A3LSGHE730ESingle-Mode PCS GSM Phone

* Some of the contents of this ma nual may differ from your phone, depending on the software installed or your service provider. World Wide Webhttp://www.samsungmobile.com Printed in Korea Code No.:GH68-0XXXXA English. 01/2005. Rev 1.0 Draft Version GPRS TELEPHONE SGH-E730 E 3 ContentsImportant safety precautions ................................ 7Unpacking ............................................................. 9Your phone .......................................................... 10Phone layout ........................................................... 10Display................................................................... 12Camera .................................................................. 15Flash...................................................................... 15Plug-in speaker ....................................................... 15Getting started .................................................... 16Installing the SIM card ............................................. 16Charging the battery ................................................ 18Switching on or off the phone.................................... 20Using the Keypad Lock feature .................................. 20Call functions....................................................... 21Making a call........................................................... 21Adjusting the volume ............................................... 26Answering a call ...................................................... 26Viewing missed calls ................................................ 27Quickly switching to Quiet mode ................................ 28Using the headset .................................................... 29Selecting functions and options ........................... 30Using the soft keys .................................................. 30Selecting options ..................................................... 31Entering text ....................................................... 32Changing the text input mode ................................... 33Using ABC mode ...................................................... 34Using T9 mode ........................................................ 35Using Number mode................................................. 36Using Symbolic mode ............................................... 36Options during a call............................................ 37Putting a call on hold................................................ 37Using the speaker .................................................... 38Call waiting............................................................. 38Switching on or off the Voice Clarity feature ................ 39Switching off the microphone (Mute) .......................... 40Muting or sending key tones...................................... 40Using Phonebook ..................................................... 41Sending a sequence of DTMF tones ............................ 41 Contents 4 Using the message service ........................................ 41Using SIM services................................................... 42Making a multi-party call .......................................... 42Using the menus.................................................. 44Accessing a menu function by scrolling ....................... 44Using shortcuts ....................................................... 45List of menu functions .............................................. 46Call records ......................................................... 51All calls (Menu 1.1) ................................................... 51 Dialled calls (Menu 1.2) ............................................. 52 Received calls (Menu 1.3) .......................................... 52 Missed calls (Menu 1.4) ............................................. 52 Delete all (Menu 1.5) ................................................ 53 Call time (Menu 1.6) ................................................. 53 Call costs (Menu 1.7) ................................................ 54 Phonebook........................................................... 55Contact list (Menu 2.1) ............................................. 55 Add new contact (Menu 2.2) ....................................... 57 Group (Menu 2.3) .................................................... 59 Speed dial (Menu 2.4) .............................................. 61 My name card (Menu 2.5) .......................................... 62 Own number (Menu 2.6) ............................................ 63 Management (Menu 2.7) ............................................ 63 Applications......................................................... 65Java world (Menu 3.1) ............................................... 65 MP3 player (Menu 3.2) .............................................. 72 Voice recorder (Menu 3.3) .......................................... 75 FM Radio (Menu 3.4) ................................................. 77 World time (Menu 3.5) .............................................. 77 Alarm (Menu 3.6) ..................................................... 78 Calculator (Menu 3.7) ................................................ 79 Convertor (Menu 3.8) ................................................. 80 Timer (Menu 3.9) ...................................................... 81 Stopwatch (Menu 3.10) ............................................. 82 Browser ............................................................... 83Homepage (Menu 4.1) ............................................... 83 Bookmarks (Menu 4.2) .............................................. 85 Go to URL (Menu 4.3) ................................................ 86 Clear cache (Menu 4.4) .............................................. 86 Settings (Menu 4.5) .................................................. 87 Current proxy (Menu 4.6) .......................................... 89 Contents 5 Messages .........................…

Text truncated - open the document above for the full version.















































April 29, 2005        !"# $%&' ( &) "*   +,-   . / (0+1+//2(34 (5 /5 ///5 /4(0+1+// 2( 34(5555,4  .(5(65(5 / (5 1 # )57/(5)8 )94144 *4    1    1: ;&/ 1&19<;3<4




















































April 29, 2005
!
 ""
 ""
#$%"
 &
'
()
*+  !

, !
 "-

)


 .
/01
#
 23!

.
A3LSGHE730E , $
5
 5!

1  " .


 !
6
2)
5
 ,
)(
/01
#
 2
3!
  -
 $

 5!
5

' +
7"

7"

 %
8
3

 !
*%
 %
"
5

-9
%%  2

:
! "

!  !
  "
 !
$%"
! %
 !
  !
 5 "

-

% !
6
/01
#
 2
3!
 !
-  7
% %

 5!
 !

  "
! 7
 !
 6
6  !




7
%- 2




! 7


-
5 "
6
5
  7
% !
6

/01

#
 2
3!
 !


 5 "
6  !
-
5
- 5


 "%
 !


!
5

 5 "


! "
6  !
7
 "%

 5
! 7


"+ 2







;"
<
"
=
3-
/01
#
"
0





















































































April 29, 2005

!
 ""
 ""
 #
 !
$
%
$&'"
 #
(
)*
+,  !

- !
 ".

*



 /
012
$
 %
3!%

/
A3LSGHE730E - &
5
 67 "
 5!


7
8 "


   /


 !
9
%*)
 !
%*
5
 -
*)
012
$
 %
3!%
 &
 6  "
 5!
5


'
'
:
'

'
 !
 ;
"
5

 !

 ' %

7
! "

!  !
  "
 !
&'"
! '
 !
  !
 5 "
.

' !
9
012
$
 %3!

 !

.
' '
 5!
 !

  "
! <
 !
 9
9  !




<
'. %


! <


.
5 "
9
5
  <
' !
9

012
$
 %
3!
5


 5 "
9  !
.
5
. 5


 "'
 !


!
5

 5 "


! "
9  !
<

 "'

 5
! <


", %






="
>
"
?
3.
012
$
"
1%

© 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE730E Single-Band PCS GSM Phone (EDGE) © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE730E Single-Band PCS GSM Phone (EDGE) © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE730E Single-Band PCS GSM Phone (EDGE) © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE730E Single-Band PCS GSM Phone (EDGE) © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE730E Single-Band PCS GSM Phone (EDGE)

© 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE730E Single-Band PCS GSM Phone (EDGE) © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE730E Single-Band PCS GSM Phone (EDGE) © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE730E Single-Band PCS GSM Phone (EDGE) © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE730E Single-Band PCS GSM Phone (EDGE) © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE730E Single-Band PCS GSM Phone (EDGE) © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE730E Single-Band PCS GSM Phone (EDGE) © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE730E Single-Band PCS GSM Phone (EDGE) © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE730E Single-Band PCS GSM Phone (EDGE) © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE730E Single-Band PCS GSM Phone (EDGE) © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE730E Single-Band PCS GSM Phone (EDGE) © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE730E Single-Band PCS GSM Phone (EDGE)

1 of 25 SAMSUNG ELECTRONICS Co., Ltd., Regulatory Compliance Group IT R&D Center 416, Maetan-3dong, Yeongtong-gu, Suwon-si, Gyeonggi-do, Korea 443-742 TEST REPORT ON SAR Model Tested: SGH-E730E FCC ID (Requested): A3LSGHE730E Job No: FC-049 Report No: FC-049-S1 Date issued: Apr.28, 2005 – Abstract – This document reports on SAR Tests carried out in accordance with FCC/OET Bulletin 65, Supplement C(July 2001). Prepared By Date JH Nam - Test Engineer Checked By Date SH PARK - Senior Manager Authorized By Date JK CHOI - General Manager 2005.04.29 2005.04.29 2005.04.29 Report Number : FC-049-S1 2 of 25 Contents 1. General Information.............................................................................................3 2. Description of Device...........................................................................................3 3. Description of Test Equipment..............................................................................4 3.1 SAR Measurement Setup.........................................................................................4 3.2 DASY4 E-Field Probe.............................................................................................5 3.3 SAM Phantom........................................................................................................6 3.4 Brain & Muscle Simulating Mixture Characterization.......................................................7 3.5 Device Holder for transmitters....................................................................................8 3.6 Validation Dipole....................................................................................................8 3.7 Equipment Calibration.............................................................................................9 4. SAR Measurement Procedure..............................................................................10 5. Description of test position.................................................................................11 5.1 SAM Phantom Shape.............................................................................................11 5.2 Cheek/Touch Position............................................................................................11 5.3 Ear/Tilt 15 Position..............................................................................................13 5.4 Body/Holster/Belt Clip Configuration..........................................................................14 6. Measurement Uncertainty...................................................................................16 7. System Verification............................................................................................17 7.1 Tissue Verification.................................................................................................17 7.2 Test System Validation...........................................................................................17 8. SAR Measurement Results.................................................................................18 8.1 Measurement Results(PCS GSM Right Head SAR-Touch)............................................19 8.2 Measurement Results(PCS GSM Right Head SAR-Tilt)................................................20 8.3 Measurement Results(PCS GSM Left Head SAR-Touch)..............................................21 8.4 Measurement Results(PCS GSM Left Head SAR-Tilt)..................................................22 8.5 Measurement Results(PCS GSM Body SAR w/o Holster).............................................23 9. Conclusion.......................................................................................................24 10. Reference.......................................................................................................25 Report Number : FC-049-S1 3 of 25 1. GENERAL INFORMATION Test Sample : Single-Band PCS GSM Phone (EDGE) Model Number : SGH-E730E Serial Number : Identical prototype (S/N : FC-049-B) Manufacturer : SAMSUNG ELECTRONICS Co., Ltd. Contact : HA PARK, Engineer Phone : +82-16-9530-7382 Fax : +82-31-279-6162 Test Standard : §2.1093; FCC/OET Bulletin 65, Supplement C(July 2001) FCC Classification : Licensed Portable Transmitter Held to Ear (PCE) Test Dates : Apr. 19, 2005 Tested for : FCC/TCB Certification 2. DESCRIPTION OF DEVICE Tx Freq. Range : 1850.20 – 1909.80 MHz (PCS GSM) Rx Freq. Range : 1930.20 – 1989.80 MHz (PCS GSM) Max. RF Output Power : 1.535 W EIRP GSM1900 (31.86 dBm) Antenna Manufacturer : EMW Model No.: HIR-01503-0000AA Antenna Dimensions : 36.52mm × 10.74mm × 15.67mm Report Number : FC-049-S1 4 of 25 3. DESCRIPTION OF TEST EQUIPMENT 3.1 SAR Measurement Setup Robotic System Measurements are performed using the DASY4 automated dosimetric assessment system. Which is made by Schmid & Partner Engineering AG (SPEAG) in Zurich, Switzerland and consists of high precision robotics system (Stäubli), robot controller, measurement server, Samsung computer, near- field probe, probe alignment sensor, and the SAM twin phantom containing the brain equivalent material. The robot is a six-axis industrial robot performing precise movements to position the probe to the location (points) of maximum electromagnetic field (EMF) (see Fig. 3.1). Figure 3.1 SAR Measurement System Setup System Hardware A cell controller system contains the power supply, robot controller, teach pendant (Joystick), and a remote control is used to drive the robot motors. The PC consists of the Samsung computer with Windows XP system and SAR Measurement Software DASY4, LCD monitor, mouse and keyboard. The Stäubli Robot is connected to the cell controller to allow software manipulation of the robot. A data acquisition electronic (DAE) circuit that performs the signal amplification, signal multiplexing, AD-conversion, offset measurements, mechanical surface detection, collision detection, etc. is connected to the Electro-optical coupler (EOC). The EOC performs the conversion from the op…

Text truncated - open the document above for the full version.

SAMSUNG FCC ID : A3LSGHE730E 1900MHz PCS GSM Head SAR DUT: SGH-E730E; Serial: FC-049-B Program Name: SGH-E730E GSM1900 Right (Job No. : FC-049) Procedure Name: Cheek/Touch, Ch.512, Ant.Intenna, Bat.Standard Procedure Notes: Meas.Tissue Temp(celsius)-22.0; Test Date-19/Apr/2005 [OET Bulletin 65- Supplement C, July 2001] Communication System: GSM 1900; Frequency: 1850.2 MHz;Duty Cycle: 1:8.3 Medium parameters used: f = 1850.2 MHz; σ = 1.41 mho/m; ε r = 39.4; ρ = 1000 kg/m 3 Phantom section: Right Section DASY4 Configuration: - Probe: ES3DV2 - SN3017; ConvF(5.11, 5.11, 5.11); Calibrated: 2004-09-24 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn533; Calibrated: 2004-12-03 - Phantom: SAM 1800/1900 MHz; Type: SAM; Serial: TP-1143 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Cheek/Touch, Ch.512, Ant.Intenna, Bat.Standard/Area Scan (51x71x1): Measurement grid: dx=20mm, dy=20mm Maximum value of SAR (interpolated) = 1.01 mW/g Cheek/Touch, Ch.512, Ant.Intenna, Bat.Standard/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 3.32 V/m; Power Drift = -0.188 dB Peak SAR (extrapolated) = 1.60 W/kg SAR(1 g) = 0.954 mW/g Maximum value of SAR (measured) = 1.09 mW/g 0 dB = 1.09mW/g SAMSUNG FCC ID : A3LSGHE730E 1900MHz PCS GSM Head SAR DUT: SGH-E730E; Serial: FC-049-B Program Name: SGH-E730E GSM1900 Right (Job No. : FC-049) Procedure Name: Ear/Tilt, Ch.661, Ant.Intenna, Bat.Standard Procedure Notes: Meas.Tissue Temp(celsius)-22.0; Test Date-19/Apr/2005 [OET Bulletin 65- Supplement C, July 2001] Communication System: GSM 1900; Frequency: 1880 MHz;Duty Cycle: 1:8.3 Medium parameters used: f = 1880 MHz; σ = 1.41 mho/m; ε r = 39.4; ρ = 1000 kg/m 3 Phantom section: Right Section DASY4 Configuration: - Probe: ES3DV2 - SN3017; ConvF(5.11, 5.11, 5.11); Calibrated: 2004-09-24 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn533; Calibrated: 2004-12-03 - Phantom: SAM 1800/1900 MHz; Type: SAM; Serial: TP-1143 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Ear/Tilt, Ch.661, Ant.Intenna, Bat.Standard/Area Scan (51x71x1): Measurement grid: dx=20mm, dy=20mm Maximum value of SAR (interpolated) = 0.169 mW/g Ear/Tilt, Ch.661, Ant.Intenna, Bat.Standard/Zoom Scan (6x6x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 7.83 V/m; Power Drift = 0.077 dB Peak SAR (extrapolated) = 0.216 W/kg SAR(1 g) = 0.141 mW/g Maximum value of SAR (measured) = 0.153 mW/g 0 dB = 0.153mW/g SAMSUNG FCC ID : A3LSGHE730E 1900MHz PCS GSM Head SAR DUT: SGH-E730E; Serial: FC-049-B Program Name: SGH-E730E GSM1900 Left (Job No. : FC-049) Procedure Name: Cheek/Touch, Ch.512, Ant.Intenna, Bat.Standard Procedure Notes: Meas.Tissue Temp(celsius)-22.0; Test Date-19/Apr/2005 [OET Bulletin 65- Supplement C, July 2001] Communication System: GSM 1900; Frequency: 1850.2 MHz;Duty Cycle: 1:8.3 Medium parameters used: f = 1850.2 MHz; σ = 1.41 mho/m; ε r = 39.4; ρ = 1000 kg/m 3 Phantom section: Left Section DASY4 Configuration: - Probe: ES3DV2 - SN3017; ConvF(5.11, 5.11, 5.11); Calibrated: 2004-09-24 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn533; Calibrated: 2004-12-03 - Phantom: SAM 1800/1900 MHz; Type: SAM; Serial: TP-1143 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Cheek/Touch, Ch.512, Ant.Intenna, Bat.Standard/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 3.54 V/m; Power Drift = 0.094 dB Peak SAR (extrapolated) = 1.70 W/kg SAR(1 g) = 1.04 mW/g Maximum value of SAR (measured) = 1.19 mW/g Cheek/Touch, Ch.512, Ant.Intenna, Bat.Standard/Area Scan (51x71x1): Measurement grid: dx=20mm, dy=20mm Maximum value of SAR (interpolated) = 1.09 mW/g 0 dB = 1.09mW/g SAMSUNG FCC ID : A3LSGHE730E 1900MHz PCS GSM Head SAR DUT: SGH-E730E; Serial: FC-049-B Program Name: SGH-E730E GSM1900 Left (Job No. : FC-049) Procedure Name: Ear/Tilt, Ch.661, Ant.Intenna, Bat.Standard Procedure Notes: Meas.Tissue Temp(celsius)-22.0; Test Date-19/Apr/2005 [OET Bulletin 65- Supplement C, July 2001] Communication System: GSM 1900; Frequency: 1880 MHz;Duty Cycle: 1:8.3 Medium parameters used: f = 1880 MHz; σ = 1.41 mho/m; ε r = 39.4; ρ = 1000 kg/m 3 Phantom section: Left Section DASY4 Configuration: - Probe: ES3DV2 - SN3017; ConvF(5.11, 5.11, 5.11); Calibrated: 2004-09-24 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn533; Calibrated: 2004-12-03 - Phantom: SAM 1800/1900 MHz; Type: SAM; Serial: TP-1143 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Ear/Tilt, Ch.661, Ant.Intenna, Bat.Standard/Area Scan (51x71x1): Measurement grid: dx=20mm, dy=20mm Maximum value of SAR (interpolated) = 0.197 mW/g Ear/Tilt, Ch.661, Ant.Intenna, Bat.Standard/Zoom Scan (6x6x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 8.10 V/m; Power Drift = 0.080 dB Peak SAR (extrapolated) = 0.241 W/kg SAR(1 g) = 0.160 mW/g Maximum value of SAR (measured) = 0.166 mW/g 0 dB = 0.166mW/g SAMSUNG FCC ID : A3LSGHE730E 1900MHz PCS GSM Body SAR DUT: SGH-E730E (Body); Serial: FC-049-B Program Name: SGH-E730E GSM1900 Body (Job No. : FC-049) Procedure Name: Body, Ch.512, Ant.Intenna, Bat.Standard Procedure Notes: Meas.Tissue Temp(celsius)-22.1;Test Date-19/Apr/2005[OET Bulletin 65- Supplement C, July 2001] Communication System: Body GPRS ; Frequency: 1850.2 MHz;Duty Cycle: 1:4.15 Medium parameters used: f = 1850.2 MHz; σ = 1.51 mho/m; ε r = 52.8; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: - Probe: ES3DV2 - SN3017; ConvF(4.46, 4.46, 4.46); Calibrated: 2004-09-24 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn533; Calibrated: 2004-12-03 - Phantom: SAM 1800/1900 MHz; Type: SAM; Serial: TP-1143 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Body, Ch.512, Ant.Intenna, Bat.Standard/Zoom Scan (5x5x7)/Cube…

Text truncated - open the document above for the full version.

DUT: Dipole 1900 MHz; Serial: 5d023 Program Name: 1900MHz Dipole Validation 2005.04.19 Procedure Name: 1900MHz @ 250mW Procedure Notes: Meas.Tissue Temp(celsius)-22.0;Test Date-19/Apr/2005[OET Bulletin 65-Supplement C, July 2001] Communication System: CW; Frequency: 1900 MHz;Duty Cycle: 1:1 Medium parameters used: f = 1900 MHz; σ = 1.41 mho/m; ε r = 39.4; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: - Probe: ES3DV2 - SN3017; ConvF(5.11, 5.11, 5.11); Calibrated: 2004-09-24 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn533; Calibrated: 2004-12-03 - Phantom: SAM 1800/1900 MHz; Type: SAM; Serial: TP-1143 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 1900MHz @ 250mW/Area Scan (51x51x1): Measurement grid: dx=20mm, dy=20mm Maximum value of SAR (interpolated) = 15.8 mW/g 1900MHz @ 250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 91.2 V/m; Power Drift = -0.105 dB Peak SAR (extrapolated) = 18.2 W/kg SAR(1 g) = 10.2 mW/g; Maximum value of SAR (measured) = 11.4 mW/g 0 dB = 11.4mW/g

© 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE730E Single-Band PCS GSM Phone (EDGE) © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE730E Single-Band PCS GSM Phone (EDGE) © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE730E Single-Band PCS GSM Phone (EDGE) © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE730E Single-Band PCS GSM Phone (EDGE) 1.5Cm © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE730E Single-Band PCS GSM Phone (EDGE) © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE730E Single-Band PCS GSM Phone (EDGE) © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE730E Single-Band PCS GSM Phone (EDGE) © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE730E Single-Band PCS GSM Phone (EDGE) © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE730E Single-Band PCS GSM Phone (EDGE) © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE730E Single-Band PCS GSM Phone (EDGE) © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE730E Single-Band PCS GSM Phone (EDGE) © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE730E Single-Band PCS GSM Phone (EDGE)

SAMSUNG ELECTRONICS Co., Ltd., Regulatory Compliance Group IT R&D Center 416 Maetan3-Dong, Yeongtong-gu, Suwon city, Gyeonggi-Do, Korea 442-742 FCC CFR47 PART 24 SUBPART CERTIFICATION REPORT Model Tested: SGH-E730E FCC ID (Requested): A3LSGHE730E Report No: FC-049-R1 Job No: FC-049 Date issued: April 27,2005 - Abstract – All measurement reported herein accordance with FCC Rules, 47CFR Part2, Part24. Prepared By Date YE PARK – Test Engineer Checked By Date SH PARK – Senior Manager Authorized By Date JK CHOI – General Manager © Copyright SAMSUNG Electronics 2005 Report Number : FC-049-R1 TABLE OF CONTENT MEASUREMENT REPORT Page 1. FCC Certification Information 3 1.1 2.1033 General Information 3 2. INTRODUCTION 4 2.1 General 4 3. MEASURING INSTRUMENT CALIBRATION 5 4. TEST EQUIPMENT LIST 6 5. DESCRIPTION OF TESTS 7 5.1 Equivalent Isotropic Radiated Power 7 5.2 Radiated Spurious & Harmonic Emission 8 5.3 Occupied Bandwidth 9 5.4 Spurious and Harmonic Emissions at Antenna Terminal 9 5.4.1 Occupied Bandwidth Emission Limits 9 5.4.2 Conducted Spurious Emission 11 5.5 Frequency Stability / Temperature Variation 13 6. TEST DATA 14 6.1 Equivalent Isotropic Radiated Power (E.I.R.P.) 14 6.2 Radiated Spurious & Harmonic Measurement 15 6.3 Radiated Spurious & Harmonic Conversion Table 16 6.4 Frequency Stability 17 6.4.1 Frequency Stability Table 17 6.4.2 Frequency Stability Graph 18 7. CONCLUSION 20 8. TEST PLOTS 21 Report Number : FC-049-R1 MEASUREMENT REPORT 1. FCC Certification Information The following information is in accordance with FCC Rules, 47CFR Part2, Subpart J, Sections 2.1033 – 2.1055. 2.1033 General Information Applicant Name: SAMSUNG ELECRONICS CO., LTD. Address: 416 Maetan3-Dong, Yeongtong-gu, Suwon City Gyeonggi-Do, Korea 442-742 Attention: FCC ID: SungJoo KIM, Engineering Manager (QA Lab) A3LSGHE730E Quantity: Quantity production is planned Emission Designators: 250KGXW Tx Freq. Range: 1850.2MHz -1909.8MHz Rx Freq. Range: 1930.2MHz – 1989.8MHz Max. Power Rating: 1.535W EIRP GSM1900 (31.86dBm) FCC Classification(s): Licensed Portable Tx Held to Ear (PCE) Equipment (EUT) Type: Single-Band PCS GSM Phone Frequency Tolerance: 0.00025% (2.5ppm) FCC Rule Part(s): 24(E), Dates of Test: April 18,25-26 , 2005 Place of Test: SAMSUNG Lab, Test Report S/N: FC-049-R1 - End of page - Report Number : FC-049-R1 2. INTRODUCTION General These measurement test were conducted at SAMSUNG ELECTRONICS CO., LTD(SUWON). The site address is 416 Maetan3-Dong, Yeongtong-gu, Suwon City, Gyeonggi-Do, Korea 442-742 The site have 1 Fully-anechoic chamber and measurement facility. Measurement Procedure The radiated and spurious measurements were made Fully-anechoic chamber at a 3-meter test range (see Figure2). The equipment under testing was placed on a Non-conducted turntable 3- meters from the receive antenna. The receive antenna height and turntable rotations were adjusted for the highest reading on the receive spectrum analyzer. The substitution antenna will replace the EUT antenna it the same position and in vertical polarization. The frequency of the signal generator shall be set to the frequencies that were measured on the EUT. The test antenna shall be raised and lowered, if necessary, to ensure that the maximum signal is still being received. The signal generator, output level, shall be adjusted until an equal or a known related level to what was measured from the EUT is obtained in the spectrum analyzer. This level was recorded. For readings above 1 GHz, the above procedure is repeated using horn antennas and the difference between the gain of the horn and an isotropic antenna are taken into consideration. Figure1. Map of the Suwon City area. Fi gure2. Photograph of 3m Fully-Anechoic Chamber Report Number : FC-049-R1 3. MEASURING INSTRUMENT CALIBRATION The measuring equipment, which was utilized in performing the tests documented herein, has been calibrated in accordance with the manufacturer’s recommendations for utilizing calibration equipment, which is traceable to recognized national standards. - End of page - Report Number : FC-049-R1 4. TEST EQUIPMENT LIST Name of Equipment Model Serial No. Due Date ESI26 836119/010 2005-09-20 E4440A(3Hz~26.5GHz) MY41000236 2005-10-27 Spectrum Analyzer E4440A(3Hz~26.5GHz) MY41000233 2005-11-04 SMIQ03B 83824/021 2005-12-27 Signal Generator SMR20 835197/030 2006-01-18 Power Meter E4419B GB41293846 2005-09-21 8481B 3318A10325 2005-10-06 Power Sensor 8485A 3318A19924 2005-09-20 Amplifier 5S1G4 304866 2005-10-19 Pre-Amplifier 8449B 3008A00691 2006-…

Text truncated - open the document above for the full version.
