A3LSGHE860VSingle-Band PCS GSM Phone w/ Bluetooth Transmitter

World Wide Webhttp://www.samsungmobile.com Printed in Korea Code No.:GH68-xxxxA English. 05/2005. Rev 1.0 * Some of the contents of this manual may not match from your phone, depending on the software installed, your service provider or country. * Depending on your country, your phone and accessories may appear different from the illustrations in this manual. SGH-E860VUser’s Manual Draft 2005. 05. 24 E860BUED2 Important safety precautions Failure to comply with the following precautions may be dangerous or illegal. Drive safely at all timesDo not use a hand-held phone while driving. Park the vehicle first. Switch off the phone when refuellingDo not use the phone at a refuelling point (service station) or near fuels or chemicals.Switch off in an aircraftWireless phones can cause interference. Using them in an aircraft is both illegal and dangerous.Switch off the phone near all medical equipmentHospitals or health care facilities may be using equipment that could be sensitive to external radio frequency energy. Follow any regulations or rules in force. Important safety precautions 1 InterferenceAll wireless phones may be subject to interference, which could affect their performance. Be aware of special regulationsMeet any special regulations in force in any area and always switch off your phone whenever it is forbidden to use it, or when it may cause interference or danger.Water resistanceYour phone is not water-resistant. Keep it dry. Sensible useUse only in the normal position (held to the ear). Avoid unnecessary contact with the antenna when the phone is switched on.Emergency callsKey in the emergency number for your present location, then press . Keep your phone away from small children Keep the phone and all its parts, including accessories, out of the reach of small children.Accessories and batteriesUse only Samsung-approved accessories and batteries. Use of any unauthorised accessories could damage your phone and may be dangerous.Qualified serviceOnly qualified service personnel may repair your phone.For more detailed safety information, see "Health and safety information" on page 90. • The phone could explode if the battery is replaced with an incorrect type. • Dispose of used batteries according to the manufacturer’s instructions. 2 About this GuideThis User’s Guide provides you with condensed information about how to use your phone. To quickly learn the basics for your ph one, please refer to “Get started” and “Step outside the phone.”In this guide, the following instruction icons appear: Indicates that you need to pay careful attention to the subsequent information regarding safety or phone features.  Indicates that you can get more information on the referenced page. → Indicates that you need to press the Navigation keys to scroll to the specified option and then select it. [ ] Indicates a key on the phone. For example, [] < > Indicates a soft key, whose function is displayed on the phone screen. For example, < Menu > • Camera and camcorder Use the camera module on your phone to take a photo or record a video. Special features of your phone •Media player Play media files on your phone. •IrDA Send and receive Phonebook and organiser data and media files via an infrared port. 3 Special features of your phone •Bluetooth Send photos, images, videos, and other personal data, and connect to other devices using free, wireless Bluetooth technology. •Web browser Access the wireless web and access various services and current information. • Get personal with photo caller ID See who’s calling you when their very own photo displays. • Name card Create name cards with your number and profile. Whenever introducing yourself to others, use this convenient electronic name card. • Multimedia message service (MMS) Send and receive MMS messages with a combination of text, images, video, and audio. •E-mail Send and receive e-mails with images, video, and audio attachments. •Java Enjoy Java ™ -based embedded games and download new games. •Calendar Keep track of your daily, weekly, and monthly schedule. • Voice recorder Record memos or sounds. 4 Contents Unpack 6 Make sure you have each itemYour phone 6 Buttons, features, and locationsGet started 7 First steps to operating your phoneInstall and charge the phone ................................... 7Power on or off ...................................................... 8Keys and display .................................................... 9Access menu functions.......................................... 11Customise your phone .......................................... 12Make/Answer calls................................................ 14Step outside the phone 14 Begin with your camera, music, and other special featuresUse camera ......................................................... 14Play media files ................................................... 15 Browse the web ................................................... 17Use Contacts ....................................................... 17Send messages.................................................... 19View messages .................................................... 21Use Bluetooth ...................................................... 22 Enter text 23 AB, T9, Number, and Symbol modeCall functions 25 Advanced calling featuresMenu functions 29 All menu options listedSolve problems 88 Help and personal needsHealth and safety information 90 Index 97 5 Overview of menu functions To access Menu mode, press < Menu > in Idle mode. 1 Entertainment  p.29 2 Vodafone live!  p.30 1 Vodafone live!2 Enter URL3 Bookmarks4 History5 Browser settings6 What’s New7 Game8 Ringtones9 Pictures0 News* Sports  p.30  p.31  p.32  p.32  p.32  p.32  p.32  p.33  p.33  p.33  p.33 3 Media player  p.33 1 Music2 Video  p.33  p.35 4 Camera  p.36 5 Messaging  p.41 1 Create2 Inbox3 Email box4 Drafts5 Sent messages6 Voicemail7 Message archive8 Templates9 Delete all0 Messaging settings* Memory status# Media alb…

Text truncated - open the document above for the full version.















































June 28, 2005        !"# $%&' ( &) "*   +,-   . / (0+1+//2(34 (5 /5 ///5 /4(0+1+// 2( 34(5555,4  .(5(65(5 / (5 1 # )57/(5)8 )94144 *4    1    1: ;&/ 1&19<;3<4




















































June 28, 2005
!
 ""
 ""
#$%"
 &
'
()
*+  !

, !
 "-

)


 .
/01
#
 23!

.
A3LSGHE860V , $
5
 5!

1  " .


 !
6
2)
5
 ,
)(
/01
#
 2
3!
  -
 $

 5!
5

' +
7"

7"

 %
8
3

 !
*%
 %
"
5

-9
%%  2

:
! "

!  !
  "
 !
$%"
! %
 !
  !
 5 "

-

% !
6
/01
#
 2
3!
 !
-  7
% %

 5!
 !

  "
! 7
 !
 6
6  !




7
%- 2




! 7


-
5 "
6
5
  7
% !
6

/01

#
 2
3!
 !


 5 "
6  !
-
5
- 5


 "%
 !


!
5

 5 "


! "
6  !
7
 "%

 5
! 7


"+ 2







;"
<
"
=
3-
/01
#
"
0





















































































June 28, 2005

!
 ""
 ""
 #
 !
$
%
$&'"
 #
(
)*
+,  !

- !
 ".

*



 /
012
$
 %
3!%

/
A3LSGHE860V - &
5
 67 "
 5!


7
8 "


   /


 !
9
%*)
 !
%*
5
 -
*)
012
$
 %
3!%
 &
 6  "
 5!
5


'
'
:
'

'
 !
 ;
"
5

 !

 ' %

7
! "

!  !
  "
 !
&'"
! '
 !
  !
 5 "
.

' !
9
012
$
 %3!

 !

.
' '
 5!
 !

  "
! <
 !
 9
9  !




<
'. %


! <


.
5 "
9
5
  <
' !
9

012
$
 %
3!
5


 5 "
9  !
.
5
. 5


 "'
 !


!
5

 5 "


! "
9  !
<

 "'

 5
! <


", %






="
>
"
?
3.
012
$
"
1%

© 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE860V Single-Band PCS GSM Phone with Bluetooth © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE860V Single-Band PCS GSM Phone with Bluetooth © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE860V Single-Band PCS GSM Phone with Bluetooth © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE860V Single-Band PCS GSM Phone with Bluetooth © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE860V Single-Band PCS GSM Phone with Bluetooth

© 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE860V Single-Band PCS GSM Phone with Bluetooth © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE860V Single-Band PCS GSM Phone with Bluetooth © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE860V Single-Band PCS GSM Phone with Bluetooth © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE860V Single-Band PCS GSM Phone with Bluetooth © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE860V Single-Band PCS GSM Phone with Bluetooth © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE860V Single-Band PCS GSM Phone with Bluetooth © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE860V Single-Band PCS GSM Phone with Bluetooth © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE860V Single-Band PCS GSM Phone with Bluetooth © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE860V Single-Band PCS GSM Phone with Bluetooth © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE860V Single-Band PCS GSM Phone with Bluetooth © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE860V Single-Band PCS GSM Phone with Bluetooth © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE860V Single-Band PCS GSM Phone with Bluetooth

SAMSUNG ELECTRONICS Co., Ltd., Regulatory Compliance Group IT R&D Center 416 Maetan3-Dong, Yeongtong-gu, Suwon city, Gyeonggi-Do, Korea 442-742 FCC CFR47 PART 15 SUBPART CERTIFICATION REPORT Model Tested: SGH-E860V FCC ID (Requested): A3LSGHE860V Report No: FC-079-R2 Job No: FC-079 Date issued: June 20, 2005 - Abstract - All measurement reported herein accordance with FCC Rules, 47CFR Part2, Part15. Prepared By Date SS LEE – Test Engineer Checked By Date SH PARK – Senior Manager Authorized By Date JK CHOI – General Manager © Copyright SAMSUNG Electronics 2005 Report Number : FC-079-R2 TABLE OF CONTENT MEASUREMENT REPORT Page 1. FCC CERTIFICATION INFORMATION 4 1.1 2.1033 GENERAL INFORMATION 4 2. INTRODUCTION 4 2.1 SAMSUNG TEST LOCATION 5 2.2 SCOPE 5 2.2 MEASUREMENT PROCEDURE 5 3. TEST EQUIPMENT LIST 6 4. TECHNICAL CHARACTERISTICS TEST 7 4.1 20dB BANDWIDTH 7 4.1.1 LIMIT 7 4.1.2 TEST SET-UP 7 4.1.3 TEST PROCEDURE 7 4.1.4 TEST RESULT 7 4.2 OUTPUT POWER MEASUREMENT 8 4.2.1 LIMIT 8 4.2.2 TEST SET-UP 8 4.2.3 TEST PROCEDURE 8 4.2.4 TEST RESULT 8 4.3 CONDUCTED SPURIOUS EMISSION TEST 9 4.3.1 LIMIT 9 4.3.2 TEST SET-UP 9 4.3.3 TEST PROCEDURE 9 4.3.4 TEST RESULT 9 4.4 BAND EDGE COMPLIANCE 10 4.4.1 LIMIT 10 4.4.2 TEST SET-UP 10 4.4.3 TEST PROCEDURE 10 4.4.4 TEST RESULT 10 4.5 NUMBER OF HOPPING CHANNELS 11 4.5.1 LIMIT 11 4.5.2 TEST SET-UP 11 4.5.3 TEST PROCEDURE 11 4.5.4 TEST RESULT 11 Report Number : FC-079-R2 4.6 CHANNEL SEPARATION TEST 12 4.6.1 LIMIT 12 4.6.2 TEST SET-UP 12 4.6.3 TEST PROCEDURE 12 4.6.4 TEST RESULT 12 4.7 DWELL TIME 13 4.7.1 LIMIT 13 4.7.2 TEST SET-UP 13 4.7.3 TEST PROCEDURE 13 4.7.4 TEST RESULT 13 4.8 RADIATED HARMONIC MEASUREMENTS 14 4.8.1 LIMIT 14 4.8.2 TEST SET-UP 14 4.8.3 TEST PROCEDURE 14 4.8.4 TEST RESULT 15 5. CONCLUSION 16 6. TEST PLOTS 17 Report Number : FC-079-R2 MEASUREMENT REPORT 1. FCC CERTIFICATION INFORMATION The following information is in accordance with FCC Rules, 47CFR Part15, Subpart C 1.1 2.1033 GENERAL INFORMATION Applicant Name: SAMSUNG ELECRONICS CO., LTD. Address: 416 Maetan3-Dong, Yeongtong-gu, Suwon City Gyeonggi-Do, Korea 442-742 Attention: FCC ID: SungJoo KIM, Engineering Manager (QA Lab) A3LSGHE860V Quantity: Quantity production is planned. Equipment (EUT) Type: Single-Band PCS GSM Phone with Bluetooth This Bluetooth Module has been tested by Bluetooth Qualification Lab, and we confirm the following: A) The hopping sequence is pseudorandom B) All Channels were used equally on average C) The receiver input bandwidth equals the transmit bandwidth D) the receiver hops in sequence with the transmit signal 15.247(g): In accordance with the Bluetooth Industry Standard, the system is designed to comply with all of the regulations in Section 15.247 when the transmitter is presented with a continuous data (or information) stream. 15.247(h): In accordance with the Bluetooth Industry Standard, the system does not coordinate its channel selection/hopping sequence with other frequency hopping systems for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters. FCC Classification(s): FCC Part15 Spread Spectrum Transceiver (DSS) Frequency Range: 2402 ~ 2480MHz(Bluetooth) Max. Output Power: 0.00139W(1.44dBm)Conducted FCC Rule Part(s): 15.247, 2 Dates of Test: June 16-20, 2005 Place of Test: SAMSUNG Lab, Test Report S/N: FC-079-R2 - End of page - Report Number : FC-079-R2 2. INTRODUCTION 2.1 SAMSUNG TEST LOCATION These measurement test were conducted at the SAMSUNG ELECTRONICS CO., LTD(SUWON). The site address is 416 Maetan3-Dong, Yeongtong-gu, Suwon City, Gyeonggi-Do, Korea 442-742. The site has 1 Fully-anechoic chamber and measurement facility. 2.2 SCOPE All measurement tests were conducted at the SAMSUNG Lab, except Radiated Emission & Conducted Emission test. RE and CE measurement test reports are issued separately. 2.3 MEASUREMENT PROCEDURE The radiated and spurious measurements were made Fully-anechoic chamber at a 3-meter test range (see Figure2). The equipment under testing was placed on a wooden turntable 3-meters from the receive antenna. The receive antenna height and turntable rotations were adjusted for the highest reading on the receive spectrum analyzer. Figure2. Photograph of 3m Fully Anechoic Chamber - End of page - Figure1. Map of the Suwon City area. Report Number : FC-079-R2 3. TEST EQUIPMENT LIST Name of Equipment Model Serial No. Due Date ESI26 836119/010 2005-09-20 E4440A(3Hz~26.5GHz) MY41000236 2005-10-27 Spectrum Analyzer E4440A(3Hz~26.5GHz) MY41000233 2005-11-04 Signal Generator SMR27 100039 2005-08-11 Pre-Amplifier 8449B 3008A00691 2006-01-11 Antenna Master MA0001 ANT0967 Not Required Controller HD100 100/756 Not Required SEP-60 83845 2005-08-10 Horn Antenna HF906 100134 2006-04-25 WHK/3.5/18G-10SS 3 Not Required High Pass Filter WHK/3.5/18G-10SS 4 Not Required Shielded Full y-Anechoic Chamber RF0002 ANT0001 Not Required Power Meter E4419B GB41293846 2005-09-21 Power sensor 8481B 3318A10325 2005-10-06 Power sensor 8485A 3318A19924 2005-09-20 Network Analyzer 8753E JP38160590 2005-07-22 Power Supply E3640A MY40003595 2005-06-30 Power Supply E3640A MY40003594 2005-07-02 UNIVERSAL RADIO COMMUNICATION TESTER CMU200 838115/081 2006-04-08 Report Number : FC-079-R2 4. TECHNICAL CHARACTERISTICS TEST 4.1 20dB BANDWIDTH FCC Part15, Subpart C Section 15.247(a) For frequency hopping system operation in the 2400-2483.5MHz and 5725-5850MHz bands, the maximum 20dB bandwidth of the hopping channels is 1MHz. T he EUT was connected to a spectrum through a 50ohm RF cable. 1. Check the calibration of the measuring instrument (SA) using either an internal calibrator or a known signal from an external generator. 2. Turn on the EUT and connect it to measurement instrument. Then set it to any one proper frequency within its operating range. 3. Measure the frequency difference of two frequencies that were attenuated 20dB from the highest peak value. 4. Repeat above procedures until all frequencies measured…

Text truncated - open the document above for the full version.

PCTEST LAB TEST REPORT 15.247 FCC CERTIFICATION REPORT Reviewed by: Quality Manager Filename: 1506260330 Test Dates: July 7, 2005 EUT Type: Samsung Single-Band GSM Phone w/ Bluetooth FCC ID: A3LSGHE860V Page 1 of 6 © 2005 PCTEST Engineering Laboratory, Inc. EXHIBIT A – Test Results (Cont.) Radiated Harmonic Measurements (Cont.) §15.247(b) / §15.205 & §15.209 Distance of Measurements: 3 Meters Channel: 00 Table A-8. Harmonic Measurements NOTES: 1. All harmonics in the restricted bands specified in §15.205 are below the limit shown in Table A-18. (Note: * = Restricted Band measured frequency) 2. All harmonics/spurs are at least 20 dB below the highest emission in the authorized band using RBW = 100kHz 3. Average Measurements > 1GHz using RBW = 1 MHz VBW = 10 Hz 4. The peak emissions above 1 GHz are not more than 20 dB above the average limit. 5. The antenna is manipulated through typical positions, polarity and length during the tests. 6. The EUT is supplied with nominal AC voltage or/and a new/fully-recharged battery. 7. The spectrum is measured from 9kHz to the 10 th harmonic and the worst-case emissions are reported. 8. < - 135 dBm are below the analyzer floor level. 9. Above 1 GHz, the limit is 500 μV/m (54dBμ/m) at 3 meters radiated. Figure A-7. Radiated limits at 3 meters. FREQ.LEVELAFCLPOLF/SF/SMARGIN (MHz)(dBm)(dB)(H/V)(dBuV/m)(uV/m)(dB) 4804.00 -98.5 40.4V48.9278.3-5.1 7206.00-101.747.4V52.7432.5-1.3 9608.00-104.750.3V52.6426.6-1.4 12010.00 -108 53.7V52.7431.5-1.3 PCTEST LAB TEST REPORT 15.247 FCC CERTIFICATION REPORT Reviewed by: Quality Manager Filename: 1506260330 Test Dates: July 7, 2005 EUT Type: Samsung Single-Band GSM Phone w/ Bluetooth FCC ID: A3LSGHE860V Page 2 of 6 © 2005 PCTEST Engineering Laboratory, Inc. EXHIBIT A – Test Results (Cont.) Radiated Harmonic Measurements (Cont.) §15.247(b) / §15.205 & §15.209 Distance of Measurements: 3 Meters Channel: 39 Table A-9. Radiated Fundamental & Harmonic Measurements NOTES: 1. All harmonics in the restricted bands specified in §15.205 are below the limit shown in Table A- 18. (Note: * = Restricted Band measured frequency) 2. All harmonics/spurs are at least 20 dB below the highest emission in the authorized band using RBW = 100kHz 3. Average Measurements > 1GHz using RBW = 1 MHz VBW = 10 Hz 4. The peak emissions above 1 GHz are not more than 20 dB above the average limit. 5. The antenna is manipulated through typical positions, polarity and length during the tests. 6. The EUT is supplied with nominal AC voltage or/and a new/fully-recharged battery. 7. The spectrum is measured from 9kHz to the 10 th harmonic and the worst-case emissions are reported. 8. < - 135 dBm are below the analyzer floor level. 9. Above 1 GHz, the limit is 500 μV/m (54dBμ/m) at 3 meters radiated. Figure A-8. Radiated limits at 3 meters. FREQ.LEVELAFCLPOLF/SF/SMARGIN (MHz)(dBm)(dB)(H/V)(dBuV/m)(uV/m)(dB) 4882.00-101.5040.5V46.0199.5-8.0 7323.00-105.7048.0V49.3291.7-4.7 9764.00-107.8050.3V49.5298.5-4.5 12205.00-110.4053.7V50.3327.3-3.7 PCTEST LAB TEST REPORT 15.247 FCC CERTIFICATION REPORT Reviewed by: Quality Manager Filename: 1506260330 Test Dates: July 7, 2005 EUT Type: Samsung Single-Band GSM Phone w/ Bluetooth FCC ID: A3LSGHE860V Page 3 of 6 © 2005 PCTEST Engineering Laboratory, Inc. EXHIBIT A – Test Results (Cont.) Radiated Harmonic Measurements (Cont.) §15.247(b) / §15.205 & §15.209 Distance of Measurements: 3 Meters Channel: 78 Table A-10. Radiated Fundamental & Harmonic Measurements NOTES: 1. All harmonics in the restricted bands specified in §15.205 are below the limit shown in Table A- 18. (Note: * = Restricted Band measured frequency) 2. All harmonics/spurs are at least 20 dB below the highest emission in the authorized band using RBW = 100kHz 3. Average Measurements > 1GHz using RBW = 1 MHz VBW = 10 Hz 4. The peak emissions above 1 GHz are not more than 20 dB above the average limit. 5. The antenna is manipulated through typical positions, polarity and length during the tests. 6. The EUT is supplied with nominal AC voltage or/and a new/fully-recharged battery. 7. The spectrum is measured from 9kHz to the 10 th harmonic and the worst-case emissions are reported. 8. < - 135 dBm are below the analyzer floor level. 9. Above 1 GHz, the limit is 500 μV/m (54dBμ/m) at 3 meters radiated. Figure A-9. Radiated limits at 3 meters. FREQ.LEVELAFCLPOLTOTALF/SMARGIN (MHz)(dBm)(dB)(H/V)(dBuV/m)(uV/m)(dB) 4960.00-103.0040.7V44.7171.8-9.3 7440.00-110.4048.2V44.8173.8-9.2 9920.00-110.1050.4V47.3231.7-6.7 12400.00-111.5053.7V49.2288.4-4.8 PCTEST LAB TEST REPORT 15.247 FCC CERTIFICATION REPORT Reviewed by: Quality Manager Filename: 1506260330 Test Dates: July 7, 2005 EUT Type: Samsung Single-Band GSM Phone w/ Bluetooth FCC ID: A3LSGHE860V Page 4 of 6 © 2005 PCTEST Engineering Laboratory, Inc. EXHIBIT A – Test Results (Cont.) Radiated Restricted Band Measurements §15.205 / §15.209 Special attention is made for the EUT’s harmonic and spurious radiated emission in the restricted bands of operations. The EUT was tested from 9kHz and up to the tenth harmonic of the fundamental frequency of the transmitter using CISPR quasi peak detector below 1GHZ. Above 1 GHz, average measurement was used, using RBW 1MHz – VBW 10Hz and linearly polarized horn antennas. All harmonics/spurs are at least 20dB below the highest emission in the authorized band using RBW = 100kHz. Measurements were performed up through the 10 th harmonic. In addition, peak measurements were taken to ensure that the peak levels are not more than 20dB above the average limit. All out of band emissions, other than those created by the spreading sequence, data sequence, and the carrier modulation must not exceed the limits show in Table G-1 per Section 15.209. Frequency F/S (μV/m) Measured Distance (Meters) 0.009 – 0.490 MHz 2400/F (kHz) 300 0.490 – 1.705 MHz 24000/F (kHz) 30 1.705 – 30.00 MHz 30 30 30.00 – 88.00 MHz 100 3 88.00 – 216.0 MHz 150 3 216.0 – 960.0 MHz 200 3 Above 960.0 MHz 500 3 Table A-18. Restricted…

Text truncated - open the document above for the full version.

© 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE860V Single-Band PCS GSM Phone with Bluetooth © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE860V Single-Band PCS GSM Phone with Bluetooth © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE860V Single-Band PCS GSM Phone with Bluetooth © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE860V Single-Band PCS GSM Phone with Bluetooth © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE860V Single-Band PCS GSM Phone with Bluetooth © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHE860V Single-Band PCS GSM Phone with Bluetooth
