A3LSCX4200Multi Function Printer

1 © 2005 Samsung Electronics Co., Ltd. All rights reserved. This manual is provided for information purposes only. All information included herein is subject to change without notice. Samsung Electronics is not responsible for any direct or indirect damages, arising from or related to use of this manual. • SCX-4200 is model names of Samsung Electronics Co., Ltd. • Samsung and Samsung logo are trademarks of Samsung Electronics Co., Ltd. • IBM and IBM PC are trademarks of International Business Machines Corporation. • PCL and PCL 6 are trademarks of Hewlett-Packard company. • Microsoft, Windows, Windows 98, Windows Me, Windows 2000, and Windows XP are registered trademarks of Microsoft Corporation. • TrueType, LaserWriter and Macintosh are trademarks of Apple Computer, Inc. • All other brand or product names are trademarks of their respective companies or organizations. 2 Contact SAMSUNG WORLD WIDE If you have any comments or questions regarding Samsung products, contact the SAMSUNG customer care center. CountryCustomer Care Center Web Site CANADA1-800-SAMSUNG (7267864)www.samsung.com/ca MEXICO01-800-SAMSUNG (7267864) www.samsung.com/mx U.S.A1-800-SAMSUNG (7267864)www.samsung.com ARGENTINE0800-333-3733www.samsung.com/ar BRAZIL0800-124-421www.samsung.com/br CHILE800-726-7864 (SAMSUNG)www.samsung.com/cl COSTA RICA0-800-507-7267www.samsung.com/latin ECUADOR1-800-10-7267www.samsung.com/latin EL SALVADOR800-6225www.samsung.com/latin GUATEMALA1-800-299-0013www.samsung.com/latin JAMAICA1-800-234-7267www.samsung.com/latin PANAMA800-7267www.samsung.com/latin PUERTO RICO1-800-682-3180www.samsung.com/latin REP. DOMINICA 1-800-751-2676www.samsung.com/latin TRINIDAD & TOBAGO 1-800-7267-864www.samsung.com/latin VENEZUELA1-800-100-5303www.samsung.com/latin BELGIUM02 201 2418www.samsung.com/be CZECH REPUBLIC 844 000 844www.samsung.com/cz DENMARK38 322 887www.samsung.com/dk FINLAND09 693 79 554www.samsung.com/fi FRANCE08 25 08 65 65 (€ 0,15/min) www.samsung.com/fr GERMANY01805 - 121213 (€ 0,12/min) www.samsung.de HUNGARY06 40 985 985www.samsung.com/hu ITALIA199 153 153www.samsung.com/it LUXEMBURG02 261 03 710www.samsung.lu NETHERLANDS0900 20 200 88 (€ 0.10/min) www.samsung.com/nl NORWAY231 627 22www.samsung.com/no POLAND0 801 801 881www.samsung.com/pl PORTUGAL80 8 200 128www.samsung.com/pt SLOVAKIA0850 123 989www.samsung.com/sk SPAIN902 10 11 30www.samsung.com/es SWEDEN08 585 367 87www.samsung.com/se U.K0870 242 0303www.samsung.com/uk RUSSIA8-800-200-0400www.samsung.ru UKRAINE8-800-502-0000www.samsung.com/ur AUSTRALIA1300 362 603www.samsung.com/au CHINA800-810-5858 010- 6475 1880 www.samsung.com.cn HONG KONG2862 6001www.samsung.com/hk INDIA3030 8282 1600 1100 11 www.samsung.com/in INDONESIA0800-112-8888www.samsung.com/id JAPAN0120-327-527www.samsung.com/jp MALAYSIA1800-88-9999www.samsung.com/my PHILIPPINES1800-10-SAMSUNG (7267864) www.samsung.com/ph SINGAPORE1800-SAMSUNG (7267864)www.samsung.com/sg THAILAND1800-29-3232 02-689-3232 www.samsung.com/th TAIWAN0800-329-999www.samsung.com/tw VIETNAM1 800 588 889www.samsung.com/vn SOUTH AFRICA0860 7267864 (SAMSUNG)www.samsung.com/za U.A.E800SAMSUNG (7267864)www.samsung.com/mea CountryCustomer Care Center Web Site 3 CONTENTS 1. Introduction Special features ..................................................................................................................... 1.1 Understanding component locations .......................................................................................... 1.2 2. Getting started Setting up your machine Finding more information ........................................................................................................ 2.1 Selecting a location ................................................................................................................ 2.2 Installing the toner cartridge ................................................................................................... 2.2 Loading paper ....................................................................................................................... 2.3 Making connections ................................................................................................................ 2.5 Turning the machine on .......................................................................................................... 2.5 Setting up the machine system Overview of control panel menus ............................................................................................. 2.6 Changing the display language ................................................................................................. 2.6 Using the save modes ............................................................................................................. 2.6 Printer software overview Supplied printer software ........................................................................................................ 2.7 Printer driver features ............................................................................................................. 2.7 System requirements ............................................................................................................. 2.8 3. Loading original documents and paper Loading document .................................................................................................................. 3.1 Selecting print materials ......................................................................................................... 3.2 Loading paper ....................................................................................................................... 3.5 Setting the paper size and type ................................................................................................ 3.6 Selecting an output location .................................................................................................... 3.6 4. Copying Copying .......................................................…

Text truncated - open the document above for the full version.

Specifications 10.1 10Specifications This chapter includes: • General specifications • Scanner and copier specifications • Printer specifications General specifications ItemDescription Model nameEG42MFC (SCX-4200) Paper input capacityTray with multi-pages: 250 multi-pages for plain paper (20 lb bond, 75 g/m 2 ) Tray with single page and manual tray: 1 single page for plain paper, transparencies, labels, Post Card and envelopes (16 ~43 lb bond, 60 ~ 165 g/m 2 ) Paper output capacity Face down: 50 sheets Face up: 1 sheet Consumables1-piece toner cartridge system Power rating110 - 127 VAC, 50/60 Hz, 4.0 A (USA, Canada) 220 - 240 VAC, 50/60 Hz, 2.5 A (Others) Power consumptionAverage: 350 W Power save mode: Less than 10 W Noise level a Standby mode: Less than 38 dBA Scanning / Printing mode: Less than 53 dBA Warm-up: Less than 53 dBA Warm-up timeLess than 42 seconds First print out timeStandby mode: less than 11 seconds Cold status: less than 53 seconds Operating environment Temperature: 50° F to 89° F (10° C to 32° C) Humidity: 20% to 80% RH Display16 characters x 2 lines Toner cartridge life b 3,000 pages at ISO 19752 5% coverage (Ships with 1,000 pages toner cartridge) Memory8 MB (Non-extendable) External dimension (W x D x H) 409 x 362 x 232 mm (16.1 x 14.3 x 9.1 inches) Weight9.3 Kg (including consumables) Package weightPaper: 1.8 Kg, Plastic: 0.4 Kg Scanner and copier specifications Duty cycleMonthly print: Up to 4,000 pages a Sound Pressure Level, ISO7779 b The number of pages may be affected by operating environment, printing interval, media type, and media size. ItemDescription CompatibilityTWAIN standard/ WIA standard Scanning methodColor CIS ResolutionOptical: Max. 600 x 2400 dpi (Mono and color) Enhanced: 4,800 x 4,800 dpi Effective scanning lengthMax. 297 mm (11.7 inches) Effective scanning widthMax. 216 mm (8.5 inches) Effective: 208 mm (8.2 inches) Color bit depth24 bit Mono bit depth1 bit for Black & White mode 8 bit for Gray mode Copy speed a a Copy Speed is based on Single Document Multiple Copy. Up to 18 ppm in A4 (19 ppm in Letter) Copy resolutionScan: up to 600 x 300 dpi (Text, Text/Photo) up to 600 x 600 dpi (Photo) Print: up to 600 x 600 dpi (Text, Text/Photo, Photo) Zoom rate50 ~ 200% Multiple copies1-99 pages Gray scale256 levels ItemDescription Specifications 10.2 Printer specifications ItemDescription Printing methodLaser Beam Printing Printing speed a a Print speed will be affected by operating system used, computing performance, applica- tion software, connecting method, media type, media size, and job complexity. Up to 18 ppm in A4 (19 ppm in Letter) First print out time11 seconds (From Ready) Print resolutionUp to 600 x 600 dpi Printer languageSPL (Samsung Printer Language) OS Compatibility b b Please visit www.samsungprinter.com to download the latest software version. Windows 98/Me/2000/XP, Various Linux OS (USB only), Macintosh 10.3/10.4 IntefaceUSB 2.0 1 INDEX Numerics 2-up, special copyG4.3 A auto fit, sepcial copyG4.2 C cleaning drum G8.2 insideG8.1 LSUG8.2 outsideG8.1 scan unitG8.2 clone, special copyG4.2 component locationG1.2 connection power cord G2.5 USBG2.5 consumablesG8.5 contrast, copyG4.1 control panelG1.3 copying 2-up G4.3 auto fitG4.2 cloneG4.2 darknessG4.1 default setting, changeG4.2 ID cardG4.2 original typeG4.1 posterG4.3 reduce/enlargeG4.1 time out, setG4.3 D display language, changeG2.6 document glass cleaning G8.2 loading documentG3.1 document, loadingG3.1 drum, cleanG8.2 E error messagesG9.4 I ID card, special copyG4.2 installing, toner cartridgeG2.2 J jam, clearG9.1 L Linux problemsG9.10 loading documents document galss G3.1 loading, paper in the manual feeder G3.5 in the paper input trayG2.3 M Macintosh problemsG9.11 manual feederG3.5 memory, clearG8.1 O order information, toner cartridgesG7.1 output location, selectG3.6 output trayG3.6 P paper guidelinesG3.3 paper jam, clearG9.1 paper load in paper input tray G2.3 in the manual feederG3.5 paper size setting G3.6 specificationsG3.2 paper type setting G3.6 specificationsG3.2 poster, special copyG4.3 power save mode, useG2.6 power, connectingG2.5 print quality problems, solveG9.6 printing, reportsG8.1 problem, solve copying G9.8 error messagesG9.4 LinuxG9.10 MacintoshG9.11 paper feedingG9.4 printingG9.5 printing qualityG9.6 scanningG9.9 WindowsG9.9 R rear cover, useG3.7 replacing, toner cartridgeG8.4 reports, printG8.1 S scanningG6.1 software overviewG2.7 special materials, guidelinesG3.4 specifications 2 generalG10.1 paperG3.2 printerG10.2 scanner and copierG10.1 Status LEDG9.3 system requirements Windows G2.8 T toner cartridge installing G2.2 maintainingG8.3 order informationG7.1 redistributingG8.3 replacingG8.4 toner save mode, useG2.6 U USB, connectingG3.6 Samsung Printer Software section 1 SOFTWARE SECTION C ONTENTS Chapter 1: INSTALLING PRINTER SOFTWARE IN WINDOWS Installing Printer Software ........................................................................................................ 4 Reinstalling Printer Software ..................................................................................................... 6 Removing Printer Software ....................................................................................................... 6 Chapter 2: BASIC PRINTING Printing a Document ................................................................................................................ 7 Printer Settings ....................................................................................................................... 8 Layout Tab .................................................................................................................... 8 Paper Tab ...................................................................................................................... 9 Graphics Tab ............................................................................................................... 10 Extras Tab ......................................…

Text truncated - open the document above for the full version.

. Introduction SCX-4200 Block Diagram

1. External Pictures 1) Front View 2) Rear View 3) Side View 1 4) Side View 2

2. Internal Pictures 1) Front View 2) Rear View 3. Print Board Assembled(PBA) Pictures 1) Top View of Main Controller 2) Bottom View of Main Controller 3) Top View of SMPS / HVPS 4) Bottom View of SMPS / HVPS 5) Top View of OPE 6) Bottom View of OPE

1 of 20 Samsung EMC Laboratory Project No: LBE052595 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. EMC Test Report According to FCC Part 15 Subpart B Project No. LBE052595 Equipment under Test Applicant Samsung Electronics Co., Ltd 416 Maetan 3-Dong, Yeongtong-Gu, Suwon-Si, Gyeonggi-Do, 443-742 Korea FCC ID A3LSCX4200 Product Name Multi Function Printer Model Name SCX-4200 Manufacturer 1) Samsung Electronics Co.,Ltd. 259, Gongdan-Dong, Gumi-City, Gyeongsangbuk-Do, 730-030 Korea 2) Shandong Samsung Telecommunications Co., Ltd. 264209, Sanxing Road, Weihai Hi-Tech IDZ, Shandong Province, China Date of Test Nov 17, 2005 ~ Nov 26, 2005 Issued Date Dec 05, 2005 Name/Position Signature Tested by Young Hun. Cheong Test Engineer Reviewed by No Cheon, Park Manager of EMC Lab. Authorized by Seung Kyu, Cha Chief of EMC Lab. 1. This test reports does not constitute an endorsement by NIST/NVLAP or U.S Government. 2. This test report is to certify that the tested device properly complies with the requirements of FCC Rules and Regulations Part 15 Subpart B Unintentional Radiators. All tests necessary to show compliance to the requirements were and these results met the specifications requirement. This laboratory is registered by the NIST/NVLAP, U.S.A. The test reported herein have been performed in accordance with its terms of registration. 3. FCC filing Registration Number : 873282 NVLAP LAB CODE 200623-0 2 of 20 Samsung EMC Laboratory Project No: LBE052595 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Table of Contents 1. General Information 1.1 Basic Information related Product 1.2 Detail Information related Product 1.3 Operating mode and condition 1.4 Test System Details 1.5 Equipment Modifications 1.6 Test Procedure 1.7 Test Configuration 1.8 Applied Standard 1.9 Test Facility 2. Summary of Test Results 3. Description of individual tests 3.1 Conducted Emission 3.2 Radiated Emission 4. Appendix 4.1 Test Photography 4.2 EUT Photography 3 of 20 Samsung EMC Laboratory Project No: LBE052595 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 1. General Information 1.1 Basic Information related Product Applicant Samsung Electronics Co., Ltd Model name SCX-4200 Applicant Address 416 Maetan 3-Dong, Yeongtong-Gu, Suwon-Si, Gyeonggi-Do, 443-742 Korea Contact Person Young Hun. Cheong Kind of product Multi Function Printer Variant List - Manufacturer 1). Samsung Electronics Co.,Ltd. 259, Gongdan-Dong, Gumi-City, Gyeongsangbuk-Do, 730-030 Korea 2). Shandong Samsung Telecommunications Co., Ltd. 264209, Sanxing Road, Weihai Hi-Tech IDZ, Shandong Province, China New / Alternative / Permissive change Information New 1.2 Detail Information related Product Specification Item Specification and Description Print Speed Black and White : Up to 18 PPM in A4(19 PPM in Letter) Resolution Printer: Up to 600 x 600 dpi Scanner: Optical 600 x 2400 dpi First print out time From Standby Mode Less than 11 seconds From ColdBoot Less than 53 seconds Warm-up time Less than 35 seconds Power Rating 110 ~ 127 VAC, 5 A, 50/60 Hz Power Average : 350 W 4 of 20 Samsung EMC Laboratory Project No: LBE052595 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Consumption Power Save mode : Less than 10 W Noise Level Scanning/Printing mode: Less than 53 dBA Standby mode : Less than 38 dBA Warm-up: Less than 50dBA Consumable life Black Toner Cartridge : Approx. 3,000 A4/Letter pages at 5% Coverage Duty cycle (Max. Monthly Volume) Print: 4,000 pages Scan: 800 pages Weight 9.5 kg (including consumables) Package weight 3.5 kg External dimensions (W x D x H) 422 x 400 x 239 mm(16.6 x 15.8 x 9.4 in) Operating Environment Temperature : 32 ~ 104 °F(0 ~ 40°C) Humidity : 30 ~ 90 % RH Printer Language SPL Memory 8MB Interface USB 2.0 OS compatibility Windows 98/Me/NT/2000/XP Various Linux OS Mac OS 10.3 ~ 10.4 Operating Frequency Main Source : 10 MHz, Video : 16.5912 MHz, CPU : 66 MHz, SDRAM : 66 MHz, USB Device : 12 MHz 5 of 20 Samsung EMC Laboratory Project No: LBE052595 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 1.3 Operating Mode and Condition The system was configured for testing in typical fashion use. Cables were attached to each of the available I/O Ports. Where applicable, peripherals were attached to the I/O cables. The mode of operation utilized for testing was selected to best simulate typical EUT use. The EUT is supporting the USB and COPY printing mode. In each test mode, finally we found worst case emission that is above configuration with the worst case components(in the above table). So, the data of the maximum EUT operation, USB printing was reported. - USB Printing Mode (worst emission) - COPY Printing Mode - Standby Mode - Power Input Voltage : AC 110V Frequency : 60Hz 1.4 Test System Details Refer to 1.2 1.5 Equipment Modifications No equipment modifications were required. 6 of 20 Samsung EMC Laboratory Project No: LBE052595 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 1.6 Test Procedure 1.6.1 Conducted Emission EUT was placed on a platform nominal size, 1 m by 1.5 m, raised 80 cm above the conducting ground plane. The rear of tabletop was located 40 cm to the vertical conducting ground plane. The rear of EUT, including peripherals was aligned and flush with rear of tabletop. All other surfaces of tabletop was at least 80cm from any other grounded conducing surface. I/O cables and AC cables that were connected to the peripherals were bundled in center. They were folded back and forth forming a bindle 30 cm to 40 cm long and were handed at a 40cm height to the ground plane. Each EUT current-carrying power lead, except the ground(safety)lead, were individu…

Text truncated - open the document above for the full version.

16 of 20 Samsung EMC Laboratory Project No: LBE052595 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 4. Appendix 4.1 Test Photography Pic. 1 Conducted Emission (Front) Pic. 2 Conducted Emission (Rear) 17 of 20 Samsung EMC Laboratory Project No: LBE052595 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Pic. 3. Radiated Emission (Front) Pic. 4. Radiated Emission (Rear)
