................................................... 92 Disconnect Ton…

Text truncated - open the document above for the full version.

February 4, 2002 Federal Communications Commission Authorization and Evaluation Div. Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concern: We, the undersigned, hereby authorize PCTEST Engineering Laboratory Inc., to act as agent on behalf of all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by PCTEST Engineering Laboratory, Inc. on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988,21 U.S.C.862. Sincerely, Wallace Oh Engineering Manager Samsun Electronics America AFFIDAVIT FOR ESN PROTECTION OF CELLULAR MOBILE TELEPHONES We hereby certify that the Portable Cellular Telephone (FCC ID: A3LSCHA512) is so designed that it complies with all the requirements for ESN protection specified in Sec.22.919 of the FCC Rules. a) The transmitter in service has a unique ESN. b) The ESN host component is permanently attached to a main circuit board of the mobile transmitter and the integrity of the unit operating software cannot be altered. The ESN is plated from fraudulent contact and tampering. The ESN is encoded using multiplication by a polynomial and the ESN data programmed in the memory with other information. c) The ESN is factory set and cannot be altered, transferred, removed or otherwise able to be manipulated. Cellular mobile equipment is specifically designed such that any attempt to remove, tamper with, or change the ESN chip, its logic system, or firmware originally programmed by the manufacturer will render the mobile transmitter inoperative. April 25, 2002 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT:Samsung Electronics Co., Ltd. FCC ID: A3LSCHA512 Users Manual RF Exposure Warning Statement Gentlemen: Samsung Electronics Co., Ltd., hereby confirms that the attached RF exposure warning page will be readily visible to the user, and will be placed at a prominent location in the front section of the users manual. If you have any further questions regarding this matter, please do not hesitate to contact me or PCTEST Lab at (410) 290-6652.

April 25, 2002 Federal Communications Commission Authorization and Evaluation Div. Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re: Samsung Electronics Co., Ltd. FCC ID.: A3LSCHA512 Request for Confidentiality To Whom It May Concern: In accordance with 0.459 of CFR 47, Samsung Electronics Co., Ltd. requests confidentiality for the Block Diagram, Schematics, Parts list, Tune-up Procedure, Operational and Circuit Description of the attached test report. These documents contain detailed system and equipment descriptions and related information about the product, which Samsung Electronics Co., Ltd. considers to be proprietary, confidential, and a custom design and otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, Samsung feels that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market.

April 29, 2002 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: SAMSUNG Electronics Co., Ltd. FCC ID: A3LSCHA512 Part 22 Certification Gentlemen: Submitted herewith, on behalf of SAMSUNG Electronics Co., Ltd., is an application for Part 22 Certification of the Single-Mode CDMA Phone. Attached is the applicant’s Letter of Authorization, Confidentiality Request, ESN Affidavit, measurement report test data and plots, RF Exposure measurement report and data, FCC ID label and location, test setup photographs, internal and external photographs, block diagram (confidential), circuit diagrams & description (confidential), operational description (confidential), parts list & tune-up procedure (confidential), and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc: SAMSUNG Electronics Co., Ltd.

May 17, 2002 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Att: Richard Fabina Chief, Equipment Authorization Branch Re: SAR Report submitted with FCC ID: A3LSCHA512 Confidentiality Request Gentlemen: Pursuant to Sections 0.457 and 0.459 of CFR Title 47 FCC Rules and Regulations, PCTest Lab request confidentiality for the SAR report submitted as an attachment(s) to the subject application for certification for the reference FCC ID: A3LSCHA512. The attachment(s) to the application is (are) identified as "PCTEST Operational Description" is marked confidential. This report contains trade secrets and commercial information that are customarily guarded from competitors and are never released to the public. Section 0.457(d)(2) stipulates that such material will be withheld from routine inspection if it is shown that the material contains the type of information specified in the preceding statement. Specifically, the PCTEST Operational Description contains processes and procedures developed by PCTest Lab that enable RF Exposure tests performed at PCTest Lab to meet the stringent requirements of the most recent FCC released Supplement C guidelines for performing such measurements. Disclosure of this information to competitors will result in material harm to PCTest Lab. In compliance with the provisions of Section 0.457(d) stipulating that test measurements will be made available to the public following the effective date of the authorization, PCTest Lab has separated the measurement data required to show compliance with the RF Exposure requirements in a separate file identified as "SAR Measurement Data" that will be available for public inspection following the effective date of the authorization. Please contact the undersigned by telephone at 410-290-6652, or by email at [email protected] or by correspondence at the above address if there are any further questions or additional information needed concerning this request for confidentiality. Regards,

June 13, 2002 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Att: Richard Fabina Chief, Equipment Authorization Branch Re: SAR Report submitted with FCC ID: A3LSCHA512 Confidentiality Request Gentlemen: PCTEST Lab is currently reviewing the document for which they requested confidentiality to insure that it conforms to the requirements of the FCC rules for withholding information. Test data that is contained in the report has been left in to facilitate review of the report by the FCC. However, the test data contained in this section has been duplicated and submitted in a public file along with the SAR plots. The “PCTEST Operational Description SAR Report” contains confidential business information that PCTEST Lab does not release to the public and accordingly does not wish to have made available to the public via the FCC files. PCTEST Lab is aware that the issue of confidential treatment of this report is under review by the OET legal counsel and possibly by the Office of General Counsel of the Commission. Pending a decision by the appropriate authorities, PCTEST Lab will continue to request confidential treatment of the file identified as “PCTEST Operational Description SAR Report”. If the determining authority decides this information cannot be held confidential, PCTEST Lab will inform the Lab as to their intentions to appeal that decision or accept the decision. In the event the decision is accepted by PCTEST Lab, we will not pursue continued confidential treatment of the report and will assist the Lab in any way possible regarding correcting existing records. Please contact the undersigned by telephone at 410-290-6652, or by email at [email protected] or by correspondence at the above address if there are any further questions or additional information needed concerning this request for confidentiality. Regards,

June 18, 2002 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Martin Perrine SUBJECT: Samsung Electronics Co., Ltd. FCC ID: A3LSPHA512 731 Confirmation No.: TC853134 Correspondence Reference No.: 4336 Request for Tech. Info.: 6/06/02 Dear Martin: Transmitted herewith, on behalf of Samsung Electronics Co., Ltd. is an amendment provided in response to the request for technical information dated June 6, 2002. 1. Please find attached the retested SAR Test data for the CDMA right head cheek position using the slim battery. 2. The PCTEST Lab ALIDX-500 system version 4.08 has calibration software built into the system. This software is commercially available from IDX and is used by PCTEST Lab for calibrating probes used with the IDX system. The probe was calibrated according to IEEE std 1528-200x (A.3.2.2.). The validation dipole construction procedures followed the IEEE std. 1528. 3. PCTEST Lab is currently reviewing the document for which they requested confidentiality to insure that it conforms to the requirements of the FCC rules for withholding information. Test data that is contained in the report has been left in the report to facilitate review of the report by the FCC. However, the test data contained in this section has been duplicated and submitted in a public file along with the SAR plots. The “PCTEST operational description SAR report” contains confidential business information that PCTEST Lab does not release to the public and accordingly does not wish to have made available to the public via the FCC files. PCTEST Lab is aware that the issue of confidential treatment of this report is under review by the OET legal counsel and possibly by the Office of General Counsel of the Commission. Pending a decision by the appropriate authorities, PCTEST Lab will continue to request confidential treatment of the file identified as “PCTEST operational description SAR Report”. If the determining authority decides this information cannot be held confidential, PCTEST Lab will inform the Lab as to their intentions to appeal that decision or accept the decision. In the event PCTEST Lab accepts the decision, we will not pursue continued confidential treatment of the report and will assist the Lab in any way possible regarding correcting existing records. 4. Please find attached the revised operational description of CDMA mode. 5. EXAMPLE: Channel 0363 mode 2 nd harmonic (1671.78 MHz). The receive analyzer reading at 3 meters with the EUT on the turn table was —91.8 dBm. The gain of the substitute antenna is 6.1 dBd. The signal generator connected to the substituted antenna terminals is adjusted to produce a reading of -91.8 dBm on the receive analyzer. The cable loss of the cable between the signal generator and the terminals of the substituted antenna is 1.0 dB at 1671.78 MHz. So 5.1 dB is added to the signal generator reading of —51.77 dBm yielding —46.67 dBm. The fundamental ERP was 25.833 dBm so this harmonic was 25.833 dBm — (-46.67 dBm) = 72.5 dBc. We trust this information is sufficient to resolve FCC questions in this application. If you have any further questions, please do not hesitate to contact us. cc: Samsung Electronics Co., Ltd.

July 16, 2002 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Martin Perrine SUBJECT: Samsung Electronics Co., Ltd. FCC ID: A3LSPHA512 731 Confirmation No.: TC853134 Correspondence Reference No.: 4475 Request for Tech. Info.: 6/21/02 Dear Martin: Transmitted herewith, on behalf of Samsung Electronics Co., Ltd. is an amendment provided in response to the request for technical information dated July 11, 2002. 1. Please find attached SAR calibration and calculations made for the system/probe calibration (PCTEST Operational Description — Confidential filing). Furthermore, please find attached the revised Probe Calibration Process (page 7). 2. Please find attached the supporting test data. We trust this information is sufficient to resolve FCC questions in this application. If you have any further questions, please do not hesitate to contact us. cc: Samsung Electronics Co., Ltd.

July 18, 2002 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Att: Richard Fabina Chief, Equipment Authorization Branch Re: SAR Report submitted with FCC ID: A3LSPHA512 Confidentiality Request Gentlemen: Pursuant to Sections 0.457 and 0.459 of CFR Title 47 FCC Rules and Regulations, PCTEST Lab request confidentiality for the SAR report submitted as an attachment(s) to the subject application for certification for the reference FCC ID: A3LSPHA512. The attachment(s) to the application is (are) identified as "PCTEST Operational Description SAR Calibration Report" is marked confidential. This report contains trade secrets and commercial information that are customarily guarded from competitors and are never released to the public. Section 0.457(d)(2) stipulates that such material will be withheld from routine inspection if it is shown that the material contains the type of information specified in the preceding statement. Specifically, the PCTEST Operational Description SAR Calibration Report contains processes and procedures developed by PCTEST Lab that enable RF Exposure tests performed at PCTEST Lab to meet the stringent requirements of the most recent FCC released Supplement C guidelines for performing such measurements. Disclosure of this information to competitors will result in material harm to PCTEST Lab. Please contact the undersigned by telephone at 410-290-6652, or by email at [email protected] or by correspondence at the above address if there are any further questions or additional information needed concerning this request for confidentiality. Regards,

July 26, 2002 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Re: Withdrawal of Confidentiality Request FCC ID: A3LSCHA512 Gentlemen: PCTEST TCB has removed or is removing the check mark from the confidentiality request box for the reference item in compliance with your request. This action insures that all requests and other issues raised by the Commission in regard to their post grant review of this application has been addressed. In regard to the original request for confidentiality of the subject business documents, it is understood that such a request should be addressed through a different venue. Accordingly, we are withdrawing the confidentiality request and the test firm, in this case PCTEST Lab, is considering addressing the confidentiality issues directly as a policy matter with the Commission. Should you have any questions or comments concerning the above, please contact the undersigned.

© 2002 PCTEST Lab SAMSUNG FCC ID: A3LSCHA512 Single-Mode CDMA Phone (Model: SCH-A512) © 2002 PCTEST Lab SAMSUNG FCC ID: A3LSCHA512 Single-Mode CDMA Phone (Model: SCH-A512) © 2002 PCTEST Lab SAMSUNG FCC ID: A3LSCHA512 Single-Mode CDMA Phone (Model: SCH-A512) © 2002 PCTEST Lab SAMSUNG FCC ID: A3LSCHA512 Single-Mode CDMA Phone (Model: SCH-A512) © 2002 PCTEST Lab SAMSUNG FCC ID: A3LSCHA512 Single-Mode CDMA Phone (Model: SCH-A512) © 2002 PCTEST Lab SAMSUNG FCC ID: A3LSCHA512 Single-Mode CDMA Phone (Model: SCH-A512) © 2002 PCTEST Lab SAMSUNG FCC ID: A3LSCHA512 Single-Mode CDMA Phone (Model: SCH-A512)

© 2002PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §§ 2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE) SAMSUNG ELECTRONICS CO., LTD. MODEL NO: SCH-A512 FCC ID: A3LSCHA512 MADE IN KOREA SAMSUNG ELECTRONICS CO., LTD

Mobile Antenna Performance Test -180 -90 0 90 180 5 0 -5-10-15-20-25-30 Unit : dBi Model : SCH-A512Serial : AZFCEXOpt. : PATTERNProtocol : CDMA_VFreq. : 824Date : 2002.01.29Max(X/Y) : -67/-1.5Min(X/Y) : 72/-4.71Average : -3.25Deviation : 3.21 Model : SCH-A512Serial : AZFCEXOpt. : PATTERNProtocol : CDMA_VFreq. : 837Date : 2002.01.29Max(X/Y) : -70/-1.18Min(X/Y) : 67/-4.32Average : -2.9Deviation : 3.14 Model : SCH-A512Serial : AZFCEXOpt. : PATTERNProtocol : CDMA_VFreq. : 849Date : 2002.01.29Max(X/Y) : -70/-0.05Min(X/Y) : 64/-3.17Average : -1.73Deviation : 3.12 Model : SCH-A512Serial : AZFCEXOpt. : PATTERNProtocol : CDMA_VFreq. : 869Date : 2002.01.29Max(X/Y) : -75/0.77Min(X/Y) : 64/-2.37Average : -0.93Deviation : 3.14 Model : SCH-A512Serial : AZFCEXOpt. : PATTERNProtocol : CDMA_VFreq. : 881Date : 2002.01.29Max(X/Y) : -65/0.76Min(X/Y) : 72/-2.39Average : -0.96Deviation : 3.15 Model : SCH-A512Serial : AZFCEXOpt. : PATTERNProtocol : CDMA_VFreq. : 894Date : 2002.01.29Max(X/Y) : -68/0.95Min(X/Y) : 72/-2.11Average : -0.74Deviation : 3.06 Mark 1 Mark 2 Degree 90.00 -90.00 Value(dB) -4.62 -1.66 Value(dB) -4.23 -1.39 Value(dB) -3.10 -0.20 Value(dB) -2.27 0.62 Value(dB) -2.31 0.60 Value(dB) -2.03 0.79 Mobile Antenna Performance Test -180 -90 0 90 180 5 0 -5-10-15-20-25-30 Unit : dBi Model : SCH-A512Serial : AZFCREOpt. : PATTERNProtocol : CDMA_VFreq. : 824Date : 2002.01.29Max(X/Y) : -65/-4.07Min(X/Y) : 70/-7.79Average : -6.07Deviation : 3.72 Model : SCH-A512Serial : AZFCREOpt. : PATTERNProtocol : CDMA_VFreq. : 837Date : 2002.01.29Max(X/Y) : -62/-3.49Min(X/Y) : 68/-7.12Average : -5.43Deviation : 3.63 Model : SCH-A512Serial : AZFCREOpt. : PATTERNProtocol : CDMA_VFreq. : 849Date : 2002.01.29Max(X/Y) : -62/-2.08Min(X/Y) : 64/-5.66Average : -3.98Deviation : 3.58 Model : SCH-A512Serial : AZFCREOpt. : PATTERNProtocol : CDMA_VFreq. : 869Date : 2002.01.29Max(X/Y) : -67/-0.96Min(X/Y) : 75/-4.57Average : -2.86Deviation : 3.61 Model : SCH-A512Serial : AZFCREOpt. : PATTERNProtocol : CDMA_VFreq. : 881Date : 2002.01.29Max(X/Y) : -67/-0.84Min(X/Y) : 70/-4.46Average : -2.77Deviation : 3.62 Model : SCH-A512Serial : AZFCREOpt. : PATTERNProtocol : CDMA_VFreq. : 894Date : 2002.01.29Max(X/Y) : -67/-0.43Min(X/Y) : 67/-3.91Average : -2.3Deviation : 3.48 Mark 1 Mark 2 Degree 90.00 -90.00 Value(dB) -7.68 -4.34 Value(dB) -7.00 -3.74 Value(dB) -5.54 -2.26 Value(dB) -4.46 -1.20 Value(dB) -4.34 -1.07 Value(dB) -3.84 -0.63 Mobile Antenna Performance Test -180 -90 0 90 180 5 0 -5-10-15-20-25-30 Unit : dBi Model : SCH-A512Serial : AZFOEXOpt. : PATTERNProtocol : CDMA_VFreq. : 824Date : 2002.01.29Max(X/Y) : 145/-1.7Min(X/Y) : 10/-3.94Average : -2.71Deviation : 2.24 Model : SCH-A512Serial : AZFOEXOpt. : PATTERNProtocol : CDMA_VFreq. : 837Date : 2002.01.29Max(X/Y) : 142/-1.39Min(X/Y) : 13/-3.66Average : -2.43Deviation : 2.27 Model : SCH-A512Serial : AZFOEXOpt. : PATTERNProtocol : CDMA_VFreq. : 849Date : 2002.01.29Max(X/Y) : 145/-0.5Min(X/Y) : 0/-2.73Average : -1.52Deviation : 2.23 Model : SCH-A512Serial : AZFOEXOpt. : PATTERNProtocol : CDMA_VFreq. : 869Date : 2002.01.29Max(X/Y) : 140/0.19Min(X/Y) : 8/-2.02Average : -0.82Deviation : 2.21 Model : SCH-A512Serial : AZFOEXOpt. : PATTERNProtocol : CDMA_VFreq. : 881Date : 2002.01.29Max(X/Y) : 131/0.29Min(X/Y) : 5/-1.91Average : -0.7Deviation : 2.2 Model : SCH-A512Serial : AZFOEXOpt. : PATTERNProtocol : CDMA_VFreq. : 894Date : 2002.01.29Max(X/Y) : 129/0.3Min(X/Y) : 6/-1.95Average : -0.76Deviation : 2.25 Mark 1 Mark 2 Degree 90.00 -90.00 Value(dB) -2.28 -2.81 Value(dB) -1.96 -2.60 Value(dB) -1.02 -1.70 Value(dB) -0.29 -1.01 Value(dB) -0.12 -0.94 Value(dB) -0.05 -1.05 Mobile Antenna Performance Test -180 -90 0 90 180 5 0 -5-10-15-20-25-30 Unit : dBi Model : SCH-A512Serial : AZFOREOpt. : PATTERNProtocol : CDMA_VFreq. : 824Date : 2002.01.29Max(X/Y) : 166/-3.08Min(X/Y) : 11/-5.26Average : -3.93Deviation : 2.18 Model : SCH-A512Serial : AZFOREOpt. : PATTERNProtocol : CDMA_VFreq. : 837Date : 2002.01.29Max(X/Y) : 142/-2.65Min(X/Y) : 10/-4.81Average : -3.52Deviation : 2.16 Model : SCH-A512Serial : AZFOREOpt. : PATTERNProtocol : CDMA_VFreq. : 849Date : 2002.01.29Max(X/Y) : 158/-1.69Min(X/Y) : 13/-3.83Average : -2.55Deviation : 2.14 Model : SCH-A512Serial : AZFOREOpt. : PATTERNProtocol : CDMA_VFreq. : 869Date : 2002.01.29Max(X/Y) : 143/-0.97Min(X/Y) : 15/-3.11Average : -1.83Deviation : 2.14 Model : SCH-A512Serial : AZFOREOpt. : PATTERNProtocol : CDMA_VFreq. : 881Date : 2002.01.29Max(X/Y) : 129/-0.87Min(X/Y) : 8/-3.07Average : -1.76Deviation : 2.2 Model : SCH-A512Serial : AZFOREOpt. : PATTERNProtocol : CDMA_VFreq. : 894Date : 2002.01.29Max(X/Y) : 129/-0.92Min(X/Y) : 0/-3.12Average : -1.82Deviation : 2.2 Mark 1 Mark 2 Degree 90.00 -90.00 Value(dB) -3.67 -3.79 Value(dB) -3.21 -3.40 Value(dB) -2.21 -2.47 Value(dB) -1.42 -1.83 Value(dB) -1.25 -1.74 Value(dB) -1.30 -1.88 Mobile Antenna Performance Test -180 -90 0 90 180 5 0 -5-10-15-20-25-30 Unit : dBi Model : SCH-A512Serial : E1FCEXOpt. : PATTERNProtocol : CDMA_HFreq. : 824Date : 2002.01.29Max(X/Y) : -105/-2.9Min(X/Y) : 156/-36.64Average : -9.66Deviation : 33.74 Model : SCH-A512Serial : E1FCEXOpt. : PATTERNProtocol : CDMA_HFreq. : 837Date : 2002.01.29Max(X/Y) : -103/-2.06Min(X/Y) : 156/-32.45Average : -9.07Deviation : 30.39 Model : SCH-A512Serial : E1FCEXOpt. : PATTERNProtocol : CDMA_HFreq. : 849Date : 2002.01.29Max(X/Y) : -104/-1.28Min(X/Y) : 156/-29.69Average : -8.33Deviation : 28.41 Model : SCH-A512Serial : E1FCEXOpt. : PATTERNProtocol : CDMA_HFreq. : 869Date : 2002.01.29Max(X/Y) : -103/-0.76Min(X/Y) : 154/-31.32Average : -7.73Deviation : 30.56 Model : SCH-A512Serial : E1FCEXOpt. : PATTERNProtocol : CDMA_HFreq. : 881Date : 2002.01.29Max(X/Y) : -103/-0.79Min(X/Y) : 154/-31.29Average : -7.87Deviation : 30.5 Model : SCH-A512Serial : E1FCEXOpt. : PATTERNProtocol : CDMA_HFreq. : 894Date : 2002.01.29Max(X/Y) : -102/-0.27Min(X/Y) : 154/-32.1Average : -7.65Deviation : 31.83 Mark 1 Mark 2 Degree 90.00 -90.00 Value(dB) -5.04 -3.24 Value(dB) -4.64 -2.48 Value(dB) -3.89 -…

Text truncated - open the document above for the full version.

PCTEST ENGINEERING LABORATORY, INC. 6660 — B Dobbin Road • Columbia, MD 21045 • USA Telephone 410.290.6652 / Fax 410.290.6654 http://www.pctestlab.com (email: [email protected]) CERTIFICATE OF COMPLIANCE (SAR EVALUATION) PCTEST SAR TEST REPORT SAR EVALUATION REPORT Reviewed by: Quality Manager SAR Filename: 22.220401142.A3L Test Dates: April 1-3, 2002 Phone Type: Single-Mode CDMA FCC ID: A3LSCHA512 Page 1 of 25 © 2002 PCTEST Engineering Laboratory, Inc. APPLICANT NAME & ADDRESS: DATE & LOCATION OF TESTING: Samsung Electronics Co., Ltd. Dates of Tests: April 1-3, 2002 416 Maetan-3 Dong, Paldal-Ku Test Report S/N: 22.220401142.A3L Suwon City Kyungki-Do Test Site: PCTEST Lab, Columbia, MD USA 441-742, KOREA Attn: Wallace Oh, Engineering Manager FCC ID: A3LSCHA512 APPLICANT: Samsung Electronics Co., Ltd. EUT Type: Single-Mode CDMA Cellular Phone Tx Frequency: 824.70 — 848.31 MHz (CDMA) Rx Frequency: 869.70 — 893.31 MHz (CDMA) Max. RF Output Power: 0.383 W ERP CDMA (25.833dBm) / 25.0 dBm Conducted Max. SAR Measurement: 1.46 W/kg CDMA Head SAR; 1.47 W/kg CDMA Body SAR; Trade Name/Model(s): SCH-A512 FCC Classification: Non-Broadcast Transmitter Held to Ear (TNE) FCC Rule Part(s): §2.1093; FCC/OET Bulletin 65 Supplement C [July 2001] Application Type: Certification Test Device Serial No.: Identical prototype This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in FCC/OET Bulletin 65 Supplement C (2001)and IEEE Std. 1528-200X (Draft 6.4, July 2001). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsib…

Text truncated - open the document above for the full version.
