A3LSGHI300Single-Band PCS GSM Phone w/ Bluetooth Transmitter

Please read this manual before operating your phone, and keep it for future reference. Smartphone SGH-i300 User’s Guide World Wide Web http://www.samsungmobile.com 2 Table of Contents Important safety precautions . . . . . . . . . . . . . . . . . . . 6 CHAPTER 1Getting started What’s in the box? . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Getting to know your phone . . . . . . . . . . . . . . . . . . . . 9 Installing the SIM card . . . . . . . . . . . . . . . . . . . . . . . 13 Installing the battery . . . . . . . . . . . . . . . . . . . . . . . . 14 Charging your phone . . . . . . . . . . . . . . . . . . . . . . . . 16 Turning your phone on or off . . . . . . . . . . . . . . . . . . 17 CHAPTER 2The basics Using the Home screen . . . . . . . . . . . . . . . . . . . . . . 18 Start menu screen . . . . . . . . . . . . . . . . . . . . . . . . . . 23 Entering text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 Using My Text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 Customising your phone . . . . . . . . . . . . . . . . . . . . . . 30 Key lock (Keyguard) . . . . . . . . . . . . . . . . . . . . . . . . 43 Using the Launcher . . . . . . . . . . . . . . . . . . . . . . . . . 44 Using an optional memory card . . . . . . . . . . . . . . . . . 46 Adding and removing programmes . . . . . . . . . . . . . . 47 Managing certificates . . . . . . . . . . . . . . . . . . . . . . . . 51 Resetting your phone . . . . . . . . . . . . . . . . . . . . . . . . 52 Using online help . . . . . . . . . . . . . . . . . . . . . . . . . . . 54 Table of Contents 3 CHAPTER 3Synchronisation Installing ActiveSync . . . . . . . . . . . . . . . . . . . . . . . . 56 Customising connection settings . . . . . . . . . . . . . . . . 58 Connecting your phone to a computer . . . . . . . . . . . . 59 Synchronising information . . . . . . . . . . . . . . . . . . . . 61 Customising synchronisation settings . . . . . . . . . . . . . 62 CHAPTER 4Phone functions Checking if you are connected . . . . . . . . . . . . . . . . . 68 Turning the phone functions on and off . . . . . . . . . . . 69 Using the Dialer screen . . . . . . . . . . . . . . . . . . . . . . 70 Making a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70 Advanced calling features . . . . . . . . . . . . . . . . . . . . . 72 Answering or rejecting a call . . . . . . . . . . . . . . . . . . . 76 Options during a call . . . . . . . . . . . . . . . . . . . . . . . . 77 Call-related features . . . . . . . . . . . . . . . . . . . . . . . . 78 Customising your phone functions . . . . . . . . . . . . . . . 87 CHAPTER 5Message, Internet, and Messenger Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97 Internet Explorer . . . . . . . . . . . . . . . . . . . . . . . . . . 118 Pocket MSN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123 WAP Browser . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124 MSN Messenger . . . . . . . . . . . . . . . . . . . . . . . . . . . 130 CHAPTER 6Organiser Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134 Calendar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142 Tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148 Table of Contents 4 CHAPTER 7Multimedia Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150 SAMSUNG Media Player . . . . . . . . . . . . . . . . . . . . . 164 Windows Media player . . . . . . . . . . . . . . . . . . . . . . 170 SRS WOW XT Settings . . . . . . . . . . . . . . . . . . . . . . 176 My Items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177 FunBox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178 CHAPTER 8Extra programmes Games . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180 Calculator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 182 Voice Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 183 Voice Assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 184 Time Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . 190 Document Viewer . . . . . . . . . . . . . . . . . . . . . . . . . 195 File Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200 SIM Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . 202 Task Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . 205 CHAPTER 9Getting connected Beaming with infrared connections . . . . . . . . . . . . . 207 Beaming with Bluetooth . . . . . . . . . . . . . . . . . . . . . 209 Modem link . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 215 Connecting to the Internet or your network . . . . . . . 216 Table of Contents 5 CHAPTER 10Troubleshooting General problems . . . . . . . . . . . . . . . . . . . . . . . . . 226 Call problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . 228 Power and charging problems . . . . . . . . . . . . . . . . . 230 Application problems . . . . . . . . . . . . . . . . . . . . . . . 232 CHAPTER 11Regulatory notices Regulatory agency identification numbers . . . . . . . . 238 SAR certification information . . . . . . . . . . . . . . . . . . 239 European union notice . . . . . . . . . . . . . . . . . . . . . . 240 Important safety information . . . . . . . . . . . . . . . . . 241 Safety precautions for power supply unit . . . . . . . . . 242 Care and maintenance . . . . . . . . . . . . . . . . . . . . . . 243 Microsoft End User License Agreement . . . . . . . . . . . 245 DESCRIPTION OF OTHER RIGHTS AND LIMITATIONS . . . . . . . . . . . . . . . . . . . . . . . . . 247 6 Important safety precautions Read these guidelines before using your wireless phone. Failure to comply with them may be dangerous or illegal. Drive safely at all times Do not use a hand-held phone while driving. Park the vehicle first. Switch off the phone when refuelling Do not use the phone at a refuelling point (service station) or nea…

Text truncated - open the document above for the full version.















































July 20         !"# $%&' ( &) "*   +,-   . / (0+1+//2(34 (5 /5 ///5 /4(0+1+// 2( 34(5555,4  .(5(65(5 / (5 1 # )57/(5)8 )94144 *4    1    1: ;&/ 1&19<;3<4




















































July 20


!
 ""
 ""
#$%"
 &
'
()
*+  !

, !
 "-

)


 .
/01
#
 23!

.
A3LSGHI300 , $
5
 5!

1  " .


 !
6
2)
5
 ,
)(
/01
#
 2
3!
  -
 $

 5!
5

' +
7"

7"

 %
8
3

 !
*%
 %
"
5

-9
%%  2

:
! "

!  !
  "
 !
$%"
! %
 !
  !
 5 "

-

% !
6
/01
#
 2
3!
 !
-  7
% %

 5!
 !

  "
! 7
 !
 6
6  !




7
%- 2




! 7


-
5 "
6
5
  7
% !
6

/01

#
 2
3!
 !


 5 "
6  !
-
5
- 5


 "%
 !


!
5

 5 "


! "
6  !
7
 "%

 5
! 7


"+ 2







;"
<
"
=
3-
/01
#
"
0





















































































July 20, 2005

!
 ""
 ""
 #
 !
$
%
$&'"
 #
(
)*
+,  !

- !
 ".

*



 /
012
$
 %
3!%

/
A3LSGHI300 - &
5
 67 "
 5!


7
8 "


   /


 !
9
%*)
 !
%*
5
 -
*)
012
$
 %
3!%
 &
 6  "
 5!
5


'
'
:
'

'
 !
 ;
"
5

 !

 ' %

7
! "

!  !
  "
 !
&'"
! '
 !
  !
 5 "
.

' !
9
012
$
 %3!

 !

.
' '
 5!
 !

  "
! <
 !
 9
9  !




<
'. %


! <


.
5 "
9
5
  <
' !
9

012
$
 %
3!
5


 5 "
9  !
.
5
. 5


 "'
 !


!
5

 5 "


! "
9  !
<

 "'

 5
! <


", %






="
>
"
?
3.
012
$
"
1%

7. Users Manual

© 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHI300 Single-Band PCS GSM Phone With Bluetooth © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHI300 Single-Band PCS GSM Phone With Bluetooth © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHI300 Single-Band PCS GSM Phone With Bluetooth © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHI300 Single-Band PCS GSM Phone With Bluetooth © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHI300 Single-Band PCS GSM Phone With Bluetooth © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHI300 Single-Band PCS GSM Phone With Bluetooth © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHI300 Single-Band PCS GSM Phone With Bluetooth © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHI300 Single-Band PCS GSM Phone With Bluetooth © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHI300 Single-Band PCS GSM Phone With Bluetooth © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHI300 Single-Band PCS GSM Phone With Bluetooth © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHI300 Single-Band PCS GSM Phone With Bluetooth © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHI300 Single-Band PCS GSM Phone With Bluetooth © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHI300 Single-Band PCS GSM Phone With Bluetooth © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHI300 Single-Band PCS GSM Phone With Bluetooth © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHI300 Single-Band PCS GSM Phone With Bluetooth

1 of 25 SAMSUNG ELECTRONICS Co., Ltd., Regulatory Compliance Group IT R&D Center 416, Maetan-3dong, Yeongtong-gu, Suwon-si, Gyeonggi-do, Korea 443-742 TEST REPORT ON SAR Model Tested: SGH-i300 FCC ID (Requested): A3LSGHI300 Job No: FC-098 Report No: FC-098-S1 Date issued: Jul. 18, 2005 - Abstract – This document reports on SAR Tests carried out in accordance with FCC/OET Bulletin 65, Supplement C(July 2001). Prepared By Date JD JANG - Test Engineer Checked By Date SH PARK - Senior Manager Authorized By Date JK CHOI - General Manager 2005.07.18 Report Number : FC-098-S1 2 of 25 Contents 1. General Information.............................................................................................3 2. Description of Device...........................................................................................3 3. Description of Test Equipment..............................................................................4 3.1 SAR Measurement Setup.........................................................................................4 3.2 DASY4 E-Field Probe.............................................................................................5 3.3 SAM Phantom.....................................................................................................6 3.4 Brain & Muscle Simulating Mixture Characterization.......................................................7 3.5 Device Holder for transmitters....................................................................................8 3.6 Validation Dipole....................................................................................................8 3.7 Equipment Calibration.............................................................................................9 4. SAR Measurement Procedure.............................................................................10 5. Description of test position..............................................................................11 5.1 SAM Phantom Shape.............................................................................................11 5.2 Cheek/Touch Position............................................................................................11 5.3 Ear/Tilt 15 Position..............................................................................................13 5.4 Body/Holster/Belt Clip Configuration..........................................................................14 6. Measurement Uncertainty...................................................................................16 7. System Verification............................................................................................18 7.1 Tissue Verification.................................................................................................18 7.2 Test System Validation...........................................................................................18 8. SAR Measurement Results.................................................................................19 8.1 Measurement Results(GSM1900 Right Head SAR-Touch)............................................19 8.2 Measurement Results(GSM1900 Right Head SAR-Tilt)................................................20 8.3 Measurement Results(GSM1900 Left Head SAR-Touch)..............................................21 8.4 Measurement Results(GSM1900 Left Head SAR-Tilt)..................................................22 8.5 Measurement Results(GPRS1900 Body SAR w/o Holster)..........................................23 9. Conclusion.......................................................................................................24 10. Reference.......................................................................................................25 Report Number : FC-098-S1 3 of 25 1. GENERAL INFORMATION Test Sample : Single-Band GSM1900 Phone With Bluetooth Model Number : SGH-i300 Serial Number : Identical prototype (S/N : FC-098-B) Manufacturer : SAMSUNG ELECTRONICS Co., Ltd. Contact : MH Kyuk, Engineer Phone : +82-54-479-7210 Fax : +82-52-479-5920 Test Standard : §2.1093; FCC/OET Bulletin 65, Supplement C(July 2001) FCC Classification : Licensed Portable Transmitter Held to Ear (PCE) Test Dates : Jul. 08, 2005 Tested for : FCC/TCB Certification 2. DESCRIPTION OF DEVICE Tx Freq. Range : 1850.20 – 1909.80 MHz (GSM1900) 2402 -2480 MHz (Bluetooth) Rx Freq. Range : 1930.20 – 1989.80 MHz (GSM1900) 2402-2480MHz (Bluetooth) Max. RF Output Power : 1.807 W EIRP GSM1900 (32.57 dBm) Antenna Manufacturer : Samsung electro mechanics products Model No.: SGH-i300 Antenna Dimensions : 43mm Report Number : FC-098-S1 4 of 25 3. DESCRIPTION OF TEST EQUIPMENT 3.1 SAR Measurement Setup Robotic System Measurements are performed using the DASY4 automated dosimetric assessment system. Which is made by Schmid & Partner Engineering AG (SPEAG) in Zurich, Switzerland and consists of high precision robotics system (Stäubli), robot controller, measurement server, Samsung computer, near- field probe, probe alignment sensor, and the SAM twin phantom containing the brain equivalent material. The robot is a six-axis industrial robot performing precise movements to position the probe to the location (points) of maximum electromagnetic field (EMF) (see Fig. 3.1). Figure 3.1 SAR Measurement System Setup System Hardware A cell controller system contains the power supply, robot controller, teach pendant (Joystick), and a remote control is used to drive the robot motors. The PC consists of the Samsung computer with Windows XP system and SAR Measurement Software DASY4, LCD monitor, mouse and keyboard. The Stäubli Robot is connected to the cell controller to allow software manipulation of the robot. A data acquisition electronic (DAE) circuit that performs the signal amplification, signal multiplexing, AD-conversion, offset measurements, mechanical surface detection, collision detection, etc. is connected to the Electro-optical coupler (EOC). The EOC performs…

Text truncated - open the document above for the full version.

SAMSUNG FCC ID : A3LSGHI300 -- 1900MHz GSM1900 Head SAR DUT: SGH-i300; Serial: FC-098-B Program Name: SGH-i300 GSM1900 Right (Job No. : FC-098) Procedure Name: Cheek/Touch, Ch.512, Ant.Intenna, Bat.Extended Procedure Notes: Meas.Tissue Temp(celsius)-21.6; Test Date-08/Jul/2005 [OET Bulletin 65- Supplement C, July 2001] Communication System: GSM 1900; Frequency: 1850.2 MHz;Duty Cycle: 1:8.3 Medium parameters used: f = 1850.2 MHz; σ = 1.4 mho/m; ε r = 39.4; ρ = 1000 kg/m 3 Phantom section: Right Section DASY4 Configuration: - Probe: EX3DV4 - SN3537; ConvF(8.29, 8.29, 8.29); Calibrated: 2004-12-15 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn468; Calibrated: 2004-12-07 - Phantom: SAM 835/900 MHz; Type: SAM; Serial: TP-1247 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Cheek/Touch, Ch.512, Ant.Intenna, Bat.Extended/Area Scan (51x61x1): Measurement grid: dx=20mm, dy=20mm Maximum value of SAR (interpolated) = 0.374 mW/g Cheek/Touch, Ch.512, Ant.Intenna, Bat.Extended/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 15.2 V/m; Power Drift = -0.018 dB Peak SAR (extrapolated) = 0.582 W/kg SAR(1 g) = 0.356 mW/g Maximum value of SAR (measured) = 0.379 mW/g 0 dB = 0.379mW/g SAMSUNG FCC ID : A3LSGHI300 -- 1900MHz GSM1900 Head SAR DUT: SGH-i300; Serial: FC-098-B Program Name: SGH-i300 GSM1900 Right (Job No. : FC-098) Procedure Name: Ear/Tilt, Ch.661, Ant.Intenna, Bat.Extended Procedure Notes: Meas.Tissue Temp(celsius)-21.6; Test Date-08/Jul/2005 [OET Bulletin 65- Supplement C, July 2001] Communication System: GSM 1900; Frequency: 1880 MHz;Duty Cycle: 1:8.3 Medium parameters used: f = 1880 MHz; σ = 1.4 mho/m; ε r = 39.4; ρ = 1000 kg/m 3 Phantom section: Right Section DASY4 Configuration: - Probe: EX3DV4 - SN3537; ConvF(8.29, 8.29, 8.29); Calibrated: 2004-12-15 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn468; Calibrated: 2004-12-07 - Phantom: SAM 835/900 MHz; Type: SAM; Serial: TP-1247 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Ear/Tilt, Ch.661, Ant.Intenna, Bat.Extended/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 15.3 V/m; Power Drift = 0.019 dB Peak SAR (extrapolated) = 0.542 W/kg SAR(1 g) = 0.321 mW/g Maximum value of SAR (measured) = 0.356 mW/g Ear/Tilt, Ch.661, Ant.Intenna, Bat.Extended/Area Scan (51x71x1): Measurement grid: dx=20mm, dy=20mm Maximum value of SAR (interpolated) = 0.351 mW/g 0 dB = 0.351mW/g SAMSUNG FCC ID : A3LSGHI300 -- 1900MHz GSM1900 Head SAR DUT: SGH-i300; Serial: FC-098-B Program Name: SGH-i300 GSM1900 Left (Job No. : FC-098) Procedure Name: Cheek/Touch, Ch.512, Ant.Intenna, Bat.Extended Procedure Notes: Meas.Tissue Temp(celsius)-21.6; Test Date-08/Jul/2005 [OET Bulletin 65- Supplement C, July 2001] Communication System: GSM 1900; Frequency: 1850.2 MHz;Duty Cycle: 1:8.3 Medium parameters used: f = 1850.2 MHz; σ = 1.4 mho/m; ε r = 39.4; ρ = 1000 kg/m 3 Phantom section: Left Section DASY4 Configuration: - Probe: EX3DV4 - SN3537; ConvF(8.29, 8.29, 8.29); Calibrated: 2004-12-15 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn468; Calibrated: 2004-12-07 - Phantom: SAM 835/900 MHz; Type: SAM; Serial: TP-1247 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Cheek/Touch, Ch.512, Ant.Intenna, Bat.Extended/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 15.6 V/m; Power Drift = -0.083 dB Peak SAR (extrapolated) = 0.834 W/kg SAR(1 g) = 0.475 mW/g Maximum value of SAR (measured) = 0.497 mW/g Cheek/Touch, Ch.512, Ant.Intenna, Bat.Extended/Area Scan (51x71x1): Measurement grid: dx=20mm, dy=20mm Maximum value of SAR (interpolated) = 0.479 mW/g 0 dB = 0.479mW/g SAMSUNG FCC ID : A3LSGHI300 -- 1900MHz GSM1900 Head SAR DUT: SGH-i300; Serial: FC-098-B Program Name: SGH-i300 GSM1900 Left (Job No. : FC-098) Procedure Name: Ear/Tilt, Ch.661, Ant.Intenna, Bat.Extended Procedure Notes: Meas.Tissue Temp(celsius)-21.6; Test Date-08/Jul/2005 [OET Bulletin 65- Supplement C, July 2001] Communication System: GSM 1900; Frequency: 1880 MHz;Duty Cycle: 1:8.3 Medium parameters used: f = 1880 MHz; σ = 1.4 mho/m; ε r = 39.4; ρ = 1000 kg/m 3 Phantom section: Left Section DASY4 Configuration: - Probe: EX3DV4 - SN3537; ConvF(8.29, 8.29, 8.29); Calibrated: 2004-12-15 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn468; Calibrated: 2004-12-07 - Phantom: SAM 835/900 MHz; Type: SAM; Serial: TP-1247 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Ear/Tilt, Ch.661, Ant.Intenna, Bat.Extended/Area Scan (51x71x1): Measurement grid: dx=20mm, dy=20mm Maximum value of SAR (interpolated) = 0.370 mW/g Ear/Tilt, Ch.661, Ant.Intenna, Bat.Extended/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 14.0 V/m; Power Drift = 0.055 dB Peak SAR (extrapolated) = 0.618 W/kg SAR(1 g) = 0.342 mW/g Maximum value of SAR (measured) = 0.373 mW/g 0 dB = 0.373mW/g SAMSUNG FCC ID : A3LSGHI300 -- 1900MHz GSM1900 Head SAR DUT: SGH-i300; Serial: FC-098-B Program Name: SGH-i300 GSM1900 Left (Job No. : FC-098) Procedure Name: Cheek/Touch, Ch.512, Ant.Intenna, Bat.Extended with BT Procedure Notes: Meas.Tissue Temp(celsius)-21.6; Test Date-08/Jul/2005 [OET Bulletin 65- Supplement C, July 2001] Communication System: GSM 1900; Frequency: 1850.2 MHz;Duty Cycle: 1:8.3 Medium parameters used: f = 1850.2 MHz; σ = 1.4 mho/m; ε r = 39.4; ρ = 1000 kg/m 3 Phantom section: Left Section DASY4 Configuration: - Probe: EX3DV4 - SN3537; ConvF(8.29, 8.29, 8.29); Calibrated: 2004-12-15 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn468; Calibrated: 2004-12-07 - Phantom: SAM 835/900 MHz; Type: SAM; Serial: TP-1247 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Cheek/Touch, Ch.512, Ant.Intenna, Bat.Extended with BT/Area …

Text truncated - open the document above for the full version.

DUT: Dipole 1900 MHz; Serial: 5d023 Program Name: 1900 Dipole Validation 2005.07.08 Procedure Name: 1900MHz @250mW Procedure Notes: Communication System: CW; Frequency: 1900 MHz;Duty Cycle: 1:1 Medium parameters used: f = 1900 MHz; σ = 1.4 mho/m; ε r = 39.4; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: - Probe: EX3DV4 - SN3537; ConvF(8.29, 8.29, 8.29); Calibrated: 2004-12-15 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn468; Calibrated: 2004-12-07 - Phantom: SAM 1800/1900 MHz; Type: SAM; Serial: TP-1248 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 1900MHz @250mW/Area Scan (51x51x1): Measurement grid: dx=20mm, dy=20mm Maximum value of SAR (interpolated) = 15.2 mW/g 1900MHz @250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 89.8 V/m; Power Drift = 0.00 dB Peak SAR (extrapolated) = 18.7 W/kg SAR(1 g) = 10.1 mW/g Maximum value of SAR (measured) = 11.3 mW/g 0 dB = 11.3mW/g

SAMSUNG ELECTRONICS Co., Ltd., Regulatory Compliance Group IT R&D Center 416 Maetan3-Dong, Yeongtong-gu, Suwon city, Gyeonggi-Do, Korea 443-742 FCC CFR47 PART 24 SUBPART CERTIFICATION REPORT Model Tested: SGH-i300 FCC ID (Requested): A3LSGHI300 Report No: FC-098-R1 Job No: FC-098 Date issued: July 18,2005 - Abstract – All measurement reported herein accordance with FCC Rules, 47CFR Part2, Part24. Prepared By Date WW JANG – Test Engineer Checked By Date SH PARK – Senior Manager Authorized By Date JK CHOI – General Manager © Copyright SAMSUNG Electronics 2005 Report Number : FC-098-R1 TABLE OF CONTENT MEASUREMENT REPORT Page 1. FCC Certification Information 3 1.1 2.1033 General Information 3 2. INTRODUCTION 4 2.1 General 4 3. MEASURING INSTRUMENT CALIBRATION 5 4. TEST EQUIPMENT LIST 6 5. DESCRIPTION OF TESTS 7 5.1 Equivalent Isotropic Radiated Power 7 5.2 Radiated Spurious & Harmonic Emission 8 5.3 Occupied Bandwidth 9 5.4 Spurious and Harmonic Emissions at Antenna Terminal 9 5.4.1 Occupied Bandwidth Emission Limits 9 5.4.2 Conducted Spurious Emission 11 5.5 Frequency Stability / Temperature Variation 13 6. TEST DATA 14 6.1 Equivalent Isotropic Radiated Power (E.I.R.P.) 14 6.2 Radiated Spurious & Harmonic Measurement 15 6.3 Radiated Spurious & Harmonic Conversion Table 16 6.4 Frequency Stability 17 6.4.1 Frequency Stability Table 17 6.4.2 Frequency Stability Graph 18 7. CONCLUSION 20 8. TEST PLOTS 21 Report Number : FC-098-R1 MEASUREMENT REPORT 1. FCC Certification Information The following information is in accordance with FCC Rules, 47CFR Part2, Subpart J, Sections 2.1033 – 2.1055. 1.1 §2.1033 General Information Applicant Name: SAMSUNG ELECRONICS CO., LTD. Address: 416 Maetan3-Dong, Yeongtong-gu, Suwon City Gyeonggi-Do, Korea 443-742 Attention: FCC ID: SungJoo KIM, Engineering Manager (QA Lab) A3LSGHI300 Quantity: Quantity production is planned Emission Designators: 246KGXW Tx Freq. Range: 1850.2MHz -1909.8MHz Rx Freq. Range: 1930.2MHz – 1989.8MHz Max. Power Rating: 1.807W EIRP GSM1900 (32.57dBm) FCC Classification(s): Licensed Portable Tx Held to Ear (PCE) Equipment (EUT) Type: Single-Band PCS GSM Phone with Bluetooth Frequency Tolerance: 0.00025% (2.5ppm) FCC Rule Part(s): 24(E), Dates of Test: July 8, 11-12 , 2005 Place of Test: SAMSUNG Lab, Test Report S/N: FC-098-R1 - End of page - Report Number : FC-098-R1 2. INTRODUCTION 2.1 General These measurement test were conducted at SAMSUNG ELECTRONICS CO., LTD(SUWON). The site address is 416 Maetan3-Dong, Yeongtong-gu, Suwon City, Gyeonggi-Do, Korea 442-742 The site have 1 Fully-anechoic chamber and measurement facility. Measurement Procedure The radiated and spurious measurements were made Fully-anechoic chamber at a 3-meter test range (see Figure2). The equipment under testing was placed on a Non-conducted turntable 3- meters from the receive antenna. The receive antenna height and turntable rotations were adjusted for the highest reading on the receive spectrum analyzer. The substitution antenna will replace the EUT antenna it the same position and in vertical polarization. The frequency of the signal generator shall be set to the frequencies that were measured on the EUT. The test antenna shall be raised and lowered, if necessary, to ensure that the maximum signal is still being received. The signal generator, output level, shall be adjusted until an equal or a known related level to what was measured from the EUT is obtained in the spectrum analyzer. This level was recorded. For readings above 1 GHz, the above procedure is repeated using horn antennas and the difference between the gain of the horn and an isotropic antenna are taken into consideration. Figure1. Map of the Suwon City area. Fi gure2. Photograph of 3m Fully-Anechoic Chamber Report Number : FC-098-R1 3.MEASURING INSTRUMENT CALIBRATION The measuring equipment, which was utilized in performing the tests documented herein, has been calibrated in accordance with the manufacturer’s recommendations for utilizing calibration equipment, which is traceable to recognized national standards. - End of page - Report Number : FC-098-R1 4. TEST EQUIPMENT LIST Name of Equipment Model Serial No. Due Date ESI26 836119/010 2005-09-20 E4440A(3Hz~26.5GHz) MY41000236 2005-10-27 Spectrum Analyzer E4440A(3Hz~26.5GHz) MY41000233 2005-11-04 SMIQ03B 83824/021 2005-12-27 Signal Generator SMR20 835197/030 2006-01-18 Power Meter E4419B GB41293846 2005-09-21 8481B 3318A10325 2005-10-06 Power Sensor 8485A 3318A19924 2005-09-20 Amplifier 5S1G4 304866 2005-10-19 Pre-Amplifier 8449B 3008A00691 2006-01-11 8960 GB42230535 2005-11-04 Communication test set 8960 GB42360886 2005-10-27 Antenna Master MA0001 ANT0967 Not Required Controller HD100 100/756 Not Required PL-4S 13005454 2005-07-31 SH-241 92000548 2005-11-22 Environmental Chamber SH-241 92000549 2005-11-22 HF906 360306/011 2006-03-17 Horn Antenna HF906 100134 2006-04-25 Dipole Antenna 3121C-DB4 9007-587 2005-12-02 Receive Antenna HL040 353255/019 2005-08-13 8494A 3308A31997 2006-01-03 Attenuator 8496A 3308A14426 2006-01-04 11636B 51941 Not Required 11636B 51942 Not Required Divider 11636B 51946 Not Required WHK1.0/15G-10SS 1 Not Required WHK1.0/15G-10SS 1 Not Required WHK/3.5/18G-10SS 3 Not Required High Pass Filter WHK/3.5/18G-10SS 4 Not Required Shielded Fully Anechoic Chamber RF0002 ANT0001 Not Required Report Number : FC-098-R1 5. DESCRIPTION OF TESTS 5.1 Equivalent Isotropic Radiated Power Test Set-up for the EIRP TEST Effective Radiated Power Output and Equivalent Isotropic Radiated Power Measurements by Substitution Method according to ANSI/TIA/EIA-603-A-2001, Aug. 15, 2001: The EUT was placed on a Non-conducted turntable 3-meters from the receive antenna. The receive antenna height and turntable rotation was adjusted for the highest reading on the receive spectrum …
