SAM PLE LABEL 1 FCC RULES ¡×2.925 SAMPLE LABEL MODEL NO : VR4AH FCC ID : A3LSCORPIO LOCATION OF THE LABEL SAM PLE LABEL 2 FCC RULES ¡×15.19 THIS DEVIES COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1)THIS DEVICE MAY NOY CAUSE HARMFUL INTERFERENCE, AND (2)THIS DEVICE MUST ACCEPT ANY INTERFEREN E RE EIVED IN LUDING INTERFEREN E THAT LOCATION OF STATEMENT

JOB Nunber : SEMC853B Page 1 of 25 EMC TEST REPORT JOB Nunber : SEMC853B 1. Applicant Name :SAMSUNG ELECTRONICS CO., LTD. 416 Maetan 3 Dong, Paldal-Ku, Suwon City, Kyungki Do, Korea, 442-742 2. Identification of tested device 2.1 FCC ID :A3LSCORPIO 2.2 Device Name :VIDEO CASSETTE RECORDER 2.3 Trade Name :RCA 2.4 Model Number :VR4AH 3. Test Procedure and Items 3.1 AC Powerline Conducted Emissions Measurement : ANSI C63.4-1992 3.2 Radiated Emissions Measurement : ANSI C63.4-1992 3.3 Output Signal Level Measurement : ANSI C63.4-1992 3.4 Output Terminal Conducted Spurious Emission Measurement : ANSI C63.4-1992 3.5 Antenna Transfer Switch Measurement : ANSI C63.4-1992 3.6 Receiver Radiated Emissions Measurement : EN55013:1990+A12:1994+A13:1996 4. Issued Date :September 26, 2000 Tested by: No Cheon, PARK / Test Engineer Reviewed by: Seung Kyu, CHA / Manager of EMC Lab. Authorised by: Taek Jeong, SHIN / Chief of EMC Lab. This reports shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. JOB Nunber : SEMC853B Page 2 of 25 TABLE OF CONTENTS 1. GENERAL INFORMATION 2. TESTED SYSTEM 3. AC POWERLINE CONDUCTED EMISSION MEASUREMENT 4. RADIATED EMISSION MEASUREMENT 5. OUTPUT SIGNAL LEVEL MEASUREMENT 6. OUTPUT TERMINAL CONDUCTED SPURIOUS EMISSION MEASUREMENT 7. ANTENNA TRANSFER SWITCH MEASUREMENT 8. RECEIVER RADIATED EMISSION MEASUREMENT 9. LIST OF TEST INSTRUMENTS This reports shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. JOB Nunber : SEMC853B Page 3 of 25 1. GENERAL INFORMATION 1.1 Description for Equipment Authorization 1.1.1 Rules Part(s) under which Equipment Authorization FCC Rule Part 15, Subpart B : Unintentional Radiators TV Interface Devices. This Product is a Video Cassette Recorder containing RF modulator. 1.1.2 Kind of Equipment Authorization : CERTIFICATION 1.1.3 FCC ID Number : A3LSCORPIO 1.1.4 Applied TM-BLOCK (RF Units) :Made by SANYO : AC40-00007A 1.1.5 RF Modulator Frequency :CH.3 Visual Carrier 61.25MHz, Aural Carrier 65.75MHz CH.4 Visual Carrier 67.25MHz, Aural Carrier 71.75MHz 1.1.6 Rate Power Supply : AC 120V, 60Hz 1.1.7 Type of RF Output Connector : Type "F" Connector 75ߟ(Unbalanced) This reports shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. JOB Nunber : SEMC853B Page 4 of 25 2. TESTED SYSTEM 2.1 Block Diagram of Tested Device System for Conducted and Radiated Emission Measurements 2.1.1 With the VITS Signal Generator AC Power cord : unshielded, 2pin type (Permanently attached to the EUT) 2.1.2 With the NTSC TV Signal Generator This reports shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. AC120V, 60Hz NTSC TV Signal Generator °Á75ߟ Coaxial cable :shielded, length 1.4m (accessory of the EUT) ANT in Out to TV(RF OUT) (75ߟ Terminator) AC120V, 60Hz VITS Signal Generator °Á75ߟ Coaxial cable :shielded, length 1.4m (accessory of the EUT) ANT in (75ߟ Terminator) Out to TV(RF OUT) (75ߟ Terminator) EUT EUT JOB Nunber : SEMC853B Page 5 of 25 3. AC POWERLINE CONDUCTED EMISSION MEASUREMENT 3.1 Reference Rule and Specification FCC Rule Part 15, Section 15.107(a) 3.2 Test Procedure 3.2.1 Configurate the EUT System in accordance with ANSI C63.4-1992 section 7 and 12.2. See also the block diagram of tested device configuration in this report. 3.2.2 Connect the EUT's AC line cord to the EUT port of LISN. 3.2.3 All input terminals are terminated in the proper impedance. The output ports are connected to the cable provided with the device and the ending port are terminated in the proper impedance. 3.2.4 Activates the EUT system 3.2.5 Using a calibrated coaxial cable, the TEST RECEIVER is connected to the measuring port of the LISN for EUT. 3.2.6 To the find out an EUT condition procedures the maximum emission, the position of cables, EUT operations mode are checked under normal usage of EUT. 3.2.7 Then, the emission are scanned from 0.45MHz to 30MHz relative to the limit are recorded. This reports shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. JOB Nunber : SEMC853B Page 6 of 25 3.3 Test Results 3.3.1 EUT Mode : Playback FrequencyTotalResultsLimitsMargin Loss(b)(a) + (b) [MHz]L1L2[dB] [dBß≈][dBß≈] [dB] 0.47535.637.20.137.348-10.7 1.30537.337.60.137.748-10.3 1.5936.232.90.136.348-11.7 2.37932.832.60.132.948-15.1 14.31730.730.10.33148-17 28.63543.542.70.343.848-4.2 * Margin = Result - Limits 3.3.2 EUT Mode : Recording(VITS 1Vp-p & 5Vp-p) FrequencyTotalResultsLimitsMargin Loss(b)(a) + (b) [MHz]L1L2[dB] [dBß≈][dBß≈] [dB] 0.47525.526.60.126.748-21.3 1.51226.828.30.128.448-19.6 3.14123.425.70.125.848-22.2 6.74138.139.10.239.348-8.7 14.31633.533.10.333.848-14.2 28.63545.344.60.345.648-2.4 * Margin = Result - Limits 3.3.3 EUT Mode : Recording(NTSC Signal) FrequencyTotalResultsLimitsMargin Loss(b)(a) + (b) [MHz]L1L2[dB] [dBß≈][dBß≈] [dB] 0.5552723.80.127.148-20.9 1.34723.325.20.125.348-22.7 1.97730.527.50.130.648-17.4 5.84438.839.10.239.348-8.7 14.31945.245.30.345.648-2.4 28.63943.543.20.343.848-4.2 * Margin = Result - Limits This reports shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Meter reading(a) LISN Port Meter reading(a) LISN Port Meter reading(a) LISN Port JOB Nunber : SEMC853B Page 7 of 25 4. RADIATED EMISSION MEASUREMENT 4.1 Reference Rule and Specification FCC Rule Part 15, Section 15.109(a) and (c) 4.2 Test Procedure 4.2.1 Configurate the EUT System in accordance with ANSI C63.4-1992section 8 and 12.2. See also the block diagram and photographs of tested configuration for radiated emission measurement in this report. 4.2.2 Power cords for the EUT System are connected the receptacle on the ground plane. The output ports are connected to the cable provided with the device and the ending port of the cable are terminated in the proper impedance. 4.2.3 Activates the EUT system. To find out th…

Text truncated - open the document above for the full version.

EUT Photograph Fig. 1 Test Setup for AC Powerline Conducted Emissions Measurement EUT Photograph Fig. 2 Test Setup for Radiated Emissions Measurement EUT Photograph Fig. 3 Test Setup for Output Signal Level & & Output Terminal Conducted Spurious Emission Measurement EUT Photograph Fig. 4 Test Setup for Antenna Transfer Switch Measurement
