A3LSGHX495HSingle-Band PCS GSM Phone

UVEH1_1.2_WCx495H_081805_F1 SGH-x495H Series PORTABLE Dual-Band TELEPHONE User Guide Please read this manual before operating your phone, and keep it for future reference. x495.book Page 1 Thursday, August 18, 2005 12:23 PM Intellectual Property All Intellectual Property, as defined below, owned by or which is otherwise the property of Samsung or its respective suppliers relating to the SAMSUNG Phone, including but not limited to, accessories, parts, or software relating there to (the “Phone System”), is proprietary to Samsung and protected under federal laws, state laws, and international treaty provisions. Intellectual Property includes, but is not limited to, inventions (patentable or unpatentable), patents, trade secrets, copyrights, software, computer programs, and related documentation and other works of authorship. You may not infringe or otherwise violate the rights secured by the Intellectual Property. Moreover, you agree that you will not (and will not attempt to) modify, prepare derivative works of, reverse engineer, decompile, disassemble, or otherwise attempt to create source code from the software. No title to or ownership in the Intellectual Property is transferred to you. All applicable rights of the Intellectual Property shall remain with SAMSUNG and its suppliers. Samsung Telecommunications America (STA), L.P. Headquarters:Customer Care Center: 1301 E. Lookout Drive1000 Klein St. Richardson, TX 75082Plano, TX 75074 Tel: 972.761.7000Toll Free Tel: 1.888.987.HELP (4357) Internet Address: http://www.samsungusa.com © 2005 Samsung Telecommunications America, Inc. is a registered trademark of Samsung Electronics America, Inc. and its related entities. Printed in South Korea x495.book Page 2 Thursday, August 18, 2005 12:23 PM GH68-08137A Openwave® is a registered Trademark of Openwave, Inc. RSA® is a registered Trademark RSA Security, Inc. Disclaimer of Warranties; Exclusion of Liability EXCEPT AS SET FORTH IN THE EXPRESS WARRANTY CONTAINED ON THE WARRANTY PAGE ENCLOSED WITH THE PRODUCT, THE PURCHASER TAKES THE PRODUCT "AS IS", AND SAMSUNG MAKES NO EXPRESS OR IMPLIED WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT TO THE PRODUCT, INCLUDING BUT NOT LIMITED TO THE MERCHANTABILITY OF THE PRODUCT OR ITS FITNESS FOR ANY PARTICULAR PURPOSE OR USE; THE DESIGN, CONDITION OR QUALITY OF THE PRODUCT; THE PERFORMANCE OF THE PRODUCT; THE WORKMANSHIP OF THE PRODUCT OR THE COMPONENTS CONTAINED THEREIN; OR COMPLIANCE OF THE PRODUCT WITH THE REQUIREMENTS OF ANY LAW, RULE, SPECIFICATION OR CONTRACT PERTAINING THERETO. NOTHING CONTAINED IN THE INSTRUCTION MANUAL SHALL BE CONSTRUED TO CREATE AN EXPRESS OR IMPLIED WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT TO THE PRODUCT. IN ADDITION, SAMSUNG SHALL NOT BE LIABLE FOR ANY DAMAGES OF ANY KIND RESULTING FROM THE PURCHASE OR USE OF THE PRODUCT OR ARISING FROM THE BREACH OF THE EXPRESS WARRANTY, INCLUDING INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES, OR LOSS OF ANTICIPATED PROFITS OR BENEFITS. x495.book Page 3 Thursday, August 18, 2005 12:23 PM x495.book Page 4 Thursday, August 18, 2005 12:23 PM Table of Contents1 Table of Contents Table of Contents Section 1: Getting Started .................................. 5 Activating Your Phone ...................................................... 6 Switching the Phone On or Off ........................................ 10 Setting Up Your Voice Mail ............................................. 11 Section 2: Understanding Your Phone ............. 15 Features of Your Phone .................................................. 16 View of Your Phone ........................................................ 16 Keys ............................................................................... 17 Understanding the Display Screen .................................. 19 Section 3: Call Functions.................................. 21 Making a Call ................................................................. 22 Adjusting the Call Volume ............................................... 24 Answering a Call ............................................................ 24 Call Log .......................................................................... 25 Call Records ................................................................... 27 Silent Mode .................................................................... 30 Selecting Functions and Options .................................... 30 Section 4: Menu Navigation ............................. 39 Menu Navigation ............................................................ 40 Menu Outline ................................................................. 41 Section 5: Entering Text ................................... 47 Changing the Text Input Mode ........................................ 48 Using T9 Mode ............................................................... 49 Using ABC Mode ............................................................ 51 Using Symbols ............................................................... 53 Using Numbers .............................................................. 53 Section 6: Understanding Your Phonebook..... 55 Finding a Phonebook Entry ............................................. 56 Storing a Number in the Phone’s Memory ...................... 56 x495.book Page 1 Thursday, August 18, 2005 12:23 PM Ta b l e o f C o nt en t s 2 Storing a Number in the SIM Memory .............................58 Dialing a Number from the Phonebook ...........................59 Dialing a Number from the SIM Card ..............................59 Speed Dialing .................................................................59 Copying SIM Phonebook Entries to Phone .......................60 Deleting all Phonebook Entries .......................................61 Group Settings ...............................................................61 Finding My Own Number ................................................62 Checking the Memory Status .................…

Text truncated - open the document above for the full version.

Section 4 40 Menu Navigation You can tailor the phone’s range of functions to your needs using menus and sub-menus. Menus and sub- menus can be accessed by scrolling using the Navigation keys or by using the shortcuts. Accessing a Menu Function by Scrolling 1.In Idle mode, press the Menu soft key to access Menu mode. 2.Scroll using the Navigation keys to reach a main menu, Settings for example. Press the Select soft key or the key to enter the menu. 3.If the menu contains sub-menus, Language for example, you can access them by pressing the Select soft key or the key. If the menu that you have selected contains further options, repeat this step. 4.To scroll through the menus, press the Up or Down keys. 5.To confirm the chosen setting, press the Select soft key, or the key. 6.To return to the previous menu level, press the key or the key. 7.To exit the menu without changing the settings, press the key. Using Shortcuts The menu items, such as menus, sub-menus, and options, are numbered and can be accessed quickly by using their shortcut numbers. For the main menus, you can access x495.book Page 40 Thursday, August 18, 2005 12:23 PM Section 4: Menu Navigation41 Menu Outline Section 4 any one of them by pressing the number keys (1 to 9) corresponding to their location on the screen. Example: Accessing the Language menu. 1.Press the Menu soft key. 2.Press the 9 key for Settings. 3.Press the 5 key for Language. 4.Press the 1 key for Text language. The available languages are displayed. Menu Outline The following list shows the menu structure and indicates the number assigned to each option. 1. Voice messages 2. Call records 2.1 Missed calls 2.2 Incoming calls 2.3 Outgoing calls 2.4 Delete all 2.5 Call time 2.5.1 Last call 2.5.2 Total outgoing 2.5.3 Total incoming 2.5.4 Life time 2.5.5 Reset timers x495.book Page 41 Thursday, August 18, 2005 12:23 PM Section 4 42 3. t-zones 3.1 Home 3.2 Favorites 3.3 Go to URL 3.4 Clear cache 4. IM 5. Messages 5.1 Text messages 5.1.1 Create 5.1.2 Inbox 5.1.3 Outbox 5.1.4 Delete all 5.2 Picture messages 5.2.1 Create 5.2.2 Inbox 5.2.3 Outbox 5.2.4 Draft 5.2.5 Delete all 5.3 Browser messages 5.3.1 Inbox 5.3.2 Receive 5.3.3 Delete all 5.4 Voice mail x495.book Page 42 Thursday, August 18, 2005 12:23 PM Section 4: Menu Navigation43 Menu Outline Section 4 5.4.1 Call voice mail 5.4.2 Voice server number 5.5 Broadcast* 5.6 Settings 5.6.1 Text messages 5.6.2 Picture messages 5.7 Memory status 5.7.1 Text messages 5.7.2 Picture messages 6. Funbox 6.1 t-zones 6.2 Sounds 6.3 Images 6.4 Games 6.5 Delete all 6.5.1 Sounds 6.5.2 Images 6.6 Memory status 7. Organizer 7.1 Alarm 7.2 Calendar 7.3 Calculator 7.4 To do list x495.book Page 43 Thursday, August 18, 2005 12:23 PM Section 4 44 7.5 Voice memo 7.5.1 Record voice 7.5.2 Voice memos 7.5.3 Delete all 7.5.4 Settings 7.5.5 Memory status 7.6 Conversion 7.6.1 Length 7.6.2 Weight 7.6.3 Volume 7.6.4 Area 7.6.5 Temperature 7.7 Timer 7.8 Stopwatch 8. Sound settings 8.1 My MegaTones 8.2 Get More MegaTones 8.3 Ringtones 8.4 Ring volume 8.5 Alert type 8.6 Keypad tone 8.7 Message tone 8.7.1 Text messages 8.7.2 Picture messages x495.book Page 44 Thursday, August 18, 2005 12:23 PM Section 4: Menu Navigation45 Menu Outline Section 4 8.8 Power on/off 8.9 Alerts on call 8.0 Extra tones 9. Settings 9.1 Time & Date 9.1.1 Set date 9.1.2 World time 9.1.3 Set time 9.1.4 Time format 9.1.5 Auto update 9.2 Display settings 9.2.1 Wallpaper 9.2.2 Interior display 9.2.3 Backlight 9.2.4 Brightness control 9.2.5 Dialing font color 9.3 Get More Help 9.4 Greeting message 9.5 Language 9.5.1 Text language 9.5.2 Input mode 9.6 Security 9.6.1 PIN check 9.6.2 Change PIN x495.book Page 45 Thursday, August 18, 2005 12:23 PM Section 4 46 9.6.3 Phone lock 9.6.4 Change password 9.6.5 Privacy 9.6.6 FDN mode 9.6.7 Change PIN2 9.7 Extra settings 9.8 Reset settings 9.8.1 Sound settings 9.8.2 Phone settings 9.8.3 All settings 9.9 Network services 9.9.1 Call forwarding 9.9.2 Call waiting 9.9.3 Network selection 9.9.4 Caller ID 9.9.5 Band selection * Shows only if supported by your SIM card. x495.book Page 46 Thursday, August 18, 2005 12:23 PM Section 5: Entering Text47 Section 5 Section 5: Entering Text Topics Covered • Changing the Text Input Mode • Using T9 Mode • Using ABC Mode • Using Symbols • Using Numbers This section outlines how to select the desired text input mode when entering characters into your phone. This section also describes how to use the T9 predictive text entry system to reduce the number of key strokes associated with entering text. x495.book Page 47 Thursday, August 18, 2005 12:23 PM 48 Section 5 Changing the Text Input Mode When using your phone, you will often need to enter text, such as when storing a name in Phonebook, creating your personal greeting or schedulin g e v e n t s o n y o u r c a l e n d a r. You can enter alphanumeric characters by using your phone’s keypad. Your phone has the following text input modes: • ABC mode: this mode allows you to enter letters by pressing the key labeled with the letter you want. Press the key once, twice, three, or four times until it displays. • T9 mode: this mode allows you to enter words with only one keystroke per letter. Each key on the keypad has more than one letter; for example, pressing the 5 key can enter J, K, or L. However, the T9 mode automatically compares the series of keystrokes you make with an internal linguistic dictionary to determine the most likely word, thus requiring far fewer keystrokes than the traditional ABC mode. • Number mode: this mode allows you to enter numbers. • Symbol mode: this mode allows you to enter symbols, such as punctuation marks. When you are in a field that allows characters to be entered, you will notice the text input mode indicator on the display. Example: Writing a text message. x495.book Page 48 Thursday, August 18, 2005 12:23 PM Section 5: Entering Text49 Using T9 Mode Section 5 1.To change the text input mode, press the key. 2.Highlight the input option th…

Text truncated - open the document above for the full version.

84 Section 7 x495.book Page 84 Thursday, August 18, 2005 12:23 PM Section 8 Section 8: Changing Your Settings85 Section 8: Changing Your Settings Topics Covered • Sound Settings • Phone Settings This section explains the sound and phone settings for your phone. It includes display settings, security settings, and extra settings associated with your phone. x495.book Page 85 Thursday, August 18, 2005 12:23 PM Section 8 86 Sound Settings You can customize various sound settings. My MegaTones This menu allows you to select different ringtone melodies that you have downloaded from the Internet. Get More MegaTones This menu allows you to download different ringtone melodies from the Internet. To enable a downloaded ringtone, use the My MegaTones option. Ringtones This menu allows you to select a ring melody. You can choose between many different melodies. Ring Volume This menu allows you to adjust the ring volume to one of five levels. Use the Up and Down keys or the Vo l u m e keys on the left side of the phone to increase or decrease the volume. Alert Type This menu allows you to specify how you are to be informed of incoming calls. The following options are available: • Melody: the phone rings using the ring melody selected in the Ringtone menu. • Vibration: the phone vibrates but does not ring. x495.book Page 86 Thursday, August 18, 2005 12:23 PM Section 8: Changing Your Settings87 Sound Settings Section 8 • Vibration then melody: the phone first vibrates 3 times and then starts ringing using the ring melody selected in the Ringtone menu. Keypad Tone This menu allows you to select the sound that the phone will make when you press a key. You may select either Tone or Beep. To turn off the sound, select Off. Message Tone This menu allows you to set up the ringer for incoming messages, text messages, and multimedia messages. Text Me ss a g e This menu allows you to select how the phone informs you that a new text message has been received. The following options are available: • To n e: allows you to use one of several message tones. • Mode: allows you specify how you are informed of any incoming messages. • Silent: only the text notification appears; the phone neither rings nor vibrates. • To n e: the phone rings using the tone selected under the Tone option. • Vibration: the phone vibrates. • Vibration then tone: the phone vibrates six times then rings using the selected tone. • Repetition: allows you to specify how often the phone informs you of a new message. The following options are available: x495.book Page 87 Thursday, August 18, 2005 12:23 PM Section 8 88 • Once: the phone alerts you to a new message just once at the time of receipt. • Periodic: the phone alerts you to a new message every 2 minutes until you open the message. Picture Message This menu allows you to select how the phone informs you that a new multimedia message has been received. The following options are available: • To n e: allows you to use one of several message tones. • Mode: allows you specify how you are informed of any incoming messages. • Silent: only the text notification appears; the phone neither rings nor vibrates. • To n e: the phone rings using the tone selected under the Ton e option. • Vibration: the phone vibrates. • Vibration then tone: the phone vibrates six times then rings using the selected tone. • Repetition: allows you to specify how often the phone informs you of a new message. The following options are available: • Once: the phone alerts you to a new message just once at the time of receipt. • Periodic: the phone alerts you to a new message every 2 minutes until you open the message. Power On/Off This menu allows you to select whether or not a melody sounds when the phone is switched on and off. To turn off the sound, select Off. x495.book Page 88 Thursday, August 18, 2005 12:23 PM Section 8: Changing Your Settings89 Phone Settings Section 8 Alerts on Call This menu allows you to choose whether or not the phone informs you when you receive a new message or when the time for an alarm comes during a call. The following options are available: • Off: the phone doesn’t actively alert you to incoming messages or alarms. It only displays the corresponding notification. • On: the phone alerts you with a beep and displays the corresponding notification. Extra Tones You can customize additional tones for the phone. 1.To turn a given tone on, press the Select soft key or the key. A check mark displays in front of the option. 2.To turn a given tone off, press the Select soft key or the key. The check mark no longer displays in front of the option. The following options are available: • Indicative tones: sets whether or not the phone informs you when you have made a mistake. • Minute minder: sets whether or not the phone beeps every minute during an outgoing call to keep you informed of the length of your call. • Connect tone: sets whether or not the phone beeps when your call is connected to the system. Phone Settings In this menu, you can customize your phone’s various settings, such as: x495.book Page 89 Thursday, August 18, 2005 12:23 PM Section 8 90 • Time and Date • Display settings • Get More Help • Greeting message • Language • Security • Extra settings • Reset settings • Network services Time & Date This menu allows you to change the current time and date displayed. You can also find out what time it is in another part of the word. The following options are available: • Set date: allows you to enter the month, day, and year. • World time: allows you to find out what time it is another part of world, using the Left and Right Navigation keys. Note: Before setting the time, you must specify your time zone in the World time menu. The screen shows the: • city name. • current time and date. • city selected as your time zone. To select your time zone: x495.book Page 90 Thursday, August 18, 2005 12:23 PM Section 8: Changing Your Settings91 Phone Settings Section 8 1.Select the city corresponding to your …

Text truncated - open the document above for the full version.















































August 30         !"# $%&' ( &) "*   +,-   . / (0+1+//2(34 (5 /5 ///5 /4(0+1+// 2( 34(5555,4  .(5(65(5 / (5 1 # )57/(5)8 )94144 *4    1    1: ;&/ 1&19<;3<4




















































August 30


!
 ""
 ""
#$%"
 &
'
()
*+  !

, !
 "-

)


 .
/01
#
 23!

.
A3LSGHX495H , $
5
 5!

1  " .


 !
6
2)
5
 ,
)(
/01
#
 2
3!
  -
 $

 5!
5

' +
7"

7"

 %
8
3

 !
*%
 %
"
5

-9
%%  2

:
! "

!  !
  "
 !
$%"
! %
 !
  !
 5 "

-

% !
6
/01
#
 2
3!
 !
-  7
% %

 5!
 !

  "
! 7
 !
 6
6  !




7
%- 2




! 7


-
5 "
6
5
  7
% !
6

/01

#
 2
3!
 !


 5 "
6  !
-
5
- 5


 "%
 !


!
5

 5 "


! "
6  !
7
 "%

 5
! 7


"+ 2







;"
<
"
=
3-
/01
#
"
0





















































































August 30, 2005

!
 ""
 ""
 #
 !
$
%
$&'"
 #
(
)*
+,  !

- !
 ".

*



 /
012
$
 %
3!%

/
A3LSGHX495H - &
5
 67 "
 5!


7
8 "


   /


 !
9
%*)
 !
%*
5
 -
*)
012
$
 %
3!%
 &
 6  "
 5!
5


'
'
:
'

'
 !
 ;
"
5

 !

 ' %

7
! "

!  !
  "
 !
&'"
! '
 !
  !
 5 "
.

' !
9
012
$
 %3!

 !

.
' '
 5!
 !

  "
! <
 !
 9
9  !




<
'. %


! <


.
5 "
9
5
  <
' !
9

012
$
 %
3!
5


 5 "
9  !
.
5
. 5


 "'
 !


!
5

 5 "


! "
9  !
<

 "'

 5
! <


", %






="
>
"
?
3.
012
$
"
1%

SAMSUNG ELECTRONICS AMERICA, INC. American QA Lab 18600 Broadwick St. Rancho Dominguez, CA 90220 DATE : September 6, 2005 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: A3LSGHX495H Subject: HAC filing Gentlemen: We, Samsung Electronics, hereby declare the samples evaluated in this application are equivalent to production samples. Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely, Steve Kim General Manager American QA Lab SAMSUNG Electronics America INC.

© 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHX495H Single-Band PCS GSM Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHX495H Single-Band PCS GSM Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHX495H Single-Band PCS GSM Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHX495H Single-Band PCS GSM Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHX495H Single-Band PCS GSM Phone

© 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHX495H Single-Band PCS GSM Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHX495H Single-Band PCS GSM Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHX495H Single-Band PCS GSM Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHX495H Single-Band PCS GSM Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHX495H Single-Band PCS GSM Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHX495H Single-Band PCS GSM Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHX495H Single-Band PCS GSM Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHX495H Single-Band PCS GSM Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHX495H Single-Band PCS GSM Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHX495H Single-Band PCS GSM Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHX495H Single-Band PCS GSM Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHX495H Single-Band PCS GSM Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHX495H Single-Band PCS GSM Phone

1 of 25 SAMSUNG ELECTRONICS Co., Ltd., Regulatory Compliance Team IT R&D Center 416, Maetan-3dong, Yeongtong-gu, Suwon-si, Gyeonggi-do, Korea 443-742 TEST REPORT ON SAR Model Tested: SGH-X495H FCC ID (Requested): A3LSGHX495H Job No: FC-111 Report No: FC-111-S1/2 Date issued: Aug. 29, 2005 Supplement Test Report FC-111-S1, dated Aug 18, 2005. The test results contained in this report supersede those. - Abstract – This document reports on SAR Tests carried out in accordance with FCC/OET Bulletin 65, Supplement C(July 2001). Prepared By Date KS AN - Test Engineer Checked By Date SH PARK - Senior Manager Authorized By Date JK CHOI - General Manager 2005.08.30 2005.08.30 2005.08.30 Report Number : FC-111-S1/2 2 of 25 Contents 1. General Information.............................................................................................3 2. Description of Device...........................................................................................3 3. Description of Test Equipment..............................................................................4 3.1 SAR Measurement Setup.........................................................................................4 3.2 DASY4 E-Field Probe.............................................................................................5 3.3 SAM Phantom.....................................................................................................6 3.4 Brain & Muscle Simulating Mixture Characterization.......................................................7 3.5 Device Holder for transmitters....................................................................................8 3.6 Validation Dipole....................................................................................................8 3.7 Equipment Calibration.............................................................................................9 4. SAR Measurement Procedure.............................................................................10 5. Description of test position..............................................................................11 5.1 SAM Phantom Shape.............................................................................................11 5.2 Cheek/Touch Position............................................................................................11 5.3 Ear/Tilt 15 Position..............................................................................................13 5.4 Body/Holster/Belt Clip Configuration..........................................................................14 6. Measurement Uncertainty...................................................................................16 7. System Verification............................................................................................17 7.1 Tissue Verification.................................................................................................17 7.2 Test System Validation...........................................................................................17 8. SAR Measurement Results.................................................................................18 8.1 Measurement Results(GSM1900 Right Head SAR-Touch)............................................19 8.2 Measurement Results(GSM1900 Right Head SAR-Tilt)................................................20 8.3 Measurement Results(GSM1900 Left Head SAR-Touch)..............................................21 8.4 Measurement Results(GSM1900 Left Head SAR-Tilt)..................................................22 8.5 Measurement Results(GPRS1900 Body SAR w/o Holster)..........................................23 9. Conclusion.......................................................................................................24 10. Reference.......................................................................................................25 Report Number : FC-111-S1/2 3 of 25 1. GENERAL INFORMATION Test Sample : Single-Band PCS GSM Phone Model Number : SGH-X495H Serial Number : Identical prototype (S/N : FC-111-F) Manufacturer : SAMSUNG ELECTRONICS Co., Ltd. Contact : IT LEE, Engineer Phone : +82-31-279-7145 Fax : +82-31-279-4288 Test Standard : §2.1093; FCC/OET Bulletin 65, Supplement C(July 2001) FCC Classification : Licensed Portable Transmitter Held to Ear (PCE) Test Dates : Aug. 25, 2005 Tested for : FCC/TCB Certification 2. DESCRIPTION OF DEVICE Tx Freq. Range : 1850.20 – 1909.80 MHz (GSM1900) Rx Freq. Range : 1930.20 – 1989.80 MHz (GSM1900) Max. RF Output Power : 1.219 W EIRP GSM1900 (30.86dBm) Antenna Manufacturer : Samsung electro-mechanics Model No.: IAPT0GDP4020HA Antenna Dimensions : 38mm × 15mm × 6.5mm [Intenna] Report Number : FC-111-S1/2 4 of 25 3. DESCRIPTION OF TEST EQUIPMENT 3.1 SAR Measurement Setup Robotic System Measurements are performed using the DASY4 automated dosimetric assessment system. Which is made by Schmid & Partner Engineering AG (SPEAG) in Zurich, Switzerland and consists of high precision robotics system (Stäubli), robot controller, measurement server, Samsung computer, near- field probe, probe alignment sensor, and the SAM twin phantom containing the brain equivalent material. The robot is a six-axis industrial robot performing precise movements to position the probe to the location (points) of maximum electromagnetic field (EMF) (see Fig. 3.1). Figure 3.1 SAR Measurement System Setup System Hardware A cell controller system contains the power supply, robot controller, teach pendant (Joystick), and a remote control is used to drive the robot motors. The PC consists of the Samsung computer with Windows XP system and SAR Measurement Software DASY4, LCD monitor, mouse and keyboard. The Stäubli Robot is connected to the cell controller to allow software manipulation of the robot. A data acquisition electronic (DAE) circuit that performs the signal amplification, signal multiplexing, AD-conversion, offset measurements, mechanical surface detectio…

Text truncated - open the document above for the full version.

APPENDIX G Plots of The SAR Measurements SAMSUNG FCC ID : A3LSGHX495H 1900MHz GSM1900 Head SAR DUT: SGH-X495H; Serial: FC-111-F Program Name: SGH-X495H GSM1900 Right (Job No. : FC-111) Proce…

Text truncated - open the document above for the full version.
