1 of 31 SAMSUNG ELECTRONICS Co., Ltd., Regulatory Compliance Team IT R&D Center 416, Maetan-3dong, Yeongtong-gu, Suwon-si, Gyeonggi-do, Korea 443-742 TEST REPORT ON SAR Model Tested: SCH-A630 FCC ID (Requested): A3LSCHA630 Job No: FC-076 Report No: FC-076-S1 Date issued: Jun. 16, 2005 - Abstract – This document reports on SAR Tests carried out in accordance with FCC/OET Bulletin 65, Supplement C(July 2001). Prepared By Date JH NAM– Test Engineer Checked By Date SH PARK - Senior Manager Authorized By Date JK CHOI – General Manager 2005.06.16 2005.06.16 2005.06.16 Report Number : FC-076-S1 2 of 31 Contents 1. General Information.............................................................................................3 2. Description of Device...........................................................................................3 3. Description of Test Equipment..............................................................................4 3.1 SAR Measurement Setup.........................................................................................4 3.2 DASY4 E-Field Probe.............................................................................................5 3.3 SAM Phantom.....................................................................................................6 3.4 Brain & Muscle Simulating Mixture Characterization....................................................7 3.5 Device Holder for transmitters.................................................................................8 3.6 Validation Dipole...................................................................................................8 3.7 Equipment Calibration.............................................................................................9 4. SAR Measurement Procedure.............................................................................10 5. Description of test position..............................................................................11 5.1 SAM Phantom Shape............................................................................................11 5.2 Cheek/Touch Position............................................................................................11 5.3 Ear/Tilt 15 Position..............................................................................................13 5.4 Body/Leather Configuration.....................................................................................14 6. Measurement Uncertainty...................................................................................16 7. System Verification............................................................................................18 7.1 Tissue Verification.................................................................................................18 7.2 Test System Validation...........................................................................................18 8. SAR Measurement Results.................................................................................19 8.1 Measurement Results(CELLULAR CDMA Right Head SAR-Touch).................................20 8.2 Measurement Results(CELLULAR CDMA Right Head SAR-Tilt).....................................21 8.3 Measurement Results(CELLULAR CDMA Left Head SAR-Touch)...................................22 8.4 Measurement Results(CELLULAR CDMA Left Head SAR-Tilt).......................................23 8.5 Measurement Results(PCS CDMA Right Head SAR-Touch)..........................................24 8.6 Measurement Results(PCS CDMA Right Head SAR-Tilt)..............................................25 8.7 Measurement Results(PCS CDMA Left Head SAR-Touch)............................................26 8.8 Measurement Results(PCS CDMA Left Head SAR-Tilt)................................................27 8.9 Measurement Results(CELLULAR CDMA Body SAR with Holster)..................................28 8.10 Measurement Results(PCS CDMA Body SAR with Holster)...........................................29 9. Conclusion.......................................................................................................30 10. Reference.......................................................................................................31 Report Number : FC-076-S1 3 of 31 1. GENERAL INFORMATION Test Sample : Dual-Band CDMA Phone Model Number : SCH-A630 Serial Number : Identical prototype (S/N : # FC-076-H ) Manufacturer : SAMSUNG ELECTRONICS Co., Ltd. Contact : KJ CHOI, Engineer Phone : +82-54-479-7638 Fax : +82-54-479-5921 Test Standard : §2.1093; FCC/OET Bulletin 65, Supplement C(July 2001) FCC Classification : Licensed Portable Transmitter Held to Ear (PCE) Test Dates : Jun. 07, 2005 ~ Jun. 08, 2005 Tested for : FCC/TCB Certification 2. DESCRIPTION OF DEVICE Tx Freq. Range : 824.70 – 848.31 MHz (CDMA) 1851.25 – 1908.75 MHz (PCS CDMA) Rx Freq. Range : 869.70 – 893.31 MHz (CDMA) 1931.25 – 1988.75 MHz (PCS CDMA) Max. RF Output Power : 0.2944 W ERP CDMA (24.69dBm) 0.542 W EIRP PCS (27.34dBm) Antenna Manufacturer : SAMSUNG Electro-Mechanics Co. Ltd Model No.: SCH-A630 Antenna Dimensions : 41.5 mm 19.8 mm10.7mm [INTENNA] Report Number : FC-076-S1 4 of 31 3. DESCRIPTION OF TEST EQUIPMENT 3.1 SAR Measurement Setup Robotic System Measurements are performed using the DASY4 automated dosimetric assessment system. Which is made by Schmid & Partner Engineering AG (SPEAG) in Zurich, Switzerland and consists of high precision robotics system (Stäubli), robot controller, measurement server, Samsung computer, near- field probe, probe alignment sensor, and the SAM twin phantom containing the brain equivalent material. The robot is a six-axis industrial robot performing precise movements to position the probe to the location (points) of maximum electromagnetic field (EMF) (see Fig. 3.1). Figure 3.1 SAR Measurement System Setup System Hardware A cell controller system contains the power supply, robot controller, teach pendant (Joystick), an…

Text truncated - open the document above for the full version.

APPENDIX G Plots of The SAR Measurements SAMSUNG FCC ID : A3LSCHA630 -- 835MHz CDMA Head SAR DUT: SCH-A630; Serial: FC-076-H Program Name: SCH-A630 CDMA Right (Job No. : FC-076) Procedure Name: Cheek/Touch, Ch.1013, Ant.Intenna, Bat. Extended Procedure Notes: Meas.Tissue Temp(celsius)-21.4;Test Date-8/Jun/2005[OET Bulletin 65- Supplement C, July 2001] Communication System: CDMA; Frequency: 824.7 MHz;Duty Cycle: 1:1 Medium parameters used: f = 824.7 MHz; σ = 0.92 mho/m; ε r = 41.8; ρ = 1000 kg/m 3 Phantom section: Right Section DASY4 Configuration: - Probe: ES3DV2 - SN3017; ConvF(6.33, 6.33, 6.33); Calibrated: 2004-09-24 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn533; Calibrated: 2004-12-03 - Phantom: SAM 835/900 MHz; Type: SAM; Serial: TP-1141 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Cheek/Touch, Ch.1013, Ant.Intenna, Bat. Extended/Area Scan (51x71x1): Measurement grid: dx=20mm, dy=20mm Maximum value of SAR (interpolated) = 0.745 mW/g Cheek/Touch, Ch.1013, Ant.Intenna, Bat. Extended/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 8.75 V/m; Power Drift = 0.016 dB Peak SAR (extrapolated) = 0.958 W/kg SAR(1 g) = 0.713 mW/g Maximum value of SAR (measured) = 0.761 mW/g 0 dB = 0.761mW/g SAMSUNG FCC ID : A3LSCHA630 -- 835MHz CDMA Head SAR DUT: SCH-A630; Serial: FC-076-H Program Name: SCH-A630 CDMA Right (Job No. : FC-076) Procedure Name: Ear/Tilt, Ch.0363, Ant.Intenna, Bat. Extended Procedure Notes: Meas.Tissue Temp(celsius)-21.4;Test Date-8/Jun/2005[OET Bulletin 65- Supplement C, July 2001] Communication System: CDMA; Frequency: 835.89 MHz;Duty Cycle: 1:1 Medium parameters used: f = 835.89 MHz; σ = 0.92 mho/m; ε r = 41.8; ρ = 1000 kg/m 3 Phantom section: Right Section DASY4 Configuration: - Probe: ES3DV2 - SN3017; ConvF(6.33, 6.33, 6.33); Calibrated: 2004-09-24 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn533; Calibrated: 2004-12-03 - Phantom: SAM 835/900 MHz; Type: SAM; Serial: TP-1141 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Ear/Tilt, Ch.0363, Ant.Intenna, Bat. Extended/Area Scan (51x71x1): Measurement grid: dx=20mm, dy=20mm Maximum value of SAR (interpolated) = 0.101 mW/g Ear/Tilt, Ch.0363, Ant.Intenna, Bat. Extended/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 5.76 V/m; Power Drift = -0.092 dB Peak SAR (extrapolated) = 0.120 W/kg SAR(1 g) = 0.095 mW/g Maximum value of SAR (measured) = 0.099 mW/g 0 dB = 0.099mW/g SAMSUNG FCC ID : A3LSCHA630 -- 835MHz CDMA Head SAR DUT: SCH-A630; Serial: FC-076-H Program Name: SCH-A630 CDMA Left (Job No. : FC-076) Procedure Name: Cheek/Touch, Ch.1013, Ant.Intenna, Bat. Extended Procedure Notes: Meas.Tissue Temp(celsius)-21.4;Test Date-8/Jun/2005[OET Bulletin 65- Supplement C, July 2001] Communication System: CDMA; Frequency: 824.7 MHz;Duty Cycle: 1:1 Medium parameters used: f = 824.7 MHz; σ = 0.92 mho/m; ε r = 41.8; ρ = 1000 kg/m 3 Phantom section: Left Section DASY4 Configuration: - Probe: ES3DV2 - SN3017; ConvF(6.33, 6.33, 6.33); Calibrated: 2004-09-24 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn533; Calibrated: 2004-12-03 - Phantom: SAM 835/900 MHz; Type: SAM; Serial: TP-1141 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Cheek/Touch, Ch.1013, Ant.Intenna, Bat. Extended/Area Scan (51x71x1): Measurement grid: dx=20mm, dy=20mm Maximum value of SAR (interpolated) = 0.651 mW/g Cheek/Touch, Ch.1013, Ant.Intenna, Bat. Extended/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 9.00 V/m; Power Drift = -0.041 dB Peak SAR (extrapolated) = 0.816 W/kg SAR(1 g) = 0.633 mW/g Maximum value of SAR (measured) = 0.657 mW/g 0 dB = 0.657mW/g SAMSUNG FCC ID : A3LSCHA630 -- 835MHz CDMA Head SAR DUT: SCH-A630; Serial: FC-076-H Program Name: SCH-A630 CDMA Left (Job No. : FC-076) Procedure Name: Ear/Tilt, Ch.0363, Ant.Intenna, Bat. Extended Procedure Notes: Meas.Tissue Temp(celsius)-21.4;Test Date-8/Jun/2005[OET Bulletin 65- Supplement C, July 2001] Communication System: CDMA; Frequency: 835.89 MHz;Duty Cycle: 1:1 Medium parameters used: f = 835.89 MHz; σ = 0.92 mho/m; ε r = 41.8; ρ = 1000 kg/m 3 Phantom section: Left Section DASY4 Configuration: - Probe: ES3DV2 - SN3017; ConvF(6.33, 6.33, 6.33); Calibrated: 2004-09-24 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn533; Calibrated: 2004-12-03 - Phantom: SAM 835/900 MHz; Type: SAM; Serial: TP-1141 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Ear/Tilt, Ch.0363, Ant.Intenna, Bat. Extended/Area Scan (51x71x1): Measurement grid: dx=20mm, dy=20mm Maximum value of SAR (interpolated) = 0.121 mW/g Ear/Tilt, Ch.0363, Ant.Intenna, Bat. Extended/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 6.40 V/m; Power Drift = -0.073 dB Peak SAR (extrapolated) = 0.138 W/kg SAR(1 g) = 0.110 mW/g Maximum value of SAR (measured) = 0.114 mW/g 0 dB = 0.114mW/g SAMSUNG FCC ID : A3LSCHA630 -- 835MHz CDMA Body SAR DUT: SCH-A630(Body); Serial: FC-076-H Program Name: SCH-A630 CDMA Body (Job No. : FC-076) Procedure Name: Body, Ch. 1013, Ant. Intenna, Bat. Standard with holster rotation -90 degree Procedure Notes: Meas.Tissue Temp(celsius)-21.2;Test Date-8/Jun/2005[OET Bulletin 65- Supplement C, July 2001] Communication System: CDMA; Frequency: 824.7 MHz;Duty Cycle: 1:1 Medium parameters used: f = 824.7 MHz; σ = 0.97 mho/m; ε r = 53.6; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: - Probe: ES3DV2 - SN3017; ConvF(6.28, 6.28, 6.28); Calibrated: 2004-09-24 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn533; Calibrated: 2004-12-03 - Phantom: SAM 1800/1900 MHz; Type: SAM; Serial: TP-1143 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Body, Ch. 1013, Ant. Intenna, Bat. St…

Text truncated - open the document above for the full version.

APPENDIX H Probe Calibration

APPENDIX F The Validation Measurements DUT: Dipole 835 MHz; Serial: 451 Program Name: 835MHz Dipole Validation 2005.06.08 Procedure Name: 835MHz @ 250mW Procedure Notes: Communication System: CDMA; Frequency: 835 MHz;Duty Cycle: 1:1 Medium parameters used: f = 835 MHz; σ = 0.92 mho/m; ε r = 41.8; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: - Probe: ES3DV2 - SN3017; ConvF(6.33, 6.33, 6.33); Calibrated: 2004-09-24 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn533; Calibrated: 2004-12-03 - Phantom: SAM 835/900 MHz; Type: SAM; Serial: TP-1141 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 835MHz @ 250mW/Area Scan (51x51x1): Measurement grid: dx=20mm, dy=20mm Maximum value of SAR (interpolated) = 2.69 mW/g 835MHz @ 250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 51.0 V/m; Power Drift = -0.01 dB Peak SAR (extrapolated) = 3.67 W/kg SAR(1 g) = 2.45 mW/g Maximum value of SAR (measured) = 2.64 mW/g 0 dB = 2.64mW/g DUT: Dipole 1900 MHz; Serial: 5d023 Program Name: 1900 Dipole Validation 2005.06.07 Procedure Name: 1900MHz @250mW Procedure Notes: Communication System: CW; Frequency: 1900 MHz;Duty Cycle: 1:1 Medium parameters used: f = 1900 MHz; σ = 1.43 mho/m; ε r = 38.4; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: - Probe: ES3DV2 - SN3017; ConvF(5.11, 5.11, 5.11); Calibrated: 2004-09-24 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn533; Calibrated: 2004-12-03 - Phantom: SAM 1800/1900 MHz; Type: SAM; Serial: TP-1143 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 1900MHz @250mW/Area Scan (51x51x1): Measurement grid: dx=20mm, dy=20mm Maximum value of SAR (interpolated) = 16.0 mW/g 1900MHz @250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 91.1 V/m; Power Drift = -0.097 dB Peak SAR (extrapolated) = 18.5 W/kg SAR(1 g) = 10.3 mW/g Maximum value of SAR (measured) = 11.6 mW/g 0 dB = 11.6mW/g
